AFL Hyperscale U Series User manual

Installation Guide
FVP Pre-Terminated
Replacement
Cassette
Series

2© AFL Hyperscale. All rights reserved Series
Safety Precautions
Laser Precautions
Warning: The laser light used to transmit information over optical ber cables can cause severe eye
damage. Because this light is invisible, it will not cause the iris of the eye to contract involuntarily as when
viewing a bright visible light, and no pain is felt as the retina is burned.
Never look into the end of a ber or connector which may have a laser coupled to it. Should accidental
eye exposure to laser light be suspected, arrange for an eye examination immediately.
General Precautions
Personnel must be thoroughly familiarized with all applicable Occupational Health and Safety (OH&S)
regulations, local regulations, and your company safety practices and policies.
Warning: To reduce the chance of accidental injury:
Before work begins, all personnel must be thoroughly familiar with the operation of all equipment
and procedures to be used during the installation.
Before use, all equipment, especially safety gear, must be inspected and tested for proper operation.
Replace and repair as necessary.
U-Series FVP Pre-Terminated
Replacement Cassette
Before installing or adjusting this product, please read these instructions carefully.
Please keep this guide for future reference.

3
U-Series FVP Pre-Terminated Replacement Cassette
© AFL Hyperscale. All rights reserved
Series
Component Overview
01
02
03
04
04

4© AFL Hyperscale. All rights reserved Series
In the Box
Item
Number Item Qty
01 FVP Pre-Terminated Cassette 1
02 LC Quad Shuttered Adapter 6
03 24f 200μm SWR LC Pigtail
(Pre-Installed) 1
04 Cable Ties 1
05 Cassette Labels 1 set
06 12f Ribbon Splice Protector 2
(01) FVP Pre-Terminated
Cassette
(04) Cable Ties
Scissors
Marker Pen
(02) LC Quad Shuttered
Adapter
(05) Cassette Labels
Jacket Stripper
(03) 24f 200µm SWR®LC
Pigtail (Pre-Installed)
(06) 12f Ribbon
Splice Protector
What You Will Need Related Products
U-Series 2RU Front-
Access V-Panel (FVP)
U-Series 6RU Front-
Access V-Panel (FVP)
250 μm WTC with SWR®U-Series 3456f & 6912f
Breakout Box

5
U-Series FVP Pre-Terminated Replacement Cassette
© AFL Hyperscale. All rights reserved
Series
Cassette Swap-Out
Un-wrap affected pigtail from Velcro and
un-coil tail from panel.
4
Un-wrap affected Ø3mm pigtail jacket from
Velcro, carefully pull out tail from tie
point / splice drawer.
3
Un-coil affected ber back to jacket strip point.
2
Cut ber of affected cassette at end of splice
protector.
1
Cut
point
Velcro Velcro
Jacket strip point
Un-coil
ber

6© AFL Hyperscale. All rights reserved Series
Cassette Swap-Out
Re-dress cassette tail into panel and drawer by
re-wrapping into Velcro bundles and tying off at
drawer entry. Add appropriate cassette number
label at shown points.
8
Push in cassette and click into drawer,
pivot tail piece left or right as appropriate.
7
Feed new cassette tail into drawer.
6
De-latch cassette and carefully pull out
with full pigtail length.
5
Velcro
Cassette
number
label
Tail tie point
Velcro

7
U-Series FVP Pre-Terminated Replacement Cassette
© AFL Hyperscale. All rights reserved
Series
Cassette Swap-Out
Prepare both cable ber (GREEN) and internal
pigtail ber (RED) and splice, dress slack ber into
drawer. Cassette swap-out complete, refer to U-Series
6RU Front-Access V-Panel (FVP) Installation Guide
(AFLHS6U864SWR041119V2) to t drawer into panel.
10
Strip tail jacket.
9
Jacket strip point

Thank you for choosing AFL Hyperscale
AFLHSFVPPTRCAS270820
www.aflhyperscale.com
AFL Hyperscale reserves the right to make changes in this Installation Guide at any time without notice
