AEG MMC 4418 DVB-T User manual

Instruction Manual
MMC 4418 DVB-T
Multimedia Centre
with DVB-T/TV/DVD
Elektro-technische Vertriebsges. mbH
Industriering Ost 40 • 47906 Kempen
[e-mail]
Stand 2/08

A lightning bolt with an arrowhead symbol within
an equilateral triangle is intended to alert the
user to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and main-
tenance (servicing) instructions in the literature
accompanying the appliance.
WARNING: TO AVOID THE DANGER OF FIRE
OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO WATER OR MOISTURE. NEVER
OPEN THE CABINET, AS DANGEROUS HIGH
VOLTAGE IS CONTAINED INSIDE. ONLY
A QUALIFIED SERVICE TECHNICIAN SHOULD
ATTEMPT TO OPEN THE CABINET.
CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE
SLOT, AND FULLY INSERT INTO ELECTRICAL
SOCKET.
CAUTION: This DVD receiver unit employs
a laser system. To prevent direct exposure to
the laser beam, do not open the enclosure.
Visible laser radiation is present when enclo-
sure is open. DO NOT STARE INTO BEAM.
Additionally, the use of controls or adjustments
or performance of procedures other than those
specified herein may result in hazardous radia-
tion exposure.
To ensure proper use of this product, please
read this owner's manual carefully and retain
for future reference. Should the unit require
maintenance, contact an authorized service
centre.
PROTECT YOURSELF!
Record the model and serial numbers for this
unit while it is easy to see them. These numbers
are located on the back of the unit's cabinet.
Retain this information for future reference.
Model Number
Serial No. _________________________
Retain this information for future reference.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). THERE IS NOS ERVICE
ABLE PART INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
PRECAUTIONS
CAUTION: Is it important that you read and follow all
of the instructions in this booklet and any marked on
the unit itself. Retain this booklet for future reference.
Accessories--- Never place this product on an un-
stable platform, stand, cart, wall mount, shelf, or
table. The product may fall, causing serious personal
injury to persons and pets, as well as seriously
damaging the product.
Any mounting of the product should follow the
manufacturer's instructions, and use a mounting
accessory recommended by the manufacturer.
This unit while positioned on some type of cart must
be moved with care. Quick stops, excessive force,
and uneven surfaces may cause the product and
cart combination to overturn.
Attachments---Use only approved attachment as
they may cause hazards.
Cleaning--- Always unplug this unit from the wall
electrical outlet before cleaning. Do not use liquid or
aerosol cleaners; use a damp cloth for cleaning.
Lightning--- For added product protection during
a lightning storm or when it is left unattended and
unused for long periods of time, unplug it from the
wall outlet and/or disconnect the antenna or cable
system. This will prevent damage to the product due
to lightning and power-line surges.
Object and Liquid Entry--- Never push objects of
any kind into this product through openings as they
may touch dangerous voltage points or short-out
parts that could result in a fire or electric shock.
Never spill liquid of any kind on or into the product.
Outdoor Antenna Grounding--- If an outside
antenna or cable system is connected to the product,
be sure the antenna or cable system is grounded so
as to provide protection against voltage surges and
built-up static charges.
Overloading---Do not overload wall outlets, exten-
sion cords, or integral convenience receptacles, as
this may result in a fire or electric shock.
Power - Cord Protection - Power - supply cords
should be routed so that they are not likely to be
walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they
exit from the product.
Power Lines---An outside antenna system should
not be located in the vicinity of overhead power lines
or other electric light or power circuits, or where it
can fall into such power lines or circuits. When
installing an outside antenna system, extreme care
should be taken to keep from touching such power
lines or circuits as contact with them might be fatal.
Power Sources---This product should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or
local power company. For products intended to
operate from battery power or other sources, refer to
the operating instructions. This DVD home theater
operates on AC 230V/50Hz. Do not turn off unit
immediately after turning on; wait at least 10 seconds.
Replacement Parts--- If replacement parts are
required, be sure the service technician has used
approved replacement parts or have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or
other hazards.
Safety Check---Upon completion of any service
or repairs to this product, ask the service technician
to perform safety checks to determine that the
product is in proper operating condition.
Servicing--- Do not attempt to service this product
yourself as opening or removing covers may expose
you to dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
TV System---This unit is compatible with television
sets featuring either the NTSC or PAL color system.
Ventilation---Slots and openings in the cabinet
are provided for ventilation and to ensure reliable
operation and protection from overheating. These
openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in install-
ation such as a bookcase or rack unless proper
ventilation is provided. Never place this product near
a heat source, such as heat registers, stoves,
radiators, or any other product that produces heat.
Water and Moisture---Do not use this product near
sources of water and moisture, such as bath tub, wash
bowl, kitchen sink, or wash machine; in a wet, damp
basement; or near a swimming pool or similar
locations. If moisture condensation occurs, remove
any disc, connect the unit's power cord to a wall outlet,
turn the unit on, and leave it on for two to three hours.
By then, the unit will warm up and moisturew ould
evaporate
IMPORTANT--
SAFETY INFORMATION
-2-
-1-

The following will help you get the most enjoyment from your DVD receiver system.
BEST LOCATION
The unit should be placed on a firm, flat surface, away from VCRs, stereos, radios, or large
speakers, as the magnetic flux from these devices may cause distortion in the sound and a poor
picture. If placed in a cabinet, be sure there is at least 1 o f f ree space completely around the unit
for proper ventilation.
TO OBTAIN A CLEAR PICTURE
A DVD receiver is a precision device. If the optical pick-up lens and disc drive parts become dirty
or worn down, picture quality will become poor. Store DVD player in a clean dust free environment.
PLAYABLE DISCS
This DVD receiver system will play the following types of discs: DVD, CD, CD-R,and
CD-RW with super-error correction ability. It is also capable of displaying picture CDs and digital
photo albums. It supports eight languages, up to 32 subtitles, and multi-angle viewing. It features
easy setup and operation with on-screen menus. It has full function CPU upgrading able capability.
DIGITAL AUDIO OUTPUT
The unit's coaxial output capability enables you to connect an external six-channel AV amplifier
and processor with built-in Dolby Digital code with just one cord. This enables you to conveniently
enjoy different DVD, CD, and Mp3 discs.
ANALOG AUDIO OUTPUT
Speaker system plug-and-play convenience through the built-in downmix 2-channel power
amplifier eliminates the use of an external power amplifier.
LASER-HEAD OVER-CURRENT
PROTECTION SYSTEM
To extend the service life of the laser head, the unit includes a unique laser-head over-current
protection system, ensuring a constant laser current.
""
ABOUT YOUR
DVD PLAYER
This page contains valuable information regarding the handling, cleaning, and storage of discs
played in this unit.
Handling
Do not touch the playback side of the disc.
Do not attach paper or tape to discs.
Do not stick or write anything on the surface. Protect against fingerprints.
Always hold a disc by the center and edge portions.
Cleaning
Fingerprints and dirt on the disc may cause picture and/or sound deterioration. Wipe the disc from
the center outward with a soft cloth. Always keep the disc clean.
If you cannot wipe the dirt off, lightly use a slightly moistened soft cloth and finish with a dry cloth.
Do not use any type of solvent such as: Paint thinner, benzene, commercially available cleaners or
anti-static spray for vinyl LPs.
Storing
Do not store discs in places subject to direct sunlight or near heat sources.
Do not store discs in places subject to moisture and dust.
Store discs vertically in a case. Stacking or placing objects on discs outside of their case may
cause warping.
NOTE: This DVD is not responsible for damage that may occur to any disc that is operated
in this unit or not handled, cleaned, or stored as suggested above.
USE OF DISCS
TABLE OF CONTENTS
Precaution ................................................ 2
Table of Contents .......................................3
About Your DVD Player ............................ 4
Best Location..........................................................4
To Obtain a Clear Picture......................................... 4
Playable Discs........................................................4
Digital Audio Output ................................................4
Analog Audio Output ................................... ............4
Use of Disc ...............................................4
Handling.................................................................4
Cleaning.................................................................4
Storing...................................................................4
Front and Back panels .. .............................5
Front Panel.............................................................5
Back Panel.............................................................6
Remote Control..........................................7
Operating the remote control.......................8
Connecting Devices................................... 9
USB interface........................................... 10
Arrangement of speakers........................... 10
Connecting speakers.................................11
Connecting antenna..................................12
Connecting power supply...........................13
Basic DVD operation .......................14 15 16
Playing the radio......................................17
PLAYING WMA MP3 AND JPEG.................18
System Setup......................19 20 21 22 23 24
LANGUAGE Setup .............................. 25 26
AUDIO SETUP... .................................. 27
VIDEO SETUP .................................... 28 29
SPEAKER Setup ................................. 30
DIGITAL Setup ...................................... .31
Trouble
shooting......................................
45
Technical specifications
...........................
46
-4-
-3-
32
41
DVB PART
The Setup Menu System
ATV PA RT
The Setup Menu System
SCREEN SET PART
The Setup Menu System
44
Important--Safety Information .................... 1
Laser-Head Over-Current Protection System ............4
Smart EQ Function....................................18

UP
DOWN
8
4
23
56
7
1
9
FRONT AND
BACK PANELS
Back Panel Functions
8. FM ANTENNA
Use to connect the provided indoor FM
loop antenna.
10. 100-240V~ 50/60HZ
This unit comes with an AC power cord. Be
sure its prongs are dry before plugging it into an
electrical outlet. Take caution not to overextend
the cord or walk on it.
Front Panel Functions
6. NEXT
While in the DVD status, you may press this
buttonfornext track.
2. VOLUME
Use this button to control the unit's volume. It
controls all channels simultaneously.
3. OPEN/CLOSE
Use this button to open and close the disc tray
while in DVD mode.
5. PREV
While in the DVD status, you may press this
button for previous track.
1.PHONE
outlet, check to make sure all of the connections
have been properly completed. When they have
to power the unit.
of electricity may cause interference with other
Before plugging the power cord into the AC
been, carefully plug power cord into outlet.
Press the POWER button on the front panel
When the unit is initially powered, a brief surge
electronic equipment on the same circuit. If this
occurs, connect the unit to an outlet on a
different circuit.
7. INPUT SIGNAL SOURCE
Use this button to select the proper input signal
source. (Note: The selected input will correspond to
the selected input terminal on the rear panel.)
9. USB CONNECT
Use only USB Flash Ram.
8. POWER
FRONT AND
BACK PANELS
PLAY /
Use this button to begin play function while in
DVD mode.
Use this button to pause play function while in
DVD mode.
PAUSE
4.
-6-
-5-
2. DOWNMIX 2-CHANNEL OUTPUT
Use to connect output for 2-channel analog
audio.
.
5. S-VIDEO OUTPUT
1. FRONT/MAIN
Use to connect the four terminals of the left
and right front or main speakers.
3. COAXIAL DIGITAL AUDIO OUTPUT
6. CVBS OUTPUT
4. Component Videos Output
(Y,Cb/Pb,Cr/Pr)
10 56
4
8
ANTENNA
FM
SPEAKERS IMPEDANCE
CVBS
Cb/Pb
Cr/Pr S-VIDEO
COAXIAL
R
L
Y
100-240V~
50/60HZ
AUDIO VIDEO OUTPUT ANTENNA
ATV/DTVATN
1
2
3
9
9.ATV/DTV ANT
SCART
7
7. SCART OUT

2
4
5
6
22
7
13
19
14
15
12
10
11
9
21
20
8
1
17
18
16
3
MUTE
0-9 NUMBER KEYS
SETUP
PRE/TUN
SCROLL UP
SCROLL RIGHT
AUTO
STOP
PLAY
CH CH+
FWD
REV BUTTON
A-B
SLOW
MENU
ANGLE
LANGUAGE
4:3/16:9
R/L
23 EQ
STANDBY
TFT ON/OFF
DISPLAY
38
37
36
27
25
26
28
29
32
31
30
33
35
34
39
42
40
41
SCROLL DOWN
SCROLL LEFT
ENTER
MEMO
PAUSE/STEP
PREV BUTTON
NEXT BUTTON
ZOOM
PROG
GOTO
TITLE
SUBTITLE
N/P
RESUME
REPEAT
OPEN/CLOSE
SOURCE
FUNCTION
RETURN
46
45 EPG
TV/RADIO
VOLVOL
0
1 2 3
4 5 6
7 8 9
SETUP
RETURN PRE/TUN
MEMO
ENTER
AUTO
STOP
VOL
+10
PAUSE/STEP PLAY
+
CH
ZOOM PROG SLOW
REPEAT
FUNCTION TFT ON/OFF
N/P
SUBTITLE LANGUAGE ANGLE
RESUME
A-B
+
R/L
MUTE
STANDBY
SOURCE
TITLE MENU
GOTO DISPLAY
4:3/16:9
EPG TV/RADIO EQVIDEO
REMOTE
CONTROLLER
-7-
Notes:
Do not direct the remote sensor toward
any light source, such as direct sunlight or
a strong fluorescent light, as it may cause
the unit to not operate correctly.
When other remote controls are used
nearby or when the remote is used near
equipment using infrared rays, interference
may occur.
Placing an object on the remote control
may cause it to inadvertently depress a
button, changing a function and shortening
battery life.
Do not glaze the front of the DVD receiver
with colored glass, as it may cause
interference with normal operation of the
controller.
Make sure there is no barrier between the
remote control and remote sensor, as it
could prevent the unit from receiving the
signal.
Do not spill water or put wet items on the
remote control.
Never disassemble remote control.
BATTERIES
INCORRECT USE OF BATTERIES MAY
CAUSE THEM TO LEAK, CORRODE OR EXPLODE.
Battery Installation
1. Push down and out on the battery Compart-
ment cover to remove it.
2. Insert the two AAA b atteries into the battery
compartment of the remote control, making
sure the + and - signs on the batteries and
inside the batteries compartment match up.
3. Replace the battery compartment cover.
Notes:
Do not mix batteries from different manu-
facturers, nor old ones with new.
If the remote control will not be used for an
extended period of time, remove the
batteries to prevent damage-causing
corrosion.
Remove dead batteries immediately to
prevent damage-causing corrosion.
If battery leakage occurs, wipe the battery
liquid from the battery compartment, then
replace both batteries.
Always replace both batteries at the same
time, using new, fully charged batteries.
Life expectancy of batteries may vary
depending on amount of use.
Using the Remote Control
Point the remote control at the remote sensor
on the DVD receiver. When the signal is
received from the remote, the unit will function
accordingly. The remote will operate to
approximately 16' from the remote sensor at an
angle of around 30 each direction.
""
OPERATING THE
REMOTE CONTROL
-8-
24 VIDEO
43
44

UP
DOWN
USB interface
This unit have a USB jack, when no disc in the player, you can insert a USB DISC or a Mp3 Player with USB
Interface to play the Music files or and JPEG files. All the function is the same to play a disc.
Press the SOURCE key on theremote control until you switched into USB work mode
Connection terminals for this DVD receiver
are found on the rear panel. Read carefully
and follow the manufacturers' instructions
of any video and audio device being
connected to this unit.
Do not connect the power until all connections
have been properly completed.
Red terminal (marked R) is for connecting the
right channel. The white terminal (marked L)
is for connecting the left channel. The yellow
terminal is for video connection. Make sure
all connections are securely made. Improper
connections may cause noise, poor perfor-
mance, or cause damage to the equipment.
Do not tie the AV cord with any other cords,
such as the power cord or speaker wires, as
it may result in poor picture and/or sound
quality.
CONNECTING
DEVICES
-9- -10-
Y
Pb/Cb
Pr/Cr
ANTENNA
FM
SPEAKERS IMPEDANCE
CVBS
Cb/Pb
Cr/Pr S-VIDEO
COAXIAL
R
L
Y
100-240V~
50/60HZ
AUDIO VIDEO OUTPUT ANTENNA
ATV/DTVATN
AMPLIFIER
USB interface
SCART
ENCODING / CDRIPPING :
With TV LCDScreen on : Whena CD is loaded,you can insert aUSB key then pressSUBTITLE knob on
the remote control tostart encoding. It willshow OPEN FILE firstfor 2-3 seconds onthe screen then
begin to record filesby showing the RECpercentage.

ANTENNA
FM
SPEAKERS IMPEDANCE
CVBS
Cb/Pb
Cr/Pr S-VIDEO
COAXIAL
R
L
Y
100-240V~
50/60HZ
AUDIO VIDEOOUTPUT ANTENNA
ATV/DTVATN
Main speaker Main speaker
1.TV set or screen
2. Front or main left speaker
3.Front or main right speaker
4.Viewer's location
1
23
4
CONNECTING
SPEAKERS
-11-
FM
Coaxial cable(75 ohm)
Coaxial cable (75 ohm)
Outdoor FM antenna
Radio signals may be difficult to receive in
some buildings and under certain conditions.
The provided antenna will help in their reception.
They are intended for indoor use only.
FM Indoor Antenna
The FM antenna should be fully extended
and in a direction that provides the clearest
signal. Secure the antenna ends in a location
where distortion is a minimum. If reception
remains poor, an outdoor antenna may be
necessary.
CONNECTING
ANTENNA
-12-
FM
SCART

POWER
UP
DOWN
Before plugging the power cord into the AC outlet, check to make sure all of the connections
have been properly completed. When they have been, carefully plug power cord into outlet.
Press the POWER button on the front panel to power the unit. The display panel will light.
When the unit is initially powered, a brief surge of electricity may cause interference with other
electronic equipment on the same circuit. If this occurs, connect the unit to an outlet on a different
circuit.
CONNECTING
POWER SUPPLY
-13-
BASIC DVD
OPERATION
-14-

BASIC DVD
OPERATION
-15-
Selecting Source
1. Press source button (DVD/FM/USB/
ATV/DVB-T) to select the desired sound source.
The appropriate symbol will appear in the display.
Note: The desired program source will not play
unless it and the selected signal button coincide
with the active program source signal input.
Volume Control
The volume may be adjusted by either turning
the large volume knob on the front panel or
using the appropriate volume button on the
remote control.
Mute
Pressing the MUTE button temporarily mutes
every speaker. To resume audio, press MUTE
button again.
-16-
BASIC DVD
OPERATION
Press PROG button.

UP
DOWN
60 150 400 1K 3K 7K 16K
0
1 2 3
4 5 6
7 8 9
SETUP
RECALL PRE/TUN
MEMO
ENTER
AUTO
STOP
VOL
+10
PAUSE/STEP PLAY
+
CH
ZOOM PROG SLOW
REPEAT
FUNCTION TFTON/OFF
N/P
SUBTITLE LANGUAGE ANGLE
RESUME
A-B
+
R/L
MUTE
STANDBY
SOURCE
TITLE MENU
GOTO RETURN
4:3/16:9
EPG TV/RADIO EQVIDEO
PLAYING THE RADIO
-17-
PLAYING MUSIC FILES AND JPEG
-18-
Current MUSIC/JPEG file
name. If a JPEG file
playing, the name should be
*.jpg.
The playing file is
a JPEG picture.
The playing file is
a music file..
File Switch Region: Displays the
file type of the playing and the
switching.
17
Basic operations
1.Press CH+ or CH- button to find a station.
The frequency will change with each press.
When a station's signal is received, it will
appear in the display.
3.To lock onto a station quickly, hold the CH+
or CH- button for few seconds. The unit
will start automatic tuning in tune state.
When a station
is found, automatic tuning
in tunstops.
1.Press the AUTO button. the
automatic tuning mode is activated.
2.Stations will be stored in ascending order
until 30 stations of that particular wave band
have been saved. When a station is stored, the
memory storage number, as well as the station's
frequency, will flash for four seconds in the
display.
3.When the total number of stations reaches
30, in a particular wave's memory,
no further station in that wave band will be saved.
1.To play preset stations
2.Press the PRE/ TUN button.
3.Press any of the numbered buttons to
select the desired station's memory number.
For example, to play the station at memory
#5, simply press the 5 button; for memory
#17, press the 1 button followed by the 7
button.
4.Stations in the memory function may also
be accessed by pressing the CH- or CH+
button.
Automatic Tuning
This unit will store up to 30 individual
FM radio stations in its memory.
4.To add a station to memory, press the MEMO
button. The memory storage number will
blink for four seconds in the display. Press
MEMO again to store the station.
Memory number
Wave band Station frequency
FM\CH: MHZ
Press the TUNER button to select the desired wave band.
2.Pree
PRE/ TUN Key to enter into tune state.
Press the EQkey on theremote control toselect smart EQ function:
NORMAL CLASSIC JAZZ ROCK POP.
NOTICE:The function isonly in playing VCD CD
Music file orin FM mode.
SMART EQ FUNCTION
Note: Pressing arrow bottonsrepeatedly it is possibleto select the filtericon
(AUDIO/Video/Picture), once selectedthe desired icon pressenter to coufirh.
The unit will showonly the files whichbelong to the selectedcategory..

SYSTEM SETUP
-19-
SYSTEM SETUP
-20-
VIDEO SETUPVIDEO SETUP
BRIGHTNESS
CONTRAST
HUE
SATURATION
EXIT SETUP
VIDEO SETUPVIDEO SETUP
BRIGHTNESS
CONTRAST
HUE
SATURATION
EXIT SETUP
SYSTEM SETUPSYSTEM SETUP
TV SYSTEM
VIDEO
TV TYPE
PASSWORD
RATING
DEFAULT
EXIT SETUP
SCREEN SAVER

INTERLACE-YUVINTERLACE-YUV
P-SCAN YPBPRP-SCAN YPBPR
S-VIDEOS-VIDEO
SYSTEM SETUPSYSTEM SETUP
TV SYSTEM
VIDEO
TV TYPE
PASSWORD
RATING
DEFAULT
EXIT SETUP
SCREEN SAVER
SYSTEM SETUPSYSTEM SETUP
TV SYSTEM
VIDEO
TV TYPE
PASSWORD
RATING
DEFAULT
EXIT SETUP
OFF
ON
SCREEN SAVER
SYSTEM SETUPSYSTEM SETUP
TV SYSTEM
VIDEO
TV TYPE
PASSWORD
RATING
DEFAULT
EXIT SETUP
AUTO
PAL
NTSC
SCREEN SAVER
SYSTEM SETUP
-21-
SYSTEM SETUP
-22-
SYSTEM SETUPSYSTEM SETUP
TV SYSTEM
VIDEO
TV TYPE
PASSWORD
RATING
DEFAULT
EXIT SETUP
4£º3PS
4£º3LB
16£º9
4£º3PS
4£º3LB
16£º9

11 KIDKID SAFESAFE
22 GG
33 PGPG
44 PG13PG13
55 PG-RPG-R
66 RR
77 NC-17NC-17
88 ADULTADULT
SYSTEM SETUPSYSTEM SETUP
TV SYSTEM
VIDEO
TV TYPE
PASSWORD
RATING
DEFAULT
EXIT SETUP
SYSTEM SETUPSYSTEM SETUP
-23-
SYSTEM SETUP
-24-
RESTORERESTORE
SYSTEM SETUPSYSTEM SETUP
TV SYSTEM
VIDEO
TV TYPE
PASSWORD
RATING
DEFAULT
EXIT SETUP
--------
SYSTEM SETUPSYSTEM SETUP
TV SYSTEM
VIDEO
TV TYPE
PASSWORD
RATING
DEFAULT
EXIT SETUP
new

LANGUAGE SETUP
-25- -26-
LANGUAGE SETUP
LANGUAGE SETUPLANGUAGE SETUP
OSD LANGUAGE
AUDIO LANG
SUBTITLE LANG
MENU LANG
EXITS ETUP
ENGLISHENGLISH
FRENCHFRENCH
SPANISHSPANISH
GERMANGERMAN
PORTUGUESEPORTUGUESE
ITALIANITALIAN
HOLANDHOLAND
CZECHCZECH
LANGUAGE SETUPLANGUAGE SETUP
OSD LANGUAGE
AUDIO LANG
SUBTITLE LANG
MENU LANG
EXIT SETUP
ENGLISHENGLISH
FRENCHFRENCH
SPANISHSPANISH
GERMANGERMAN
PORTUGUESEPORTUGUESE
ITALIANITALIAN
ROMANIANROMANIAN
HOLANDHOLAND
LANGUAGE SETUPLANGUAGE SETUP
OSD LANGUAGE
AUDIO LANG
SUBTITLE LANG
MENU LANG
EXIT SETUP
ENGLISHENGLISH
FRENCHFRENCH
SPANISHSPANISH
GERMANGERMAN
OFFOFF
ITALIANITALIAN
HOLANDHOLAND
ROMANIANROMANIAN
LANGUAGE SETUPLANGUAGE SETUP
OSD LANGUAGE
AUDIO LANG
SUBTITLE LANG
MENU LANG
EXIT SETUP
ENGLISH
FRENCH
SPAISH
GERMANY
ITALIAN
HOLAND
ENGLISH
FRENCH
SPAISH
GERMANY
ITALIAN
HOLAND

SPDIP/OFF
SPDIF/RAW
SPDIF/PCM
SPDIP/OFF
SPDIF/RAW
SPDIF/PCM
AUDIO OUTAUDIO OUT
AUDIO OUT
EXIT SETUP
AUDIO SETUP
-27-
48K
96K
192K
48K
96K
192K
AUDIO SETUPAUDIO SETUP
AUDIO OUT
DOWN SAMPLE
EXIT SETUP
DOWN SAMPLE
Select the setting suitable to your amplifier.
-28-
VIDEO SETUPVIDEO SETUP
BRIGHTNESS
CONTRAST
HUE
SATURATION
EXIT SETUP
VIDEO SETUP
DOWN SAMPLE
3

-30-
SPEAKER SETUP
VIDEO SETUPVIDEO SETUP
BRIGHTNESS
CONTRAST
HUE
SATURATION
EXIT SETUP
VIDEO SETUPVIDEO SETUP
BRIGHTNESS
CONTRAST
HUE
SATURATION
EXIT SETUP
-29-
VIDEO SETUP
VIDEO SETUPVIDEO SETUP
BRIGHTNESS
CONTRAST
HUE
SATURATION
EXIT SETUP
SPEAKER SETUPSPEAKER SETUP
DOWNMIX
EXIT SETUP
LT/RT
STEREO
DOWNMIX (only DolbyDigital DVD disc)
DOWNMIX function is used to play analogue audio when the recorded audio channel
on the disc does not correspond to the audio output channel configuration. If the disc
has 5.1 audio channels and the audio output can only receive stereo channels,
downmix function is necessary to hear all the channels recorded on the disc. This
function has 2 options: LT/RT and stereo. If you are using Dobly Surround pro logic
decoder you mayset LT/RT mode; in other situation please set to Stereo.

-31-
SYSTEM SETUP
6)DIGITALSETUP
DIGITAL SETUPDIGITAL SETUP
DUAL MONO
EXIT SETUP
6/86/8
4/84/8
2/82/8
OFFOFF
FULLFULL
DYNAMIC RANGE
DIGITAL SETUPDIGITAL SETUP
DUAL MONO
EXIT SETUP
STEREO
MONO L
MONO R
MIX MONO
DYNAMIC RANGE
1. FIRST installation after power on
First Time Setup In Figure (1), a message appears, asking the user if he/she wants to run the First Time
Installation Wizard. Upon selecting Yes , a new box appears, shown in Figure (2), asking for country,
OSD language, and time zone. Use the arrow keys to make the correct selections. Select Next and press
<ENTER> to proceed to the next screen, which is shown in Figure (3).
The setup menu system---DVB PART
Figure (1) Figure (2)
First time installationFirst time installation
Do you want to start first
time installation wizard?
YES
NO
Figure(3)
Figure (4)
First time installation (2)First time installation (2)
Do you want to start Auto
Scan?
YES NO
BACK
Channel: 21 Frequency: 474000kHz
Progress 1/11/1
TV: 0004 Radio: 0009
0001. Xxxxx
0002. Xxxx
0003. Xxxx
0004. Xxxxxx
0006. Xxxxx
0007. Xxxx
0008. Xxxx
0009. Xxxxxx
Advanced Features
How to switchto DVB-T work mode?
Press the SOURCEkey on theremote control untilyou switched intoDVB-T work mode.
-32-
DYNAMIC RANGE
The requirement of a different dynamic range changes due to the room in which
you are and the personal taste. The high quality audio programs, as movies,
usually have a wide dynamic range. Compared to the dialogue the sound of an
explosion result to be 20dB higher, and the leaf whispering is 50 dB lower. In
some rooms it is necessary to decrease the volume of the strong sounds and
increase the volume of weak sounds. In order to maintain the original dynamic
range of the disc you may set Dynamic Range OFF. Otherwise set to FULL to
decrease the dynamic range by decreasing the level of strong sounds and
increasing the levelof weak sounds.
DUAL MONO (LEFT + RIGHT)
DUAL MONO function has two mono channels in Dolby Digital. You may useit
mainly for theprograms broadcasting indifferent languages. It works in the same
qay for TVand VCR which support a secondary audio program. From two MONO
channels, the audiois emitted infour possible differentcombinations: STEREO,
LEFT MONO, RIGHTMONO and MIXED MONO.
First time installation (1)First time installation (1)
NEXTBACK
Selecl countrySelecl country Switzerland
OSD LanguageOSD Language English

2. The Main Menu Pressing <SETUP> will enter the Main Menu, which is shown in Figure (5). From here,
pressing <SETUP> again or <RETURN> will exit the menu. The the main menu is divided into four main
selection items: Channel Guide, System Config, Installation, and Game, which are displayed on
the left side. Selecting an item will open a submenu, with the menu s items displayed on the right side of
the screen. The menus are shown in Figures (5) to (8), and are detailed later in this document.
The setup menu system---DVB PART Advanced Features
3. Channel Guide
3.1 TV Channels
The TV Channels Menu is shown in Figure (9). The channels are listed on the left side of the menu, and a
preview window is on the right side. From here, the channel can be changed using the <UP> or <DOWN>
keys, <ENTER> to start viewing, <LEFT> or <RIGHT> to change channel groups. Channel groups include
news, sports, favorites, etc. Press <DISPLAY> to sort the channels, which can be set to alphabetical (A-Z),
reverse alphabetical, free on top, scrambled on top, and transponder (Figure (10)).
3.2 Radio Channels
The Radio Channels Menu, shown in Figure (11), is similar to the TV Channels Menu.
The channels are listed on the left side. The channel can be changed using <UP> and <DOWN>, and group
can be changed using <LEFT> or <RIGHT>. Press <DISPLAY> to sort the channels.
Figure (11) Radio Channels Menu
No All TV
0001
0002
0003
0004
Xxx
Xxx
Xxx
Xxx
Channel Guide -> TV ChannelsChannel Guide -> TV Channels
Cancel
A~Z
Z~A
Free~Scramble
Scramble~Free
Transponder
Cancel
A~Z
Z~A
Free~Scramble
Scramble~Free
Transponder
No All TV
0001
0002
0003
0004
Xxx
Xxx
Xxx
Xxx Picture
Channel Guide -> TV ChannelsChannel Guide -> TV Channels
< >to switch calssify
DISPLAY key to sort channel
No All TV
0001
0002
0003
0004
Xxx
Xxx
Xxx
Xxx Picture
Channel Guide -> Radio ChannelsChannel Guide -> Radio Channels
< >to switch calssify
DISPLAY key to sort channel
Figure (9) TV Channels Menu Figure (10) Sort Channels
3.3 Channels Class
From the Channels Class Menu, shown in Figure (12), each channel can be classified into
a group. Pressing <ENTER> will add the row s c hannel to the column s category. Use <TV/RADIO> to
switch between TV and radio channels. Note: If there are no channels, the user cannot enter this menu.
Figure (12) Channel Class Menu
Channel Guide->Channel classChannel Guide->Channel class
NO TV Favor Movie News Show
0001
0002
0003
0004
Xx
Xxx
Xxxx
Xxx
Enter key to check/uncheck
TV/RADIO key to switch TV/RADIO
Enter key to check/uncheck
TV/RADIO key to switch TV/RADIO
The setup menu system---DVB PART Advanced Features
-33- -34-
Figure (5) Main Menu + Channel Guide Figure (6) System Config Menu
Figure (7) Installation Menu Figure (8) Game Menu
Upon entering the main menu, the first item, Channel Guide, will already be highlighted. Use the <UP> or
<DOWN> buttons to highlight a different item. Press <ENTER> to enter a new menu corresponding to the
highlighted item. The submenus are their items include:
Channel Guide:
This includes TV Channels, Radio Channels, Channels Class, and Channels Edit. See Figure (5).
System Config:
This includes TV Setting, Video Setting, Audio Setting, Language, Parent Control, Time Setting, and
System Info. See Figure (6).
Installation:
This includes Auto Scan, Manual Scan, and Default Setup. See Figure (7).
Game:
This includes Boxman and Burning Tetris and Hit Rat. See Figure (8).
Channel guide -> TV ChannelChannel guide -> TV Channel
Channel guide
System Config
Installation
Game
TV Channels
Radio Channels
Channels Class
Channels Edit
Book List
Channel guide -> TV ChannelChannel guide -> TV Channel
Channel guide
System Config
Installation
Game
TV Setting
Video Setting
Audio Setting
Language
Parent Control
Time Setting
System Info
Channel guide -> TV ChannelChannel guide -> TV Channel
Channel guide
System Config
Installation
Game
Auto Scan
Manual Scan
Default Setup
Channel guide -> TV ChannelChannel guide -> TV Channel
Channel guide
System Config
Installation
Game
Box Man
Burning Tetris
Hit Rat

3.4 Channels Edit
The Channel Edit Menu is shown in Figure (13). To change a channel name, select a channel
name and press <ENTER>. From here, use <LEFT> or <RIGHT> to select a character, and <UP> or
<DOWN> to change the character. Press <ENTER> to confirm the name change. To move a channel,
select the MOVE column of a channel and press <ENTER>. From here, use the <UP> or <DOWN> to change
the placement order of the channel, and <ENTER> to confirm the change. Select the DELETE column and
press <ENTER> to delete the channel. Use <TV/RADIO> to change between TV and radio channels. Note:
If there are no channels available, this user cannot be entered.
Figure (13) Channel Edit Menu
Channel Guide->Channel EditChannel Guide->Channel Edit
NO TV Move Delete
0001
0002
0003
0004
Xx
Xxx
Xxxx
Xxx
UP/DOWN key to move program
ENTER key to finish move
UP/DOWN key to move program
ENTER key to finish move
3.5 Book List
It will display all the program events you have booked in your EPG menu or manual added.
To manually set the program in the Booklist move with the arrow buttons and select the desired parameters.
4. System Config
4.1 TV Setting
From the TV Setting Menu, shown in Figure (14), the TV system, video output, and TV aspect ratio can be
changed. Press <UP> or <DOWN> to select one of the items. To change the setting, press <LEFT> or
<RIGHT> to cycle between the different settings, or press <ENTER> and then <UP> or <DOWN> to select
from a list of settings. The possible settings are:
TV System: NTSC, PAL, Auto. See Figure (15).
Video: YCbCr, TV-RGB, P-SCAN-YUV, PC-VGA, S-VIDEO. See Figure (16).
TV Type: 4:3 Pan-and-Scan, 4:3 Letterbox, 16:9. See Figure (17).
Figure (14) TV Setting Menu Figure (15) TV System
TV Setting -> TV SystemTV Setting -> TV System
TV System
Video
TV Type
PAL
YCbCr
4:3PS
TV Setting -> TV SystemTV Setting -> TV System
TV System
Video
TV Type
Auto
YCbCr
4:3PS
NTSC
PAL
Auto
NTSC
PAL
Auto
The setup menu system---DVB PART Advanced Features
Figure (16) Video Figure (17) TV Type
TV Setting -> TV SystemTV Setting -> TV System
TV System
Video
TV Type
Auto
YCbCr
4:3PS
4:3PS
4:3LB
16:9
4:3PS
4:3LB
16:9
TV Setting -> TV SystemTV Setting -> TV System
TV System
Video
TV Type
Auto
YCbCr
4:3PS
YCbCrYCbCr
P_SCAN_YUVP_SCAN_YUV
S_VIDEOS_VIDEO
4.2 Video Setting
From the Video Setting Menu, shown in Figure (18), the video brightness, contrast, hue, and
saturation can be changed. Press <UP> or <DOWN> to select one of the items. To change
the setting, press <LEFT> or <RIGHT> to cycle between the different settings. Alternatively,
press <ENTER> to select from a list of possible settings.
Figure (18) Video Setting Menu
Settings:
Brightness: 0, 2, 4, 6, 8, 10, 12.
Contrast: 0, 2, 4, 6, 8, 10, 12.
Hue: +12, +10, +8, +6, +4, +2, 0.
Saturation: 0, 2, 4, 6, 8, 10, 12.
Brightness
Contrast
Hue
6
6
0
Saturation 0
4.3 Audio Setting
From the Audio Setting Menu (Figure (19)), the Audio Out option can be changed using the
<LEFT> or <RIGHT> keys. Alternatively, press <ENTER> to select from a list of possible settings. Audio
Out: SPDIF OFF, SPDIF RAW, SPDIF PCM.
Figure (19) Audio Setting Menu
Audio Setting -> Audio OutAudio Setting -> Audio Out
Audio Out SPDIF/OFF
SPDIF/OFF
SPDIF/RAW
SPDIF/PCM
SPDIF/OFF
SPDIF/RAW
SPDIF/PCM
The setup menu system---DVB PART Advanced Features
-35- -36-

4.4Language
The Language Menu, shown in Figure (202), allows the user to change the OSD language. Use
the <LEFT> or <RIGHT> to select a language, or <ENTER> to select from a list with all the possible
languages. OSD Language: English, German, French, Greece.
Figure (20) Language Menu
The setup menu system---DVB PART Advanced Features
Language -> OSD Language
OSD Language English
ENGLISH
FRENCH
SPAISH
GERMANY
ITALIAN
Holand
System Info System Info displays the firmware version and date, along with tuner and model information.
See Figure (28).
Figure (28) System Infor
System Info -> INFO PAGESystem Info -> INFO PAGE
UPDATE DATE:
TUNER INFO:
F/W VERSION:
MODEL VERSION:
The setup menu system---DVB PART Advanced Features
-37- -38-
4.5 Parent Control
The Parent Control Menu, Figure (21), has two items, Change Pin and Channel Lock. When changing the
pin, the user will be asked to enter the old pin, the new pin, and the new pin again (Figure (22)). In order to
change the channel lock, the user must first enter the pin, as shown in Figure (23). If the pin is okay,
the Channel Lock Menu will appear (Figure (24)). Use <UP> or <DOWN> to select a channel, <ENTER> to
lock or unlock the channel, and <TV/RADIO> to switch between television and radio channels.
Figure (21) Parent Control Menu Figure(22) Change Pin
Figure (23) Enter Pin Figure(24) Channel Lock
Parent Control -> Change pinParent Control -> Change pin
Change pin
Press ENTER
Channel Lock
Press ENTER
Old Pin:
New Pin:
Confirm:
Old Pin:
New Pin:
Confirm:
Parent Control -> Change pinParent Control -> Change pin
Change pin
Press ENTER
Channel Lock
Press ENTER
Parent Control -> Channel LockParent Control -> Channel Lock
Change pin
Press ENTER
Channel Lock
Press ENTER
Password:Password:
Parent Control -> Channel LockParent Control -> Channel Lock
0001
No
0002
0003
0004
TV
XXXX
XXXXXXX
XXX
XXXXX
Lock
4.6Time Setting
From the Time Setting Menu, Figure (25), the time zone and sleep settings can be changed.
Use <UP> or <DOWN> to select an item, and <LEFT> or <RIGHT> to change the setting. Alternatively, the
user can press <ENTER> to select from a list of possible settings.
Figure (25) Time Setting Menu Figure (26)
Time Setting -> Time ZoneTime Setting -> Time Zone
Time Zone
GMT +2
Sleep
Off
GMT+5
GMT+6
GMT+7
GMT+8
GMT+9
GMT+10
GMT+11
GMT+5
GMT+6
GMT+7
GMT+8
GMT+9
GMT+10
GMT+11
Figure (27)
GMT +2
Time Setting -> Time ZoneTime Setting -> Time Zone
Time Zone
Sleep
Off
GMT +2
OFF
10 min
20 min
30 min
40 min
50 min
60 min
OFF
10 min
20 min
30 min
40 min
50 min
60 min
Time Zone
Sleep
Off
