Mentor Visual iQ*Borescope Adapter
Remote Visual Inspection
GE
Measurement & Control
Spec Sheet
Adapt Rigid Borescopes and
Flexible Fiberscopes to the
Mentor Visual iQ VideoProbe*
Combine optical clarity, durability and high-temperature
operation of a rigid borescope with the image capture and
data management capabilities of the Mentor Visual iQ
VideoProbe system. The borescope adapter connects to the
handset of the Mentor Visual iQ system as an interchangeable
probe, adding versatility to your RVI toolkit.
Features
• Couples illumination from Mentor Visual iQ system to
the borescope
• VGA camera captures live video at high resolution
• Minimizes cables and connections
• Enables all Mentor Visual iQ system data
management features
• Adapt to all GE rigid borescopes and fiberscopes.
Can also adapt to rigid borescope and fiberscopes from
other manufacturers.

Spec Sheet
© 2015 General Electric Company. All Rights Reserved. We reserve the rights to technical
modifications without prior notice.
*VideoProbe is a registered trademark of GE Inspection Technologies.
*Mentor Visual iQ is a trademark of GE Inspection Technologies.
®LP. Super HAD CCD is a registered trademark of Sony Corp.
®Olympus is a registered trademark of Olympus Optical Co. Ltd.
GEA32131 (09/2015)
GEIT-65009EN
Rigid Borescope Light Post Adapter
Manufacturer Adapter Part Number
GE Inspection Technologies Included
Henke-Sass Wolf Included
Olympus®LGA-PAM†
Richard Wolf LGA-PWF†
KARL STORZ LGA-PS†
†Sold separately
C-Mount Eyepiece Coupler†
Part Number Focal Length Recommended Scope
CCF28 28 mm Rigid borescope greater than
4.0 mm diameter.
CCF35 35 mm All fiberscopes and 2.7 mm
diameter rigid borescope.
CCF35 45 mm 1.7 mm and 1.9 mm diameter rigid
borescopes. Fiberscopes less than
2.0 mm in diameter.
†Sold separately
GE Inspection Technologies: productivity through
inspection solutions
GE inspection Technologies provides technology-driven
inspection solutions that deliver productivity, quality and safety.
We design, manufacture and service ultrasonic, remote visual,
radiographic and eddy current equipment and systems. We offer
specialized solutions that will help you improve productivity in
your applications in the aerospace, power generation, oil and
gas, automotive or metals industries.
www.ge.com/inspectiontechnologies
Borescope Adapter Kit Contents (Part No. MV1QABSA)
• Mentor Visual iQ Borescope Adapter
• Nylon carrying case
• GE Inspection Technologies light post adapter
• Quick start guide
Technical Specifications
Camera: 1/3” COLOR, SUPER HAD CCD®
Pixel Count: 470,000 pixels
Camera coupling: 28 mm, 35 mm and 45 mm C-Mount
Illumination: Powered by Dual Internal High Intensity LEDs
Cable length: 1.97 m (6.46 ft.)
Weight: 0.89 kg (1.97 lbs.) 1.45 kg (3.19 lbs.)
Construction: Painted Magnesium Body, Stainless Steel manocoil
with Rugged Neoperene Elastomer outer layer
Operating -20° to 46°C (-4° to 115°F)
Temperature:
Storage -25° to 60°C (-13° to 140°F)
Temperature:
Hazardous Not rated for use in hazardous environments
Environments:
