AFX STA006 User manual
INSTALLATION MANUAL
MOTOCROSS SERVICE STAND
SKU STA006
Align the aluminum holders on the chair legs holes and
present the screws using washers and nuts. Do not tighten
yet.
3
Tighten the right side screws to finish the installation.
4
Aluminum Holders
AFX Motorsports products are designed to best fit user’s ATV/UTV under stock conditions. Adding, modifying, or fabricating any factory
or aftermarket parts will void any warranty provided by AFX Motorsports and is not recommended. AFX Motorsports products could
interfere with other aftermarket accessories. If user has aftermarket products on machine, contact AFX Motorsports to verify that they
will work together. Although AFX Motorsports has thousands of satisfied customers, user should be aware that installing bumpers, rock
sliders, spare tire carriers, etc. will change the ride of machine and may increase maintenance and part wear. Operating any off-road
machine while, or after, consuming alcohol and/or drugs increases risk of bodily harm or death. No warranty or representation is made
as to this product’s ability to protect user from severe injury or death. AFX Motorsports urges operators and occupants to wear a helmet
and appropriate riding gear at all times. By purchasing and installing AFX Motorsports products, user agrees that should damages
occur, AFX Motorsports will not be held responsible for loss of time, use, labor fees, replacement parts, or freight charges. AFX
Motorsports, nor any 3rd party, will not be held responsible for any direct, indirect, incidental, special, or consequential damages that
result from any product purchased from AFX Motorsports. The total liability of seller to user for all damages, losses, and causes of
action, if any, shall not exceed the total purchase price paid for the product that gave rise to the claim. AFX Motorsports will warranty
only parts provided by AFX Motorsports. Any damage or problems with OEM housings, bearings, seals, or other manufacturers’
products will not be covered by AFX Motorsports. AFX Motorsports parts and products are not warrantied if item was not installed
properly, misused, or modified.
Liability Statement
Place the A1 and B1 Chair Legs on the main base as shown
in the picture, align them properly with 1/4 x 1 screw (use
washer and nuts provided) do not tight them yet. Repeat
this step with chair legs A2 and B2..
Once the chair legs are placed on the main base, align the
customized plates on the original holes of the chair legs,
place screws using nuts and washers. Do not tighten yet.
Repeat step for both plates.
7/32” Allen Key.
9/16” or 14 mm Combination Wrench.
(20x) 1/4” x 1” Bolts with washers and nuts.
MOTOCROSS SERVICE STAND
HOW TO INSTALL
“A1” Chair Leg
“B1” Chair Leg
“A2” Chair Leg
“B2” Chair Leg
(4) Chair Legs
(2)Customized Plate
Main Base
(2) Aluminum Holders
Customized Plate
FOR PURCHASING AT AFX MOTORSPORTS
