AHN myLab VT-01
Mini Vortex Mixer 4500 rpm
Instruction Manual

CONTENTS
1. Introduction.......................................................................... 1
2. IntendedUse......................................................................... 1
3. Features.................................................................................. 1
4. StandardPartListing......................................................... 2
5. SafetyPrecautions.............................................................. 2
6. Operation................................................................................ 3
7. TechnicalSpecifications.....................................................3
8. Maintenance&Cleaning.................................................. 5
9. Troubleshooting.................................................................. 6
10. WarrantyStatement.......................................................... 6
11.ProductDisposal................................................................. 7

1. INTRODUCTION
This Mini Vortex Mixer is available in two variants: Fixed Speed and
Variable speed. It comes with a powerful brushless DC motor and
delivers speed up to 4500 RPM. With an orbital motion of 4.5 mm it
provides thorough mixing and it can accommodate plastic tubes & vials
up to a 30 mm diameter.
2. INTENDED USE
It is used in laboratories for the general mixing of applications in
individual test tubes, up to a 30 mm diameter.
3. FEATURES
Touch Operation – can handle plastic tubes of up to 30 mm in
diameter
Extremely small footprint
4.5mm orbital motion
Suction cups for proper grip
Die cast base for stable operation
Low voltage power supply
Suspension design for longer switch life
Variable speed for gentle to vigorous mixing (Variable model)
1

Speed
Knob
Die Cast
Base
Silicone
Cup
Variable Fixed
4. STANDARD PART LISTING
5. SAFETY PRECAUTIONS
Read the following safety instructions before using the mini vortex mixer
for your safety & the safety of the equipment.
1. Gently take the mini vortex mixer out of the packaging box and
place it on a flat, stable, clean, non ‐ slippery surface.
2. Do not lift or hold the device from the power cable.
3. This mini vortex mixer is to be used to mix material that the user
knows will not react dangerously to any extra energy produced
from mixing.
4. The mini vortex mixer should be used for the specified application
only. It must not be operated in a hazardous or flammable
environment and must not be used to mix explosive or highly
reactive material.
5. Users should always use covered test tubes. Overfilling of liquid may
cause the medium to splash out.
6. Caution: The equipment will restart, both in case of power
interruption and in case of any fault or mechanical interruption.
Care should be taken based on the sample used for mixing.
2

7. Always use tubes up to 30 mm in diameter for best result and
product safety.
6. OPERATION
Operation starts automatically when the soft rubber cup is pressed
down using the test tube (as shown in
image) and stops once the test tube is
removed. In the variable mini vortex mixer,
rotate the speed knob to increase or
decrease the speed between 2500 to 4500
RPM. Rotate clockwise to increase the peed
and counter clockwise to decrease the
speed
7. TECHNICAL SPECIFICATIONS
Press
Down
Type of movement Orbital
4.5 mm
100 g
Touch
0.55 Kg
5 ‐ 40 °C
Up to 30 mm
100 x 100 x 70 mm
± 5 %
4500 RPM
Shaker diameter
Permissible shaking weight
(Include attachment)
Operation Type
Dimensions (L x W x H)
Weight
Permissible ambient
temperature
Tube diameter
Speed Accuracy
Maximum Speed
Variable Speed
Specification
No
Yes
Variable Fix
Noise Level <50 dB
3

8. MAINTENANCE & CLEANING
1. While cleaning, the product must not be plugged in to the power
supply.
2. The entire unit should be wiped down periodically with a soft cloth.
Excessive amount of liquid should be avoided. Liquid should not
come in contact with the motor.
3. After cleaning, ensure that all parts are dried before re‐use.
4. Do not use the unit if it shows signs of mechanical or electrical
damage. Do not use the equipment if the rubber cup or suction cup
is damaged. In such case, see warranty & contact manufacturing if
applicable
5. The brushless motor in the mini vortex mixer doesn’t require
routine maintenance. Any required service should be performed by
authorized, qualified personnel only.
<80%
IP 43
Permissible relative moisture
Protection class according
to DIN EN 60529
100 ‐ 240 V, 50 / 60 Hz
14 W
9 V , 1.5A
Input Voltage
Power Consumption
Output Voltage
Rated input of adaptor 0.3A
Air Pressure 80 to 106 kPa
Specification Variable Fix
4

9. TROUBLESHOOTING
Note: If aer implementaon of the required soluon does not produce normal
vortex acon, contact service representave.
10. WARRANTY STATEMENT
This product is warranted to be free from defects in material and
workmanship for a period of two (2) years from date of purchase. Your
product will be duly repaired upon prompt notification in compliance
with the following conditions :
This warranty is valid only if the product is used for its intended
purpose and within the guidelines specified in this instruction manual.
This warranty does not cover damage caused by accident, neglect,
misuse, improper service, natural forces or other causes not arising
from defects in original material or workmanship. This warranty does
not cover any incidental or consequential damages, commercial loss or
any other damages from the use of this product.
Soluon
Tighten the small
boom screw
(1/2 or 1
turns max)
Tighten the small
boom screw
(1 or 2
turns max)
Vortex
Acon
Parally
Working
(stops in
between)
Not working
at all.
(completely
stopped)
Connuously
working
(run without
press)
Problem
Small boom
screw might
have loosened.
Need to adjust
Small boom
screw might
have loosened.
Need to ghten
Small boom
screw might have
ghtened.
Need to loosen.
Loosen the small
boom screw
(1 or 2
turns max)
Small boom
screw at the
base of device
pointed by
an arrow.
5

6
For your reference, make a note of the serial number, date of
purchase and supplier here.
Serial No.:
Supplier:
Purchase Date:
• The warranty is invalidated by any non‐factory modification, which
will immediately terminate all liabilities on us for the products or
damages caused by its use. The customer shall be responsible for the
product or use of products as well as any supervision required for safety.
If requested the products must be returned to the distributor in well
packed and insured manner and all shipping charges must be paid.
Note: Some states do not allow limitation on the length of implied warranties or the
exclusion or limitation of incidental or consequential damages. This warranty gives you
specific legal rights. This warranty is given expressly in lieu of all other warranties,
expressed or implied.
• The purchaser agrees that there is no warranty of merchantability or
of fitness for any intended purpose and that there are no other
remedies or warranties, expressed or implied, which extend beyond the
description on the face of the agreement. This warranty is only
applicable to the original purchaser.
Products received without proper authorization will not be processed
for warranty or service. All items returned for service should be sent
with postage prepaid in the original packaging or other suitable
packaging, padded to avoid damage. We will not be responsible for
damage incurred by improper packaging.
Note: This warranty is valid only if the warranty is registered with the supplier within
30 days from the date of purchase.

7
11. PRODUCT DISPOSAL
In case the product is to be disposed of, the relevant legal regulations
are to be observed.
Information on the disposal of electrical and electronic devices in the
European Community
The disposal of electrical devices is regulated within the European
Community by national regulations based on EU Directive 2012/19/EU
on waste electrical and electronic equipment (WEEE). According to
these regulations, any devices supplied after 13.06.05 in the business to
business sphere, to which this product is assigned, may no longer be
disposed off in municipal or domestic waste. They are marked with the
following symbol to indicate this.
As disposal regulations within the EU may vary from country to country,
please contact your supplier if necessary.
