AEG 30" DEO76 User manual

User’s Manual
DEO76 30” Built-in Double Oven -
User’s Manual

2
Congratulations on the purchase of your AEG appliance.
We are sure it will provide many years of great cooking experience.
You may find that it has different features and characteristics to your last
appliance.
It is essential you read this operation manual thoroughly to fully understand all
of the various functions and operations. Experiment with your cooking and take
advantage of the features your new appliance offers.
This manual should be retained for future reference. Should ownership of the
appliance be transferred, please ensure that the manual is also passed onto the
new owner.
Contents
A - Installation check and warnings Page 3
B - Accessories Page 4
C - Using the appliance for the first time Page 5
D - Electronic Programmer Operation Page 6-8
E - Cooking modes and instructions Page 9-16
F - Cleaning and maintenance Page 17-19
G - Trouble shooting guide Page 21
H - Installation instructions Page 21-27
I - Electrical wiring diagrams and instructions Page 28-30
J - Warranty Page 31

3
A - Installation check and warnings
IMPORTANT:
Please ensure that the oven cavity, venting and wiring is as specified in the relevant section H of
this manual. It is important to the performance of the oven to allow sufficient air circulation
around the appliance.
All installation, adjustments and maintenance operations must be carried out by qualified
technicians in accordance with the enclosed instructions and current installation standards. The
manufacturer accepts no liability for faulty installation, setting, handling and use of the oven.
A licensed electrician must perform electrical work when installing or servicing the appliance. The supply
cable and fuse rating must be suitable for the appliance. You must never repair or replace any part of
the appliance unless specifically recommended in the operation manual. Refer to section I of this
manual for electrical instructions.
Ventilation opening must not be covered or obstructed in any way.
NOTE: DO NOT use aluminum foil on the base of ovens
The use of foil on the base of the oven to avoid spillage and improve cleaning is not recommended. The
bottom element is concealed under the base of the oven liner (not exposed). Foil or dishes with
reflective qualities must never be placed on the base of the oven during cooking as the concentration of
direct and reflected heat will damage the enamel surface.
Damage resulting from such use is not covered under the provisions of the warranty.
Initial heat up
Some smoke and smell may be noticed during the initial heat up cycle. This should quickly dissipate.
If abnormal levels of smoke are observed (i.e.: it is not food that is burning), have the appliance
thoroughly checked.
Don’t use the appliance as a space heater
The appliance must never be used for warming or heating the surrounding room. Combustible materials
must never be placed on or near the appliance.
Do not leave children alone
Children must not be left unsupervised in the area where the appliance is in use. Children must never be
allowed to sit or stand on any part of the appliance.
Wear proper apparel when using the appliance
Loose fitting, hanging or highly flammable garments (such as synthetics) should never be worn while
using the appliance.
Use only dry pot holders
Moist or damp pot holders on hot surfaces may result in burns from steam. Do not allow pot holder to
touch hot heating elements. Do not use a towel or bulky cloth when handling hot cooking utensils in the
appliance.
Oven compartments must never be used for storage
Items, particularly flammable materials, must never be stored in an oven or near surface units.

4
Do not use water on grease fires
Fires or flame should be smothered using flameproof material or extinguished using a dry chemical or
other suitable fire retardant.
When the cooker is not in use, ensure that all the knobs are in the off position. Furthermore, if it is
unused for a period of time, shut off the mains electricity supply for the appliance.
B - Accessories
Your appliance should come equipped with the following items.
Single Oven – B3007M-m, SEO 90
1 x pair of Retractable Slide Runners capable of being moved to any selected position
1 x Deep Enameled Roasting Pan with dual height reversible Grill Rack insert – ready for sliding
into side rack positions or fitting onto Retractable Slide Runners
2 x Wire Oven Shelves that can be fitted into Retractable Slide Runners or for sliding into side
rack positions
Note: Additional Retractable Slide Runners are available as an optional extra and can be fitted
at any time
Note: Additional oven shelves and pans are available as optional extras.
Double Oven – D2006M-m, DEO 76
Note Upper Oven as per Single Oven above
Lower Oven
1 x pair of Retractable Slide Runners to accommodate Enameled Grill Pan or Wire shelves
1 x Deep Enameled Roasting Pan with dual height reversible Grill Rack insert
2 x Wire Oven shelf that can be fitted onto Retractable Slide Runners or for sliding into side rack
positions

5
C - Using the appliance for the first time
After installation remove all notification labels (not identification or warning labels) and packaging
materials. After cleaning make sure cleaned surfaces are thoroughly rinsed and wiped dry using a clean,
soft cloth.
Power on
NOTE: Oven will not operate unless time clock is set
When power is first applied the display will flash and shows 00:00.
The time of day is displayed in digital 24 hour format (e.g.: 18:00 is 6:00 pm). Press the reset button to
select manual mode and set clock as describe in section C.
Burning in
Before cooking in the appliance an initial pre-heating is required to burn off the fine oil film used to
protect the elements for shipping. The first time you heat up the oven (or grill) the oil will be given off as
smoke, which is perfectly normal.
Select a cooking mode and set the oven temperature to 180°C. With the oven door closed, leave for
approximately 5 minutes.
Repeat the above step for each cooking mode.
After completing the above make sure all controls are turned off. The oven is now ready for cooking and
grilling.

6
D - Electronic Programmer Operation
The 24 hour clock allows the setting of automatic cooking options up to 24 hours in advance.
1 - Minus Time Button
2 Mode (Countdown Timer with Alarm, Cooking duration, End Time)
3 +Plus Time Button
IMPORTANT – NOTE FOR NEW INSTALLATION AND FIRST OPERATION
Setting the time on the 24 hour clock
1- The clock will require setting when you first turn on the power (or following a power failure).
2- At power on, the relay contact is opened. The display and AUTO symbol flashes and time of
day starts from 0:00.
3- Press PLUS and MINUS button simultaneously for minimum 3 seconds. The AUTO symbol
goes out, POT symbol goes on, the DOT is flashing. With the PLUS button the time will
advance slowly, and then speed up. If you over-shoot the desired time , use the MINUS button)
4- Press the MODE button twice to display the time of day. The oven will be in manual cooking
mode, with POT symbol displayed.
5- The oven is now ready for use and to accept the selected cooking functions
Setting the timer
6- The timer can be set for countdown up to 24 hours and for automatic cooking modes up to 10
hours and will countdown to zero. When zero is reached the alarm will sound.
7- To set the countdown timer, press the MODE button for minimum 3 seconds. The
BELL symbol is flashing and the display shows 0:00. Using the PLUS button advance
the timer to the desired time.
8- Once the countdown timer is set, the normal time of day will return to the display within 7
seconds. If you wish to check how much time remains on the countdown, press the MODE
button for 3 seconds. The remaining time will be displayed. After 7 seconds the normal time will
return to the display.
9- To silence the alarm press the MODE button for minimum 4 seconds.

7
Adjusting the tone of the electronic timer alarm.
There are 3 different tones from which you can select. To change the tone you press the “+” and “-“
simultaneously, then press the Mode button once, Ton will be displayed. Pressing the “-“ button while
ton is in the display, will change the tone to the desired setting, then press the mode button once.
The electronic timer will store in its memory the last tone activated.
Manual cooking
Once the time of day is set the POT symbol will be displayed. The oven is now in manual operation
mode ready for you to select the desired cooking function and temperature
Automatic cooking modes (Based on setting the duration “DUR”)
Set cooking mode and temperature to the desired position
For example: if you wish to cook for 45 minutes. Press the MODE button minimum for 4 seconds. Press
the MODE button again. The AUTO symbol is flashing and the display shows “dur”. The display
automatically switches over between "dur" display and 0:00. During this time you can set the duration
time of 45 minutes by pressing the PLUS button (use MINUS button should you over-shoot the required
time). Release and the display will return to the normal time of day after 7 seconds. The AUTO symbol
will also appear indicating that you have set the automatic cooking function.
The oven will operate for 45 minutes only, turn off automatically and the alarm will sound. The AUTO
symbol is flashing and the POT symbol will disappear. The alarm will turn off after pressing the MODE
button.
If you hold the MODE button down longer than 4 seconds the oven will return to the normal cooking
mode.
If further cooking is required, either leave on manual or repeat the above setting sequence.
Note: If you have not turned the cooking mode and temperature setting off, your oven will continue to
operate manually. The AUTO symbol will disappear and the POT symbol will reappear.
Setting a cook end time
1 Set the cooking mode and oven temperature control to the desired position
2 For example: if you would like the oven to turn off at 6.00pm: press the MODE button minimum
for 4 seconds. (Display shows 00:00 with Bell symbol flashing). Press the MODE button two
times again. The AUTO symbol is flashing and the display shows “End”. The display
automatically switches over between "End" and time of day. During this time you can set the
cooking stop time to 6.00pm, i.e.18:00 on the 24 hour clock, by pressing the PLUS button (use
MINUS button should you over-shoot the required time). Release and the display will return to
the normal time of day after 7 seconds. The AUTO symbol will also appear indicating that you
have set the automatic cooking function.
3 The oven will continue to cook until 18:00 (6.00pm) and then switch off and the alarm will sound.
The AUTO symbol is flashing and the POT symbol will disappear. The alarm will turn off after
pressing the MODE button.
4 If you hold the MODE button pressed longer then 4 seconds the oven will return to the normal
cooking mode.
Canceling automatic settings
To cancel a program, press plus and minus button simultaneously for minimum 3 seconds.
If further cooking is required, either leave on manual or repeat the above setting sequence.

8
Note: If you have not turned the cooking mode and temperature off, your oven will now continue to
operate manually. The AUTO symbol will disappear and the POT symbol will reappear.
Fully automatic – (Start Later – Stop Later)
Your oven may be programmed to start, cook for the desired time and turn off automatically.
This function is particularly useful in the preparation of the evening meal, should you be out during the
day, it will be ready on your return home. For example if your cooking time is 45 minutes and you want
the cooking to finish at 6.00 p.m.
1. Press the MODE button minimum for 4 seconds, display shows 00:00. Press the MODE button again,
display shows Dur. Set the cooking duration time for say 45 minutes using the PLUS or MINUS
button.
2. Press the MODE button again, display shows End. Set the stop cooking time to 6.00pm (18:00).
Release and the display will return to the normal time of day after 7 seconds. The AUTO symbol will
be displayed.
3. Using the above settings, the oven is now programmed automatically to commence cooking 45
minutes prior to 18.00. (The AUTO symbol and POT symbol will be displayed). Then automatically
turn off.
When cooking is complete the AUTO symbol is flashing and the POT symbol will disappear and the
alarm will sound. The alarm will turn off after pressing the MODE button.
4. If you hold the MODE button longer then 4 seconds the oven will return to the normal cooking mode.
NOTE:
On oven start up or possibly at other times, due to electricity supply deviations – the set
program may freeze on a function – if this occurs we recommend that, after checking other
solutions without success, it is recommended that power supply be disconnected to the
appliance for 5 minutes before reconnecting. This may have a result of clearing the frozen
position allowing you to reset the clock/timer for normal operation.
Cooling Fan
The Single and Double Ovens are provided with a cooling fan motor to reduce the heat around the oven.
The fan motor is controlled by a sensor, which will start when the oven is on and stop working when the
temperature is reduced accordingly.
This safeguards both the oven and the adjoining cupboards from the possibility of temperature damage.
Safety Thermostat
Your oven is fitted with an oven temperature sensor that will automatically shut down your oven for a
period if it is deemed to be overheating- this sensor is fitted to the rear wall of the oven, inside the outer
case – it will only activate in extreme circumstances and is provided as protection to the appliance and
the adjoining furnishings. If activated it will shut down the appliance for a short time and will
automatically reset allowing normal operations – you should consult your service technician if the
problem re-occurs.

9
E - Cooking modes and Instructions
NOTE: cooking functions will vary from model to model – following is a description
of the functions that are available and some or all of these functions will be included on
the product you have purchased.
Single Oven
Double Oven
PREHEATING
Preheating the oven is not essential, but you will achieve better results if you do. Some foods,
particularly cakes and pastry, are better cooked in a preheated oven. Other foods, for example
casseroles, cook just as well when cooked in a non-preheated oven but may need longer cooking times.
For faster preheating select pizza mode and the required temperature and once the oven has reached
the required level change to cooking mode/function for the task.
To preheat the oven:
1- Set the mode required for preheating.
2- Set the oven to the desired temperature
3- The oven has reached the set temperature when the pilot light above the thermostat turns off.
Preheating guide (for 180°C settings)
Cooking Mode Preheat Time
CONVENTIONAL MODE 20-30 MINUTES
PIZZA MODE 15-20 MINUTES

10
NOTE:
Any food or other cooking utensils placed in the oven during preheating will affect the preheating time.
The preheat time may also vary with installations.
WARNING
When using an alternative cooking mode for fast preheat, be sure to turn the cooking mode to your
required setting before placing food in the oven.
HINT:
To allow for heat loss while placing food into the oven, preheat the oven 10-20°C higher and then reduce
the temperature to your required cooking temperature.
Always preheat the oven when cooking multiple dishes at the same time.
Roasting guide. These cooking charts are intended as a guide only. Temperature, cooking mode and
cooking times may vary to suit individual tastes.
Type of Meat
Approx. 450 grams =
1lb
Cuts of Meat Time per lb
(allow) Oven Temperature
0C
Beef
Prime Rib, rolled
sirloin bolar blade,
Top Loin, New York
Strip Sirloin
30 minutes per 1lb
20 minutes per 1lb
1800– 2000
1800- 2000
Veal Shoulder or leg (with
bone or rolled) 20-25 minutes per 1lb 1800- 2000
Lamb Leg, shoulder (loin or
rolled) 20-25 minutes per 1lb 1800- 2000
Pork Leg loin 45 minutes per 1lb 2200-2300/ 1800-2000
Pork leg should be cooked at a higher temperature for the first 15-25 minutes then reduced to lower
temperature for remaining cooking time.
Type of Poultry Size of Meat Time per lb Oven Temperature
0C
Chicken Whole or pieces 30 minutes per lb. 1800- 2000
Duck 3lbs – 4.1lbs 30 minutes per lb.
+ 35 minutes extra 1800- 2000
Turkey 5.4lbs – 21lbs 40-50 minutes per lb.
+ 35 minutes extra 1800- 2000
Turkey should be well basted and turned during cooking
Type of Fish Cuts of Fish Time per lb Oven Temperature
0C
Fish Whole or fillets 10 minutes per lb. 170-1900C
In Conventional Oven mode, fish should be covered for the first ¾ of the cooking time to help retain
moisture.

11
Baking guide. These cooking charts are intended as a guide only. Temperature and cooking times may
vary to suit individual tastes.
Oven Temperature 0C General Times Foods Suitable
1300– under Very slow Small meringues, pavlova, custard, reheating
1300- 1500Slow Rich fruit cake, light fruit cake
1500- 1800Moderate Casseroles, deep butter cake
1800- 2000Moderately hot
Shallow butter cakes, sponges, biscuits, meat loaf,
baked fish
2000- 2300Hot Swiss roll, patty cakes, rock cakes, short crust pastry
2300– and over Very Hot Scones, Choux pastry
CONVERSION GUIDE
50oC = 120oF
PLATE
WARMER
100oC = 210oF
SIMMER
150oC = 300oF
SLOW ROAST
175oC = 350oF
BAKING
200oC = 390oF
ROASTING
250oC = 480oF
HIGH ROAST
275oC = 525oF
BROIL OR
GRILL

12
STEAM CLEAN ASSIST
Traditionally, oven enamels have been porous. This creates a surface that, over time, collects
microscopic oil and grime deposits that build up within these pores and become nearly impossible to
remove.
Thanks to some of the latest technology, we have revolutionary new enamel which is much less porous
than predecessors and creates a surface that has glass-like characteristics.
Added to this breakthrough technology, we have incorporated a new component into the enamel that is
non-stick. The two together creates a surface that is brilliantly effective and easy to clean.
To assist with easy cleaning, AEG have developed a Steam Clean function. Not only is this
environmentally friendly, it is also less severe on the oven surfaces as no harsh chemicals are used. In
addition to this, the power consumption normally needed by a traditional Pyrolytic Oven have been
minimized to reduce unnecessary energy use. This new enamel is also acid resistant which ensures that
stains around the walls of the oven liner are minimized, and particularly if the new Steam Clean function
is used regularly.
If the following simple Steam Cleaning procedure is adopted regularly, your oven should remain in
original condition for many years.
To activate Steam Cleaning follow these simple steps:
After completion of cooking cycle, turn oven off and allow to cool. The oven must be cold before
commencing steam cleaning.
1. When oven is cold, activate the steam clean function as follows,
2. Add approximately ½ a liter (1 Pint) of clean water to an oven safe dish and place on the
lowest rack. Add a small amount of dishwashing liquid to water to help remove stubborn
stains.
3. Close the oven door and select the Steam function on the Mode selector.
4. Select Steam on the Temperature Selector
5. Run the oven in this mode for approximately 45 minutes (set timer if preferred to remind)
6. After 45 minutes of steaming, turn both the Steam Mode selection and Steam Temperature
selection off . DO NOT OPEN OVEN DOOR FOR 30 min. allowing oven to cool to a safe
temperature for you to access it.
7. If not already done, remove the oven shelves and fittings. You can also wash these either in
your dishawasher or by hand.
8. With a warm damp cloth, simply wipe out grease from inside the oven. You should apply a
small amount of dish washing liquid to this cloth for further efficiency. It will be noted that
most grime has congregated on the base of the oven and is easily wiped away.
NOTE: If stubborn stains remain after Steam Clean apply Ceramic Cooktop
Cleaner/Polish.

13
CONVENTIONAL OVEN
In this traditional mode, oven heat is provided from the top and under the oven compartment and is most
suitable when cooking on a single shelf. For best results, arrange the shelves so the top of the food is
near the centre of the oven.
If cooking on more than one shelf, always preheat the oven and position the pans to allow as much free
circulation of heat as possible.
Depending on the food, you may need to rearrange the tray position during cooking.
1- Adjust oven shelves to desired position/s.
2- Select Conventional Oven mode.
3- Set the oven to the desired temperature.
4- When cooking is complete turn the oven off.
HINT:
If water is used in your cooking (such as water placed in a baking dish) the water will evaporate in the
oven in the form of steam. The level of condensation will be reduced when cooking in fan oven mode
where excess moisture is circulated and evaporates during the cooking cycle.
NOTE:
Stand clear of the oven when opening the oven door as steam may escape rapidly
FAN FORCED CONVECTION – most commonly used function
In this mode the oven fan circulates heat from behind the fan cover to give a more even temperature
throughout the oven. The even heat provides similar cooking results for each portion of food. Although
temperatures for cooking foods in this type of oven are generally the same as required by a conventional
oven, when cooking foods that require lengthy cooking cycles a fan forced oven normally cooks more
quickly, saving time and energy.
Always place the food as near to the centre of the oven as possible. If cooking on more than one level,
arrange the pan positions to allow for free circulation of heat.
1- Adjust oven shelves to desired position/s.
2- Select FAN OVEN mode.
3- Set the oven to the desired temperature.
4- When the cooking is complete turn the oven off.
HINT:
Always preheat the oven when cooking on multiple shelves at the same time.
Depending on the food, you may need to rearrange the tray positions during cooking.
DEFROST
All foods may be defrosted using the Fan Forced Convection mode. It is important to note that
NO temperature (0 Degrees) is selected when using this function.
As a general guide, the defrosting time for meat is approximately 15-20 minutes per lb.

14
FAN ASSIST
This style of cooking provides traditional cooking heating from top and bottom elements with the
assistance of a circulation fan to ensure fast even results. This mode is most suitable for delicate
cooking such as cakes, pastries, gateaux, biscuits and yeast dough. Best results when thermostat is set
to 150-180 degrees – depending on recipe.
Depending on the food, you may need to rearrange the tray position during cooking.
5- Adjust oven shelves to desired position/s.
6- Select Conventional Oven mode.
7- Set the oven to the desired temperature.
8- When cooking is complete turn the oven off.
FULL GRILL & HALF GRILL
This mode of cooking uses direct heat from the top of the oven to cook foods to your requirements. Half
grill engages only the inner band of the top element and is suitable for smaller volumes and
consequently has a lower energy usage.
This method of grilling in the oven is recommended for short duration (5 minutes or less) grilling
only, which is ideal for toasting (see note below). Foods with higher fat content or foods, which
require more than 5 minutes grilling time, should be grilled using the FAN GRILL mode.
When in GRILL mode the oven door should be opened.
1- Commence grilling from a hot oven whenever possible.
2- Place food on grill rack and pan supplied.
3- Position the shelf to your preference.
4- Select GRILL mode and, turn to your desired heat setting.
5- When cooking is complete turn the oven off.
NOTE:
The grill element is controlled by the oven thermostat. Once the temperature in the oven has reached
the selected temperature the element will switch off, and then on again, when more heat is required.
FAN GRILL
NOTE: Door must be closed in Fan Grill Mode
Fan grilling is a combination of direct heat and circulated hot air which gives the appearance and flavor
similar to rotisserie cooking which is ideal for single level roasts. Direct infrared heat from the grill
element is circulated by the fan to cook the food, which should be positioned as near to the centre of the
oven as possible.
For best cooking results, it is recommended that food be turned once only.
1- Oven door must be closed in Fan grill mode.
2- Place food on grill rack and pan supplied (ensure grill rack is inverted to the high position to
allow best circulation of air) as close to the centre of the oven as possible.

15
3- Select FAN GRILL mode.
4- Set the oven to the desired temperature. (see note below and refer to FAN GRILL temperature
guide).
5- When cooking is complete turn the oven off.
NOTE:
Large grill pans or roasting dishes can restrict the circulation of air in the oven. To prevent moisture
condensing in the cooler lower sections of the oven, preheat the oven for approximately 10 minutes,
using CONVENTIONAL OVEN or HIGH BAKE modes, prior to fan grilling.
NOTE: The temperature setting in FAN GRILL mode must not exceed 200°C. The grill element
has a safety shutdown at approximately 200°C.
Fan grill guide
These cooking charts are intended as a guide only. Temperatures and cooking times may vary to suit
individual tastes.
Type of meat/poultry/fish Oven Temperature 0C Approximate Cooking Time
Chicken – whole
pieces 1750- 1850
1850- 195030 minutes per lb 15-20 minutes
Lamb - loin/rack
Chops - medium/rare
Chops – medium
1750- 1850
1750- 1850
1750- 1850
25 minutes per lb
10-12 minutes
14-16 minutes
Beef- Steak – rare
Steak – medium
Steak – well done
1750- 1850
1750- 1850
1750- 1850
6-8 minutes
8-12 minutes
12-15 minutes
Pork Chops – medium/rare
Chops - medium
Chops – well done
1900- 2000
1750- 1850
1750- 1850
6-10 minutes
10-12 minutes
12-15 minutes
Sausages- thin
thick 1750- 1850
1750- 1850 8-10 minutes
12-14 minutes
Fish fillets
1750- 1850
10-14 minutes
Sliced vegetables
Tomato halves
Crumb Based dishes
Pasta dishes
1800- 1900
1900- 2000
1750- 1850
1750- 1850
20-30 minutes
6-8 minutes
20-30 minutes
20-30 minutes
HIGH BAKE
The HIGH BAKE mode uses the oven fan to circulate air with heat from the concealed bottom element.
Quick and consistent heat is evenly distributed throughout the oven.
The results are quick, not unlike a microwave oven. With the circulation of heat, foods cooked with high
bake mode retain a crisp, dry texture on the outside especially pizza, pastry and other foods where you
want the base to be well cooked. HIGH BAKE is also excellent for re-heating.
1- Adjust oven shelves to desired position/s.
2- Select HIGH BAKE mode.
3- Set the oven to the desired temperature.
4- When cooking is complete turn the oven off.

16
CLASSIC BAKE (bottom of double oven)
In this mode, oven heat is provided from the concealed bottom element. This is most suitable for cooking
food which requires a well cooked base or where minimal browning is required.
1- Adjust oven shelves to desired position/s.
2- Select CLASSIC BAKE.
3- Set the oven to the desired temperature.
4- When cooking is complete turn the oven off.
PIZZA
This function is also excellent as the fastest oven pre heat, engaging maximum power to heat the oven
to a selected temperature before selecting an appropriate function and temperature for a task.
In this position the fan and fan element together with the concealed bottom element are engaged
simultaneously. This is used for food that requires a concentration of cooking to the base, and allows
the top to gently cook at the same time.
F - Cleaning and Maintenance
NOTE:
Your AEG oven comes with a Steam Clean function, please refer to page 12 for further
instructions.
1. Cleaning and maintenance
Proper cleaning and care of your appliance is essential to maintain its appearance and durability.
NOTE:
People with sensitivity to cleaning chemicals must take the necessary precautions. It is recommended
that protective gloves be worn while cleaning the appliance. Routine cleaning of the appliance should
only be performed when the appliance is at room temperature.
Do not use any acid or caustic cleaners, abrasive powders or scourers on the interior or exterior
of the appliance. Substances or items with these properties may discolor or damage the finishes of
your appliance. If any abrasive, acidic or caustic substance or cleaning agent should come into contact
with the appliance, rinse off immediately with water, taking special care to avoid injury if surfaces are
hot.
When using the appliance, it may be soiled by food spills and spatters or foreign items such as plastics
accidentally coming into contact with warm or hot surfaces. Foods which contain acidic substances or
sugar can discolor or damage enamel finishes.
The enamel interior of the oven is a hard durable finish which is resistant to wear and discoloration.
However, to maintain the appearance and durability of the finish any spills must be wiped off as soon as

17
it is safe to do so. Once cool the affected area should be thoroughly cleaned and rinsed using non-
abrasive, mild cleaning detergents and water.
2. Care for stainless steel
No metal is indestructible and certain procedures should be followed to maintain the finish and durability
of stainless steel.
Never leave stainless steel items unwashed. The surface responds best to gentle cleaning methods,
scouring materials and harsh abrasives should not be used. Frequent washing with water (preferably
hot) is the recommended treatment, followed by rinsing with fresh clean water and wiping dry with a soft
cloth or paper towel.
A little soap or detergent may be added to the washing water but too much can produce a cloudy film
over the appliance. Use of steel wool is not recommended but stainless steel wool (a fine mesh pad) is
an excellent cleaning aid. Oil or grease in the washing water can leave a rainbow film when it dries. It
can easily be removed by simply using polishing and cleaning methods described previously.
Thoroughly rinsing with clean water is the real secret and it a surprise how easily stainless steel can be
kept sparkling clean by using the above simple method.
Never leave stainless steel to dry by itself.
3. Only place cookware on oven shelves.
Other surfaces such as trims are not totally resistant to hard materials or direct heat and may be
permanently damaged by such use.
Recommended cleaners
Mild detergents and warm water together with a clean, soft, non-abrasive cloth achieve good results for
normal cleaning. Diluted washes with ammonia and water should rinse away any adhesive residue or
gummy deposits on the appliance surfaces. Eucalyptus oil (small amounts) is also good for removing
adhesive residue. Alcohol based products (eg: methylated spirit, etc.) are not recommended. Brand
name cream cleansers and concentrates, without abrasive qualities, can be used in small amounts to
break down greasy deposits and dirt. After cleaning make sure cleaned surfaces are thoroughly rinsed
to prevent any risk of baked on cleaner residues and wipe dry with a clean, soft cloth.
If using commercial oven cleaners, choose only non-caustic cleaners and follow the manufacturer’s
instructions. (Avoid contact with elements, rubber door seals and exterior surfaces.)
NOTE:
When cleaning stainless steel surfaces AEG recommend 3M brand or Advance stainless steel cleaner.
Other reputable brand cleaners specifically formulated for cleaning stainless steel may also be
acceptable. Do not use steel soap pads or abrasive scourers of any kind. The abrasive qualities of these
pads will ruin the even brushed finish of the stainless steel and any residual metal fibers may corrode
causing a rusty/dull appearance. Metal polishes with abrasive qualities are also not recommended.
WARNING:
Do not use any acid or caustic cleansers or abrasive powders or scourers on the interior or
exterior of the appliance.

18
Routine cleaning
Ensure all controls are in the off position and the appliance is cool before cleaning. When wiping
stainless steel surfaces with a brushed finish, wipe in the same directions as the brushing.
To clean the oven interior, fully open or remove the door/s (top opening type, see opposite page) for
better access while cleaning. The shelves and shelf guides can be lifted out for cleaning by removing the
relevant thumb screws. The shelves and shelf guides can be washed manually but are also dishwasher
safe.
After cleaning make sure all surfaces are thoroughly rinsed and wiped dry with a clean, soft cloth.
Drop Down Grilling Element
The removal of a single screw at the front of the upper grill element allows the grill to drop down to
facilitate the cleaning of the oven ceiling. On completion of cleaning, simply replace the grill element and
secure with the screw.
To avoid smoking, use a clean, damp cloth to regularly clean oil and fat splatters from
the exposed drop down grilling element.
The fan cover can be lifted out for cleaning separately by removing the retaining screws. The fan blade
can also be removed for cleaning if necessary.
NOTE: that the fan blade nut has a left-handed thread.
Removing oven door (pull down door models only)
The oven door can be easily removed for better access while cleaning. To remove the oven door:
1. Open the door fully and fit the supplied pin in the hole.
2. Raise the door slightly, holding the sides of the door about half way up. Make sure the pin
stays in the hole the whole time. Lift the door gently. This should disconnect the hinges
from the oven frame.
3. Remove the door by continuing to raise it while pulling the door away from the oven. When
handling the door be careful not to dislodge the pin off the hole. If the pin does dislodge, the
hinge will have to be closed by hand and the pin re-fitted onto the hole before re-fitting into
the oven.

19
To re-fit the oven door:
i. Holding the door at an angle to the oven, slide the hinges into the oven frame, making sure
that on each side the top curved arm fits into the top slot and the lower arm fits into the
bottom slot.
ii. Make sure the hinges are pushed as far as they will go and the lower arm engages into the
plate mounted in the oven frame.
iii. Open the door fully and ensure the pin fully disengages from the hole. The door can now be
opened and as normal.
How to Rotate Doors in the Double and Single Oven
NOTE: Side Opening Only
This should only be done by a qualified person or installer. We recommend that it be a two person task
to ensure support of the heavy door apparatus during changeover. Damage done to the appliance
during a door rotation may effect the warranty provision for the appliance.
Stage1: REMOVE THE BOTTOM DOOR FOR DOUBLE OVEN OR THE MAIN DOOR FOR
SINGLE OVEN
a) Remove the screws fixing the hinge to the oven front frame, being careful to support the
door, then remove the door and place in a safe place
b) Remove the door catch by removing the two screws top and bottom of the door latch on
the opposite side of the oven front frame to the hinges
c) Remove the screws fitted in the thread holes in the oven front frame to allow the re-
positioning of the door hinge to the opposite side
Stage 2: (FOR DOUBLE OVENS ONLY) REMOVE THE TOP DOOR AS PER STAGE 1 ABOVE AND
LEAVE IN POSITION THE FITTED MIDDLE SPACER
4. Remove the screws fixing the bracket of the middle spacer profile
5. Remove the screws fixing the hinge of the top door
6. Remove the door with the middle profile fixed to the hinge, rotate 180° place in a safe place
ready for re-affixing
Stage 3: FITTING THE DOORS – FOR DOUBLE OVENS AND SINGLE OVENS

20
7. For Double Oven re-fit the bottom door first by fixing the hinges with their screws; fix also
the bracket of the middle spacer profile at the same time
8. Re-fit the top door after having rotated it by 180°
9. Re-fit the two door catches in the appropriate oven front frame position – minor adjustment
available later to ensure accurate receipt of door striker pin
10. Re-fit the remaining screws in the thread holes in the oven front frame
The changeover is complete – please check that all screws are fully tightened and that the striker
pin is accurately received by the re-located door latch.
Changing the light globe
The light globe is located behind the glass cover and is a screw-in type.
To change a light globe:
1- Gently lever out the glass cover only.
2- Pull the light globe and push in a replacement globe.
3- Replace the glass cover making sure it fits correctly into place.
NOTE:
Recommended globe: Halogen 40W
G - Trouble Shooting Guide
Symptom Remedy
No power supplied to appliance Has the power been disconnected? Check the meter
box. Has the main fuse or circuit breaker blown or
tripped?
Oven power is on but appliance does not
operate Oven may be set on AUTO (see auto programmed cooking)
Oven power is on but there is no heat Oven may be set on AUTO
Oven temperature may be set OFF
Mode may be on incorrect selection
Rubber seal has gap/s at bottom and
ends do not meet Correct - doors are sealed this way for oven venting purposes
Display is flashing, is only part
illuminated or is cycling through various
displays.
Turn power supply to appliance off, wait 30 seconds and
turn power on. Reset clock
