AEG LAVAMAT 61270 WDBI User manual

LAVAMAT 61270 WDBI
LAVAMAT 61470 WDBI
EN WASHER DRYER USER MANUAL 2
ES LAVADORA-SECADORA MANUAL DE INSTRUCCIONES 40

CONTENTS
4 SAFETY INFORMATION
5 TECHNICAL INFORMATION
7 PRODUCT DESCRIPTION
8 CONTROL PANEL
11 WASHING PROGRAMMES
13 DRYING PROGRAMMES
14 CONSUMPTION VALUES
14 FIRST USE
14 DAILY USE - WASHING
19 DAILY USE - DRYING
21 HELPFUL HINTS AND TIPS
23 CARE AND CLEANING
27 TROUBLESHOOTING
31 INSTALLATION
37 BUILDING IN
ENVIRONMENT CONCERNS
Recycle the materials with the symbol . Put the packaging in applicable containers to
recycle it.
Help protect the environment and human health and to recycle waste of electrical and
electronic appliances. Do not dispose appliances marked with the symbol with the
household waste. Return the product to your local recycling facility or contact your
municipal office.
VISIT OUR WEBSITE FOR:
- Products
- Brochures
- User manuals
- Trouble shooter
- Service information
www.aeg.com
LEGEND
Warning - Important Safety information.
General information and tips
Environmental information
Subject to change without notice.
2www.aeg.com

FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler – features you might not find on ordinary appliances. Please spend
a few minutes reading to get the very best from it.
ACCESSORIES AND CONSUMABLES
In the AEG webshop, you’ll find everything you need to keep all your AEG
appliances looking spotless and working perfectly. Along with a wide range of
accessories designed and built to the high quality standards you would expect, from
specialist cookware to cutlery baskets, from bottle holders to delicate laundry bags…
Visit the webshop at:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
We recommend the use of original spare parts.
When contacting Service, ensure that you have the following data available. The
information can be found on the rating plate.
Model
PNC
Serial Number
ENGLISH 3

SAFETY INFORMATION
Before the installation and use, read this
manual carefully:
• For your safety and the safety of your
property
• To help the environment
• For the correct operation of the appli-
ance.
Always keep these instructions with the
appliance also if you move or give it to a
different person.
The manufacturer is not responsible if an
incorrect installation and use causes dam-
age.
CHILDREN AND VULNERABLE
PERSON SAFETY
• Do not let persons, children included,
with reduced physical sensory, reduced
mental functions or lack of experience
and knowledge use the appliance. They
must have supervision or instruction for
the operation of the appliance by a per-
son who is responsible for their safety.
Do not let children play with the appli-
ance.
• Keep all packaging away from children.
There is the risk of suffocation or injury.
• Keep all detergents away from children.
• Keep children and pets away from the
appliance when the door is open.
• Before you close the appliance door,
make sure that children and pets are
not into the drum.
• If the appliance has a child safety de-
vice, we recommend to activate it.
CHILD SAFETY DEVICE
• When you activate this device, you can-
not close the door. This prevents chil-
dren or pets to be closed in the drum.
To activate the device, turn it clockwise,
until the groove is horizontal. To deacti-
vate the device, turn it counterclock-
wise, until the groove is vertical.
GENERAL SAFETY
• Do not use the appliance for professio-
nal use. The appliance is only for do-
mestic use.
• Do not change the specifications of this
appliance. There is the risk of injury and
damage to the appliance.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
Risk of explosion or fire.
• Obey the safety instructions on the de-
tergent packaging to prevent burns to
eyes, mouth and throat.
• Make sure that you remove all metal
objects from the laundry. Hard and
sharp material can cause damage to
the appliance.
• Do not touch the glass of the door
while a programme operates. The glass
can be hot.
• Plastic items are not heat resistant.
– If you use a detergent ball, remove it
before you set the drying pro-
gramme.
– Do not use a detergent ball when
you set a non-stop programme.
• Before you set the drying programme,
fully rinse items cleaned with flammable
products. There is a risk of explosion.
CARE AND CLEANING
• Deactivate the appliance and discon-
nect the mains plug from the mains
socket.
• Do not use the appliance without the
filters. Make sure that the installation of
the filters is correct. An incorrect instal-
lation causes water leakages.
4www.aeg.com

INSTALLATION
• The appliance is heavy, be careful when
you move it.
• Do not transport your appliance with-
out the transit bolts, you can damage
internal components and cause leak-
ages or malfunctions.
• Do not install and connect a damaged
appliance.
• Make sure to remove all packaging and
transport bolts.
• Make sure that the mains plug is dis-
connected from the mains socket dur-
ing installation.
• Only a qualified person must do the
electrical installation, the plumbing and
the installation of the appliance. This to
prevent the risks of structural damage
or injury.
• Do not install or use the appliance
where the temperature is less than 0 °C.
• When you install the appliance on a
carpet floor, make sure that there is air
circulation between the appliance and
the carpet. Adjust the feet to have the
necessary space between the appliance
and the carpet.
Water connection
• Do not connect the appliance with old
hoses already used. Only use new ho-
ses.
• Make sure not to cause damage to the
water hoses.
• Do not connect the appliance to new
pipes or pipes not used for a long time.
Let the water flow for some minutes,
then connect the inlet hose.
• The first time you use the appliance,
make sure that the water hoses and the
couplings do not have leakages.
Electrical connection
• Make sure that the appliance is earth-
ed.
• Make sure that the electrical informa-
tion on the rating plate agrees with the
power supply.
• Always use a correctly installed shock-
proof socket.
• Do not use multiple plugs and exten-
sion cables. There is a risk of fire.
• Do not replace or change the mains ca-
ble. Contact the service centre.
• Make sure not to cause damage to the
mains plug and cable.
• Connect the mains plug to the mains
socket only at the end of the installa-
tion. Make sure that there is access to
the mains plug after the installation.
• Do not pull the mains cable to discon-
nect the appliance. Always pull the
mains plug.
DISCARD THE APPLIANCE
1.
Disconnect the mains plug from the
mains socket.
2.
Cut off the mains cable and discard it.
3.
Discard the door catch. This prevents
children or pets to be closed in the
appliance. There is a risk of suffoca-
tion (only for front-loading applian-
ces).
TECHNICAL INFORMATION
Dimensions Width / Height / Depth 600 / 820 / 630 mm
Total depth 640 mm
Electrical connection: Voltage
Overall power
Fuse
Frequency
220-230 V
2000 W
10 A
50 Hz
ENGLISH 5

Level of protection against ingress of solid particles
and moisture ensured by the protective cover, ex-
cept where the low voltage equipment has no pro-
tection against moisture
IPX4
Water supply pressure Minimum 0,5 bar (0,05 MPa)
Maximum 8 bar (0,8 MPa)
Water supply 1) Cold water
Maximum wash load Cotton 7 kg
Maximum dry load Cotton 3 kg
Cotton big capacity 4 kg
Synthetics 2 kg
Spin speed Maximum 1200 rpm (L 61270 FL)
1400 rpm (L 61470 FL)
1) Connect the water inlet hose to a water tap with a 3/4'' thread.
6www.aeg.com

PRODUCT DESCRIPTION
7 8 9
10
1 2
3
4
5
6
1
Detergent dispenser
2
Control panel
3
Door handle
4
Rating plate
5
Drain pump
6
Feet for the appliance level
7
Water drain hose
8
Mains cable
9
Water inlet hose
10
Feet for the appliance level
ACCESSORIES
1 2
34
1
Spanner
To remove the transit bolts.
2
Plastic caps
To close the holes on the rear side of
the cabinet after the removal of the
transit bolts.
3
Anti-flood inlet hose
To prevent possible leakage
4
Plastic hose guide
To connect the drain hose on the
edge of a sink.
ENGLISH 7

CONTROL PANEL
1 2 3 4 5 6 7 98 10
A
B
C
1
Programme selector dial
2
SPIN button (Centrif.)
•Rinse hold position
3
STAIN button (Manchas)
4
TIME SAVING (TIME) button (Ahorra
Tiempo)
5
EXTRA RINSE button (Aclarado Extra)
6
DRYING TIME button (Tiempo de se-
cado)
7
Display
8
START/PAUSE button (Start/Pausa)
9
DELAY START button (Inicio Diferido)
10
Pilot lights:
• A – Washing phase (Lavado)
• B – Drying phase (Secado)
• C – Door locked (Puerta bloquea-
da)
DISPLAY
The display shows the following informa-
tion:
Duration of the set programme
When you set a programme, the display shows the duration in
hours and minutes (for example 2.05).
The duration is calculated automatically on the maximum load for
each type of fabric.
After the programme has started, the time remaining is updated
every minute.
Set drying time
when you set a drying programme, the display shows the drying
time in minutes and/or hours (see paragraph «Drying»).
After the programme has started, the appliance updates the re-
maining time every minute.
8www.aeg.com

Alarm codes
In the event of operating problems, some alarm codes can be dis-
played, for example (see chapter «Troubleshooting»).
End of programme
When the programme has finished, the display shows a blinking
zero .
The DOOR light C, the WASHING light A(or the DRYING light B)
and the light of button 8go out.
The door can be opened.
Incorrect option selection
If you set an option which is not compatible with the wash pro-
gramme, the display shows the message Err for some seconds.
The yellow pilot light of button 8light starts blinking.
Delay Start
When you press the relevant button to set the delay (20 hours
max), it appears for some seconds, then the display shows the du-
ration of the set programme.
The delay time value decreases by one unit every hour. When only
1 hour remains, the time decreases every minute.
Delay Start symbol
This symbol comes on when you set the delay time.
Child safety lock
This symbol comes on when you activate the child lock function.
ENGLISH 9

INDICATOR PILOT LIGHTS
A
B
C
After you have pressed the button 8, the
WASHING light (A) comes on.
The machine is operating.
When you set a drying programme, the
DRYING light (B) illuminate and stays on
during the drying phase.
The DOOR light (C) indicates when the
door can be opened:
• light on: the door cannot be opened
• light blinking: the door is opening in
some minutes
• light off: the door can be opened
ACOUSTIC SIGNALS
The machine is provided with an acoustic
device, which sounds in the following ca-
ses:
• at the end of the cycle
• in the event of operating problems.
By pressing the 3and 4buttons simulta-
neously for some seconds, the acoustic
signal is deactivated (except for the
events of operating problems). By press-
ing these two buttons again, the acoustic
signal is reactivated.
CHILD SAFETY LOCK
This device permits you to leave the ap-
pliance unsupervised and not to worry
that children might be injured by or cause
damage to the appliance.
This function remains able also when the
washing machine is not working.
There are two different ways to set this
option:
• Before pressing button 8: it will be im-
possible to start the machine.
• after pressing button 8: it will be impos-
sible to change any other programme
or option.
To enable or disable this option press si-
multaneously for about 6 seconds buttons
4and 5until the symbol comes on or
disappears from the display.
10 www.aeg.com

WASHING PROGRAMMES
Programme
Maximum and Minimum Temperature
Type of Laundry
Maximum Load
Cycle De-
scription Options
Algodón
95° - 30°
Max. load 7 kg - Reduced load 3 kg
White and coloured cotton (normally soiled
items).
Main wash
Rinses
Long spin
SPIN REDUCTION
RINSE HOLD
STAIN1)
TIME SAVING 2)
EXTRA RINSE
Algodón Eco
40°
Max. load 7 kg
Fast coloured cotton.
Slightly soiled cotton items.
The appliance decreases the temperature
and extends the washing time to obtain a
good washing efficiency so saving energy.
Main wash
Rinses
Long spin
SPIN REDUCTION
RINSE HOLD
STAIN
EXTRA RINSE
Algodón + Prelavado3)
95° - 40°
Max. load 7 kg - Reduced load 3 kg
White and coloured cotton
(normally soiled items).
Prewash
Main wash
Rinses
Long spin
SPIN REDUCTION
RINSE HOLD
STAIN
TIME SAVING2)
EXTRA RINSE
Sintéticos
60° - 30°
Max. load 3 kg - Reduced load 2 kg
Synthetic or mixed fabrics: underwear, col-
oured garments, non-shrink shirts, blouses.
Main wash
Rinses
Short spin
SPIN REDUCTION
RINSE HOLD
STAIN 1)
TIME SAVING 2)
EXTRA RINSE
Plancha Fácil
40°
Max. load 1 kg
Synthetic fabrics to be gentle washed and
spun.
The laundry is gently washed and spun to
avoid any creasing. Furthermore the machine
will perform additional rinses.
Main wash
Rinses
Short spin
SPIN REDUCTION
RINSE HOLD
EXTRA RINSE
Delicados
40° - 30°
Max. load kg 3 - Reduced load kg 2
Delicate fabrics: acrylics, viscose, polyester.
Main wash
Rinses
Short spin
SPIN REDUCTION
RINSE HOLD
STAIN1)
TIME SAVING2)
EXTRA RINSE
ENGLISH 11

Programme
Maximum and Minimum Temperature
Type of Laundry
Maximum Load
Cycle De-
scription Options
Lana/Seda
30° - Cold
Max. load 2 kg
Machine washable wool as well as for hand
washable woollens and delicate fabrics.
Note: A single or bulky item may cause im-
balance. If the appliance doesn’t perform the
final spin phase, add more items, redistribute
the load manually and then select the spin-
ning programme.
Main wash
Rinses
Short spin
SPIN REDUCTION
RINSE HOLD
Aclarado delicados
Max. load 7 kg
Programme for rinsing and spinning items
which have been washed by hand. The ma-
chine performs some rinses, followed by a fi-
nal spin. The spin speed can be reduced.
Rinses
Long spin SPIN REDUCTION RINSE HOLD
EXTRA RINSE
Descarga
Max. load 7 kg
For emptying out the water of the last rinse
in programmes with the Rinse hold option
set.
Draining of
water
Centrifugado
Max. load 7 kg
Separate spin for hand washed cotton gar-
ments and after programmes with the Rinse
hold option set.
Turn the programme dial to Off before set-
ting this programme.
Reduce the spin speed if needed.
Drain
Long spin SPIN REDUCTION
Secado — Sintéticos
Drying synthetic programme. DRYING TIME se- lection.
Secado — Algodón
Drying cotton programme. DRYING TIME se- lection.
Refrescar
30°
Max. load 3 kg
Quick wash for sport items, or cotton and
synthetic items lightly soiled or worn once.
Main wash
Rinses
Short spin
SPIN REDUCTION
Algodón Eco
60°
Max. load 7 kg
White and fast coloured cotton.
Normally soiled cotton items.
The appliance decreases the temperature
and extends the washing time to obtain a
good washing efficiency so saving energy.
Main wash
Rinses
Long spin
SPIN REDUCTION
RINSE HOLD
STAIN
EXTRA RINSE
12 www.aeg.com

Programme
Maximum and Minimum Temperature
Type of Laundry
Maximum Load
Cycle De-
scription Options
Off
For cancelling the running programme or to
switch the machine off .
1) Stain option can be selected only at the temperature of 40°C or higher.
2) If you select the Super Quick option by pressing button 4, we recommend that you reduce
the maximum load as indicated. Full loading is possible however with somewhat reduced
cleaning results.
3) If using liquid detergents, a programme without PREWASH must be selected.
DRYING PROGRAMMES
Timed programmes
Degree of Drying Type of Fabric Drying
Load Spin Speed
Sugges-
ted
drying
time
Minutes
EXTRA DRY
Ideal for towelling mate-
rials
Cotton and linen
(bathrobes, bath
towels, etc)
4 kg 1400 160 - 180
3 kg 1400 110 - 120
1.5 kg 1400 75 - 85
CUPBOARD DRY1)
Suitable for items to put
away without ironing
Suitable for items to put
away without ironing
Cotton and linen
(bathrobes, bath
towels, etc)
4 kg 1400 150 - 170
3 kg 1400 100 - 110
1.5 kg 1400 65 - 75
Synthetics and
mixed fabrics
(jumpers, blouses,
underwear, house-
hold linen)
2 kg 1200 90 - 100
1 kg 1200 55 - 65
IRON DRY
Suitable for ironing
Cotton and linen
(sheets, table-
cloths, shirts, etc.)
4 kg 1400 120 - 140
3 kg 1400 80 - 90
1.5 kg 1400 50 - 60
1) In compliance with EC directive EN 50229 the cotton reference programme for the data
entered in the Energy Label must be tested dividing the maximum washing load by two
equal parts and drying with DRYING TIME each of them.
ENGLISH 13

CONSUMPTION VALUES
Programme Energy con-
sumption
(KWh)
Water con-
sumption
(litres)
Programme
duration
(minutes)
White Cottons 95° 2.2 72
For the dura-
tion of the
programmes,
please refer
to the dis-
play on the
control pan-
el.
Cottons 60° 1.35 67
Cotton Energy Saving Pro-
gramme 60° 1) 1.05 49
Cottons 40° 0.85 67
Synthetics 40° 0.55 42
Delicates 40° 0.55 63
Wool/ Handwash 30° 0.25 55
1) «Cotton Energy Saving programme » at 60°C with a load of 7 kg is the reference
programme for the data entered in the energy label, in compliance with EEC 92/75
standards.
The consumption data shown on
this chart is to be considered
purely indicative, as it may vary
depending on the quantity and
type of laundry, on the inlet water
temperature and on the ambient
temperature.
FIRST USE
1.
To activate the drain system, put 2 li-
tre of water in the main wash com-
partment of the detergent dispenser.
2.
Put a small quantity of detergent in
the main wash compartment of the
detergent dispenser. Set and start a
programme for cotton at the highest
temperature without laundry. This re-
moves all possible dirt from the drum
and the tub.
DAILY USE - WASHING
1.
Open the appliance door.
2.
Put the laundry in the drum, one item
at a time. Shake the items before you
put them in the appliance. Make sure
not to put too much laundry in the
drum.
3.
Close the door.
14 www.aeg.com

Make sure that no laundry stays between
the seal and the door. There is a risk of
water leakage or damage to the laundry.
FILLING THE DETERGENT AND ADDITIVES
MAX
The detergent compartment for the prewash phase, the soak pro-
gramme and for the stain function.
Add the detergent for prewash, soak and stain remover before
the start of the programme.
The detergent compartment for the washing phase.
If you use a liquid detergent, put it immediately before you start
the programme.
Liquid additives compartment (fabric conditioner, starch).
Put the product in the compartment before you start the pro-
gramme.
This is the maximum level for the quantity of liquid additives.
Always obey the instructions that you find on the packaging of the deter-
gent products.
SETTING THE PROGRAMME
(KNOB 1 )
Turn the programme selector dial to the
required programme.
The programme dial determines the type
of washing cycle (e.g. water level, drum
movement, number of rinses) and the
washing temperature according to the
type of laundry.
The pilot light of button 8starts blinking.
The programme dial can be turned either
clockwise or anticlockwise.
= Reset programme / switching OFF
of the machine
ENGLISH 15

If you turn the programme dial to
another programme when the ap-
pliance is working, the yellow pilot
light of button 8blinks 3 times.
The display shows the message
Err to indicate a wrong selection.
The machine will not perform the
new set programme.
SETTING THE SPIN SPEED
(BUTTON 2)
When you set the programme, the appli-
ance automatically proposes the maxi-
mum spin speed allowed by that pro-
gramme.
Press this button repeatedly to change
the spin speed. The relevant light will
light up.
RINSE HOLD : the water of the last rinse is
not emptied out to prevent the fabrics
from creasing. When the programme has
finished the display shows a blinking .
The DOOR pilot light goes on.
The pilot light of button 8is off. The door
is blocked to indicate that the water must
be emptied out.
To empty the water out please read
chapter «At the end of the pro-
gramme».
SETTING THE STAIN OPTION
(BUTTON 3)
Set this option to treat heavily soiled or
stained laundry with stain remover
The appliance extends the main wash
phase and intensifies the stain action
phase. The relevant light illuminates.
This option is not available with a
temperature lower than 40°C.
If you wish to perform a programme with
the stain option, pour stain remover into
compartment .
SETTING THE TIME SAVING
OPTION (BUTTON 4)
This option allows you to modify the
washing time, automatically proposed by
the appliance.
Press button 4
once
DAILY The relative pilot light
comes on.
The washing duration will be
reduced to wash daily soiled
laundry.
Press button 4twice
SUPER
QUICK The relative pilot light re- mains lit.
The washing duration will be
reduced to wash lightly
soiled laundry or items used
or worn for a short time.
The display shows the decreased washing
time.
SETTING THE EXTRA RINSE
OPTION (BUTTON 5)
This appliance is designed for saving wa-
ter.
However, for people with a very delicate
skin (allergic to detergents) it may be nec-
essary to rinse the laundry using an extra
quantity of water (extra rinse).
The appliance will perform some addi-
tional rinses.
STARTING THE PROGRAMME
(BUTTON 8)
Press the button 8to start the pro-
gramme. The corresponding red pilot
light stops blinking.
The pilot light Ais on to indicate that the
appliance starts operating.
The pilot light Cis on to indicate the door
is locked.
Press the button 8to interrupt a pro-
gramme which is running. The corre-
sponding red pilot light starts blinking.
Press the button 8again to restart the
programme from the point at which it was
interrupted
If you have chosen a delayed start with
button 9, the machine will begin the
countdown.
If you set an incorrect option, the yellow
pilot light of the button 8blinks for 3
times. The display shows the message Err
for some seconds.
16 www.aeg.com

SETTING THE DELAY START
(BUTTON 9)
Press this button again an again to set the
required delay.
The display shows the set delay time val-
ue (up to 20 hours) for some seconds,
then it shows the duration of the pro-
gramme again.
Set the delay before you press the button
8.
You can delay the wash programme can
be delayed from 30 min - 60 min - 90 min,
2 hours and then by 1 hour up to a maxi-
mum of 20 hours.
Adding items after you have set the de-
lay (throughout the delay time the door
will be locked):
• Press the button 8to put the machine
in pause
• Add the laundry, close the door .
• Press the button 8again.
Setting the delayed start:
• Set the programme and the required
options.
• Set the delay start.
• Press the button 8: the appliance starts
its hourly countdown.
The programme will start after the se-
lected delay has expired.
Cancelling the delayed start:
• Press the button 8to set the washing
machine to PAUSE;
• Press the button 9once until the dis-
play shows the symbol ’;
• Press the button 8again to start the
programme.
You can change the set delay only
after you set the washing pro-
gramme again.
The Delay Start can not be selected with
DRAIN programme.
ALTERING AN OPTION OR A
RUNNING PROGRAMME
It is possible to change some options be-
fore the programme carries it out. Before
you make any change, you must press the
button 8to pause the appliance.
Changing a running programme is possi-
ble only by resetting it.
Turn the programme dial to and then
to the new programme position.
Press the 8button again to start the new
programme. The washing water in the tub
will not emptied out.
INTERRUPTING A
PROGRAMME
Press the button 8to interrupt a pro-
gramme which is running, the corre-
sponding light starts blinking. Press the
button again to restart the programme.
CANCELLING A PROGRAMME
Turn the selector dial to to cancel a
programme which is running. Now you
can select a new programme.
OPENING THE DOOR
When the machine is working and
through the delay time, the door is
locked.
If, for any reason, it is necessary to open
it, firstly press the button 8to set the ma-
chine to pause
If the light Cafter a few minutes goes off,
the door can be opened.
If the light Cstays on and the door re-
mains locked, this means that the ma-
chine is already heating or that the water
level is too high. In this case the door can
not be opened.
If you cannot open the door but you need
to open it, turn the programme dial to
to switch the machine off. After a few mi-
nutes the door can be opened (pay at-
tention to the water level and tempera-
ture !) .
After closing the door, it is necessary to
set the programme and the options
again. Press button 8to start the pro-
gramme again.
AT THE END OF THE
PROGRAMME
The machine stops automatically. The pi-
lot light of button 8, the pilot lights Aand
Cgo off. A blinking will appear on the
display.
If you have set a programme or an option
that ends with water in the tub, the light C
remains lit. The door is locked. The water
ENGLISH 17

must be emptied out before opening the
door. During this time the drum continues
to turn at regular intervals until water
drain.
Follow the below instructions to empty
out the water:
•Turn the programme selector dial to
• Set the DRAIN or SPIN programme
• Reduce the spin speed, if needed
• Press the button 8
• When the programme has finished the
display shows a blinking . The pilot
light Cgoes off. The door can be
opened.
Turn the programme selector dial to
to switch the machine off.
Remove the laundry from the drum and
carefully check that the drum is empty. If
you do not intend to carry out another
wash, close the water tap. Leave the door
open to prevent the formation of mildew
and unpleasant smells.
Stand by : once the programme has fin-
ished after a few minutes the energy sav-
ing system will be enabled. The bright-
ness of the display is reduced. By pressing
any button the appliance will come out of
the energy saving status.
18 www.aeg.com

DAILY USE - DRYING
DRYING ONLY
The recommended load size is 3 kg for
cottons and linen, and 2 kg for synthetic
items.
It is also possible to dry up to 4 kg
of cotton items (see the «Drying
Programme » table).
The water tap must be open and the
drain hose must be positioned in the
sink or connected to the drain pipe.
1.
Load the laundry.
2.
Select a spin cycle at the maximum
spin speed allowed for the type of
laundry in order to obtain the best
drying performances.
3.
Set the drying programme for Cot-
tons or Synthetic in the Drying sector
of the programme dial.
4.
Press button 6to set the drying time.
Press this button again and again un-
til the time you want appears on the
display.
For Cottons you can set a drying time
from 10 minutes to 250 minutes
(hours 4.10).
For Synthetic you can select a drying
time from 10 minutes to 130 minutes
(hours 2.10).
Every time you press this button the
drying time increases by 5 minutes.
Note! The programme time will auto-
matically increase by a few minutes.
5.
Press button 8to start the pro-
gramme.
After the programme has started, the
time remaining is updated every mi-
nute.
If you set only 10 minutes of dry-
ing phase with the timed drying
button, the appliance performs
only a cooling phase.
6.
At the end of the drying programme,
some acoustic signals sound. A blink-
ing appears on the display.
The pilot light B, and Cand the light
of the button 8go off.
At this point, begins an anti-crease
phase, which lasts for about 10 mi-
nutes. During this time the light Cis
on. The door cannot be opened.
If you need to open the door be-
fore or during the anti-crease
phase or to interrupt it, press any
button or turn the programme di-
al to any programme position (ex-
cept O.
The door can be opened after
some minutes. (In any case do not
try to open the door if it is
locked!) .
7.
Turn the selector dial to the Oposi-
tion to switch the machine off.
8.
Remove the laundry.
Note!
The different type of cottons (towelling,
sheets, shirts, and so on) or any laundry
items rolling up during the spinning
phase may result in partial dryness.
In the exceptional case that at the end of
the cycle the laundry remains slightly wet,
we suggest that you unfold the rolled up
items, redistribute them evenly in the
drum and select an additional drying cy-
cle of 20-30 minutes.
NON-STOP PROGRAMME:
WASHING AND TIMED
DRYING
The recommended load size is 3 kg for
cotton and 2 kg for synthetic.
It is also possible to dry up to 4 kg
of cotton items (see the «Drying
Programme » table).
CAUTION!
Do not use a dosing device/ball
when carrying out a washing
and drying programme.
1.
Load the laundry.
2.
Add detergent and fabric softener.
3.
Switch the machine on: turn the selec-
tor dial to the required washing pro-
gramme/fabric.
4.
Press the relevant buttons to set the
required options.
If possible, do not set a spin
speed lower than that proposed
by the appliance to avoid too long
ENGLISH 19

a drying time therefore saving en-
ergy. In any case the lowest values
you can select are 900 r.p.m. for
cottons and synthetics and 700
r.p.m. for delicate fabrics. The re-
duction of the spin speed is only
possible after selecting drying.
5.
Press the button 6to set the drying
time. When selecting a «non-stop
programme» the pilot lights Aand B
illuminate.
The DRYING TIME value appears on
the display for some seconds, then
the entire duration of the washing
and drying cycle appears.
If you set a washing programme
and only 10 minutes of drying cy-
cle by pressing the button 6, the
total duration of the cycles dis-
played includes also the unrolling
and the cooling phase.
6.
Press the button 8to start the pro-
gramme. After the programme has
started, the time remaining is upda-
ted every minute.
7.
At the end of the programme, follow
the indications given in the previous
chapter. Then, turn the selector to the
Oposition to switch the machine off.
8.
Remove the laundry.
FLUFF IN THE GARMENTS
During the WASHING AND/OR DRYING
PHASE, certain types of fabric, as sponge-
cloth, wool, sweatshirt, could release fluff.
The released fluff could stick to the fabrics
during the next cycle.
This drawback increases with technical
fabrics.
To prevent the lint in your clothes, it is
recommended:
• To do not wash dark fabrics after you
washed and dried light colored fabrics
(new sponge, wool, sweatshirt especial-
ly) and vice versa.
• To air-dry this type of fabrics when they
are washed the first time.
• To clean the filter.
• Perform one or more rinse cycles to
wash the drum between the washing
and drying of fabrics with different col-
ors.
• After the drying phase, thoroughly
clean the empty drum, the gasket and
the door with a wet rag.
20 www.aeg.com
