AEMC instruments 501 User manual


CLAMP-ON METER

MEDIDORES DE TENAZA
501
503
ESPAÑOL Manual de
Instrucciones
ENGLISH User Manual
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
certifies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specifications.
An NIST traceable certificate may be
requested at the time of purchase, or obtained
by returning the instrument to our repair and
calibration facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date
of receipt by the customer. For recalibration,
please use our calibration services. Refer to our
repair and calibration section at .
Serial #: ________________________________
Catalog #: 2117.21 / 2117.22
Model #: 501/503
Please fill in the appropriate date as indicated:
Date Received: ___________________________
Date Calibration Due: ______________________
Chauvin Arnoux®, Inc. d.b.a AEMC®Instruments
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

2 Clamp-on Meter Models 501 and 503
TABLE OF CONTENTS
INTRODUCTION ..................................... 4
1.1 International Electrical Symbols...........5
1.2 Receiving Your Shipment.....................5
1.3 Ordering Information ............................5
PRODUCT FEATURES............................. 6
2.1 Model 501 Control Features.................6
2.2 Model 503 Control Features.................7
2.3 LCD Display .........................................8
SPECIFICATIONS ................................... 9
3.1 ElectricalSpecications .......................9
3.1.1 Model 501..................................9
3.1.2 Model 503................................10
3.2 MechanicalSpecications..................11
3.3 EnvironmentalSpecications.............12
3.4 SafetySpecications.........................12
OPERATION.......................................... 13
4.1 Functions............................................13
4.1.1 Data Hold ................................13
4.1.2 Manual Range Mode
(Model 503 only) ...........................13
4.1.3 (Relative) Zero Mode
(Model 503 only) ...........................13
4.1.4 Disabling Auto Power Off
(Model 503 only).................................... 14
4.2 AC Current Measurement ..................14
4.3 AC Volt Measurement ........................15
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 501 and 503 3
4.4 DC Volt Measurement ........................16
4.5 DC Current Measurement (503 only)....17
4.6 Resistance Measurement ..................18
4.7 Continuity Measurement ....................19
4.8 Frequency Measurement
Using Current Input............................20
4.9 Frequency Measuring Using .................
Voltage Input ......................................21
MAINTENANCE..................................... 22
5.1 Warning!.............................................22
5.2 Cleaning.............................................22
5.3 Battery Replacement..........................23
Repair and Calibration........................................24
Technical and Sales Assistance .........................24
Limited Warranty ................................................25
Warranty Repairs................................................25
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

4 Clamp-on Meter Models 501 and 503
CHAPTER 1
INTRODUCTION
Warning
● Readtheusermanualbeforeoperatingand
follow all safety information.
● Onlyusethemeterasspeciedinthisuser
manual.
● Neverusethismeteronacircuitwithvolt-
ages greater than 600Vrms @ 50/60Hz.
● Nevermeasurecurrentwhilethetestleads
are connected to the input jacks.
● Donotoperatethemeterifthebodyortest
leads look damaged.
● Checktherotaryrangeswitchandmake
sure it is at the correct position before each
measurement.
● Donotperformresistanceandcontinuity
test on a live circuit.
● Useextremecautionwhenmeasuringlive
systems with voltages greater than 60VDC or
30VAC.
● Useextremecarewhenworkingaroundbus
bars and bare conductors.
● Donotusethemeterinoverrange/overload
conditions (OL).
● Foraccuratereadings,changethebattery
when the symbol appears.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 501 and 503 5
1.1 International Electrical Symbols
This symbol signies that the instrument is pro-
tected by double or reinforced insulation.
This symbol on the instrument indicates a
WARNING and that the operator must refer to the
user manual for instructions before operating the
instrument.Inthismanual,thesymbolpreceding
instructions indicates that if the instructions are
notfollowed,bodilyinjury,installation/sampleand
product damage may result.
Risk of electric shock. The voltage at the parts
marked with this symbol may be dangerous.
1.2 Receiving Your Shipment
Uponreceiving your shipment, make surethat thecon-
tents are consistent with the packing list. Notify your dis-
tributor of any missing items. If the equipment appears to
bedamaged,leaclaimimmediatelywiththecarrierand
notifyyourdistributoratonce,givingadetaileddescrip-
tion of any damage. Save the damaged packing container
to substantiate your claim.
1.3 Ordering Information
Clamp-on Meter Model 501..................... Cat. #2117.21
Includes meter, pair of test leads (red/black with probe
tips), two 1.5V AAA batteries, soft carrying case and a
user manual.
Clamp-on Meter Model 503..................... Cat. #2117.22
Includes meter, pair of test leads (red/black with probe
tips), two 1.5V AAA batteries, soft carrying case and a
user manual.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

6 Clamp-on Meter Models 501 and 503
CHAPTER 2
PRODUCT FEATURES
2.1 Model 501 Control Features
MODEL 501
CLAMP METER
VV
A
OFFHz
HOLD
COM
Ω
H
CAT II
600V
!
600V CAT II
300V CAT III 400A
!
IEC 1010
600V CAT II
300V CAT III
POLLUTION DEGREE 2
WARNING
TO AV OID ELECTRIC
SHOCK REMOVE ALL
INPUTS BEFORE
OPENING THE CASE
SIZE AAA 1.5V X 2
PLEASE READ
MANUAL FOR SAFETY
1
2
4
5
67
8
3
9
1. Jaw assembly - Ø 1.18" (28mm)
2. Safety barrier – anti-slip guard
3. Lever for jaw opening/closing
4. Rotary range selector switch
5. LCD display with bargraph
6. COM (Black) input terminal jack
7. Positive (Red) input terminal jack
8. Data hold button (Blue)
9. Battery compartment cover
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 501 and 503 7
2.2 Model 503 Control Features
1. Jaw assembly - Ø 1.18" (28mm)
2. Safety barrier – anti-slip guard
3. Lever for jaw opening/closing
4. Rotary range selector switch
5. LCD display with bargraph
6. COM (Black) input terminal jack
7. Positive (Red) input terminal jack
8. Data hold & ranging button (Blue)
9. DC zero button (Blue)
10. Battery compartment cover
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

8 Clamp-on Meter Models 501 and 503
2.3 LCD Display
0 10 20 30 40
MK Hz
AUTO
V
A
Ω
H
Low Battery
AUTO Auto Range
Manual Range
Data Hold
Continuity
VVoltage Indicator
ACurrent Indicator
AC Inupt
DC Input
Polarity Indicator
Analog Bargraph
MK Hz Frequency Measurement
Zero (Relative)
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 501 and 503 9
CHAPTER 3
SPECIFICATIONS
Accuracyisprovidedunderthefollowingreferenceconditions:23°C±5°C,45
to75%RH,3Vsupply,conductorcentered,earth’smagneticeld,noexter-
nalmagneticorelectricaleld,sinewave50/60Hz.Accuracyisexpressed
as ± [% of reading (Rdg) ± counts (cts)]
3.1 Electrical Specifications
3.1.1 Model 501
AC Amperes (Auto-ranging)
Range
Measurement Resolution Accuracy
40A 0.05 to 39.99A 0.01A 50 to 60Hz: 1.9% of Rdg ± 5cts
60 to 500Hz: 2.5% of Rdg ± 5cts
400A 40.0 to 400.0A 0.1A
Overload protection: 600Arms
AC Volts (Auto-ranging)
Range Measurement Resolution Accuracy Protection
400V 0.5 to 399.9V 0.1V 50 to 60Hz:
0.8% of Rdg ± 5cts
60 to 500Hz:
1.5% of Rdg ± 5cts
600Vrms
600V 400 to 600V 1V
InputImpedance:1MΩ
DC Volts (Auto-ranging)
Range Measurement Resolution Accuracy Protection
400V 0.2 to 399.9V 0.1V 1% Rdg
± 2 cts 600Vrms
600V 400 to 600V 1V
InputImpedance:1MΩ
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

10 Clamp-on Meter Models 501 and 503
Resistance(Ω)
Range Measurement Resolution Accuracy Max Test Voltage
400Ω0.2 to 399.9Ω0.1Ω1% Rdg ± 2cts 1.5VDC
Overload protection: 600Vrms
Continuity ( )
Range Beeper Activation Max Test Voltage
<40Ω 1.5VDC
Overload protection: 600Vrms
Frequency (Hz) (Auto-ranging)
Input Range Resolution Accuracy Min. Input
Signal
Current 20 to 3999 Hz 1 Hz 0.1% Rdg
± 1ct 2Arms
4.00 to 10.00 kHz 10 Hz
Voltage
2 to 3999 Hz 1 Hz
0.1% Rdg
± 1ct 5Vrms4.00 to 39.99 kHz 10 Hz
40.0 to 399.9 kHz 100 Hz
InputImpedance:1MΩ
Overload protection: 600Vrms or 600Arms
3.1.2 Model 503
DC Amperes (Auto-ranging)
Range Measurement Resolution Accuracy
40A 0.10 to 39.99A 0.01A 2.5% Rdg ± 10cts
400A 40.0 to 400.0A 0.1A
Overload protection: 600Arms
AC Amperes (Auto-ranging)
Range Measurement Resolution Accuracy
40A 0.05 to 39.99A 0.01A 50 to 60Hz: 1.5% Rdg ±10cts
60 to 500Hz: 2.5% Rdg ±10cts
400A 40.0 to 400.0A 0.1A
Overload protection: 600Arms
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 501 and 503 11
AC Volts (Auto-ranging)
Range Measurement Resolution Accuracy Input Impedance
400V 0.5 to 399.9V 0.1V 50 - 60Hz:
0.8% Rdg ± 5cts
60 - 500Hz:
1.5% Rdg ± 5cts
10M
Ω
600V 400 to 600V 1V
Overload protection: 600Vrms
DC Volts (Auto-ranging)
Range Measurement Resolution Accuracy Input Impedance
400V 0.2 to 399.9V 0.1V 1% Rdg ± 2cts 10M
Ω
600V 400 to 600V 1V
Overload protection: 600Vrms
Resistance (Ω)
Range Measurement Resolution Accuracy Max Test Voltage
400Ω0.2 to 399.9Ω0.1Ω1% Rdg ± 2cts 1.5VDC
Overload protection: 600Vrms
Continuity ( )
Range Beeper Activation Max Test Voltage
< 40Ω1.5VDC
Overload protection: 600Vrms
3.2 Mechanical Specifications
Digital Display:
3¾digitsLCDdisplay,4000-count(3999max)
Analog Display:
Fast 42 segment analog bargraph display
Symbol and Scale Range:
Automatic according to range and input signal
Polarity:
displayed when negative signal applied to input
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

12 Clamp-on Meter Models 501 and 503
Over Load:
displayedwheninputsignalexceedsrange
Sample Rate: 2 samples/sec for the digital display
20 samples/sec for the analog bargraph
Power Supply: Two 1.5V AAA (LR03) batteries
Low Power Indication: displayed when the battery
is below the required voltage
Battery Life: 100hoursapprox(Model501)
 80hoursapprox(Model503)
Auto Power Off: The meter will shut itself OFF if there
is no activity for 30 minutes.
Jaw Opening: 1.1" (28mm)
Dimension (L x W x D):
7.60x1.97x1.1"(193x50x28mm)
Weight: 8.11 oz (230g) with batteries
3.3 Environmental Specifications
Operating Temperature:
32°to104°F(0°to40°C),<80%RH,non-condensing
Storage Temperature:
14°to140°F(-10°to60°C),<70%RH,batteryremoved
Altitude: 2000m
3.4 Safety Specifications
EN61010,600V,CATII
EN61010,300V,CATIII
Pollution Degree: 2
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 501 and 503 13
CHAPTER 4
OPERATION
4.1 Functions
4.1.1 Data Hold
• The last reading may be held on the display by pressing
the Hold button. The symbol will be displayed.
• Whenthehelddataisnolongerneeded,releasethe
hold function by pressing the Hold button again.
4.1.2 Manual Range Mode (Model 503 only)
• The Model 503 operates in an Auto-ranging mode
(AUTO displayed) by default. Manual-ranging in V
(400V,600V),andA(40A,400A)isavailable.
Press and hold the RANGE button. When the range
changes(decimalpointshift),releasethebutton.
• The symbol is displayed in the manual range mode.
• Press and hold the RANGE button for more than 2 sec-
onds to re-enter the Auto-ranging mode.
4.1.3 (Relative) Zero Mode (Model 503 only)
• Press the ZERO button to enter the Zero mode - the
symbol turns on and the display is set to zero.
• Toviewtheoffsetvalue,presstheZERO button again.
The
annunciator blinks and the memorized offset
value will be displayed. This value will be subtracted from
thenextmeasurement.
• Whenthezeromodeisactivated,themeterautomati-
cally enters the manual range mode (the auto-range
function will be disabled).
• Press and hold down the ZERO button for 2 seconds
toexit.
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

14 Clamp-on Meter Models 501 and 503
4.1.4 Disabling Auto Power Off (Model 503 only)
• Start in OFFsetting,thenpressandholdZERO button.
• Power the meter on by selecting a range.
• Thenexttimethemeteristurnedon,theauto-offfunc-
tion will be re-activated.
4.2 AC Current Measurement
NOTE: Remove the test leads before measuring current
• Turntherotaryrangeswitchtothe range.
• Pressthelevertoopenthejaws.
• Clamp the jaws around the conductor to be measured.
• Ifreadingisunstableandishardtoread,pushthe
HOLD button and read the measurement.
WARNING: If overload " "isdisplayed,
unclamp the meter immediately .
V
V
A
OFF Hz
Ω
0 1020
CATII
600V
AUTO
A
2 0 0 0
!
COM
®
INSTRUMENTS
MODEL 501
CLAMP METER
HOLD
H
600V CAT II
300V CAT III 400A
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 501 and 503 15
4.3 AC Volt Measurement
WARNING: MaximumInputVoltageis600V.Do
notexceedthisvoltagetoavoidelectricalshock
and/or damage to the instrument.
• Turntherotaryrangeswitchtothe range.
• Inserttheredtestleadtothered"+" input jack and
the black lead to the black "COM" input jack.
• Bringthetestprobetipsintocontactwiththetest
points.
• Ifreadingisunstableandishardtoread,pushthe
HOLD button and read the measurement.
WARNING: Immediately unclamp the meter
from the conductor under test if overload " "
is displayed.
®
INSTRUMENTS
MODEL 501
CLAMP METER
VV
A
OFF Hz
HOLD
Ω
H
600V CAT II
300V CAT III 400A
0 10
AUTO
V
1 1 0 0
CAT II
600V
!
COM
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

16 Clamp-on Meter Models 501 and 503
4.4 DC Volt Measurement
• Turntherotaryrangeswitchtothe range.
• Inserttheredtestleadtothered"+" input jack and
the black lead to the black "COM" input jack.
• Bringthetestprobetipsintocontactwiththetest
points.
• Ifreadingisunstableandishardtoread,pushthe
HOLD button and read the measurement.
WARNING: Immediately unclamp the meter
from the conductor under test if overload " "
is displayed.
®
INSTRUMENTS
MODEL 501
CLAMP METER
HOLD
H
600V CAT II
300V CAT III 400A
VV
A
CAT II
600V
AUTO
OFF Hz
V
1 2 0
!
COM
Ω
010
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

Clamp-on Meter Models 501 and 503 17
4.5 DC Current Measurement (503 only)
NOTE: Remove the test leads before measuring current
• Turntherotaryrangeswitchtothe range.
• Ifneeded,thedisplaymaybe“zeroed”.Pressthe
ZERO button to zero the reading. Note that the meter
enters the 40A manual range mode when zeroed. If
the measured current is greater than 40A (OL dis-
played),theuserneedstomanuallyselectthe400A
range(seeManualRangeprocedure§4.1.2),and
then zero the probe again.
• Pressthelevertoopenthejaws.
• Clamp the jaws around the conductor to be measured.
• Ifreadingisunstableandishardtoread,pushthe
HOLD button and read the measurement.
WARNING: Immediately unclamp the meter
from the conductor under test if overload " "
is displayed.
0
CAT II
600V
AUTO
A
5 00
!
COM
CAT II
600V
!
OFF
A
A
V
Ω
®
INSTRUMENTS
HOLD
RANGE
Press 1 Sec
H
ZERO
MODEL 503
CLAMP METER
600V CAT II
300V CAT III 400A
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664

18 Clamp-on Meter Models 501 and 503
4.6 Resistance Measurement
• Turntherotaryrangeswitchtothe range.
• Inserttheredtestleadtothered"+" input jack and
the black lead to the black "COM" input jack.
• Bringthetestprobetipsintocontactwiththesample
under test.
WARNING: Immediately unclamp the meter
from the conductor under test if overload " "
is displayed.
WARNING: When making a resistance mea-
surement, make sure that the power is off
(dead circuit), and that all capacitors in the
measured circuit are fully discharged.
®
INSTRUMENTS
MODEL 501
CLAMP METER
HOLD
H
600V CAT II
300V CAT III 400A
01020
Ω
3 000
VV
A
CAT II
600V
OFF Hz
!
COM
Ω
www.ShopAEMC.com
Shop for AEMC products online at: 1.888.610.7664
