Chapter1Introduction
RS-400-SF is equipped with the SMB-2501, an ATX
size Pentium 4 motherboard, designed for high-density
Internet services, CT and industrial automation. The
serverboard uses a highly integrated core logic chipset,
SIS650 chipset with a high performance host interface for
Intel Pentium 4 processor, a high performance 2D/3D
Graphic Engine, a high performance memory controller and
an AGP 4X interface. The SiS 650 integrated a high
performance 2D/3D Graphic Engine, Video Accelerator and
Advanced Hardware Acceleration MPEGI/MPEGII Video
Decoder for the Intel Pentium 4 series based PC systems. It
also integrates a high performance 2.1GB/s DDR266
Memory controller to sustain the bandwidth demand from
the integrated GUI or external AGP master, host processor,
as well as the multi I/O masters. In addition to the integrated
GUI, the SiS650 can also support external AGP slot with
AGP 4X capability and Fast Write Transactions. The
SiS650 adopts a Shared Memory Architecture, eliminating
the need and thus the cost of the frame buffer memory by
organizing it in the system memory. The frame buffer size
can be allocated from 8MB to 64MB. The Integrated GUI
features a high performance 3D accelerator with 2 Pixel / 4
Texture, and a 128 bit 2D accelerator with 1T pipeline

RS-400-SF User’s Manual
12
BITBLT engine. It also features a Video Accelerator and
advanced hardware acceleration logic to deliver high quality
DVD playback.
The RS-400-SF has 1 AGP 4X slot, 2 PCI slots, 4 ISA
slots and 1 CNR slot for function expansion. It supports
maximum 5 add-on cards for PCI slots and ISA slots. ISA
bus support PIO mode only, doesn’t support DMA mode.
CNR slot supports modem only.
The SIS650 currently supports processor front bus
(PSB) 400MHz. The RS-400-SF will support PSB 533MHz
once it upgrades to the SIS651 chipset.

RS-400-SF User’s Manual 13
1.1HardwareSpecifications
CPU Intel® Pentium® 4/
Celeron CPU
Max. Speed 2.4GHz / 1.8GHz
L2 Cache 512 KB/128 KB
Chipset SIS 650
Processor
BIOS Award 2 Mb Flash
FSB 400 MHzBus
PCI 32-bit/33 MHz
Technology DDR-266 SDRAM
Max. Capacity 3 GB
Memory
Socket DDR-266 DIMM x 3
Controller SIS 650 with AGP 4XGraphic
VRAM Shares with system memory
up to 4/8/16/32/64MB
Interface 10/100 Base-TX
Controller Intel 82559ER x2
Ethernet
Connector RJ-45 x2
AGP 1 AGP 4X slot
PCI 2 PCI bus slots
ISA 4 ISA bus slots*
Expansion
CNR 1 CNR slot**
3.5” HDD 1 swappable HDD cartridge
2 fixed HDD bay
3.5” FDD 1
Drive Bay
5.25”CD-ROM 1 (52X speed)
USB 2
Serial 2 (RS-232)
Parallel 1 (Accessory)
PS/2 2 (mouse x1, keyboard x1)
I/O Interface
CRT 1

RS-400-SF User’s Manual
14
Cooling Fan 2 (86 CFM, 37CFM)
Operating
System
Compatibility Windows 98/ME/2000/XP,
Linux Red Hat 7.x,
FreeBSD 4.x, QNX R6.1
Management Indicator LED for power, LANs and
HDDs
MiscellaneousControl Momentary power switch
Watt 300W or 400 W ATXPower
Supply Input AC 90 ~ 264 V Full Range
@47 ~ 63 Hz
Operating
Non-Operating
Temperature 0 ~ 50 °C(32 ~ 122 °F)
-20 ~ 70 °C(-68 ~ 158 °F)
Environment
Humidity 5 ~ 85 % @40 °C (104 °F)
5 ~ 95 %
Physical Dimension
(W x H x D)
482 x 177 x 502 mm
(19” x 7” x 19.76”)
Weight 20.5 kg (45.1 lb)
Note: * ISA slot doesn’t support DMA mode
** CNR slot supports Modem only
*** SIS651 supports PSB 400/533MHz. Motherboard
A103-1 version supports FSB 533.
RS-400-SFsupports 300W ATX Power
RS-400-SF-S4 supports 400W ATX power

RS-400-SF User’s Manual 15
1.2SoftwareSpecifications
OS support: Windows 98/ME/XP/2000
RedHatLinux6.x/7.x
FreeBSD 4.x, QNX R6.1
* No support for Win NT Series

RS-400-SF User’s Manual
16
1.3 Environmental Specifications
• Operating temperature: 0 ~ 50° C
• Storage temperature: -40 ~ 75° C (-40 ~ 167° F)
• Operating Humidity: 10 ~ 85% @ 40℃
• Storage Humidity: 5~95%

RS-400-SF User’s Manual 17
Chapter 2 Placement and Installation
2.1SystemPlacement
2.1.1 Frontal View
CD-ROMdrive
Reset HDD cartridge*
FDDdrive
AirFilter Powerswitch HDDbay**
Note:
*- Please refer to mobile rack manual in accessory box.
**- Please refer to section 2.2 “adding your disk drives” in
the manual of IPC-610F Industrial Chassis. When you
install HDD drive, it is necessary to fix HDD bracket in
accessory box on the two sides of the HDD drive first.

RS-400-SF User’s Manual
18
2.1.2 Rear View
Powerswitch PS/2 VGA LAN
Powersocket USB RS-232 Expansion

RS-400-SF User’s Manual 19
2.1.3 Top View
Hold-down Clamp Fan Power Supply
Motherboard
FAN Air Filter
Please refer to IPC-610 Manual (IPC-610MB) for more information
about it mechanism.
