REPAIR PARTS FOR MODEL 45-0265 - BOX SCRAPER/GRADER BLADE
REF. PART QTY. DESCRIPTION
NO. NO.
1 63656 1 Hitch Assembly
2 46848 2 Frame Tube
3 24223 2 Frame Brace End)
4 24224 2 Frame Brace Middle)
5 63506 1 Pivot Reinforcement Bracket
Assembly
6 24233 1 Blade
7 24231 1 Clevis Bracket
8 63507 1 Scarifier Bar Assembly)
9 24237 2 Box End Plate
10 43432 18 Hex Bolt, 3/8-16 x 2-1/2" Lg.
11 43350 4 Carriage Bolt, 3/8-16 x 1" Lg.
12 44326 4 Carriage Bolt, 5/16-18 x 1" Lg.
REF. PART QTY. DESCRIPTION
NO. NO.
13 46853 2 U-Bolt, 3/8-16
14 43015 26 Hex Nut, 3/8-16 Thread
15 43083 4 Hex Nut, 5/16-18 Thread
16 43086 4 Lock Washer, 5/16"
17 43003 26 Lock Washer, 3/8"
18 43070 18 Washer, 3/8" Std. Wrt.
19 43038 1 Pivot Lock Pin
20 44044 2 Clevis Pin, 3/8" x 3/4" Lg.
21 46855 1 Cotter Pin, 3/16" x 2" Lg.
22 43055 2 Hairpin Cotter, 3/32" #3
23 43343 1 Hairpin Cotter, 1/8" #4
24 23336 1 Washer, Special
47056 1 Owners Manual
PARTS LIST FOR MODEL 45-0265 - BOX SCRAPER/GRADER BLADE
1
2
3
3
4
4
5
6
7
8
9
9
10
10
10
14
17
17
14
14
17
14
17
17
15
16
13
24
18
18
18
21
11
12
20
22
19
23
A
A
PIVOT ROD
PIVOT PLATE
1714
2
10
10
18
17
18

FULL SIZE HARDWARE CHART
10 11 12 13
14
15
16
17
18
19
21 22 23
24
20
3/8" x 2-1/2"
HEX BOLT
18 pcs.)

3/8" x 1"
CARRIAGE BOLT
4 pcs.)
5/16" x 1"
CARRIAGE BOLT
4 pcs.)
3/8" U-BOLT
2 pcs.)3/8" WASHER
18 pcs.)
3/8" HEX NUT
26 pcs.)
5/16" HEX NUT
4 pcs.)
5/16" LOCK WASHER
4 pcs.)
3/8" LOCK WASHER
26 pcs.)
PIVOT LOCK PIN
1 pc.)
CLEVIS PIN
3/8" x 3/4"
2 pcs.)
SPECIAL WASHER
1 pc.)
HAIRPIN COTTER
3/32" 2 pcs.)
HAIRPIN COTTER
1/8" 1 pc)
COTTER PIN
3/16" 1 pc)
REPAIR PARTS
