User’s and Service Guide
Agilent Technologies
87075C
Multiport Test Set
For E506x Network Analyzers
Part No. 87075-90027
Printed in USA
Print Date: March 2004
© Copyright 2004 Agilent Technologies, Inc.

ii
WARRANTY STATEMENT
THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROVIDED
“AS IS,” AND IS SUBJECT TO BEING CHANGED, WITHOUT
NOTICE, IN FUTURE EDITIONS. FURTHER, TO THE MAXIMUM
EXTENT PERMITTED BY APPLICABLE LAW, AGILENT
DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED
WITH REGARD TO THIS MANUAL AND ANY INFORMATION
CONTAINED HEREIN, INCLUDING BUT NOT LIMITED TO THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. AGILENT SHALL NOT BE LIABLE
FOR ERRORS OR FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE
FURNISHING, USE, OR PERFORMANCE OF THIS DOCUMENT
OR ANY INFORMATION CONTAINED HEREIN. SHOULD AGILENT
AND THE USER HAVE A SEPARATE WRITTEN AGREEMENT
WITH WARRANTY TERMS COVERING THE MATERIAL IN THIS
DOCUMENT THAT CONFLICT WITH THESE TERMS, THE
WARRANTY TERMS IN THE SEPARATE AGREEMENT WILL
CONTROL.
DFARS/Restricted Rights Notice
If software is for use in the performance of a U.S. Government
prime contract or subcontract, Software is delivered and licensed
as “Commercial computer software” as defined in DFAR
252.227-7014 (June 1995), or as a “commercial item” as defined in
FAR 2.101(a) or as “Restricted computer software” as defined in
FAR 52.227-19 (June 1987) or any equivalent agency regulation or
contract clause. Use, duplication or disclosure of Software is
subject to Agilent Technologies’ standard commercial license
terms, and non-DOD Departments and Agencies of the U.S.
Government will receive no greater than Restricted Rights as
defined in FAR 52.227-19(c)(1-2) (June 1987). U.S. Government

iii
users will receive no greater than Limited Rights as defined in
FAR 52.227-14 (June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any technical data.
Certification
Agilent Technologies, Inc. certifies that this product met its
published specifications at the time of shipment from the factory.
Agilent Technologies, Inc. further certifies that its calibration
measurements are traceable to the United States National
Institute of Standards and Technology, to the extent allowed by
the Institute's calibration facility, and to the calibration facilities
of other International Standards Organization members.
Assistance
Product maintenance agreements and other customer assistance
agreements are available for Agilent Technologies, Inc. products.
For information about these agreements and for other assistance,
contact Agilent. Refer to page 120.
Safety Notes
The following safety notes are used throughout this manual.
Familiarize yourself with each of the notes and its meaning before
operating this instrument. All pertinent safety notes for using this
product are located in Chapter 10.

iv
WARNING Warning denotes a hazard. It calls attention to a procedure
which, if not correctly performed or adhered to, could
result in injury or loss of life. Do not proceed beyond a
warning note until the indicated conditions are fully
understood and met.
CAUTION Caution denotes a hazard. It calls attention to a procedure that, if
not correctly performed or adhered to, could result in damage to or
destruction of the instrument. Do not proceed beyond a caution
sign until the indicated conditions are fully understood and met.
Printing Copies of This Document
To print copies of documentation from the Web, download the PDF
file from the Agilent web site:
•Go to http://www.agilent.com.
•Enter the document’s part number (located on the title page) in
the Quick Search box.
•Click GO.
.

Contents
Contents-v
1. Introduction and Installation
Introduction to the Multiport Test Set . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
A Complete Multiport Test System . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Fully Characterize Your Devices with a Single Connection. . . . . . . . . .2
Improve Your Competitiveness with a Fully Specified Test System . . .3
Eliminate Redundant Connection of Calibration Standards with Test
Set Cal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Reduce the Effects of Test-System Drift with SelfCal . . . . . . . . . . . . . .4
Decrease Calibration Times and Increase Production Throughput . . .4
Improve Measurement Accuracy with Two-Port Calibration . . . . . . . .4
Typeface Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
If You are Using an 8712ET/ES or 8714ET/ES Analyzer . . . . . . . . . . . . .6
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Step 1. Check the Shipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Step 2. Determine Network Analyzer Compatibility . . . . . . . . . . . . . .11
Step 3. Connect the Test Set to the Analyzer . . . . . . . . . . . . . . . . . . .12
Step 4. Satisfy Electrical and Environmental Requirements . . . . . . .14
Step 5. Activate the Test Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Step 6. Connect Peripheral Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Cleaning the Test Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
2. Making Measurements
Measurement Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Setting port connections of the multi-port test set . . . . . . . . . . . . . . . .22
Setting the measurement conditions. . . . . . . . . . . . . . . . . . . . . . . . . . .23
Calibrating the test set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Performing Measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
3. Test Set Cal and SelfCal

Contents-vi
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Test Set Cal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
SelfCal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Test Set Cal: An Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Setting Up the Measurement Parameters. . . . . . . . . . . . . . . . . . . . . . 32
Determining the Best Position for the Calibration Reference Plane . 34
Determining the Type of Calibration Kit to Use . . . . . . . . . . . . . . . . . 36
Determine the Test Set Ports to Be Used . . . . . . . . . . . . . . . . . . . . . . 37
Performing the Test Set Cal with a Mechanical Calibration Kit . . . . 37
Performing the Test Set Cal with an ECal Module. . . . . . . . . . . . . . . 40
Saving the Test Set Cal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Recalling the Test Set Cal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Copying the Test Set Cal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Executing Self Cal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Test Set Cal and SelfCal: Theory of Operation. . . . . . . . . . . . . . . . . . . . 45
4. Front/Rear Panel
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Line Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Test Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
The REFLECTION Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
The TRANSMISSION Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
The Chassis Ground Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
The PORT CONNECTION Status LEDs . . . . . . . . . . . . . . . . . . . . . . 53
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
The PARALLEL IN Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
The PARALLEL OUT Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Line Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5. Key Reference

Contents
Contents-vii
Cal Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
System Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
6. SCPI Command Reference
7. COM Object Reference
8. Specifications
About This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Test Set Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Limitation of Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Exclusive Remedies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Contacting Agilent. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .120
9. Service
Automated Performance Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Test Equipment Required . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Program Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Performance Verification Test Results . . . . . . . . . . . . . . . . . . . . . . . .129
Manual Performance Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136
The Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136
The LED Display Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .137
The Main Switch Board Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . .137

Contents-viii
Contents
Post-Repair Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Rebuilt-Exchange Assemblies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Major Parts and Assemblies. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Cables, Front Panel, and Main Board Assembly — Option 012
(75 Ω) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Cables, Front Panel, and Main Board Assembly— Option 006 . . . . 145
Instrument Covers and Associated Parts . . . . . . . . . . . . . . . . . . . . . 147
Accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
10. Safety and Regulatory Information
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 154
Statement of Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Shipping Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
Instrument Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Notice for Germany: Noise Declaration . . . . . . . . . . . . . . . . . . . . . . 157
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

1
1 Introduction and Installation

2Chapter1
Introduction and Installation
Introduction to the Multiport Test Set
Introduction to the Multiport Test Set
• The 87075C is a 75-ohm multiport test set that is available with 6 or 12 test
ports.
A Complete Multiport Test System
87075C multiport test sets are designed to work with E5061A (1.5 GHz) and
E5062A (3 GHz) RF network analyzers to provide complete measurement systems
for 75 ohm multiport devices. These test systems offer fast measurement speed, high
accuracy, and productivity features that will maximize your production throughput.
They feature:
• specified performance to 1.3 GHz (87075C)
• solid-state switches for fast, repeatable, and reliable switching between
measurement paths
Fully Characterize Your Devices with a Single
Connection
A single connection between the multiport test set and each port of the DUT allows
complete testing of all transmission paths and port reflection characteristics. Agilent
multiport test systems eliminate time-consuming reconnections to the DUT, keeping
your production costs down and your volumes up. By reducing the number of RF
connections, you also:
• lower the risk of misconnections
• reduce operator fatigue
• minimize wear on cables, fixtures, connectors, and the DUT

Chapter 1 3
Introduction and Installation
Introduction to the Multiport Test Set
Improve Your Competitiveness with a Fully Specified
Test System
A multiport test set coupled with an E5061A/E5062A network analyzer offers fully
specified performance at the actual test ports, whether you measure in a fixture or at
the end of test cables. Specified performance means you can:
• get the same results no matter which test station you use to measure your DUT
• correlate test data from many DUTs across multiple test systems
• reduce measurement uncertainty to tighten your product specifications
• increase customer confidence in your products
Eliminate Redundant Connection of Calibration
Standards with Test Set Cal
Calibrating a multiport test set using two-port error correction and a traditional
network analyzer requires a unique instrument state for each measurement path,
forcing many redundant connections of calibration standards. As the number of
ports increases, so does the number of connections required to calibrate all possible
measurement paths. Full calibration of the multiport test system is quick and simple
when performing a Test Set Cal:
• connect short, open, and load standards only once to each measurement port
• minimize the number of through standards required during calibration

4Chapter1
Introduction and Installation
Introduction to the Multiport Test Set
Reduce the Effects of Test-System Drift with SelfCal
SelfCal is an internally automated calibration technique that uses solid-state
switches to measure calibration standards located inside the test set. SelfCal
executes automatically in just a few seconds (at an interval you define), so the
impact to your test process is minimal. Use SelfCal to:
• re-calibrate your multiport test system, returning it to the same measurement
accuracy achieved immediately after performing a Test Set Cal
• reduce the effects of test-system drift, improving overall measurement accuracy
between Test Set Cals
Since SelfCal does not correct for drift associated with interconnect elements
between the test set and your DUT, it is essential to use high-quality test cables,
adapters, and fixtures to ensure the best measurement accuracy.
Decrease Calibration Times and Increase Production
Throughput
With SelfCal, a Test Set Cal needs to be performed about once per month, if within
the specified temperature range. This is unlike other test systems that typically
require calibration once or twice a day. Using Test Set Cal and SelfCal, you can:
• easily reduce your overall calibration times by a factor of twenty or more
• increase the amount of time a test station can be used for measuring
devices—typically, by three days per month.
Improve Measurement Accuracy with Two-Port
Calibration
When using a multiport test set with an E5061A/E5062A with the option 275
S-parameter test set, Test Set Cal and SelfCal support full two-port calibrations.
Two-port error correction greatly improves the effective load match of the test
system, providing excellent measurement accuracy.

Chapter 1 5
Introduction and Installation
Introduction to the Multiport Test Set
Typeface Conventions
Sample (bold) Boldface type is used when a term is
defined or emphasis.
Sample (Italic) Italic type is used for emphasis.
[ ] key Indicates a hardkey (key on the front panel
or external keyboard) labeled “Sample.”
“key” may be omitted.
Sample menu/button/box Indicates a menu/button/box on the screen
labeled “Sample” which can be
selected/executed by clicking. “menu,”
“button,” or “box” may be omitted.
Sample block/toolbar Indicates a block (group of hardkeys) or a
toolbar (setup toolbar) labeled “Sample.”
Sample 1 - Sample 2 - Sample 3 Indicates a sequential operation of Sample
1, Sample 2, and Sample 3 (menu, button,
or box). “-” may be omitted.

6Chapter1
Introduction and Installation
If You are Using an 8712ET/ES or 8714ET/ES Analyzer
If You are Using an 8712ET/ES or 8714ET/ES
Analyzer
This document is intended for use with E5061A and E5062A analyzers, so some of
the information (for example, key presses and calibration features) does not apply to
your analyzer. You can order the copy of the manual specifically written for using
the 87075C with 8712ET/ES and 8714ET/ES analyzers with the part number
87050-90026 by contacting Agilent Technologies. Refer to page 120 for contact
information. The manual can be also viewed in the Agilent web site:
http://www.agilent.com/find/manuals

Chapter 1 7
Introduction and Installation
Installation
Installation
This section will guide you through the steps necessary to correctly and safely
install your multiport test set. The steps are:
•“Step 1. Check the Shipment”
•“Step 2. Determine Network Analyzer Compatibility”
•“Step 3. Connect the Test Set to the Analyzer”
•“Step 4. Satisfy Electrical and Environmental Requirements”
•“Step 5. Activate the Test Set”
•“Step 6. Connect Peripheral Devices”

8Chapter1
Introduction and Installation
Installation
Figure 1-1 87075C Multiport Test Set — Two Versions
87075C Option 006 — Six Port Test Set
87075C Option 012 — Twelve Port Test Set

Chapter 1 9
Introduction and Installation
Installation
Step 1. Check the Shipment
After you have unpacked your test set, keep the packaging materials to use if your
instrument should need to be returned for maintenance or repair.
NOTE The packaging material is designed to protect the test set from damage that can
happen during shipping. Returning the test set in anything other than the original
packaging may result in non-warranted damage.
Check the items received against Table 1-1 to make sure that you received
everything.

10 Chapter1
Introduction and Installation
Installation
Table 1-1 Test Set Accessories Supplied
Item No. Description Quantity Part Number
1 Power Cord 1 See Figure 4-3.
2 Type-N Cable (Analyzer to test set’s
REFLECTION Port)1
1. Not to be used with a rack-mounted system or if the analyzer has had its bottom feet removed.
See Figure 1-6 to see how these cables are to be connected.
1(75Ω) 87075-60026
3 Type-N Cable (Analyzer to test set’s
TRANSMISSION Port)11(75Ω) 87075-60028
4 Type-N Cable (Analyzer to test set’s
REFLECTION Port)2
2. You will only receive these cables if you ordered Option 1CM (rack mount kit). Use these cables
if you are rack-mounting your system, or if the bottom feet of the analyzer have been removed.
See Figure 1-6 for information on how to connect these cables.
1(75Ω) 87075-60027
5 Type-N Cable (Analyzer to test set’s
TRANSMISSION Port)21(75Ω) 87075-60029
6 Parallel Port Interface Cable 1 8120-6818
7 87075C User's and Service Guide (for E506x
Network Analyzers)
87050E and 87075C User’s and Service Guide
(for 871x Network Analyzers)
1
1
87075-90027
87050-90026
8 Test Set Calibration Disk 1 N/A
9 Performance Test Programs Disks
(DOS and LIF formats) 1 08714-60049
10 CD-ROM 1 08714-90051

Chapter 1 11
Introduction and Installation
Installation
Figure 1-2 Test Set Accessories Supplied
Step 2. Determine Network Analyzer Compatibility
If you are using a 8712ET/ES or 8714ET/ES analyzer, refer to “If You are Using an
8712ET/ES or 8714ET/ES Analyzer”.
