Agilent Technologies Series N6700 User manual


Agilent Technologies
Low
-Profile
Modular Power System
Series N6700
User’s Guide

2 Series N6700 User’s Guide
Legal Notices
© Agilent Technologies, Inc. 2006-2012
No part of this document may be
photocopied, reproduced, or translated to
another language without the prior
agreement and written consent of Agilent
Technologies, Inc. as governed by United
States and international copyright laws.
Warranty
The material contained in this document
is provided “as is,” and is subject to
being changed, without notice, in future
editions. Further, to the maximum extent
permitted by applicable law, Agilent
disclaims all warranties, either express or
implied, with regard to this manual and
any information contained herein,
including but not limited to the implied
warranties of merchantability and fitness
for a particular purpose. Agilent shall not
be liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or performance
of this document or of any information
contained herein. Should Agilent and the
user have a separate written agreement
with warranty terms covering the material
in this document that conflict with these
terms, the warranty terms in the separate
agreement shall control.
Manual Editions
Manual Part Number: 5969-2937
Seventh Edition, June, 2012
Printed in Malaysia.
Reprints of this manual containing minor
corrections and updates may have the
same printing date. Revised editions are
identified by a new printing date. .
Declaration of Conformity
Declarations of Conformity for this
product and for other Agilent products
may be downloaded from the Web. Go to
http://regulations.corporate.agilent.com
and click on “Declarations of Conformity.”
You can then search by product number
to find the latest Declaration of
Conformity
Waste Electrical and
Electronic Equipment (WEEE)
Directive 2002/96/EC
This product complies with the WEEE
Directive 2002/96/EC) marketing
requirement. The affixed product label
(see below) indicates that you must not
discard this electrical/electronic product
in domestic household waste.
Product Category: With reference to the
equipment types in the WEEE directive
Annex 1, this product is classified as
“Monitoring and Control instrumentation”
product.
Do not dispose in domestic household
waste.
To return unwanted products, contact our
local Agilent office, or see
www.agilent.com/environment/product
for more information.
Certification
Agilent Technologies certifies that this
product met its published specifications
at time of shipment from the factory.
Agilent Technologies further certifies that
its calibration measurements are
traceable to the United States National
Institute of Standards and Technology, to
the extent allowed by the Institute's
calibration facility, and to the calibration
facilities of other International Standards
Organization members.
Exclusive Remedies
THE REMEDIES PROVIDED HEREIN ARE
THE CUSTOMER'S SOLE AND EXCLUSIVE
REMEDIES. AGILENT TECHNOLOGIES
SHALL NOT BE LIABLE FOR ANY DIRECT,
INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, WHETHER
BASED ON CONTRACT, TORT, OR ANY
OTHER LEGAL THEORY.
Assistance
This product comes with the standard
product warranty. Warranty options,
extended support contacts, product
maintenance agreements and customer
assistance agreements are also available.
Contact your nearest Agilent
Technologies Sales and Service office for
further information on Agilent
Technologies' full line of Support
Programs.
Technologies Licenses
The hardware and or software described
in this document are furnished under a
license and may be used or copied only in
accordance with the terms of such
license.
U.S. Government Restricted
Rights
Software and technical data rights
granted to the federal government include
only those rights customarily provided to
end user customers. Agilent provides this
customary commercial license in
Software and technical data pursuant to
FAR 12.211 (Technical Data) and 12.212
(Computer Software) and, for the
Department of Defense, DFARS 252.227-
7015 (Technical Data – Commercial
Items) and DFARS 227.7202-3 (Rights in
Commercial Computer Software or
Computer Software Documentation).
Trademarks
Microsoft and Windows are U.S.
registered trademarks of Microsoft
Corporation.

Series N6700 User’s Guide 3
Safety Notices
The following general safety precautions
must be observed during all phases of
operation of this instrument. Failure to
comply with these precautions or with
specific warnings or instructions
elsewhere in this manual violates safety
standards of design, manufacture, and
intended use of the instrument. Agilent
Technologies assumes no liability for the
customer's failure to comply with these
requirements.
General
Do not use this product in any manner
not specified by the manufacturer. The
protective features of this product may be
impaired if it is used in a manner not
specified in the operation instructions.
Before Applying Power
Verify that all safety precautions are
taken. Make all connections to the unit
before applying power. Note the
instrument's external markings described
under "Safety Symbols"
Ground the Instrument
This product is a Safety Class 1
instrument (provided with a protective
earth terminal). To minimize shock
hazard, the instrument chassis and cover
must be connected to an electrical
ground. The instrument must be
connected to the AC power mains
through a grounded power cable, with the
ground wire firmly connected to an
electrical ground (safety ground) at the
power outlet. Any interruption of the
protective (grounding) conductor or
disconnection of the protective earth
terminal will cause a potential shock
hazard that could result in personal injury.
Fuses
The instrument contains an internal fuse,
which is not customer accessible.
Do Not Operate in an Explosive
Atmosphere
Do not operate the instrument in the
presence of flammable gases or fumes.
Do Not Remove the Instrument
Cover
Only qualified, service-trained personnel
who are aware of the hazards involved
should remove instrument covers. Always
disconnect the power cable and any
external circuits before removing the
instrument cover.
Do Not Modify the Instrument
Do not install substitute parts or perform
any unauthorized modification to the
product. Return the product to an Agilent
Sales and Service Office for service and
repair to ensure that safety features are
maintained.
In Case of Damage
Instruments that appear damaged or
defective should be made inoperative and
secured against unintended operation
until they can be repaired by qualified
service personnel.
A CAUTION notice denotes a hazard.
It calls attention to an operating
procedure, practice, or the like that, if
not correctly performed or adhered to,
could result in damage to the product
or loss of important data. Do not
proceed beyond a CAUTION notice
until the indicated conditions are fully
understood and met.
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or the
like that, if not correctly performed
or adhered to, could result in
personal injury or death. Do not
proceed beyond a WARNING notice
until the indicated conditions are
fully understood and met.
Safety Symbols
Direct current
Alternating current
Both direct and alternating
current
Three phase alternating
current
Earth (ground) terminal
Protective earth ground
terminal.
Frame or chassis terminal
Terminal is at earth
potential.
Neutral conductor on
permanently installed
equipment
Line conductor on
permanently installed
equipment.
On supply
Off supply
Standby supply. Unit is not
completely disconnected
from AC mains when
switch is off
In position of a bi-stable
push switch
Out position of a bi-stable
push switch
Caution, risk of electric
shock
Caution, hot surface
Caution, refer to
accompanying description
CAUTION
WARNING

4 Series N6700 User’s Guide
In this Book
Specific chapters in this manual contain the following information:
Quick Reference – Chapter 1 is a quick reference section that
helps you quickly become familiar with your Agilent N6700
Modular Power System. It describes the differences between the
various modules in the power system.
Installation – Chapter 2 describes how to install your power
system. It describes how to connect various loads to the output. It
discusses remote sensing as well as parallel and series operation.
Getting Started – Chapter 3 describes how to set the voltage,
current, over-voltage protection, and turn on the output. It also
describes how to configure the remote interface.
Operating the Power System – Chapter 4 describes how to use
the advanced features of the power system using the front panel
menus and the corresponding SCPI commands.
Specifications – Appendix A describes the mainframe
characteristics.
Using the Digital Port – Appendix B describes how to configure
and use the digital port on the back of the instrument.
Power Allocation – Appendix C describes the power allocation
function, which applies to power system in which the combined
ratings of the power modules exceed the power rating of the
mainframe.
Output On/Off Synchronization – Appendix D discusses output
on/off synchronization, which lets you accurately synchronize
output turn-on sequences across multiple mainframes.
Source Operating Modes – Appendix E discusses operating mode
information for all power modules.
For complete details on the SCPI (Standard Commands for
Programmable Instruments) commands, refer to the N6700
Programmer’s Reference Help file included on the Agilent N6700
Product Reference CD. This CD-ROM is shipped along with your
instrument.
NOTE You can contact Agilent Technologies at one of the following telephone
numbers for warranty, service, or technical support information.
In the United States: [phone]
In Europe: 31 20 547 2111
In Japan: 0120-421-345
Or use our Web link for information on contacting Agilent in your country or
specific location: www.agilent.com/find/assist
Or contact your Agilent Technologies Representative.

Series N6700 User’s Guide 5
Contents
1 – Quick Reference ..............................................................................................................................7
The Agilent N6700 Modular Power System – At a Glance.......................... 8
The Front Panel – At a Glance........................................................................ 11
The Rear Panel – At a Glance......................................................................... 11
Front Panel Display – At a Glance ................................................................. 12
Front Panel Keys – At a Glance...................................................................... 13
Front Panel Menu Reference .......................................................................... 14
SCPI Command Summary................................................................................ 16
2 – Installation .....................................................................................................................................23
General Information.......................................................................................... 24
Inspecting the Unit ........................................................................................... 25
Installing the Unit.............................................................................................. 26
Connecting the Line Cord ................................................................................ 30
Connecting the Outputs................................................................................... 31
Remote Sense Connections............................................................................ 36
Parallel Connections......................................................................................... 38
Series Connections........................................................................................... 40
Additional Load Considerations...................................................................... 42
Connecting the Auxiliary Voltage Measurement Input .............................. 44
3 – Getting Started ..............................................................................................................................45
Turning the Unit On .......................................................................................... 46
Selecting an Output Channel .......................................................................... 46
Entering an Output Voltage Setting ............................................................... 46
Entering a Current Limit Setting..................................................................... 47
Enabling the Output.......................................................................................... 47
Using the Front Panel Menu ........................................................................... 48
Connecting to the Interfaces .......................................................................... 50
Communicating Over the LAN ........................................................................ 57
Securing the Interfaces.................................................................................... 59
4 – Operating the Power System.......................................................................................................61
Programming the Output ................................................................................. 62
Synchronizing Output Steps............................................................................ 68
Programming Output Lists............................................................................... 72
Making Measurements.................................................................................... 77
Using the Digitizer............................................................................................. 79
Using the Protection Functions ...................................................................... 87

6 Series N6700 User’s Guide
External Data Logging ...................................................................................... 91
System-Related Operations............................................................................. 95
A – Specifications................................................................................................................................99
Agilent N6700B, N6701A, N6702A MPS Mainframes..............................100
B – Using the Digital Port.................................................................................................................103
Digital Control Port .........................................................................................104
Configuring the Digital Control Port.............................................................105
C – Power Allocation ........................................................................................................................109
Power Limit Operation ...................................................................................110
Module Power Allocation ..............................................................................111
D – Output On/Off Synchronization ................................................................................................113
Synchronizing Output Turn-on Delays.........................................................114
Synchronizing Multiple Mainframes............................................................117
Operation ..........................................................................................................118
E – Source Operating Modes ...........................................................................................................119
Single Quadrant Operation ............................................................................120
Agilent N678xA Multi-Quadrant Operation ................................................122
Updates
This manual describes firmware revision D.01.09 and up. Go to
http://www.agilent.com/find/N6700firmware if you need to
download this or any later versions of the firmware. Information on
how to install the firmware is available on the web site.
Refer to “Instrument Identification” in chapter 4 to view the
firmware version that is currently installed in your mainframe.
Updated versions of this manual are also posted on the web. Go to
http://www.agilent.com/find/N6700 to get the latest version of the
manual.

Series N6700 User’s Guide 7
1
Quick Reference
The Agilent N6700 Modular Power System – At a Glance.......................... 8
The Front Panel – At a Glance........................................................................ 11
The Rear Panel – At a Glance......................................................................... 11
Front Panel Display – At a Glance ................................................................. 12
Front Panel Keys – At a Glance...................................................................... 13
Front Panel Menu Reference .......................................................................... 14
SCPI Command Summary................................................................................ 16
This chapter concisely describes the operation of the Agilent N6700
Modular Power System (MPS).
This chapter does not describe every operating feature in detail. It is
simply a quick reference guide to quickly become familiar with the
essential operating features of the power system.
For complete details on the SCPI (Standard Commands for
Programmable Instruments) commands, refer to the Programmer’s
Reference Help file included on the Agilent N6700 Product Reference
CD. This CD-ROM is shipped along with your instrument.
NOTE Unless otherwise noted, the Agilent N6700 Modular Power System will also be
referred to as “MPS” and “power system” throughout this manual.

1 Quick Reference
8 Series N6700 User’s Guide
The Agilent N6700 Modular Power System – At a Glance
The Agilent N6700 Modular Power System is a configurable, one rack-
unit (1U) platform that lets you mix and match power modules to
create a power system optimized for your test system requirements.
Agilent N6700–N6702 MPS mainframes are available in power levels
of 400 W, 600 W, and 1,200 W. Up to four power modules can be
installed in each mainframe. Power modules come in power levels of
20 W through 500 W, have various voltage and current combinations,
and provide the following performance features:
The N673xB, N674xB, and N677xA DC Power Modules provide
programmable voltage and current, measurement, and protection
features, making these economical models suitable for powering
the device-under-test or system resources such as fixture controls.
The N675xA High-Performance, Autoranging DC Power Modules
provide low noise, high accuracy, fast programming times, and
advanced programming and measurement capabilities to speed
test throughput.
The N676xA Precision DC Power Modules provide precise control
and measurements in the milli- and micro-ampere region with
the ability to simultaneously digitize voltage and current and
capture those measurements into an oscilloscope-like data buffer.
The N678xA Source/Measure Units (SMU) have a multiple-
quadrant power mesh with separate voltage and current priority
source modes. These models are optimized for applications such
as battery drain analysis and functional testing.
The N6783A Application-Specific DC Power Modules are two-
quadrant low-wattage models specifically designed for battery
charging/discharging and mobile communications applications.
The output and system features are described in the following
sections. Not all output features are available on every power
module. The “Model Differences” section describes the features that
apply only to specific power modules.
Output Features
Programmable voltage
and current
Full programming capability is provided for the entire range of output
voltage and current. Outputs can operate as either constant volt
age (CV) or
constant current (CC) sources.
Low output noise
Available on Agilent N676xA and N675xA power modules. Output noise is
<4.5 mV peak-to-peak, which is comparable to linear supplies.
Fast up/down
programming
Available on Agilent N675xA, N676xA,
and N678xA SMU power modules.
≤1.5 millisecond response time from 10% to 90% of the output rating.
Fast transient response
Available on Agilent N675xA, N676xA, and N678xA
SMU power modules.
Transient response is less than 100 μs.

Quick Reference 1
Series N6700 User’s Guide 9
Output a
utoranging
capa
bility
Available on Agilent N676xA and N675xA power modules.
Autoranging supplies the maximum rated power over a continuous range of
voltage and current settings.
Output On/Off sequencing
A turn
-on/turn-off delay capability for each output allows output on/off
sequencing.
Remote voltage sensing
Two remote sensing terminals are provided for each output. When shipped,
the remote sense jumpers are included in a separate bag. See Chapter 2.
Output
protection
Each output has over
-voltage, over-current, and over-temperature
protection. Over-voltage and over-current protection are programmable.
Multiple
-Quadrant
operation
Available on Agilent N678xA
SMU and N6783A power modules.
2- and 4-quadrant operation provides source and sink output capability.
Measurement Features
Multiple
-output/Single-
output meter display
Switch between a 4
-output summary view and a 1-output detailed view of
power supply information. All power modules display real
-time output
voltage and current measurements as well as status information.
Seamless measurement
autoranging
Available on Agilent N6781A and N6782A
SMU power modules.
Output
measurements seamlessly autorange between ranges – however,
the 10 μA current range must be selected manually.
Microampere
current
measurements
Available on Agilent
N6761A, N6762A, and N678xA SMU power modules.
Current measurement can be made as low as 1 μA in the 10 μA range.
Fast d
igitizing
Available on Agilent N678xA
SMU power modules.
5.12 μs/sample for one parameter; 10.24 μs/sample for two parameters.
System Features
Choice of three interfaces
GPIB (IEEE-488), LAN, and USB remote programming interfaces are built in.
Built
-in Web server
A built
-in Web server lets you control the instrument directly from an
internet browser on your computer.
SCPI language
The instrument is compatible with the Standard Commands for
Programmable Instruments (SCPI).
Front panel I/O setup
Menus let you set up GPIB and LAN parameters from the front panel.
Real
-time status
information
The front panel indicates the status of each output. It also indicates when a
protection shut-down has occurred.
Module identification
Each module has identifying data stored in non
-volatile memory.
Information includes model number, serial number, and options.
Universal AC
input
Mainframes have
universal input voltage capability
with active power factor
correction.

1 Quick Reference
10 Series N6700 User’s Guide
Model Differences
Feature
DC Power
High-Performance
Precision
(● = available)
N673xB, N674xB, N677xA
N675xA
N676xA
50 W output rating
N6731B – N6736B
N6751A
N6761A
100 W output rating
N6741B – N6746B
N6752A
N6762A
300 W output rating
N6773A – N6777A
N6753A, N6754A
N6763A, N6764A
500 W output rating N6755A, N6756A N6765A, N6766A
Output disconnect relays
Option 761
Option 761
Option 761
Output disconnect/polarity reversal relays
NOTE 1
Option 760
Option 760
Option 760
Autoranging output capability ●●
Voltage or current turn-on priority N6761A, N6762A
Precision voltage and current measurements
●
Low voltage and current output ranges N6761A, N6762A
Low voltage and current measurement ranges ●
200 microampere measurement range
NOTE 2
Option 2UA
Simultaneous voltage and current measurements
●
Output list capability (
Test Extensions
)
NOTE 3
Option 054
Option 054
●
Array readback capability (
Test Extensions
)
NOTE 3
Option 054
Option 054
●
Programmable sample rate (Test Extensions)
NOTE 3
Option 054
Option 054
●
Double-wide (occupies 2 channel locations)
N6753A – N6756A
N6763A – N6766A
Feature
Source/Measure Units (SMU)
Application-Specific
(● = available) N6781A N6782A N6784A N6783A-BAT N6783A-MFG
Output rating 20 W 20 W 20 W 24 W 18 W
2-quadrant operation
●
●
●
●
4-quadrant operation
●
Auxiliary voltage measurement input
●
Output disconnect relays ●●●Option 761 Option 761
Negative voltage protection
●
●
●
●
●
Voltage or current priority mode
●
●
●
Programmable output resistance
●
600 mV output range
●
●
●
300 mA output range
●
●
100 mA, 10 mA output ranges ●
1 V, 100 mV measurement ranges
●
●
●
100 mA, 1 mA, 10 μA measurement ranges
●
●
●
150 mA measurement range ●●
Simultaneous voltage and current measurements
●
●
●
Seamless measurement autoranging
●
●
Output list capability NOTE 3, 4 ●●●●●
Array readback capability
NOTE 3
●
●
●
●
●
Programmable sample rate
NOTE 3
●
●
●
●
●
1Output current is limited to 10A max. on Models N6742B and N6773A with Option 760.
Option 760 is not available on Models N6741B, N6751A, N6752A, N6761A, and N6762A.
2Option 2UA.is only available on Models N6761A and N6762A. It includes Option 761.
3Only available when using the remote interfaces; not from the front panel.
4List capability is not available on the negative current output on Model N6783A

Quick Reference 1
Series N6700 User’s Guide 11
The Front Panel – At a Glance
Display
Turns off after 1 hour of
inactivity. Press any key to
restore the display.
Navigation keys
Move the cursor to a menu item.
Select the highlighted menu item.
Output keys
Turn the outputs on or off.
Enter voltage or current.
N6700A Modular Power System
20.007V 4.004A
CV Set: 20.000V 5.500A
o -
Menu
3
E
+/-
Back
.
2
0
1
4 5 6
987
Sel
Meter
Channel
Help
On/Off
Voltage
Current
1Error Enter
On/Off switch and LED
LED indicates power is on.
Green = normal operation.
Amber = display is screen-
saver mode.
System keys
Toggle between single-channel and
multiple-channel view.
Access front panel command menu.
Select an output channel to control.
Numeric entry keys
Enter values.
Arrow keys increment or
decrement voltage and
current settings.
The Rear Panel – At a Glance
GPIB connector
Chassis ground
binding post
3-pin IEC 320 AC
input connector
Power cord requires
ground conductor.
+s + -s +s + -s +s + -s +s + -s
1 2 3 4 5 6 7
Output connector.
Includes +/−output and
+/−sense terminals.
8-pin digital control
connector
Connector function is
user-configurable.
USB connector LAN connector
10/100 Base-T
Left LED indicates
activity. Right LED
indicates link integrity.
WARNING SHOCK HAZARD The power cord provides a chassis ground through a third
conductor. Be certain that your power outlet is of the three-conductor type
with the correct pin connected to earth ground.

1 Quick Reference
12 Series N6700 User’s Guide
Front Panel Display – At a Glance
Single
-channel view Voltage
measurement
Bar indicates output
pol
arity is reversed
Current
measurement
Press the
Meter key
to toggle between
views
Operating status
(CV = constant voltage)
Voltage and
current settings
Interface status
(IO
= activity on interface)
Multiple
-channel view Voltage and Current measurements
Press the
Meter key
to toggle between
views
The highlighted channel is the active channel
Grouped
-channel view Channels 2 through 4 are connected in parallel and have been
configured or grouped to act as a single, higher-power channel
Refer to Chapter 4,
under “System
-Related
Operations” for more
information
Grouped channels are addressed using the channel number of the
lowest channel in the group
Double
-wide view Channel 2 is a double-wide power module that occupies two channel
locations in the mainframe
Interface status
indicators
Err = an error has occurred (press Error key to display error message)
Lan = the LAN is connected and has
been configured
IO = there is activity on one of the remote interfaces

Quick Reference 1
Series N6700 User’s Guide 13
Operating status
indicators
OFF = the output is off
CV = the outpu
t is in constant voltage mode
CC = the output is in constant current mode
CP+ = the output is limited (or disabled) by the positive power limit
CP
– = the output is limited (or disabled) by the negative power limit
V
L+/– = the output is in positive or negative voltage limit mode
C
L+/– = the output is in positive or negative current limit mode
OV = the output is disabled by the over
-voltage protection
OV
– = the output is disabled by the negative over-voltage protection
OC = the output is disabled by the over
-current protection
OT = the over
-temperature protection has tripped
PF = the output is disabled by a power
-fail condition
OSC = the output is disabled by the oscillation protection
INH = the output is disabled by an external inhibit signal
UNR = the outpu
t is unregulated
PROT = the output is disabled by a condition from a coupled channel
Front Panel Keys – At a Glance
System keys
Menu
Back
Meter
Channel
Help Error
Meter returns the display to metering mode.
Menu accesses the command menu.
Channel selects or highlights a channel to control.
Back backs out of a menu without activating any changes.
Help accesses information about the displayed menu control.
Error displays any error messages in the error queue.
Navigation keys
Sel
The Arrow keys let you move around in the command menus.
The Select key lets you make a selection in the command menus.
It also lets you enter edit mode for numeric parameters.
Output keys
On/Off
Voltage
Current
On/Off controls the selected output (or all outputs when All is lit).
This key is only active in Single- channel or Multiple-channel view.
Voltage lets you change the voltage setting of the selected channel.
Current lets you change the current setting of the selected channel.
Number keys
Enter
3
E
+/-
.
2
0
1
4 5 6
987
The 0 through 9 keys enter numbers. The (.) key is the decimal point.
The +/
−key is only used to enter a minus sign.
The E key enters an exponent. Add the value to the right of the E.
The
backspace key deletes digits as it backspaces over them.
The
arrow keys increment or decrement the voltage or current
setting
s. They are also used to select letters in alphabetic entry fields.
The Enter key enters a value. If you exit a field without pressing the
Enter key, the val
ue is ignored.

1 Quick Reference
14 Series N6700 User’s Guide
Front Panel Menu Reference
NOTE Menu commands that appear grayed-out on the front panel are either not
available for the power module, or are password protected.
Menu Command Control Description
Output Voltage Programs voltage setting, limits, and ranges.
Current Programs current setting, limits, and ranges.
Mode Programs output priority mode on Models N678xA SMU.
Sequence Delay Programs Turn-on /Turn off delay.
Couple Couples output channels for output on/off synchronization.
Advanced Slew Voltage Programs voltage slew rate.
Current
Programs current slew rate on Models N678xA SMU.
Power Programs the power allocation function.
Pol Lets you reverse the polarity of the output and sense terminals.
Resistance Programs output resistance on Model N6781A.
Bandwidth Programs output voltage bandwidth on Models N678xA SMU.
Tmode Programs turn-on/turn-off impedance on Models N678xA SMU.
Measure Range Selects voltage and current measurement range.
Sweep
Specifies measurement points, time interval, and trigger offset.
Window Selects measurement window: Rectangular, Hanning.
Input Selects Auxiliary voltage measurements on Model N6781A.
Control Lets you abort a measurement in progress.
Transient Mode Selects voltage or current transient mode: Fixed, Step, List.
Step Programs voltage and current step value. Enables step triggers.
List Pace Specifies Dwell or Trigger paced list.
Repeat Specifies number of list repetitions, or specifies continuous list.
Terminate
Specifies list settings when the list terminates.
Config Configures list step voltage, current, dwell, and trigger signals.
Reset Aborts the list and resets all list parameters.
TrigSource Specify the trigger source: Bus, Tran 1-4, Pin 1-7, Ext.
Control Initiates, Triggers, or Aborts output triggers. Displays trigger state.
Protect OVP Configures over-voltage protection function.
OCP Configures over-current protection function.
Inhibit Configures the external inhibit signal: Off, Latching, Live
Coupling Disables ALL output channels when a protection fault occurs.
Wdog Configures the output watchdog timer.
Osc Enables/disables oscillation protection on Models N678xA SMU.
Clear Clears output protection. Displays output state.
States Reset Resets the instrument to its reset (*RST) state.
SaveRecall Saves or recalls an instrument state.
PowerOn Selects the power-on state: *RST, RCL0.

Quick Reference 1
Series N6700 User’s Guide 15
Menu Command Control Description
System
IO
LAN
ActiveSettings
Displays the LAN interface settings that are presently active.
Config IP Configures the IP addressing of the instrument.
Name Configures the Dynamic DNS and NetBIOS naming service.
Domain Configures the Domain Name.
DNS Configures the DNS server.
TCP Configures the TCP keepalive function.
Reset Resets the LAN interface settings to the factory-shipped state.
USB Status Displays status, speed, packets received, and packets sent.
Identification USB connect string - the instrument’s unique USB identifier.
GPIB Selects the GPIB address.
DigPort Pins<1> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut, FaultOut.
Pins<2> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut.
Pins<3> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut, InhibitIn.
Pins<4-7> Function Specifies the pin function: DigIn, DigIO, TrigIn, TrigOut, OnC, OffC.
Pins<1-7>
Polarity
Specifies the pin polarity: Positive, Negative
Data
Sends/reads data from the digital I/O port
Groups Defines groups of output channels that are connected in parallel.
Preferences Display Contrast Configures the display contrast.
Saver
Configures the screen saver and wake-on I/O timer.
View Selects 1-channel or 4-channel view at turn-on
Keys Enables/disables key clicks and configures the On/Off key.
Lock Locks front panel keys. Enter a password to unlock the front panel.
Admin Login/Logout Enter a password to access the admin functions.
Cal Volt Vprog Calibrates High and Low voltage ranges.
Vlim Calibrates voltage limit High and Low ranges
Vmeas Calibrates High, Low, and Aux voltage measurement ranges.
Curr Iprog Calibrates High and Low current ranges.
Ilim Calibrates current limit.
Imeas Calibrates High and Low current measurement ranges.
Misc CMRR Calibrates common mode rejection ratio.
Dprog Calibrates the downprogrammer.
Ipeak Calibrates I peak.
Resistance
Calibrates output resistance High and Low ranges.
Date Saves the calibration date for each channel.
Save Saves the calibration data.
LAN Enables/disables the LAN interface and the built-in Web server.
USB Enables/disables the USB interface.
Nvram Resets all non-volatile RAM settings to their factory defaults.
Password Changes the password for the admin functions.
About Frame Displays model, serial number, and firmware revisions.
Module Displays model, serial number, options, voltage, current, power.

1 Quick Reference
16 Series N6700 User’s Guide
SCPI Command Summary
Subsystem Commands
NOTE Some [optional] commands have been included for clarity. All settings commands
have a corresponding query. Not all commands apply to all models.
SCPI Command
Description
ABORt
:ACQuire (@chanlist)
Resets the measurement trigger system to the Idle state
:ELOG (@chanlist)
Stops the external data log
:TRANsient (@chanlist)
Resets the transient trigger system to the Idle state
CALibrate
:CURRent
[:LEVel] <NRf>, (@channel)
Calibrates the output current programming
:LIMit
:NEGative <NRf>, (@channel)
Calibrates the negative current limit (only on N6783A)
:POSitive <NRf>, (@channel)
Calibrates the positive current limit (only on N678xA SMU)
:MEASure <NRf>, (@channel)
Calibrates the current measurement
:PEAK (@channel)
Calibrates the peak current limit (only on N675xA, N676xA)
:DATA <NRf>
Enters the calibration value
:DATE <”date”>, (@channel)
Sets the calibration date
:DPRog (@channel)
Calibrates the current downprogrammer
:LEVel P1 | P2 | P3
Advances to the next calibration step
:PASSword <NRf>
Sets the numeric calibration password
:RESistance 20| 6, (@channel)
Calibrates the output resistance (only on N6781A)
:SAVE
Saves the new cal constants in non-volatile memory
:STATE <Bool> [,<NRf>]
Enables/disables calibration mode
:VOLTage
[:LEVel] <NRf>, (@channel)
Calibrates the output voltage programming
:CMRR (@channel)
Calibrates common mode rejection ratio (only N675xA, N676xA)
:LIMit
:POSitive <NRf>, (@channel)
Calibrates the positive voltage limit (only on N678xA SMU)
:MEASure <NRf>, (@channel)
Calibrates the voltage measurement
:AUXiliary (@channel)
Calibrates the auxiliary voltage measurement (only on N6781A)
DISPlay
[:WINDow]
:CHANnel <channel>
Selects the channel in 1-channel meter view
:VIEW METER1 | METER4
Selects 1-channel or 4-channel meter view
FETCh
(Fetch commands only on N676xA, N678xA SMU and Option 054)
[:SCALar]
:CURRent
[:DC]? (@chanlist)
Returns the average current
:ACDC? (@chanlist)
Returns the total rms current (AC + DC)
:HIGH? (@chanlist)
Returns the high level of a current pulse
:LOW? (@chanlist)
Returns the low level of a current pulse
:MAXimum? (@chanlist)
Returns the maximum current
:MINimum? (@chanlist)
Returns the minimum current

Quick Reference 1
Series N6700 User’s Guide 17
SCPI Command Description
FETCh[:SCALar] (continued)
:POWer
[:DC]? (@chanlist)
Returns the average output power
:VOLTage
[:DC]? (@chanlist)
Returns the average voltage
:ACDC? (@chanlist)
Returns the total rms voltage (AC + DC)
:HIGH? (@chanlist)
Returns the high level of a voltage pulse
:LOW? (@chanlist)
Returns the low level of a voltage pulse
:MAXimum? (@chanlist)
Returns the maximum voltage
:MINimum? (@chanlist)
Returns the minimum voltage
:ARRay
:CURRent [:DC]? (@chanlist)
Returns the instantaneous output current
:POWer [:DC]? (@chanlist)
Returns the instantaneous output power
:VOLTage [:DC]? (@chanlist)
Returns the instantaneous output voltage
:ELOG <NR1>, (@chanlist)
Returns the most recent external data log records
FORMat
[:DATA] ASCII | REAL
Returns data as ASCII or binary
:BORDer NORMal | SWAPped
Sets the byte order of the external data log data
INITiate
[:IMMediate]
(Acquire command only on N676xA, N678xA SMU and Option 054)
:ACQuire (@chanlist)
Enables the measurement system to receive triggers
:ELOG (@chanlist)
Enables external data log measurements
:TRANsient (@chanlist)
Enables the output transient system to receive triggers
:CONTinuous
:TRANsient <Bool>, (@chanlist)
Enables/disables continuous transient triggers
MEASure
[:SCALar]
:CURRent
[:DC]? (@chanlist)
Takes a measurement; returns the average current
:ACDC? (@chanlist)
Takes a measurement; returns the total rms current (AC + DC)
:HIGH? (@chanlist)
Takes a measurement; returns the high level of a current pulse
:LOW? (@chanlist)
Takes a measurement; returns the low level of a current pulse
:MAXimum? (@chanlist)
Takes a measurement, returns the maximum current
:MINimum? (@chanlist)
Takes a measurement, returns the minimum current
:POWer
[:DC]? (@chanlist)
Takes a measurement, returns the average output power
:VOLTage
[:DC]? (@chanlist)
Takes a measurement; returns the average voltage
:ACDC? (@chanlist)
Takes a measurement; returns the total rms voltage (AC + DC)
:HIGH? (@chanlist)
Takes a measurement; returns the high level of a voltage pulse
:LOW? (@chanlist)
Takes a measurement; returns the low level of a voltage pulse
:MAXimum? (@chanlist)
Takes a measurement, returns the maximum voltage
:MINimum? (@chanlist)
Takes a measurement, returns the minimum voltage
:ARRay
(Array commands only on N676xA, N678xA SMU and Option 054)
:CURRent [:DC]? (@chanlist)
Takes a measurement; returns the instantaneous output current
:POWer [:DC]? (@chanlist)
Takes a measurement; returns the instantaneous output power
:VOLTage [:DC]? (@chanlist)
Takes a measurement; returns the instantaneous output voltage

1 Quick Reference
18 Series N6700 User’s Guide
SCPI Command Description
OUTPut
[:STATe] <Bool> [,NORelay], (@chanlist)
Enables/disables the specified output channel(s)
:COUPle
[:STATe] <Bool>
Enables/disables channel coupling for output synchronization
:CHANNel [<NR1> {,<NR1>}]
Selects which channels are coupled
:DOFFset <NRf>
Specifies a maximum delay offset to synchronize output changes
:MAX
:DOFFset?
Returns the maximum delay offset required for a mainframe
:DELay
:FALL <NRf+>, (@chanlist)
Sets the output turn-off sequence delay
:RISE <NRf+>, (@chanlist)
Sets the output turn-on sequence delay
:PMODe VOLTage | CURRent, (@chanlist)
Sets the mode for turn on/off transitions (N6761A, N6762A)
:TMODe HIGHZ | LOWZ, (@chanlist)
Specifies the turn-on/turn-off impedance (only on N678xA SMU)
:INHibit
:MODE LATChing | LIVE | OFF
Sets the remote inhibit input
:PON
:STATe RST | RCL0
Programs the power-on state
:PROTection
:CLEar (@chanlist)
Resets latched protection
:COUPle <Bool>
Enables/disables channel coupling for protection faults
:DELay <NRf+>, (@chanlist)
Sets over-current protection programming delay
:OSCillation <Bool>, (@chanlist)
Enables/disables output oscillation protection (N678xA SMU)
:WDOG
[:STATe] <Bool>
Enables/disables the I/O watchdog timer
:DELay <NRf+>
Sets the watchdog timer delay
:RELay
:POLarity NORMal | REVerse, (@chanlist)
Sets the output relay polarity (Option 760)
SENSe
:CURRent
:CCOMpensate <Bool>, (@chanlist)
Enables/disables the capacitive current compensation
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Selects the current measurement range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A)
:ELOG
:CURRent
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Sets the external data log current range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A)
:FUNCtion
:CURRent <Bool>, (@chanlist)
Enables/disables external current data logging
:MINMax <Bool>, (@chanlist)
Enables/disables external min/max current data logging
:VOLTage <Bool>, (@chanlist)
Enables/disables external voltage data logging
:MINMax <Bool>, (@chanlist)
Enables/disables external min/max voltage data logging
:PERiod <NR1>, (@chanlist)
Sets the integration time of the external data logging
:VOLTage
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Sets the external data log voltage range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A)
:FUNCtion “VOLTage” | ”CURRent” | “NONE”, (@chanlist)
Selects the measurement function (for backward compatibility)
:CURRent <Bool>, (@chanlist)
Enables/disables current measurements (replaces FUNCtion)
:VOLTage <Bool>, (@chanlist)
Enables/disables voltage measurements (replaces FUNCtion)
:INPut MAIN | AUXiliary, (@chanlist)
Selects the voltage measurement input (only on N6781A)

Quick Reference 1
Series N6700 User’s Guide 19
SCPI Command Description
SENSe (continued)
:SWEep
(Sweep commands only on N676xA, N678xA SMU and Option 054)
:OFFSet
:POINts <NRf+>, (@chanlist)
Defines the trigger offset in the measurement sweep
:POINts <NRf+>, (@chanlist)
Defines the number of data points in the measurement
:TINTerval <NRf+>, (@chanlist)
Sets the measurement sample interval
:RESolution RES20 | RES40, (@chanlist)
Sets the measurement resolution
:VOLTage
[:DC]:RANGe
[:UPPer] <NRf+>, (@chanlist)
Selects the voltage measurement range
:AUTO <Bool>, (@chanlist)
Enables/disables measurement autoranging (N6781A, N6782A)
:WINDow
[:TYPE] HANNing | RECTangular, (@chanlist)
Selects measurement window (N676xA, N678xA SMU, Option 054)
[SOURce:]
CURRent
[:LEVel]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the output current
:TRIGgered [:AMPLitude] <NRf+>, (@chanlist)
Sets the triggered output current
:LIMit
[:POSitive]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the positive current limit (only on N678xA SMU, N6783A)
:COUPle <Bool>, (@chanlist)
Sets the current limit tracking state (only on N678xA SMU)
:NEGative
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the negative current limit (only on N678xA SMU, N6783A-BAT)
:MODE FIXed | STEP | LIST, (@chanlist)
Sets the current trigger mode
:PROTection
:DELay
[:TIME] <NRf+>, (@chanlist)
Sets the over-current protection programming delay
:STARt SCHange | CCTRans, (@chanlist)
Sets the over-current protection programming mode
:STATe <Bool>, (@chanlist)
Enables/disables over-current protection on the selected output
:RANGe <NRf+>, (@chanlist)
Sets the output current range
:SLEW
[:IMMediate] <NRf+> | INFinity, (@chanlist)
Sets the output current slew rate (only N678xA SMU)
:MAXimum <Bool>, (@chanlist)
Enables/disables the maximum slew rate override (N678xA SMU)
DIGital
:INPut:DATA?
Reads the state of the digital port pins
:OUTPut:DATA <NRf>
Sets the digital port
:PIN<1-7>
:FUNCtion DIO | DINPut | TOUTput | TINPut | FAULt
| INHibit | ONCouple | OFFCouple
Sets the selected pin’s function
:POLarity POSitive | NEGative
Sets the selected pin’s polarity
:TOUTput
:BUS[:ENABle] <Bool>
Enables/disables BUS-generated triggers on digital pins
FUNCtion CURRent | VOLTage, (@chanlist)
Specifies current priority or voltage priority mode (N678xA SMU)
LIST
(List commands only on N676xA, N678xA SMU and Option 054)
:COUNt <NRf+> | INFinity, (@chanlist)
Sets the list repeat count
:CURRent
[:LEVel] <NRf> {,<NRf>}, (@chanlist)
Sets the current list
:POINts? (@chanlist)
Returns the number of current list points

1 Quick Reference
20 Series N6700 User’s Guide
SCPI Command Description
[SOURce:]LIST:TOUTput (continued)
:DWELl <NRf> {,<NRf>}, (@chanlist)
Sets the list of dwell times
:POINts? (@chanlist)
Returns the number of dwell list points
:STEP ONCE | AUTO, (@chanlist)
Specifies how the list responds to triggers
:TERMinate
:LAST <Bool>, (@chanlist)
Sets the list termination mode
:TOUTput
:BOSTep
[:DATA] <Bool> {,<Bool>}, (@chanlist)
Generate triggers at the Beginning Of Step
:POINts? (@chanlist)
Returns the number of beginning of step list points
:EOSTep
[:DATA] <Bool> {,<Bool>}, (@chanlist)
Generate triggers at the End Of Step
:POINts? (@chanlist)
Returns the number of end of step list points
:VOLTage
[:LEVel] <NRf> {,<NRf>}, (@chanlist)
Sets the voltage list
:POINts? (@chanlist)
Returns the number of voltage level points
POWer
:LIMit <NRf+>, (@chanlist)
Sets the power limit on output channels
RESistance
[:LEVel][:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the output resistance (only on N6781A)
:STATe <Bool>, (@chanlist)
Enables/disables output resistance programming (only N6781A)
STEP
:TOUTput <Bool>, (@chanlist)
Generate a trigger output on the voltage or current step transient
VOLTage
[:LEVel]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the output voltage
:TRIGgered [:AMPLitude] <NRf+>, (@chanlist)
Sets the triggered output voltage
:BWIDth LOW | HIGH1 | HIGH2 | HIGH3, (@chanlist)
Sets the voltage bandwidth (only on N678xA SMU)
:LIMit
[:POSitive]
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the positive voltage limit (only on N678xA SMU)
:COUPle <Bool>, (@chanlist)
Sets the voltage limit tracking state (only on N6784A)
:NEGative
[:IMMediate][:AMPLitude] <NRf+>, (@chanlist)
Sets the negative voltage limit (only on N6784A)
:MODE FIXed | STEP | LIST, (@chanlist)
Sets the voltage trigger mode
:PROTection
[:LEVel] <NRf+>, (@chanlist)
Sets the over-voltage protection level
:DELay[:TIME] <NRf+>, (@chanlist)
Sets the over-voltage protection delay (only on N6783A)
:REMote
[:POSitive][:LEVel] <NRf+>, (@chanlist)
Sets the positive remote OV protection level (only on N678xA SMU)
:NEGative[:LEVel] <NRf+>, (@chanlist)
Sets the negative remote OV protection level (only on N6784A)
:TRACking
(Tracking commands only on Option J01)
[:STATe] <Bool>, (@chanlist)
Enables/disables tracking OVP
:OFFSet <NRf+>, (@chanlist)
Sets the tracking OVP offset
:RANGe <NRf+>, (@chanlist)
Sets the output voltage range
:SLEW
[:IMMediate] <NRf+> | INFinity, (@chanlist)
Sets the output voltage slew rate
:MAXimum <Bool>, (@chanlist)
Enables/disables the maximum slew rate override
