Sunrise Medical Quickie Wheelchair ST/DT Guide

User
Instruction
Manual &
Warranty
Quickie ST/DT
SUPPLIER:
THIS MANUAL MUST BE GIVENTO THE RIDER OFTHIS
WHEELCHAIR.
RIDER:
BEFORE USINGTHISWHEELCHAIR READTHIS ENTIRE
MANUALAND SAVE FOR FUTURE REFERENCE

QUICKIE LISTENS
Thank you for choosing a Quickie wheelchair. We want to hear your questions or
comments about this manual,the safety and reliability of your chair, and the service
you receive from your Quickie supplier. Please feel free to write or call us at the
address and telephone number below:
Sunrise Medical
Customer Service Department
7477 East Dry Creek Parkway
Longmont,CO 80503
[phone]
Be sure to return your warranty card,and let us know if you change your address.
This will allow us to keep you up to date with information about safety, new prod-
ucts and options to increase your use and enjoyment of this wheelchair. You will
also receive a free subscription to Quickie Chronicles,a newsletter just for Quickie
users. If you lose your warranty card,call or write and we will gladly send you a
new one.
FOR ANSWERS TO YOUR QUESTIONS
Your authorized Quickie supplier knows your wheelchair best, and can answer
most of your questions about chair safety, use and maintenance. For future refer-
ence, fill in the following:
Quickie Supplier: ______________________________________________________________________
Address: ______________________________________________________________________________
______________________________________________________________________________________
Telephone:____________________________________________________________________________
Serial #: _____________________________________ Date/Purchased: ________________________
I.INTRODUCTION
1

2
1. INTRODUCTION .............................................................................. 1
a.Quickie Listens...................................................................................... 1
11. TABLE OF CONTENTS .................................................................. 2
III. YOUR CHAIR AND ITS PARTS ................................................ 4
IV. NOTICE - READ BEFORE USE .................................................. 6
a. Choose the Right Chair & Safety Option...................................... 6
b. Review this Manual Often ................................................................ 6
c.Warnings.................................................................................................. 6
V. GENERALWARNINGS.................................................................... 7
a. Weight Limit ........................................................................................ 7
b. WeightTraining .................................................................................... 7
c. Getting to KnowYour Chair ............................................................ 7
d. To ReduceThe Risk of anAccident ................................................ 7
e. Safety Checklist .................................................................................. 8
f. Changes &Adjustments .................................................................... 8
g. Environmental Conditions ................................................................ 8
h. Terrain .................................................................................................... 8
i. Street Use ............................................................................................ 8
j. MotorVehicle Safety .......................................................................... 9
k. WhenYou Need Help ........................................................................ 9
VI. WARNINGS: FALLS &TIP-OVERS .......................................... 10
a. Center of Balance .............................................................................. 10
b. Dressing or Changing Clothes ........................................................ 10
c. Wheelies .............................................................................................. 11
d. Obstacles .............................................................................................. 11
e. Reaching or Leaning .......................................................................... 11
f. Moving Forward .................................................................................. 12
g. Ramps,Slopes & Side Hills ................................................................ 12
h. Transfers ................................................................................................ 13
i. Curbs & Steps ...................................................................................... 14
j. Stairs ...................................................................................................... 14
k. Escalators .............................................................................................. 14
VII. WARNINGS: COMPONENTS & OPTIONS ........................ 15
a. Amputee or“Extended”Axle Plates .............................................. 15
b. Anti-TipTubes ...................................................................................... 15
c. Armrests .............................................................................................. 15
d. Cushion & Sling Seats ........................................................................ 15
e. Fasteners .............................................................................................. 16
f. Footrests................................................................................................ 16
g. PneumaticTires .................................................................................. 16
h. Positioning Belts .................................................................................. 16
II. TABLE OF CONTENTS
i. Power Drive ........................................................................................ 17
j. Quick-Release Axles .......................................................................... 17
k. RearAxles ............................................................................................ 17
l. RearWheel Locks .............................................................................. 17
m.Modified Seat Systems ...................................................................... 18
n. Upholstery Fabric .............................................................................. 18
VIII. TIPS FOR ATTENDANTS ............................................................ 19
a. Learning to do a“Wheelie” ............................................................ 19
b. Descending a Curb or Single Step .................................................. 19
c. Climbing a Curb or Single Step ...................................................... 20
d. Climbing Stairs .................................................................................... 20
e. Descending Stairs ................................................................................ 20
IX. CHAIR BASICS .................................................................................. 21
a. To Mount & Remove RearWheels ................................................ 21
X. SET-UP AND ADJUSTMENTS .................................................... 22
a.Wheels .................................................................................................... 22
b.Wheel Locks ........................................................................................ 22
c.Armrests (Optional) ............................................................................ 23
d.Anti-TipTubes (Optional) .................................................................. 23
e. Height AdjustableArmrest (Optional) .......................................... 24
f.Folding Backrest .................................................................................... 24
g.Back Angle Adjustable (Folding Backrest) ...................................... 24
h.CamberTube ........................................................................................ 25
i.Wheel Locks .......................................................................................... 26
j.Footrest .................................................................................................. 27
k.Anti-TipTubes (Optional) .................................................................. 27
XI. TROUBLESHOOTING .................................................................... 26
X11. MAINTENANCE ................................................................................ 27
XIII. QUICKIE LIMITEDWARRANTY .............................................. 29
II. TABLE OF CONTENTS
3

1. Backrest
2. Pneumatic tire
3. Seat cushion
4. Seat sling (not shown)
5. Scissor wheel lock
6. Leg strap
7. Footrest
8. Aluminum handrim
9. Spokes
10. Rear wheel hub
11. Quick-release axle
12. Aluminum wheel rim
13. Caster housing
14. Caster fork
15. Caster wheel
4
III. YOUR CHAIR AND ITS PARTS
Quickie Shadow ST/DT
Weight
22 lbs.with steel rear axles
20.5 lbs.with titanium rear axles and
performance wheels
Adjustments
1” vertical caster adjustment with
2-hole fork
2” wheelbase width adjustment
6oseat angle adjustment
Colors
Blue, Black, Red, Midnight Purple,Teal
Pearl Pink,Lavender,Forest Green
Burgundy,Yellow, Blue Green,Candy
Teal, Candy Razzberry,Candy Purple
Chair Parts
Std - Black
Frame Dimensions
Frame width: Std - 12”-20”
Sling depth: 12”-19”
Cushion: 2”,3”, 4”
Backrest
Folding - adjustable height: 11”-14”,
15”-18”
Backrest options: push handles,
adjustable upholstery
Footrests
Std - Rigid (Shadow ST)
Std - Platform (Shadow DT)
Opt -Adaptive,adjustable
Impact guards - neoprene
Casters
Std - 5”,low-profile polyurethane
Opt - 3” micros,(may require differ-
ent forks,stems or spacers)
Armrests
Opt - height-adjustable
CamberTubes
0o,3o,6o,9o,12o,15
o
Axles
Std - stainless steel
Opt - titanium,quad-release axle
nuts
Standard Rear Wheels
Std - spoke
Opt - mountain
Quickie Performance Wheels
Opt - tennis,basketball,heat-treated
tennis,heat-treated basketball
Tire Size
Std - 24”
Opt - 22”,26”
All features may not be available with
some chair set-ups or in conjunction
with another chair feature. Please
consult your Quickie Sports Center
for more information.
5
III. YOUR CHAIR AND ITS PARTS
1
2
3
5
6
8
9
10
11
12
13
19
714
15

6
A. CHOOSE THE RIGHT CHAIR & SAFETY OPTIONS
Quickie provides a choice of many wheelchair styles to meet the needs of the
wheelchair rider. However, final selection of the type of wheelchair, options
and adjustments rests solely with you and your health care advisor. Choosing
the best chair and set-up for your safety depends on such things as:
1. Your disability,strength,balance and coordination.
2. The types of hazards you must overcome in daily use (where you live and
work,and other places you are likely to use your chair).
3. The need for options for your safety and comfort (such as anti-tip tubes,
positioning belts,or special seating systems).
B. REVIEW THIS MANUAL OFTEN
Before using this chair you,and each person who may assist you,should read
this entire manual and make sure to follow all instructions. Review the warn-
ings often,until they are second nature to you.
C. WARNINGS
The word "WARNING" refers to a hazard or unsafe practice that may cause
severe injury or death to you or to other persons. The "Warnings" are in
three main sections,as follows:
1. V — GENERALWARNINGS
Here you will find a safety checklist and a summary of risks you need to be
aware of before you ride this chair.
2. VI —WARNINGS — FALLS &TIP-OVERS
Here you will learn how to avoid a fall or tip-over while you perform daily
activities in your chair.
3. VII —WARNINGS — COMPONENTS & OPTIONS
Here you will learn about the components of your chair and options you can
select for safety. Consult your authorized Quickie supplier and your health
care advisor to help you choose the best set-up and options for
safe use.
Note: Where they apply, you will also find "Warnings" in other sections of this Manual.
IV. NOTICE—READ BEFORE USE
7
A.WEIGHT LIMIT
NEVER exceed the weight limit of 250 pounds (113.6 kilograms) for
combined weight of rider and items carried. This may cause the chair to fail.
B. WEIGHT TRAINING
NEVER use this chair for weight training if total weight (rider plus equipment)
exceeds 250 pounds. This is likely to damage seat, frame and fasteners and will
void the warranty.
C. GETTING TO KNOW YOUR CHAIR
Every wheelchair is different. Take the time to learn the feel of this chair
before you begin riding. Start slowly, with easy,smooth strokes. If you are
used to a different chair,you may use too much force and tip over.
D. TO REDUCE THE RISK OF AN ACCIDENT
1. BEFORE riding,you should be trained in the safe use of this chair by your
health care advisor.
2. Practice bending,reaching and transfers until you know the limit of your
ability. Have someone help you until you know what can cause a fall or
tip-over and how to avoid doing so.
3. Be aware that you must develop your own methods for safe use best
suited to your level of function and ability.
4. NEVER try a new maneuver on your own until you are sure you can do it
safely.
5. Get to know the areas where you plan to use your chair. Look for hazards
and learn how to avoid them.
6. Use anti-tip tubes unless you are a skilled rider of this chair and are sure
you are not at risk to tip over.
E. SAFETY CHECKLIST
Before Each Use Of Your Chair:
1. Make sure the chair rolls easily and that all parts work smoothly. Check
for noise, vibration, or a change in ease of use. (They may indicate low tire
pressure, loose fasteners,or damage to your chair.)
2. Repair any problem. Your authorized Quickie supplier can help you find
and correct the problem.
3. Check to see that both quick-release rear axles are locked. When locked,
the axle button will "pop out" fully. (See p. 21) If not locked,the wheel
may come off and cause you to fall.
4. If your chair has anti-tip tubes,lock them in place.
Note: See p.21 for times you should not use them.
V. GENERAL WARNINGS
▲
!
Heed all warnings in this section. If you fail to do so a fall,tip-over or loss
of control may occur and cause severe injury to the rider or others.
▲
!WARNINGS

8 9
3. NEVER transport this chair in the front seat of a vehicle. It may shift and
interfere with the driver.
4. ALWAYS secure this chair so that it cannot roll or shift.
K. WHEN YOU NEED HELP
ForThe Rider:
Make sure that each person who helps you reads and follows all warnings and
instructions that apply.
For Attendants:
1.Work with the rider's doctor,nurse or therapist to learn safe methods best
suited to your abilities and those of the rider.
2.Tell the rider what you plan to do,and explain what you expect the rider to
do. This will put the rider at ease and reduce the risk of an accident.
3.Make sure the chair has push handles. They provide secure points for you
to hold the rear of the chair to prevent a fall or tip-over.
•Check to make sure push handle grips will not rotate or slip off.
4.To prevent injury to your back,use good posture and proper body mecha-
nics. When you lift or support the rider or tilt the chair, bend your knees
slightly and keep your back as upright and straight as you can.
5.Remind the rider to lean back when you tilt the chair backward.
6.When you descend a curb or single step,slowly lower the chair
in one easy movement.
• Do not let the chair drop the last few inches to the ground.
This may damage the chair or injure the rider.
7.To avoid tripping,unlock and rotate anti-tip tubes up,out of the way.
8. ALWAYS lock the rear wheels and lock anti-tip tubes in place if you must
leave the rider alone, even for a moment. This will reduce the risk of a tip
over or loss of control of the chair.
V. GENERAL WARNINGS
▲
!
F. CHANGES & ADJUSTMENTS
If you modify or adjust this chair, it may increase the risk of a tip-over UNLESS
you make other changes as well.
1. Consult your authorized Quickie supplier BEFORE you modify or adjust
your chair.
2. We recommend that you use anti-tip tubes until you adapt to the change,
and are sure you are not at risk to tip over.
G. ENVIRONMENTAL CONDITIONS
1. Use extra care if you must ride your chair on a wet or slick surface. If you
are in doubt,ask for help.
2. Contact with water or excess moisture may cause your chair to rust or
corrode. This could cause your chair to fail.
a. Do not use your chair in a shower, pool or other body of water. The
chair tubing and parts are not water-tight and may rust or corrode from
the inside.
b. Avoid excess moisture (for example, do not leave your chair in a damp
bathroom while taking a shower).
c. Dry your chair as soon as you can if it gets wet,or if you use water to
clean it.
H.TERRAIN
1. Your chair is designed for use on firm, even surfaces such as concrete,
asphalt and indoor floors and carpeting.
2. Do not operate your chair in sand,loose soil or over rough terrain.
This may damage wheels or axles, or loosen fasteners of your chair.
I. STREET USE
In most states,wheelchairs are not legal for use on public roads. Be alert
to the danger of motor vehicles on roads or in parking lots.
1. At night,or when lighting is poor,use reflective tape on your chair and
clothing.
2. Due to your low position,it may be hard for drivers to see you. Make eye
contact with drivers before you go forward. When in doubt,yield until you
are sure it is safe.
J. MOTOR VEHICLE SAFETY
Quickie wheelchairs do not meet federal standards for motor vehicle seating.
1. NEVER let anyone sit in this chair while in a moving vehicle.
a. ALWAYS move the rider to an approved vehicle seat.
b. ALWAYS secure the rider with proper motor vehicle restraints.
2. In an accident or sudden stop the rider may be thrown from the chair.
Wheelchair seat belts will not prevent this,and further injury may result
from the belts or straps.
V. GENERAL WARNINGS
▲
!

10
A.CENTER OF BALANCE
The point where this chair will tip forward,back, or to the side depends on
its center of balance and stability. How your chair is set up, the options you
select and the changes you make, may affect the risk of a fall or tip-over.
1. The Most Important Adjustments Are:
a. The position of the rear axles. The more you move the axles forward,the
more likely your chair will tip over backward.
b. The position of the front casters. Moving the casters back (or "reversing"
them) will increase the risk of tipping forward.
2. The Center Of Balance IsAlso Affected By:
a. A change in the set-up of your chair,including:
• The distance between the rear wheels.
• The amount of rear wheel camber.
• The seat height and seat angle.
b. A change in your body position,posture or weight distribution.
c. Riding your chair on a ramp or slope.
d. The use of a back pack or other options,and the amount of added weight.
3. To ReduceThe Risk OfAn Accident:
a. Consult your doctor,nurse or therapist to find out what axle and caster
position is best for you.
b. Consult your authorized Quickie supplier BEFORE you modify or adjust
this chair. Be aware that you may need to make other changes to correct
the center of balance.
c. Have someone help you until you know the balance points of your chair
and how to avoid a tip-over.
d. Use anti-tip tubes.
B. DRESSING OR CHANGING CLOTHES
Your weight may shift if you dress or change clothes while seated in this chair.
To reduce the risk of a fall or tip-over:
1. Rotate the front casters until they are as far forward as possible. This
makes the chair more stable. (See p. 27)
2. Lock anti-tip tubes in place. (If your chair does not have anti-tip tubes,
back it up against a wall and lock both rear wheels.)
VI. WARNINGS: FALLS & TIP-OVERS
▲
!
Heed all warnings in this section. If you fail to do so a fall,tip-over or loss
of control may occur and cause severe injury to the rider or others.
▲
!WARNINGS
11
C. WHEELIES
Doing a "wheelie" means: balancing on the rear wheels of your chair,while the
front casters are in the air. It is dangerous to do a "wheelie" as a fall or tip-
over may occur. However, if you do it safely, a "wheelie" can help you over-
come curbs and obstacles.
1. Consult your doctor, nurse or therapist to find out if you are a good candi-
date to learn to do a "wheelie."
2. Do not attempt a "wheelie" UNLESS you are a skilled rider of this chair,or
you have help.
Note: See p.19 for steps to learn to do a "wheelie."
D. OBSTACLES
Obstacles and road hazards (such as potholes and broken pavement) can damage
your chair and may cause a fall, tip-over or loss of control. To avoid these risks:
1. Keep a lookout for danger — scan the area well ahead of your chair as
you ride.
2. Make sure the floor areas where you live and work are level and free of
obstacles.
3. Remove or cover threshold strips between rooms.
4. Install a ramp at entry or exit doors. Make sure there is not a drop off
at the bottom of the ramp. (See p. 12)
5. To Help CorrectYour Center Of Balance:
a. Lean your upper body FORWARD slightly as you go UP over an
obstacle.
b. Press your upper body BACKWARD as you go DOWN from a higher
to a lower level.
6. If your chair has anti-tip tubes,lock them in place before you go UP over
an obstacle.
7. Keep both of your hands on the handrims as you go over an obstacle.
8. Never push or pull on an object (such as furniture or a doorjamb) to
propel your chair.
E. REACHING OR LEANING
If you reach or lean it will affect the center of balance of your chair. This may
cause you to fall or tip over. When in doubt, ask for help or use a device to
extend your reach.
1. NEVER reach or lean if you must shift your weight sideways or rise up off
the seat.
2. NEVER reach or lean if you must move forward in your seat to do so.
Always keep your buttocks in contact with the backrest.
VI. WARNINGS: FALLS & TIP-OVERS
▲
!

12
VI. WARNINGS: FALLS & TIP-OVERS
▲
!
3. NEVER reach with both hands (you may not be able to catch yourself to
prevent a fall if the chair tips).
4. NEVER REACH OR LEANTOTHE REAR unless your chair has anti-tip
tubes locked in place.
5. DO NOT REACH OR LEAN OVERTHETOP OFTHE SEAT BACK. This
may damage one or both backrest tubes and cause you to fall.
6. If You Must Reach Or Lean:
a. Do not lock the rear wheels. This creates a tip point and makes a fall
or tip-over more likely.
b. Do not put pressure on the footrests.
Note: Leaning forward puts pressure on the footrests and may cause the chair to tip if
you lean too far.
c. Move your chair as close as you can to the object you wish to reach.
d. Do not try to pick up an object from the floor by reaching down
between your knees. You are less likely to tip if you reach to the side
of your chair.
e. Rotate the front casters until they are as far forward as possible. This
makes the chair more stable. Note: To do this: Move your chair past
the object you want to reach, then back up alongside it. Backing up will
rotate the casters forward.
f. Firmly grasp a rear wheel or an armrest with one hand. This will help
to prevent a fall if the chair tips.
F. MOVING BACKWARD
Use extra care when you move your chair backward. You may lose control or
tip over if one of the rear wheels hits an object and stops rolling.
1. Propel your chair slowly and smoothly.
2. If your chair has anti-tip tubes,make sure to lock them in place.
3. Stop often and check to be sure your path is clear.
G. RAMPS, SLOPES & SIDE HILLS
RIDING ONA SLOPE, WHICH INCLUDES A RAMP OR SIDE HILL, will
change the center of balance of your chair. Your chair is less stable when it is
at an angle. Anti-tip tubes may not prevent a fall or tip-over.
1. Do not use your chair on a slope steeper than 10%. (A 10% slope means:
one foot in elevation for every ten feet of slope length.)
2. Always go as straight up and as straight down as you can. (Do not "cut the
corner" on a slope or ramp.)
3. Do not turn or change direction on a slope.
4. ALWAYS STAY INTHE CENTER OFTHE RAMP. Make sure ramp is wide
enough that you are not at risk that a wheel may fall over the edge.
5. Do not stop on a steep slope. If you stop,you may lose control of your chair.
13
VI. WARNINGS: FALLS & TIP-OVERS
▲
!
6. NEVER use rear wheel locks to try to slow or stop your chair. This is like-
ly to cause your chair to veer out of control.
7. Beware Of:
a. Wet or slippery surfaces.
b. A change in grade on a slope (or a lip,bump or depression). These may
cause a fall or tip-over.
c. A drop-off at the bottom of a slope. A drop-off of as small as 3/4 inch
can stop a front caster and cause the chair to tip forward.
8. To ReduceThe Risk OfA Fall OrTip-Over:
a. Lean or press your body UPHILL. This will help adjust for the change in
the center of balance caused by the slope or side hill.
b. Keep pressure on the handrims to control your speed on a down slope.
If you go too fast you may lose control.
c. Ask for help any time you are in doubt.
9. Ramps At Home &Work
For your safety, ramps at home and work must meet all legal requirements
for your area.We recommend:
a. Width. At least four feet wide.
b. Guardrails. To reduce the risk of a fall, sides of ramp must have
guardrails (or raised borders at least three inches high).
c. Slope. Not more than a 10% grade. (See p. 12)
d. Surface. Flat and even, with a thin carpet or other non-skid material.
(Make sure there is no lip,bump or depression.)
e. Bracing. Ramp must be STURDY. You may need bracing so ramp does
not "bow" when you ride on it.
f. AvoidA Drop Off. You may need a section at the top or bottom to
smooth out the transition.
H.TRANSFERS
It is dangerous to transfer on your own. It requires good balance and agility.
Be aware that there is a point during every transfer when the wheelchair seat
is not below you.
To AvoidA Fall:
1. Work with your health care advisor to learn safe methods.
a. Learn how to position your body and how to support yourself during
a transfer.
b. Have someone help you until you know how to do a safe transfer on
your own.
2. Lock the rear wheels before you transfer. This keeps the rear wheels
from rolling.
Note: This will NOT keep your chair from sliding away from you or tipping.

14
3. Make sure to keep pneumatic tires properly inflated. Low tire pressure
may allow the rear wheel locks to slip.
4. Move your chair as close as as you can to the seat you are transferring to.
If possible, use a transfer board.
5. Rotate the front casters until they are as far forward as possible.
(See p. 27)
6. If you can,remove or swing footrests out of the way.
a. Make sure your feet do not catch in the space between the footrests.
b. Avoid putting weight on the footrests as this may cause the chair to tip.
7. Make sure armrests are out of the way and do not interfere.
8. Transfer as far back onto the seat surface as you can. This will reduce the
risk that the chair will tip or move away from you.
I. CURBS & STEPS
1. Each person who helps you should read and follow the warnings "For
Attendants" (p. 19),and the "Tips ForAttendants" (p. 9).
2. Do not try to climb or descend a curb or step alone UNLESS you are a
skilled rider of this chair and:
a. You can safely do a "wheelie";and
b. You are sure you have the strength and balance to do so.
3. Unlock and rotate anti-tip tubes up,out of the way, so they do not interfere.
4. Do not try to climb a high curb or step (more than 4 inches high) UNLESS
you have help. Doing so may cause your chair to exceed its balance point
and tip over.
5. Go straight up and straight down a curb or step. If you climb or descend
at an angle, a fall or tip-over is likely.
6. Be aware that the impact of dropping down from a curb or step can dam-
age your chair or loosen fasteners.
J. STAIRS
1. NEVER use this chair on stairs UNLESS you have someone to help you.
Doing so is likely to cause a fall or tip-over.
2. Persons who help you should read and follow the warnings "For
Attendants" (p. 19),and the "Tips ForAttendants" (p. 9).
K. ESCALATORS
NEVER use this chair on an escalator, even with an attendant. If you do,a fall
or tip-over is likely.
Note: If you modify this chair or use parts not approved by Quickie,it may void the
warranty and create a safety hazard.
VI. WARNINGS: FALLS & TIP-OVERS
▲
!
15
A.AMPUTEE OR "EXTENDED" AXLE PLATES (Optional)
Use extended axle plates for amputees or for persons with short leg length
or minimal leg mass. They allow you to set the rear axles farther back. This
adjusts the center of balance and will reduce the risk of a fall or tip-over.
B. ANTI-TIP TUBES (Optional)
Anti-tip tubes can help keep your chair from tipping over backward in most
normal conditions.
1. Quickie Recommends Use OfAnti-TipTubes:
a. UNLESS you are a skilled rider of this chair and are sure you are not at
risk to tip over.
b. Each time you modify or adjust your chair. The change may make it easier
to tip backward. Use anti-tip tubes until you adapt to the change, and are
sure you are not at risk to tip over.
2. When locked in place (in the "down" position) anti-tip tubes should be
BETWEEN 1 1/2 to 2 inches off the ground.
a. If set too HIGH,they may not prevent a tip-over.
b. If set too LOW, they may "hang up" on obstacles you can expect in normal
use. If this occurs, you may fall or your chair may tip over.
3. Keep Anti-TipTubes Locked In Place UNLESS:
a. You have an attendant;or
b. You have to climb or descend a curb, or overcome an obstacle,and can
safely do so without them.
At these times,make sure anti-tip tubes are up, out of the way.
C. ARMRESTS
Armrests detach and will not bear the weight of this chair.
1. NEVER lift this chair by its armrests. They may come loose or break.
2. Lift this chair only by non-detachable parts of the main frame.
D. CUSHIONS & SLING SEATS
1. Quickie sling seats and standard foam cushions are not designed for the
relief of pressure.
2. If you suffer from pressure sores,or if you are at risk that they will occur,
you may need a special seat system or a device to control your posture.
• Consult your doctor, nurse or therapist to find out if you need such a
device for your well-being.
VI. WARNINGS: FALLS & TIP-OVERS
▲
!
Heed all warnings in this section. If you fail to do so a fall,tip-over or loss
of control may occur and cause severe injury to the rider or others.
Note: If you modify this chair or use parts not approved by Quickie,it may void
the warranty and create a safety hazard.
▲
!WARNINGS

16
E. FASTENERS
Many of the screws,bolts and nuts on this chair are special high-strength fas-
teners. Use of improper fasteners may cause your chair to fail.
1. ONLY use fasteners provided by an authorized Quickie supplier (or ones
of the same type and strength,as indicated by the markings on the heads).
2. Over- or under-tightened fasteners may fail or cause damage to chair parts.
3. If bolts or screws become loose,tighten them as soon as you can.
F. FOOTRESTS
1. At the lowest point,footrests should beAT LEAST 21/2” off the ground.
If set too LOW, they may "hang up" on obstacles you can expect to find in
normal use. This may cause the chair to stop suddenly and tip forward.
2. To Avoid ATrip Or Fall WhenYou Transfer:
a. Make sure your feet do not "hang up" or get caught in the space
between the footrests.
b. Avoid putting weight on the footrests,as the chair may tip forward.
c. Remove or swing the footrests out of the way, if possible.
3. NEVER lift this chair by the footrests. Footrests detach and will not bear
the weight of this chair. Lift this chair only by non-detachable parts of the
main frame.
G. PNEUMATIC TIRES
Proper inflation extends the life of your tires and makes your chair easier
to use.
1. Do not use this chair if any of the tires is under- or over-inflated. Check
weekly for proper inflation level,as listed on the tire sidewall.
2. Low pressure in a rear tire may cause the wheel lock on that side to slip
and allow the wheel to turn when you do not expect it.
3. Low pressure in any of the tires may cause the chair to veer to one side
and result in a loss of control.
4. Over-inflated tires may burst.
H.POSITIONING BELTS (Optional)
Use positioning belts ONLY to help support the rider's posture. Improper
use of these belts may cause severe injury to or death of the rider.
1. Make sure the rider does not slide down in the wheelchair seat. If this
occurs,the rider may suffer chest compression or suffocate due to pres-
sure from the belts.
2. The belts must be snug,but must not be so tight that they interfere with
breathing. You should be able to slide your open hand,flat,between the
belt and the rider.
3. A pelvic wedge or a similar device can help keep the rider from sliding
down in the seat. Consult with the rider's doctor, nurse or therapist to
find out if the rider needs such a device.
VI. WARNINGS: FALLS & TIP-OVERS
▲
!
17
4. Use positioning belts only with a rider who can cooperate. Make sure
the rider can easily remove the belts in an emergency.
5. NEVER Use Positioning Belts:
a. As a patient restraint. A restraint requires a doctor's order.
b. On a rider who is comatose or agitated.
c. As a motor vehicle restraint. In an accident or sudden stop the rider
may be thrown from the chair. Wheelchair seat belts will not prevent
this,and further injury may result from the belts or straps.
I. POWER DRIVE
Do not install a power drive on any Quickie wheelchair. If you do:
1. It will affect the center of balance of your chair and may cause a fall
or tip-over.
2. It will alter the frame and void the warranty.
J. QUICK-RELEASE AXLES
1. Do not use this chair UNLESS you are sure that both quick-release rear
axles are locked. An unlocked axle may come off during use and cause a fall.
2. An axle is not locked until the quick-release button pops out fully.and the
ball bearings are fully visible on the outside of the sleeve. (See p. 22)
K. REAR AXLES
A change in set-up of the rear axles will affect the center of balance of your
chair.
1. The farther you move the rear axles FORWARD,the more likely it is that
your chair will tip over backward.
2. Consult your doctor, nurse or therapist to find the best rear axle set-up
for your chair. Do not change the set-up UNLESS you are sure you are
not at risk to tip over.
3. Adjust the rear wheel locks after you make any change to the rear axles.
a. If you fail to do so,the locks may not work.
b. Make sure lock arms embed in tires at least 3/8 inch when locked.
L. REAR WHEEL LOCKS
Rear wheel locks are NOT designed to slow or stop a moving wheelchair.
Use them only to keep the rear wheels from rolling when your chair is at a
complete stop.
1. NEVER use rear wheel locks to try to slow or stop your chair when it is
moving. Doing so may cause you to veer out of control.
2. To keep the rear wheels from rolling, always set both rear wheel locks
when you transfer to or from your chair.
3. Low pressure in a rear tire may cause the wheel lock on that side to slip
and may allow the wheel to turn when you do not expect it.
4. Make sure lock arms embed in tires at least 3/8 inch when locked. If you
fail to do so,the locks may not work.
VI. WARNINGS: FALLS & TIP-OVERS
▲
!

18
VI. WARNINGS: FALLS & TIP-OVERS
▲
!
M. MODIFIED SEAT SYSTEMS
Use of a seat system not approved by Quickie may alter the center of balance
of this chair. This may cause the chair to tip over.
1. Do not change the seat system of your chair UNLESS you consult your
authorized Quickie supplier first.
2. Use of a seat system not approved by Quickie may affect the folding mech-
anism of this chair.
N.UPHOLSTERY FABRIC
1. Replace worn or torn fabric of seat sling and seat back as soon as you can.
If you fail to do so,the seat may fail.
2. Sling fabric will weaken with age and use. Look for fraying or thin spots,or
stretching of fabric at rivet holes.
3. "Dropping down" into your chair will weaken fabric and result in the need
to inspect and replace sling more often.
4. Be aware that laundering or excess moisture will reduce flame retarda-
tion of the fabric.
19
A.LEARNING TO DO A "WHEELIE"
Follow these steps to help the rider learn to do a "wheelie":
1. Read and follow the warnings for "WHEELIES." (See p. 11)
2. Stand at the rear of the chair. You must be able to move with the chair to
prevent a tip-over.
3. Keep your hands BENEATH the push handles,ready to catch the rider if
the chair tips too far back.
4. When you are ready,have the rider place his or her hands on the forward
part of the handrims.
5. Have the rider make a quick BACKWARD movement of the rear wheels,
quickly followed by a hard FORWARD thrust. (This will tilt the chair up
on the balance point of the rear wheels.)
6. Have the rider make small movements of the handrims to stay in balance.
B. DESCENDING A CURB OR SINGLE STEP
Follow these steps to help a rider descend a curb or single step going
BACKWARD:
1. Stay at the rear of the chair.
2. Several feet before your reach the edge of the curb or step,turn the chair
around and pull it backward.
3. While looking over your shoulder, carefully step back until you are off the
curb or stair and standing on the lower level.
4. Pull the chair toward you until the rear wheels reach the edge of the curb
or step. Then allow the rear wheels to slowly roll down onto the lower
level.
5. When the rear wheels are safely on the lower level,tilt the chair back to
its balance point. This will lift the front casters off the curb or step.
6. Keep the chair in balance and take small steps backward. Turn the chair
around and gently lower front casters to the ground.
VII. TIPS FOR ATTENDANTS
Before you assist a rider, be sure to read the warnings “FOR ATTENDANTS”
(pg. 8) and follow all instructions that apply. Be aware that you will need to
learn safe methods best suited to your abilities.
▲
!WARNINGS

20
C. CLIMBING A CURB OR SINGLE STEP
Follow these steps to help the rider climb a curb or single step going
FORWARD:
1. Stay behind the chair.
2. Face the curb and tilt the chair up on the rear wheels so that the front
casters clear the curb or step.
3. Move forward,placing the front casters on the upper level as soon as you
are sure they are past the edge.
4. Continue forward until the rear wheels contact the face of the curb or
step. Lift and roll the rear wheels to the upper level.
D. CLIMBING STAIRS
Note: Use at least two attendants to move a chair and rider up stairs.
1. Move the chair and rider BACKWARD up the stairs.
2. The person at the rear is in control.He or she tilts the chair back to its
balance point.
3. A second attendant at the front firmly grasps a non-detachable part of
the front frame and lifts the chair up and over one stair at a time.
4. The attendants move to the next stair up. Repeat for each stair, until you
reach the landing.
E. DESCENDING STAIRS
Note: Use at least two attendants to move a chair and rider down stairs.
1. Move the chair and rider FORWARD down the stairs.
2. The person at the rear is in control.He or she tilts the chair to the
balance point of the rear wheels and rolls it to the edge of the top step.
3. A second attendant stands on the third step from the top and grasps the
chair frame. He or she lowers the chair one step at a time by letting the
rear wheels roll over the stair edge.
4. The attendants move to the next stair down. Repeat for each stair,until
you reach the landing.
VII. TIPS FOR ATTENDANTS
21
A. TO MOUNT & REMOVE REAR WHEELS
VIII. CHAIR BASICS
Do not use this chair UNLESS you are sure both quick-release axles are
locked. An unlocked axle may come off during use and cause a fall.
Note: Axle is not locked until:
a. The quick-release button pops out
fully. (Fig.A)
b. The ball bearings are fully visible on
the outside of the sleeve. (Fig.A)
1. To Install Wheel:
a. Depress quick-release button (1) fully.
This will release tension on ball bear-
ings at other end.
b. Insert axle through hub of rear wheel.
c. Keep pressure on button (1) as you
slide axle (2) into axle sleeve (3).
d. Release button to lock axle in sleeve.
Adjust axle if it does not lock.
(Follow steps at p. 22)
e. Repeat steps on other side.
2. To RemoveWheel:
a. Depress quick-release button (1) fully.
b. Remove wheel by sliding axle out of
axle sleeve (2).
c. Repeat steps on other side.
▲
!WARNING!
1.Quick-release
3
2
FigureA

22
IX. SET UP & ADJUSTMENT
Note: The Shadow ST/DT is shipped fully assem-
bled except for the following items which may
need to be attached or adjusted before final adjust-
ments are made. Setting the chair on a flat surface
(such as a workbench or table) helps make these
procedures easier.
Note onTorque Setting: Unless otherwise,use
a torque setting of 60 in./lbs.when assembling this
wheelchair.
A. WHEELS
Depress the quick-release button on the axle
and slide it into the axle sleeve until it locks.
The axle is not secure until the outside
quick-release button pops out to its fully
extended position. Check to make sure
the axles are locked.
B. WHEEL LOCKS
Shadow ST/DT wheelchairs are shipped
with wheel locks mounted. Wheel locks
are installed at the factory unless you
have requested otherwise.
Note onTorque Setting: Use a torque setting of
100 in./lbs.when assembling wheel locks.
Low-Mount ScissorWheel Locks:
The wheel lock mounts on a split-clamp
system. Loosen the bolts on the two
inside clamps. Position wheel lock on
frame tube and tighten bolts.
High-Mount Push-to-Lock or Scissor
Wheel Locks:
The wheel lock mounts on a split-clamp
system. Loosen the bolts on the two
inside clamps. Position wheel lock on
frame tube and tighten bolts.
Using wheel locks for braking is dangerous.
Use wheel locks for parking ONLY. When
properly adjusted,wheel locks prevent the
rear wheels from turning when the chair
is parked. Always adjust the wheel locks
after making any changes to the rear cam-
ber tube position. Wheel locks should be
embedded into the tires to prevent wheel
movement (when in the locked position).
23
IX. SET UP & ADJUSTMENT
C. ARMRESTS (Optional)
To install armrest,slide the outer armpost
into the receiver that is mounted to the
wheelchair frame. The armrest will auto-
matically lock into place.
Note: Armrests can be mounted facing forward or
backward.
Armrests are detachable. Lifting the
wheelchair by them may cause damage to
the chair or injury to the rider. NEVER
lift the wheelchair by the armrests.
D. ANTI-TIP TUBES (Optional)
Insert anti-tip tube into anti-tip tube receiv-
er and placing locking pin through holes.
Note: Use a torque setting of 100 in./lbs.when
assembling wheel locks.
CAUTION:To allow the anti-tip tubes to
function properly there must be a 1 1/2” to
2” clearance from the anti-tip wheel to the
ground.
Failure to adjust anti-tip tubes correctly
can result in injury to rider. Anti-tip tubes
are available from your local authorized
Quickie supplier. Quickie Designs recom-
mends anti-tip tubes for wheelchairs.
Note onTorque Setting: Unless otherwise
noted,use a torque setting of 60 in./lbs.when
assembling this wheelchair.
▲
!WARNINGS
▲
!WARNINGS
▲
!WARNINGS
Outer
Armpost
Receiver

25
H. CAMBER TUBE
The most important adjustment on your
Shadow Rigid wheelchair is the position of
the camber tube. the center of gravity is
determined by the camber tube. The cen-
ter of gravity is determined by the camber
tube adjustment. Use a torque setting of
100 in./lbs.when adjusting rear axle.
Work with your health care professional for
assistance in adjusting the axle to a position
that is best suited to your abilities.
1. Center of Gravity
The center of gravity is adjusted by mov-
ing the camber tube forward or backward
on the frame. Moving the axle forward
will increase your turning speed and light-
en the front end.
The farther forward the axles are posi-
tioned, the more likely it is that the wheel-
chair will tip over backward.
Always adjust the wheel locks after making
any change to the camber tube position,so
the wheel locks embed into the tires to
prevent wheel movement when in the
locked position.
2. Wheel Camber
Wheel camber is determined by the cam-
ber tube. Tubes are available in 0o,3o,6o,
9o,12oand 15oangles.
3. Wheelbase Width Adjustment
Adjust the wheelbase width by loosening
the nuts and repositioning the axle sleeve
(A);retighten nut. Both sides should be
adjusted the same.
Always adjust the wheel locks after making
any change to the camber tube position,so
the wheel locks embed into the tires to
prevent wheel movement when in the
locked position.
IX. SET UP & ADJUSTMENT
24
E. HEIGHT-ADJUSTABLE ARM-
REST (Optional)
a. Height-Adjustment
To adjust armrest height,depress
detent button in the upright tube and
move up or down to the height
desired. Release button into proper
hole.
b. RemovingArmrest
To detach armrest,pull straight up on
armrest and remove.
Armrests are detachable. Lifting the
wheelchair by them may cause damage
to the chair or injury to the rider.
NEVER lift the wheelchair by the armrests.
F. FOLDING BACKREST
The backrest comes standard with a 3”
height adjustment. Remove the backrest
upholstery from the frame. You will see
the backrest frame which telescopes into
the support and is secured by a screw on
the side of the frame. After selecting the
proper height,slide the backrest uphol-
stery back on with the overlap portion
unattached. SecureVELCRO®-style mate-
rial on backrest.
G. BACK ANGLE ADJUSTMENT
(Folding backrest)
An 6oangle adjustment is standard. Angle
adjustment is made by moving the posi-
tion of the backrest support bracket. The
adjustment on each side of the chair must
be exactly equal. Loosen the lock nut and
adjust to the desired angle and retighten
lock nut. Check operation of backrest
after adjusting the angle.
IX. SET UP & ADJUSTMENT
▲
!WARNINGS
▲
!WARNINGS
▲
!WARNINGS
▲
!WARNINGS
Height-Adjustable Armrest
Key
1.Standard receiver
2.Armrest
3.Receiver adjustment bolts
1
2
3
A

26
IX. SET UP & ADJUSTMENT
I. WHEEL LOCKS
Note: Use a torque setting of 100 in.-lbs.when
setting up wheel locks.
1. Low-Mount ScissorWheel Locks:
Loosen screws on top clamp. Slide
assembly toward rear wheel until clamp
embeds into tire to prevent wheel move-
ment,when in locked position. Adjust
angle position and tighten screws.
Using wheel locks for braking is danger-
ous. Use wheel locks for parking ONLY.
When properly adjusted,wheel locks pre-
vent the rear wheels from turning when
the chair is parked. Always adjust the
wheel locks after making any changes to
the rear axle sleeve position. Wheel locks
should be embedded into the tires to pre-
vent wheel movement.
2. High-Mount Push-to-Lock or Pull-to-
LockWheel Locks:
To adjust push-to-lock toggle type locks that
mount with a split clamp,loosen the screws
on the top of each clamp. Using a 3/16”
Allen wrench,turn one of the screws coun-
terclockwise one-quarter turn. Repeat the
same process with the second of the two
screws. Alternately loosen the screws (two
turns each) until both screws are removed.
Slide clamp toward the rear wheel until the
wheel lock is embedded into the tire to
prevent wheel movement (when in the
locked position). Tighten screws. Some
adjustments to the wheel lock position can
be accomplished without moving the clamp.
To adjust,loosen the two socket-head cap
screws on the top of the clamp. Slide the
mounting bar forward or backward and
rotate it to the correct angle position. The
wheel lock should embed into the tire to
prevent wheel movement when in the
locked position. Tighten screws.
Note: High-mount push-to-lock require frame
modifications for use on your Shadow Rigid.
▲
!WARNINGS
IX. SET UP & ADJUSTMENT
J. FOOTREST
Adjust height by removing bolts and sliding
footrest up or down to desired position.
Replace bolts.
Note: Footrest adjusts in 3/4” increments. Keep
footrest 1”-2” above the ground. Use a torque set-
ting of 100 in./lbs.when adjusting footplate.
K. ANTI-TIP TUBES (Optional)
Note: Use a torque setting of 100 in.-lbs.when set-
ting up the anti-tip tubes.
Remove anti-tip tubes from anti-tip
receivers. Remove button head bolts from
camber tube mounting brackets. Install
anti-tip receiver on the underside of the
camber tube with the long part of the tube
facing rearward. Use the longer screw
supplied with the anti-tips and reinstall
the camber tube and mounting brackets.
Insert the anti-tip tube into the receiver.
Turn the anti-tip tube down until release
pin is through the receiver mounting hole.
Insert second anti-tip tube the same way.
CAUTION:To allow the anti-tip tubes to func-
tion properly there must be a 1 1/2” to 2”
clearance from the anti-tip wheel to the
ground. To maintain this clearance an adjust-
ment in the positioning of the anti-tip tube
should be made to correspond with any
change in seat height.
Failure to adjust anti-tip tubes correctly can
result in injury to the rider. Anti-tip tubes
are available from your local authorized
Quickie supplier. Quickie Designs recom-
mends anti-tip tubes for wheelchairs.
▲
!WARNINGS
27

29
XI. MAINTENANCE
A. INTRODUCTION
1. Proper maintenance will improve performance and extend the useful life
of your chair.
2. Clean your chair regularly. This will help you find loose or worn parts and
make your chair easier to use.
3. Repair or replace loose, worn,bent or damaged parts before using this
chair.
4. To protect your investment,have all major maintenance and repair work
done by your authorized Quickie supplier.
B. MAINTENANCE CHART
If you fail to heed these warnings your chair may fail and cause severe
injury to the rider or others.
1. Inspect and maintain this chair strictly per chart.
2. If you detect a problem, make sure to service or repair the chair
before use.
3. At least once a year, have a complete inspection, safety check and
service of your chair made by an authorized Quickie supplier.
▲
!WARNINGS!
28
You will need to adjust your chair from time to time for best performance (espe-
cially if you alter the original settings). This chart gives you a first solution, then a
second and a third if needed. You may need to look farther to find the best solu-
tion for a specific problem.
Note: To keep track of your progress,make only ONE change at a time.
X. TROUBLESHOOTING

XII. QUICKIE LIMITED WARRANTY
A. FOR LIFETIME
Quickie warrants the frame and quick-release axles of this wheelchair against
defects in materials and workmanship for the life of the original purchaser.
The expected life of this frame is five years.
B. FOR TWO (2) YEARS
We warrant all Quickie-made parts and components of this wheelchair against
defects in materials and workmanship for two years from the date of first
consumer purchase.
C. LIMITATIONS
1. We do not warrant:
• Tires and tubes, upholstery, armrests and push-handle grips.
• Damage from neglect,misuse,or from improper installation or repair.
• Damage from exceeding weight limit of 250 pounds.
2. This warranty isVOID if the original chair serial number tag is removed
or altered.
3. This warranty applies in the USA only. Check with your Quickie supplier
to find out if international warranties apply.
D. WHAT WE WILL DO
1. Our sole liability is to repair or replace covered parts.This is the exclu-
sive remedy for consequential damages.
E. WHAT YOU MUST DO
1. Obtain from us,while this warranty is in effect,prior approval for return
or repair of covered parts.
2. Return the wheelchair or part(s), freight pre-paid,to Quickie at:2842
Business ParkAvenue, Fresno,CA 93727-1328.
3. Pay the cost of labor to repair, remove or install parts.
F. NOTICE TO CONSUMER
1. If allowed by law,this warranty is in place of any other warranty (written
or oral,express or implied,including a warranty of merchantability, or
fitness for a particular purpose).
2. This warranty gives you certain legal rights.You may also have other rights
that vary from state to state.
Record your serial number here for future reference:
________________________
3130
C.MAINTENANCE TIPS
1. Axles &Axle Sleeves:
Check axles and axle sleeves every six months to make sure they are tight.
Loose sleeves will damage the axle plate and will affect performance.
2. Tire Air Pressure:
Check air pressure in pneumatic tires at least ONCEAWEEK. The wheel
locks will not grip properly if you fail to maintain the air pressure shown on
tire sidewall.
D. CLEANING
1. Paint Finish
a. Clean the paint finish with mild soap at least once a month.
b. Protect the paint with a coat of non-abrasive auto wax every three
months.
2. Axles and Moving Parts
a. Clean around axles and moving partsWEEKLY with a slightly damp (not
wet) cloth.
b. Wipe off or blow away any fluff,dust,or dirt on axles or moving parts.
Note: You do not need to grease or oil the chair.
3. Upholstery
a. Hand-wash (machine washing may damage fabric).
b. Drip-dry only. DO NOT machine dry as heat will damage fabric.
E. STORAGE TIPS
1. Store your chair in a clean, dry area. If you fail to do so, parts may rust
or corrode.
2. Before using your chair, make sure it is in proper working order. Inspect
and service all items on the "Maintenance Chart." (See p. 27)
3. If stored for more than three months,have your chair inspected by an
authorized Quickie supplier before use.
XI. MAINTENANCE

Sunrise Home Healthcare Group
Mobility Products Division
7477 East Dry Creek Parkway • Longmont,Colorado • 80503 USA
[phone] or [phone]
in Canada [phone]
© 1997, Sunrise Medical 12.97
931142 Rev. B
