AGROdeviate Hawkins Corn Reel Series User manual

Corn Reel
Operation Manual
Revised 09.20
308.708.8185 | [email protected] | Rev. 09/20
FOR ALL CORN REEL MODELS

Table of Contents
OPERATION GUIDE
IN THE FIELD. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SERVICE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
ENABLE REEL FUNCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 

Operation GUide
(1) In the eld
1
-See (3.1) for information on how to enable the reel function in your combine monitor.
1.1 - Initial startup
-Check that all reel functions are working in the desired direction before going to
the eld. Reverse hydraulic hoses, if necessary.
-Make sure Stop Bolts/Stroke Control Blocks are installed for proper lower height limit.
-After rst 5 hours of use check all bolts, drive chain, and ttings for tightness.
Loose parts and oil leaks can be hazardous.
-Check that Zerk Bolts on Reel Holders are unlocked and greased to allow
Fore & Aft function to work.

Operation GUide
(1) In the eld
2
Slow down! Down corn typically requires slower operating speeds to feed material
into the corn head and through the combine, even with a corn reel.
1.2 - General Tips for Operating your Hawkins Corn Reel
If possible, wait for dry conditions to allow smooth feeding of material into the head.
Conditions can change quickly. Reel settings will need to be adjusted as conditions
evolve to optimize material ow.

2
Operation GUide
(1) In the eld
3
- A good starting point for reel speed is approximately equal to ground speed.
1.3 - Setting Corn Reel speed
- Make small adjustments to reel speed to optimize ow into the corn head.
- Running the reel too fast can cause ears to be thrown out of the corn head.
- Running the reel too slow can inhibit material ow into the corn head.

Operation GUide
(1) In the eld
4
- Reel height should be set just low enough to create a conveying action into the
corn head.
1.4 - Setting Corn Reel height
- Running the reel height too low can cause stalk wrapping and overthrow of material.
- When harvesting corn that is mostly upright with tops broken, set reel paddles near
ear height to aid in moving“u”into the corn head.
- When harvesting areas of standing corn, raise the reel out of the way of incoming corn.

4
Operation GUide
(1) In the eld
5
A good starting point for reel fore & aft is to set the reel just behind the ear saver aps to aid in
moving material as it is sheared o by the stalk rolls.
1.5 - Setting Corn Reel Fore & Aft
In dry conditions it may help to run the reel closer to the head auger, leaving at least an ear width
between the paddle tips and the ighting to avoid shelling.
Generally, the reel will need to be run forward in its range in heavy down corn conditions and further
back in less severe“dry u”conditions.

Operation Guide
308.708.8185 | [email protected]| Rev. 09/20 6
(1) - In the eld
1.6 - Fore & Aft Control Switch
Up Position: Reel Lift function activated
Middle Position: Combine deck plate function activated
Down Position: Reel Fore & Aft function activated
- The Selector Valve for hydraulic functions on the Hawkins Corn Reel is controlled from the combine
cab with a 3-position switch.

Operation Guide
(2) - Service
308.708.8185 | [email protected]| Rev. 09/20 7
- Grease Reel Holders & Chain Box Zerk Bolts/Arms daily (10 hrs) to weekly (50 hrs) depending
on Fore & Aft usage
2.1 – The Hawkins Corn Reel is equipped with grease zerks at critical wear points. These should be
greased according to recommendations listed below. Graphite grease is recommended.
- Grease Corn Reel bearings daily (10 hours).

Operation Guide
(2) - Service
308.708.8185 | [email protected]| Rev. 09/20 8
- Lubricate Chain weekly (50 hours)
2.1 – The Hawkins Corn Reel is equipped with grease zerks at critical wear points. These should be
greased according to recommendations listed below. Graphite grease is recommended.
- Grease Corn Reel hinges weekly (50 hours) - If reel height is adjusted frequently, grease daily (10 hours)
Drago/Geringho
Hinge
Standard Hinge

Operation Guide
(2) - Service
308.708.8185 | [email protected]| Rev. 09/20 9
2.2 – General Maintenance
- Check all bolts for tightness after the rst 5 hours of operation and periodically throughout
the harvest season
- Recheck all bolts, tension chain, and check for any worn parts before each season of use.

Operation Guide
(3) - Enable Reel Function
3.1 - In order for the Hawkins Corn Reel to turn when using a 2600 series monitor, the reel option
must be selected in the setup process. The following steps layout the process for enabling the
reel function.
- Select header setup from the right side menu in the main
harvest screen.
- Select header width settings
- Select header width settings
308.708.8185 | [email protected]| Rev. 09/20 10

Operation Guide
(3) - Enable Reel Function
3.1 - In order for the Hawkins Corn Reel to turn when using a 4600 series monitor, the reel option
must be selected in the setup process. The following steps layout the process for enabling the
reel function.
- Select “Setup”from the bottom left side in the main harvest
screen.
- Select “Combine”under“Equipment”in the Work Setup
screen.
- Select “Header Settings”in the Equipment Setup screen.
308.708.8185 | [email protected]| Rev. 09/20 11

Operation Guide
(3) - Enable Reel Function
3.1 - In order for the Hawkins Corn Reel to turn when using a 4600 series monitor, the reel option
must be selected in the setup process. The following steps layout the process for enabling the
reel function.
- Press anywhere in the top selectable area in the Header
Setup screen.
- Press on the Box next to“Reel Installed”in the Header
Details screen to enable the Reel.
- With the check mark in the“Reel Installed”box, you can
wexit the setup menus and return back to the operating screen.
308.708.8185 | [email protected]| Rev. 09/20 12

Operation Guide
(3) - Enable Reel Function
3.1 - In order for the Hawkins Corn Reel to turn when using a Pro 700 series monitor, the reel option
must be selected in the setup process. The following steps layout the process for enabling
the reel function.
- On the main Run screen, press“Back”.
- Select “Toolbox”.
- Press the arrow button to scroll over to next page of tabs
308.708.8185 | [email protected]| Rev. 09/20 13

Operation Guide
(3) - Enable Reel Function
3.1 - In order for the Hawkins Corn Reel to turn when using a Pro 700 series monitor, the reel option
must be selected in the setup process. The following steps layout the process for enabling
the reel function.
- Select “Head 2”from the bottom tabs to enter the
Header Setup menu.
- Press down arrow to get to the second page of selections
under Header Setup 2.
- Press the arrow button to scroll over to next page of tabs
308.708.8185 | [email protected]| Rev. 09/20 14

Operation Guide
(3) - Enable Reel Function
3.1 - In order for the Hawkins Corn Reel to turn when using a Pro 700 series monitor, the reel option
must be selected in the setup process. The following steps layout the process for enabling
the reel function.
- Select the dropdown arrow under“Reel End Dividers”
and select“Yes”. This is how you would enable the corn reel.
- Press the Back button to get out of theToolbox Setup Menu.
- Press the“Run Screen”button to return to the operating screen.
308.708.8185 | [email protected]| Rev. 09/20 15
