OmniBER 725
communications
performance analyzer
Configuration Guide

The OmniBER 725 provides
optical and electrical interfaces
for SDH/SONET bit error rate
and jitter testing from 50 Mb/s
to 2.5 Gb/s (STM-16c/OC-48c).
Configuration and ordering
To order the test capability you require from your
Agilent Technologies OmniBER 725 communications
performance analyzer, simply follow the four steps below.
NB. E4547A wander analysis is not compatible with the
Omniber 725
1. Please select the mainframe that meets your requirements
(includes RS-232-C, LAN and GP-IB remote control interfaces)
Mainframe
Bit Error Rate (BER) capability J1408A ❑
BER and jitter capability J1409A ❑
2. Order standards version
(one must be ordered)
Option
SDH (ITU-T) 001 ❑
Dual standard SONET/SDH (ANSI/ITU-T) 002 ❑
3. Optical interface
(optics must be ordered)
1310 nm only 104 ❑
1550 nm only 105 ❑
Dual wavelength 1310 nm/1550 nm 106 ❑
Replaces FC/PC adapters with SC 610 ❑
Replaces FC/PC adapters with ST 611 ❑
4. Accessory options
80-column in-lid graphics printer 602 ❑

Optical coupler
15744B‡: In-lid optical coupler.
15744C‡: In-pouch optical
coupler (for use when option
602, graphics printer is fitted).
‡ Order the appropriate option. For full
details of the 15744B/C optical coupler,
please ask your local Agilent
Technologies representative for a
brochure.
E4545A: Additional 3m fiber
optic cable (FC/PC connectors).
E4546A: Additional FC/PC
15 dB attenuator.
Graphics printer paper
Printer paper: Part Number
9270-1360.
Carrying cases and
rack mount kit
15772C: Hard, robust transit
case.
15910B: Soft, vinyl carrying
case.
15989A: 19-inch rack mount kit.
Manuals and calibration
certificate
Option 0B1: Additional set of
manuals.
Option UK6: Calibration
certificate.
Warranty
1-year warranty as standard.
Warranty and calibration plan
extensions to 3 and 5 years can
be provided
Standards conformance
CE mark*: The OmniBER 725
communications performance
analyzer has full CE mark
compliance and meets the
following standards:
· ESD/mains fast transients/
radiated susceptibility: meets
EN50082-1 (1991).
· Radiation emissions/
conducted emissions: meets
EN55011 (1991).
Product safety:
The OmniBER 725 communi-
cations performance analyzer
meets the following safety
standards:
· IEC 348/EN61010.
* All products sold in EC and
ETSI countries must have the CE
mark.
