Agilent Technologies
Agilent Digital Test
Console
Installation Guide

Notices
© Agilent Technologies, Inc. 2009- 2011
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or transla-
tion into a foreign language) without prior
agreement and written consent from Agi-
lent Technologies, Inc. as governed by
United States and international copyright
laws.
Warranty
The material contained in this docu-
ment is provided “as is,” and is sub-
ject to being changed, without notice,
in future editions. Further, to the max-
imum extent permitted by applicable
law, Agilent disclaims all warranties,
either express or implied, with regard
to this manual and any information
contained herein, including but not
limited to the implied warranties of
merchantability and fitness for a par-
ticular purpose. Agilent shall not be
liable for errors or for incidental or
consequential damages in connection
with the furnishing, use, or perfor-
mance of this document or of any
information contained herein. Should
Agilent and the user have a separate
written agreement with warranty
terms covering the material in this
document that conflict with these
terms, the warranty terms in the sep-
arate agreement shall control.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license.
Restricted Rights Legend
If software is for use in the performance of
a U.S. Government prime contract or sub-
contract, Software is delivered and
licensed as “Commercial computer soft-
ware” as defined in DFAR 252.227-7014
(June 1995), or as a “commercial item” as
defined in FAR 2.101(a) or as “Restricted
computer software” as defined in FAR
52.227-19 (June 1987) or any equivalent
agency regulation or contract clause. Use,
duplication or disclosure of Software is
subject to Agilent Technologies’ standard
commercial license terms, and non-DOD
Departments and Agencies of the U.S. Gov-
ernment will receive no greater than
Restricted Rights as defined in FAR
52.227-19(c)(1-2) (June 1987). U.S. Govern-
ment users will receive no greater than
Limited Rights as defined in FAR 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Manual Notices
This manual provides these notices:
CAUTION
A CAUTION notice denotes a haz-
ard. It calls attention to an operat-
ing procedure, practice, or the like
that, if not correctly performed or
adhered to, could result in damage
to the product or loss of important
data. Do not proceed beyond a
CAUTION notice until the indicated
conditions are fully understood and
met.
WARNING
A WARNING notice denotes a
hazard. It calls attention to an
operating procedure, practice, or
the like that, if not correctly per-
formed or adhered to, could result
in personal injury or death. Do not
proceed beyond a WARNING
notice until the indicated condi-
tions are fully understood and met.
Manual Part Number
U4002-97004
Edition
Third Edition, January 2011
Agilent Technologies, Inc.
1900 Garden of the Gods Road
Colorado Springs, CO 80907 USA

Certification
For specific information on regulatory com-
pliance, refer to the Declarations of Confor-
mity for the chassis and blades.
Agilent Technologies certifies that this
product met its published specifications at
the time of shipment from the factory. Agi-
lent Technologies further certifies that its
calibration measurements are traceable to
the United States National Institute of
Standards and Technology to the extent
allowed by that organization's calibration
facility, and to the calibration facilities of
other International Standards Organization
members.
Additional Information for Test and Mea-
surement Equipment
To comply with EMC regulations, supplied
or recommended cables must be used on
all appropriate connections. Otherwise, the
user has to ensure that, under operating
conditions, the Radio Interference Limits
are still met at the border of the user's
premises.
To ensure continued compliance to radi-
ated emissions standards, all RJ45 connec-
tions must be made using shielded
Category 5 (STP) cables.
Warnings
The following general safety precautions
must be observed during all phases of oper-
ation, service, and repair of this product.
Failure to comply with these precautions or
with specific warnings elsewhere in this
manual violates safety standards of design,
manufacture, and intended use of the prod-
uct. Agilent Technologies assumes no lia-
bility for the customer's failure to comply
with these requirements.
Ground the Equipment: For safety, Class 1
equipment (equipment having a protective
earth terminal), an uninterruptible safety
ground must be provided from the mains
power source to the product input wiring
terminals or supplied power cable. Before
operating the equipment, guard against
electric shock in case of fault by always
using the provided 3-conductor power
cords to connect the equipment to a
grounded power outlet.
DO NOT use in hazardous environments:
Do not operate the product in an explosive
atmosphere or in the presence of flamma-
ble gases or fumes. This product is
designed for indoor use only.
Keep away from live circuits: Operating
personnel must not remove equipment cov-
ers or shields. Procedures involving the
removal of covers and shields are for use
by service-trained personnel only. Under
certain conditions, dangerous voltages may
exist even with the equipment switched
off. To avoid dangerous electrical shock, DO
NOT perform procedures involving cover or
shield removal unless you are qualified to
do so.
DO NOT operate damaged equipment:
Whenever it is possible that the safety pro-
tection features built into this product have
been impaired, either through physical
damage, excessive moisture, or any other
reason, REMOVE POWER and do not use
the product until safe operation can be ver-
ified by service-trained personnel. If neces-
sary, return the product to an Agilent
Technologies Sales and Service Office for
service and repair to ensure the safety fea-
tures are maintained.
DO NOT substitute parts or modify equip-
ment: Because of the danger of introducing
additional hazards, do not install substitute
parts or perform any unauthorized modifi-
cation to the product. Return the product to
an Agilent Technologies Sales and Service
Office for service and repair to ensure fea-
tures are maintained.
DO NOT clean with fluids: Doing so may
make the equipment unsafe for use. Power
down the equipment and disconnect the
power cord before cleaning. To clean, use a
soft dry cloth.
DO NOT block the primary disconnect: The
primary disconnect device is the appliance
connector/power cord when a chassis
used by itself, but when installed into a
rack or system the disconnect may be
impaired and must be considered part of
the installation.
Blades can become hot during use: DO
NOT touch any of the components on a
blade as you remove it from the chassis.
Beware especially of the power module,
which is situated at the rear of the blade.
Cautions
Do NOT block vents: To ensure adequate
cooling and ventilation, leave a gap of at
least 50mm (2") around all vent holes.
Do NOT operate with empty slots: To
ensure proper cooling and avoid damaging
equipment, fill any empty slots with the
filler blade, Part Number N5650-00080.
Do NOT stack more than the recom-
mended number of free-standing chassis:
With the U4002A 2-slot chassis, do not
stack more than five chassis.
All RFI gaskets must remain in place: Any
damaged gaskets must be replaced.
All blades are grounded through the chas-
sis: During installation, tighten the blade's
retaining screws to secure the blade to the
chassis and to make the ground connec-
tion.

Safety Symbols
Products display the following symbols:
If you see this symbol on a product, you
must refer to this guide for specific Warn-
ing or Caution information to avoid per-
sonal injury or damage to the product.
Indicates the field wiring terminal that
must be connected to ground before oper-
ating the equipment. Protects against elec-
trical shock in case of fault.
Frame or chassis ground terminal. Typically
connects to the equipment's metal frame.
Alternating current (AC).
Direct current (DC).
Standby. This device is not completely dis-
connected from the AC mains when its
power switch is off.
Indicates hazardous voltages and potential
for electrical shock.
Indicates that antistatic precautions should
be taken.
Operate the U4002A 2-slot chassis in the
horizontal orientation. Do NOT operate this
chassis in the vertical orientation.
!
o
The CSA mark is a registered trademark of
the Canadian Standards Association and
indicates compliance to the standards laid
out by them. Refer to the product Declara-
tion of Conformity for details.
Notice for European Community: This prod-
uct complies with the relevant European
legal Directives: EMC Directive
(2004/108/EC) and Low Voltage Directive
(2006/95/EC).
Notice for the European Community: This
product complies with the WEEE Directive
(2002/96/EC) marking requirements. The
affixed label indicates that you must not
discard this electrical/electronic product in
domestic household waste. Product Cate-
gory: With reference to the equipment
types in the WEEE Directive Annex I, this
product is classed as a “Monitoring and
Control instrumentation” product.
Do not dispose in domestic household
waste. To return unwanted products, con-
tact your local Agilent office or get more
information from www.agilent.com/envi-
ronment/product.
This is the symbol for an Industrial, Scien-
tific, and Medical Group 1 Class A product.
The C-tick mark is a registered trademark of
the Spectrum Management Agency of Aus-
tralia. This signifies compliance with the
Australia EMC Framework regulations
under the terms of the Radio Communica-
tion Act of 1992.
ICES/NMB-001 indicates that this ISM
device complies with the Canadian
ICES-001.
ISM

Agilent Digital Test Console Installation Guide 5
Contents
1 Introduction
About the Agilent Digital Test Console 8
U4002A 2-Slot Chassis 8
Chassis Manager 9
System Controller 10
Application Blade 11
2 Hardware Installation
Overview 14
Step 1: Plan the installation 15
Power 15
Rackmounting 15
Ventilation 16
Static Electricity 16
To manage cables 17
Step 2: Set up the U4002A 2-slot chassis 18
To rackmount the U4002A 2-slot chassis 18
To set up a portable U4002A 2-slot chassis 20
Step 3: Insert and remove blades 22
To insert a blade into the chassis 23
To remove a blade from the chassis 25
Step 4: Set up a system controller 26
To set up a laptop controller 26
Step 5: Power up the system 27
To power up the U4002A 2-slot chassis 27
To power down the chassis 28
Step 6: Troubleshoot problems 29
To troubleshoot powerup problems 29
To diagnose LEDs 30

6 Agilent Digital Test Console Installation Guide
3 Software Installation
4 For More Information
On the U4301A PCIe Analyzer Blade 34
On the U4998A HDMI Tester Blade 35
5 Characteristics
Standards 38
Environmental 38
Electrical 38
Mechanical 39
Calibration 39
Connectors 40
Chassis Manager 40
To contact us ... 41
Index

7
Agilent Digital Test Console
Installation Guide
Agilent Technologies
1
Introduction
About the Agilent Digital Test Console 8
U4002A 2-Slot Chassis 8
Chassis Manager 9
System Controller 10
Application Blade 11

8 Agilent Digital Test Console Installation Guide
1Introduction
About the Agilent Digital Test Console
The Agilent Digital Test Console is a modular and scalable test system that
supports complex, high-density testing. The platform includes a
general-purpose chassis, chassis manager, and application-specific blades.
Multiple chassis can be connected and managed by a central system
controller running a variety of test applications.
These chassis models are available:
•U4002A — a portable 2-slot chassis
U4002A 2-Slot Chassis
Designed for portable or small system testing, the U4002A 2-slot chassis
comes with the following:
•a removable plastic handle
•optional transit case
•rackmount brackets for lab installation
The components on a U4002A 2-slot chassis are as follows:
Agilent Technologies
U4002A 2-Slot Chassis
Agilent Digital Test
Console
Power inlet
back
Circuit breaker
front
2
1
Agilent Technologies
U4002A 2-Slot Chassis
Agilent Digital Test
Console
2
1
Power
button
Grounding
terminal
Fan
Slots
The bottom half-width slot is for the chassis manager;
the other two slots are for application blades.
Backplane
Provides a Gigabit Ethernet interface, synchronizes
timing signals, and distributes power for all blades.

Introduction 1
Agilent Digital Test Console Installation Guide 9
Chassis Manager
The chassis manager performs the following functions:
•tracks inserted blades, manages blade power
•monitors chassis temperature, controls variable-speed chassis fans
•monitors blade sensors, reports component failures to a system log
•acts as a Gigabit Ethernet switch, forwards frames along the backplane
•connects to other chassis through a Gigabit Ethernet network
•synchronizes timing across all blades through an Agilent Test Bus
•synchronizes timing with an internal or external clock source
The chassis manager is factory-installed into the bottom slot of the
U4002A 2-slot chassis. This chassis managers is available:
•U4002-00101 — Chassis manager with PCIe and USB.
STATUS
OUT
EXT
CHASSIS
MANAGER
U4002-00101
IN
PCIe
USB
AGILENT
TEST BUS
TRIGGER
IN
OUT
CLOCK
RS232
LAN 1
LINK ACT
LINK ACT
LAN 2
IN
OUT
PCIe (x4, Gen1 and Gen2 compliant)
(Available on U4002-00101) Connects an external system controller to the chassis via PCIe.
USB
(Available on U4002-00101) Not supported in intitial release.
Agilent Test Bus
Synchronizes timing signals with multiple daisy-chained chassis.
•IN—Gets timing signals from the previous chassis. If this chassis is at the head of the chain, the chassis
becomes the master, using an internal or external clock to send timing signals to other chassis in the chain.
•OUT—Provides timing signals to the next chassis.
•EXT—(not used).
Trigger
Connects external trigger devices.
Clock
Connects external clocks.
RS232
For Agilent use only; do not connect any serial devices. Enables Agilent personnel to do local diagnostics.
LAN 1 & 2 (not used)
Status
Indicates the status of the chassis manager: For operational details, see “To diagnose LEDs" on page 30.
Agilent

10 Agilent Digital Test Console Installation Guide
1Introduction
System Controller
The Agilent Digital Test Console requires a system controller PC. A system
controller centrally configures and reports test results from multiple
chassis.
The system controller PC communicates with a chassis via the chassis
manager’s PCIe interface, so the system controller must have a PCIe
interface.
The system controller is typically a laptop PC with an ExpressCard PCIe
adapter, but it could also be a desktop PC ar any other PC with a PCIe
interface.

Introduction 1
Agilent Digital Test Console Installation Guide 11
Application Blade
An application blade connects to a System Under Test (SUT), injects test
data, and makes real-time measurements. Application blades in the Agilent
Digital Test Console have the following common components:
0101
OOS (Out of Service)
Indicates blade health:
•red, steady—The blade detected a failure, for example, an unsuccessful bootup test or corrupted firmware.
To diagnose problems, see “To diagnose LEDs" on page 30.
•off—The blade detects no failures.
Display
(Optional) Provides status information about the blade:
•During bootup—May indicate the bootup progress to enable fast diagnostics if a blade experiences a
problem.
•After bootup—Identifies the following:
•chassis number (two digits)—The number starts at 1. If there are multiple, daisy-chained chassis, the
number is 1 for the chassis at the head of the chain, and increments by 1 for each chassis in the chain.
•slot number (two digits)—Starts at 1 for the slot next to the chassis manager, and increments by 1 for
each slot to the right.
•During operation—Identifies each active test session and its associated ports, by scrolling text across the
display (right to left) at least once per minute.
Ports
Connect to the DUT.
Serial Number (On Top)
Uniquely identifies the blade. When contacting Agilent support, report this number so that any manufacturing
information or past servicing associated with the blade can be noted. The serial number is also provided in a
Code 128 bar code for inventory purposes.
Reset Button
(Optional) Gracefully reboots a blade. If a blade does not provide this button, you can reboot the blade by
removing the blade from the chassis then re-inserting the blade. However, while doing this, ensure that the
blade is not powered on.
Blade Description
Identifies the blade’s product number, title, and class. When contacting Agilent support, report this information.
Ejector Levers (top and bottom)
Releases the blade from the chassis. For details, see “To remove a blade from the chassis" on page 25.

12 Agilent Digital Test Console Installation Guide
1Introduction

13
Agilent Digital Test Console
Installation Guide
Agilent Technologies
2
Hardware Installation
Overview 14
Step 1: Plan the installation 15
Step 2: Set up the U4002A 2-slot chassis 18
Step 3: Insert and remove blades 22
Step 4: Set up a system controller 26
Step 5: Power up the system 27
Step 6: Troubleshoot problems 29

14 Agilent Digital Test Console Installation Guide
2Hardware Installation
Overview
Step 1: Plan the installation.
Consider the power, rackmounting, and ventilation requirements of the
system.
Step 2: Set up the U4002A 2-slot chassis.
If you are using the U4002A 2-slot chassis in a portable application,
attach the plastic bumpers and handle. If you are using it in a lab,
attach the rackmount brackets and mount onto a rack.
Step 3: Insert blades.
Insert any application blades that are not already in the chassis,
ensuring that empty slots have filler blades.
Step 4: Set up a system controller.
Connect an external system controller to the chassis manager’s PCIe
interface.
Step 5: Power up the system.
Attach the power cords, switch the circuit breakers on, and press the
power buttons on the chassis.

Hardware Installation 2
Agilent Digital Test Console Installation Guide 15
Step 1: Plan the installation
Power
For the power requirements of the chassis, see “Electrical" on page 38.
Rackmounting
The following rackmounting options are possible:
• 4-post rack—With the U4002A 2-slot chassis, the brackets are provided
separately (N5650-00035) and must be attached to the chassis before
rackmounting.
• 4-post shelf—You can order a kit (E3664AC), which provides rails that
attach to the front and back posts in a 4-post rack, forming a shelf
onto which you can slide the chassis. You can then secure the chassis
onto the front two posts using the chassis brackets.
• 2-post rack—You can front-mount a chassis into a telecom-style 19”
2-post rack.
The bottom chassis becomes the head of the chain. Position the system
controller near the head chassis at the bottom of the chain.
When connecting other chassis to the chain, add them to the top of the
chain, such that an Agilent Digital Test Console chassis is at the bottom
and serves as the master controlling the entire chain.
WARNING
Before installing equipment, always review your corporate
safety policies and consult with your lab manager to avoid
equipment damage and personal injury.
WARNING
Avoid overloading an electrical circuit.
In case you need to power down the chassis in an emergency,
make sure that you have clear and quick access to the primary
disconnect. If the chassis is rackmounted, this primary
disconnect can be a power system on the rack and not the
power button or circuit breaker on a chassis.
WARNING
Always install the heaviest equipment at the bottom of a rack
and deploy anti-tip and anti-rolling mechanisms on the rack.

16 Agilent Digital Test Console Installation Guide
2Hardware Installation
Ventilation
Static Electricity
CAUTION
Do not block the vent holes on the chassis. This overheats and
damages their components. Leave a gap of at least 2” (50mm)
around all vent holes.
CAUTION
Do not place multiple chassis side-by-side. This feeds exhaust air
from one chassis into the air intake of the other chassis and
overheats and damages components. Stack multiple chassis on
top of each other.
CAUTION
The components and connectors on blades are sensitive to static
electricity. To minimize electrostatic damage, take the necessary
anti-static precautions. Both chassis provide a grounding
terminal, to which you can connect a wrist strap. To locate this
terminal, see “U4002A 2-Slot Chassis" on page 8.

Hardware Installation 2
Agilent Digital Test Console Installation Guide 17
To manage cables
The Agilent Digital Test Console has high-density blades that provide many
connectors, each of which can have an attached cable. To facilitate the
insertion and removal of blades, neatly route cables around the chassis.
Doing this enables you to insert and remove blades without having to
navigate a web of cables crossing the fronts of blades.
Each chassis includes cable ties, which are secured onto the rackmount
brackets. Use these ties to bundle and route cables:
To minimize having cables cross in front of blades, locate blades that are
not often removed in the bottom slots. This leaves the top slots free for
frequently inserted and removed blades.
|O|O|

18 Agilent Digital Test Console Installation Guide
2Hardware Installation
Step 2: Set up the U4002A 2-slot chassis
To rackmount the U4002A 2-slot chassis
The U4002A 2-slot chassis ships with plastic bumpers that slide onto the
front and back of the chassis, and a handle that attaches to the bumpers
on the left side of the chassis. To rackmount the chassis, you must remove
the bumpers first.
To remove the bumpers
1Place the chassis on its side with the handle oriented upwards.
2Use a Phillips screwdriver to remove the two screws securing the
handle.
3Use a Phillips screwdriver to remove the four screws securing the front
bumper to the chassis.
4Slide the front bumper off the chassis.
5Repeat steps 3 to 4 for the rear bumper.

Hardware Installation 2
Agilent Digital Test Console Installation Guide 19
To attach the 2-slot brackets
The U4002A 2-slot chassis ships with brackets (N5650-00035) that attach
to the sides of the chassis and front two posts of a 4-post rack.
1Use a Torx T10 screwdriver with a torque of 1.37 Nm or 14 kgf-cm
(12.15 lbs-in) to attach the two rackmount brackets to both sides of the
chassis.
2Position the U4002A 2-slot chassis in the 19” rack.
3Secure the chassis to the rack using four screws that are appropriate
for the rack.
