AEG AHT1852B User manual
AHT1852B
AHT1852BS6
2
2
Important!
It is essential that you read the instructions in this manual
before assembling, operating, and maintaining the product.
Subject to technical modifications.
33
FRONT
HANDLE
FRONT
GUARD
BLADES
BLADE
SAFETY TIP
BLADE
COVER
TRIGGER
REAR HANDLE
LOCK TRIGGER FOR
ROTATING HANDLE
BATTERY
OPERATOR
PRESENCE SWITCH
4
4
START
STOP
6
10
7
8
12
17
13
15
18
55
START
STOP
6
10
7
8
12
17
13
15
18
6
6
1
2
2
1
click
77
START
STOP
8
8
2
1
99
STOP
4
3
10
10
90°90°
click
3
1
2
11 11
6
5
4
12
12
13 13
1
2
4
3
2
1
14
14
5
7
6
21
15 15
12
4
3
2
1
16
16
1
2
5
7
6
17 17
1
2
3
4
18
18
1
2
3
4
19 19
INTENDED USE
The cordless hedge trimmer is only intended for use outdoors. For
safety reasons the product must be adequately controlled by using
two-handed operation.
It is intended to cut and trim hedges, shrubs, and similar vegetation.
It should be used in dry, well-illuminated conditions.
It is not intended to cut grass, trees, or branches. It should not be
used for any other purpose than hedge trimming.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings, instructions,
illustrations and specications provided with this power tool.
Failure to follow the warnings and instructions may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated
(corded) power tool or battery-operated (cordless) power tool.
WORK AREA SAFETY
Keep work area clean and well lit. Cluttered or dark areas invite
accidents.
Do not operate power tools in explosive atmospheres, such as
in the presence of ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.
ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify the
plug in any way. Do not use any adapter plugs with earthed
(grounded) power tools. Unmodied plugs and matching outlets
will reduce risk of electric shock.
Avoid body contact with earthed or grounded surfaces, such
as pipes, radiators, ranges and refrigerators. There is an
increased risk of electric shock if your body is earthed or grounded
Do not expose power tools to rain or wet conditions. Water
entering a power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling
TECHNICAL DATA CORDLESS HEDGE TRIMMER AHT1852B/AHT1852BS6
Rated voltage 18 V DC
No load speed 2700 min-1 (SPM)
Blade length
550
mm
Cutting capacity 26 mm
Weight (without battery) 3.0 kg
Weight with heaviest battery pack 4.2 kg
Noise emission values determined according to EN 60745-1 and EN
60745-2-15
Sound pressure level at operator’s position LpA= 78.4 dB(A)
Uncertainty K= 2.5 dB
A-weighted sound power level LWA= 89.4 dB(A)
Uncertainty K= 2.2 dB
Vibration total values determined according to EN 60745-1 and EN 60745-
2-15
Vibration emission value
Front handle ah = 2.3 m/s2
Rear handle ah = 4.3 m/s2
Uncertainty K= 1.5 m/s2
*SPM (strikes per minute) is the number of strokes the connecting rod completes in one minute.
BATTERY AND CHARGER
Model AHT1852B AHT1852BS6
Battery pack Not included L1860R-X5
Charger Not included BL1218
Compatible battery packs L1815G, L1815R, L1820R, L1825R, L1830R, L1840R, L1850R, L1860R, L1860B, L1890R,
L1860B-X5, L1860R-X5
Compatible chargers BL1218, AL1218G, BLK1218, BL18DP-X5, BL18DP2-X5
WARNING!
The declared vibration value has been measured with a standard test method and may be used to compare one tool with another.
The declared vibration value may be used in a preliminary assessment of exposure.
The vibration emission during actual use of power tool can differ from the declared total value depending on the ways in which the tool is
used.
Identify safety measures to protect yourself based on an estimation of exposure in the actual conditions of use, taking account of all parts of
the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time.
20
20
or unplugging the power tool. Keep cord away from heat, oil,
sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock
If operating a power tool in a damp location is unavoidable,
use a residual current device (RCD) protected supply. Use of
an RCD reduces the risk of electric shock.
PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while
you are tired or under the inuence of drugs, alcohol, or
medication. A moment of inattention while operating power tools
may result in serious personal injury.
Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for appropriate
conditions will reduce personal injury.
Prevent unintentional starting. Ensure the switch is in the off-
position before connecting to power source and/or battery
pack, picking up or carrying the tool. Carrying power tools with
your nger on the switch or energising power tools that have the
switch on invites accidents.
Remove any adjusting key or wrench before turning the power
tool on. A wrench or a key left attached to a rotating part of the
power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power in unexpected situations.
Dress properly. Do not wear loose clothing or jewellery. Keep
your hair, clothing and gloves away from moving parts. Loose
clothes, jewellery, or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction
and collection facilities, ensure these are connected and
properly used. Use of dust collection can reduce dust-related
hazards.
Do not let familiarity gained from frequent use of tools allow
you to become complacent and ignore tool safety principles.
A careless action can cause severe injury within a fraction of a
second.
POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer
at the rate for which it was designed.
Do not use the power tool if the switch does not turn it on
and off. Any power tool that cannot be controlled with switch is
dangerous and must be repaired.
Disconnect the plug from the power source and/or the battery
pack from the power tool before making any adjustments,
changing accessories, or storing power tools. Such preventive
safety measures reduce the risk of starting the power tool
accidentally.
Store idle power tools out of the reach of children and do
not allow persons unfamiliar with the power tool or these
instructions to operate the power tool. Power tools are
dangerous in the hands of untrained users.
Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that
may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are easier
to control.
Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the
working conditions and the work to be performed. Use of the
power tool for operations different from those intended could result
in a hazardous situation.
Keep handles and grasping surfaces dry, clean and free
from oil and grease. Slippery handles and grasping surfaces do
not allow for safe handling and control of the tool in unexpected
situations.
BATTERY TOOL USE AND CARE
Recharge only with the charger specied by the manufacturer.
A charger that is suitable for one type of battery pack may create a
risk of re when used with another battery pack.
Use power tools only with specically designated battery
packs. Use of any other battery packs may create a risk of injury
and re.
When battery pack is not in use, keep it away from other metal
objects, like paper clips, coins, keys, nails, screws or other
small metal objects that can make a connection from one
terminal to another. Shorting the battery terminals together may
cause burns or a re.
Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs, ush
with water. If liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause irritation or burns.
Do not use a battery pack or tool that is damaged or modied.
Damaged or modied batteries may exhibit unpredictable behaviour
resulting in re, explosion or risk of injury.
Do not expose a battery pack or tool to re or excessive
temperature. Exposure to re or temperature above 130 °C may
cause explosion.
Follow all charging instructions and do not charge the battery
pack or tool outside the temperature range specied in the
instructions. Charging improperly or at temperatures outside the
specied range may damage the battery and increase the risk of
re.
SERVICE
Have your power tool serviced by a qualied repair person
using only identical replacement parts. This will ensure that
safety of the power tool is maintained.
Never service damaged battery packs. Service of battery packs
should only be performed by the manufacturer or authorized service
providers.
CORDLESS HEDGE TRIMMER WARNINGS
Keep all parts of the body away from the cutter blade. Do not
remove the cut material or hold the material to be cut when
blades are moving. Make sure the switch is off when clearing
jammed materials. A moment of inattention while operating the
hedge trimmer may result in serious personal injury.
Carry the hedge trimmer by the handle with cutter blade
stopped. When transporting or storing the hedge trimmer
always t the cutting device cover. Proper handling of the hedge
trimmer reduces possible personal injury from the cutter blades.
Hold the power tool by insulated gripping surfaces only,
because the cutter blade may contact hidden wiring. Cutter
blades contacting a “live” wire may make exposed metal parts
of the power tool “live” and could give the operator an electric
shock.
ADDITIONAL SAFETY WARNINGS
Some regions have regulations that restrict the use of the product to
some operations. Check with your local authority for advice. Read
This manual suits for next models
