AEG CHDD 8509 Specification sheet

CHDD 8509
CHDD 8510
Dunstabzugshaube
Afzuigkap
Hotte
Cooker Hood
Campana extractora
Montage- und Gebrauchsanweisung
Installatie- en gebruiksaanwi zing
Notice dutilisation et dinstallation
Operating and Installation Instructions
Instrucciones de monta e y mane o

47
Contents
Safety warnings .............................................................................. 4
For the user ...................................................................................... 48
For the installer ................................................................................. 49
Description of the Appliance ......................................................... 51
Extraction mode ................................................................................ 51
Recirculation mode ........................................................................... 51
Control Panel .................................................................................. 52
Maintenance and care ................................................................... 53
Cleaning the hood ............................................................................. 53
Metal grease filter ............................................................................. 53
Removing the metal grease filter........................................................ 53
Charcoal filter .................................................................................... 54
Changing the light bulb ...................................................................... 55
What to do if ................................................................................... 56
Special accessories ........................................................................ 57
Technical assistance service ......................................................... 57
Technical Details ............................................................................ 59
Mounting accessories included ......................................................... 59
Electrical connection ..................................................................... 60
Wall unit mounting ............................................................................ 61

48
Safety warnings
For the user
 The cooker hood is designed to extract unpleasant odours from the
kitchen, it will not extract steam.
 Always cover lighted elements, to prevent excess heat from
damaging the appliance. In the case of oil, gas and coal fired
cookers it is essential to avoid open flames.
 Also, when frying, keep the deep frying pan on the cooker top/cooker
under careful control.
 The hot oil in the frying pan might ignite due to overheating.
 The risk of self-ignition increases when the oil being used is dirty.
 It is extremely important to note that overheating can cause a fire.
Never carry out any flambé cooking under the hood.
Always disconnect the unit from the power supply before
carrying out any work on the hood, including replacing the
light bulb (take the cartridge fuse out of the fuse holder or switch off
the automatic circuit breaker).
It is very important to clean the hood and replace the filter at
the recommended intervals. Failure to do so could cause
grease deposits to build up, resulting in a fire hazard.
 The appliance is not intended for use by young children or infirm
persons without supervision.
 Older children must be supervised if using the appliance.
 Young children should be supervised to ensure that they do not play
with the appliance.
 WARNING - Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
This appliance is marked according to the European directive 2002/96/
EC on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of
this product.
The symbol on the product, or on the documents accompanying
the product, indicates that this appliance may not be treated as
household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment.
Disposal must be carried out in accordance with local environmental
regulations for waste disposal.
For more detailed information about treatment, recovery and recycling
of this product, please contact your local city office, your household
waste disposal service or the shop where you purchased the product.

49
For the insta er
 When used as an extractor unit, the hood must be fitted with a
150mm diameter hose.
When installing the hood, make sure you respect the following
minimum distance from the top edge of the cooking hob/ring
surfaces:
electric cookers 650 mm
gas cookers 750 mm
If the instructions for installation for the gas hob specify a greater
distance, this must be adhered to.
 The national Standard on fuel-burning systems specifies a maximum
depression of 0.04 mbar in such rooms.
 The air outlet must not be connected to chimney flues or combustion
gas ducts. The air outlet must under no circumstances be connected
to ventilation ducts for rooms in which fuel-burning appliances are
installed.
 The air outlet installation must comply with the regulations laid down
by the relevant local authorities.
 When the unit is used in extraction mode, a sufficiently large
ventilation hole must be provided, with dimensions that are approxi-
mately the same as the outlet hole.
 ational and regional building regulations impose a number of
restrictions on using hoods and fuel-burning appliances connected to
a chimney, such as coal or oil room-heaters and gas fires, in the
same room.
 Hoods can only be used safely with appliances connected to a
chimney if the room and/or flat (air/environment combination) is
ventilated from outside using a suitable ventilation hole approximately
500-600 cm2 large to avoid the possibility of a depression being
created during operation of the hood.
 If you have any doubts, contact the relevant controlling authority or
building inspectors office.
 Since the rule for rooms with fuel burning appliances is outlet hole of
the same size as the ventilation hole, a hole of 500-600 cm2, which
is to say a larger hole, could reduce the performance of the extractor
hood.
 If the hood is used in its recirculation mode, it will operate simply
and safely in the above conditions without the need for any of the
aforementioned measures.
 When the hood is used in its extraction mode, the following rules
must be followed to obtain optimal operation:
- short and straight outlet hose

50
- keep bends in outlet hose to a minimum
- never install the hoses with an acute angle, they must always
follow a gentle curve.
- keep the hose as large as possible (preferably the same diameter
as the outlet hole).
- the length should be no more than:
3 metres with one 90° bend
2 metres with two 90° bends
Bends of more than 90° will reduce the efficiency of the hood and
reduce the airflow.
 Failure to observe these basic instructions will drastically reduce the
performance and increase the noise levels of the extractor hood.

51
A
Fig. 1
Fig. 2
B
Description of the Appliance
The cooker hood is designed to extract unpleasant odours
from the kitchen, it will not extract steam.
 The cooker hood is supplied ready for use as a recirculation hood
and may be used for extraction by removing the charcoal filter which
has been fitted inside the cooker hood.
Extraction mode
 In this mode fumes are extracted
to the outside via a hose
connected to the coupling ring A.
Fig. 1.
 In order to obtain the best perfor-
mance the hose should have a
diameter equal to the outlet hole.
Recircu ation mode
 The air is filtered through a charcoal
filter and returned to the kitchen.
 You will need an original charcoal filter
for the recirculation mode. (See Special
Accessories).
 The deflector should be mounted on the
wall near the ceiling with two wall
dowels and 5x45 screws. Figure 2.
 Connect a tube to the exit hole of the
hood (A-Figure 1) long enough to reach
the deflector connection ring (B-Figure
2).

52
Control Panel
 Best results are obtained by using a low speed for normal conditions
and a high speed when odours are more concentrated.
Turn the hood on a few minutes before you start cooking.
The hood should be left on after cooking for about 15 minutes or until
all the odours have disappeared.
The control switches are located on the hoods front panel:
Light switch: this switch is used to turn the light fitted in the hood
on and off.
Extractor fan switch: used to turn the fan off
Push-button 1: used to set the fan to speed 1.
Push-button 2: used to set the fan to speed 2.
Push-button 3: used to set the fan to speed 3.
Light switch
Extractor fan
switch
Push
button 1 Push
button 2
Push
button 3

53
Fig. 3
Maintenance and Care
The hood must always be disconnected from the electricity
supply before beginning any maintenance work.
C eaning the hood
 Clean the outside of the hood using a damp cloth and a solution of
water and mild washing up liquid.
 ever use corrosive, abrasive or flammable cleaning products or
products containing bleach. .
 ever insert pointed objects in the motors protective grid.
 Only ever clean the switch panel and filter grill using a damp cloth
and mild washing up liquid.
 It is extremely important to clean the
unit and change the filters at the
recommended intervals. Failure to do
so will cause grease deposits to build
up that could constitute a fire hazard.
Meta grease fi ter
 The purpose of the grease filters is to
absorb grease particles which form
during cooking and it must always be
used, either in the external extraction
or internal re-circulation function.
Attention: the metal grease filters must be removed and washed,
either by hand or in the dishwasher, every four weeks.
Removing the meta grease fi ter
 Pull the handle downwards, then remove the filter.. Fig. 3.
Hand washing
Soak grease filters for about one hour in hot water with a grease-
loosening cleaner, then rinse off thoroughly with hot water. Repeat
the process if necessary. Refit the grease filters when they are dry.
Dishwasher
Place grease filters in the dishwasher. Select most powerful washing
programme and highest temperature, at least 65°C. Repeat the
process. Refit the grease filters when they are dry.
When washing the metal grease filter in the dishwasher a slight
discolouration of the filter can occur, this does not have any impact
on its performance.
 Clean the inner housing using a hand hot solution only(never use
caustic detergents, abrasive powders or brushes).

54
Fig. 4
Charcoa fi ter
 The charcoal filter should only be used if you want to use the hood in
recirculation mode.
 To do this you will need an original charcoal filter (available from your
local Service Force Centre).
 The charcoal filter cannot be washed nor regenerated.
The charcoal filter should be replaced every 4 months under normal
use.
Replacement filters are available from your local Service Force
Centre.
Fitting - Fig. 4
Fit the charcoal filter first from the rear side and fix it frontwards
using the two red keys A.
To remove proceed in the reverse order.
 Always specify the hood model code number and serial number
when ordering replacement filters. This information is shown on the
rating plate located on the inside of the unit.
 The charcoal filter can be ordered from your local Service Force
Centre.
A

55
Fig. 5
Warning
 Failure to observe the instructions on cleaning the unit and changing
the filters will cause a fire hazard. You are therefore strongly
recommended to follow these instructions.
 The manufacturer declines all responsibility for any damage to the
motor or any fire damage linked to inappropriate maintenance or
failure to observe the above safety recommendations.
Changing the ight bu b
Disconnect the cooker hood from the mains
supply.
 Remove the lamp cover carefully, use a screw
driver as a lever. Fig. 5.
 Replace the old bulb with a new one of the
same type.
 Refit the lamp cover.
 If the light does not come on, make sure the
bulb has been inserted in correctly before
contacting your local Service Force Centre.

56
What to do if
If your appliance fails to work properly please carry out the following
checks.
Symptom Solution
The cooker hood will not start... Check that:
The hood is connected to
the electricity supply.
Check that a fan speed has
been selected
The cooker hood is not working Check that:
effectively.. The fan speed is set high
enough for the task.
The grease filters are clean.
The kitchen is adequately vented
to allow the entry of fresh air.
If set up for recirculation, check
that the charcoal filter is still
effective.
If set up for extraction, check that
the ducting and outlets are not
blocked.
The cooker hood has The safety cut-out device has been
switched off during operation... tripped.
Turn off the hob and then wait for
the device to reset.
If the hood has been installed
below the heights indicated in the
installation instructions the motor
will cut-out frequently which will
damage the hood.
If after all these checks, the problem persists, contact your local
Service Force Centre, quoting the model and serial number.
Please note that it will be necessary to provide proof of purchase for
any in-guarantee service calls.
In-guarantee customers should ensure that the above checks have
been made as the engineer will make a charge if the fault is not a
mechanical or electrical breakdown.

57
Special accessories
Charcoal filter Type 150
Technica assistance service (not for UK)
You are welcome to telephone our technical assistance service (see list
of technical assistance centres) whenever you need information or in the
unlikely event of a fault.
For service in Australia call 1300 650 020.
When calling, please be ready to specify:
1. The model code number
2. The serial number (E-Nr.)
3. The manufacturing number (F-Nr.)
This information is shown on the registration plate inside the unit
behind the grease filter.
We reserve the right to change specifications and colours as a result of
our policy of continuing technological development.
Service and Spare Parts
In the event of your appliance requiring service, or if you wish to purchase spare parts,
contact your local Service Force Centre by telephoning: 08705 929 929
Your call will be automatically routed to the Service Centre covering your post code
area. For the address of your local Service Force Centre and further information about
Service Force, please visit the website at www.serviceforce.co.uk
Please ensure that you have read the section What to do if.... as the engineer will make
a charge if the fault is not a mechanical or electrical breakdown even the appliance is
under warranty. Please note that proof of purchase is required for in-guarantee
service calls.
Help us to help you
Please determine your type of enquiry before writing or telephoning.
When you contact us we need to know:
 Your name  Clear and concise details of the fault
 Address and post code  Name and model of the appliance*
 Telephone number  E number*
 Serial number*
* This information can be found on the rating plate, which can be seen when the grease
filters are removed.

58
If you require Customer Service in the Republic of Ireland please contact us at
the address below:
AEG
Electrolux Group (Ire) Ltd
Long Mile Road
Dublin 12
Republic of Ireland
Tel: + 353 (0) 1 4090751
Email: [email protected]
CUSTOMER CARE DEPARTMENT
For general enquiries concerning your AEG appliance or for further information on AEG
products, please contact our Customer Care Department by letter or telephone at the
address below or visit our website at www.aeg.co.uk
Customer Services Department
Major Appliances
AEGElectrolux
Addington Way
Luton
Bedfordshire
LU4 9QQ
0 705 350 350 (*)
* calls to this number may be recorded for training purposes. purposes.

59
Technical Details
Model CHDD 8509 CHDD 8510
Dimensions:
Height x Width x Depth (in cm) 70/126x90x51,5 70/126x100x51,5
Maximum absorbed power: 320 W 320 W
Motor absorption: 2 0 W 2 0 W
Lighting: 2 x 20W 2 x 20 W
Length of the cable: 150cm 150 cm
lectrical connection: 220-240V 220-240 V
Fuse rating: 5A Time Delay Fuse
Mounting accessories inc uded
1deflector/support
1 chimney support
6 wall plugs
6 screws 5x45
2 hooks
4 screws (2 as extra screws)

60
lectrical connection (not for UK)
Safety warnings for the e ectrician
Before connecting the appliance to the power supply, check that the
voltage indicated on the rating plate corresponds to the mains power
supply available. Appliances fitted with a plug can be connected to any
standard power socket within easy access.
Should it be necessary to provide a fixed connection, the hood must
only be installed by an electrician authorised by the local electricity
board. When installing, an omnipolar disconnector with a distance of at
least 3 mm between contacts must be provided.
Fixed connection of the appliance must only be carried out by an
authorised electrician.
E ectrica connection for UK on y
Safety warnings for the electrician
Connect the hood to the mains supply via a double pole switch which
has 3 mm minimum separation between the contacts.
The switch must be accessible at all times.
The following is valid in the United Kingdom only:
- the wire which is coloured green and yellow must be connected to
the terminal which is marked with the letter E or by the earth symbol
( ), or coloured green or green and yellow;
- the wire which is coloured blue must be connected to the terminal
which is marked with the letter or coloured black, -
- the wire which is coloured brown must be connected to the terminal
which is marked with the letter L or coloured red.

61
Wa unit mounting - Fig. 6
 Mark the wall with a centre line, this will aid mounting procedure ,
position the template so that the mid line printed on the template
matches with the centre line previously drawn (1), drill two holes Ø
8mm (2).
 Fit two wall plugs with hooks (3).
 Hang the hood and adjust its position (4).
 Remove the grease filters (5) and from the inside of the hood mark 4
points for fixing (6). Remove the hood and drill 4 holes Ø 8mm.
 Fit two wall plugs (7).
 Fit the chimney support ( ) with wall plugs and screws close to the
ceiling, check that the support is perfectly centered.
 Hang the hood again and fix securely with 4 screws (9) .
 Connect a tube to the exit hole of the hood (10) long enough to reach
the outside (suction version) or the deflector connection ring (filtering
version).
 Make electrical connection (11).
 Fix the chimney up (12a) to the chimney support (12b).
 slide the lower section of the chimney down into the housing on top
of the hood (13).

62
1
2-3
2-3
4
5
6
6
7
7
9
9
8
8
10 11
12a
12a 12b
12b
13
Fig. 6

LI194E ed. 07/05
AEG Hausgeräte GmbH
Postfach 1036
D-90327 Nür berg
http://www.aeg.hausgeraete.de
http://www.aeg.co.uk
© Copyright by AEG
From the Electrolux Group. The world´s No.1 choice.
The Electrolux Group is the world´s largest producer of powered appliances for kitchen,
cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators,
cookers, washing machines,vacuum cleaners, chain saws and lawn mowers are sold each
year to a value of approx. USD 14 billion in more than 150 countries around the world.
