AIGOSTAR 30KYE User manual

SAMSPARTY SL
CL CABAÑA 78, 45210 YUNCOS ,TOLEDO,ESPAÑA
The plastic material in contact with the food is Silicone, BPA free.
B45824786
HTTP://WWW.AIGOSTAR.COM
MADE IN P.R.C
8433325188016

01-32
33-64
65-96
97-128
129-160
161-192
193-224
225-256

Precautions
Read all the instructions
1.Do not operate any appliance with a damaged cord or
plug or after the appliance malfunctions or has been
damaged in any manner. Return appliance to the nearest
authorized service facility for examination, repair, or
adjustment
2.This appliance is for household use only. Do not use
outdoors.
3.Keep electrical appliance out of reach from children or
inform person. Do not let them use the appliance
without supervision.
4.This appliance shall not be used by children. Keep the
appliance and its cord out of reach of children.
5.Appliances can be used by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved.
6.Children shall not play with the appliance.
7.Do not immerse any part of the appliance in water or
other liquid.
8.Please turn off and unplug the appliance before
cleaning, maintenance or relocation and whenever it is
not in use.
9.This appliance is intended to be used in household
and similar applications such as:
-Staff kitchen areas in shops, offices and other working
environments;
-farm houses;
-by clients in hotels, motels and other residential type
environments;
-bed and breakfast type environments;
10.The pressure regulator allowing the escape of steam
should be checked regularly to ensure that they are not
blocked.
11.State that the container must not be opened until the
pressure has decreased sufficiently.
12.The appliance is not intended to be operated by
means of an external timer or a separate remote-control
system.
13.Cooking appliances should be positioned in a stable
situation with the handles positioned to void spillage of
the hot liquids.
14.The heating element surface is subject to residual
heat after use, do not touch.
15.The cooker cannot gain pressure when the lid is not
well closed and the lid cannot be opened when the
inner pressure is too high.
16.Do not let children near the pressure cooker when in
use.
17.Do not put the pressure cooker into a heated oven.
18.Move the pressure cooker under pressure with the
greatest care. Do not touch hot surfaces. Use the
handles and knobs. If necessary, use protection.
19.Do not use the pressure cooker for a purpose other
than the one for which it is intended.
20.This appliance cooks under pressure. Scalds may
result from inappropriate use of the pressure cooker.
Make sure that the cooker is properly closed before
applying heat, see “instruction for use”.
21.Never forces open the pressure cooker. Do not open
before making sure that its internal pressure has
1 2

Precautions
completely dropped. See the “instructions for use”.
22.Never use your pressure cooker without adding water
or food, except the Sauté function, this would seriously
damage it.
23.Do not fill the cooker beyond 2/3 of its capacity.
When cooking foodstuffs which expand during cooking,
such as rice or dehydrate vegetables, do not fill the
cooker to more than half of its capacity.
24.Use the appropriate heat source(s) according to the
instructions for use.
25.After cooking meat with a skin (e.g. ox tongue) which
may smell under the effect of pressure, do not prick the
meat which the skin is swollen; you might be scalded.
26.When cooking doughy food, gently shake the cooker
before opening the lid to avoid food ejection.
27.Before each use, check that the valves are not
obstructed. See the instructions for use.
28.Never use the pressure cooker in its pressurized
mode for deep or shallow frying of food.
29.Do not tamper with any of the safety systems beyond
the maintenance instructions specified in the
instructions for use.
30.Only use manufacture’s spare parts in accordance
with the relevant model. In particular, use a body and a
lid from the same manufacturer indicated as being
compatible.
31.KEEP THESE INSTRUCTIONS.
Warning
1.When discharging keep your face or hand away from
the relief pipe and from the lid during operation to
avoid scald.
2.Unplug appliance from mains electricity supply before
taking food.
3.Don't touch the lid during cooking procedure or in
heating status.
4.Never block the periphery of the clamping position to
ensure safety.
5.Never attempt to uncover the cooker when floating
valve is flopping or pressure inside.
6.Please mind of flowing hot water from the pressure
discharging valve when open the cover.
7.The silicone ring is not as a safety device.
8.Improper installation could cause danger. Please mind
of the right installation.
9.Avoid spillage on the connector.
Customer service address:
SAMSPARTY Ltd
Cabaña 78, 45210 YUNCOS,TOLEDO,SPAIN
3 4

Product Structure
This marking indicates that this product
should not be disposed with other
household wastes throughout the EU. To
prevent possible harm to the environment
or human health from uncontrolled waste
disposal, recycle it responsibly to promote
the sustainable reuse of material
resources. To return your used device,
please use the return and collection
systems or contact the retailer where the
product was purchased. They can take this
product for environmental safe recycling.
Specification of the Product
Model Capacity Power
Supply Rated Power Size of Working Pressure Keep Warm Temperature
80kPa 140°F~176°F
Inner Pot
8.66"
1000W
220-240V~
50/60Hz
5.5 L8433325188016
Accessories:
Spoon
Soup Spoon
User Manual
Measuring Cup
Power Cord Components
Cooker body
handle
Inner pot
Housing cover
Outer pot
Control Box
Base
Cooker body
Power cord socket
③Water box(note)
Upper cover
handle
Lid
Exhaust valve
handle
Float valve
①(note)Exhaust valve
Exhaust opening
Block proof cover
②Sealing gate (note)
Seal ring
Internal
side of lid
Seal ring bracket
5 6

Instructions before use
Operation Part
Structural diagram of float valve
Tips:
Confirm that the float valve, block proof cover and seal ring
are correctly installed before use each time;
Before putting the inner pot into the cooker each time,
please remove the dirt and water from the external side of
the inner pot and internal side of the external pot;
Please move the product with the handle of the cooker body;
Please remove the water from the housing cover with cloth.
Note:
① Exhaust valve: Pull out the exhaust valve from the lid.
Clean the internal side of the exhaust valve and
the exhaust valve and float valve of the lid with brush and
cloth at least once a month.
② Sealing gate: Please remove oil and dirt from the sealing
gate with detergent and brush. The remained
oil and dirt in it may appear in yellowish. After washing, it
may recover to the original color as stainless steel. It is
suggested to clean the sealing gate once every 2 months.
③ Water box: After cooking, the steam may stay in the water
box of the external pot as water. Water in
the box should be removed for avoiding bad odor, please
clean it with clean cloth.
When use for the first time, please take out all accessories
from the cooker body, read the User Manual carefully,
particularly for the usage and cautions for avoiding property
loss or physical injury for you.
Menu Function Panel
Keep warm/ Button
Cooking Timer Button
“+”Button
Menu Button
Delay Timer Button
Pressure Level Button
“-”Button
Manual Setting Button
Display Screen
7 8

Disassemble and install the block proof cover and
seal ring
Use and maintain the inner pot
Optional pressure maintaining function
This function allows adjusting the pressure level according to
the personal requirement by pressing “Pressure Level”
button, it requires entering into the “Manual Setting” state.
Cooking Timer Function
If the pressure maintaining time is adjusted by pressing
“+”/“-” button, it requires entering into the “Manual
Setting” state.
Delay Timer Function
Set the time of finishing cooking by pressing the “+”/“-”
button.
Disassemble and install the block
proof cover
Disassemble and install the seal
ring
Disassemble:
Pull it out upwards
Install:
Press it down to install
Disassemble:
Pull it out upwards
Install:
Press it down to install
1.Please do not pull the seal ring, otherwise, the distorted seal
ring may influence the seal ring and pressure effect.
2.Do not use the damaged seal
ring, please replace it at the authorized repair office.
1.Do not empty
It may cause yellowish and spotted inner pot or distorted
bottom if it is empty for a long time.
2.Do not use it to store the acid, alkali and preserved foods
for a long period.
Although the inner pot has excellent anti-corrosion
performance, it may cause corrosion of certain degree, the
suggested time of keep warm shall not exceed 2h.
3.Keep it clean to prolong the service life. Do not immerse it
in water for a long period.
Clean the inner pot with soap, weak detergent or warm water
to remove dust, oil and dirt.
4.Do not use a metal shovel or other harder tool, otherwise it
will damage the inner surface of pot.
1.Check if the seal ring and block proof cover are correctly
installed in the upper cover before use each time.
2.After use, please clean the seal
ring and around of block proof cover for avoiding jamming
the cover, keep it clean to avoid bad odor.
9 10

“ ”
“ ”
“ ”
“ ”
“ ”
“ ”
Prepare for cooking
Function Selection
General Function
1.Opening the lid correctly
● Hold the handle of upper cover, turn it
anticlockwise for about 30° till the mark
on the edge of the upper cover aiming at
the mark on the edge of the housing
cover, and then lift the upper cover.
2.Check if the parts and accessories of lid are
well installed
● Check if the floater valve and exhaust valve
are jammed, confirm if the sealing ring and
block proof cover are well installed.
3.Take out the inner pot, put the foods and
water into the inner pot
● The total amount of foods and water shall
not exceed the Max marked on the inner
pot.
● The max rice and water amount when
cooking shall not exceed the Max on the
inner pot.
4.Put the inner pot into the cooker
● Wipe to clean the external surface of inner
pot, foreign object and water are not
allowed on the inner surface of electric
pressure cooker;
● Turn the inner pot to left and right to
ensure good contact with the heating plate.
5.Safely close the lid
● Before closing the lid, check if the sealing
ring is well installed.
● Hold the handle of upper cover, aim the
mark on the edge of the upper cover aiming
at the mark on the edge of the housing
cover, put the top cover horizontally on the
cooker body, turn the upper cover clockwise
for about 30° to the lock place, and aim the
mark on the edge of the housing cover at the mark on the lid.
6.Put the exhaust valve well
● When working, please turn the exhaust valve to the sealing place, which
means the electric pressure cooker keeps at sealing state;
● For manual exhaust, please turn the exhaust valve handle to the exhaust
place, the electric pressure cooker keeps at the exhaust state; when
exhausting, do not keep the hands or face above the exhaust opening;
● Check if the floater valve drops down before working (before heating, the
floater valve is down).
Sealing schematic
diagram Exhaust schematic
diagram
1.Prepare for cooking according to the chapter of
“Instructions before use”
2.Switch on If the buttons are inactive when use, please
confirm if the lid is closed at the right place, the buttons are
inactive if the lid is not closed correctly for product of this
series.
3.Select the required function under the standby state, press
the “Menu” button to select function, press the
“+”/“-” button to switch the function; Different function
requires different cooking time, the more the foods, the
longer the cooking time.
4.Press one function button, 10s later, the electric pressure
cooker starts to select the program of corresponding
function 10s after selecting the function, the electric pressure
cooker starts working.
When the cooker is working, press the "Keep Warm/ ”
button to cancel the current work state and return standby
state.
11 12

Operation Guidelines
Safely open the lid
5.After cooking, the cooker may automatically enter into the
keep warm state. The time of keep warm shall not exceed 2h!
After cooking, the indicator of corresponding function lights
off, the keep warm indicator lights on, the cooker makes
sound and enters into the keep warm state.
Under the standby state, press the "Keep Warm/ ”
button, the keep warm indicator lights on, the cooker makes
sound and enters into the keep warm state.
Function
Standby
Meat
Operation Guidelines
After supplying power, the default is standby state, the digital screen
flashes “----”
1.Normal cooking: Under standby state, press the “Menu”
button,“ ” indicator lights on, the digital screen flashes
“P01”, 10s later if no button is pressed, the product automatically
starts cooking at “Meat”, the digital screen displays ” P01”, and
starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
press the “Delay Timer” button again, “Delay Timer” indicator
flashes, the digital screen flashes the time, start to adjust the preset
time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts
preset cooking at “Meat”, the digital screen displays the finishing
time and starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
Tips:
Under any state, press the “Keep Warm/ ” button to
cancel the current work state and return standby state.
When the cooker is working, it is normal that it makes "cluck"
sound, please set your heart at relax when use.
To cook a small amount of foods, the inner pot may possibly
be lifted when opening the lid, please shake the lid to drop
the inner pot in the cooker body and then remove the lid.
1.Cut off power supply or remove the power plug 2.Exhaust
method
A.Quickly open the lid
Turn the exhaust valve to the exhaust place for exhausting,
till the float valve drops down. (For non- fluid foods)
B.Generally open the lid
Keep the electric pressure cooker cool naturally till the float
valve drops down.
3.Open the lid
Turn the upper cover anticlockwise with the left hand, turn it
to the cover open limit place, lift the upper cover with the
right hand to open the lid.
Do not open the lid before the pressure in the pot has been
completely released, do not open the lid fiercely if it is
difficult to open.
Do not pull out the exhaust valve when turning the exhaust
valve.
After cooking fluid foods (porridge and soup), do not turn
the exhaust valve, please cut off power supply to make it cool
naturally till the float drops before opening the lid.
After cooking a large amount of foods, please do not
immediately exhaust, it is suggested to keep
warm for a certain moment before opening the lid.
13 14

Poultry Steam
Sauté
Slow Cook
Vegetable
1.Normal cooking: Under standby state, press the “Menu”
button,“ ” indicator lights on, the digital screen flashes
“P01”, then press “+” one time, the digital screen displays
“P02”. 10s later if no button is pressed, the product automatically
starts cooking at “Poultry”, the digital screen displays “P02”, and
starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” one time, the digital screen displays “P02”, press
the “Delay Timer” button again, “Delay Timer” indicator flashes,
the digital screen flashes the time, start to adjust the preset time,
press the “+''/“-” button to adjust minute, press it once to adjust
by 10min. 10s after setting, the product automatically starts preset
cooking at “Meat”, the digital screen displays the finishing time and
starts countdown.
Exit work state: Press the “ ” button to exit the current work
state
1.Normal cooking: Under standby state, press the “Menu”
button,“ ” indicator lights on, the digital screen flashes
“P01”, then press “+” three times, the digital screen displays
“P04”. 10s later if no button is pressed, the product automatically
starts cooking at “Steam”, the digital screen displays “P04”, and
starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” three times, the digital screen displays “P04”,
press the “Delay Timer” button again, “Delay Timer” indicator
flashes, the digital screen flashes the time, start to adjust the preset
time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts
preset cooking at “Steam”, the digital screen displays the finishing
time and starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
1.Normal cooking: Under standby state, press the “Menu”
button,“ ”indicator lights on, the digital screen flashes “P01”,
then press “+” four times, the digital screen displays “P05”. 10s
later if no button is pressed, the product automatically starts cooking
at “Saute”, the digital screen displays countdown “0:30”.
2.Exit work state: Press the “ ” button to exit the current work
state.
Please note that this function must be no lid.
1.Normal cooking: Under standby state, press the “Menu” button,
“ ”indicator lights on, the digital screen flashes “P01”, then
press “+” five times, the digital screen displays “P06”. 10s later if
no button is pressed, the product automatically starts cooking at
“Slow Cook”, the digital screen displays countdown “8:00”.
Exit work state: Press the “ ” button to exit the current work
state.
1.Normal cooking: Under standby state, press the “Menu”
button,“ ”indicator lights on, the digital screen flashes
“P01”, then press “+” two times, the digital screen displays
“P03”. 10s later if no button is pressed, the product automatically
starts cooking at “Vegetable”, the digital screen displays “P03”,
and starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” two times, the digital screen displays “P03”, press
the “Delay Timer” button again, “Delay Timer” indicator flashes,
the digital screen flashes the time, start to adjust the preset time,
press the “+''/“-” button to adjust minute, press it once to adjust
by 10min. 10s after setting, the product automatically starts preset
cooking at “Vegetable”, the digital screen displays the finishing
time and starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
15 16

White Rice Beams
Broth
Brown Rice
1.Normal cooking: Under standby state, press the “Menu”
button,“ ” indicator lights on, the digital screen flashes
“P01”, then press “+” six times, the digital screen displays
“P07”. 10s later if no button is pressed, the product automatically
starts cooking at “White Rice”, the digital screen displays “P07”,
and starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” six times, the digital screen displays “P07”, press
the “Delay Timer” button again, “Delay Timer” indicator flashes,
the digital screen flashes the time, start to adjust the preset time,
press the “+''/“-” button to adjust minute, press it once to adjust
by 10min. 10s after setting, the product automatically starts preset
cooking at “White Rice”, the digital screen displays the finishing
time and starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
1.Normal cooking: Under standby state, press the “Menu”
button,“ ” indicator lights on, the digital screen flashes
“P01”, then press “+” eight times, the digital screen displays
“P09”. 10s later if no button is pressed, the product automatically
starts cooking at “Beans”, the digital screen displays “P09”, and
starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” eight times, the digital screen displays “P09”,
press the “Delay Timer” button again, “Delay Timer” indicator
flashes, the digital screen flashes the time, start to adjust the preset
time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts
preset cooking at “Beans”, the digital screen displays the finishing
time and starts countdown.
Exit work state: Press the “Keep Warm” button to exit the current
work state.
1.Normal cooking: Under standby state, press the “Menu”
button,“ ”indicator lights on, the digital screen flashes
“P01”, then press “+” nine times, the digital screen displays
“P10”. 10s later if no button is pressed, the product automatically
starts cooking at “Broth”, the digital screen displays “P10”, and
starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” nine times, the digital screen displays “P10”, press
the “Delay Timer” button again, “Delay Timer” indicator flashes,
the digital
screen flashes the time, start to adjust the preset time, press the
“+''/“-” button to adjust minute, press it once to adjust by 10min.
10s after setting, the product automatically starts preset cooking at
“Broth”, the digital screen displays the finishing time and starts
countdown.
Exit work state: Press the “ ” button to exit the current work
state.
1.Normal cooking: Under standby state, press the “Menu”
button,“ ” indicator lights on, the digital screen flashes
“P01”, then press “+” seven times, the digital screen displays
“P08”. 10s later if no button is pressed, the product automatically
starts cooking at “Brown Rice”, the digital screen displays “P08”,
and starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” seven times, the digital screen displays “P08”,
press the “Delay Timer” button again, “Delay Timer” indicator
flashes, the digital screen flashes the time, start to adjust the preset
time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts
preset cooking at “Brown Rice”, the digital screen displays the
finishing time and starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
17 18

Curry Multigrain
Congee
Soup
1.Normal cooking: Under standby state, press the “Menu”
button,“ ”indicator lights on, the digital screen flashes
“P01”, then press “+” ten times, the digital screen displays
“P11”. 10s later if no button is pressed, the product automatically
starts cooking at “Curry”, the digital screen displays “P11”, and
starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” ten times, the digital screen displays “P11”, press
the “Delay Timer” button again, “Delay Timer” indicator flashes,
the digital screen flashes the time, start to adjust the preset time,
press the “+''/“-” button to adjust minute, press it once to adjust
by 10min. 10s after setting, the product automatically starts preset
cooking at “Curry”, the digital screen displays the finishing time and
starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
1.Normal cooking: Under standby state, press the “Menu”
button,“ ” indicator lights on, the digital screen flashes
“P01”, then press “+” twelve times, the digital screen displays
“P13”. 10s later if no button is pressed, the product automatically
starts cooking at “Soup”, the digital screen displays “P13”, and
starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” twelve times, the digital screen displays “P13”,
press the “Delay Timer” button again, “Delay Timer” indicator
flashes, the digital screen flashes the time, start to adjust the preset
time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts
preset cooking at “Multigrain”, the digital screen displays the
finishing time and starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
1.Normal cooking: Under standby state, press the “Menu”
button,“ ” indicator lights on, the digital screen flashes
“P01”, then press “+” thirteen times, the digital screen displays
“P14”. 10s later if no button is pressed, the product automatically
starts cooking at “Congee”, the digital screen displays “P14”, and
starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” thirteen times, the digital screen displays “P14”,
press the “Delay Timer” button again, “Delay Timer” indicator
flashes, the digital screen flashes the time, start to adjust the preset
time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts
preset cooking at “Congee”, the digital screen displays the finishing
time and starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
1.Normal cooking: Under standby state, press the “Menu”
button,“ ” indicator lights on, the digital screen flashes
“P01”, then press “+” eleven times, the digital screen displays
“P12”. 10s later if no button is pressed, the product automatically
starts cooking at “Soup”, the digital screen displays “P12”, and
starts countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” eleven times, the digital screen displays “P12”,
press the “Delay Timer” button again, “Delay Timer” indicator
flashes, the digital screen flashes the time, start to adjust the preset
time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts
preset cooking at “Soup”, the
digital screen displays the finishing time and starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
19 20

Keep Warm Function
Daily check and maintenance
Chili
Manual Setting
1.Normal cooking: Under standby state, press the “Menu” button,
“ ” indicator lights on, the digital screen flashes “P01”,
then press “+” fourteen times, the digital screen displays “P15”.
10s later if no button is pressed, the product automatically starts
cooking at “Chili”, the digital screen displays “P15”, and starts
countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Menu” button,
then press “+” fourteen times, the digital screen displays “P15”,
press the “Delay Timer” button again, “Delay Timer” indicator
flashes, the digital screen flashes the time, start to adjust the preset
time, press the “+''/“-” button to adjust minute, press it once to
adjust by 10min. 10s after setting, the product automatically starts
preset cooking at “Chili”, the digital screen displays the finishing
time and starts countdown.
Exit work state: Press the “ ” button to exit the current work
state.
1.Normal cooking: Under standby state, press the “Manual Setting”
button, “Manual Setting” and “High” indicators lights on, the
digital screen displays “30”. Press the “Cooking Timer” button
then press the “+”/“-” button to adjust the pressure keeping time
.10s later if no button is pressed, the product automatically starts
cooking, the digital screen displays “ ”, and starts
countdown when pressure rises in the cooker.
2.Preset cooking: Under standby state, press the “Manual Setting”
button, “Manual Setting” and “High” indicators lights on, the
digital screen displays “30”. Press the “Delay Timer” button again,
“Delay Timer” indicator flashes, the digital screen flashes the time,
start to adjust the preset time, press the “+”/“-” button to adjust
minute, press it once to adjust by 10min. 10s after setting, the product
automatically starts preset cooking at “Manual Setting”, the digital
screen displays the finishing time and starts countdown.
3.Pressure selection: Under standby state, press the “Manual Setting”
button, “Manual Setting” and “High” indicators lights on, the
digital screen displays “30”. Adjust the pressure with “Pressure
Level”, the “High” lights off, “Low” lights on. 10s later if no button
is pressed, the product automatically starts cooking at “Manual
Setting”, the digital screen displays “ ” , and starts
countdown when pressure rises in the cooker.
Exit work state: Press the “ ” button to exit the current work state.
If followings occur Solutions
● After cooking, the electric pressure cooker
automatically enters into
the keep warm state; Under keep warm
state, keep warm indicator lights on;
● Under standby state, you may also press
the “Keep Warm” button to
keep warm;
● Keep warm temperature is 140°F~176°F;
● For use the product safely with a longer service life, please carefully check
and maintain it.
● Power cord and plug is expanded,
deformation, damaged and it color is
changed.
● One part of the power cord and plug are
hotter.
● Power cord is flexible with discontinuous
power supply.
● The electric pressure cooker has
abnormal heating and generates bad odor.
There's abnormal noise or vibration when
supply power.
Stop using, and repair it by the authorized
repair center.
Remove the dust or dirt.There's dust or dirt on the plug or socket.
21 22

Safety precautions
To avoid personal injury and property loss, be sure to observe
the following safety precautions.
● The danger caused by mistaken use if following warnings
are neglected includes to two grades
It may possibly cause death or serious injury if
the warming items are disobeyed.
It may cause physical injury or property
damage if the caution items are disobeyed.
● Meaning of the marks:
Means
”Forbidden”
items
Means
“Mandatory”
items
General Forbid
Wet hands
Forbidden
Spray Water
Forbidden
Must be
executed Remove the
power plug
Disassemble
Forbidden
Contact
Forbidder
Warning:
Warning:
Caution:
AC 220-240V
Use 220V~240V power outlet
● Failure to use AC 220V~ 240V
electricity can cause fire or electric shock.
● Danger of fire if the bad socket is
adopted.
It is strictly prohibited to use other lid
● It is strictly prohibited to use other lid for
heating, and in the (switching on) process,
the use of non- original lid is not allowed.
As this may cause electric shock or safety
hazards.
Do not put foreign objects
● It is prohibited to insert metal shavings,
needles and other foreign matter in the
gap. As this may cause electric shock or
movement anomalies.
Modification is prohibited
● Modification or repair by
non-professionals is prohibited.
● Violation may cause a fire or electric
shock.
● Repair or replacement of parts shall be
made in a designated service center.
23 24

Warning on Opening the lid
● When the electric pressure cooker is not
working, there isn't pressure in the pot, the
float valve is down;
● When the electric pressure cooker is
working, pressure in the cooker rises, float
valve ascends; do not fiercely open the lid
before the pressure has been completely
released;
● If it is difficult to open the lid, please do not
open it fiercely, otherwise, it may cause
scalding or physical injury.
socket shall be used alone
● A socket of more than 10A rated current
with grounding wire shall be used alone;
● If shared with other electrical appliances,
the socket may cause abnormal heat and
result in fire.
Stop using if the power cord is damaged
● Replace the damaged power cord with
special soft cord or replace it with special
assembly purchased from the
manufacturer or authorized repair center.
Place the appliance in a location out of
reach of infants
● Place the appliance in a location out of
reach of infants.
● To avoid electric shock and scald.
Products may not be immersed or
sprinkled in water
● Doing so could cause electric shock and
electrical short circuits.
Check periodically
● Be sure to check periodically the block
proof cover and exhaust valve core to
make sure that they are not be blocked;
● Do not cover the exhaust valve with
heavy object or replace it with other object.
25 26

Caution:
Max
Never pull the plug with a wet hand
● To avoid electric shock.
Unplugging when not in use
● Otherwise, it may produce leakage, fire
or failure.
When the cooker is working, please do
not touch the lid
● When the cooker is working, lid has high
temperature, do not touch it; otherwise, it
may possibly cause scalding.
Do not use a pot other than the dedicated
pot
● When there is foreign object on the
bottom of pot and heating plate surface,
remove the foreign object before use.
Otherwise, it may cause overheating and
work abnormalities etc.
When moving the product, please hold
the handle of cooker body
● When moving the product, do not
directly hold the handle of lid for avoiding
lid dropping.
When pulling the plug, you must pinch
the plug
● When pulling the plug, you must pinch
the plug;
● Do not pull the power cord, otherwise it
will damage the cord, causing electric
shock and short circuit.
In working, never move your hands to
close to the exhaust port.
● In cooking process, never move your
hands to close to the exhaust port to
avoid burns.
● During cooking, do not cover the vent
with a cloth and other items.
The total amount of food and water can
not exceed Max scale
● The total amount of food and water can
not exceed Max scale, otherwise food may
be cooked unfamiliar, or cause
malfunction.
27 28

θ
L
N
E
N
L
θ
Max
Do not put the inner pot on other
appliance for heating
● In order to avoid deformation or fault.
Please use the special inner pot.
Do not use in the following locations
● Do not use in unstable locations;
● Do not use in locations near water and
fire; Do not use near walls and furniture;
● Do not use in locations exposed to direct
sunlight and oil splatter.
● Do not approach the stove for avoiding
fire.
Environment for storing the Product
Clean after use
Electrical Schematic Diagram
● Periodically clean the cooker and remove oil and dirt if it is
stored on the table.
● Put the electric pressure cooker 30cm away from other
kitchen appliances.
1.Clean after each use.
2.Before cleaning and maintenance, please unplug the
power cord until the product cool down.
3.Remove the lid and inner pot, clean with detergent first,
then rinse well with water and wipe dry with a soft cloth.
4.Clean the internal side of the lid with water, the seal ring,
block proof cover,
exhaust valve core and float valve can be removed for
washing, timely and correctly install them after washing, and
then dry the internal side of lid with cloth.
5.Wipe clean the cooker body with a rag, and it is prohibited
to soak the cooker body in water or spray water to it.
AC Input
Transmit Board
Wireless
Connecting Line
Power Board
Connecting Line
Bottom Temperature
Sensor
Top Switch
Pressure Switch
Display Board
Receive Board
TOP Temperature Sensor
Pressures Sensor
Temperature Fuse
Temperature cut-out
Heater
29 30

Troubleshooting
When followings occur, it is not the cooker fault, please
carefully check once before sending it for repair. ——If the fault is not removed after above check, please contact the authorized service center for repair.
WARRANTY: 2 YEARS
S/N
Problem
Reason
Solution
1 Difficult to close the lid
Sealing ring not installed properly
Position the sealing ring w ell
The floater valve clamps the push rod
Lightly push the push rod
2 Difficult to open the lid
Float valve in the popped-up position Pr ess the float valve lightly w ith a
chopstick.
Pressure exists inside the cooker Open the lid after the pressure is
completely released.
3 Steam leaks from the lid
Sealing ring installed improperly
Install the sealing ring as required
Food debris attached to the sealing ring
Clean the sealing ring
Sealing ring damaged
Replace the sealing ring
The lid is not closed correctly
Close the lid correctly
4 Steam leaks from float valve
Food debris on the float valve gasket
Clean the float valve gasket
Float valve gasket w orn-out
Replace the float valve gasket
5 Float valve unable to rise Too little food and w ater in inner pot Add water and food according to the
recipe
Steam leaks from the lid or exhaust valve
Send to the service center for repair
6 Steam comes out from exhaust
valve non-stop
Exhaust valve not in sealing position Turn the exhaust valve to the
sealing position
Pressure control fails
Send to the service center for repair
7
Pow er indicator doesn't light on
Pow er socket bad contact
Please check the pow er socket
8 Rice half cooked or too hard
Too litter w ater
Add w ater accordingly
Lid opened prematurely After cooking cycle completes,
leave the lid on for 5 more minutes.
9
Rice too soft
Too much w ater
Reduce water accordingly
10
All indicators flash
Display screen displays E1
Bottom sensor open circuit
Send to the service center for repair
Display screen displays E2
Bottom sensor short circuit
Display screen displays E5
Sensor on the lid open circuit
Display screen displays E6
Sensor on the lid short circuit
Display screen displays E8
Pressure sw itch f ault
Display screen displays E11 Control PCB and Launch PCB
communication fault
Display screen displays E12 Receive PCB and Launch PCB
communication fault
Display screen displays E13
Float sensor open/short circuit
Display screen displays E14
Float sensor correction fault
Display screen displays E15
Temperature sensor on Receive PCB fault
Display screen displays E17
Receive PCB fault
Display screen displays 18
Launch PCB fault
Display screen displays EC
The lid is on the error position
Placed in the right position
Addition: Any technical improvements shall be placed in the
revised manual without notice; for any changes in appearance
and color, those of the actual product shall prevail.
Special Declaration
31 32

Instrucciones de Seguridad
Lea con atención estas instrucciones
1.No utilice ningún aparato con cables o enchufes en
mal estado, si funcionan mal o si están dañados de
cualquier forma. Lleve el aparato al distribuidor
autorizado más cercano para que lo examinen, reparen
o ajusten.
2.Este aparato está diseñado para un uso doméstico
únicamente. No utilice el aparato al aire libre.
3.Mantenga el aparato eléctrico fuera del alcance de los
niños y personas enfermas. No deje que utilicen este
aparato sin supervisión.
4.Este aparato no deben utilizarlo los niños. Mantenga el
aparato y el cable eléctrico fuera del alcance de los
niños.
5.Este producto no debe ser utilizado por personas con
capacidades físicas, sensoriales o mentales reducidas, o
que carezcan de experiencia o conocimiento sobre el
manejo de estos dispositivos, a menos que estén bajo
supervisión de una persona responsable y sean
conscientes de los posibles riesgos.
6.No deje que los niños jueguen con este aparato.
7.No sumerja el aparato ni ninguna de sus partes en
agua u otro líquido.
8.Apague el aparato y desconéctelo de la corriente
eléctrica cuando vaya a realizar de las tareas de limpieza
y mantenimiento, a moverlo de sitio, o cuando no vaya a
usarlo.
9.Este aparato está diseñado exclusivamente para uso
doméstico.
10.Compruebe regularmente el estado de la válvula de
evacuación de vapor para asegurarse de que esté libre
de obstrucciones.
11.No abra la olla a presión antes de que esta se haya
enfriado y la presión interna se haya liberado.
12.No accione el producto con un temporizador externo
o un mando a distancia.
13.Los aparatos de cocina se deben colocar sobre una
superficie estable y con las asas de tal manera que se
evite el derrame de líquidos calientes.
14.Las superficies de la olla están muy calientes y
mantienen un calor residual tras el uso, no las toque.
15.La olla no generará presión si la tapa no está bien
cerrada; no debe abrir la tapa si la presión interna es
demasiado alta.
16.Extreme la precaución cuando use la olla cerca de los
niños.
17.Nunca coloque la olla a presión dentro de un horno
caliente.
18.Tenga especial cuidado cuando mueva el aparato.
Evite tocar las superficies calientes. Utilice las asas.
Utilice protección si fuera necesario.
19.Utilice el aparato únicamente para el fin previsto.
20.Este aparato cocina a presión. El uso inadecuado
puede causar lesiones por quemaduras. Asegúrese de
que la tapa esté debidamente cerrada antes de empezar
a funcionar. Consulte la sección “Preparación para
cocinar”
21.No fuerce para extraer la tapa. Asegúrese de que la
presión interna se haya liberado completamente antes
de abrir la olla a presión. Consulte la sección
“instrucciones de uso”.
22.No llene la olla por encima del nivel MAX (2/3 lleno).
Cuando cocine alimentos que se expanden durante la
ES ES
33 34

Instrucciones de seguridad
cocción, tales como el arroz o las verduras
deshidratadas, no llene el artefacto más de la mitad
(1/2).
23.Utilice una fuente de calor apropiada, según las
instrucciones de uso.
24.No pinche los trozos de carne, como la lengua de
buey, que pueden hincharse debido al efecto de la
presión. Esto podría producir quemaduras.
25.Al cocinar alimentos pastosos, agite suavemente la
olla a presión antes de abrir la tapa para evitar
salpicaduras.
26.Verifique siempre, antes de cada utilización, que las
válvulas no estén obstruidas. Consulte la sección
“instrucciones de uso”.
27.No utilice la olla para freír alimentos a presión.
28.No manipule ninguno de los sistemas de seguridad
más allá de lo estipulado en las instrucciones de
mantenimiento precisadas en el manual de
instrucciones.
29.Utilice únicamente piezas de repuesto originales
conforme al modelo correspondiente. En particular,
utilice el cuerpo y la tapa del fabricante.
30.CONSERVE ESTAS INSTRUCCIONES.
Atención
1.Mantenga las manos y la cara alejadas de la válvula de
escape y de la tapa mientras el aparato esté en
funcionamiento para evitar quemaduras.
2.Desenchufe el aparato de la corriente eléctrica antes
de sacar los alimentos.
3.No toque la tapa durante la cocción o mientras esté
calentando.
4.Mantenga libre el área de la posición de blocaje para
garantizar su seguridad.
5.No intente abrir la tapa de la olla si la válvula de
seguridad está en movimiento o hay presión interna.
6.Preste atención al flujo de agua caliente proveniente
de la descarga de presión al abrir la tapa.
7.La junta de silicona no es un dispositivo de seguridad.
8.Una instalación inadecuada podría causar daños. Lleve
a cabo una instalación apropiada.
9.Evite derramar líquidos sobre el conector.
Customer service address:
SAMSPARTY SL
CL CABAÑA 78, 45210 YUNCOS ,TOLEDO,ESPAÑA
ES ES
35 36
