Agri-Fab 45-03523 User manual

• Safety
• Assembly
• Operation
• Maintenance
• Parts
PRINTEDINU.S.A. FORMNO.41957(01/31/11)
42" PROFESSIONAL
LAWNSWEEPER
CAUTION:
ReadRulesfor
SafeOperation
andInstructions
Carefully
the fastest way to purchase parts
www.speedepart.com
Model No.
45-03523
OWNERS
MANUAL
™
Call1-800-448-9282formissingpartsorassemblyhelp.

2
Anypowerequipmentcancauseinjuryifoperatedimproperlyoriftheuserdoesnotunderstandhowtooperatetheequipment.
Exercisecautionatalltimeswhenusingpowerequipment.
1. Readthevehicleandsweeperownersmanualsand
knowhowtooperateyourvehicleandsweeperbefore
usingthissweeperattachment.Alwaysinstructother
usersbeforetheyoperatethesweeper.
2. Donotpermitchildrentooperatesweeper.
3. Donotpermitanyonetorideonsweeper.
4. Neverattachthehopperropetoanypartofyourbody
orclothing!Neverholdontotheropewhiletowing
thesweeper!Attachtheropetothetowingvehicleto
keepitawayfromwheelsandrotatingparts.
5. Operatethesweeperatreducedspeedonrough
terrain,nearditchesandonhillsidestopreventlossof
control.
6. Vehiclebrakingandstabilitymaybeaffectedwiththe
attachmentofthissweeper.
7. Donotllsweepertomaximumcapacitywithout
checkingthecapabilityofthetowingvehicletosafely
pullandstopwiththesweeperattached.Stay off of
steep slopes.
8. Stopandinspectvehicleandsweeperfordamage
afterstrikinganobject.Repairanydamagebefore
continuingoperation.
9. Keepsweeperawayfromre.Excessiveheatcan
damagethebrushesandhopperbagandcould
causethebaganditscontentstoburn.
10.Beforestoringthesweeper,alwaysemptythehopper
bagtoavoidspontaneouscombustion.
11.Followmaintenanceandlubricationinstructionsas
outlinedinthemaintenancesectionofthismanual.
Lookforthissymboltopointoutimportantsafetyprecautions.Itmeans—Attention!!
Become alert!! Yoursafetyisinvolved.
SAFETY RULES
CARTON CONTENTS
1
2
3
4
5
6
7
8
2
9
10
11
12
13
14
15 16
17
18
19
REF. PART NO. QTY DESCRIPTION
1 68164 1 HousingAssembly
246781 2Tube,BagArm
3 46776 1 HitchTube,R.H.
4 23687 1 HitchBracket,Bent
5 24192 1 Bracket,Hitch(Straight)
625537 1 HeightAdjustmentHandle
7 25531 1 HeightAdjustmentPlate
846777 1 HitchTube,L.H.
9 43737 1 HopperRope
10 46738 1 HopperBag
REF. PART NO. QTY DESCRIPTION
11 46739 1 WindScreen
12 46735 1 UpperHopperTube,L.H.
13 46734 1 UpperHopperTube,R.H.
14 46733 1 LowerHopperTube,L.H.
15 46732 1 LowerHopperTube,R.H.
16 46823 1 Rod,HopperBagPivot
17 43938 2Rod,HopperSupport34"
18 24190 1 Retainer,Bag
19 25430 1 BagFrameStrap

3
A B C D EFGHI
K
LMN
R
S
TU
V
Q
J
SHOWN FULL SIZE
NOT SHOWN FULL SIZE
P
X
O
W
REF PART NO. QTY DESCRIPTION
A 46782 2HexBolt,5/16-18x3"Lg.
B43224 2HexBolt,5/16-18x2-1/4"Lg.
C43084 4 HexBolt,5/16-18x1-3/4"Lg.
D 43182 2HexBolt,5/16"x3/4"
E 44326 3 CarriageBolt,5/16-18x1"
F43346 6Screw,#10-32x5/8"
G47810 13 NylockNut,5/16"
H47171 6NylockNut,#10-32
I 44917 2Palnut
J23625 3 SmallSpacer
K23368 2LargeSpacer
L48366 2ClevisPin,3/8"x1/2"
REF PART NO. QTY DESCRIPTION
M 48365 2ClevisPin,1/4"x1-1/8"
N 46867 2ClevisPin,1/4"x1-3/4"
O 142 1 CotterPin,1/8"x3/4"
P 43070 1 Washer,3/8"
Q43055 6HairCotterPin,Small
R 43343 1 HairCotterPin,Large
S 43943 1 Grip
T 44481 2VinylCap
U 48402 2PlasticPlug
V23353 1 HitchPin
W49608 1 HeightAdjustmentPin
XHA2394 1 Spring

4
STEP 4 - CONNECT HITCH TUBES
• Fastenthehitchtubestogetherusingtwo5/16"x3"
hexboltsand5/16"nylocknuts.Do not tighten yet.
Seegure2.
FIGURE 1
FIGURE 2
5/16" x 1-3/4"
HEX BOLT
HITCH TUBE (L.H.)
5/16" NYLOCK NUT
HOUSING
MARKED "L"
PLASTIC TIE
5/16" NYLOCK NUT
5/16" x 3"
HEX BOLT
ASSEMBLY OF SWEEPER
TOOLS REQUIRED FOR ASSEMBLY
(1)KnifeorScissors
(1)Screwdriver
(1)Hammer
(1)3/8"OpenEndorBoxEndWrench
(2)1/2"OpenEndorBoxEndWrench
STEP 1 - REMOVE PARTS FROM CARTON
• Removethesweeperhousing,loosepartsand
hardwarepackagefromthecarton.Layouttheparts
andhardwareasshownonpages2and3.
STEP 2 - INSTALL HITCH TUBES
• Thehitchtubesarestampedwitha"77L"forthe
lefttubeanda"76R"fortherighttube.Thesweeper
housingismarkedwithan"L"ontheleftsideandan
"R"ontherightside.Seegure1.
• Holdthelefthitchtubeagainsttheleftsideofthe
sweepersothatthe"77L"onthetubefacesaway
fromthesweeper.Attachthehitchtubeusingtwo
5/16"x1-3/4"hexboltsand5/16"nylocknuts.Repeat
fortherighthitchtube,butwiththe"76R"facingin
towardtherightsideofthesweeper.Do not tighten
yet.Seegure1.
STEP 3 - REMOVE PLASTIC TIE
• Removetheplastictiethatfastenstheheight
adjustmenttubetothefrontofthesweeperhousing.
Seegure1.
STEP 5 - MEASURE TRACTOR HITCH
• Usethemarkalongthesideofthispagetomeasure
theheightofthetractorhitch.Themarkis10"fromthe
bottomofthepage.Ifthetractorhitchislessthan10"
abovetheground,gotoSTEP 6a.Ifthetractorhitchis
10"ormoreabovetheground,gotoSTEP 6b.
FIGURE 3
5/16" NYLOCK NUT
HITCH PIN
HITCH
BRACKET
5/16" x 2-1/4"
HEX BOLT
HITCH
BRACKET
(STRAIGHT)
HAIRPIN COTTER
3/4" SPACERS
STEP 6a - ASSEMBLE HITCH BRACKETS
• FORTRACTORHITCHESLOWERTHAN10".
Placethebenthitchbracketunderneaththehitch
tubesandthestraighthitchbracketontopofthehitch
tubes.Inserttwo5/16"x2-14"hexboltsthroughthe
brackets,withtherearhexboltbetweenthecrossbolts
inthehitchtubes.Securethehexboltswithtwo5/16"
nylocknuts.Seegure3.Do not tighten yet.
• Assemblehitchpin,thetwolargespacersandthe
hairpincottertothehitchbrackets.Seegure3.
10"

5
5/16" NYLOCK NUT
HITCH BRACKET
(STRAIGHT)
HITCH
BRACKET
HITCH PIN
5/16" x 2-1/4"
HEX BOLT
3/4" SPACERS
1/8" HAIRPIN
COTTER
FIGURE 4
FIGURE 5
FIGURE 6
HEIGHT
ADJUSTMENT
PLATE
SPACER
5/16" NYLOCK NUT
5/16" x 1"
CARRIAGE
BOLT
HEIGHT
ADJUSTMENT
TUBE
HEIGHT
ADJUSTMENT
HANDLE
5/16" NYLOCK NUT
5/16" x 3/4"
HEX BOLT
GRIP
HEIGHT
ADJUSTMENT
BRACKET
STEP 6b - ASSEMBLE HITCH BRACKETS
• FORTRACTORHITCHESHIGHERTHAN10".
Placethebenthitchbracketontopofthehitchtubes
andthestraighthitchbracketunderneaththehitch
tubes.Inserttwo5/16"x2-1/4"hexboltsthroughthe
brackets,withtherearhexboltbetweenthecrossbolts
inthehitchtubes.Securethehexboltswithtwo5/16"
nylocknuts.Seegure4.Do not tighten yet.
• Assemblehitchpin,thetwolargespacersandthe
hairpincottertothehitchbrackets.Seegure4.
STEP 7 - TIGHTEN BOLTS
• Tightenthefourboltsingure1thatfastenthehitch
tubestothesweeperhousing.Next,tightenthetwo
boltsingure2thatfastentheendsofthehitchtubes
together.Finally,tightenthetwoboltsingure3or4
thatfastenthehitchbracketstothehitchtubes.
STEP 8 - ATTACH HEIGHT ADJUSTMENT
PLATE
• Attachtheheightadjustmentplatetothesweeper
housingusingthree5/16"x1"carriagebolts,spacers
(placedbetweenplateandhousing)and5/16"nylock
nuts.Seegure5.
Hint:Pushtheheightadjustmenttubedownoutofthe
waytoalloweasieraccesstoholesinsweeperhousing.
Hint:Attachthebolts,spacersandnutstooneholeata
timestartingwiththetopholetoeaseassembly.
STEP 9 - ATTACH HANDLE
• Assembletheheightadjustmenthandletotheheight
adjustbracketatthefrontofthesweeperhousing.
Usetwo5/16"x3/4"hexboltsand5/16"nylocknuts.
Seegure6.
• Assemblethegripontotheendoftheheight
adjustmenthandleasshowningure6.

6
FIGURE 7
COIL SPRING
HEIGHT
ADJUSTMENT
PIN
1/8" x 3/4"
COTTER PIN
3/8" WASHER
STEP 10 - ASSEMBLE HEIGHT ADJUSTMENT
PIN
• Placetheheightadjustmentpinintotheheightadjust
bracket.Assemblecoilspringand3/8"washeronto
theheightadjustmentpinandthensecurethemusing
a1/8"x3/4"cotterpin.Seegure7.
ASSEMBLY OF HOPPER BAG
STEP 11 - ASSEMBLE UPPER TUBES
• Insertthelefthandupperhoppertubethroughthe
stitchedapsofthehopperbag,starting at the center
cut outinthetopofthebag.Seegures8,9and10.
Repeatfortherighthandupperhoppertube.
FIGURE 8
• Slidethetwoupperhoppertubestogetherandlineup
thecenterholesasshowningure9.
FIGURE 9
Right Left
BAG FLAP
UPPER HOPPER TUBE
(LEFT HAND SHOWN)
END HERE
CENTER CUT OUT
(START HERE)
UPPER HOPPER TUBES
PLASTIC PLUG
• Fastentheupperhoppertubestogetherusinga
plasticplug.Seegure10.
NOTE:Plastic plug may break in later steps. It is only
used to hold tubes in place a short time and does not
need to be replaced.
FIGURE 10

7
FIGURE 11
FIGURE 12
PLASTIC PLUG
LOWER
HOPPER
TUBE
• Placetheassembledlowerhoppertubesintothe
bottomofthehopperbagandthenslidethetubesto
thebackofthebag.Seegure12.
• Attachtheendsofthelowerhoppertubestothe
insideoftheupperhoppertubesusingtwo3/8"x
1/2"clevispinsinsertedfromtheinside,andtwo
smallhaircotterpins.Seegure12.
STEP 12 - ASSEMBLE LOWER TUBES
• Assemblethetwolowerhoppertubetogetherusinga
plasticplug.Seegure11.
NOTE:Plastic plug may break in later steps. It is only
used to hold tubes in place a short time and does not
need to be replaced.
LOWER HOPPER TUBE
HOPPER BAG
BOTTOM
UPPER HOPPER
TUBE
3/8" x 1/2"
CLEVIS PIN
SMALL HAIR
COTTER PIN
STEP 13 - ATTACH BAG BOTTOM
• Assemblethebagretainerandthebagframestrap
tothefrontedgeofthebagbottom.Placethebag
retainerontopandthebagframestrapunderneath
thebagbottom.Fastentogetherusingsix#10x5/8"
screwsand#10-32nylocknuts.Seegure13.
FIGURE 13
#10-32
NYLOCK NUT
FRAME STRAP
FRONT EDGE OF BAG BOTTOM
#10-32 x 5/8" SCREW
BAG RETAINER
FIGURE 14
1/4" x 1-1/8"
CLEVIS PIN (N)
SMALL HAIR
COTTER PIN
BAG FRAME STRAP
• Assemblethebagframestraptotheholesinthe
lowerhoppertubesusingtwo1/4"x1-1/8"clevispins
andsmallhaircotterpins.Seegure14.

8
STEP 15 - ASSEMBLE SUPPORT RODS
IMPORTANT: Do notoverbendthesupportrodsduring
thefollowingstep.Overbendingwilldecreasethesupporting
tensionoftherods.
• Assemble the two hopper support rods as shown in
gure16.Placetheendsoftherodsintotheholesin
theupperandlowerhoppertubes,exingtherodjust
enoughtotintotheholesinthetubes.
STEP 14 - ATTACH BAG SIDES
• Foldthebagapsaroundthelowerhoppertubesand
attachtothebagbottomusingthesnaps.Seegure
15.
FIGURE 15
FIGURE 16
SNAP FLAP
SUPPORT
RODS
STEP 16 - ASSEMBLE HOPPER ROD AND
BAG ARM TUBES
• If the hole in the side of the upper hopper tubes is
coveredoverbythebag,locatetheholebytouch.Itis
approximatelymidwayalongthesideofthebag.Pierce
holesthroughthestitchedbagapswheretheholesin
bothhoppertubesarelocated.Seegure17.
UPPER HOPPER TUBE
FIGURE 17
FIGURE 18
PIVOT ROD
BAG ARM TUBE
• Slidethehopperbagpivotrodthroughtheholeinan
upperhoppertube.Assembletwobagarmtubesand
onto the rod as shown in gure 18. Push the rod on
throughtheupperhoppertubeontheoppositesideof
thebag.

9
STEP 19 - ATTACH HOPPER BAG
• Toattachthehopperbagtothesweeper,slidethe
endsofthebagarmtubesintotheendsofthehitch
tubesandsecurewithtwo1/4"x1-3/4"clevispins
andsmallhairpincotters.Seegure21.
STEP 18 - ATTACH ROPE
• Securetheropetothecenteroftheupperrear
hoppertubeasshowningure20.
FIGURE 21
FIGURE 20
FIGURE 19
STEP 17 - ASSEMBLE PALNUTS AND CAPS
• Assembletwopalnutsontotheendsofthepivotrodby
lightlytappingthemwithahammer.Seegure19.
• Placeavinylcapontoeachbagarmtube.Seegure19.
HINT: Toeaseassemblyofthepalnuts,placethebagon
itssideonahardsurface.Withthebottomendofthepivot
rodagainstthesurface,tapapalnutontothetopendofthe
rod.Repeatforotherendofrod.
PALNUT
VINYL CAP
1/4" X 1-3/4"
CLEVIS PIN
SMALL
HAIRPIN
COTTER HITCH TUBE
HITCH TUBE
BAG ARM TUBE

10
STEP 20 - ATTACH SWEEPER TO TRACTOR
FIGURE 22
• Placethetractorandsweeperonaatlevelsurface.
• Setthesweeperheightadjustmenthandletoabout
themiddleofitsadjustmentrange.

• Attachthesweeperhitchtothetractorhitch,
arrangingthehitchspacersinoneofsixpossible
combinationsasshowninGROUPAandGROUPB
diagramsbelow.
IMPORTANT: Toobtainthebestperformancefromyour
sweeper, arrangethespacers so that the sweeperbag is
approximatelylevelwiththegroundandapproximately5"to
7"offthegroundasshowningure22.
GROUP "B" - For vehicles with hitches
having 10" to 13" ground clearance.
GROUP "A" - For vehicles with hitches
having 8" to 10" ground clearance.
APPROXIMATELY LEVEL
(5" TO 7" FROM SURFACE)
BRUSH HEIGHT ADJUSTED
APPROXIMATELY MID-WAY
BLACK LINE IS TRACTOR HITCH
HITCH BRACKET MOUNTED
BELOW HITCH TUBES
BLACK LINE IS TRACTOR HITCH
HITCH BRACKET MOUNTED
ABOVE HITCH TUBES
