AEG DVB5560B User manual

USER
MANUAL
EN User Manual
Cooker Hood
DVB5860B
DVB5560B

CONTENTS
1. SAFETY INFORMATION AND INSTALLATION...................................................2
2. PRODUCT DESCRIPTION...................................................................................3
3. DAILY USE........................................................................................................... 3
4. CARE AND CLEANING........................................................................................ 4
5. ENVIRONMENTAL CONCERNS..........................................................................5
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website to:
Get usage advice, brochures, trouble shooter, service and repair information:
www.aeg.com/support
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
1. SAFETY INFORMATION AND INSTALLATION
WARNING!
Refer to the separate Installation
Instructions booklet for Safety
Information and Installation. Read
carefully the Safety chapters before any
use or maintenance of the appliance.
www.aeg.com2

2. PRODUCT DESCRIPTION
2.1 Control panel overview
1 2 3 4 5 6 7
1On / Off
2First motor speed
3Second motor speed
4Third motor speed
5Maximum motor speed
6Filter alarm indicator
7Lamp
3. DAILY USE
3.1 Using the hood
Check the recommended speed
according to the table below.
While heating up food, cooking with covered pots.
While cooking with covered pots on multiple cooking
zones or burners, gentle frying.
While boiling, frying big quantities of food without a
lid, cooking on multiple cooking zones or burners.
While boiling, frying big quantities of food without a
lid, big humidity. The hood operates on maximum
speed. After 8 minutes the appliance returns to previ‐
ous setting.
It is recommended to leave
the hood operating for
approximately 15 minutes
after cooking.
The control Panel is a
sensor field. Touch the
symbols to activate the
functions.
To operate the hood:
1. Turn on the appliance by pressing
the symbol.
You can now activate the functions.
2. To activate the function touch the
symbol.
3. If needed, touch the light symbol
to illuminate the cooking surface.
To turn off the appliance press the
symbol again.
3.2 Activating Maximum
Motor Speed
When you press the button , the
Maximum Motor Speed starts to operate
for 6 minutes. After that time, the
ENGLISH 3

appliance returns to its previous speed
settings.
When the function is turned
on, additional touch on the
button does not have any
effects.
3.3 Activating and
deactivating the filter
notification
Filter alarm reminds to change or clean
the charcoal filter and clean the grease
filter. The filter indicator is turned on
(red) for 30 seconds if the grease filter
must be cleaned. The filter indicator
flashes (red) for 30 seconds if the
charcoal filter must be replaced or
cleaned.
Refer to filter alarm in care
and cleaning chapter.
1. Switch on the control panel.
2. Make sure that the icons are turned
off.
3. To activate or deactivate the charcoal
filter notification touch for 3
seconds.
If the charcoal filter
notification is activated, the
filter icon flashes (red)
five times.
If the charcoal filter
notification is deactivated,
the filter icon flashes
(red) three times.
4. CARE AND CLEANING
4.1 Cleaning the grease filter
Each filter must be cleaned at least once
a month. Filters are mounted with the
use of clips and pins on the opposite
side.
To clean the filter:
1. Pull the cover to open it.
1
2. Press the handle of the mounting clip
on the filter panel underneath the
hood (1).
1
2
3. Slightly tilt the front of the filter
downwards (2), then pull.
Repeat the first two steps for all filters.
4. Clean the filters using a sponge with
non abrasive detergents or in a
dishwasher.
The dishwasher must be set
to a low temperature and a
short cycle. The grease filter
may discolour, it has no
influence on the
performance of the
appliance.
5. To mount the filters back follow the
first two steps in reverse order.
Repeat the steps for all filters if
applicable.
www.aeg.com4

4.2 Replacing the charcoal
filter
The charcoal filter must be replaced if
the filter alarm is on.
Refer to the filter alarm in
this chapter.
The time of saturation of the charcoal
filter varies depending on the type of
cooking and the regularity of cleaning the
grease filter.
WARNING!
The charcoal filter is NON-
washable! The filter cannot
be regenerated!
To replace the charcoal filter:
1. Remove the grease filters from the
appliance.
Refer to "Cleaning the grease filter" in
this chapter.
2. Turn the filter counterclockwise (1)
and then pull (2).
1
2
To mount the filters back follow the steps
in reverse order.
4.3 Filter alarm
Refer to activating and
deactivating the filter alarm
in daily use chapter.
Refer to cleaning the grease
filter in this chapter.
Refer to cleaning the
charcoal filter or replacing
the charcoal filter (depends
on filter type).
To reset the alarm:
Touch the for 3 seconds.
4.4 Replacing the lamp
This appliance is supplied with a LED
lamp and separate control gear (LED
driver). These parts can be replaced by a
technician only. In case of any
malfunction refer to "Service" in the
"Safety Instructions" chapter.
5. ENVIRONMENTAL CONCERNS
Recycle materials with the symbol .
Put the packaging in relevant containers
to recycle it. Help protect the
environment and human health by
recycling waste of electrical and
electronic appliances. Do not dispose of
appliances marked with the symbol
with the household waste. Return the
product to your local recycling facility or
contact your municipal office.
*
ENGLISH 5
