AEG Powertools BL 1218 User manual

BL 1218
Original instructions

2
Important!
It is essential that you read the instructions in this manual before
operating this machine.
Subject to technical modifications.

3
Contact AEG customer
service centre
0°C
1
50°C
0°C
50°C
23

4
100 %
45

5
BL 1218
................. 12-18 V
..................... 4,1 A
..................... 4,1 A
..................... 4,1 A
...................... 30 min
...................... 50 min
...................... 60 min
..................... 0,7 kg
TECHNICAL DATA Charger
Voltage range .........................................................................
Quick charge current NiCd .....................................................
Quick charge current NiMH ....................................................
Quick charge current Li-Ion ....................................................
Battery charging time NiCd (1.5 Ah)...........................approx.
Battery charging time NiMH (3.0 Ah)..........................approx.
Battery charging time Li-Ion (3.0 Ah)..........................approx.
Weight according EPTA-Procedure 01/2003..........................
Do not try to charge non-rechargeable batteries with this
charger.
No metal parts must be allowed to enter the battery section
of the charger (short circuit risk).
Never break open battery packs and chargers and store
only in dry rooms. Keep dry at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new
one.
Before use check machine, cable, and plug for any
damages or material fatigue. Repairs should only be carried
out by authorised Service Agents.
This appliance is not intended for use by persons (including
children) with limited physical, sensory or mental capabilities
or insufficient experience and/or knowledge unless they are
supervised by a person who is responsible for their safety or
have been instructed by them in the safe use of the tool.
Children should be supervised in order to ensure that they
do not play with the appliance.
SPECIFIED CONDITIONS OF USE
The quick charger is intended to charge AEG System GBS
batteries from 12 V to 18 V.
Do not use this product in any other way as stated for
normal use.
LED
Mode Pack
inserted? Green Green Orange Orange Red
Standby
Power Fade Off Off Off Off
Evaluate On Off Flash Off Off
Charging On Flash Off Off Off
Fully
Charged On On Off Off Off
Standby Full Fade Fade Off Off Off
Too hot
Too cold Fade Off Off Fade Off
Defective Fade Off Off Off Fade
WARNING! Read all safety warnings and all
instructions, including those given in the accompanying
brochure. Failure to follow the warnings and instructions
may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
The following battery packs can be charged with this
charger:
voltage battery rated No. of
capacity
battery
cells
12 V Range B 12...R 1.5 Ah 10
14.4 V Range B 14...R 1.5 Ah 12
18 V Range B 18...R 2.0 Ah 15
12 V Range M 12...R 3.0 Ah 10
14.4 V Range M 14...R 3.0 Ah 12
18 V Range M 18...R 3.0 Ah 15
14.4 V Range L 14...R 3.0 Ah 4x2
18 V Range L 18...R 1.5 Ah 5
18 V Range L 18...R 3.0 Ah 5x2
Do not dispose of used battery packs in the household
refuse or by burning them. AEG Distributors offer to retrieve
old batteries to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
Use only System GBS chargers for charging System GBS
battery packs. Do not use battery packs from other systems.

6
MAINS CONNECTION
Connect only to single-phase a.c. current and only to the
system voltage indicated on the rating plate. It is also
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.
BATTERIES
New battery packs reach full capacity after 4 - 5 chargings
and dischargings. Battery packs which have not been used
for some time should be recharged before use.
For an optimum life-time, the battery packs have to be fully
charged, after use.
To obtain the longest possible battery life remove the battery
pack from the charger once it is fully charged.
For battery pack storage longer than 30 days:
Store the battery pack where the temperature is below 27°C
and away from moisture
Store the battery packs in a 30% - 50% charged condition
Every six months of storage, charge the pack as normal.
CHARACTERISTICS
After inserting the battery into the reception of the charger
the battery will be analysed within 10 seconds and then
automatically be charged.
When a hot or cold battery pack is inserted into the charger,
charging will begin automatically once the battery reaches
the correct charging temperature (0°C...50°C).
Charging time varies depending on the battery temperature,
charge needed and the type of battery pack being charged.
As soon as charging is completed, the charger switches
over to ”trickle” charge to maintain the full capacity.
If green and red lamp fade at the same time, either the
battery has not been completely mounted or there is a fault
in the battery or the charger. For safety reasons you must
stop using the charger and battery immediately and have
them inspected by an AEG Customer Service Centre.
MAINTENANCE
If the supply cord of this appliance is damaged, it must only
be replaced by a repair shop appointed by the manufacturer,
because special purpose tools are required.
Use only AEG accessories and AEG spare parts. Should
components need to be replaced which have not been
described, please contact one of our AEG service agents
(see our list of guarantee/service addresses).
If needed, an exploded view of the tool can be ordered.
Please state the ten-digit No. as well as the machine type
printed on the label and order the drawing at your local
service agents or directly at: AEG Elektrowerkzeuge,
Max-Eyth-Straße 10, D-71364 Winnenden, Germany.
SYMBOLS
Please read the instructions carefully before
starting the machine.
Do not dispose of electric tools together with
household waste material! In observance of
European Directive 2002/96/EC on waste
electrical and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their
life must be collected separately and returned to
an environmentally compatible recycling facility.
This tool is only suitable for indoor use. Never
expose tool to rain.
Do not burn used battery packs.
Never charge a damaged battery pack. Replace
by a new one.
