AEG Perfekt T?24P User manual









PerfektT‐24P,PerfektT‐30P
RangeHoodInstructionManual










Thankyouforthepurchaseofthisproduct.Pleasereadthe
manualcarefullybeforeoperatingtheappliance.


1|Page


Contents

ImportantSafetyInstructions2
Introduction3
Features3
Installation4‐5
HowtoUse6
GroundingInstructions7
SafetyInformation8
TroubleShooting9
ElectricalDiagram10
Specifications10
Cleaning&Maintenance11
InstallationDiagram12
Warranty13










13|Page


Warranty

AEGAppliancesareimportedanddistributedinNorth
AmericabyEuro‐LineAppliancesInc.
Formoreinformationvisitwww.euro‐line‐appliances.com
orcontact:

2278SpeersRoad
Oakville,ONL6L2X8
Canada

1‐800‐421‐6332–Euro‐LineAppliancesInc.
1‐800‐ELA‐WEST–Euro‐LineAppliancesWest

marketing@euro‐line‐appliances.com

AllAEGAppliancesarebackedbyacomprehensive2‐year
partandlabourwarranty.Informationonserviceandparts
availablefromEuro‐Partsat1‐800‐678‐8352

2|Page

ImportantSafetyInstructions
○Readandsavetheseinstructions
○Warning‐Toreducetheriskoffireorelectricshock,do
notusethisfanwithanysolid‐statespeedcontroldevice.
○CAUTION:Forgeneralventilatinguseonly.Donotuse
toexhausthazardousorexplosivematerialsandvapors.
○Warning‐Toreducetheriskofarangetopgreasefire:
Neverleavesurfaceunitsunattendedathighsettings.
Boiloverscausesmokingandgreasyspilloversthat
mayignite.Heatoilsslowlyonlowormediumsettings.
AlwaysturnhoodONwhencookingathighheator
whenflambéingfood(i.e.CrepesSuzette,Cherries
Jubilee,PeppercornBeefFlambé)
Cleanventilatingfansfrequently.Greaseshouldnotbe
allowedtoaccumulateonfanorfilter.
Useproperpansize.Alwaysusecookwareappropriate
forthesizeofthesurfaceelement.
○Warning‐Toreducetheriskofinjurytopersonsinthe
eventofarangetopgreasefire,observethefollowing:
Smotherflameswithaclose‐fittinglid,bakingsheet,or
metaltray,andthenturnofftheburner.Becarefulto
preventburns.Iftheflamesdonotgooutimmediately,
evacuateandcallthefiredepartment.
Neverpickupaflamingpan‐youmaybeburned.
Donotusewater,includingwetdishclothsortowelsa
violentsteamexplosionmayresult.
UseanextinguisherONLYif:A)Youknowyouhavea
classABCextinguisher,andyoualreadyknowhowto
operateit.B)Thefireissmallandcontainedinthe
areawhereitstarted.C)Thefiredepartmentisbeing
called.D)Youcanfightthefirewithyourbacktoan
exit.

3 | P a g e
Introducon
oThis appliance has been manufactured with materials
and processes that respect the environment. We hope
that you will connue this important consideraon in
the operaon of this appliance and the disposal of the
packaging materials – thank you.
oThe installaon work must be undertaken by a
qualified technician experienced in range hood
installaon. Please connect the correct power rang
(see page 10)
oThe manufacturer disclaims all liability for any damage
or injury caused as a result of not following
instrucons for installaon contained in the following
text
oThe appliance is not intended for use by young
children or infirm persons without supervision
oYoung children should be supervised to ensure that
they do not play with the appliance
oThe maximum number of burners covered by a range
hood should not exceed 5
oAny modificaons to the appliance, electric wire and
plug is dangerous and voids the warranty
Features
oThis appliance is manufactured from top quality
materials, and offers superb streamlined effects
oWith high sucon power and low noise, it is designed
to remove cooking fumes from your kitchen quietly
and effecvely
12 | P a g e
Installaon Diagram
Perfekt T-24P
Perfekt T-30P
12”
305mm 12”
305mm
12”
305mm 12”
305mm


11|Page


Cleaning&Maintenance

1. Cleanthesurfaceofthehoodeveryweekwithmild
soapordetergent.Avoidsolvents,acid,alkali,scouring
padsorpowderthatcouldirreparablydamagethe
stainlesssteelsurface
2. Thegreasefiltersmaybewashedusingmildsoap,
detergentordegreasingagents
3. Thecharcoalfilterscannotbecleanedandmustbe
generallyreplacedafter6monthsofuse

















4|Page

Pic1

Installation(ductisnotsupplied)

1. Therangehoodshouldbemountedata
distanceof600mmfromanelectricor
inductioncooktop,and762mmabovea
gascooktopforsafetyandoptimum
performance.Iftheinstructionsfor
installationofthegascooktopspecifya
greaterdistance,thishastobetaken
intoaccount.(seepic1)Theexhaustair
mustnotbedischargedintoaflue
whichisusedforexhaustingfumesfrom
otherappliancesburninggasorotherfuels
2. Toinstallontothewall,drill2holesofØ8mmona
sturdywallandinlinewiththehood
3. Insertexpandingscrewsintotheholes
4. Fixdrillingtemplateonthewall(seepic2)
5. Addthesoottube(alternativepart)totheoneway
valve,andconnectittothekitchenoutletvent.(seepic
3)
6. Inserttheouterchimney,theouterchimneyshouldbe
fixedonthemainbodybyscrews.Thenmountthe
bracketandinserttheinnerchimneyandscrewitto
tighten.(seepic4)







600
–
762mm


5|Page







7. Ensurethatthewallthehoodistobeinstalledonis
sufficientlysturdytocarrytheweightofthehood.It
shouldbemountedlevelforbestperformance
8. Donotconnecttoacommonventwithanyother
appliancessuchasagasheater,waterheater,
washer/dryer,etc.
9. Theductshouldnotbebentmorethan120°fromthe
onewayvalveoutletinthekitchenvent
10. Checktomakesurethattheelectricalcordisnotin
contactwithsharpedgesoftheappliance
11. Besurethattheplugisaccessibleafterinstallation









Pic2Pic3Pic4Pic5
10|Page


ElectricalDiagrams


PerfektT‐24P,PerfektT‐30P





Specifications

PerfektT‐24P,PerfektT‐30P
PowerSupply115V,60Hz
RatedInputPower99W
LightingPower2x2W
MotorPower95W
Airflow500CFM
OutletDiameter150mm


115V,60Hz
L2


9|Page


TroubleShooting

Ifanyproblemoccurs,pleasedetachtheplugfromthe
socketandcontactEuro‐Partsorasimilarlyqualified
personinordertoavoidahazard.

ProblemCauseSolution
Lighton,but
motordoesnot
work
Theoutletvalveis
blocked
Detachflueandduct
thenturnonthehood
tocheckifthevalves
open
Thecapacitorhas
failed
Callfortechnical
service
Thecontrolswitch
hasbroken
Callfortechnical
service
Lightdoesnot
work,motor
doesnotwork
Nopowersupply
Pluganotherappliance
intothesocketto
confirmthereispower
supply
FusehasblownOpenuptheplugand
replacehe13Afuse
Vibration
Thepropelleris
damagedor
unbalanced
Callfortechnical
service
Thehoodisnot
installedcorrectly
Reviewtheinstallation
instructionsandcheck
theinstallationagain
forloosescrews,
bracketsor
connections
Insufficient
suctioneffect
Thedistance
betweenthehood
andcooktopistoo
great
Checkthatthe
distanceisbetween
600mmand762mm
Thefiltersare
saturated
Cleanthefiltersfrom
greaseresidueand
replaceaftercleaning
6|Page


HowtoUse

3speedadjustment(seepic6)

oPushthe1button,andthemotorwillrunatthelowest
speed
oPushthe2button,andthemotorwillrunatmedium
speed
oPushthe3button,andthemotorwillrunatthe
highestspeed
oPushtheLightbutton,andthelightinglampswill
illuminate.Pushitagainandthelightswillturnoff
oOnanyspeed,the“T”andthedelaytimerwillswitch
offafter5minutes
oToturnoffthemotor,push“T”buttontwice.











Pic
6


7|Page


GroundingInstructions

oThisappliancemustbegrounded.Intheeventofan
electricalshortcircuit,groundingreducestheriskof
electricshockbyprovidinganescapewireforthe
electriccurrent.Thisapplianceisequippedwithacord
havingagroundingwirewithagroundingplug.The
plugmustbepluggedintoanoutletthatisproperly
installedandgrounded.
oWarning‐Impropergroundingcanresultinariskof
electricshock.
oConsultaqualifiedelectricianifthegrounding
instructionsarenotcompletelyunderstood,orifdoubt
existsastowhethertheapplianceisproperly
grounded.
oDonotuseanextensioncord.Ifthepowersupplycord
istooshort,havingaqualifiedelectricianinstallan
outletneartheappliance.

WARNING:TOREDUCETHERISKOFFIRE,USEONLYMETAL
DUCTWORK.








8|Page


SafetyInformation

oTheremustbepermanentandadequateventilationofthe
roomwhenoperatingtherangehoodwithappliances
burninggasorotherfuels
oDonotcheckthestatusofthefilterswhentherangehood
isoperating–waitatleast30minutesafterswitchingoff
toavoidscalding
oDonottouchtheLEDlightwithin30minutesafter
applianceuse
oAvoidoperatingagascooktopwhenthereisnopanonthe
stove.Itisafirehazardandmaycausedamagetothe
hoodfilters
oDisconnecttheelectricalplugpriortoanymaintenance
oThisapplianceisnotintendedforusebyyoungchildren
unlesstheyhavebeenadequatelysupervisedbya
reasonablepersontoensurethattheycanusethe
appliancesafely
oTherangehoodisforhomeuseonlyandisnotsuitablefor
outdoor,barbeque,andothercommercialapplications
oTherangehoodanditsfiltershouldbecleanedregularly
forbestperformance
oBeforecleaning,pleaseconfirmthatthepowerisswitched
off
oBuildingregulationsconcerningthedischargeofexhaust
airhavetobefulfilled
oDon’tcookwithanopenflameundertherangehood
oForanytechnicalissuesensurethatasuitablyqualified
personhandlesanyrepairsorinspections


