MM701
7” LCD OVERHEAD MONITOR
OPERATION MANUAL
1286534A.p65 3/28/2003, 2:20 PM1

IMPORTANT
An LCD panel and/or video monitor may be installed in a motor vehicle and visible to
the driver if the LCD panel or video monitor is used for vehicle information, system
control, rear or side observation or navigation. If the LCD panel or video monitor is used
for television reception, video or DVD play, the LCD panel or video monitor must be
installed so that these features will only function when the vehicle is in ‘park’ or when
the vehicle’s parking brake is applied.
An LCD panel or video monitor used for television reception, video or DVD play that
operates when the vehicle is in gear or when the parking brake is not applied, must be
installed to the rear of the driver’s seat where it will not be visible, directly or indirectly,
to the operator of the motor vehicle.
Warnings
t Do not use any solvents or cleaning materials when cleaning the video system.
tDo not use any abrasive cleaners, they may scratch the screen. Use only a
lightly dampened lint free cloth to wipe the screen if it is dirty.
tLock the LCD screen in the fully closed position when not in use.
tBefore putting on headphones always adjust the volume setting to the lowest position.
tRemember to leave the dome light switch in the off or auto positions when the
vehicle is unattended, as the dome lights, if left on, can drain the vehicle’s battery.
tDo not put pressure on the screen.
tCaution children to avoid touching or scratching the screen, as it may become dirty
or damaged. Safety Precaution
For safety reasons, when changing video tapes it is recommended that the vehicle is
not in motion, and that you do not allow children to unfasten seatbelts to change tapes
or make any adjustments to the system. System adjustments can be accomplished
using the remote control unit, while seatbelts remain fastened. Enjoy your Movies 2 Go
entertainment system but remember-safety of all passengers remains the number
one priority.
1286534A.p65 3/28/2003, 2:20 PM2

Congratulations on your purchase of the Movies 2 Go MM701 drop-down Video
Monitor. The MM701 has been designed to give you and your family many
years of video entertainment in the mobile environment. Please read the
directions that follow to familiarize yourself with the product and to ensure
that you obtain the best results from your equipment.
NOTE:Installation options vary, see the individual owner’s manuals for
each component in your system to obtain a full understanding of each
component’s operation.
FEATURES
t7” TFT (Thin Film Transistor) LCD (Liquid Crystal
Display) Monitor
tOSD (On Screen Display) for Control of Picture Quality
and Functions
tInfrared Transmitter for Optional IR Wireless
Headphones
tTwo Audio / Video Source Inputs
tPower ON/OFF Select Switch
tRemote Repeater Sensor
tDome Lights with Built-in Three Way Switch
tVideo Display ON/OFF Control (when LCD Panel is
Opened and Closed)
1286534A.p65 3/28/2003, 2:20 PM3

4MM701
1
2
3
4
5
6
7
8
9
10
FRONT PANEL FEATURES
2
1286534A.p65 3/28/2003, 2:20 PM4

5MM701
FRONT PANEL
1. Infrared Transmitter – Used to transmit audio to wireless headphones.
2. Dome Lights – Provide additional interior illumination.
3. Power ON/OFF Select Switch – Turn the MM701 on and off.
4. Select Up Button – Adjust picture quality and source selection.
5. Select Down Button – Adjust picture quality and source selection.
6. Menu button – Display Contrast, Brightness, Tint, Color, Input Select (AV1 &
AV2), Reset and Exit OSD.
7. LCD Panel – Display the video source and the On Screen Displays (OSD).
8. Three Position Dome Light Switch
•Auto – Automatically switches on the dome lights in conjunction with the
vehicle’s interior illumination.
•Off – The Dome lights will not turn on in this position.
•On – Turns on the Dome lights.
9. Screen Release – Slides in the direction of the arrow to release the drop
down screen.
10. Remote Sensor – For remote repeater.
1286534A.p65 3/28/2003, 2:20 PM5

6MM701
TURNING THE MM701 ON OR OFF
1. Sliding the screen release lock forward will unlock the LCD screen and drop
down slightly. Move the screen downward and pivot it until a comfortable viewing
angle is reached. The internal friction detent will hold the screen in position
while the system is in use.
2. Move the POWER switch to the ON position.
3. After the unit is turned ON and begins to display a picture, adjust the viewing
angle by pivoting the screen to optimize the picture quality.
4. Remember to turn the unit OFF and pivot the LCD to the locked position when
not in use.
Power
ON/OFF
Switch
1286534A.p65 3/28/2003, 2:20 PM6

7MM701
OPERATION
OVERHEAD DOME LIGHTS
The Dome Lights integrated into the MM701 are controlled by a three position slide
switch. Sliding the switch to the ON position will turn the lights ON. The OFF
position will prevent the lights from turning ON with the vehicle’s interior lighting,
and the auto position will allow the lights to turn ON and OFF with the vehicle’s
interior lighting. Do not leave the vehicle unattended with the dome light switch in
the ON position, as this could result in a discharged battery.
Dome
Light
Switch
1286534A.p65 3/28/2003, 2:20 PM7

8MM701
REMOTE SENSOR
The MM701 incorporates an Infrared sensor which relays signals from the remote
control to allow an auxiliary source to be controlled simply by pointing its remote
control at the remote sensor eye. This provides control of auxiliary equipment
such as a Video Cassette Player or DVD Player. The infrared sensor can relay
signals from most manufacturer’s remote control to its respective component
connected to the Video 1 and 2 inputs, such as a DVD player. In this case you must
use the remote control supplied with the DVD player.
Remote
Sensor Eye
Infrared Transmitter
1286534A.p65 3/28/2003, 2:20 PM8

9MM701
PICTURE ADJUSTMENT
When watching the program, the quality of the picture can be adjusted to suit your
taste.
Press the MENU button, the main menu will
appear. Then press the MENU button
consecutively to select the item which you need
to adjust. For example, press MENU button
consecutively to select BRIGHTNESS and press
UP / DOWN button to adjust the desired level.
Description of Adjustment Items:-
Item Press DOWN button Press UP button
CONTRAST
BRIGHTNESS
TINT
COLOR
CONTRAST
TINT
COLOR
INPUT SELECT
RESET
EXIT OSD
BRIGHTNESS
R
GB
Decrease the contrast
for soft color
To darken the picture
Increases the
greenish skin tones
To decrease the color
intensity
Increase picture
contrast for vivid color
To brighten the picture
Increases the redish
skin tones
To Increase the color
intensity
To restore the factory settings, select the item RESET and press UP / DOWN
button. All the picture adjustment function (CONTRAST, BRIGHTNESS, TINT
and COLOR) will go back to the factory settings.
1286534A.p65 3/28/2003, 2:20 PM9

10 MM701
SOURCE SELECT
There are 2 inputs to select from in the Input Select Menu: AV1 and AV2.
To select the input source, press MENU button consecutively to the item INPUT
SELECT. Then, press UP / DOWN button to select AV1 or AV2.
CONTRAST
BRIGHTNESS
TINT
COLOR
RESET
EXIT OSD
INPUT SELECT
R
GB
AV1
EXIT THE MENU
To exit the main menu, press MENU button to select EXIT OSD and press UP /
DOWN button, the menu will disappear.
NOTE: The menu also disappears from the screen automatically if you do
not press any button within few seconds.
