Agilent Technologies 1290 infinity User manual

Agilent Technologies
Agilent 1290 Infinity Pump
Service Kit
Contents
“Overview of 1290 Infinity Pump Service Kit” on
page 2
“Overview of Maintenance parts” on page 2
“Disassembling the Pump Head” on page 3
“Disassembling the Primary Pump Head” on page 5
“Disassembling the Secondary Pump Head” on
page 8
“Assembling the Pump Head” on page 12
Pump Alignment Tool (lower part)
Pump Alignment Tool Handle
Plunger assy
Bit Kit
Pump Alignment Tool
(upper part)
Torque Wrench
2-25Nm

2 Agilent 1290 Infinity Pump Service Kit
Overview of 1290 Infinity Pump Service Kit
Overview of Maintenance parts
Tab le 1 1290 Infinity Pump Service Kit
Description Part Number
Pump Head Alignment Tool 5023-0279
Torque Wrench 2-25Nm G4220-20012
Bit Kit 5023-0282
4 mm hex bit, 89mm legth
2.5 mm hex bit
adapter 1/4 inch square to hex
1290 Infinity Pump Service Kit Note G4220-90120
Tab le 2 Maintenance parts
Description Part Number
Pump Seals PE 0905-1719
Piston 1290 Binary Pump 5067-4603
Gasket (Seal Wash) G4220-20015
Backup Seal PE (Seal Wash) 0905-1718
PTFE frits, 5 er pack 01018-22707
Gold seal 5001-3707
Cap 5042-1346

Agilent 1290 Infinity Pump Service Kit 3
Disassembling the Pump Head
When If parts inside the pump head need to be replaced
Tools required 14mm wrench
4mm Hex key
2.5mm hex bit
Parts required See Ta b l e 2 , “Maintenance parts,” on page 2
NOTE
This procedure describes replacements for the pump heads of channel A.
Replacement for channel B can be done accordingly. The primary pump head
does not have a heat exchanger. Seal wash parts are optional.
1Do NOT switch off the pump. Use your service
user interface, for example Lab Advisor for
bringing the pump to its maintenance
position. In Lab Advisor go to Tools >
Remove/Install Pump Head and follow
instructions given on the screen.
2Close the shut-off valve of the respective
pump channel.
3Remove the flow connection between the
degassing unit and the primary pump head
inlet. Remove the capillary connection at the
top of the secondary pump head to the pump
valve.
DO NOT REMOVE the capillary connection
between the pump heads marked by the red X.
X

4 Agilent 1290 Infinity Pump Service Kit
4Open the 4 screws holding the pump heads.
NOTE
Open all screws step by step, not screw by
screw.
5Open the hex screw at the top of the primary
pump head, which fixes the connection
capillary of the heat exchanger. Then lift up
the capillary and remove it from the primary
pump head..
6Remove both pump heads from the link plate
by pushing the clips at the rear of the plate..
Heat exchanger with
connection capillary
Primary pump head
Link plate
Secondary pump
head
Link plate
Clips

Agilent 1290 Infinity Pump Service Kit 5
Disassembling the Primary Pump Head
Figure 1 Pump Head (with seal wash option)
1 Pump head chamber housing
2 Pump seal
3 Backup ring for seal holder
4 Seal holder
5 Film washer (seal wash)
6 Backup seal PE for seal wash
7 Support ring (seal wash)
8 Pump head ferrule
9 Piston housing
10 Piston
123
4
5
6
7
8
9
10

6 Agilent 1290 Infinity Pump Service Kit
CAUTION
Damage of pump piston
7The pump piston has an excellent stability and chemical resistance inside
the pump head, but it is sensitive to shearing forces from the side.
➔Do not try to remove the pump piston from the rear.
➔Do not use the piston for removing pump seals.
1Remove the outlet valve at the top of the pump
head and the inlet valve at the bottom of the
pump head..
2For disassembling the pump head, open the 4
hex screws and remove screws at the rear of
the pump head.

Agilent 1290 Infinity Pump Service Kit 7
3Remove the front part of the pump head
including pump chamber housing with pump
seal and support ring. If the seal wash option
is installed, also remove the seal holder with
backup seal and gasket.
•Make sure, that the backup ring inside the
seal holder does not drop out. Do not
remove it from the holder..
4Remove the piston from the piston housing by
pushing it to the rear, then pull it out from the
rear..
5Use the insert tool of the pump head
alignment tool for removing the pump seal
from the pump chamber housing.
•Do not use the pump piston for that
purpose!
6If the wash seal shall be replaced by a new
one, use a screw driver for removing it.
Pump seal
Support ring
Pump chamber
housing
Seal holder with backup ring
Gasket (seal wash)
Wash seal PE for seal wash
Wash seal

8 Agilent 1290 Infinity Pump Service Kit
Disassembling the Secondary Pump Head
CAUTION
Loss of small spacer fitting
Inside the secondary pump head is a small spacer fitting, which
can be dropped easily when removing the heat exchanger.
➔Be careful when removing the heat exchanger.
CAUTION
Damage of pump piston
The pump piston has an excellent stability and chemical
resistance inside the pump head, but it is sensitive to shearing
forces from the side.
➔Do not try to remove the pump piston from the rear.
➔Do not use the piston for removing pump seals.

Agilent 1290 Infinity Pump Service Kit 9
8
1 Pump head screw
2 Pump head front plate
3 Heat exchanger (primary pump head only)
4 Pump chamber housing
5 Spacer fitting
6 Pump head hex screw
7Pumpseal
8 Backup ring for seal holder
9 Seal holder
10 Gasket (seal wash)
11 Wash Seal PE (seal wash)
12 Support ring (seal wash)
13 Piston housing
1
11
2
3
6
5
478
910
12
13

10 Agilent 1290 Infinity Pump Service Kit
1Remove the filter assembly at the top of the
pump head. See Agilent 1290 Infinity Binary
Pump User Manual for replacing the filter frit..
2For disassembling the pump head, open the 4
hex screws at the rear of the pump head..
3Remove the front part of the pump head
including pump chamber housing with pump
seal and support ring. If the seal wash option
is installed, also remove the seal holder with
backup seal and gasket.
•Make sure, that the backup ring inside the
seal holder does not drop out. Do not
remove it from the holder..
4Remove the piston from the piston housing by
pushing it to the rear, then pull it out from the
rear..
Pump seal
Support ring
Pump chamber
housing
Seal holder with backup ring
Gasket (seal wash)
Wash seal PE for seal wash

Agilent 1290 Infinity Pump Service Kit 11
5Use the insert tool of the pump head
alignment tool for removing the pump seal
from the pump chamber housing.
•Do not use the pump piston for that
purpose!
6If the wash seal shall be replaced by a new
one, use a screw driver for removing it.
Wash seal

12 Agilent 1290 Infinity Pump Service Kit
Assembling the Pump Head
When Befor installing the pump.
Tools required 5023-0279 Pump Head Alignment Tool
G4220-20012 Torque wrench 2-25 Nm
01018-23702 Insert Tool
G4220-20013 4 mm Hex bit
G4220-20015 Adapter ¼ square to hex
CAUTION
Limited life time of the pump head
Inserting the backup seal wrongly may limit the life time of the
pump.
Please note the correct orientation of the backup seal.
CAUTION
Damage of the pump piston
The pump piston is sensitive to shearing foces from the side.
Use the Plunger assy of the pump head alignment tool for the
alignment procedure described below.
1Insert the pump seal to the pump chamber
housing.
2If the seal wash option is installed, use the
insert tool for inserting the wash seal to the
support ring.
Seal
Insert tool
Support ring
Seal

Agilent 1290 Infinity Pump Service Kit 13
3If the backup seal has been removed from the
seal holder, insert it in the correct orientation
as shown below. Ensure that the cut end faces
the seal holder..
4If the seal wash option is installed, put the
gasket into the support ring and insert the seal
holder..
5Insert the support ring and pump head ferrules
into the piston housing. Assemble the pump
head by putting the pump chamber housing on
top of the support ring.
6Loosely close the 4 screws at the rear of the
pump head. The screws will be fixed tightly
later. Then insert the plunger assy..
Cut end
Link plate
Backup seal
Gasket
Seal holder
Support ring
Piston housing
Support ring
Pump hesd ferrules
Pump chamber housing
Plunger assy

14 Agilent 1290 Infinity Pump Service Kit
7Insert the primary or secondary pump head to
the pump head alignment tool. There are
openings for the seal wash support ring and
heat exchanger of the secondary pump head.
8Close the tool by closing the 3 screws at the
connection ring.
9Using a torque key, set 5 Nm and close the
screw at the front of the pump head alignment
tool. Then close the 4 screws at the rear of the
pump head with 5 Nm.
NOTE
This procedure will align pump head parts to their
correctpositions and close the pump head tightly.
Pump head alignement tool (rear)
Pump head (secondary)
Pump head alignment tool
(front)
Heat exchanger
capillary
5 Nm
5 Nm
front
rear

Agilent 1290 Infinity Pump Service Kit 15
10 Open the 3 screws which have closed the
pump head alignment tool and take out the
aligned pump head.
11 For the primary pump head, install the inlet
valve and outlet valve.
12 For the secondary pump head, assemble and
install the outlet valve as shown.
13 Remove plunger assy..
Heat exchanger capillary

© Agilent Technologies 2010
Part Number: G4220-90120
*G4220-90120*
*G4220-90120*
Edition: 04/10
Printed in Germany
Agilent Technologies
Hewlett-Packard-Strasse 8
76337 Waldbronn
14 Insert pump piston 15 Insert both pump heads in the link plate and
make sure that the clips snap in that fix the
pump heads.
16 Insert the heat exchanger capillary into the
outlet of the primary pump head. Using a
torque key, set 3 Nm and close the hex screw
at the top of the outlet.
17 Install the pump head assembly and install
flow connections as described in Replacing
the pump heads, discribed in the user Manual.
Pump piston
Link plate
Clips
