Advantech ASMB-815 Series Installation and operation manual

ASMB-815 Startup Manual 1
Before you begin installing your card, please make sure
that the following items have been shipped:
• 1 ASMB-815 Startup Manual
• 1 Driver CD
• 2 Serial ATA HDD data cables
• 2 Serial ATA HDD power cables
• 2 CPU power cables (8P)
• 1 I/O port bracket
• 1 Warranty card
If any of these items are missing or damaged, please
contact your distributor or sales representative immediately.
Note 1: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
https://www.adobe.com/downloads.html
(Acrobat is a trademark of Adobe)
ASMB-815 Series LGA 3647 Intel Xeon® Processor Scalable
Family Server Board with 6 DDR4, 5 PCIe x8 or 2 PCIe x16
and 1 PCIe x8, 8 SATA3, 6 USB3.0, Dual 10GbE, IPMI
Startup Manual
Standard M/B Functions
• CPU: LGA3647-P0 Intel Xeon® Processor scalable family
series
• BIOS: AMI 256 Mb SPI BIOS
• Chipset: Intel® C622 PCH
• System Memory: 6* DDR4-1866/2133/2400/2666
Registered ECC DIMM, Max. Capacity 192 GB
Note 2: Due to the inherent limitations of the PC architec-
ture, the system may not fully detect 192 GB
RAM when 192 GB RAM is installed.
• SATA Interface: 8 SATA3 6 Gb/s ports Intel Rapid
Storage (for Windows only) (SATA0-SATA7 supports
software RAID 0, 1, 10 & 5)
• Serial Ports: One onboard header, only supports RS-232
• Keyboard/Mouse Header (KBMS2): Supports the stan-
dard PS/2 keyboard and mouse via PS/2 cable
• Watchdog Timer: 255 level timer intervals
• USB Port: Supports up to 6 USB 3.0 ports (2 ports from
onboard 20-pin header) and 7 USB 2.0 ports (1*Type-A,
4 ports from onboard 10-pin header)
VGA Interface
• Chipset: ASPEED AST2500/2510
• Display Memory: 64 MB
• Resolution: Supports VGA up to resolution 1920 x 1200
@ 60 Hz refresh rate
Ethernet Interface
• Interface: 10/100/1000 Mbps & 10 GbE Base-T
• Controller: LAN1/2: Intel I210; LAN3/4: Intel X557
Mechanical and Environment
• Dimensions (L x W): 244 x 304 mm (9.6” x 12”)
• Power Supply Voltage: +3.3 V, +5 V, ±12 V, +5 Vs
• Power Consumption (mainboard only, excluding IO
device): Max. load: +3.3 V @ 2.77 A, +5 V@ 7.01 A,
+12 V @ 0.58 A,+5 Vsb @ 013 A, -12 V@ 0.06 A,
12V_8P @ 17.58A
• Operating Temperature: 0 ~ 60° C (depending on CPU)
• Weight: 0.91 kg (weight of board)
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our
support website at:
http://support.advantech.com
This manual is for the ASMB-815 series Rev. A1
Part No. 2001815I10
Print in China
1st Edition
July 2017

2 ASMB-815 Startup Manual
The board has a number of jumpers that allow you to con-
figure your system to suit your application. The table below
lists the function of each of the jumpers and connectors.
Connectors
Label Function
ATXPWR1 ATX 24 Pin main power connector
ATX12V1 Processor power connector
(for CPU0)
BH2 For optional battery kit
BIOS_SKT1 BIOS SPI ROM
BMC_CN1, BMC_CN2 IPMI module header
COM2 Serial port: RS-232
CPUFAN0 CPU FAN connector
DIMMA1, DIMMB1,
DIMMC1, DIMMD1,
DIMME1, DIMMF1
DDR4 slot
EX_THR1 Connector for external thermistor
GPIO1 GPIO connector
HDAUD1 Audio header
JFP1, JFP2, JFP3 Front panel header
KBMS2 External keyboard and mouse
connector (6-pin)
LAN1_2, LAN3_4 RJ-45 LAN connector
LANLED1 LAN LED extension connector
LPC1 TPM connector
M2_2280 M.2 connector (SATA & PCIe x4)
PMBUS1 PMBUS connector to communi-
cate with power supply
SATA0~SATA7 Serial ATA0~7
SGPIO1 SATA SGPIO header
SLOT1 PCIE x1 slot (x1 link) (PCH)
SLOT2 PCIE x4 slot (x4 link) (CPU)
SLOT3 PCIE x8 slot (0 or x8 link) (CPU)
SLOT4 PCIE x16 slot (x16 or x8 link)
(CPU)
SLOT5 PCIE x8 slot (0 or x8 link) (CPU)
SLOT6 PCIE x16 slot (x16 or x8 link)
(CPU)
SLOT7 PCIE x8 slot (x8 link) (CPU)
SMBUS1 SMBus header
Jumpers and Connectors (Cont.)
SPI_CN1 Connector for BIOS update tool
SPI_SKT1 EC EEPROM
SYS_LED1 System LED connector
SYSFAN0~SYSFAN4 System FAN connector
USB1_2, USB9_10,
USB13_14
USB 2.0 port 1, 2; USB 2.0 port
9, 10, 13, 14 (9-pin header)
USB11 USB 2.0 port 11 (Type-A)
USB3_12, USB3_34,
USB3_56
USB 3.0 port 1, 2, 3, 4; USB 3.0
port 5, 6 (20-pin header)
VGA1_COM1 VGA + COM connector
VOLT1 Voltage display
VROC1 Intel Virtual RAID (VROC) key
Jumper list
Label Function
JCASE1 Chassis case open alarm
JCMOS1 CMOS clear
JME1 ME update
JSKTOCC1 To force power when no CPU installed:
Normal (1-2)/Debug (2-3)
JTHR_SEL To select on board or external thermis-
tor
JWDT1 Watch Dog Reset
PSON1 AT(1-2) / ATX(2-3)
JCMOS1/JME1: CMOS clear/ME update function
Closed pins Result
1-2 Keep CMOS data/Disable ME update*
2-3 Clear CMOS data/Enable ME update
*: Default
Keep CMOS data/Disable ME update Clear CMOS data/Enable ME update
1 2 3
1 2 3
Jumpers and Connectors

ASMB-815 Startup Manual 3
The CD disc contains a driver installer program that will
lead you through the installation of various device drivers
needed to take full advantage of your motherboard.
The computer is supplied with a battery-powered realtime
clock circuit. There is a danger of explosion if battery is
incorrectly replaced. Replace only with same or equivalent
type recommended by the manufacturer. Discard used
batteries according to manufacturer’s instructions.
The device complies with the requirements in Part 15 of
the FCC rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference;
2. This device must accept any interference received,
including interference that may cause undesired
operation.
JFP1, JFP2
Pin.3 #PWR_SW
Pin.6 GND
Pin.9 #RST_SW
Pin.12 GND
Pin.8, Pin.11 HWM_SMB_DATA, HWM_SMB_CLK
*Power button pin is located in Pin 3 & 6 of front panel
connector.
3 6 9 12 PWRSW RESET
HDDLED
SNMP
JFP1
&
1(+) 4 7 10(-)
HDDLED
SM_BUS
SPEAKER
JPF2
&
PWRLED & KEYLOCK
1(+) 23(-) 45JFP3
2(+) 5(-) 8 11
Software Installation
Declaration of Conformity
Figure 1: Board Layout: Jumper and Connector Locations
HDAUD1
COM2
KBMS2
USB11
USB13_14
USB3_56
SATA0
SATA1
SATA2
PCH
SPI_SKT1
SATA3
M2_2280 GPIO1
JWDT1 SATA4
USB9_10
EX_THR1 SATA6
SATA7
SATA5
JCMOS1 JME1
SGPIO1
JFP3
JFP1+JFP2
JCASE1
SMBUS1
LANLED1
PSON1
SYSFAN3
SYS
_LED1
LPC1
JTHR_SEL1
VOLT1
VROC1
SYS
FAN2
SPI
_CN1
BIOS
_SKT1
SYS
FAN1
SLOT12V1
CPU
FAN0
JSKTOCC1 SYSFAN0
PMBUS1
BH1
BH2
DIMMA1
DIMMB1
DIMMC1
DIMMF1
DIMME1
DIMMD1
Intel LGA3647 CPU0
ATX12V1
ATXPWR1
SYSFAN4
PCIEX1
_SLOT1
PCIEX4
_SLOT2
BMC_CN2
PCIEX8
_SLOT3
BMC_CN1
PCIEX16
_SLOT4
PCIEX8
_SLOT5
PCIEX16
_SLOT6
PCIEX8
_SLOT7
LAN5_
USB3_34
LAN3_4
LAN2_
USB3_12
LAN1_
USB1_2
VGA1_COM1
Installation Note
Board Layout
