AEMC MN114 User manual
AC Current Probe
Model MN114
User Manual
DESCRIPTION
The The MN114 (Catalog #2110.71) is a high accuracy voltage output current probe for
tight areas such as crowded wiring. Extends DMM AC measurements to 10 A. The Model
WARNING
These safety warnings are provided to ensure the safety of personnel and proper operation of the
instrument.
• Read the instruction manual completely and follow all the safety information before attempting to use
or service this instrument.
• Use caution on any circuit: Potentially high voltages and currents may be present and may pose a
shock hazard.
•
voltage ratings given.
• Safety is the responsibility of the operator.
• ALWAYS connect the current probe to the display device before clamping the probe onto the sample
being tested.
• ALWAYS inspect the instrument, probe, probe cable, and output terminals prior to use. Replace any
defective parts immediately.
•
clamping around bare conductors or bus bars.
INTERNATIONAL ELECTRICAL SYMBOLS
instrument.
Thi
before using the instrument.
DEFINITION OF MEASUREMENT CATEGORIES (CAT)
CAT IV corresponds to measurements performed at the primary electrical supply (< 1000 V).
Example: primary overcurrent protection devices, ripple control units, and meters.
CAT III corresponds to measurements performed in the building installation at the
distribution level.
Example: hardwired equipment in xed installation and circuit breakers.
CAT II corresponds to measurements performed on circuits directly connected to the
electrical distribution system.
Example: measurements on household appliances and portable tools.
RECEIVING YOUR SHIPMENT
Upon receiving your shipment, make sure that the contents are consistent with the packing
description of any damage.
INSTRUMENT COMPATIBILITY
The Model MN114 is compatible with any voltmeter, multimeter, or other voltage measuring
instruments with an input impedance greater than 100 KΩ. To achieve the stated accuracy,
ELECTRICAL SPECIFICATIONS
Current Range:
1 mA to 10 A, continuous
Output Signal:
100 mV/
(1 V @ 10 A)
Accuracy and Phase Shift*:
(*Reference conditions: 23 °C ± 3 °K, (20 to
-
nal current carrying conductor, test sample
centered.) Load impedance 1 MΩ.
Accuracy:
Phase Shift:
Overload:
20 A continuous
Frequency Range:
Load Impedance:
100 KΩmin
Working Voltage:
Common Mode Voltage: 30 V
MECHANICAL SPECIFICATIONS
Operating Temperature:
Storage Temperature:
Temperature Inuence:
Maximum Cable Diameter:
0.47 in Ø max (12 mm)
Dimensions:
Weight:
Colors:
Dark gray handles with red cover
Polycarbonate Material:
-
bonate UL 94 V0
Output:
banana plug
SAFETY SPECIFICATIONS
Electrical:
core and output cable
ORDERING INFORMATION
AC Current Probe MN114.......Cat #2110.71
Accessories:
Banana plug adapter
(to nonrecessed plug) ............Cat #1017.45
OPERATION
Making Measurements with the AC Current Probe Model MN114
■Connect the black (S2) and red (S1) terminals to the 2 V range of your DMM or
instrument. The MN114 has a ratio of 10:1. This means that for 10 A in the conductor
around which the probe is clamped, 1 V will come out of the probe leads to your
DMM or instrument. The output is 100 mV per Amp AC. Select the range on your
is unknown, start with the highest range (2 V) then work down until the appropriate
range and resolution is reached. Clamp the probe around the conductor. Take the
reading on the meter and multiply it by 10 to obtain the measured current.
Meter Reading 10 mV 120 mV 1200 mV
Measured Value
■For best accuracy, avoid if possible, the proximity of other conductors which may
create noise.
Tips for Making Precise Measurements
■When using a current probe with a meter, it is important to select the range that provides
the best resolution. Failure to do this may result in measurement errors.
■Make sure that probe jaw mating surfaces are free of dust and contamination.
Contaminants cause air gaps between the jaws, increasing the phase shift between
MAINTENANCE
Warning
■For maintenance use only original factory replacement parts.
■To avoid electrical shock, do not attempt to perform any servicing unless you are
■To avoid electrical shock and/or damage to the instrument, do not allow water or other
foreign agents to come into contact with the probe.
Cleaning:
■To ensure optimum performance, it is important to keep the probe jaw mating surfaces
clean at all times. Failure to do so may result in error in readings. To clean the probe
clean with a soft oiled cloth.
REPAIR AND CALIBRATION
You must contact our Service Center for a Customer Service Authorization number
(CSA#). This will ensure that when your instrument arrives, it will be tracked and processed
promptly. Please write the CSA# on the outside of the shipping container.
Chauvin Arnoux®®
[email protected]
(Or contact your authorized distributor)
NOTE: You must obtain a CSA# before returning any instrument.
TECHNICAL AND SALES ASSISTANCE
use or application of this instrument, please contact our technical hotline.
[email protected]
LIMITED WARRANTY
The instrument is warrantied to the owner for a period of two years from the date of
original purchase against defects in manufacture. This limited warranty is given by AEMC®
unit has been tampered with, abused, or if the defect is related to service not performed by
AEMC®
Full warranty coverage and product registration is available on our website at:
www.aemc.com/warranty.html.
Please print the online Warranty Coverage Information for your records.
