ADVANTEST R3267 series User manual

MANUAL NUMBER
CPrinted in Japan
ADVANTEST CORPORATION
All rights reserved.
R3267 Series OPT62
3GPP Measurement Option
Operation Manual
FOE-8370669G00
1999 First printing December 20, 1999
Applicable Models
R3264
R3267
R3273
Cover

No. ESF00
Safety-1
Safety Summary
To ensure thorough understanding of all functions and to ensure efficient use of this instrument, please read the
manual carefully before using. Note that Advantest bears absolutely no responsibility for the result of operations
caused due to incorrect or inappropriate use of this instrument.
If the equipment is used in a manner not specified by Advantest, the protection provided by the equipment may
be impaired.
• Warning Labels
Warning labels are applied to Advantest products in locations where specific dangers exist. Pay
careful attention to these labels during handling. Do not remove or tear these labels. If you have
any questions regarding warning labels, please ask your nearest Advantest dealer. Our address
and phone number are listed at the end of this manual.
Symbols of those warning labels are shown below together with their meaning.
DANGER: Indicates an imminently hazardous situation which will result in death or serious
personal injury.
WARNING: Indicates a potentially hazardous situation which will result in death or serious
personal injury.
CAUTION: Indicates a potentially hazardous situation which will result in personal injury or
a damage to property including the product.
• Basic Precautions
Please observe the following precautions to prevent fire, burn, electric shock, and personal inju-
ry.
• Use a power cable rated for the voltage in question. Be sure however to use a power cable
conforming to safety standards of your nation when using a product overseas.
• When inserting the plug into the electrical outlet, first turn the power switch OFF and then
insert the plug as far as it will go.
• When removing the plug from the electrical outlet, first turn the power switch OFF and then
pull it out by gripping the plug. Do not pull on the power cable itself. Make sure your hands
are dry at this time.
• Before turning on the power, be sure to check that the supply voltage matches the voltage
requirements of the instrument.
• Be sure to plug the power cable into an electrical outlet which has a safety ground terminal.
Grounding will be defeated if you use an extension cord which does not include a safety
ground terminal.
• Be sure to use fuses rated for the voltage in question.
• Do not use this instrument with the case open.
• Do not place objects on top of this product. Also, do not place flower pots or other containers
containing liquid such as chemicals near this product.
Safety Summary

Safety Summary
Safety-2
• When the product has ventilation outlets, do not stick or drop metal or easily flammable ob-
jects into the ventilation outlets.
• When using the product on a cart, fix it with belts to avoid its drop.
• When connecting the product to peripheral equipment, turn the power off.
• Caution Symbols Used Within this Manual
Symbols indicating items requiring caution which are used in this manual are shown below to-
gether with their meaning.
DANGER: Indicates an item where there is a danger of serious personal injury (death or seri-
ous injury).
WARNING: Indicates an item relating to personal safety or health.
CAUTION: Indicates an item relating to possible damage to the product or instrument or relat-
ing to a restriction on operation.
• Safety Marks on the Product
The following safety marks can be found on Advantest products.
: ATTENTION - Refer to manual.
: Protective ground (earth) terminal.
: DANGER - High voltage.
: CAUTION - Risk of electric shock.
• Replacing Parts with Limited Life
The following parts used in the instrument are main parts with limited life.
Replace the parts listed below after their expected lifespan has expired.
Note that the estimated lifespan for the parts listed below may be shortened by factors such as
the environment where the instrument is stored or used, and how often the instrument is used.
The parts inside are not user-replaceable. For a part replacement, please contact the Advantest
sales office for servicing.
There is a possibility that each product uses different parts with limited life. For more informa-
tion, refer to Chapter 1.

Safety Summary
Safety-3
Main Parts with Limited Life
• Hard Disk Mounted Products
The operational warnings are listed below.
• Do not move, shock and vibrate the product while the power is turned on.
Reading or writing data in the hard disk unit is performed with the memory disk turning at a
high speed. It is a very delicate process.
• Store and operate the products under the following environmental conditions.
An area with no sudden temperature changes.
An area away from shock or vibrations.
An area free from moisture, dirt, or dust.
An area away from magnets or an instrument which generates a magnetic field.
• Make back-ups of important data.
The data stored in the disk may become damaged if the product is mishandled. The hard disc
has a limited life span which depends on the operational conditions. Note that there is no
guarantee for any loss of data.
• Precautions when Disposing of this Instrument
When disposing of harmful substances, be sure dispose of them properly with abiding by the
state-provided law.
Harmful substances: (1) PCB (polycarbon biphenyl)
(2) Mercury
(3) Ni-Cd (nickel cadmium)
(4) Other
Items possessing cyan, organic phosphorous and hexadic chromium
and items which may leak cadmium or arsenic (excluding lead in sol
der).
Example: fluorescent tubes, batteries
Part name Life
Unit power supply 5 years
Fan motor 5 years
Electrolytic capacitor 5 years
LCD display 6 years
LCD backlight 2.5 years
Floppy disk drive 5 years

Environmental Conditions
Safety-4
This instrument should be only be used in an area which satisfies the following conditions:
• An area free from corrosive gas
• An area away from direct sunlight
• A dust-free area
• An area free from vibrations
Figure-1 Environmental Conditions
• Operating position
Figure-2 Operating Position
• Storage position
Figure-3 Storage Position
This instrument can be used safely under the following conditions:
• Altitude of up to 2000 m
• Installation Categories II
• Pollution Degree 2

























Vibration
Direct sunlight
Corrosive
gas
Dust
Front
Keep at least 10 centimeters of space
between the rear panel and any other
surface
Front
This instrument should be stored in a horizontal
position.
When placed in a vertical (upright) position for
storage or transportation, ensure the instrument is
stable and secure.
-Ensure the instrument is stable.
-Pay special attention not to fall.

R3267 Series OPT62 3GPP Measurement Option Operation Manual
Preface-1
PREFACE
This manual provides the information necessary to check functionality, operate and program the R3267 Series Op-
tion 62, 3GPP measurement.
(1) Organization of this manual
This manual consists of the following chapters:
Safety Summary To use the analyzer safely, be sure to read
this manual first.
1. Introduction
• Product Description (Option)
• Standard Accessories
• Self Test Error
• Connectors on the rear panel
Includes a description of the option and
its’ parts and a self test error.
2. Operation You can learn the basic operations of the
option through the examples shown in this
chapter.
3. Reference
• Menu Index
• Menu Map
• Functional Description
Shows a list of operation keys, and
describes the function of each key.
4. Remote Control
•GPIB
Included area list of commands necessary
for programming.
5. Technical Information
• Template Edit Function
• Measurement Parameter Settings in Due to Transient, Due to
Modulation and Inband Spurious
• Mag Error (Magnitude Error)
• Phase Error
• E.V.M. (Error Vector Magnitude)
• About a ρ
• About a Code Domain Power coefficient
• About the Carrier Frequency Error of QPSK
• Block Diagram
Describes the principle of operation nec-
essary for taking measurements more
accurately.
6. Performance Verification Test Describes how to test performance.
7. Specifications Shows the specifications of the option.
APPENDIX
•Messages
If an error occurs during operation, an
error number and its corresponding error
message are displayed. The meaning of
each error is explained in this section.
PREFACE

R3267 Series OPT62 3GPP Measurement Option Operation Manual
Preface
Preface-2
(2) Typeface conventions used in this manual
• Panel keys and soft keys are printed in a contrasting typeface to make them stand out from the text as
follows:
Panel keys: Boldface type Example: TRANSIENT
Soft keys: Boldface and italic type Example: T-Domain, Detector
• When a series of key operations are described using a comma between two keys.
• There are various soft menus used to switch between two states such as ON/OFF and AUTO/MNL.
For example, when turning off the Window ON/OFF function, the annotation “Window ON/
OFF(OFF)” is used.

R3267 Series OPT62 3GPP Measurement Option Operation Manual
C-1
TABLE OF CONTENTS
1 INTRODUCTION
........................................................................................... 1-1
1.1 Product Overview ................................................................................................ 1-1
1.2 Accessories .......................................................................................................... 1-1
1.3 Self Test Function ................................................................................................ 1-1
1.4 About Calibration ................................................................................................ 1-1
1.5 Explanation of the Connectors ............................................................................ 1-2
2 MEASUREMENT EXAMPLES
................................................................. 2-1
2.1 Measuring the BTS 3GPP Signals ....................................................................... 2-1
2.1.1 Measuring the Slot ........................................................................................ 2-1
2.1.2 Measuring the Frame .................................................................................... 2-6
2.2 Measuring the MS 3GPP Signal .......................................................................... 2-9
2.2.1 Measuring the Slot ........................................................................................ 2-9
2.2.2 Measuring of the Frame ................................................................................ 2-13
2.3 Graphical Display of 3GPP Measurements ......................................................... 2-16
2.4 Measuring a QPSK Signal ................................................................................... 2-21
2.5 Power vs Time ..................................................................................................... 2-24
2.5.1 Measuring Power Variations Using the External Trigger ............................ 2-24
2.5.2 Measuring Power Variations Using the IF Trigger ...................................... 2-27
2.6 CCDF Measurement ............................................................................................ 2-31
2.7 Measuring Primary CPICH Power ...................................................................... 2-35
3 REFERENCE
.................................................................................................... 3-1
3.1 Menu Index .......................................................................................................... 3-1
3.2 Menu Map ........................................................................................................... 3-7
3.3 Functional Description ........................................................................................ 3-26
3.3.1 Switching Communication Systems ............................................................. 3-27
3.3.2 T-Domain ...................................................................................................... 3-28
3.3.2.1 Power (T-Domain) ...................................................................................... 3-28
3.3.2.2 ON/OFF Ratio ............................................................................................. 3-31
3.3.2.3 Spurious (T-Domain) .................................................................................. 3-34
3.3.3 F-Domain ...................................................................................................... 3-37
3.3.3.1 Power (F-Domain) ...................................................................................... 3-37
3.3.3.2 OBW ........................................................................................................... 3-40
3.3.3.3 Due to Transient .......................................................................................... 3-42
3.3.3.4 Due to Modulation ...................................................................................... 3-45
3.3.3.5 Inband Spurious (1) .................................................................................... 3-49
3.3.3.6 Inband Spurious (2) .................................................................................... 3-52
3.3.3.7 Outband Spurious ....................................................................................... 3-55
3.3.4 Modulation .................................................................................................... 3-57
3.3.4.1 3GPP ........................................................................................................... 3-57
TABLE OF CONTENTS

R3267 Series OPT62 3GPP Measurement Option Operation Manual
Table of Contents
C-2
3.3.4.2 QPSK .......................................................................................................... 3-76
3.3.4.3 Power .......................................................................................................... 3-79
3.3.4.3.1 Tx Power ................................................................................................ 3-79
3.3.4.3.2 Power vs Time ........................................................................................ 3-80
3.3.4.3.3 CCDF ..................................................................................................... 3-83
3.3.4.3.4 P-CPICH Power ..................................................................................... 3-84
3.3.4.4 Time & FFT ................................................................................................ 3-86
3.3.4.5 STD ............................................................................................................. 3-87
4 REMOTE CONTROL
.................................................................................... 4-1
4.1 GPIB Command Index ........................................................................................ 4-1
4.2 GPIB Command Codes ....................................................................................... 4-10
5 TECHNICAL INFORMATION
.................................................................. 5-1
5.1 Template Edit Function ....................................................................................... 5-1
5.1.1 Template Setting in the T-Domain Measuring Mode ................................... 5-1
5.1.2 Template Setting in the F-Domain Measuring Mode ................................... 5-3
5.2 Measurement Parameter Settings in Due to Transient,
Due to Modulation and Inband Spurious ............................................................. 5-4
5.2.1 Marker Edit Function .................................................................................... 5-4
5.2.2 Measurement results Using Due to Modulation,
Due to Transient and Inband Spurious Modes .............................................. 5-5
5.2.3 Measurement Result of Inband Spurious ...................................................... 5-6
5.3 Mag Error (Magnitude Error) .............................................................................. 5-7
5.4 Phase Error .......................................................................................................... 5-7
5.5 E.V.M. (Error Vector Magnitude) ....................................................................... 5-8
5.6 Waveform Quality ............................................................................................... 5-9
5.7 About a Code Domain Power coefficient ............................................................ 5-9
5.8 About the Carrier Frequency Error of QPSK ...................................................... 5-9
5.9 Block Diagram ..................................................................................................... 5-10
6 PERFORMANCE VERIFICATION TEST(3GPP)
................................ 6-1
6.1 General ................................................................................................................ 6-1
6.1.1 Introduction ................................................................................................... 6-1
6.1.2 Test Equipment ............................................................................................. 6-2
6.1.3 Specifications Required for Test Signals ...................................................... 6-3
6.1.4 Calibration Cycle .......................................................................................... 6-4
6.1.5 Performance Verification Test Record Sheets .............................................. 6-4
6.1.6 Performance Verification Procedure ............................................................ 6-4
6.2 Performance Verification Test Procedure ........................................................... 6-5
6.2.1 Down Link Measurement in RF Input .......................................................... 6-5
6.2.2 Up Link Measurement in RF Input ............................................................... 6-6
6.2.3 QPSK Measurement in RF Input .................................................................. 6-8

R3267 Series OPT62 3GPP Measurement Option Operation Manual
Table of Contents
C-3
6.2.4 Down Link Measurement in IQ Input ........................................................... 6-10
6.2.5 Up Link Measurement in IQ Input ............................................................... 6-11
6.2.6 QPSK Measurement in IQ Input ................................................................... 6-13
6.2.7 Simplified Performance Check ..................................................................... 6-14
6.3 Performance Verification Test Record Sheet ...................................................... 6-16
6.4 Performance Check Record Sheet ....................................................................... 6-18
7 SPECIFICATIONS
.......................................................................................... 7-1
APPENDIX ................................................................................................................ A-1
A.1 Messages .............................................................................................................. A-1
ALPHABETICAL INDEX .................................................................................... I-1

F-1
R3267 Series OPT62 3GPP Measurement Option Operation Manual
LIST OF ILLUSTRATIONS
No. Title Page
2-1 Setup for the measurement of the 3GPP signal ................................................................ 2-1
2-2 3GPP Signal’s Spectrum ...................................................................................................2-2
2-3 STD-Measurement parameter set Dialog Box .................................................................. 2-2
2-4 Parameter Setup [SLOT/DOWNLINK] Dialog Box ........................................................ 2-3
2-5 Measurement Result of 3GPP Signal ................................................................................ 2-5
2-6 Setup for the measurement of the 3GPP signal ................................................................ 2-6
2-7 3GPP Signal’s Spectrum ...................................................................................................2-6
2-8 Parameter Setup [FRAME/DOWNLINK] Dialog Box .................................................... 2-7
2-9 Setup for the measurement of the 3GPP signal ................................................................ 2-9
2-10 3GPP Signal’s Spectrum ................................................................................................... 2-10
2-11 Parameter Setup [SLOT/UPLINK] Dialog Box ............................................................... 2-11
2-12 Measurement Result of 3GPP Signal (UPLINK mode) ................................................... 2-12
2-13 Setup for the measurement of the 3GPP signal ................................................................ 2-13
2-14 3GPP Signal’s Spectrum ................................................................................................... 2-13
2-15 Parameter Setup [FRAME/UPLINK] Dialog Box ........................................................... 2-14
2-16 Graph Display (When Meas Mode Set to SLOT and Link Set to DOWNLINK) ............ 2-16
2-17 Graph Display (When Meas Mode Set to SLOT and Link Set to UPLINK) ................... 2-16
2-18 Graph Display (When Meas Mode Set to FRAME and Link Set to DOWNLINK) ........ 2-17
2-19 Variation over Time in the Code Domain Power Coefficient .......................................... 2-18
2-20 Constellation ..................................................................................................................... 2-18
2-21 Eye Pattern ........................................................................................................................ 2-19
2-22 Eye Pattern (Dual Screen Display) ................................................................................... 2-20
2-23 Setup for the measurement of the QPSK signal ............................................................... 2-21
2-24 QPSK Signal’s Spectrum ..................................................................................................2-21
2-25 Parameter Setup Dialog Box ............................................................................................. 2-22
2-26 QPSK Signal Measurement Result ................................................................................... 2-23
2-27 Setup for the measurement of the Power vs Time ............................................................ 2-24
2-28 3GPP Signal Spectrum under Control of Transmission Power ........................................ 2-25
2-29 Power vs Time Parameter Setup Dialog Box ................................................................... 2-26
2-30 Measurement Result of Power vs Time ............................................................................ 2-26
2-31 Setup for the measurement of the Power vs Time ............................................................ 2-27
2-32 3GPP Signal Spectrum under Control of Transmission Power ........................................ 2-28
2-33 Time & FFT Parameter Setup Dialog Box ....................................................................... 2-29
2-34 Power vs Time Parameter Setup Dialog Box ................................................................... 2-30
2-35 Setup for CCDF Measurement ......................................................................................... 2-31
2-36 3GPP Signal Spectrum under Control of Transmission Power ........................................ 2-32
2-37 CCDF Parameter Setup Dialog Box ................................................................................. 2-32
2-38 CCDF Measurement Result .............................................................................................. 2-33
2-39 CCDF Measurement Result (Trace Write ON) ................................................................ 2-34
2-40 Setup for Primary CPICH Power Measurement ............................................................... 2-35
2-41 3GPP Signal Spectrum ...................................................................................................... 2-36
2-42 STD Measurement Parameter Set Dialog Box ................................................................. 2-36
2-43 Parameter Setup Dialog Box ............................................................................................. 2-37
2-44 P-CPICH Power Measurement Results ............................................................................ 2-37
3-1 Communication Systems Dialog Box ............................................................................... 3-27

F-2
R3267 Series OPT62 3GPP Measurement Option Operation Manual
List of Illustrations
No. Title Page
3-2 Trigger Setup Dialog Box .................................................................................................3-28
3-3 Parameter Setup Dialog Box ............................................................................................. 3-30
3-4 Trigger Setup Dialog Box .................................................................................................3-31
3-5 Parameter Setup Dialog Box ............................................................................................. 3-33
3-6 Trigger Setup Dialog Box .................................................................................................3-34
3-7 Parameter Setup Dialog Box ............................................................................................. 3-35
3-8 Trigger Setup Dialog Box .................................................................................................3-37
3-9 Detector Dialog Box ......................................................................................................... 3-38
3-10 Parameter Setup Dialog Box ............................................................................................. 3-39
3-11 Parameter Setup Dialog Box ............................................................................................. 3-41
3-12 Parameter Setup Dialog Box ............................................................................................. 3-43
3-13 Trigger Setup Dialog Box ................................................................................................. 3-45
3-14 Detector Dialog Box ......................................................................................................... 3-46
3-15 Parameter Setup Dialog Box ............................................................................................. 3-47
3-16 Parameter Setup Dialog Box ............................................................................................. 3-50
3-17 Parameter Setup Dialog Box ............................................................................................. 3-53
3-18 Parameter Setup Dialog Box ............................................................................................. 3-56
3-19 Selecting the Unit of the Graph Horizontal Axis (for Channel Number) ......................... 3-58
3-20 Selecting the Unit of the Graph Horizontal Axis (for Time) ........................................... 3-58
3-21 Graph Type of Analysis Dialog Box ................................................................................ 3-59
3-22 Graph Type of Analysis Dialog Box ................................................................................ 3-60
3-23 3GPP User Channel Setting Dialog Box .......................................................................... 3-63
3-24 Parameter Setup [SLOT/DOWNLINK] Dialog Box ........................................................ 3-63
3-25 Explanation Diagram of MEAS Unit ................................................................................ 3-66
3-26 Parameter Setup [FRAME/DOWNLINK] Dialog Box .................................................... 3-67
3-27 Explanation Diagram of MEAS Slots ............................................................................... 3-69
3-28 Parameter Setup [SLOT/UPLINK] Dialog Box ............................................................... 3-70
3-29 Explanation Diagram of MEAS Unit ................................................................................ 3-72
3-30 Parameter Setup [FRAME/UPLINK] Dialog Box ........................................................... 3-73
3-31 Examination Diagram of Meas Slots ................................................................................ 3-74
3-32 Graphic Type of Analysis Dialog Box ............................................................................. 3-76
3-33 QPSK Measurement parameter set Dialog Box ............................................................... 3-77
3-34 Limit Setup Dialog Box .................................................................................................... 3-78
3-35 Parameter Setup Dialog Box ............................................................................................. 3-79
3-36 Scale Setup Dialog Box .................................................................................................... 3-80
3-37 Parameter Setup Dialog Box ............................................................................................. 3-81
3-38 Marker Setup Dialog Box .................................................................................................3-82
3-39 Template Setup Dialog Box .............................................................................................. 3-83
3-40 Scale Setup Dialog Box .................................................................................................... 3-83
3-41 Parameter Setup Dialog Box ............................................................................................. 3-84
3-42 Parameter Setup Dialog Box ............................................................................................. 3-85
3-43 Select Type Dialog Box .................................................................................................... 3-86
3-44 Parameter Setup Dialog Box ............................................................................................. 3-86
3-45 STD Measurement parameter Setup Dialog Box ............................................................. 3-87
5-1 Template to Be Set ............................................................................................................ 5-1
5-2 Template Settings ............................................................................................................. 5-2
5-3 Template Shifted Using the Shift Y Function .................................................................. 5-2

R3267 Series OPT62 3GPP Measurement Option Operation Manual
List of Illustrations
F-3
No. Title Page
5-4 Template with the Set Values ........................................................................................... 5-3
5-5 Template with Margin Delta X ......................................................................................... 5-3
5-6 Example of Marker Edit Setting (1) ................................................................................. 5-4
5-7 Example of Marker Edit Setting (2) ................................................................................. 5-5
5-8 Example of Peak Marker Y Delta ..................................................................................... 5-5
5-9 Mag Error, Phase Error, E.V.M. ....................................................................................... 5-8
5-10 Block Diagram .................................................................................................................. 5-10
6-1 Timing Chart ..................................................................................................................... 6-3
6-2 Setup of Down Link Measurement (RF Input) ................................................................. 6-5
6-3 Setting of Measurement Parameters for Down Link (RF Input) ...................................... 6-6
6-4 Setup of Up Link Measurement (RF Input) ...................................................................... 6-7
6-5 Setting of Measurement Parameters for Up Link (RF Input) ........................................... 6-8
6-6 Setup of QPSK Measurement (RF Input) ......................................................................... 6-9
6-7 Setting of Measurement Parameters for QPSK (RF Input) .............................................. 6-9
6-8 Setup of Down Link Measurement (IQ Input) .................................................................. 6-10
6-9 Setting of Measurement Parameters for Down Link (IQ Input) ....................................... 6-11
6-10 Setup of Up Link Measurement (IQ Input) ...................................................................... 6-12
6-11 Setting of Measurement Parameters for Up Link (IQ Input) ............................................ 6-12
6-12 Setup of QPSK Measurement (IQ Input) .......................................................................... 6-13
6-13 Setting of Measurement Parameters for QPSK (IQ Input) ............................................... 6-14
6-14 Setup of Simplified Performance Check .......................................................................... 6-15
6-15 Setting of Measurement Parameters for QPSK (RF Input) .............................................. 6-15

T-1
R3267 Series OPT62 3GPP Measurement Option Operation Manual
LIST OF TABLES
No. Title Page
4-1 Operating Mode ................................................................................................................ 4-10
4-2 ATT Key (Attenuator) ...................................................................................................... 4-10
4-3 COPY Key (Hard copy) .................................................................................................... 4-10
4-4 COUPLE Key (Couple function) ...................................................................................... 4-11
4-5 FREQ Key (Frequency) .................................................................................................... 4-11
4-6 LEVEL Key (Reference Level) ........................................................................................ 4-11
4-7 MKR Key (Marker) .......................................................................................................... 4-12
4-8 PRESET Key (Initialization) ............................................................................................ 4-12
4-9 RCL Key (Recall) ............................................................................................................. 4-12
4-10 SAVE Key (Save) ............................................................................................................. 4-13
4-11 SPAN Key (Frequency span) ............................................................................................ 4-13
4-12 TRANSIENT Key .............................................................................................................4-14
4-13 Numeric Keys/Step Keys/Data Knob/Unit Keys (Entering Data) .................................... 4-63
4-14 Miscellaneous ................................................................................................................... 4-64
6-1 Performance Verification Items ........................................................................................ 6-1
6-2 Equipment List .................................................................................................................. 6-2
6-3 Specifications Required for Test Signals .......................................................................... 6-3

R3267 Series OPT62 3GPP Measurement Option Operation Manual
1.1 Product Overview
1-1
1 INTRODUCTION
1.1 Product Overview
This 3GPP analysis option software allows you to measure the waveform quality and resolution accuracy of
a 3GPP signal.
This option is a factory option which is incorporated into the R3267 Series Spectrum Analyzer prior to ship-
ment.
This option includes the following features:
• Can measure the modulation accuracy, waveform quality, frequency error, and magnitude error of the
base station (BS) and mobile station (UE) signals.
• Can measure the code domain power of the BS and UE signals.
• Can be used to measure OBW or ACP due to Transient specified by the communication standard with a
simple key operation.
1.2 Accessories
1.3 Self Test Function
The self test also checks the Option 62 for correct operation when the spectrum analyzer power is turned on.
The message shown below will be displayed when an error related to Option 62 occurs. Contact
ADVANTEST Corp. for repair.
1.4 About Calibration
When you want to calibrate the R3267 Series, please contact a sales representative.
Name of accessories Type of name Quantity Remarks
R3267 Series OPT62
Operation manual ER3267/73OPT62-3GPP 1 English
Error Message
Handshake error occurred to DSP
Desirable Period One year

R3267 Series OPT62 3GPP Measurement Option Operation Manual
1.5 Explanation of the Connectors
1-2
1.5 Explanation of the Connectors
Connectors used for this option are described as follows:
1. EXT TRIG terminal Connector for inputting the external trigger signal.
2. I channel terminal Connector for inputting the I channel signal (Baseband).
3. Q channel terminal Connector for inputting the Q channel signal (Baseband).

R3267 Series OPT62 3GPP Measurement Option Operation Manual
2.1 Measuring the BTS 3GPP Signals
2-1
2 MEASUREMENT EXAMPLES
This chapter describes how to use this option using practical measurement examples.
2.1 Measuring the BTS 3GPP Signals
By measuring the BS signals in 3GPP mode, it is possible to measure code domain powers for the Primary
CPICH, Primary CCPCH, SCH and speech channels separately.
Measurement conditions:
The signal to be measured is as follows:
the output signal of a unit to be measured in the 3GPP mode with a frequency of 2112.5 MHz and a level of
-10 dBm.
Signal specifications are as follows:
Scrambling code number 0
2.1.1 Measuring the Slot
Setup
1. Connect the unit under test as shown in Figure 2-1.
Figure 2-1 Setup for the measurement of the 3GPP signal
Channel Spreading Factor Code Number
Primary CPICH 256 (15 ksps) 0
Primary CCPCH 256 (15 ksps) 1
SCH 256 (15 ksps) -
Channel 1 128 (30 ksps) 2
Channel 2 128 (30 ksps) 3
Channel 3 128 (30 ksps) 4
Spectrum Analyzer Base Transceiver
system (BTS)
REF IN 10 MHz Reference
RF Tx
BTS Control
Terminal

R3267 Series OPT62 3GPP Measurement Option Operation Manual
2.1 Measuring the BTS 3GPP Signals
2-2
Setting the measurement conditions
This changes the analyzer setting so that the input signal displayed more clearly.
2. Press FREQ, 2, 1, 1, 2, ., 5 and MHz.
3. Press SPAN, 8 and MHz.
4. Press COUPLE, RBW AUTO/MNL(MNL), 3, 0 and kHz.
5. Press VBW AUTO/MNL(MNL), 3, 0, 0 and kHz.
6. Press LEVEL, 0 and GHz(+dBm).
Figure 2-2 3GPP Signal’s Spectrum
7. Press TRANSIENT, STD and STD Setup.
The STD Measurement Parameter Set dialog box is displayed.
Figure 2-3 STD-Measurement parameter set Dialog Box

R3267 Series OPT62 3GPP Measurement Option Operation Manual
2.1 Measuring the BTS 3GPP Signals
2-3
8. Press the key.
The cursor moves to the item Meas Mode.
9. Select SLOT from Meas Mode using the data knob, and press Hz(ENTR).
The measurement mode is set to SLOT.
10. Select DOWNLINK from Link using the data knob, and press Hz(ENTR).
The measurement mode is set to the BTS measurement.
The following parameters are default settings.
Offset Level: 0.0 dB
Frequency Input: FREQUENCY
Input: RF
Cont Auto Level Set: OFF
Average Type: PEAK
EXT Trigger Source: TTL
11. Press RETURN, Modulation, 3GPP and Parameter Setup.
The Parameter Setup [SLOT/DOWNLINK] dialog box is displayed.
Figure 2-4 Parameter Setup [SLOT/DOWNLINK] Dialog Box
12. Select PRECISE from Meas Mode using the data knob, and press Hz(ENTR).
The detailed measurement mode is set.
13. Select DEFINE from Scrambling Code Define using the data knob, and press
Hz(ENTR).
A Scrambling code number becomes active.
14. Press 0and Hz(ENTR) to set Scrambling Code No.
The Scrambling code No. is set to 0.

R3267 Series OPT62 3GPP Measurement Option Operation Manual
2.1 Measuring the BTS 3GPP Signals
2-4
15. Select INT from Trigger Mode using the data knob, and press Hz(ENTR).
The trigger is set to the internal trigger.
16. Select SCH from Search Mode using the data knob, and press Hz(ENTR).
A synchronization mode using a SCH is set.
17. Enter 256 for Primary CPICH SF using the data knob, and press Hz(ENTR).
The spreading factor of the Primary CPICH is set to 256 (the rate is set to 15
ksps).
18. Enter 0for Primary CPICH No. using the data knob, and press Hz(ENTR).
The code number of the Primary CPICH is set to 0.
19. Select Auto from Active CH. Detection using the data knob, and press
Hz(ENTR).
The automatic rate judgement mode is set.
20. Select ACTIVE from Analysis Rate using the data knob, and press Hz(ENTR).
The rates of the channels currently transmitting data are set for measurement.
21. Enter 640 (2560 chips) for Meas Unit using the data knob, and press Hz(ENTR).
The measurement with the range of 640 (2560 chips:1 slot) is set.
22. Enter 0for Meas Start Position using the data knob, and press Hz(ENTR).
The measurement start position is set to the head of the slot (0 chip).
23. Press -, 2, 0 and GHz(dB) to set the threshold.
The threshold value of an active channel is set to -20 dB.
24. Select NORMALfrom Phase Inverse using the data knob, and press Hz(ENTR).
The IQ phase is set to a normal phase.
25. Select PRECISE from Frequency Error using the data knob, and press
Hz(ENTR).
The carrier frequency Error Precise Measurement mode is set.
26. Select ON from Transmit Timing using the data knob, and press Hz(ENTR).
27. Press Parameter Setup.
The dialog box is closed.
28. Press Auto Level Set.
The measurement range is set to the optimum range.
29. Press SINGLE.
The sweep is set to a single mode and starts.
