Mobile Commode & Footrests
VR166X, VR231X
Fixing and Maintenance Instructions

Fixing and Maintenance Instructions 2
INTRODUCTION
Thank you for choosing to purchase the Linton Mobile Commode/Footrests from Aidapt. The
Linton Mobile Commode and Footrests are manufactured using only the finest materials
available. If used in accordance ith the user instructions they should give you many years of
continuous service.
NB. This equipment must be installed by a competent person and a risk assessment
may be needed as to the suitability of the chair for the particular user.
eight Limit: 190 kg (30 stone)
Do not exceed the weight limit stated – doing so could put the user at risk.
BEFORE USE
•Carefully remove all packaging. Avoid using any knives or other sharp instruments as
this may damage the surface of the product.
•Check the product for any visible damage If you see any damage or suspect a fault, do
not use your product as it may compromise the safety of the user, but contact your
supplier for support.
ASSEMBLY
The package contains the following components:
• The main frame with four brake castors attached
• White commode plastic aperture seat (attached to the main frame)
• Grey commode seat cover
• A pair of detachable arms
• Detachable back
VR166X Commode w/Footrests
VR231X Height adjustable commode w/Footrest
Please read the following installation instructions carefully:
1. Remove all contents from the box
2. Place the assembled base on a level floor
3. At the rear of the commode you will see two black threaded wheel nuts; undo the wheel nuts
so that
the locking holes are clear
4. Place the two back legs into the locating holes on the back edge of the commode frame
5. Secure the back by turning the black lock nuts until you feel the nut biting against the back
leg.
6. Do no over tighten
7. Do not use tools as it is only necessary to have the back secured finger tight
8. Place the two detachable arms into the four locating holes featured two each side of the
commode

Fixing and Maintenance Instructions
3
FOOTRESTS
Footrests are supplied separately to the main commode. Please examine your footrests for
any visible damage before use. If you see any damage or suspect a fault, please contact your
supplier immediately.
In this case, please do not use your product as it may compromise your safety.
1. Remove the commode footrests from their packaging
2. You ill see on each of the front legs of the commode main frame about 150 mm
high from the castor 2 retaining lugs either side
3. Take the footrests and align the holes in the inverted ‘U’ section ith the lugs and
lo er do n into place.
4. Rotate the footrests to ards the commode so that they clip into place.
USE OF THE COMMODE
When moving al ays lift the commode by placing you hands on the tubular metal frame
beneath the blo moulded seat.
•Do not allo children or unauthorised persons to play ith or use the commode.
•Do not rock back and forth or side ays hen using the commode as this ill cause
excessive stress and possible damage and failure hich may cause injury.
•Do not use the commode outside the home or on uneven surfaces (such as in the
garden) as this ill cause stress to the legs and possible damage hich may cause
injury. It is not intended as a heelchair.
•Do not place fingers or foreign objects into any of the exposed tubular sections as
this can lead to serious injury.
•When operating the brake mechanism, do not stamp on the lever as this may cause
damage to the mechanism and possible failure.
•Not for use in the sho er. Dry immediately if the Linton becomes et.
CLEANING
A useful guide to decontamination is MHRA leaflet DB2003(06).
Do not use abrasive cleaners as this could damage the surface of the equipment. For
cleaning, ipe ith a clean cloth soaked in detergent solution and ring out. Depending on
the detergent manufacturer’s instructions the solution may be heated.
Wipe all surfaces of the equipment and the cloth should be re-immersed periodically and the
detergent changed frequently. The detergent should be rinsed or iped off using a clean
cloth immersed in clean ater and rung out.
To disinfect make sure the equipment has been cleaned and dried and then ipe over ith a
clean cloth and a compatible liquid disinfectant. After disinfecting clean ith clean ater
and dry.
When using detergent or disinfectants then please refer to manufacturers’ instructions and if
unsure then consult your local Infection Control Specialist for advice.
This equipment can be cleaned/disinfected by moist heat at 80oC for a minimum of 1 minute
or autoclaved at 80oC for at least 1 minute. After cleaning or disinfecting dry and treat all
joints ith a ater dispersing agent, e.g. WD40.

TECHNICAL SPECIFICATION - VR166X
Colour = Grey/Chrome
Overall height............................................................970mm
Overall width..............................................................520mm
Overall depth..............................................................580mm
Main body frame to end of footrest...................240mm
PU seat dimensions.................................................430mm x 430mm
Width between arms...............................................440mm
Net weight.................................................................13.6kg
Gross weight..............................................................14.5kg
Max user weight........................................................190kg (30stone)
Fixing and Maintenance Instructions
4
Transport dimensions..............................................520 x 585 x 545mm

TECHNICAL SPECIFICATION - VR166X
Fixing and Maintenance Instructions
5

TECHNICAL SPECIFICATION - VR231X
Colour = Grey and Chrome
Overall height............................................................970 - 1045mm
Overall width..............................................................520mm
Overall depth..............................................................580mm
Main body frame to end of footrest...................240mm
PU seat dimensions.................................................430mm x 430mm
Width between arms...............................................440mm
Net weight.................................................................13.6kg
Gross weight..............................................................14.5kg
Max user weight........................................................190kg (30stone)
Fixing and Maintenance Instructions
6
Transport dimensions..............................................340 x 545 x 555mm

TECHNICAL SPECIFICATION - VR231X
Fixing and Maintenance Instructions
8

HEIGHT ADJUSTMENT - VR231X
NB. Before attempting to adjust the height of your commode, always ensure
that the commode
pail is removed.
To adjust the height of your VR231X carefully lay the commode on its side. Remove
all the e-clips and adjust all four legs equally to the desired height.
Re-insert the e-clips ensuring that each one passes through the frame and the
correct hole in the extension leg.
Return the commode to the upright position and make sure that all wheels are
sitting evenly on the floor.
NB. Never extend the legs in a manner that the commode is slanting, this will
compromise the safety of the user.
Fixing and Maintenance Instructions
7

Fixing and Maintenance Instructions
9
COMPOSITION
The frame is made from chromium-plated mild steel. You must not, under any
circumstances, use any abrasive cleaners or cleaners hich attack chromium plating.
COMMODE BUCKET
To remove the commode bucket, simply slide the bucket out from the chrome runners at the
rear of the commode. Cover the top of the bucket to avoid splashing, carefully dispose of the
contents into a proper sluice or WC.
Never use an open drain, sink or basin. This could cause a serious health risk.
Clean out the residue ith a suitable disinfectant and refit to the commode after use.
REISSUE
If you reissue or are about to reissue this product, please thoroughly check all components
for their safety.
This includes:
•Tightness of all nuts/bolts/castors and other scre in/bolt in/push in components.
•Also check all upholstery (if applicable) for security, splits, exposed staples, etc.
If in any doubt, please do not issue or use, but immediately contact your supplier for
service support.
When reissuing, a risk assessment may be required as to the suitability of the chair for a
particular user
CARE & MAINTENANCE
Please make a safety check of the product at regular intervals or if you have any concerns.
IMPORTANT INFORMATION
The information given in this instruction booklet must not be taken as forming part of or
establishing any contractual or other commitment by Aidapt Bathrooms Limited, Aidapt
(Wales) Ltd or its agents or its subsidiaries and no arranty or representation concerning the
information is given.
Please exercise common sense and do not take any unnecessary risks hen using this
product; as the user you must accept liability for safety hen using the product.
Please do not hesitate to contact the person ho issued this product to you or the
manufacturer (detailed belo ) if you have any queries concerning the assembly/use of your
product.
