ADMINISTRATIVE INFORMATION
SERVICE NOTE CLASSIFICATION: INFORMATION ONLY
AUTHOR: KO
PRODUCT LINE: 1A
ADDITIONAL INFORMATION:
© AGILENT TECHNOLOGIES, INC. 2010
PRINTED IN U.S.A.
April 5, 2010
Rev. 17 Page 1 of 14
MSO8104A-05A
S E R V I C E N O T E
Supersedes:
MSO8104A-05
MSO8104A Digitizing Oscilloscope
Serial Numbers: MY00000000-MY46001900
SG00000000-SG46001900
The original scopes motherboard is no longer available for replacement if the
above serial numbers of scopes need a replacement board. This new
replacement motherboard will requires some different cables and other
hardware. This service note is to provide service centers the documentation to
perform the motherboard upgrade.
Parts Required:
P/N Description Qty.
D8104-68700 M880 Motherboard Kit 1

Page 2 of 14 MSO8104A-05A
Situation:
The old motherboard that the units originally shipped with is no longer available. The new
replacement motherboard requires new cables and other hardware.
Solution/Action:
This is the documentation to perform the upgrade
M880 Motherboard Upgrade Procedure.
8000 series part number changes:
Old New Description
---------------- ---------------- ----------------------------------------------------------------------
0960-2652 or 0960-2689 ADLink M880 motherboard w/ 2 SATA cables
81004-68809 3160-4243 Heatsink/Fan assembly
D8104-60102 D8104-60103 Motherboard deck w/ 4 mount points for heatsink/fan
D8104-61605 D8104-61607 Backlight cable
D8104-61602 D8104-61608 Front panel USB port
D8104-61604 D8104-61609 Touchscreen USB cable
54855-61624 54855-61628 Motherboard switch cable
0960-2530 1400-2120 ADD2 board replaced by rear panel slot filler plate
0515-0430 0515-0430 Screw for ADD2 or filler plate
D8104-94302 NA USB Front Panel Label
1 Disconnect the power cable and remove the top cover.
2 Remove the CD-ROM
3 Remove the following cables:
• SATA Cable
• CD-ROM Power cable
4 Using a Torx T10 driver remove the three CD-ROM support bracket screws holding the CD-
ROM drive in place.
5 Using a T20 driver remove the rear panel screw holding the CD-ROM drive in place.
6 Move the CD-ROM drive back towards the front frame, then lift and pull to remove.

Page 3 of 14 MSO8104A-05A
Figure 1
7 Remove all cables from the PCI cards.
8 Remove all PCI cards from the motherboard.
9 Disconnect all cables from the motherboard.
10 Remove the six 5 mm port lock screws from the rear panel connectors.
11 Remove the 5 short and 3 long Torx T10 screws holding the motherboard to the ATX tray.
12 Remove the 8 T20 screws holding the tray to the rear panel.
13 Remove the 3 T10 screws holding the filler plate to rear panel and tray.
Figure 2

Page 4 of 14 MSO8104A-05A
Figure 3
Remove the two Torx T20 screws holding the shock mount in place (See Figure 4)
You may need to use a Torx key to loosen the screws.
14 Tilt the disk drive assembly forward and lift up to remove.
15 Remove the following cables:
• SATA Cable
• Hard Drive Power cable
Figure 4
16 Lift tray with old motherboard from rear and slide to clear the rear panel clearing the three
long standoffs under the tray remove the tray from the chassis.
17 Remove the Auto Probe board b the following.
a Place the unit so the bottom is facing up.
b Locate the access hole on the inside of the front-panel assembly which is below and almost between
channel 2 and channel 3 BNC connectors.
c From the back of the front panel, put a small screw driver or other slender pointed object through the
access hole to push the Auto Probe assembly faceplate away from the front panel assembly.
Figure 5
Access hole
CAUTION: AVOID DAMAGE TO THE RIBBON CABLE AND FACEPLATE!
Do not pry around the edge of the assembly. Doing so may damage the ribbon cable or faceplate.
Figure 5
d Disconnect the mylar flex cable from the AutoProbe board.

Page 5 of 14 MSO8104A-05A
To disconnect the cable
e Pry up the retainer slightly at either end of the connector using a small flat-blade screwdriver.
Do not force the retainer; it should remain attached to the body of the socket.
f Gently pull the flex cable out of the connector.
Figure 6
18Using a 9/16” nut driver, remove the hex nuts that secure the BNC connectors to the front
panel.
Figure 7
Removing the BNC nuts
Figure 7
19 Remove the four Torx T15 screws that secure the chassis sides to the front panel assembly.

Page 6 of 14 MSO8104A-05A
Figure 8
20 Remove the ten Torx T10 screws that secure the front panel cover plate to the front casting.
The four screws in circled in red are longer be sure to re-assemble correctly.
Figure 9
21 Turn front panel cover plate over and Remove the Touch Screen cable D8104-61604 and
replace with D8104-61609. Route new cable though the hole. Secure with tape (see figure 10)

Page 7 of 14 MSO8104A-05A
Figure 10
22 Turn front panel cover plate back over and re-assemble. When re-assembling, torque the ten
Torx T10 screws to 5 in-lb.
23 Remove old Back Light cable D8104-61605 and replace with D8104-61607.
See Figure 11
Figure 11
24 Remove the Front Panel USB cover label remove two T10 screws and replace the old USB
cable D8104-61602 with new D8104-61608. Install New USB Cover Label D8104-94302 (See
figure12)

Page 8 of 14 MSO8104A-05A
Figure 12
25 Route cables though the chassis holes to prepare to reattach the front Panel assembly to the
frame. (See figure 12 and 13)
Figure 13 and 14
26 Re-install Front Panel with four Torx T15 screws that secure the chassis sides to the front
panel assembly.
When re-assembling, torque the four Torx T15 screws to 18 in-lb.
27 Using a 9/16” nut driver, install five hex nuts that secure the BNC connectors to the front
panel.
When assembling the hex nuts to secure the BNC connectors to the front panel, put the conical side of
the nut toward the front-panel casting. Torque the five hex nuts to 18 in-lb.
28 Reattach the Auto-Probe to the mylar flex cable and pop board back into place.
29 Using new Motherboard Deck “Tray” D8104-60103 and New Motherboard 0960-2689
a Install the six 5 mm port lock screws from the rear panel connectors.
b Install the 5 short Torx T10 screws holding the motherboard to the M880 tray. (See Figure 15)

Page 9 of 14 MSO8104A-05A
Figure 15
30 Using new Heat Sink and Fan Assembly install fan to Motherboard and Deck. (See Figure
16) Connect fan power cable to fan CPU Fan jack. Torgue fan screws to 5 in-lb.
Figure 15
Note: Do not use thermal grease on Heat Sink/Fan assembly. It comes with its own thermal type material.
31 Using new Motherboard Switch Cable 54855-61628 connect to motherboard assembly. (See
Figure 16)

Page 10 of 14 MSO8104A-05A
Figure 16
32 Re-install Motherboard Assembly into the frame chassis.
a Install the 3 long Torx T10 screws and two short T10 into the tray holding the
motherboard assembly to the frame chassis. (See Figure 17 and 18)
Figure 17

Page 11 of 14 MSO8104A-05A
Figure 18
33 Re-install eight short T20 screws in rear panel attaching deck to the frame chassis. Torgue
T20 to 8 in-lb.
34 Re-install three short T10 screws and filler plate to the rear panel. Torgue T10 to 5 in-lb.
35 Re-install the Acquisition Interface PCI card into the slot marked GPIB on the rear panel.
36 Re-connect new cables
a Connect new display cable to motherboard. (See Figure 19)
bConnect the two USB cables (See Figure 20)
c. Connect motherboard Switch cable to PCI card (See Figure 21)

Page 12 of 14 MSO8104A-05A
Figure 19
Figure 20
Figure 21
37 Re-connect all other cables to the appropriate sources.
38 Install all ISA slot filler plates (See figure 22)

Page 13 of 14 MSO8104A-05A
Figure 22
.
39 Tilt the disk drive assembly forward and push down to reinstall.
When re-assembling, torque the screws to 18 in-lb.
a Reattach the following cables:
• SATA Cable
• Hard Drive Power cable
40 Re-install CDROM
3 Reattach the following cables:
• SATA Cable
• CD-ROM Power cable
a Using a Torx T10 driver, install the three CD-ROM support bracket screws holding the CD-
ROM drive in place.
When re-assembling, torque the three Torx T10 screws to 5 in-lb.
b Using a T20 driver install the rear panel screw holding the CD-ROM drive in place.
When re-assembling, torque the Torx T20 screw to 18 in-lb.
c Move the CD-ROM drive back towards the rear frame.

Page 14 of 14 MSO8104A-05A
41 Re-dress all cables to their original positions. Making sure they are in the appropriate tie
downs and clamps.
42 Re-install top cover and feet and handles.
