AERMEC FCLI 32 User manual

TECHNICAL MANUAL
CASSETTE-TYPE FAN COIL WITH INVERTER
IFCLITY1806 - 5773010_03
FCLI
FCLI 32 (600x600)
FCLI 34 (600x600)
FCLI 42 (600x600)
FCLI 44 (600x600)
FCLI 62 (600x600)
FCLI 64 (600x600)
FCLI 82 (840x840)
FCLI 122 (840x840)
FCLI 124 (840x840)

4
The fan coils are shipped in standard package which consists of expanded polystyrene foam and cardboard shells.
PACKAGE
TRASPORTO • TRANSPORT • TRANSPORT • TRANSPORT • TRANSPORTE
NON bagnare. Tenere al
riparo dalla pioggia.
KEEP DRY. Keep out of
the rain.
NE PAS mouiller. Tenir à
l’abri de la pluie.
NICHT nass machen.
Vor Regen geschützt
anbringen
NO mojar. Conservar
protegido de la lluvia.
NON calpestare. DO NOT step on unit. NE PAS marcher sur
l’appareil. NICHT betreten . NO pisar.
N
Sovrapponibilità: con-
trollare sull’imballo per
conoscere il numero di
macchine impilabili.
Stackability: check the
package to know the
number of stackable
machines.
Empilement : vérifier sur
l’emballage le nombre
d’appareils empilables.
Stapelbarkeit: Auf der
Verpackung nachsehen,
wie die Anzahl der sta-
pelbaren Geräte lautet.
Superponibilidad: obser-
var en el embalaje la
cantidad de máquinas
que pueden apilarse.
>25Kg
NON trasportare la mac-
china da soli se il suo
peso supera i 25Kg.
DO NOT carry the equip-
ment alone if weight
exceeds 25Kg.
NE PAS faire transporter
l’appareil par une seule
personne si son poids est
supérieur à 25kg.
NICHT das Gerät allein
transportieren, wenn
sein Gewicht die 25kg
übersteigt.
NO transportar la máqui-
na solos si su peso es
superior a los 25Kg.
NON lasciare gli imballi
sciolti durante il
trasporto.
Non rovesciare.
DO NOT leave boxes
unsecured during
transportation.
Do not overturn.
NE PAS laisser les embal-
lages sans attaches
durant le transport.
Ne pas renverser.
NICHT die Verpackungen
während des Transports
geöffnet lassen.
Nicht stürzen.
NO dejar los embalajes
sin sujetar durante el
transporte.
No invertir.
Fragile, maneggiare con
cura. Fragile, handle with care. Fragile, manipuler avec soin.
Zerbrechlich, sorgfältig
handhaben.
Frágil, manipular con
cuidado.
SIMBOLI DI SICUREZZA • SAFETY SYMBOL • SIMBOIES DE SECURITE
SICHERHEITSSYMBOLEOLE • SÍMBOLOS DE SEGURIDAD
Pericolo:
Tensione
Danger:
Power supply
Danger:
Tension
Gefahr !
Spannung
Peligro:
Tensión
Pericolo:
Organi in movimento
Danger:
Movings parts
Danger:
Organes en mouvement
Gefahr !
Rotierende Teile
Peligro:
Elementos en
movimiento
Pericolo!!! Danger!!! Danger!!! Gefahr!!! Peligro!!!

5
ATTENTION: reserved solely to the
After-sales service/assistance. On the
Inverter board there are 2 LED (Alarm/
Power) indicating the operating status
of the unit. The table for decoding
the messages can be found in the
installation chapter.
WARNING: the fan coil is connect-
ed to the power supply and a water cir-
cuit. Operations performed by persons
without the required technical skills can
lead to personal injury to the operator
or damage to the unit and surrounding
objects.
ONLY SUPPLY THE FAN COIL WITH
SINGLEPHASE 230 VOLT ELECTRICITY
Use of other power supplies could
cause permanent damage to the fan
coil.
DO NOT USE THE FAN COIL IMPROP
ERLY
Do not use the fan coil in animal hus-
bandry applications (e.g. incubation).
DO NOT TUG THE ELECTRICAL CABLE
It is very dangerous to pull, tread on or
crush the electrical power cable or fix it
with nails or drawing pins.
A damaged power cable can cause
short circuits and personal injury.
DO NOT PUT ANYTHING IN THE AIR
OUTLETS
Do not put anything at all in the air
outlet slots.
This could cause injury to people and
damage to the fan.
WARNING
If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.”
This appliance can be used by
children aged from 8 years and above
and persons with reduced physical,
sensory or mental capabilities or lack
of experience and knowledge if they
have been given supervision or
instruction concerning use of the
appliance in a safe way and understand
the hazards involved. Children shall not
play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision
.
AIRING THE ROOM
Periodically air the room in which the
fan coil has been installed; this is par-
ticularly important if the room is occu-
pied by many people, or if gas appli-
ances or sources of odours are present.
CORRECTLY REGULATING THE TEM
PERATURE
The room temperature should be
adjusted in order to provide maximum
comfort to the people in the room,
especially if they are elderly, children
or sick people; avoid differences over
7°C between the outdoor temperature
and the temperature inside the room
in summer.
In summer, a temperature that is too low
causes higher electrical consumption.
CORRECTLY ADJUSTING THE AIR JET
Air coming out from the fan coil must
not reach people directly; in fact, even
if the air is warmer than the room tem-
perature, it could cause a cold sensation
and result in discomfort.
DURING OPERATIONS
Always leave the filter on the fan coil
during operation (otherwise dust in
the air could soil the coil surface area).
WHAT IS NORMAL
During cooling function, water vapour
may be present in the air delivery.
In the heating operation, a slight hiss
might be heard close to the fan coil.
Sometimes the fan coil might give off
unpleasant smells due to the accumu-
lation of substances present in the air
of the room (clean the filter more often,
especially if the room is not ventilated
regularly).
IMPORTANT INFORMATION AND MAINTENANCE

6
DESCRIPTION OF THE UNIT
PURPOSE OF THE FCLI CASSETTE MODULATING FAN COIL
The fan coil is a terminal used to treat air, both during winter and summer.
The Cassette modulating fan coils of the FCLI series with brushless type inverter motor (ie without brushes) are different from the
traditional fan coils because they offer a better climatic, acoustic comfort and energy saving.
- The set temperature is maintained
with utmost precision, the continuous
modulation of the fan speed prevents
oscillations due to speed changes or
succession of on-off cycles.
- The acoustic comfort is remarkable,
since there are no abrupt changes
between the various speeds, you
cannot hear the noise changes from
one speed to another, or the change
between off and on. The type of motor
and control used also allow a minimum
rotation speed must lower than that of
traditional models (even less than half)
and so, not only is the average noise
must lower, but above all it is the feeling
of actual noise (e.g. if the traditional
fancoil in a bedroom alternates cycles at
minimum speed and fan off cycles, what
we perceive is not the average noise,
but the noise of when it is running at
minimum speed).
- Energy saving thanks to the use
of brushless motor that allows for
greater efficiency, even under normal
conditions. For comparison we have
created a display that we will use
during fairs and events, where we have
installed two of our fan coils of the same
size, one with traditional motor and
the other with brushless. On an equal
number of motor revs (and so with same
air flow rate), the reduction in input
power of the fan coil with brushless
motor exceeds 50%. The inverter is a
system that automatically reduces the
revs and the input, allowing the fan
coil to work partialised, with significant
savings on annual management costs.
The more efficient distribution system
contributes in improving the energy
class of the building. The electronic
control of the number of revs allows
ensuring and controlling the peak
phase, avoiding input peaks typical
of this phase had with asynchronous
motors. Obviously these benefits
increase in the installation with the
increasing of the number of FCLI fan
coils present.
ADVANTAGES
Cassette Type Fan Coil with Inverter
for installation in suspended ceiling,
integrable in standard panels 600x600
and 840x840 in larger sizes.
The FCLI cassette type fan coil is a
terminal for the conditioning of air in
a room. The FCLI concentrates high
technological and functional features
that make it the ideal means for air
conditioning for all environments.
The supply of heated air is distributed
throughout the room thanks to the flow
louvers oriented in the four directions.
FCLI heats the room if included in a
heating system with boiler or heat
pump. However, it may also be used in
the summer as an air conditioner, if the
heating system has a water chiller.
The fan coils are designed for systems
with 2 and 4 pipes.
The unit is mounted in a suspended
ceiling with the possibility of sending
conditioned air to adjacent rooms and
introducing external air independently
from unit ventilation.
FCLI CASSETTE
MACHINE PURPOSE
The fan coil is a room air treatment terminal unit for both winter and summer operation.
FCLI VERSION
Cassette-type fan coil with Inverter for installation in suspended ceilings; can be integrated in standard 600x600 and
840x840 panelling.
DESCRIPTION OF THE UNIT
AVAILABLE SIZES
The cassette-type fan coils of the FCLI range are available in:
for 2-pipe systems
FCLI 32 (600x600)
FCLI 42 (600x600)
FCLI 62 (600x600)
FCLI 82 (840x840)
FCLI 122 (840x840)
For 4-pipe systems
FCLI 34 (600x600)
FCLI 44 (600x600)
FCLI 64 (600x600)
FCLI 124 (840x840)
GLLI100/GLFI10/GLLI100N/GLFI10N/GLFI10M/GLLI100EH/GLFI10EH - 



7
MAIN COMPONENTS
DESCRIPTION
The FCLI cassette-type fan coil is a room air
treating unit. The FCLI concentrates high
technological and functional characteris-
tics that make it the ideal climate control
unit for all types of room. The supply
of climate-controlled air is distributed
throughout the room. FCLI generates
heat if included in a heating system with
boiler or heat pump, but may also be
used in the summer as an air conditioner
if the heating system has a water chiller.
The fan coils are designed for 2- and 4-pipe
systems.
The unit is installed in a suspended ceiling
with the possibility to send conditioned
air to adjacent rooms and introduce
external air regardless of unit ventilation.
Thanks to its dimensions, the FCLI with
"module 600" can be perfectly integrat-
ed in standard 600x600 suspended ceil-
ing panelling.

The unit has an integrated metal struc-
ture. The load-bearing base is in galva-
nised sheet steel and is varnished with
polyester powders. The following are
fixed to the base: fixing brackets, coils,
motor and fan, condensate discharge
pump, attachment plate, control board

of the flanges, it allows the channels (for
renewing environmental air and/or deliv-
ery to an adjacent room) to be joined to
the sides.

Galvanised steel clamps for attaching the
unit to the ceiling.
TRAY
Tray closing off the unit. Made of injec-
tion co-moulded polystyrene to avoid
thermal dispersion and the formation of
condensate, it conveys conditioned air
towards the fins and from the conden-
sate drip tray.
The air suction conveyor is equipped with
a protective grille that impedes access to
the moving fan.
THERMAL EXCHANGE COIL
The coils used have copper pipes and cor-
rugated or turbulent aluminium fins.
They are designed to offer the maximum
heat exchange surface. All batteries are
provided with air bleed pipes and water
1 Grille with air filter (GLLI-GLFI)
2 Air delivery deflector (GLLI-GLFI)
3 Grille frame (GLLI-GLFI)
4 Tray
5 Inverter device
 
7 Fastening brackets
8 Electrical box
9 Water connections (only for 4 pipes)
10 Water connections (2 pipes)
11 Air drain valve
12 Push-out, coupling for air delivery in an
adjacent room
13 Condensate drain
FCLI (module 600)
(GLLI100) (GLLI100N) (GLLI100EH)
FCLI (Module 840)
GLLI 20
13
12
8
9
10 7
2
1
11
12 11
13
10
987
6
1
23
4
FCLI (module 600)
(GLFI10) (GLFI10N) (GLFI10M) (GLFI10EH)
1
6
7
13
9
32 4
4
12 11 10 8

8
SA SA
SA SA
SW
SW
VHL
VHL
VHL1
SA SA
SW
SW
V2
V2
VHL2
SYSTEM EXAMPLES
Key: SA Room probe
SW Water probe
VHL 3-way valve (Hot/Cold)
V2 2-way valve (Hot/Cold)
VHL1 3-way Hot Valve
VHL2 2-way Hot Valve
FCLI (Standard)
4-pipe system2-pipe system
FCLI (V2)
4-pipe system2-pipe system
FCLI (VL) without valves
4-pipe system2-pipe system
drain valves, located respectively on the
highest and lowest point of the battery
circulation.
THREE-WAY VALVE
Internal 3-way valve, of the all-or-nothing
  
  , assem-
bled as standard on the heating/cooling
coil, powered with a voltage of 230V ~
50Hz.
FAN UNIT
The fan unit, with the latest axial-centrif-
ugal fan designed to obtain low-sound
emissions, is dynamically and statically
balanced.
The three-phase brushless electric motor is
powered by a dedicated inverter device
that allows the ventilation speed to be
continuously varied.
The electric motor is cushioned with elastic
supports and the steel shaft is mount-
ed on bearings and resists salty fog in

The fan unit can be easily accessed for
cleaning and maintenance.
CONDENSATE DISCHARGE DEVICE
The condensate discharge device disposes
of the condensate that is produced by
the unit and deposited in the polysty-
rene basin. The device consists of a con-
trol board, a non-return valve, a 3-level
float, and a pump with a maximum head
of 800mm. The unit can be easily con-
nected to the condensate discharge sys-
tem by means of a plastic connector with
an external Ø of 16mm.
ALARM: when the level of condensate in
the tray reaches the prefixed limit, the
alarm will stop the flow of water to the
battery, allowing only the fan to function.
WATER CONNECTIONS
The attachment plate groups together
the water connections and the vent of
the coil's primary circuit for 2-pipe and
4-pipe systems. The plates contain raised
symbols that identify the input (IN) and
output (OUT) water connections for the
water.
GLLI/ GLFI (Accessory)
Suction and delivery grille unit
The grille is part of the GLLI100/GLLI10
GLLI100N/GLLI10N/ GLLI10M GLLI100EH/
GLFI10EH and GLLI20 range grille unit
(obligatory accessory).
The form and opening of the intake slats
were developed in order to have the
best possible distribution of the air, both
when functioning in winter as well as in
summer.
Suction occurs through the central grille,
and delivery through the manually
adjustable, perimetric slots. In plastic,
colour RAL 9010, it contains the air filter
that can be easily removed for cleaning.
the GLLI/GLFI need to be interfaced with
an external control panel (not included)
with thermostat and ventilation speed
control, with a 0-10V output.
FILTERING SECTION

RAL9010.
Filter in filtering class G1, self-extinguishing
class V0 (UL94).
Easily removable and made from regener-
able materials. May be cleaned by wash-
ing.
CONTROL PANEL
Use a control panel with thermostat and
ventilation speed control, with 0-10V
output.

9
Minimum average water temperature
If the fan coil is working in continuous
cooling mode in an environment where
the relative humidity is high, condensate
might form on the air delivery and
on the outside of the device. This
condensate might be deposited on any
objects underneath and on the floor.
To avoid condensate on the external struc-
ture of the apparatus with the fan in
operation, the average temperature of
the water must not be lower than the lim-
its shown in the table below, that depend
on the thermo-hygrometric condition of
the air in the environment.
The limits mentioned above refer to opera-
tion while the fan is set
to its minimum speed level.
TECHNICAL DATA AND OPERATING LIMITS

- at the maximum motor speed;
- the total input power is determined by adding the input power
for the unit to the input power for the accessories connected and
declared in the corresponding manuals.
Water temperature
In order to prevent air stratification in the
room, and therefore to achieve improved
mixing, it is advisable not to supply the fan coil
with water at a temperature over 65°C.
The use of water at high temperatures
could cause squeaking due to the different
thermal expansions of the elements (plastics
and metals), this does not however cause
damage to the unit if the maximum operating
temperature is not exceeded.
FCLI 32 34 42 44 62 64 82 122 124
Maximum recommended temperature 65°C
Maximum water inlet temperature 80°C
 kPa 800 (8 bar)
 kPa 100 (1 bar)
Room temperature limit R.T. 0°C<Ta<40 °C
Room temperature limit R.H. R.H.< 85%
 °C 100 50 100 50 150 50 250 350 50
 °C 750 400 750 400 1050 400 1750 2450 400
Minimum delivery (cooling) °C 100 100 100 100 150 150 250 350 250
Maximum delivery (cooling) °C 750 750 750 750 1050 1050 1750 2450 1750
Maximum input current A 0.22 0.22 0.33 0.33 0.37 0.37 0.7 0.75 0.75
Power supply V / Hz 230V (±10%) 50 Hz
230V (±10%) 50/60 Hz
MINIMUM AVERAGE WATER TEMPERATURE [°C] Ambient air temperature with dry bulb
21 23 25 27 29 31
Ambient air temperature
with wet bulb
15 3 3 3 3 3 3
17 3 3 3 3 3 3
19 3 3 3 3 3 3
21 6 5 4 3 3 3
23 - 8 7 6 5 5

10
TECHNICAL DATA
Sound pressure level (weighted A) measured in environment with
volume V=100m3, reverberation time t=05s directivity factor Q=2,
distance r=2.5m
Cooling:
• Room air temperature 27°C D.B.; 19°C W.B.
• Water inlet temperature 7°C; water Dt 5°K
Heating 50°C:
• Environmental air temperature 20°C
• Inlet water temperature: 50°C ; water Dt 10°K
Heating 70°C:
• Environmental air temperature 20°C
• Inlet water temperature: 50°C ; water Dt 10°K
The earth leakage current of several devices
placed under the same circuit breaker is
summed, therefore we recommend paying
attention to the calibration value of the
circuit breaker and, if necessary, consider
splitting the installation in more circuits, each
of which protected by its own circuit breaker.
The performance refers to the following conditions:
FCL_I 32 34 42 44 62 64
Fan speed H M L H M L H M L H M L H M L H M L
Performance in heating mode
2-pipe systems:
Heating capacity (70°C) (1) kW 4.00 2.95 2.22 / / / 7.34 4.47 3.32 / / / 10.49 6.37 5.19 / / /
Water ow rate (1) l/h 350 258 194 / / / 642 391 290 / / / 918 558 454 / / /
Pressure drops (1) kPa 10 6 4 / / / 24 10 6 / / / 42 17 12 / / /
Heating capacity (45°C) (2) kW 1.99 1.47 1.10 / / / 3.65 2.23 1.65 / / / 5.22 3.17 2.58 / / /
Water ow rate (2) l/h 345 254 192 / / / 633 386 287 / / / 905 550 448 / / /
Pressure drops (2) kPa 10 6 4 / / / 23 10 6 / / / 41 17 11 / / /
4-pipe systems with additional heat exchanger
Heating capacity (65°C) (3) kW / / / 2.32 1.96 1.74 / / / 2.74 2.04 1.75 / / / 3.19 2.51 2.21
Water ow rate (3) l/h / / / 203 171 152 / / / 240 178 153 / / / 279 219 194
Pressure drops (3) kPa / / / 9 7 5 / / / 12 7 5 / / / 19 12 10
Performance in cooling mode
Total cooling capacity (4) kW 1.90 1.47 1.16 1.90 1.47 1.16 3.95 2.54 1.96 3.64 2.30 1.83 4.98 3.21 2.66 4.61 2.96 2.46
Sensitive cooling
capacity (4) kW 0.99 1.25 1.52 1.52 1.25 0.99 3.16 1.82 1.38 2.91 1.62 1.30 3.81 2.24 1.87 3.53 2.08 1.73
Water ow rate (4) l/h 327 253 200 327 253 200 679 437 337 626 396 314 856 551 458 793 510 424
Pressure drops (4) kPa 11.7 7.4 4.8 12.7 8 5.2 32.4 14.7 9.2 31.7 13.9 9.2 47.8 21.6 15.5 50.3 22.7 16.3
Fan
Fan - Centrifugal no. 1
Air ow rate m/h 600 410 300 600 410 300 700 360 260 700 360 260 880 500 380 880 500 380
Sound levels
Sound power level (5) dB(A) 46 38 35 46 38 35 53 39 35 53 39 35 61 47 41 61 47 41
Sound pressure level dB(A) 37 29 26 37 29 26 44 30 26 44 30 26 52 38 32 52 38 32
Fittings diameter
Standard coil Ø 3/4" 3/4" 3/4" 3/4" 3/4" 3/4"
Additional coil Ø / 1/2" / 1/2" / 1/2"
Larger coil Ø / / / / / /
Electric functioning
Input power W 18 13 10 18 13 10 55 16 12 55 16 12 61 20 14 61 20 14
Input current A 0.28 0.28 0.43 0.43 0.47 0.47
0-10V signal % 90 62 42 90 62 42 90 46 34 90 46 34 90 52 40 90 52 40
Power supply 230V~50Hz
Kvs (standard version 3-way valve) 2.5 2.5 2.5 2.5 2.5 2.5
Kvs (V2 version 2-way valve) 2.5 2.5 2.5 2.5 2.5 2.5
Hmaximum speed; Mmedium speed; Lminimum speed
(1) Room air 20°C d.b.; Water (in/out) 70°C/60°C;
(2) Ambient air 20°C d.b.; Water (in/out) 45°C/40°C (EUROVENT)
(3) Ambient air 20°C d.b.; Water (in/out) 65°C/55°C; (EUROVENT)
(4) Ambient air 27°C d.b./19°C w.b.; Water (in/out) 7°C/12°C (EUROVENT)
(5) Sound power based on the measurements carried out in accordance with Eurovent 8/2 standard
Sound pressure (weighted A) measured in environment with volume V=100 m reverberation time t=05s, directivity factor Q=2, distance r=2.5m

11
TECHNICAL DATA
Sound pressure level (weighted A) measured in environment with
volume V=100m3, reverberation time t=05s directivity factor Q=2,
distance r=2.5m
Cooling:
• Room air temperature 27°C D.B.; 19°C W.B.
• Water inlet temperature 7°C; water Dt 5°K
Heating 50°C:
• Environmental air temperature 20°C
• Inlet water temperature: 50°C ; water Dt 10°K
Heating 70°C:
• Environmental air temperature 20°C
• Inlet water temperature: 50°C ; water Dt 10°K
The earth leakage current of several devices
placed under the same circuit breaker is
summed, therefore we recommend paying
attention to the calibration value of the
circuit breaker and, if necessary, consider
splitting the installation in more circuits, each
of which protected by its own circuit breaker.
The performance refers to the following conditions:
FCL_I 82 122 124
Fan speed H M L H M L H M L
Performance in heating mode
2-pipe systems:
Heating capacity (70°C) (1) kW 11.88 8.12 5.88 21.75 14.73 10.53 / / /
Water ow rate (1) l/h 1039 710 514 1903 1289 921 / / /
Pressure drops (1) kPa 26 13 7 42 21 11 / / /
Heating capacity (45°C) (3) kW 5.91 4.04 2.92 10.82 7.33 5.24 / / /
Water ow rate (3) l/h 1025 701 507 1877 1271 909 / / /
Pressure drops (3) kPa 25 13 7 41 20 11 / / /
4-pipe systems with additional heat exchanger
Heating capacity (65°C) (4) kW / / / / / / 11.17 8.31 6.30
Water ow rate (4) l/h / / / / / / 977 727 551
Pressure drops (4) kPa / / / / / / 25 14 9
Performance in cooling mode
Total cooling capacity (5) kW 6.00 4.04 2.80 11.00 7.51 5.36 8.80 6.21 4.57
Sensitive cooling capacity (5) kW 4.20 2.76 1.90 8.47 5.74 4.04 6.77 4.67 3.37
Water ow rate (5) l/h 1032 695 482 1893 1292 921 1513 1068 786
Pressure drops (5) kPa 34.7 17 8.8 60.1 30.2 16.4 52.3 28 16.1
Fan
Fan - Centrifugal no. 1
Air ow rate m/h 1100 680 460 1750 1100 750 1750 1100 750
Sound levels
Sound power level (6) dB(A) 50 43 39 60 50 44 60 50 44
Sound pressure level dB(A) 41 34 30 51 41 35 51 41 35
Fittings diameter
Standard coil Ø 3/4" 3/4" 3/4"
Additional coil Ø / / 1/2"
Larger coil Ø / / /
Electric functioning
Input power W 33 14 9 135 33 16 135 33 16
Input current A 0.71 0.80 0.80
0-10V signal % 90 54 38 90 58 38 90 58 38
Power supply 230V~50/60Hz
Kvs (standard version 3-way valve) 4 4 4
Kvs (V2 version 2-way valve) 2.5 2.5 2.5
Hmaximum speed; Mmedium speed; Lminimum speed
(1) Room air 20°C d.b.; Water (in/out) 70°C/60°C;
(2) Ambient air 20°C d.b.; Water (in/out) 45°C/40°C (EUROVENT)
(3) Ambient air 20°C d.b.; Water (in/out) 65°C/55°C; (EUROVENT)
(4) Ambient air 27°C d.b./19°C w.b.; Water (in/out) 7°C/12°C (EUROVENT)
(5) Sound power based on the measurements carried out in accordance with Eurovent 8/2 standard
Sound pressure (weighted A) measured in environment with volume V=100 m reverberation time t=05s, directivity factor Q=2, distance r=2.5m

12
COOLING CAPACITY OUTPUT - FCLI32
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY FCLI 32 / FCLI34 Qv [m3/h] k (Pc) k (Ps)
Speed V3 600 1 1
Speed V2 410 0.77 0.82
Speed V1 300 0.61 0.65
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 1497 829 1196 717 864 831 644 509 501 395
23 1487 935 1189 822 922 728 782 618 642 506
25 1481 1039 1185 927 1057 834 918 725 779 615
27 1459 1141 1326 1047 1189 938 1051 830 914 722
29 1592 1257 1456 1149 1319 1042 1183 934 1047 826
31 1719 1357 1584 1250 1448 1144 1313 1037 1178 930
17
21 1884 830 1587 719 1267 606 910 491 475 357
23 1894 935 1600 825 1281 713 928 598 642 506
25 1880 1039 1587 929 1271 819 920 704 779 615
27 1874 1142 1584 1033 1268 923 1051 830 914 722
29 1850 1243 1562 1135 1319 1042 1183 934 1047 826
31 1840 1344 1584 1250 1448 1144 1313 1037 1178 930
19
21 2342 826 2049 717 1733 606 1389 491 1008 377
23 2329 934 2037 825 1724 715 1382 605 1002 487
25 2318 1038 2028 930 1716 821 1377 710 1000 596
27 2305 1141 2016 1033 1706 925 1368 814 993 722
29 2312 1251 2004 1136 1696 1028 1361 918 1047 826
31 2302 1351 1997 1237 1691 1129 1358 1021 1178 930
21
21 2785 819 2493 710 2181 600 1842 491 1472 380
23 2819 938 2508 821 2197 713 1861 601 1494 491
25 2803 1045 2495 929 2185 821 1851 712 1487 600
27 2785 1147 2478 1032 2171 925 1838 817 1476 708
29 2798 1249 2493 1135 2188 1028 1858 921 1498 812
31 2745 1349 2442 1236 2139 1130 1810 1023 1452 915
23
23 3297 929 2988 814 2678 707 2344 598 1983 490
25 3310 1039 3003 925 2695 818 2364 707 2005 599
27 3143 1146 2838 1032 2532 925 2202 818 1844 710
29 3268 1239 2985 1133 2681 1027 2353 921 1999 814
31 3222 1339 2940 1235 2638 1129 2313 1024 1960 917
5
15
21 1366 779 1025 656 735 567 588 464 433 341
23 1358 885 1020 762 877 692 733 579 586 463
25 1354 989 1155 912 1015 801 874 690 731 578
27 1427 1126 1288 1017 1150 908 1011 798 870 687
29 1557 1229 1420 1121 1283 1013 1146 905 1007 795
31 1686 1331 1549 1223 1414 1116 1278 1009 1140 900
17
21 1769 786 1448 669 1082 545 600 396 433 341
23 1781 892 1463 776 1101 654 733 545 586 463
25 1768 996 1452 881 1092 759 874 690 731 578
27 1764 1100 1449 985 1150 900 1011 798 870 687
29 1741 1202 1428 1087 1283 1013 1146 905 1007 795
31 1732 1302 1549 1223 1414 1116 1278 1009 1140 900
19
21 2239 786 1928 674 1587 555 1196 433 695 288
23 2227 895 1918 783 1578 667 1191 546 692 400
25 2217 1000 1911 888 1573 773 1188 652 692 509
27 2205 1103 1900 990 1564 875 1181 750 870 687
29 2193 1205 1890 1095 1556 981 1175 861 1007 795
31 2184 1306 1884 1196 1552 1083 1278 1009 1140 900
21
21 2690 782 2384 671 2052 558 1684 443 1256 315
23 2703 894 2401 783 2071 669 1706 553 1289 432
25 2690 1001 2389 891 2061 780 1698 663 1284 542
27 2672 1104 2373 995 2047 885 1686 770 1275 651
29 2688 1207 2391 1098 2067 988 1710 875 1302 756
31 2636 1308 2340 1199 2018 1090 1662 977 1254 858
23
23 3188 887 2888 778 2563 669 2209 557 1816 439
25 3203 998 2905 890 2582 778 2232 666 1843 552
27 3036 1104 2739 996 2417 887 2065 776 1674 659
29 3184 1207 2890 1099 2571 991 2224 882 1841 768
31 3138 1307 2845 1201 2529 1093 2184 984 1801 872
7
15
21 1166 705 697 545 666 526 486 384 205 162
23 1159 811 965 756 818 646 666 526 492 388
25 1248 968 1106 873 962 760 816 644 664 524
27 1383 1092 1243 981 1102 870 960 758 814 643
29 1516 1197 1378 1088 1238 978 1099 867 957 755
31 1646 1300 1509 1192 1372 1083 1234 974 1095 864
17
21 1608 726 1233 595 723 433 486 364 205 162
23 1623 833 1252 704 753 545 666 526 492 388
25 1612 938 1242 809 962 729 816 644 664 524
27 1608 1042 1242 913 1102 870 960 758 814 643
29 1587 1144 1378 1088 1238 978 1099 867 957 755
31 1578 1246 1509 1192 1372 1083 1234 974 1095 864
19
21 2102 736 1759 615 1359 482 821 324 205 159
23 2092 845 1751 725 1354 595 819 435 492 348
25 2084 950 1744 830 1350 702 819 545 664 508
27 2073 1051 1735 930 1343 796 960 743 814 643
29 2062 1156 1726 1037 1337 910 1099 854 957 755
31 2055 1258 1722 1140 1335 1014 1234 974 1095 864
21
21 2566 736 2238 620 1869 499 1437 367 842 204
23 2583 849 2257 733 1892 611 1466 482 890 321
25 2571 956 2246 842 1883 722 1460 592 887 435
27 2554 1060 2233 946 1871 828 1450 700 879 543
29 2572 1164 2253 1050 1895 933 1478 806 923 654
31 2521 1264 2202 1151 1845 1034 1427 908 1095 829
23
23 3077 847 2759 734 2409 619 2016 499 1556 367
25 3094 958 2779 846 2432 729 2043 610 1587 480
27 2926 1063 2610 951 2262 836 1868 717 1395 582
29 3078 1166 2766 1056 2424 943 2040 826 1592 700
31 3032 1268 2722 1158 2382 1045 1999 928 1551 803

13
COOLING CAPACITY OUTPUT - FCLI34
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY
FCLI 32 / FCLI34 Qv [m3/h] k (Pc) k (Ps)
Speed V3 600 1 1
Speed V2 410 0.77 0.82
Speed V1 300 0.61 0.65
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 1497 1273 1196 1100 864 1276 644 644 501 501
23 1487 1435 1189 1262 922 922 782 782 642 642
25 1481 1481 1185 1423 1057 1057 918 918 779 779
27 1459 1459 1326 1607 1189 1189 1051 1051 914 914
29 1592 1592 1456 1765 1319 1319 1183 1183 1047 1047
31 1719 1719 1584 1920 1448 1448 1313 1313 1178 1178
17
21 1884 1274 1587 1104 1267 931 910 753 475 475
23 1894 1435 1600 1267 1281 1095 928 919 642 642
25 1880 1595 1587 1426 1271 1257 920 920 779 779
27 1874 1754 1584 1586 1268 1268 1051 1051 914 914
29 1850 1850 1562 1742 1319 1319 1183 1183 1047 1047
31 1840 1840 1584 1920 1448 1448 1313 1313 1178 1178
19
21 2342 1268 2049 1100 1733 931 1389 754 1008 578
23 2329 1434 2037 1267 1724 1098 1382 929 1002 748
25 2318 1594 2028 1427 1716 1260 1377 1090 1000 915
27 2305 1752 2016 1586 1706 1420 1368 1249 993 993
29 2312 1921 2004 1744 1696 1578 1361 1361 1047 1047
31 2302 2074 1997 1899 1691 1691 1358 1358 1178 1178
21
21 2785 1257 2493 1089 2181 922 1842 753 1472 583
23 2819 1440 2508 1261 2197 1095 1861 923 1494 753
25 2803 1604 2495 1426 2185 1261 1851 1094 1487 921
27 2785 1761 2478 1585 2171 1421 1838 1255 1476 1087
29 2798 1918 2493 1742 2188 1578 1858 1414 1498 1247
31 2745 2072 2442 1898 2139 1735 1810 1571 1452 1404
23
23 3297 1426 2988 1250 2678 1085 2344 919 1983 752
25 3310 1595 3003 1420 2695 1256 2364 1086 2005 920
27 3143 1759 2838 1584 2532 1420 2202 1256 1844 1089
29 3268 1902 2985 1740 2681 1577 2353 1414 1999 1250
31 3222 2056 2940 1896 2638 1734 2313 1572 1960 1408
5
15
21 1366 1196 1025 1007 735 735 588 588 433 433
23 1358 1358 1020 1170 877 877 733 733 586 586
25 1354 1354 1155 1400 1015 1015 874 874 731 731
27 1427 1427 1288 1562 1150 1150 1011 1011 870 870
29 1557 1557 1420 1722 1283 1283 1146 1146 1007 1007
31 1686 1686 1549 1878 1414 1414 1278 1278 1140 1140
17
21 1769 1206 1448 1028 1082 837 600 600 433 433
23 1781 1369 1463 1192 1101 1003 733 733 586 586
25 1768 1530 1452 1353 1092 1092 874 874 731 731
27 1764 1689 1449 1512 1150 1150 1011 1011 870 870
29 1741 1741 1428 1669 1283 1283 1146 1146 1007 1007
31 1732 1732 1549 1878 1414 1414 1278 1278 1140 1140
19
21 2239 1207 1928 1034 1587 851 1196 664 695 443
23 2227 1375 1918 1202 1578 1024 1191 838 692 614
25 2217 1535 1911 1364 1573 1187 1188 1001 692 692
27 2205 1693 1900 1520 1564 1343 1181 1152 870 870
29 2193 1850 1890 1681 1556 1506 1175 1175 1007 1007
31 2184 2006 1884 1836 1552 1552 1278 1278 1140 1140
21
21 2690 1201 2384 1030 2052 857 1684 680 1256 484
23 2703 1372 2401 1203 2071 1027 1706 849 1289 663
25 2690 1537 2389 1368 2061 1197 1698 1018 1284 832
27 2672 1695 2373 1528 2047 1358 1686 1183 1275 999
29 2688 1853 2391 1685 2067 1517 1710 1344 1302 1161
31 2636 2008 2340 1842 2018 1673 1662 1500 1254 1254
23
23 3188 1362 2888 1195 2563 1027 2209 855 1816 674
25 3203 1532 2905 1366 2582 1194 2232 1023 1843 848
27 3036 1695 2739 1530 2417 1361 2065 1191 1674 1011
29 3184 1853 2890 1687 2571 1521 2224 1354 1841 1180
31 3138 2007 2845 1844 2529 1679 2184 1510 1801 1338
7
15
21 1166 1083 697 837 666 666 486 486 205 205
23 1159 1159 965 1161 818 818 666 666 492 492
25 1248 1248 1106 1340 962 962 816 816 664 664
27 1383 1383 1243 1507 1102 1102 960 960 814 814
29 1516 1516 1378 1670 1238 1238 1099 1099 957 957
31 1646 1646 1509 1830 1372 1372 1234 1234 1095 1095
17
21 1608 1115 1233 914 723 665 486 486 205 205
23 1623 1279 1252 1081 753 753 666 666 492 492
25 1612 1441 1242 1241 962 962 816 816 664 664
27 1608 1599 1242 1402 1102 1102 960 960 814 814
29 1587 1587 1378 1670 1238 1238 1099 1099 957 957
31 1578 1578 1509 1830 1372 1372 1234 1234 1095 1095
19
21 2102 1130 1759 944 1359 740 821 497 205 205
23 2092 1298 1751 1112 1354 914 819 667 492 492
25 2084 1458 1744 1274 1350 1077 819 819 664 664
27 2073 1614 1735 1427 1343 1223 960 960 814 814
29 2062 1776 1726 1593 1337 1337 1099 1099 957 957
31 2055 1931 1722 1750 1335 1335 1234 1234 1095 1095
21
21 2566 1130 2238 952 1869 767 1437 563 842 313
23 2583 1303 2257 1126 1892 937 1466 740 890 493
25 2571 1468 2246 1293 1883 1109 1460 909 887 667
27 2554 1628 2233 1453 1871 1271 1450 1075 879 834
29 2572 1787 2253 1611 1895 1432 1478 1238 923 923
31 2521 1941 2202 1768 1845 1587 1427 1393 1095 1095
23
23 3077 1300 2759 1127 2409 951 2016 767 1556 564
25 3094 1470 2779 1299 2432 1119 2043 936 1587 737
27 2926 1632 2610 1461 2262 1284 1868 1100 1395 893
29 3078 1791 2766 1621 2424 1448 2040 1269 1592 1075
31 3032 1947 2722 1778 2382 1605 1999 1425 1551 1233

14
COOLING CAPACITY OUTPUT - FCLI42
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 3111 2647 2486 2288 1796 2652 1339 1339 1041 1041
23 3092 2984 2471 2624 1917 1917 1626 1626 1334 1334
25 3079 3079 2463 2958 2197 2197 1908 1908 1619 1619
27 3034 3034 2756 3341 2471 2471 2186 2186 1900 1900
29 3310 3310 3026 3668 2743 2743 2460 2460 2176 2176
31 3574 3574 3293 3991 3011 3011 2730 2730 2448 2448
17
21 3916 2649 3300 2294 2633 1935 1893 1566 988 988
23 3937 2984 3327 2633 2664 2276 1929 1910 1334 1334
25 3908 3316 3300 2965 2643 2613 1912 1912 1619 1619
27 3895 3645 3293 3297 2637 2637 2186 2186 1900 1900
29 3846 3846 3247 3623 2743 2743 2460 2460 2176 2176
31 3825 3825 3293 3991 3011 3011 2730 2730 2448 2448
19
21 4868 2636 4260 2288 3602 1935 2888 1569 2095 1202
23 4842 2981 4235 2633 3584 2283 2873 1930 2084 1555
25 4819 3313 4216 2968 3568 2620 2862 2267 2078 1903
27 4793 3643 4192 3297 3548 2952 2845 2597 2065 2065
29 4806 3994 4167 3625 3527 3281 2830 2830 2176 2176
31 4785 4312 4152 3948 3516 3516 2822 2822 2448 2448
21
21 5790 2613 5184 2265 4534 1917 3829 1566 3060 1211
23 5860 2993 5214 2622 4568 2276 3869 1919 3106 1566
25 5828 3334 5187 2965 4543 2622 3848 2274 3090 1914
27 5790 3661 5151 3295 4513 2954 3822 2608 3068 2260
29 5816 3987 5184 3623 4549 3281 3863 2940 3115 2592
31 5707 4307 5078 3945 4447 3607 3763 3265 3019 2920
23
23 6853 2965 6211 2599 5567 2256 4874 1910 4122 1564
25 6882 3316 6243 2952 5603 2610 4915 2258 4169 1912
27 6534 3657 5899 3293 5263 2952 4577 2610 3833 2265
29 6795 3955 6206 3618 5575 3279 4893 2940 4156 2599
31 6699 4275 6113 3941 5484 3604 4808 3268 4075 2926
5
15
21 2839 2487 2131 2093 1528 1528 1222 1222 899 899
23 2824 2824 2120 2432 1823 1823 1524 1524 1218 1218
25 2815 2815 2401 2910 2110 2110 1817 1817 1521 1521
27 2966 2966 2679 3247 2392 2392 2103 2103 1810 1810
29 3236 3236 2953 3579 2667 2667 2382 2382 2093 2093
31 3504 3504 3221 3904 2939 2939 2656 2656 2371 2371
17
21 3678 2507 3011 2136 2250 1740 1247 1247 899 899
23 3703 2846 3041 2478 2290 2086 1524 1524 1218 1218
25 3676 3181 3019 2812 2271 2271 1817 1817 1521 1521
27 3667 3510 3013 3144 2392 2392 2103 2103 1810 1810
29 3619 3619 2970 3469 2667 2667 2382 2382 2093 2093
31 3601 3601 3221 3904 2939 2939 2656 2656 2371 2371
19
21 4655 2510 4009 2150 3298 1770 2486 1381 1445 921
23 4630 2858 3988 2498 3281 2130 2477 1743 1439 1275
25 4609 3192 3973 2835 3270 2468 2469 2081 1439 1439
27 4585 3520 3950 3160 3251 2791 2456 2395 1810 1810
29 4560 3847 3929 3494 3234 3130 2443 2443 2093 2093
31 4541 4170 3916 3817 3226 3226 2656 2656 2371 2371
21
21 5592 2496 4957 2141 4265 1782 3500 1413 2611 1005
23 5620 2853 4991 2501 4305 2134 3548 1765 2681 1378
25 5592 3194 4966 2844 4284 2489 3531 2116 2669 1729
27 5556 3524 4934 3176 4256 2823 3506 2459 2650 2077
29 5588 3852 4970 3503 4298 3153 3555 2794 2707 2414
31 5480 4174 4864 3829 4196 3478 3455 3119 2607 2607
23
23 6627 2833 6003 2484 5329 2134 4592 1777 3776 1401
25 6659 3185 6039 2839 5369 2482 4640 2127 3831 1763
27 6311 3524 5694 3181 5025 2830 4294 2475 3480 2102
29 6619 3852 6007 3508 5346 3162 4624 2814 3827 2452
31 6523 4172 5915 3833 5257 3490 4539 3139 3744 2782
7
15
21 2424 2251 1449 1740 1385 1385 1011 1011 427 427
23 2410 2410 2006 2414 1700 1700 1385 1385 1022 1022
25 2594 2594 2299 2787 2001 2001 1696 1696 1381 1381
27 2875 2875 2584 3133 2291 2291 1995 1995 1693 1693
29 3151 3151 2864 3471 2575 2575 2284 2284 1989 1989
31 3423 3423 3138 3803 2852 2852 2565 2565 2276 2276
17
21 3344 2317 2563 1901 1504 1383 1011 1011 427 427
23 3374 2659 2603 2246 1566 1566 1385 1385 1022 1022
25 3351 2995 2582 2581 2001 2001 1696 1696 1381 1381
27 3344 3325 2582 2915 2291 2291 1995 1995 1693 1693
29 3298 3298 2864 3471 2575 2575 2284 2284 1989 1989
31 3281 3281 3138 3803 2852 2852 2565 2565 2276 2276
19
21 4369 2349 3657 1962 2826 1539 1708 1033 427 427
23 4349 2697 3640 2313 2815 1901 1702 1388 1022 1022
25 4332 3032 3625 2649 2807 2239 1702 1702 1381 1381
27 4309 3355 3606 2968 2792 2542 1995 1995 1693 1693
29 4286 3691 3589 3311 2779 2779 2284 2284 1989 1989
31 4273 4014 3580 3639 2775 2775 2565 2565 2276 2276
21
21 5335 2349 4653 1978 3886 1594 2988 1170 1751 650
23 5371 2709 4692 2340 3933 1949 3047 1539 1849 1026
25 5344 3052 4670 2688 3914 2306 3036 1889 1844 1388
27 5310 3384 4641 3020 3890 2642 3015 2235 1827 1733
29 5348 3714 4683 3350 3939 2977 3073 2574 1919 1919
31 5240 4035 4577 3675 3835 3300 2968 2897 2276 2276
23
23 6396 2702 5735 2343 5008 1976 4192 1594 3234 1172
25 6432 3057 5777 2700 5055 2326 4247 1946 3300 1532
27 6083 3394 5425 3036 4702 2670 3884 2288 2900 1857
29 6398 3723 5750 3371 5040 3011 4241 2638 3310 2235
31 6304 4048 5660 3696 4951 3336 4156 2963 3225 2562
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY FCLI 42 Qv [m3/h] k (Pc) k (Ps)
Speed V4 700 1 1
Speed V3 530 0,82 0,75
Speed V2 360 0,64 0,58
Speed V1 260 0,50 0,44

15
COOLING CAPACITY OUTPUT - FCLI 44
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 2867 2438 2291 2107 1655 2442 1234 1234 959 959
23 2850 2748 2277 2417 1767 1767 1499 1499 1229 1229
25 2837 2837 2270 2724 2025 2025 1758 1758 1492 1492
27 2796 2796 2540 3077 2277 2277 2014 2014 1751 1751
29 3050 3050 2789 3378 2528 2528 2267 2267 2005 2005
31 3294 3294 3034 3675 2775 2775 2515 2515 2256 2256
17
21 3609 2440 3041 2113 2427 1782 1744 1442 910 910
23 3628 2748 3066 2425 2455 2096 1777 1759 1229 1229
25 3602 3053 3041 2731 2435 2406 1762 1762 1492 1492
27 3590 3357 3034 3037 2430 2430 2014 2014 1751 1751
29 3544 3544 2992 3336 2528 2528 2267 2267 2005 2005
31 3525 3525 3034 3675 2775 2775 2515 2515 2256 2256
19
21 4486 2427 3925 2107 3320 1782 2662 1444 1931 1107
23 4462 2746 3903 2425 3302 2102 2648 1778 1920 1432
25 4441 3051 3885 2733 3288 2412 2637 2088 1915 1752
27 4416 3355 3863 3037 3269 2718 2622 2391 1903 1903
29 4429 3678 3840 3338 3250 3022 2608 2608 2005 2005
31 4409 3971 3826 3635 3240 3240 2601 2601 2256 2256
21
21 5336 2406 4777 2086 4178 1765 3529 1442 2820 1116
23 5400 2756 4805 2414 4209 2096 3565 1767 2862 1442
25 5370 3070 4780 2731 4187 2414 3546 2094 2848 1763
27 5336 3372 4747 3034 4159 2720 3522 2402 2827 2081
29 5360 3671 4777 3336 4192 3022 3560 2708 2871 2387
31 5259 3966 4679 3633 4098 3321 3468 3007 2782 2689
23
23 6316 2731 5724 2393 5130 2077 4491 1759 3798 1440
25 6342 3053 5753 2718 5163 2404 4530 2079 3842 1761
27 6021 3368 5436 3032 4850 2718 4218 2404 3532 2086
29 6262 3642 5719 3332 5137 3020 4509 2708 3830 2393
31 6173 3937 5633 3629 5054 3319 4430 3009 3755 2695
5
15
21 2616 2290 1964 1927 1408 1408 1126 1126 829 829
23 2602 2602 1953 2239 1680 1680 1405 1405 1123 1123
25 2594 2594 2213 2680 1944 1944 1675 1675 1401 1401
27 2733 2733 2468 2990 2204 2204 1938 1938 1668 1668
29 2982 2982 2721 3296 2458 2458 2195 2195 1929 1929
31 3229 3229 2968 3595 2709 2709 2448 2448 2185 2185
17
21 3389 2309 2775 1967 2073 1603 1149 1149 829 829
23 3412 2621 2803 2282 2110 1921 1405 1405 1123 1123
25 3388 2929 2782 2589 2092 2092 1675 1675 1401 1401
27 3379 3233 2777 2895 2204 2204 1938 1938 1668 1668
29 3335 3335 2737 3195 2458 2458 2195 2195 1929 1929
31 3318 3318 2968 3595 2709 2709 2448 2448 2185 2185
19
21 4289 2311 3694 1980 3039 1630 2291 1272 1332 848
23 4267 2632 3675 2301 3024 1961 2282 1605 1326 1175
25 4248 2940 3661 2611 3013 2273 2275 1917 1326 1326
27 4225 3241 3640 2910 2996 2571 2263 2206 1668 1668
29 4202 3543 3621 3218 2980 2883 2251 2251 1929 1929
31 4185 3840 3609 3515 2973 2973 2448 2448 2185 2185
21
21 5153 2298 4568 1972 3931 1641 3226 1301 2406 926
23 5179 2627 4599 2303 3967 1965 3269 1626 2470 1269
25 5153 2942 4577 2619 3948 2292 3254 1948 2460 1592
27 5120 3245 4547 2925 3922 2600 3231 2265 2442 1913
29 5149 3547 4580 3226 3960 2904 3276 2573 2495 2223
31 5050 3844 4483 3526 3866 3203 3184 2872 2402 2402
23
23 6107 2608 5532 2288 4911 1965 4232 1636 3480 1291
25 6136 2933 5565 2615 4947 2286 4275 1959 3530 1624
27 5816 3245 5247 2929 4631 2606 3957 2280 3207 1936
29 6100 3547 5536 3231 4926 2912 4261 2592 3527 2258
31 6011 3842 5450 3530 4845 3214 4183 2891 3450 2562
7
15
21 2233 2073 1335 1603 1276 1276 931 931 393 393
23 2221 2221 1849 2223 1567 1567 1276 1276 942 942
25 2390 2390 2119 2566 1844 1844 1563 1563 1273 1273
27 2649 2649 2381 2885 2112 2112 1838 1838 1560 1560
29 2904 2904 2639 3197 2373 2373 2105 2105 1833 1833
31 3154 3154 2891 3503 2629 2629 2364 2364 2098 2098
17
21 3081 2134 2362 1750 1386 1274 931 931 393 393
23 3109 2448 2399 2069 1443 1443 1276 1276 942 942
25 3088 2758 2380 2377 1844 1844 1563 1563 1273 1273
27 3081 3062 2380 2684 2112 2112 1838 1838 1560 1560
29 3039 3039 2639 3197 2373 2373 2105 2105 1833 1833
31 3024 3024 2891 3503 2629 2629 2364 2364 2098 2098
19
21 4026 2164 3370 1807 2604 1417 1574 951 393 393
23 4007 2484 3355 2130 2594 1750 1568 1278 942 942
25 3992 2792 3341 2440 2587 2062 1568 1568 1273 1273
27 3971 3089 3323 2733 2573 2341 1838 1838 1560 1560
29 3950 3399 3308 3049 2561 2561 2105 2105 1833 1833
31 3938 3697 3299 3351 2557 2557 2364 2364 2098 2098
21
21 4916 2164 4288 1822 3581 1468 2754 1078 1614 599
23 4949 2495 4324 2155 3624 1795 2808 1417 1704 945
25 4925 2811 4303 2476 3607 2123 2797 1740 1699 1278
27 4893 3117 4277 2781 3584 2433 2778 2058 1683 1596
29 4928 3420 4315 3085 3630 2741 2832 2370 1769 1769
31 4829 3716 4218 3384 3534 3039 2735 2668 2098 2098
23
23 5894 2488 5285 2157 4615 1820 3863 1468 2980 1080
25 5927 2815 5323 2486 4658 2142 3913 1792 3041 1411
27 5605 3125 5000 2796 4333 2459 3579 2107 2672 1710
29 5896 3429 5299 3104 4644 2773 3908 2429 3050 2058
31 5809 3728 5215 3403 4563 3072 3830 2729 2972 2360
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY FCLI 42 Qv [m3/h] k (Pc) k (Ps)
Speed V4 700 1 1
Speed V3 530 0,82 0,75
Speed V2 360 0,64 0,58
Speed V1 260 0,50 0,44

16
COOLING CAPACITY OUTPUT - FCLI 62
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 3923 3192 3134 2758 2265 3198 1689 1689 1312 1162
23 3899 3597 3115 3164 2417 2417 2051 2051 1681 1489
25 3882 3882 3106 3567 2770 2770 2405 2405 2041 1807
27 3825 3825 3475 4028 3115 3115 2756 2756 2396 2121
29 4173 4173 3815 4423 3458 3458 3101 3101 2744 2429
31 4506 4506 4151 4812 3796 3796 3441 3441 3087 2733
17
21 4937 3194 4161 2766 3320 2333 2386 1888 1246 1050
23 4963 3597 4194 3175 3358 2744 2432 2303 1681 1489
25 4928 3998 4161 3575 3332 3150 2410 2410 2041 1807
27 4911 4395 4151 3976 3325 3325 2756 2756 2396 2121
29 4849 4785 4094 4368 3458 3458 3101 3101 2744 2429
31 4823 4823 4151 4812 3796 3796 3441 3441 3087 2733
19
21 6137 3178 5371 2758 4542 2333 3642 1891 2641 1107
23 6104 3595 5340 3175 4518 2753 3622 2327 2627 1432
25 6076 3995 5316 3578 4499 3158 3608 2733 2620 1752
27 6042 4393 5285 3976 4473 3559 3587 3131 2603 2121
29 6059 4815 5254 4370 4447 3956 3568 3534 2744 2429
31 6033 5199 5235 4760 4432 4346 3558 3558 3087 2733
21
21 7300 3150 6535 2731 5716 2311 4828 1888 3858 1116
23 7388 3608 6573 3161 5759 2744 4878 2314 3915 1442
25 7347 4020 6540 3575 5728 3161 4851 2742 3896 1763
27 7300 4415 6495 3973 5690 3562 4818 3145 3868 2081
29 7333 4807 6535 4368 5735 3956 4870 3545 3927 2387
31 7195 5193 6402 4757 5606 4348 4744 3937 3806 2689
23
23 8641 3575 7831 3134 7019 2719 6145 2303 5197 1440
25 8676 3998 7871 3559 7064 3147 6197 2722 5256 1761
27 8238 4409 7438 3970 6635 3559 5771 3147 4832 2086
29 8567 4768 7824 4362 7028 3954 6168 3545 5240 2393
31 8445 5155 7707 4751 6914 4346 6061 3940 5137 2695
5
15
21 3580 2998 2686 2523 1927 1927 1541 1541 1134 1004
23 3561 3407 2672 2932 2298 2298 1922 1922 1536 1360
25 3549 3549 3027 3509 2660 2660 2291 2291 1917 1698
27 3739 3739 3377 3915 3015 3015 2651 2651 2282 2020
29 4080 4080 3722 4315 3363 3363 3003 3003 2639 2336
31 4418 4418 4061 4707 3706 3706 3349 3349 2989 2646
17
21 4637 3023 3796 2576 2837 2098 1572 1524 1134 1004
23 4668 3432 3834 2987 2887 2515 1922 1922 1536 1360
25 4635 3835 3806 3390 2863 2863 2291 2291 1917 1698
27 4623 4232 3799 3791 3015 3015 2651 2651 2282 2020
29 4563 4563 3744 4183 3363 3363 3003 3003 2639 2336
31 4539 4539 4061 4707 3706 3706 3349 3349 2989 2646
19
21 5868 3026 5054 2592 4158 2134 3134 1665 1822 848
23 5837 3446 5028 3012 4137 2568 3122 2101 1815 1175
25 5811 3849 5009 3418 4123 2976 3113 2510 1815 1497
27 5780 4243 4980 3810 4099 3366 3096 2888 2282 2020
29 5749 4638 4954 4213 4077 3774 3079 3079 2639 2336
31 5725 5028 4937 4602 4068 4068 3349 3349 2989 2646
21
21 7050 3009 6249 2581 5378 2148 4413 1703 3291 926
23 7085 3440 6292 3015 5428 2573 4473 2129 3380 1269
25 7050 3851 6261 3429 5402 3001 4451 2551 3365 1592
27 7004 4249 6221 3829 5366 3404 4420 2965 3341 1913
29 7045 4644 6266 4224 5418 3802 4482 3368 3413 2223
31 6909 5033 6133 4616 5290 4194 4356 3760 3287 2522
23
23 8355 3415 7569 2996 6719 2573 5790 2142 4761 1291
25 8395 3840 7614 3423 6769 2993 5849 2565 4830 1624
27 7957 4249 7178 3835 6335 3412 5413 2985 4387 1936
29 8345 4644 7574 4230 6740 3813 5830 3393 4825 2258
31 8224 5030 7457 4622 6628 4208 5723 3785 4720 2562
7
15
21 3056 2714 1827 2098 1746 1746 1274 1274 538 477
23 3039 3039 2529 2910 2143 2143 1746 1746 1288 1141
25 3270 3270 2898 3360 2522 2522 2139 2139 1741 1541
27 3625 3625 3258 3777 2889 2889 2515 2515 2134 1889
29 3973 3973 3611 4185 3246 3246 2879 2879 2508 2220
31 4316 4316 3956 4586 3596 3596 3234 3234 2870 2541
17
21 4215 2794 3232 2292 1896 1668 1274 1274 538 477
23 4254 3205 3282 2708 1974 1974 1746 1746 1288 1141
25 4225 3611 3256 3112 2522 2522 2139 2139 1741 1541
27 4215 4009 3256 3515 2889 2889 2515 2515 2134 1889
29 4158 4158 3611 4185 3246 3246 2879 2879 2508 2220
31 4137 4137 3956 4586 3596 3596 3234 3234 2870 2541
19
21 5509 2833 4611 2366 3563 1855 2153 1245 538 468
23 5483 3252 4589 2788 3549 2292 2146 1673 1288 1023
25 5461 3655 4570 3194 3539 2700 2146 2096 1741 1493
27 5433 4045 4547 3578 3520 3065 2515 2515 2134 1889
29 5404 4451 4525 3992 3503 3503 2879 2879 2508 2220
31 5387 4840 4513 4387 3499 3499 3234 3234 2870 2541
21
21 6726 2833 5866 2385 4899 1922 3768 1411 2208 599
23 6771 3266 5916 2822 4959 2350 3842 1855 2332 945
25 6738 3680 5887 3241 4935 2780 3827 2278 2324 1278
27 6695 4081 5852 3642 4904 3186 3801 2695 2303 1596
29 6742 4478 5904 4039 4966 3589 3875 3103 2420 1921
31 6607 4865 5771 4431 4835 3978 3742 3493 2870 2436
23
23 8064 3258 7231 2824 6314 2383 5285 1922 4077 1080
25 8109 3686 7283 3255 6373 2805 5354 2347 4161 1411
27 7669 4092 6840 3661 5928 3219 4897 2758 3656 1710
29 8067 4489 7250 4064 6354 3631 5347 3181 4173 2058
31 7948 4881 7135 4456 6242 4023 5240 3573 4065 2360
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY FCLI 62 Qv [m3/h] k (Pc) k (Ps)
Speed V4 880 1 1
Speed V3 660 0,79 0,74
Speed V2 500 0,64 0,60
Speed V1 380 0,53 0,49

17
COOLING CAPACITY OUTPUT - FCLI 64
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 3631 2957 2901 2555 2097 2963 1563 1563 1215 1215
23 3609 3333 2884 2931 2238 2238 1898 1898 1557 1557
25 3594 3594 2875 3305 2564 2564 2227 2227 1889 1889
27 3541 3541 3217 3732 2884 2884 2551 2551 2218 2218
29 3863 3863 3532 4098 3201 3201 2871 2871 2540 2540
31 4171 4171 3843 4459 3514 3514 3186 3186 2857 2857
17
21 4570 2960 3852 2563 3073 2161 2209 1750 1153 1153
23 4595 3333 3882 2942 3109 2543 2251 2133 1557 1557
25 4561 3704 3852 3313 3084 2919 2231 2231 1889 1889
27 4546 4072 3843 3683 3078 3078 2551 2551 2218 2218
29 4489 4433 3790 4047 3201 3201 2871 2871 2540 2540
31 4464 4464 3843 4459 3514 3514 3186 3186 2857 2857
19
21 5681 2944 4972 2555 4204 2161 3371 1752 2445 1343
23 5651 3330 4943 2942 4182 2550 3353 2156 2432 1737
25 5624 3701 4921 3315 4165 2926 3340 2532 2425 2126
27 5593 4070 4892 3683 4140 3297 3320 2901 2410 2410
29 5609 4461 4864 4049 4116 3666 3303 3274 2540 2540
31 5584 4817 4846 4410 4103 4026 3294 3294 2857 2857
21
21 6757 2919 6050 2530 5291 2141 4469 1750 3572 1353
23 6839 3343 6085 2929 5331 2543 4515 2144 3625 1750
25 6801 3724 6054 3313 5302 2929 4491 2540 3607 2138
27 6757 4090 6012 3681 5267 3300 4460 2914 3580 2525
29 6788 4453 6050 4047 5309 3666 4509 3284 3636 2896
31 6660 4812 5926 4407 5190 4029 4392 3648 3523 3261
23
23 7999 3313 7249 2903 6497 2520 5688 2133 4811 1747
25 8032 3704 7286 3297 6539 2916 5737 2522 4866 2136
27 7626 4085 6885 3678 6142 3297 5342 2916 4473 2530
29 7930 4418 7242 4042 6506 3663 5710 3284 4850 2903
31 7818 4776 7134 4402 6400 4026 5611 3650 4756 3269
5
15
21 3314 2778 2487 2338 1784 1784 1426 1426 1049 1049
23 3296 3157 2474 2717 2128 2128 1779 1779 1422 1422
25 3285 3285 2802 3251 2463 2463 2121 2121 1775 1775
27 3461 3461 3126 3627 2791 2791 2454 2454 2112 2112
29 3777 3777 3446 3998 3113 3113 2780 2780 2443 2443
31 4090 4090 3759 4361 3430 3430 3100 3100 2767 2767
17
21 4293 2801 3514 2387 2626 1944 1455 1412 1049 1049
23 4321 3180 3550 2768 2672 2330 1779 1779 1422 1422
25 4290 3553 3523 3141 2650 2650 2121 2121 1775 1775
27 4279 3921 3516 3512 2791 2791 2454 2454 2112 2112
29 4224 4224 3466 3875 3113 3113 2780 2780 2443 2443
31 4202 4202 3759 4361 3430 3430 3100 3100 2767 2767
19
21 5432 2804 4678 2402 3849 1977 2901 1542 1687 1028
23 5404 3192 4654 2791 3830 2379 2890 1947 1680 1425
25 5379 3566 4636 3167 3816 2757 2882 2325 1680 1680
27 5351 3932 4610 3530 3794 3118 2866 2676 2112 2112
29 5322 4297 4586 3903 3774 3497 2851 2851 2443 2443
31 5300 4658 4570 4264 3766 3766 3100 3100 2767 2767
21
21 6526 2788 5785 2392 4978 1990 4085 1578 3047 1123
23 6559 3187 5825 2793 5024 2384 4140 1972 3128 1540
25 6526 3568 5796 3177 5000 2781 4121 2364 3115 1931
27 6484 3937 5759 3548 4967 3154 4092 2747 3093 2320
29 6521 4303 5801 3914 5016 3522 4149 3121 3159 2696
31 6396 4663 5677 4277 4897 3886 4032 3484 3042 3042
23
23 7734 3164 7006 2775 6219 2384 5360 1985 4407 1565
25 7772 3558 7048 3172 6266 2773 5415 2376 4471 1970
27 7366 3937 6645 3553 5864 3162 5011 2765 4061 2348
29 7725 4303 7011 3919 6239 3533 5397 3144 4467 2740
31 7613 4661 6903 4282 6136 3898 5298 3507 4370 3108
7
15
21 2829 2514 1691 1944 1616 1616 1180 1180 498 498
23 2813 2813 2341 2696 1984 1984 1616 1616 1193 1193
25 3027 3027 2683 3113 2335 2335 1980 1980 1612 1612
27 3356 3356 3016 3499 2674 2674 2328 2328 1975 1975
29 3677 3677 3342 3878 3005 3005 2665 2665 2322 2322
31 3995 3995 3662 4249 3329 3329 2994 2994 2657 2657
17
21 3902 2589 2992 2123 1755 1545 1180 1180 498 498
23 3938 2970 3038 2509 1828 1828 1616 1616 1193 1193
25 3911 3346 3014 2883 2335 2335 1980 1980 1612 1612
27 3902 3714 3014 3256 2674 2674 2328 2328 1975 1975
29 3849 3849 3342 3878 3005 3005 2665 2665 2322 2322
31 3830 3830 3662 4249 3329 3329 2994 2994 2657 2657
19
21 5099 2624 4268 2192 3298 1719 1993 1154 498 498
23 5075 3013 4248 2584 3285 2123 1986 1550 1193 1193
25 5055 3387 4231 2960 3276 2502 1986 1942 1612 1612
27 5029 3747 4209 3315 3259 2839 2328 2328 1975 1975
29 5002 4123 4189 3699 3243 3243 2665 2665 2322 2322
31 4987 4484 4178 4065 3239 3239 2994 2994 2657 2657
21
21 6226 2624 5430 2210 4535 1780 3488 1307 2044 726
23 6268 3026 5476 2614 4590 2177 3556 1719 2158 1146
25 6237 3410 5450 3003 4568 2576 3543 2110 2152 1550
27 6197 3781 5417 3374 4539 2952 3519 2497 2132 1936
29 6241 4149 5465 3742 4597 3325 3587 2875 2240 2240
31 6116 4507 5342 4106 4476 3686 3464 3236 2657 2657
23
23 7465 3018 6693 2617 5845 2208 4892 1780 3774 1310
25 7507 3415 6742 3016 5900 2599 4956 2174 3852 1711
27 7099 3791 6332 3392 5487 2983 4533 2555 3384 2075
29 7467 4159 6711 3765 5882 3364 4950 2947 3863 2497
31 7357 4522 6605 4129 5778 3727 4850 3310 3763 2862
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY FCLI 64 Qv [m3/h] k (Pc) k (Ps)
Speed V4 700 1 1
Speed V3 530 0,82 0,75
Speed V2 360 0,64 0,58
Speed V1 260 0,50 0,43

18
COOLING CAPACITY OUTPUT - FCLI 82
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 4726 3518 3776 3040 2729 3525 2034 2034 1581 1581
23 4697 3966 3753 3488 2912 2912 2471 2471 2026 2026
25 4677 4407 3742 3932 3337 3337 2898 2898 2459 2459
27 4608 4608 4187 4440 3753 3753 3320 3320 2887 2887
29 5027 5027 4597 4876 4166 4166 3736 3736 3306 3306
31 5429 5429 5001 5305 4574 4574 4146 4146 3719 3719
17
21 5948 3521 5013 3050 4000 2572 2875 2082 1501 1501
23 5980 3966 5053 3500 4046 3025 2930 2538 2026 2026
25 5937 4407 5013 3941 4014 3473 2904 2904 2459 2459
27 5917 4845 5001 4383 4006 3914 3320 3320 2887 2887
29 5842 5274 4933 4815 4166 4166 3736 3736 3306 3306
31 5811 5700 5001 5305 4574 4574 4146 4146 3719 3719
19
21 7395 3503 6471 3040 5472 2572 4387 2085 3182 1598
23 7354 3963 6433 3500 5443 3034 4364 2566 3165 2067
25 7320 4404 6405 3944 5420 3482 4347 3013 3156 2529
27 7280 4842 6367 4383 5389 3923 4321 3451 3136 3062
29 7300 5308 6330 4818 5357 4361 4298 3896 3306 3306
31 7268 5731 6307 5247 5340 4790 4287 4287 3719 3719
21
21 8795 3473 7874 3010 6887 2547 5816 2082 4648 1610
23 8901 3978 7920 3485 6938 3025 5877 2550 4717 2082
25 8852 4431 7879 3941 6901 3485 5845 3022 4694 2544
27 8795 4867 7825 4380 6855 3926 5805 3467 4660 3004
29 8835 5299 7874 4815 6910 4361 5868 3908 4732 3445
31 8669 5725 7713 5244 6755 4793 5716 4340 4585 3880
23
23 10410 3941 9435 3454 8456 2998 7403 2538 6261 2079
25 10453 4407 9484 3923 8511 3470 7466 3001 6333 2541
27 9925 4860 8961 4377 7994 3923 6953 3470 5822 3010
29 10321 5256 9426 4809 8468 4358 7432 3908 6313 3454
31 10175 5682 9286 5238 8330 4790 7303 4343 6189 3890
5
15
21 4313 3305 3237 2782 2321 2321 1857 1857 1366 1366
23 4290 3756 3220 3232 2769 2769 2316 2316 1851 1851
25 4275 4197 3647 3868 3205 3205 2760 2760 2310 2310
27 4505 4505 4069 4316 3633 3633 3194 3194 2749 2749
29 4915 4915 4485 4757 4052 4052 3618 3618 3179 3179
31 5323 5323 4892 5189 4465 4465 4034 4034 3601 3601
17
21 5587 3333 4574 2840 3418 2313 1894 1680 1366 1366
23 5624 3783 4620 3293 3478 2773 2316 2310 1851 1851
25 5584 4227 4585 3737 3449 3220 2760 2760 2310 2310
27 5570 4666 4577 4179 3633 3633 3194 3194 2749 2749
29 5498 5098 4511 4611 4052 4052 3618 3618 3179 3179
31 5469 5469 4892 5189 4465 4465 4034 4034 3601 3601
19
21 7070 3336 6089 2858 5010 2353 3776 1835 2195 1223
23 7033 3798 6057 3320 4984 2830 3762 2316 2187 1695
25 7001 4243 6034 3768 4967 3281 3750 2767 2187 2161
27 6964 4678 6000 4200 4938 3710 3730 3183 2749 2749
29 6927 5113 5968 4644 4912 4160 3710 3652 3179 3179
31 6898 5542 5948 5073 4901 4596 4034 4034 3601 3601
21
21 8494 3317 7529 2846 6479 2368 5317 1878 3966 1336
23 8537 3792 7581 3323 6539 2837 5389 2347 4072 1832
25 8494 4246 7544 3780 6508 3308 5363 2812 4055 2298
27 8439 4684 7495 4221 6465 3753 5326 3269 4026 2760
29 8488 5119 7549 4657 6528 4191 5400 3713 4112 3208
31 8324 5548 7389 5089 6373 4623 5248 4145 3960 3640
23
23 10066 3765 9119 3302 8095 2837 6976 2362 5736 1863
25 10115 4233 9174 3774 8155 3299 7047 2827 5819 2343
27 9587 4684 8648 4227 7633 3762 6522 3290 5286 2794
29 10055 5119 9125 4663 8121 4203 7024 3740 5813 3260
31 9908 5545 8984 5095 7986 4638 6895 4173 5687 3698
7
15
21 3681 2992 2201 2313 2103 2103 1535 1535 648 648
23 3661 3442 3047 3208 2582 2582 2103 2103 1552 1552
25 3940 3940 3492 3704 3039 3039 2577 2577 2098 2098
27 4367 4367 3925 4163 3481 3481 3030 3030 2571 2571
29 4786 4786 4350 4614 3911 3911 3469 3469 3022 3022
31 5199 5199 4766 5055 4333 4333 3897 3897 3458 3458
17
21 5079 3080 3894 2526 2284 1838 1535 1535 648 648
23 5125 3533 3954 2986 2379 2310 2103 2103 1552 1552
25 5090 3981 3923 3430 3039 3039 2577 2577 2098 2098
27 5079 4419 3923 3874 3481 3481 3030 3030 2571 2571
29 5010 4854 4350 4614 3911 3911 3469 3469 3022 3022
31 4984 4984 4766 5055 4333 4333 3897 3897 3458 3458
19
21 6637 3123 5555 2608 4293 2045 2594 1373 648 648
23 6605 3585 5529 3074 4275 2526 2585 1844 1552 1476
25 6580 4030 5506 3521 4264 2977 2585 2310 2098 2098
27 6545 4459 5478 3944 4241 3378 3030 3030 2571 2571
29 6511 4906 5452 4401 4221 3862 3469 3469 3022 3022
31 6491 5335 5438 4836 4215 4215 3897 3897 3458 3458
21
21 8103 3123 7067 2630 5902 2118 4539 1555 2660 864
23 8158 3600 7128 3110 5974 2590 4628 2045 2809 1363
25 8118 4057 7093 3573 5945 3065 4611 2511 2801 1844
27 8066 4498 7050 4014 5908 3512 4580 2970 2775 2304
29 8123 4937 7113 4453 5983 3957 4669 3421 2915 2773
31 7960 5363 6953 4885 5825 4386 4508 3850 3458 3458
23
23 9716 3591 8712 3113 7607 2627 6367 2118 4912 1558
25 9770 4063 8775 3588 7679 3092 6451 2587 5013 2036
27 9240 4510 8241 4036 7142 3549 5900 3040 4405 2468
29 9719 4949 8735 4480 7656 4002 6442 3506 5027 2970
31 9575 5381 8597 4912 7521 4434 6313 3938 4898 3406
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY FCLI 82 Qv [m3/h] k (Pc) k (Ps)
Speed V4 1100 1 1
Speed V3 830 0,80 0,79
Speed V2 680 0,68 0,66
Speed V1 460 0,47 0,45

19
COOLING CAPACITY OUTPUT - FCLI 122
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 8664 7095 6923 6132 5003 7109 3730 3730 2899 2899
23 8612 7997 6881 7034 5340 5340 4529 4529 3714 3714
25 8575 8575 6860 7930 6118 6118 5313 5313 4508 4508
27 8449 8449 7675 8955 6881 6881 6087 6087 5292 5292
29 9217 9217 8428 9833 7638 7638 6849 6849 6060 6060
31 9953 9953 9169 10698 8385 8385 7602 7602 6818 6818
17
21 10905 7101 9190 6150 7333 5186 5271 4198 2751 2751
23 10963 7997 9264 7058 7418 6101 5371 5119 3714 3714
25 10884 8887 9190 7948 7360 7003 5324 5324 4508 4508
27 10847 9771 9169 8838 7344 7344 6087 6087 5292 5292
29 10711 10637 9043 9710 7638 7638 6849 6849 6060 6060
31 10653 10653 9169 10698 8385 8385 7602 7602 6818 6818
19
21 13557 7064 11863 6132 10032 5186 8044 4204 5834 3222
23 13483 7991 11794 7058 9979 6119 8001 5174 5802 4167
25 13420 8881 11742 7954 9937 7022 7970 6076 5787 5100
27 13346 9765 11673 8838 9879 7911 7923 6960 5750 5750
29 13383 10704 11605 9716 9822 8795 7880 7856 6060 6060
31 13325 11557 11563 10581 9790 9661 7859 7859 6818 6818
21
21 16124 7003 14435 6070 12626 5137 10663 4198 8522 3247
23 16319 8022 14519 7028 12720 6101 10774 5143 8648 4198
25 16229 8936 14446 7948 12652 7028 10716 6095 8606 5131
27 16124 9814 14346 8832 12568 7918 10642 6991 8543 6058
29 16198 10686 14435 9710 12668 8795 10758 7881 8675 6948
31 15892 11545 14141 10575 12384 9667 10479 8752 8407 7826
23
23 19086 7948 17297 6966 15503 6046 13572 5119 11479 4192
25 19165 8887 17386 7911 15603 6997 13688 6052 11610 5125
27 18197 9802 16429 8826 14656 7911 12747 6997 10674 6070
29 18923 10600 17281 9698 15524 8789 13625 7881 11573 6966
31 18654 11459 17023 10563 15272 9661 13388 8758 11347 7844
5
15
21 7907 6666 5934 5610 4256 4256 3404 3404 2504 2504
23 7865 7574 5902 6518 5077 5077 4245 4245 3393 3393
25 7838 7838 6686 7801 5876 5876 5061 5061 4235 4235
27 8259 8259 7460 8703 6660 6660 5855 5855 5040 5040
29 9011 9011 8222 9593 7428 7428 6634 6634 5829 5829
31 9758 9758 8969 10465 8186 8186 7396 7396 6602 6602
17
21 10242 6721 8385 5726 6265 4665 3472 3388 2504 2504
23 10311 7629 8470 6641 6376 5591 4245 4245 3393 3393
25 10237 8525 8407 7537 6323 6323 5061 5061 4235 4235
27 10211 9409 8391 8427 6660 6660 5855 5855 5040 5040
29 10079 10079 8270 9299 7428 7428 6634 6634 5829 5829
31 10027 10027 8969 10465 8186 8186 7396 7396 6602 6602
19
21 12962 6727 11163 5763 9185 4744 6923 3701 4024 2467
23 12894 7660 11105 6696 9138 5708 6897 4671 4009 3419
25 12836 8556 11063 7598 9106 6616 6876 5579 4009 4009
27 12768 9434 11000 8470 9054 7482 6839 6420 5040 5040
29 12699 10311 10942 9366 9006 8390 6802 6802 5829 5829
31 12647 11177 10905 10232 8985 8985 7396 7396 6602 6602
21
21 15571 6690 13804 5739 11879 4775 9748 3787 7270 2694
23 15650 7648 13899 6702 11989 5720 9879 4732 7465 3695
25 15571 8562 13830 7623 11931 6672 9832 5671 7433 4634
27 15472 9446 13741 8513 11852 7568 9764 6592 7381 5567
29 15561 10324 13841 9391 11968 8452 9901 7488 7538 6469
31 15261 11189 13546 10262 11684 9323 9622 8360 7260 7260
23
23 18454 7592 16718 6659 14840 5720 12789 4763 10516 3756
25 18544 8538 16818 7611 14951 6653 12920 5702 10669 4726
27 17576 9446 15856 8525 13993 7586 11957 6635 9690 5634
29 18433 10324 16729 9403 14888 8476 12878 7543 10658 6573
31 18165 11183 16471 10274 14640 9354 12641 8415 10427 7457
7
15
21 6749 6033 4035 4665 3856 3856 2814 2814 1189 1189
23 6713 6713 5587 6469 4735 4735 3856 3856 2846 2846
25 7223 7223 6402 7470 5571 5571 4724 4724 3846 3846
27 8007 8007 7197 8396 6381 6381 5555 5555 4714 4714
29 8775 8775 7975 9305 7170 7170 6360 6360 5539 5539
31 9532 9532 8738 10195 7944 7944 7144 7144 6339 6339
17
21 9311 6211 7139 5094 4187 3707 2814 2814 1189 1189
23 9396 7126 7249 6021 4361 4361 3856 3856 2846 2846
25 9332 8028 7191 6917 5571 5571 4724 4724 3846 3846
27 9311 8912 7191 7813 6381 6381 5555 5555 4714 4714
29 9185 9185 7975 9305 7170 7170 6360 6360 5539 5539
31 9138 9138 8738 10195 7944 7944 7144 7144 6339 6339
19
21 12168 6297 10185 5260 7870 4125 4756 2768 1189 1189
23 12110 7230 10137 6199 7838 5094 4740 3719 2846 2846
25 12063 8126 10095 7101 7817 6003 4740 4659 3846 3846
27 12000 8992 10043 7954 7775 6813 5555 5555 4714 4714
29 11936 9894 9995 8875 7738 7738 6360 6360 5539 5539
31 11900 10759 9969 9753 7728 7728 7144 7144 6339 6339
21
21 14856 6297 12957 5303 10821 4272 8322 3136 4877 1743
23 14956 7261 13067 6273 10953 5223 8485 4125 5150 2750
25 14882 8182 13004 7206 10900 6181 8454 5064 5134 3719
27 14788 9071 12925 8096 10832 7083 8396 5990 5087 4646
29 14893 9955 13041 8979 10968 7979 8559 6899 5345 5345
31 14593 10815 12747 9851 10679 8844 8264 7764 6339 6339
23
23 17813 7242 15971 6279 13946 5297 11673 4272 9006 3142
25 17912 8194 16087 7236 14077 6236 11826 5217 9190 4106
27 16939 9096 15109 8139 13094 7157 10816 6132 8075 4978
29 17818 9980 16013 9035 14035 8071 11810 7071 9217 5990
31 17555 10851 15761 9906 13788 8943 11573 7942 8980 6868
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY FCLI 122 Qv [m3/h] k (Pc) k (Ps)
Speed V4 1750 1 1
Speed V3 1350 0,81 0,81
Speed V2 1100 0,68 0,68
Speed V1 750 0,49 0,48

20
Tw [°C] = Inlet water temperature
Ta W.B. [°C] = Inlet air temperature with wet bulb
Ta D.B. [°C] = Inlet air temperature with dry bulb
Pc [W] = Total cooling capacity
Ps [W] = Sensitive cooling capacity
NB: The values marked in bold indicate the nominal value.
Sensitive cooling capacity values greater than the total power indicate
that cooling occurs without dehumidification.
In this case take into account the sensitive power values only.
The cooling yields in the table refer to maximum speed (maximum air
flow rate).
To determine the cooling capacity output according to speed (air flow
rate), the values stated in the table must be multiplied by the following
factors (k):
CORRECTIVE FACTORS FOR YIELD COOLING CAPACITY FCLI 124 Qv [m3/h] k (Pc) k (Ps)
Speed V4 1750 1 1
Speed V3 1350 0,83 0,82
Speed V2 1100 0,71 0,69
Speed V1 750 0,52 0,50
Dt Tbu Tbs Pc Ps Pc Ps Pc Ps Pc Ps Pc Ps
[°C] [°C] [°C] Tw(in) = 5°C Tw(in) = 7°C Tw(in) = 9°C Tw(in) = 11°C Tw(in) = 13°C
3
15
21 6931 3384 5538 2925 4002 3391 2984 2076 2319 1613
23 6889 3815 5505 3355 4272 2971 3624 2521 2971 2067
25 6860 4239 5488 3782 4895 3405 4251 2957 3607 2509
27 6759 4658 6140 4271 5505 3829 4869 3387 4234 2945
29 7373 5129 6742 4690 6111 4251 5479 3812 4848 3373
31 7963 5539 7335 5103 6708 4666 6081 4230 5454 3794
17
21 8724 3387 7352 2933 5867 2474 4217 2002 2201 1458
23 8771 3815 7411 3367 5934 2910 4297 2442 2971 2067
25 8707 4239 7352 3791 5888 3340 4259 2872 3607 2509
27 8678 4661 7335 4216 5875 3765 4869 3387 4234 2945
29 8569 5073 7234 4631 6111 4251 5479 3812 4848 3373
31 8522 5483 7335 5103 6708 4666 6081 4230 5454 3794
19
21 10845 3370 9490 2925 8026 2474 6435 2005 4667 1537
23 10786 3812 9435 3367 7984 2919 6401 2468 4642 1988
25 10736 4236 9393 3794 7950 3349 6376 2898 4629 2433
27 10677 4658 9339 4216 7904 3774 6338 3320 4600 2945
29 10706 5106 9284 4634 7857 4195 6304 3747 4848 3373
31 10660 5513 9250 5047 7832 4608 6288 4166 5454 3794
21
21 12899 3340 11548 2895 10100 2450 8531 2002 6818 1549
23 13055 3826 11615 3352 10176 2910 8619 2453 6919 2002
25 12983 4262 11557 3791 10121 3352 8573 2907 6885 2447
27 12899 4681 11477 4213 10054 3777 8514 3334 6835 2889
29 12958 5097 11548 4631 10134 4195 8606 3759 6940 3314
31 12714 5507 11312 5044 9907 4611 8383 4175 6725 3733
23
23 15268 3791 13838 3323 12402 2884 10858 2442 9183 2000
25 15332 4239 13909 3774 12482 3337 10951 2887 9288 2444
27 14557 4675 13143 4210 11725 3774 10197 3337 8539 2895
29 15138 5056 13825 4626 12419 4192 10900 3759 9259 3323
31 14923 5466 13619 5038 12217 4608 10711 4178 9078 3741
5
15
21 6325 3179 4747 2676 3405 2313 2723 1894 2003 1394
23 6292 3613 4722 3109 4061 2825 3396 2363 2714 1888
25 6271 4037 5349 3721 4701 3270 4049 2816 3388 2357
27 6607 4596 5968 4151 5328 3706 4684 3258 4032 2805
29 7209 5015 6578 4576 5942 4134 5307 3692 4663 3244
31 7807 5431 7176 4991 6548 4555 5917 4116 5282 3674
17
21 8194 3206 6708 2731 5012 2225 2778 1616 2003 1394
23 8249 3639 6776 3168 5101 2667 3396 2222 2714 1888
25 8190 4066 6725 3595 5059 3097 4049 2816 3388 2357
27 8169 4488 6713 4020 5328 3671 4684 3258 4032 2805
29 8064 4904 6616 4435 5942 4134 5307 3692 4663 3244
31 8021 5313 7176 4991 6548 4555 5917 4116 5282 3674
19
21 10370 3209 8930 2749 7348 2263 5538 1765 3220 1177
23 10315 3654 8884 3194 7310 2723 5517 2228 3207 1631
25 10269 4081 8851 3624 7285 3156 5501 2661 3207 2079
27 10214 4500 8800 4040 7243 3569 5471 3062 4032 2805
29 10159 4918 8754 4467 7205 4002 5442 3513 4663 3244
31 10117 5331 8724 4880 7188 4421 5917 4116 5282 3674
21
21 12457 3191 11043 2737 9503 2278 7798 1806 5816 1285
23 12520 3648 11119 3197 9591 2728 7904 2257 5972 1762
25 12457 4084 11064 3636 9545 3182 7866 2705 5947 2210
27 12377 4505 10993 4060 9482 3610 7811 3144 5905 2655
29 12449 4924 11073 4479 9574 4031 7920 3572 6031 3086
31 12209 5337 10837 4895 9347 4447 7697 3987 5808 3501
23
23 14763 3621 13375 3176 11872 2728 10231 2272 8413 1792
25 14835 4072 13455 3630 11961 3173 10336 2720 8535 2254
27 14061 4505 12684 4066 11195 3618 9566 3165 7752 2687
29 14747 4924 13383 4485 11910 4043 10302 3598 8526 3135
31 14532 5334 13177 4901 11712 4462 10113 4014 8341 3557
7
15
21 5400 2878 3228 2225 3085 2146 2252 1566 951 662
23 5370 3311 4469 3086 3788 2635 3085 2146 2277 1584
25 5778 3949 5122 3563 4457 3100 3779 2629 3076 2140
27 6405 4456 5757 4005 5105 3551 4444 3091 3771 2623
29 7020 4883 6380 4438 5736 3990 5088 3539 4432 3083
31 7626 5305 6990 4863 6355 4421 5715 3976 5071 3528
17
21 7449 2963 5711 2430 3350 1768 2252 1484 951 662
23 7516 3399 5799 2872 3489 2222 3085 2146 2277 1584
25 7466 3829 5753 3299 4457 2974 3779 2629 3076 2140
27 7449 4251 5753 3727 5105 3551 4444 3091 3771 2623
29 7348 4669 6380 4438 5736 3990 5088 3539 4432 3083
31 7310 5085 6990 4863 6355 4421 5715 3976 5071 3528
19
21 9734 3004 8148 2509 6296 1967 3804 1320 951 650
23 9688 3449 8110 2957 6271 2430 3792 1774 2277 1420
25 9650 3876 8076 3387 6254 2863 3792 2222 3076 2073
27 9600 4289 8034 3794 6220 3250 4444 3033 3771 2623
29 9549 4719 7996 4233 6191 3715 5088 3484 4432 3083
31 9520 5132 7975 4652 6182 4137 5715 3976 5071 3528
21
21 11885 3004 10366 2529 8657 2038 6658 1496 3901 831
23 11965 3463 10454 2992 8762 2491 6788 1967 4120 1312
25 11906 3902 10403 3437 8720 2948 6763 2415 4108 1774
27 11830 4327 10340 3861 8665 3378 6717 2857 4070 2216
29 11914 4748 10433 4283 8775 3806 6847 3291 4276 2667
31 11674 5158 10197 4699 8543 4219 6612 3703 5071 3381
23
23 14250 3454 12777 2995 11157 2526 9339 2038 7205 1499
25 14330 3908 12870 3452 11262 2974 9461 2488 7352 1959
27 13551 4339 12087 3882 10475 3414 8653 2925 6460 2374
29 14254 4760 12811 4309 11228 3850 9448 3373 7373 2857
31 14044 5176 12609 4725 11031 4265 9259 3788 7184 3276
COOLING CAPACITY OUTPUT - FCLI 124

21
HEATING CAPACITY OUTPUT 2-PIPE SYSTEM CONFIGURATION Room air 20°C D.B.; WATER IN/OUT 70°C/60°C;
FCLI32
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
54485 4291 4100 3911 3726
10 4383 5079 4000 3812 3623
15 4263 4069 3877 3686 3500
65
54060 3869 3680 3492 3309
10 3951 3763 3575 3386 3201
15 3823 3632 3440 3252 3066
60
53766 3575 3380 3192 3004
10 3520 3332 3146 2961 2778
15 3380 3192 3004 2815 2630
50
52781 2595 2413 2233 2056
10 2652 2467 2281 2099 1916
15 2484 2293 2101 1910 1719
45
52353 2170 1990 1810 1633
10 2210 2027 1842 1659 1473
15 2019 1824 1627 1425 1219
40
51921 1742 1565 1385 1211
10 1764 1576 1390 1202 1008
15 1530 1322 1071 697 400
FCLI42
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5 8231 7874 7523 7178 6837
10 8042 9320 7340 6994 6648
15 7822 7466 7115 6764 6423
65
5 7450 7099 6753 6407 6072
10 7251 6905 6559 6214 5873
15 7015 6664 6313 5967 5627
60
5 6910 6559 6203 5857 5512
10 6460 6114 5774 5433 5098
15 6203 5857 5512 5166 4825
50
5 5103 4762 4427 4097 3772
10 4867 4527 4186 3851 3515
15 4558 4207 3856 3505 3154
45
5 4317 3982 3652 3322 2997
10 4055 3720 3379 3044 2703
15 3704 3348 2986 2614 2237
40
5 3526 3196 2871 2541 2221
10 3238 2892 2551 2206 1849
15 2808 2426 1965 1278 733
FCLI62
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5 1176 1125 1075 1026 977
10 1149 1332 1049 1000 950
15 1118 1067 1017 967 918
65
5 1065 1015 965 916 868
10 1036 987 937 888 839
15 1003 952 902 853 804
60
5 988 937 887 837 788
10 923 874 825 776 729
15 887 837 788 738 690
50
5 729 681 633 586 539
10 696 647 598 550 502
15 651 601 551 501 451
45
5 617 569 522 475 428
10 580 532 483 435 386
15 529 478 427 374 320
40
5 504 457 410 363 317
10 463 413 365 315 264
15 401 347 281 183 105
FCLI122
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5 24389 23334 22293 21269 20260
10 23830 27618 21750 20725 19701
15 23178 22123 21082 20042 19033
65
5 22076 21036 20011 18987 17993
10 21486 20461 19437 18412 17403
15 20787 19747 18707 17683 16673
60
5 20477 19437 18381 17357 16332
10 19142 18117 17108 16099 15105
15 18381 17357 16332 15307 14298
50
5 15121 14112 13118 12140 11178
10 14422 13413 12404 11411 10417
15 13506 12466 11426 10386 9346
45
5 12792 11799 10821 9843 8880
10 12016 11022 10013 9020 8011
15 10976 9920 8849 7747 6629
40
5 10448 9470 8507 7529 6582
10 9594 8570 7560 6536 5480
15 8321 7188 5822 3788 2173
FCLI82
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5 13322 12745 12177 11617 11066
10 13016 15085 11880 11320 10761
15 12660 12084 11515 10947 10396
65
5 12058 11490 10930 10371 9828
10 11736 11176 10617 10057 9506
15 11354 10786 10218 9658 9107
60
5 11185 10617 10040 9480 8921
10 10455 9896 9345 8793 8251
15 10040 9480 8921 8361 7810
50
5 8259 7708 7165 6631 6105
10 7878 7326 6775 6233 5690
15 7377 6809 6241 5673 5105
45
5 6987 6445 5910 5376 4850
10 6563 6021 5469 4927 4376
15 5995 5419 4833 4231 3621
40
5 5707 5173 4647 4113 3595
10 5240 4681 4130 3570 2993
15 4545 3926 3180 2069 1187

22
HEATING CAPACITY OUTPUT 4-PIPE SYSTEM CONFIGURATION 20°C d.b.; Water (in/out) 65°C/55°C; (EUROVENT)
FCLI34
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5 2915 2789 2665 2542 2422
10 2849 3301 2600 2478 2355
15 2771 2645 2520 2396 2275
65
5 2639 2515 2392 2270 2151
10 2568 2446 2323 2201 2080
15 2485 2361 2236 2114 1993
60
5 2448 2323 2197 2075 1952
10 2288 2166 2045 1924 1806
15 2197 2075 1952 1830 1709
50
5 1808 1687 1568 1451 1336
10 1724 1603 1483 1364 1245
15 1615 1490 1366 1242 1117
45
5 1529 1410 1294 1177 1062
10 1436 1318 1197 1078 958
15 1312 1186 1058 926 792
40
5 1249 1132 1017 900 787
10 1147 1024 904 781 655
15 995 859 696 453 260
FCLI44
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
WWWWW
70
5 3443 3294 3147 3002 2860
10 3364 3898 3070 2925 2781
15 3272 3123 2976 2829 2687
65
5 3116 2969 2825 2680 2540
10 3033 2888 2743 2599 2456
15 2934 2787 2641 2496 2353
60
5 2890 2743 2594 2450 2305
10 2702 2557 2415 2272 2132
15 2594 2450 2305 2161 2018
50
5 2134 1992 1852 1714 1578
10 2036 1893 1751 1611 1470
15 1906 1760 1613 1466 1319
45
5 1806 1665 1527 1389 1253
10 1696 1556 1413 1273 1131
15 1549 1400 1249 1093 936
40
5 1475 1337 1201 1063 929
10 1354 1210 1067 923 774
15 1175 1015 822 535 307
FCLI64
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
W W W W W
70
5 4003 3830 3659 3491 3325
10 3911 4533 3570 3402 3234
15 3804 3631 3460 3290 3124
65
5 3624 3453 3285 3116 2953
10 3527 3359 3190 3022 2857
15 3412 3241 3071 2902 2737
60
5 3361 3190 3017 2849 2681
10 3142 2974 2808 2642 2479
15 3017 2849 2681 2513 2347
50
5 2482 2316 2153 1993 1835
10 2367 2202 2036 1873 1710
15 2217 2046 1875 1705 1534
45
5 2100 1937 1776 1616 1458
10 1972 1809 1644 1480 1315
15 1802 1628 1452 1272 1088
40
5 1715 1554 1396 1236 1080
10 1575 1407 1241 1073 900
15 1366 1180 956 622 357
FCLI124
T.w. Water [°C] Air R.T. in [°C]
in dt 16 18 20 22 24
WWWWW
70
5 14017 13410 12812 12223 11643
10 13696 15873 12500 11911 11322
15 13321 12714 12116 11519 10939
65
5 12687 12090 11501 10912 10341
10 12348 11759 11171 10582 10002
15 11947 11349 10751 10162 9582
60
5 11768 11171 10564 9975 9386
10 11001 10412 9832 9252 8681
15 10564 9975 9386 8797 8217
50
5 8690 8110 7539 6977 6424
10 8289 7709 7129 6558 5987
15 7762 7165 6567 5969 5371
45
5 7352 6781 6219 5657 5103
10 6906 6335 5755 5184 4604
15 6308 5701 5086 4452 3810
40
5 6005 5443 4889 4327 3783
10 5514 4925 4345 3756 3150
15 4782 4131 3346 2177 1249
HEATING CAPACITY CORRECTION FACTORS
The heating capacity refers to the maximum speed. For the others the speeds, the values must be multiplied by the following fac-
tors:
FCLI 32 34 42 44 62 64 82 124 122
speed 3 1 1 1 1 1 1 1 1 1
speed 2 0.30 0.20 0.45 0.20 0.64 0.25 0.81 1.47 0.83
Speed 1 (minimum) 0.22 0.17 0.33 0.18 0.52 0.22 0.59 1.05 0.63
