Installation Guide

Agilent Technologies
E444xAU Options H20, H25 and H70
Installation Guide
Retrofit Kit for the PSA Instruments
Use this manual with the following products:
E4440A/E4443A/E4445A/E4446A/E4448A
Manufacturing Part Number: E4440-90214
Printed Date: March 2008
Supersede: November 2005
© Copyright 2004, 2005, 2008 Agilent Technologies, Inc. All rights reserved.

ii Installation Guide
Warranty Statement
THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROVIDED “AS IS,” AND IS SUBJECT
TO BEING CHANGED, WITHOUT NOTICE, IN FUTURE EDITIONS. FURTHER, TO THE
MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, AGILENT DISCLAIMS ALL
WARRANTIES, EITHER EXPRESS OR IMPLIED WITH REGARD TO THIS MANUAL AND
ANY INFORMATION CONTAINED HEREIN, INCLUDING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. AGILENT SHALL NOT BE LIABLE FOR ERRORS OR FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE FURNISHING, USE, OR
PERFORMANCE OF THIS DOCUMENT OR ANY INFORMATION CONTAINED HEREIN.
SHOULD AGILENT AND THE USER HAVE A SEPARATE WRITTEN AGREEMENT WITH
WARRANTY TERMS COVERING THE MATERIAL IN THIS DOCUMENT THAT CONFLICT
WITH THESE TERMS, THE WARRANTY TERMS IN THE SEPARATE AGREEMENT WILL
CONTROL.
DFARS/Restricted Rights Notice
If software is for use in the performance of a U.S. Government prime contract or
subcontract, Software is delivered and licensed as “Commercial computer software” as
defined in DFAR 252.227-7014 (June 1995), or as a “commercial item” as defined in FAR
2.101(a) or as “Restricted computer software” as defined in FAR 52.227-19 (June 1987) or
any equivalent agency regulation or contract clause. Use, duplication or disclosure of
Software is subject to Agilent Technologies’ standard commercial license terms, and
non-DOD Departments and Agencies of the U.S. Government will receive no greater than
Restricted Rights as defined in FAR 52.227-19(c)(1-2) (June 1987). U.S. Government users
will receive no greater than Limited Rights as defined in FAR 52.227-14 (June 1987) or
DFAR 252.227-7015 (b)(2) (November 1995), as applicable in any technical data.

Installation Guide iii
Safety Notes
The following safety notes are used throughout this document. Familiarize yourself with
each of these notes and its meaning before performing any of the procedures in this
document.
WARNING Warning denotes a hazard. It calls attention to a procedure
which, if not correctly performed or adhered to, could result in
injury or loss of life. Do not proceed beyond a warning note
until the indicated conditions are fully understood and met.
CAUTION Caution denotes a hazard. It calls attention to a procedure that, if not
correctly performed or adhered to, could result in damage to or
destruction of the instrument. Do not proceed beyond a caution sign
until the indicated conditions are fully understood and met.
Definitions
•Specifications describe the performance of parameters covered by the product warranty
(temperature –0 to 55 °C, unless otherwise noted.)
•Typical describes additional product performance information that is not covered by the
product warranty. It is performance beyond specification that 80% of the units exhibit
with a 95% confidence level over the temperature range 20 to 30 °C. Typical
performance does not include measurement uncertainty.
•Nominal values indicate expected performance or describe product performance that is
useful in the application of the product, but is not covered by the product warranty.
•Characteristic Performance describes performance parameter that the product is
expected to meet before it leaves the factory, but is not verified in the field and is not
covered by the product warranty. A characteristic includes the same guard bands as a
specification.

iv Installation Guide

Contents
Installation Guide Contents-1
E444xAU Options H20, H25 and H70
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Verifying the Shipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Removing the Feet, Handles and Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Instruments with H7L or HNQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installing the Rear Panel with H7L or HNQ. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Instruments without H7L or HNQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Nominal Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Performance Tests and Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Equipment Required. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Option IF Output Amplitude Test Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
321.4 MHz IF Out Amplitude Test Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Measuring the Bandwidth of the IF Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Safety and Regulatory Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Before Applying Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Connector Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Statement of Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Compliance with Canadian EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Compliance with German Noise Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Cautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Instrument Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Agilent Support, Services, and Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Service and Support Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Contacting Agilent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Shipping Your Analyzer to Agilent for Service or Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Contents-2 Installation Guide
Contents

Installation Guide 1
E444xAU Options H20, H25 and H70

2Installation Guide
E444xAU Options H20, H25 and H70 E444xAU IF Output Options
Introduction
Introduction
This manual incorporates the installation of the following similar instrument models
E4440A, E4443A, E4445A, E4446A, E4448A with Option H20, H25 or H70.
Only one of the options can be installed per instrument due to the 321.4 MHz IF being
required as the input. When the Option IF Output is installed with Option H7L or HNQ,
the 321.4 MHz IF Output must be jumpered (8120-5066) to the H7L IN, HNQ IN, or
Option IF IN (H20 IN, H25 IN or H70 IN) for any one of the options to function properly.
Description
The Agilent model numbers E4440AU, E4443AU, E4445AU, E4446AU and E4448AU are
refered to as the E444xAU through out this document. Options H20, H25, and H70 are
referred to as the Option IF Output.
The E444xAU Option IF Output is a retrofit kit that provides the components necessary to
install a down converted IF Output connector to the rear panel of the PSA Performance
Spectrum Analyzer. The Option IF Output can be installed with Options H7L and HNQ.
Verifying the Shipment
Check the items received in the following option specific Tables on the following pages to
ensure that you have received all the items in your shipment. If there are any signs of
damage that may have occurred during shipment, or any accessories appear to be damaged
or missing, call your nearest Agilent Technologies sales or service office. See “Contacting
Agilent” on page 32 for more information.

Installation Guide 3
E444xAU IF Output Options E444xAU Options H20, H25 and H70
Verifying the Shipment
Table 1 E4440xAU Option H20 Content List
Description Agilent
Part Number Quantity
Plug Hole .25D NYL 6960-0076 3
Plug Hole .5D NY 6960-0149 2
Option Label (H20) E4440-80560 1
Panel Rear Dress E4440-00059 1
Cable AY (W40) E4440-60411 1
Cable AY (W51) E4440-60412 1
Cable AY (W41) E4440-60413 1
IF Output Board E4440-60414 1
Label (20 MHz) E4440-80541 1
Label (H20 IN) E4440-80552 1
Installation Guide E4440-90214 1
Product Note E4440-90545 1
Wire Marker Clip 2 (red) 7121-5602 2
Table 2 E4440xAU Option H25 Content List
Description Agilent
Part Number Quantity
Plug Hole .25D NYL 6960-0076 3
Plug Hole .5D NY 6960-0149 2
Option Label (H25) E4440-80561 1
Panel Rear Dress E4440-00059 1
Cable AY (W40) E4440-60411 1
Cable AY (W51) E4440-60412 1
Cable AY (W41) E4440-60413 1
IF Output Board E4440-60429 1
Label (H25 IN) E4440-80553 1
Label (25 MHz) E4440-80554 1
Product Note E4440-90575 1
Installation Guide E4440-90214 1
Wire Marker Clip 2 (red) 7121-5602 2

4Installation Guide
E444xAU Options H20, H25 and H70 E444xAU IF Output Options
Verifying the Shipment
Table 3 E4440xAU Option H70 Content List
Description Agilent
Part Number Quantity
Plug Hole .25D NYL 6960-0076 3
Plug Hole .5D NY 6960-0149 2
Option Label E4440-80563 1
Panel Rear Dress E4440-00059 1
IF Output Board E4440-604241
1. Earlier versions of this upgrade kit may include the IF Output Board (E4440-60410).
1
Cable AY (W40) E4440-60411 1
Cable AY (W51) E4440-60412 1
Cable AY (W41) E4440-60413 1
Product Note E4440-90213 1
Installation Guide E4440-90214 1
Wire Marker Clip 2 (red) 7121-5602 2

Installation Guide 5
E444xAU IF Output Options E444xAU Options H20, H25 and H70
Installation Procedure
Installation Procedure
Removing the Feet, Handles and Covers
NOTE Keep all of the hardware (screws, nuts, etc.) for re-use when installing the
assemblies.
Follow the steps outlined below to install the Option IF Output retrofit kit.
1. Remove the four rear panel feet on the PSA, using a #20 Torx driver. Refer to
Figure 1. Upon re-installation torque to 21 in-lb.
Figure 1 Rear Panel Feet
2. Remove the two side handles on the PSA, using a #20 Torx driver. Refer to
Figure 2. Upon re-installation torque to 21 in-lb.
Figure 2 Side Handles

6Installation Guide
E444xAU Options H20, H25 and H70 E444xAU IF Output Options
Installation Procedure
3. Remove the four feet from the bottom of the PSA instrument by pulling the tabs away
from the instrument and sliding the feet toward the center of the instrument.
Refer to Figure 3.
4. Remove the outside cover by sliding it toward the rear of the instrument.
Figure 3 Bottom Feet Orientation

Installation Guide 7
E444xAU IF Output Options E444xAU Options H20, H25 and H70
Installation Procedure
5. Remove the chassis cover, using a #10 Torx driver. Refer to Figure 4 for location of top
screws. There are ten screws to remove from the “speaker” side of the chassis cover and
two screws from the “power supply” side of the chassis cover. Place all hardware in a
safe location for re-installation.
NOTE The E4446A and E4468A have two additional screws in the chassis cover. The
white circles indicate the approximate position.
Figure 4 Chassis Cover Screw Location

8Installation Guide
E444xAU Options H20, H25 and H70 E444xAU IF Output Options
Installation Procedure
6. Remove the rear panel plate by removing the following components. Refer to Figure 5.
• BNC (f) connectors nuts
• SMA connector nut
• thirteen rear plate screws
7. Carefully pull the rear panel plate away from the BNC and SMA connectors. Insure
that the cables are labeled so that the BNC and SMA connectors are inserted into the
correct holes when re-installing them on the new rear panel plate. Discard the old rear
panel plate.
Figure 5 Rear Panel Plate Connectors and Hardware

Installation Guide 9
E444xAU IF Output Options E444xAU Options H20, H25 and H70
Installation Procedure
Instruments with H7L or HNQ
1. Remove the brown (1) wire marker clip from the E4440-60412 cable and add a red
marker clip (2) to each end of the cable. The wire marker will now read 52 (reference
designator W52).
2. Install cables (E4440-60412 and E4440-60413) and hole plug(s), as per the specific
option configuration, on the rear panel plate (E4440-00059). See Figure 6, Figure 7 and
Figure 8.
3. Apply the option specific label to cover the 70 MHz silk screen with the frequency for
the specific option being installed (20 MHz or 25 MHz). The Option H70 does not
require a label.
4. Apply the label to cover the “H70 IN” silk screen with the specific option being installed
(H20 IN or H25 IN). The Option H70 does not require a label.
Figure 6 Rear Panel Plate with Option H7L
6960-0149
E4440-60413 E4440-60412 H20 IN or
H25 IN Label
l
HNQ IN
20 MHz or
25 MHz Label
6960-0076
Hole Plug

10 Installation Guide
E444xAU Options H20, H25 and H70 E444xAU IF Output Options
Installation Procedure
Figure 7 Rear Panel Plate with Option HNQ
Figure 8 Rear Panel Plate with Option H7L and HNQ
6960-0149
6960-0076
E4440-60413 E4440-60412
H7L IN
20 MHz or
25 MHz Label
H20 IN or
H25 IN Label
Hole Plug
6960-0149
E4440-60413 E4440-60412
20 MHz or
25 MHz Label
Hole Plug

Installation Guide 11
E444xAU IF Output Options E444xAU Options H20, H25 and H70
Installation Procedure
Installing the Rear Panel with H7L or HNQ
1. Connect the BNC and SMA connectors as labeled in step 7 on Page 8, using the
previously removed hardware. Carefully route the new cables (W41 and W52) through
the rear frame, near Slot 2. (To be connected to the Option IF board later in this
procedure). Refer to Figure 12 on page 13.
2. Connect the new rear panel plate to the rear panel, using the previously removed
screws. Torque to 9 in-lb.
3. Partially insert the Option IF board into Option Slot 2. See Figure 9.
Figure 9 Option IF Board Insertion
Option IF
Out Board

12 Installation Guide
E444xAU Options H20, H25 and H70 E444xAU IF Output Options
Installation Procedure
4. Carefully route the cables along the top of the rear frame and between the board
extractors to insure that they will not be damaged when installing the chassis cover.
Refer to Figure 12 and Figure 13 on page 14. Connect the cables as follows:
• Connect the 321.4 MHz IF Input cable (E4440-60412) (W52) on the rear panel to the
321.4 MHz IF Input connector (J1) on the Option IF board. Refer to Figure 11 on
page 13.
• Connect the Option IF Output cable (E4440-60413, W41) on the rear panel to the
Option IF Output connector (J2) on the Option IF board.
• Connect the jumper cable (8120-5066). See Figure 10.
NOTE Jumper cable (8120-5066) is included on instruments with Option H7L or
HNQ. Move the cable from the Option H7L IN or HNQ IN to the Option IF IN
connector (H20 IN, H25 IN or H70 IN) for the option to function properly.
Figure 10 Jumper Cable (Option H7L)
5. Completely insert the Option IF Output board into Slot 2.
6. Attach the appropriate option label (H20, H25 or H70) to the rear panel next to the
existing list of options on the serial number label.
7. Install the chassis cover, instrument cover, side handles, bottom and rear feet in reverse
order of the removal process described in the beginning of the procedure.
8. Install licence key to enable Option H20, H25 or H70. Refer to Option Upgrade
Entitlement Certificate for option license procedure.
