Agua GUSTAVO User manual

1
TOWEL WARMER
INSTRUCTION MANUAL

2
Before using this product. Please read the following
instructions carefully and keep this pamphlet for
future reference.
ABOUT THE PRODUCT
This heated towel rail is designed for drying towels or clothes. It has a surface stabilized
temperature of 40°C -50°C (104°F -122°F) and it used in household bathrooms and kitch-
ens. This appliance is used under the voltage of 110V-120V AC and is manufactured accord-
ing to ETL standard.
SAFETY PRECAUTIONS
1. The supplied power system which is connected to the towel rail must be used with
a over-current protection device.
2. This product is supplied with the relevant, fitted three pin socket and
three-wire cable, to avoid any risks or danger it must be properly grounded.
3. Any change of the repair to the damaged internal wires must be done
by a qualified technician who is deemed qualified by the industry standard.
When any external wire fittings are required, the power must be cut o completely.
4. Any hard scrubbing or scratching on the product surface is strictly prohibited.
NOTE
1. In the event of any technical statistics dierence, please refer to the actual product.
2. Please wipe the towel rail with a soft dry clothes when cleaning it.
TOWEL WARMER
INSTRUCTION
MANUAL

3
REQUIRED TOOLS
ACCESSORIES LIST
Pencil Tape Measure Hammer Cross screwdriver Electric Drill
1pc
Power cord outlet wall bracket
3pcs
Normal wall bracket
Hardwired wall bracket
+
Hardwired wall panel
4pcs
Long screw
M6 x 45mm
1 pc
Screw M6x10
(16)mm
4pcs
Tapping
screw
1 pc
Screw
M5 x 8mm
4pcs
Wall
anchor
1 pc
Hex key
wrench
4pcs
Bushing
4pcs
M5 inner hex
angular set
screw
2pcs
Screw
M3.5 x 25mm
Leveling instrument
+
+
+
or
or
01
02
03
09
04
10
05
11
06 07 08

4
INSTALLATION STEPS
Drill the long screw (3) through the normal
wall bracket (1)
Screw down the long screw (3) to firmly
connect the normal wall bracket (1) to
the vertical bar. Note that the set screw
on the wall bracket should towards the floor
when the unit is installed.
Use tape to measure the distance between
these four holes, and the data AB, AC, CD
and BD
Mark A, B, C, D according to the distance.
We strongly suggest it is installed at least
600mm above the floor level.
Try to install the towel warmer and
use the leveling instrument to test
the levelness and perpendicularity.
01
02
03
04

5
INSTALLATION STEPS
Drill A, B, C, D holes with size Ø 8*D45mm.
Use hammer to knock wall anchor (5) into
the wall completely.
Insert the tapping screw (4) through
bushing (6). Then into the wall anchor (5),
make sure bushing (6) is firmly connected
to the wall.
Connect the wall bracket (1) to the
bushing (6), and tighten the set screw (7)
by hex key wrench (11). Then plug in
the unit and press the switch on.
05
06
07
A
C
D
B

6
INSTALLATION FOR HARDWIRED
Cut o the plug.
Take out the wall bracket (1).
Connect hardwired wall bracket and
panel (2) by screw (10). Screw down
the screw (9) to firmly connect
the hardwired wall bracket (2)
to the vertical bar.
Fix the hardwired wall panel with screw (9).
01
02
03
WARNING
1. Only use for drying textiles which have been dampened by water.
2. The original wire cannot be replaced, when it is unworkable, the whole
product should be replaced.
3. If the appliance is supplied from an extension cord set or electric portable
outlet device, then the extension cord set or electric portable outlet
device should be positioned so that it is not subject to splashing or
excessive moisture.

7
AVAILABLE MODELS & DIMENSIONS
GEORGIA GUSTAVO
GIOVANNA
