Front-line Future Hoods
64 Hoods 65
Hoods
With a variety of sizes and the choice of extraction or recirculation
mode, AEG-Electrolux has a range of hoods suitable for all kitchen
and cooking needs. Whisper-quiet operation ensures your kitchen
is cleared of cooking odours efficiently and quietly.
FM2500DD
■Down draught extractor
■Touch controls
■Variable 4 speed control including
1 intensive setting
■2 heights of operation, fully retracts to
worktop level when not in use
■Delayed switch off timer and auto safety
switch off
PERFORMANCE
480m3/h extraction rate
65dB(A) noise level
Extraction and recirculation
Removes grease and odours directly from the
cooking area
REASSURANCE
Washable aluminium grease filter
Charcoal filter as an optional extra (type 25)
DESIGN
For worktop installation
FLF18STSTR: Stainless steel look strip
(optional extra)
HD8890
PERFORMANCE
570m3/h extraction rate
63dB(A) noise level
Extraction and recirculation
REASSURANCE
2 washable aluminium dishwasher safe grease
filter cassettes
Long life charcoal filter included (type 20)
DESIGN
2 x halogen lights
For wall mounting or installation between
furniture
Front-line Future 90cm chimney hood.
18cm down draught for worktop
extraction.
■Touch controls with LED display
■Variable 4 speed control including
1 intensive setting
■Delayed switch off timer and auto safety
switch off
18cm 90cm
570m316m 2

Design Control
Stunning hoods. Precise control for peace of mind.
Variable speed control.
Allows the rate of extraction to be
varied to suit different types of
cooking, providing optimum efficiency
at minimal cost.
Touch control.
Stylish, simple and precise electronic
touch controls to adjust speed levels
and hood lights.
Push button control.
Ideal for those who want just one
touch control to adjust speed levels
and hood lights.
Slider controls.
An easy way to use slider control to
adjust speed levels and hood lights.
Precise control.
AEG-Electrolux’s powerful cooker
hoods have a wide choice of different
controls so you can adjust your
extraction speed to suit every kitchen
need, ensuring it is a fresher, more
peaceful place to cook or relax.
The electronic touch controls are
stylish, simple with precise settings.
Automatic sensor control.
This ingenious sensor takes away the
guesswork involved in selecting an
extraction level. The sensor controls
the intensity of the extraction, always
working at the optimum level. They
detect hob heat, ambient temperature
and humidity levels and ensure that
the hood works at exactly the right
level to rid your kitchen of odours.
LED display.
Indicates extraction speed and when
the charcoal filter or metal grease
filter needs changing or cleaning.
Electronic variable speed control.
Precisely controls the rate of
extraction, which can be varied to suit
different types of cooking, providing
optimum efficiency at minimal costs.
Control 67 Design
66
g
Design flexibility.
AEG-Electrolux have an extensive range
of cooker hoods to suit all needs,
whether you want to be discreet or
make a bold design statement.
Integrated, canopy and telescopic hoods
can be discreetly concealed to blend in
with your kitchen furniture, while our
designer or chimney hoods are
designed for maximum visual impact.
Hood types.
Designer hood. For those who want to
create a stunning centrepiece in the
kitchen, award-winning designer
hoods from AEG-Electrolux.
Island hood. Suspended from the
ceiling over a cooking station, the hood
becomes the focal point of the kitchen.
Ideal for installation with island units.
Chimney hood. Providing an attractive
focal point in the kitchen, the chimney
hood can be fitted between furniture
or wall mounted.
Canopy hood. An attractive feature in
the kitchen, the canopy hood is fitted
& fixed into an island chimney, corner
unit or wall cupboard.
Telescopic hood. Fitted & fixed into a
60cm wide furniture unit, with a
shallow front cupboard. When in use it
extends outwards beyond the cabinet
and inwards for a flush finish when
not in use.
Integrated hood. Fitted & fixed
between wall units. Hidden by a
furniture door, the hood is not visible,
enhancing the appearance of the
kitchen.
Halogen lamps.
This type of illumination on the hood
provides excellent cooking visibility and
can be used to provide soft lighting in
the kitchen.
Hob lamps.
Illuminating the cooking areas for
excellent cooking visibility, they can
also be used to provide soft lighting in
the kitchen.

Reassurance
Performance
Designer hood in stunning black glass.
DD9995B
■Stylish black glass hood
■Electronic touch controls with LED display
■Continuous motor with
intensive setting
CONTROL
920m3/h extraction rate
61dB(A) noise level
REASSURANCE
Long-life charcoal filter included
Washable aluminium grease filters
Electronic saturation indicators
Extraction and recirculation
DESIGN
2 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
80cm
920m320m2
Hoods 69
For a peaceful kitchen environment.
Performance & Reassurance
68
2008
Recirculation mode. The hood draws
in the cooking vapours, filters the air
through the charcoal filter and then
recirculates the clean air back into the
kitchen, leaving it free from cooking
odours. For those hoods that do not
come with a charcoal filter, it is
available as an accessory.
Filters.
Long-life charcoal filter. This charcoal
filter is used in recirculation mode to
remove cooking smells. It may be
washed in the dishwasher and dried in
the oven.
Charcoal filter. This charcoal filter is
used in recirculation mode to remove
cooking smells. Needs replacing
periodically.
Metal grease filters. The metal filter
attracts the grease from cooking
vapours, reducing odours, purifying
the air and optimising performance.
The filter is dishwasher-safe and never
needs replacing.
Acrylic grease filter with saturation
indicator. The filter absorbs grease
from cooking vapours, producing
cleaner air and reducing odours.
Diagonal lines appear when the filter
needs changing.
This efficient and simple measure
maintains perfect hood performance
and extends hood life.
Whisper-quiet operation.
AEG-Electrolux hoods are quieter by
design. AEG-Electrolux hoods give a
higher extraction without a loud noise,
creating a more peaceful kitchen
environment.
Extraction rates.
This is the level at which the cooker
hood clears cooking vapours from the
kitchen environment. AEG-Electrolux
cooker hoods are measured in cubic
metres per hour and are in accordance
with IEC standards.
Extraction mode. A ducting kit is
attached to the hood to extract the
cooking vapours externally, giving a
pleasant kitchen environment, which is
free from cooking odours.
AEG-Electrolux’s powerful cooker hoods make a real difference to your whole kitchen environment, ensuring that it is a
fresher, more peaceful place to cook or relax.

Hoods 71 Hoods
70
DD9693-M DD9663-M
60cm chimney hood.
■Stylish stainless steel and black
chimney hood
■Electronic touch controls
■Variable 4 speed control including
1 intensive setting
PERFORMANCE
970m3/h extraction rate
57dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filter
Long-life charcoal filter included
Extraction and recirculation
DESIGN
2 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
90cm chimney hood.
■Stylish stainless steel and black
chimney hood
■Electronic touch controls
■Variable 4 speed control including
1 intensive setting
PERFORMANCE
970m3/h extraction rate
57dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filter
Long-life charcoal filter included
Extraction and recirculation
DESIGN
3 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
90cm
Endorsed by the
UK Noise Association
SSSH
970m320m2
60cm
Endorsed by the
UK Noise Association
SSSH
970m320m2
Designer hoods in stainless steel. Designer hoods in stainless steel.
HD8795M HD8760M
■Stylish stainless steel hood
■Variable 4 speed control including
1 intensive setting
■Electronic rotary control with colour
display for speed, filter and light settings
■Electronic dimmer control for softer
lighting
PERFORMANCE
540m3/h extraction rate
61dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filters
Long-life charcoal filter included
Extraction and recirculation
DESIGN
3 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
Chimney section available as an optional
extra (K8004m)
PERFORMANCE
540m3/h extraction rate
61dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filters
Long-life charcoal filter included
Extraction and recirculation
DESIGN
3 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
Chimney section available as an optional
extra (K8004m)
60cm designer hood.90cm designer hood.
■Stylish stainless steel hood
■Variable 4 speed control including
1 intensive setting
■Electronic rotary control with colour
display for speed, filter and light settings
■Electronic dimmer control for softer
lighting
2003
60cm
540m316m2
90cm
540m316m2

Hoods 73 Hoods
72
HD8990M HD8960M
■Stylish stainless steel chimney hood
■Electronic touch controls with digital
LED display
■Automatic sensor programme
■Variable 4 speed control including
1 intensive setting
■Delayed switch off timer and auto safety
switch off
PERFORMANCE
490m3/h extraction rate
60dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filters
Long-life charcoal filter included
Extraction and recirculation
DESIGN
2 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
90cm chimney hood. 60cm chimney hood.
■Stylish stainless steel chimney hood
■Electronic touch controls with digital
LED display
■Automatic sensor programme
■Variable 4 speed control including
1 intensive setting
■Delayed switch off timer and auto safety
switch off
PERFORMANCE
490m3/h extraction rate
60dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filter
Long-life charcoal filter included
Extraction and recirculation
DESIGN
2 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
90cm
Endorsed by the
UK Noise Association
SSSH
490m316m2
60cm
Endorsed by the
UK Noise Association
SSSH
490m316m2
Hi8610M HD6470M
100cm island hood.
■Stylish stainless steel hood with glass
canopy
■Electronic touch controls with LED display
■Variable 4 speed control including
1 intensive setting
■Delayed switch off timer and auto safety
switch off
PERFORMANCE
500m3/h extraction rate
60dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filter
Long-life charcoal filter included
Extraction and recirculation
DESIGN
4 x halogen lamps
For island installation
■Stylish stainless steel hood with glass
canopy
■Extendable to 70cm or 80cm using
stainless steel side trims
■Electronic variable 3 speed push button
control
PERFORMANCE
470m3/h extraction rate
64dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filter
Long-life charcoal filter included
Extraction and recirculation
DESIGN
2 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
60cm chimney hood.
100cm
Endorsed by the
UK Noise Association
SSSH
500m316m2
60 - 80cm
470m312m 2
Sensor controlled hoods. Glass chimney hoods.

Hoods 75 Hoods
74
HC5690M
■Stylish stainless steel chimney hood
■Electronic variable 4 speed push control
including 1 intensive setting
■Delayed switch off timer on Intensive
setting
PERFORMANCE
660m3/h extraction rate
62dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filters
Long-life charcoal filter included
Extraction and recirculation
DESIGN
2 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
90cm chimney hood. 60cm chimney hood.
■Stylish stainless steel chimney hood
■Variable 3 speed push button control
PERFORMANCE
410m3/h extraction rate
62dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filter cassettes
Long-life charcoal filter included
Extraction and recirculation
DESIGN
2 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
Suitable for installation at low ceiling height
100cm professional chimney hood.
■Stylish professional stainless steel
chimney hood
■Electronic variable 4 speed push button
control
■Co-ordinates perfectly with the
AEG-Electrolux 100cm range cookers
PERFORMANCE
790m3/h extraction rate
74dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filters
Charcoal filter included
Extraction and recirculation
DESIGN
2 x halogen lamps
For wall mounting between furniture or
as a stand alone unit
90cm
660m316m2
60cm
410m310 m 2
100cm
790m320m2
HC3360M HD8510M
Chimney hoods. Telescopic hoods.
■Electronic variable 3 speed slider control
■Extended vapour guide
PERFORMANCE
550m3/h extraction rate
65dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filters
Optional charcoal filter for recirculation (EFF55)
Extraction and recirculation
DESIGN
2 x 9W neon lights
For installation between 90cm wide furniture
with shallow front cupboard
Main colour: Grey
PERFORMANCE
310m3/h extraction rate
63dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filters
Optional charcoal filter for recirculation (EFF70)
Extraction and recirculation
DESIGN
2 x 40W lights
For installation between 60cm wide furniture
with shallow front cupboard
Main colour: Grey
60cm telescopic hood.
90cm telescopic hood.
■Electronic variable 3 speed slider control
■Extended vapour guide
90cm
550m3
60cm
310m3
EFP90033X EFP60032X
A range of hoods manufactured by the Electrolux Group designed to complement your AEG-Electrolux kitchen appliances

Hoods 77 Hoods
76
A range of hoods manufactured by the Electrolux Group designed to complement your AEG-Electrolux kitchen appliances
EFI60012S
60cm integrated hood.
nVariable 3 speed slider speed control
nExtended vapour guide
PERFORMANCE
320m3/h extraction rate
65dB(A) noise level
REASSURANCE
Washable aluminium grease filters
Extraction and recirculation
Optional charcoal filter for recirculation (type 29)
DESIGN
2 x 40W lights
Installation between furniture 60cm wide
Main colour: Grey
60cm
320m3
60cm integrated hood.
nVariable 3 speed slider speed control
nTwin motors for high performance
nExtended vapour guide
PERFORMANCE
510m3/h extraction rate
66dB(A) noise level
REASSURANCE
Electronic saturation indicators
Washable aluminium grease filters
Optional charcoal filter for recirculation (type 29)
Extraction and recirculation
DESIGN
2 x 40W neon lights
Installation between furniture 60cm wide
Main colour: Grey
60cm
510m3
EFI60013S
Integrated hoods.Canopy hoods.
EFG70023S EFG50022S
nElectronic variable 3 speed slider control
PERFORMANCE
620m3/h extraction rate
68dB(A) noise level
REASSURANCE
Washable aluminium grease filters
Extraction and recirculation
Optional charcoal filter for recirculation (EFF70)
DESIGN
2 x halogen lights
For installation into an island chimney, wall
or corner unit
Main colour: Grey
70cm canopy hood. 52cm canopy hood.
nElectronic variable 3 speed slider control
PERFORMANCE
320m3/h extraction rate
64dB(A) noise level
REASSURANCE
Washable aluminium grease filters
Extraction and recirculation
Optional charcoal filter for recirculation (EFF70)
DESIGN
2 x 40W neon lights
For installation into an island chimney, wall
or corner unit
Main colour: Grey
70cm
620m3
52cm
320m3
A range of hoods manufactured by the Electrolux Group designed to complement your AEG-Electrolux kitchen appliances

Cooking 79
Range cooker hand finished to perfection.
COMPETENCE C41022GM
100cm mixed fuel double oven range
cooker with gas hob and cast iron
griddle.
■Diamond glazed enamel interior
■Auto-stop anti-tip chrome shelves
■Acoustic signal
CONTROL
Rotary controls
24-hour electronic clock with minute minder
Fully programmable timer for main oven
HOB FEATURES
1 Wok burner
Cast iron pan supports & griddle
MAIN OVEN
Conventional cooking
Ventitherm® - true fan
Base heat finishing & top heat browning
Rotitherm roasting
Multifunction
Fan controlled defrosting
Dual circuit variable grill
SIDE OVEN
Conventional cooking
Grill
Turnspit rotisserie feature
Base heat finishing & top heat browning
DESIGN
Isofront® triple glazed doors
Side
oven
B
Main
oven
B
Energy
B
Class
Splashbacks
78
EFB675X | EFB975X | EFB175X
■75cm high
■Available in 60cm width (EFB675X)
■Available in 90cm width (EFB975X)
■Available in 100cm width (EFB175X)
■Easy to wipe clean with rigid reinforced
back
SK3060A | SK3090A
Stylish Alutec® splashbacks to complement
AluTec range of ovens, hobs and hoods.
■75cm high
■Alutec® Splashback 60cm wide 75cm high
■Alutec® Splashback 90cm wide 75cm high
■Easy to wipe clean with rigid reinforced
back
Stylish stainless steel splashbacks to
complement stainless steel range of
ovens, hobs and hoods.
EFB60X | EFB90X | EFB120X
Stylish stainless steel splashbacks to
complement stainless steel range of
ovens, hobs and hoods.
■70cm high
■Available in 60cm width (EFB60X)
■Available in 90cm width (EFB90X)
■Available in 120cm width (EFB120X)
■Easy to wipe clean with rigid reinforced
back
