Agilent Technologies E7474A User manual

Agilent Technologies
E7473A, E7474A, E7475A,
E7476A, E7477A, E7490A
Drive Test Wireless Solutions
Getting Started Guide

*HWWLQJ6WDUWHG*XLGH
$JLOHQW7HFKQRORJLHV($($
($($($($
'ULYH7HVW:LUHOHVV6ROXWLRQV
e74xx_gsg.book Page 1 Tuesday, September 26, 2000 10:51 AM

Agilent Wireless Solutions 2
Manual part number
E7474-90035
Edition/Print Date
All Editions and Updates of this
manual and their creation dates
are listed below.
Notices
Copyright © Agilent
Technologies, Inc 1997, 1998,
1999, 2000 All Rights
Reserved.
No part of this manual may be
reproduced in any form or by
any means (including electronic
storage and retrieval or
translation into a foreign
language) without prior
agreement and written consent
from Agilent Technologies, Inc.
as governed by United States
and international copyright
laws.
Trademarks
ArcView ® is a registered
trademark of Environmental
Systems Research Institute, Inc.
MapInfo ® is a registered
trademark of MapInfo
Corporation.
Pentium ® is a registered
trademark of Intel Corporation.
PlaNET ® is a registered
trademark of Mobile Systems
International.
Adobe ® is a trademark of
Adobe Systems Incorporated.
Windows NT ® and
Windows 95 ® and
Windows 98 ® are U.S.
registered trademarks of
Microsoft Corporation.
Hewlett-Packard ® is a
registered trademark of
Hewlett-Packard Limited.
Warranty
The material contained in this
document is subject to change
without notice. Agilent
Technologies makes no
warranty of any kind with
regard to this material,
including, but not limited to, the
implied warranties of
merchantability and fitness for a
particular purpose. Agilent
Technologies shall not be liable
for errors contained herein or
for incidental or consequential
damages in connection with the
furnishing, performance, or use
of this material.
Technology Licenses Notice
The Hardware and/or Software
described in this document are
furnished under a license and
may be used or copied only in
accordance with the terms of
such license.
Restricted Rights Legend
If Software is for use in the
performance of a U.S.
Government prime contract or
subcontract, Software is
delivered and licensed as
“Commercial computer
software” as defined in DFAR
252.227-7014 (June 1995), or as
a “commercial item” as defined
in FAR 2.101(a) or as
“Restricted computer software”
as defined in FAR 52.227-19
(June 1987) or any equivalent
agency regulation or contract
clause. Use, duplication or
disclosure of Software is subject
to Agilent Technologies’
standard commercial license
terms, and non-DOD
Departments and Agencies of
the U.S. Government will
receive no greater than
Restricted Rights as defined in
FAR 52.227-19(c)(1-2) (June
1987). U.S. Government users
will receive no greater than
Limited Rights as defined in
FAR 52.227-14 (June 1987) or
DFAR 252.227-7015 (b)(2)
(November 1995), as applicable
in any technical data.
Agilent Technologies
1400 Fountaingrove Parkway
Santa Rosa, CA 95403-1799
First Edition March 2000
Second Edition September 2000
e74xx_gsg.book Page 2 Tuesday, September 26, 2000 10:51 AM

3 Agilent Wireless Solutions
Safety and Regulatory Information
Safety and Regulatory Information
Review this product and related documentation to familiarize yourself with
safety markings and instructions before you operate the system. This product
has been designed and tested in accordance with appropriate international
standards.
For more details on Safety and Regulatory Information, refer to “Safety and
Regulatory Information” on page 177
MUST READ FIRST
WARNING The WARNING notice denotes a hazard. It calls attention to a procedure,
practice,or thelike, that,if notcorrectlyperformedor adhered to,could resultin
personal injury. Do not proceed beyond a WARNING notice until the indicated
conditions are fully understood and met.
CAUTION The CAUTION notice denotes a hazard. It calls attention to an operating
procedure, practice, or the like, which, if not correctly performed or adhered
to, could result in damage to the product or loss of important data. Do not
proceed beyond a CAUTION notice until the indicated conditions are fully
understood and met.
e74xx_gsg.book Page 3 Tuesday, September 26, 2000 10:51 AM

Agilent Wireless Solutions 5
Welcome to Your Agilent Wireless Solutions
Welcome to Your Agilent Wireless Solutions
Thank you for choosing Agilent Technologies, Inc. In this getting started
guide, you’ll find the setup instructions you need to begin taking
measurements.
Follow These Steps
If You Need Help...
To Do This See This And Check This
Install the software. Chapter 1, “Installing the
Software” If you have purchased a computer from Agilent with yoursystem, the software
came pre-installed. Go to step 2.
Set up your system. Chapter 2, “Setting Up
Your System” You’ll find all system configuration information, including GPS (Global
Positioning System) setup here.
Verify the system. Chapter 4, “Verifying the
System” Perform these tests to ensure that your system is ready to make measurements.
Start the software. Chapter 3, “Starting and
Learning to Use the
Software”
An online tutorial and online help instruct
you how to use your system.
To Do This... See This
Get training http://agilent.com/find/networks
Check the web site for information about training registration, software
updates, phone support, FAQs, and more.
Get help Chapter 5, “Solving Problems and Updating Your System”
Find GPS installation tips and more.
Once you start the software, press F1 to use the extensive help system.
Check specification or
confirm the contents of
your system.
Agilent System Information Guide for your specific system number.
e74xx_gsg.book Page 5 Tuesday, September 26, 2000 10:51 AM

6 Agilent Wireless Solutions
Welcome to Your Agilent Wireless Solutions
Online Getting Started Guide
If you would like an additional copy of this Guide, check the following web
site for the latest PDF1version:
http://agilent.com/find/manuals and then search for your system type
This PDF version has also been loaded with your application software, if you
chose the typical installation. For more information on accessing this and
other online documentation, refer to “Additional Documentation” on
page 131.
Systems Covered by this Guide
The following table outlines the wireless solutions covered by this guide. For
more detailed lists of system options and accessories, refer to the
Agilent System Information Guide. This guide has been loaded with your
application, if you chose the typical installation. For more information on
accessing this guide and other online documentation, refer to “Additional
Documentation” on page 131.
1. Portable Document Format - online version that can be viewed using Adobe ®
Acrobat reader.
For more information about this reader, refer to http://www.adobe.com
System Part Number Description
Agilent E7473A CDMA Cellular and PCS Network Test System
Agilent E7474A TDMA Cellular and PCS Network Test System
Agilent E7475A GSM900, DCS1800 and GSM1900 Network Test Systems
Agilent E7476A W-CDMA (UMTS) Network Test Systems
Agilent E7477A CDMA 2000 Network Test Systems
Agilent E7490A CDMA Base Station Over Air Maintenance Test System
e74xx_gsg.book Page 6 Tuesday, September 26, 2000 10:51 AM

Contents
7
Safety and Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
MUST READ FIRST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Welcome to Your Agilent Wireless Solutions . . . . . . . . . . . . . . . . . . . . . . . 5
1. Installing the Software
What You’ll Find in This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Read This First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Follow These Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Agilent Technologies License Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Installing Adobe Reader . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installing Socket PCMCIA I/O Card Software . . . . . . . . . . . . . . . . . . . . . . 17
2. Setting Up Your System
What You’ll Find in This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Hardware Installation Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Automatic Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Connecting the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Receiver-Based System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Trimble Placer GPS/DR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Trimble Placer GPS 400 or SVeeSix . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Trimble Placer GPS 455 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Trimble Placer GPS 455 & Differential . . . . . . . . . . . . . . . . . . . . . . . . 40
Internal GPS & Internal GPS with Differential Setup . . . . . . . . . . . . . 44
Trimble Placer GPS 455 with Dead Reckoning . . . . . . . . . . . . . . . . . . 46
Receiver and Phone-Based System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Trimble Placer GPS/DR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Trimble Placer GPS 400 or SVeeSix . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Trimble Placer GPS 455 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Trimble Placer GPS 455 & Differential . . . . . . . . . . . . . . . . . . . . . . . . 62
Internal GPS & Internal GPS with Differential . . . . . . . . . . . . . . . . . . 66
Trimble Placer GPS 455 with Dead Reckoning . . . . . . . . . . . . . . . . . . 68
Phone-Based System Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
e74xx_gsg.book Page 7 Tuesday, September 26, 2000 10:51 AM

8 Agilent Wireless Solutions
Trimble Placer GPS/DR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Trimble Placer GPS 400 or SVeeSix . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Trimble Placer GPS 455 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Trimble Placer GPS 455 & Differential . . . . . . . . . . . . . . . . . . . . . . . . 84
Trimble Placer GPS 455 with Dead Reckoning . . . . . . . . . . . . . . . . . . 88
Configuring Multiple Receivers and Phones . . . . . . . . . . . . . . . . . . . . . . . . 92
Multiple Receivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Multiple Phones (Option 150) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Multiple Receivers and Phones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Universal Serial Bus (USB), 4-port Adapter Configuration . . . . . . . . . . . 105
Receiver Connector Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Internal GPS Receiver Connector Panel . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Receiver to PC Serial Port Cable Configuration . . . . . . . . . . . . . . . . . . . . 109
RS-232 to GPS Unit Cable Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 110
RS-232 to Differential Unit Cable Configuration . . . . . . . . . . . . . . . . . . . 111
RX Loop In/Out Cable Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Pulse Trigger Device Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Mounting the Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
3. Starting and Learning to Use the Software
What You’ll Find in This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Starting the Agilent Wireless Solutions Software . . . . . . . . . . . . . . . . . . . 119
Selecting GPS Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Using the Online Tutorial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Run the Tutorial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
After the Tutorial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Using Online Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
Run the Online Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Using the License Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Starting the License Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Learning the License Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Transferring Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129
Additional Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Location of Online Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Viewing and Printing Online Documents . . . . . . . . . . . . . . . . . . . . . . 132
e74xx_gsg.book Page 8 Tuesday, September 26, 2000 10:51 AM

Agilent Wireless Solutions 9
4. Verifying the System
What You Will Find In This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
Method 1: Using a Signal Generator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Preparing the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Preparing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Testing the Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Passing the Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Method 2: Measuring a Known Channel in the System . . . . . . . . . . . . . . 144
Preparing the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Preparing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Testing the Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Passing the Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Method 3: Measuring the Noise Floor . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
Preparing the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Preparing the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Passing the Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Method 4: GPS Measurement Verification Procedure . . . . . . . . . . . . . . . 152
Setting Up the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
Selecting the Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Passing the Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
5. Solving Problems and Updating Your System
What You’ll Find in This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
Troubleshooting Resource, GPS, or, COM Errors Problems . . . . . . . . . . 159
Resource Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
COM Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Locating and Eliminating GPS Errors . . . . . . . . . . . . . . . . . . . . . . . . 164
Updating the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
Updating the Firmware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
Replacement Firmware Security Key . . . . . . . . . . . . . . . . . . . . . . . . . 169
Calling for Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
If You Have a Problem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Technical Telephone Assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Returning the Instrument for Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
e74xx_gsg.book Page 9 Tuesday, September 26, 2000 10:51 AM

10 Agilent Wireless Solutions
Preparing the Instrument for Shipping . . . . . . . . . . . . . . . . . . . . . . . . 174
6. Safety and Regulatory Information
Warning and Caution Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
Instrument Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
General Safety Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
Product Installation, Use, and Storage . . . . . . . . . . . . . . . . . . . . . . . . 181
Product Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
Declarations of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
e74xx_gsg.book Page 10 Tuesday, September 26, 2000 10:51 AM

1
Installing the Software
e74xx_gsg.book Page 11 Tuesday, September 26, 2000 10:51 AM

12 Agilent Wireless Solutions
Installing the Software
What You’ll Find in This Chapter
What You’ll Find in This Chapter
Read This First
If you purchased your laptop computer as part of Agilent 86154A option 010
or option 030, the software came factory-installed. Skip this procedure and go
to “Setting Up Your System” on page 19.
The factory-installed software does not include Adobe Reader.
To Do This See This
Install the system software “Installing the Software” on page 13
Install the License Manager software “Agilent Technologies License Manager” on
page 15
Install Adobe Reader “Installing Adobe Reader” on page 16
Install Socket I/O card software “Installing Socket PCMCIA I/O Card Software”
on page 17
e74xx_gsg.book Page 12 Tuesday, September 26, 2000 10:51 AM

Agilent Wireless Solutions 13
Installing the Software
Installing the Software
Install Software
Installing the Software
Before you begin installing the software, ensure that your computer system is
configured with the minimum requirements. Check “Personal Computer
Recommendations, Minimum” on page 68 for information.
Follow These Steps
Do This See This
1 Insert the CD-ROM into the CD-ROM drive,
choose Start>Run, and type d:\setup where
d: is the drive containing the software CD-
ROM. Click OK.
AWelcomedialogboxappearsinstructing youto
close any currently running Windows
applications before you begin installation.
2ClickNext whenyou arereadytocontinuethe
installation. Type your name and the name of
the company you work for, then click Next.
The “Choose Destination Location” dialog box
appears. The default folder for installation is
C:\Program Files\Agilent Technologies\E74xx
(depending on the system you’re installing).
3 If you wish to install the program in a folder
other than the default, click Browse to display
text. When the correct destination folder
appears in the field, click Next.
The Setup Type box appears.
4 Select the language inwhich you would liketo
see the online help and tutorial displayed ,
and click Next.
For more information see “Online Help and
Tutorial Language Options” on page 14
5 Select the type of installation you want:
typical, compact, or custom, and click Next.
•Typical: Includes Agilent E74xx application,
online help files, tutorial and documentation.
•Compact: Includes Agilent E74xx application
and online help files
•Custom: Lets you select individual
components.
The Destination Folder box appears.
Agilent Technologies recommends using the
Typicalinstallation.Refertopage 68toseeifyou
have enough disk space available to perform the
Typical installation before proceeding.
e74xx_gsg.book Page 13 Tuesday, September 26, 2000 10:51 AM

14 Agilent Wireless Solutions
Installing the Software
Installing the Software
NOTES •It is recommended that new users go through the online tutorial before
using the software. Refer to “Starting and Learning to Use the Software”
on page 117 for instructions on running the online tutorial.
•When you run the software, disable the Windows 95 Advanced Power
Management Support capabilities to significantly improve the
performance of the system.
Online Help and Tutorial Language Options
During the software installation, you can select the language for the online
help and tutorial (English is always the most up-to-date). The measurement
software does not change. The currently supported languages are:
To change the language, once the installation is complete, you must re-install
the software.
6 Select the destination folder for the program.
The default folder is “C:\Program Files\Agilent
Technologies\ E74xx” or you can select a
different folder that can be found on your
system. Click Next.
The list of folders found on your system is
displayed.
Agilent Technologies recommends using the
default folder
7 Read the list of software installation options
and check thatSetup Type, Target Folder,and
User Information are correct, and click Next.
The software installs from CD to PC.
8ClickFinish to complete the installation. Depending on the files installed or updated you
may be prompted to reboot your system.
Do This See This
•Simplified Chinese •Korean
•English (default) •Brazilian Portuguese
•Japanese •Latin American Spanish
e74xx_gsg.book Page 14 Tuesday, September 26, 2000 10:51 AM

Agilent Wireless Solutions 15
Installing the Software
Agilent Technologies License Manager
Install Software
Agilent Technologies License Manager
The hardware key that came with your Agilent Technologies system enables
and secures the functionality you purchased from Agilent. The Agilent
License Manager, automatically installed when you install the
Agilent Wireless Solutions Software, enables you to manage licensing
security information. You can use the software to:
•Add product options to license keys. You can add licenses (temporary or
permanent) to the license key by entering a string obtained from an
Agilent representative.
•Transfer licensed product options between license keys in order to
consolidate licenses onto one key.
•Transfer a license from one key to another.
•Transfer licenses between keys on different computers. You can move
license options to license keys on another computer that is located
anywhere from the same room to another country.
For more information on learning and using the license manager refer to
“Learning the License Manager” on page 129. Details on the operation of the
license manager can be found in the online help.
e74xx_gsg.book Page 15 Tuesday, September 26, 2000 10:51 AM

16 Agilent Wireless Solutions
Installing the Software
Installing Adobe Reader
Installing Adobe Reader
NOTE Before starting the installation process, ensure that you have removed
previous versions of Adobe reader. This version is Adobe Reader 4.05.
Do This See This
1 Insert the CD-ROM into the CD-ROM
drive, choose Start>Run, and type
d:\Acrobat\rs405eng.exewhered:isthe
drive containing the software CD-ROM.
Click OK.
A Welcome dialog box appears detailing copyright
information.
2ClickNext when you are ready to
continue the installation. The “Choose Destination Location” dialog box appears. The default folder for installation is
C:\Program Files\Adobe\Acrobat4.0
3 If you wish to install the program in a
folder other than the default, click
Browse to display text. When the correct
destination folder appears in the field,
click Next.
The software will install from CD to PC.
4 Once the installation is complete, click
OK. A user guide for the Adobe Reader has been provided on the CD in PDF format.
e74xx_gsg.book Page 16 Tuesday, September 26, 2000 10:51 AM

Agilent Wireless Solutions 17
Installing the Software
Installing Socket PCMCIA I/O Card Software
Install Software
Installing Socket PCMCIA I/O Card Software
If you have a phone or phone/receiver-based system, a serial I/O card (such as
the Socket Ruggedized Serial I/O card) must be installed in the PCMCIA slot
(Personal Computer Memory Card International Association) to configure the
system properly. See “Setting Up Your System” on page 19 for instructions
on installing the I/O card. The software that is provided with the serial I/O
card must be installed at the time the I/O card is installed.
NOTE See Chapter 3, “Software Setup” of the Serial I/O ™ and Ruggedized Serial
I/O Card ™ User’s Guide for instructions on installing the software for that
specific card.
If you are using the USB 4-Port adapter, Agilent 86154A option 036, refer to
the Agilent Technologies Indoor Test System Setup Guide for more
information.
e74xx_gsg.book Page 17 Tuesday, September 26, 2000 10:51 AM

2
Setting Up Your System
e74xx_gsg.book Page 19 Tuesday, September 26, 2000 10:51 AM

20 Agilent Wireless Solutions
Setting Up Your System
What You’ll Find in This Chapter
What You’ll Find in This Chapter
NOTE Trimble provides downloadable documentation on the Web. At the time of
this printing, you can find the files (Microsoft Word and PDF formats) at
http://www.trimble.com/mpc/placer/download/manuals.htm.If the
URL has changed, use the search facility provided at the Web site
(www.trimble.com). For further information about support and training, you
can contact Trimble at a phone number on their Web site.
To Do This See This
Connect the hardware “Hardware Installation Tips” on page 21 covers
important setup information.
“Connecting the Hardware” on page 25 covers
setup of all types of systems. Refer to this page
for the pages that cover your particular system.
Configure hardware automatically. “Automatic Configuration” on page 23
Configure internal GPS. “Internal GPS & Internal GPS with Differential
Setup” on page 44
Configure multiple receivers and/or multiple
phones. “Configuring Multiple Receivers and Phones” on page 92
Review receiver connection panels and
connectors. “Universal Serial Bus (USB), 4-port Adapter Configuration” on page 105
Set pin-out specifications for serial port
connection. “Receiver to PC Serial Port Cable Configuration” on page 109
Configure other GPS units. “RS-232 to GPS Unit Cable Configuration” on
page 110
Set pin-out specifications for connecting
differential GPS receiver to a receiver with an
internal GPS.
“RS-232 to Differential Unit Cable Configuration”
on page 111
e74xx_gsg.book Page 20 Tuesday, September 26, 2000 10:51 AM

Agilent Wireless Solutions 21
Setting Up Your System
Hardware Installation Tips
Index Setting up
Hardware
Hardware Installation Tips
Item Information
Hardware security key Thehardware security keymustbe connectedto theparallelport
of the PC. The application runs with a limited feature set without
the key. You cannot configure projects or collect data without the
key.
Power supply connections Make sure that power supply connections to the GPS, the
receiver, the PC, and the phones (if applicable) are correct.
PC turn on After all cables are connected, turn on the PC. The PC should
be the last device you turn on.
Create a project Make sure your hardware is properly configured.
1 Verify hardware type and COM port settings.
2 Open application and choose a project from the Project drop-
down list that best represents your hardware configuration.
3 Click Configuration and go to Hardware tab. Verify or add
descriptions to complete hardware configuration or use the
Automatic Configuration wizard (refer to“Automatic
Configuration” on page 23).
4 Click Collection to verify that there are no COM errors. If
errors appear, repeat previous steps or refer to “Solving
Problems and Updating Your System” on page 157.
5 Click Save As and name current project.
6. Set project as default project under Tools > Options >New
Project and click OK.
e74xx_gsg.book Page 21 Tuesday, September 26, 2000 10:51 AM
