Aimco AcraDyne ABP Series User manual

PC-Software: 2.0.2.21
Firmware: 2.0.2.8
TRANSDUCERIZED CORDLESS TOOL
OPERATING INSTRUCTIONS
ABP Series ABS Series ABN Series
10000 SE Pine St., Portland, Oregon 97216
Phone: [phone]
www.aimco-global.com

- 2 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
1. IMPORTANT INFORMATION 8
2. GENERAL INFORMATION 9
2.1.0. Importance of the operating instructions . . . . . . . . . . . . . . . . . 9
2.2.0. Proper intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
2.3.0. Improper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.4.0. Guarantee and liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3. BASIC SAFETY INSTRUCTIONS 12
3.1.0. Notices in the operating instructions . . . . . . . . . . . . . . . . . . . 12
3.2.0. Operator‘s responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2.1. Personnel‘s responsibility . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.2.2. Personnel training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.3.0. Risks when working with the tool . . . . . . . . . . . . . . . . . . . . . 12
3.4.0. Danger from electrical energy . . . . . . . . . . . . . . . . . . . . . . . 13
3.4.1. Fundamental safety measures . . . . . . . . . . . . . . . . . . . . . . . 13
3.4.1. Workplace safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4.2. Electrical safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4.3. Personal safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.4.4. Using and handling the power tool . . . . . . . . . . . . . . . . . . . . 15
3.4.5. Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.5.0. Lithium-ion battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.6.0. Cleaning and disposing of the tool . . . . . . . . . . . . . . . . . . . . 19
3.7.0. Risk of injury and damage to the tool . . . . . . . . . . . . . . . . . . . 19
4. STARTUP 20
4.1.0. Installing or removing the battery . . . . . . . . . . . . . . . . . . . . . 20
4.1.1. Trigger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.1.2. Rotating direction switch. . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.1.3. LED / Barcode scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.1.4. Multi-color LED control light . . . . . . . . . . . . . . . . . . . . . . . . 23
4.2.0. Cancel job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.3.0. Back-up strategy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.4.0. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
5. DISPLAY 29
5.1.0. Displays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
6. ACCESSORIES 38
7. TECHNICAL DATA 39
7.1.0. Pistol tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.2.0. Angle tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.3.0. Straight tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
TABLE OF CONTENTS

Im Martelacker 12 – D-79588 Efringen-Kirchen – Telefon 0 76 28 - 91 11- 0 – Telefax 0 76 28 - 91 11-90
E-Mail: [email protected] – Internet: www.hs-technik.com
- 3 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
Disposal
Power tools, batteries, accessories and
packaging must be disposed of at an
environmentally-compatible recycling
facility. Power tools and batteries do not go into the household trash.
Transport
Li-Ion batteries are subject to the specications in the laws pertaining
to hazardous goods. The batteries can be transported on roads by
the user without further constraints.
When shipping with third parties (e.g.: freight forwarders), special
requirements must be observed for packaging and labeling!
Only ship batteries if the casing is not damaged. Cover the contacts
with tape and package the battery so it cannot move around in
the packaging. Please comply with other national and international
requirements.

- 4 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
NOTICE
This warning symbol indicates additional information that
will make your work easier.
WARNING
General warning to prevent operating errors and
failures.
DANGER
This indicates a direct hazard for the worker or the tool.
This warning symbol is especially important and must
be observed.

Im Martelacker 12 – D-79588 Efringen-Kirchen – Telefon 0 76 28 - 91 11- 0 – Telefax 0 76 28 - 91 11-90
E-Mail: [email protected] – Internet: www.hs-technik.com
- 5 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
11 3
24
1 OLED Display to lead the
worker through the process
2 Multi color LED control light
3 Brushless high-powered motor
4 Color index
5 CW / CCW
6 Large trigger
7 Ergonomical handle
8 USB interface
9 Powerful LED
10 Optional WiFi module
11 Optional scanner
12 Premium Li-Ion battery
13 1/4“ hex. socket adapter
5
6
7
8
9
13
10
12
11

- 6 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
5
3
2
1
6
7
8
9
14
4
12
11
10
1
1 OLED Display to lead the
worker through the process
2 Multi color LED control light
3 Brushless high-powered motor
4 Color index
5 CW / CCW
6 Large trigger
7 Ergonomical handle
8 USB interface
9 Powerful LED
10 Optional WiFi module
11 Optional scanner
12 Premium Li-Ion battery
14 3/8“ square adapter

Im Martelacker 12 – D-79588 Efringen-Kirchen – Telefon 0 76 28 - 91 11- 0 – Telefax 0 76 28 - 91 11-90
E-Mail: [email protected] – Internet: www.hs-technik.com
- 7 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
1
5
3
2
1
6
7
8
9
13
4
12
11
10
1 OLED Display to lead the
worker through the process
2 Multi color LED control light
3 Brushless high-powered motor
4 Color index
5 CW / CCW
6 Large trigger
7 Ergonomical handle
8 USB interface
9 Powerful LED
10 Optional WiFi module
11 Optional scanner
12 Premium Li-Ion battery
13 1/4“ hex. socket adapter

- 8 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
NOTE
Tool conguration determines which functions can
be used. Furthermore each basic function has many
subfunctions.
Included Optional
Model Shut-o
clutch
Torque
transducer
Reaction
sensor Display Scanner WiFi
Pistol Tool
ABP-CTAxx
Angle Tool
ABN-CTAxx
Straight Tool
ABS-CTAxx
Danger!
Before you put the tool down, wait until it has come
to a complete stop as otherwise, the tool can jam
and you may lose control of the tool.
Danger!
When tightening and unscrewing screws, high
reaction torques may arise. Therefore, always keep
a tight grip on the tool.
Danger!
Switch the electrical device off immediately if the
tool used locks up and be prepared for high reaction
torques that can cause kickback. The tool locks up
when it is overloaded or jams in the workpiece.
1. IMPORTANT INFORMATION

Im Martelacker 12 – D-79588 Efringen-Kirchen – Telefon 0 76 28 - 91 11- 0 – Telefax 0 76 28 - 91 11-90
E-Mail: [email protected] – Internet: www.hs-technik.com
- 9 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
2. GENERAL INFORMATION
2.1.0. IMPORTANCE OF THE OPERATING INSTRUCTIONS
This information was written with the intention of being read, understood
and complied with in all points by persons responsible for the operation
of the AIMCO tool.
Prior to start-up, please read the operating instructions and comply
with the safety instructions. Work station faults can only be prevented
if the contents of these operating instructions are known and fault-free
operation can be ensured.
We are not liable for damages and operational errors that result from
non-compliance with these operating instructions. If difculties arise
nonetheless, please contact us and we will gladly provide assistance.
2.2.0. PROPER INTENDED USE
The tool may only be used, as described in these instructions, to create
screw joints suitable for the type of tool.
NOTICE
Proper intended use also includes:
• complying with all instructions in the operating
instructions
• complying with inspection and maintenance work.
Any other use beyond this is not considered proper intended use.
AIMCO is not liable for any damages resulting from non-compliance.
2.3.0. IMPROPER USE
We are not liable for damages and operational errors that result from
non-compliance with these operating instructions or improper use.
Danger!
The tool is not a torque wrench. This tool cannot be
used for already tightened connections as otherwise
very high reaction torques arise and the motor control
and the motor can overheat.

- 10 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
2.4.0. GUARANTEE AND LIABILITY
NEW TOOL AND ACCESSORY WARRANTY
Any new tool or accessory branded with the AIMCO, Uryu, AcraDyne
or Eagle Industries name, and purchased from AIMCO, or through one
of its authorized distributors or agents, is warranted to the original buyer
against defects in materials and workmanship for a period of one (1)
year* from date of delivery. Under the terms of this warranty, AIMCO
will repair or replace any product or accessory warranted hereunder
and returned freight prepaid proving to AIMCO’s satisfaction to be
defective as a result of workmanship or materials. In order to qualify
for this warranty, written notice to AIMCO must be given immediately
upon discovery of such defect, at which time AIMCO will issue an
authorization to return the tool. The defective item must be promptly
returned to an authorized AIMCO service center with all freight charges
prepaid.
REPAIRED TOOL WARRANTY
Once a tool is beyond the new product warranty period as detailed
above, AIMCO repairs are subject to the following warranty periods:
pneumatic tools: 90 days*; electric tools and Acra-Feed: 90 days;
battery tools: 30 days*; DC Electric tools: 90 days*
EXCLUSION FROM WARRANTY
This warranty is valid only on products purchased from AIMCO,
or thru its authorized distributors or agents. AIMCO shall have no
obligation pursuant to the AIMCO Warranty with respect to any tools
or accessories which in AIMCO’s sole judgment have been altered,
damaged, misused, abused, badly worn, lost or improperly maintained.
This Warranty is null and void if the customer, or any other person other
than an authorized representative of AIMCO, has made any attempt
to service or modify the tool or accessory prior to its return to AIMCO
under this Warranty.
The warranty provision with respect to each such product may be
amended by AIMCO from time to time in its sole discretion. The liability
of AIMCO hereunder shall be limited to replacing or repairing, at its
option, any products which are returned freight prepaid to AIMCO
and which AIMCO determines to be defective as described above or,
at AIMCO’s option, refunding the purchase price of such products.

Im Martelacker 12 – D-79588 Efringen-Kirchen – Telefon 0 76 28 - 91 11- 0 – Telefax 0 76 28 - 91 11-90
E-Mail: [email protected] – Internet: www.hs-technik.com
- 11 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
AIMCO reserves the right to make periodic changes in construction or
tool design at any time. AIMCO specically reserves the right to make
these changes without incurring any obligation or incorporating such
changes or updates in tools or parts previously distributed.
THE AIMCO WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, AND AIMCO EXPRESSLY DISCLAIMS ANY
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. THIS WARRANTY SETS FORTH THE SOLE AND EXCLUSIVE
REMEDY IN CONTRACT, TORT, STRICT LIABILITY, OR OTHERWISE.
THIS WARRANTY IS THE ONLY WARRANTY MADE BY AIMCO WITH RESPECT
TO THE GOODS DELIVERED HEREUNDER, AND MAY BE MODIFIED
OR AMENDED ONLY BY A WRITTEN INSTRUMENT SIGNED BY A DULY
AUTHORIZED OFFICER OF AIMCO.
LIMITATION OF LIABILITY
AIMCO’S LIABILITY PURSUANT TO WARRANTY OF THE PRODUCTS
COVERED HEREUNDER IS LIMITED TO REFUND OF THE PURCHASE PRICE.
IN NO EVENT SHALL AIMCO BE LIABLE FOR COSTS OF PROCUREMENT
OF SUBSTITUTE GOODS BY THE BUYER. IN NO EVENT SHALL AIMCO BE
LIABLE FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL OR OTHER
DAMAGES (INCLUDING WITHOUT LIMITATION, LOSS OF PROFIT)
WHETHER OR NOT AIMCO HAS BEEN ADVISED OF THE POSSIBILITY
OF SUCH LOSS, HOWEVER CAUSED, WHETHER FOR BREACH OR
REPUDIATION OF CONTRACT, BREACH OF WARRANTY, NEGLIGENCE
OR OTHERWISE. THIS EXCLUSION ALSO INCLUDES ANY LIABILITY WHICH
MAY ARISE OUT OF THIRD PARTY CLAIMS AGAINST BUYER. THE ESSENTIAL
PURPOSE OF THIS PROVISION IS TO LIMIT THE POTENTIAL LIABILITY OF
AIMCO ARISING OUT OF THIS AGREEMENT AND/OR SALE.
Note: The AIMCO Warranty confers specic legal rights, however
some states or jurisdictions may not allow certain exclusions or
limitations within this warranty.
* All warranty periods addressed herein are determined using a
standard shift, eight-hour work day.

- 12 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
3. BASIC SAFETY INSTRUCTIONS
3.1.0. NOTICES IN THE OPERATING INSTRUCTIONS
• The basic requirement for safe and proper use and fault-free
operation is knowledge of the basic safety instructions and safety
regulations.
• In addition, the rules and regulations for the place of use must be
followed.
3.2.0. OPERATOR‘S RESPONSIBILITY
The operator is obligated to only allow persons to work with this tool
who are familiar with the basic regulations for work safety and accident
prevention and are trained in how to use the tool. Safety-conscious
work of the personnel must be checked at regular intervals.
3.2.1. PERSONNEL‘S RESPONSIBILITY
All persons working with this tool are obligated to comply with the basic
regulations for work safety and accident prevention prior to starting
work.
3.2.2. PERSONNEL TRAINING
Only trained and qualied personnel may work with this tool. The respon-
sibilities of the personnel for the assembly, start-up, operation, mainte-
nance and servicing must be clearly dened. Personnel-in-training may
only operate the machine in the presence of an experienced person.
3.3.0. RISKS WHEN WORKING WITH THE TOOL
Faults that may hinder safety must be immediately rectied.

Im Martelacker 12 – D-79588 Efringen-Kirchen – Telefon 0 76 28 - 91 11- 0 – Telefax 0 76 28 - 91 11-90
E-Mail: [email protected] – Internet: www.hs-technik.com
- 13 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
WARNING
The tool was built in accordance with the state
of the art in technology and the approved safety
regulations. Still, when using it, risks to life and limb of
the user or third parties or other material assets may
arise.
DANGER
Only allow a qualied electrician to perform work on
this tool. The electrical equipment of the tool must be
regularly inspected. Loose connections and charred
cables must be immediately repaired. If work must be
performed with the tool, remove the battery prior to
opening the device.
WARNING
Only use the tool
• for the proper intended use
• in working order with regards to safety
NOTICE
The terms "tool" and "power tool" used in the safety
instructions pertain to mains-operated power tools
(with power cable) and battery operated power
tools (without power cord).
WARNING
The tool must be kept closed at all times. Access is
only permitted for authorized persons with a tool.
3.4.0. DANGER FROM ELECTRICAL ENERGY
3.4.1. FUNDAMENTAL SAFETY MEASURES

- 14 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
3.4.1. WORKPLACE SAFETY
a) Keep your workspace clean and well lit.
Disorder or poorly lit workspaces can lead to accidents.
b) Do not use the tool in an explosive environment, in which
ammable liquids, gases or dusts are located. Power tools can
generate sparks which can ignite the dust of vapors.
c) Takeenvironmentalinuencesintoaccount.
Never subject tools to rain. Do not use in moist or wet environments.
d) Keep other persons away from tool while in use.
If you are distracted, you can lose control of the device.
3.4.2. ELECTRICAL SAFETY
a) Avoid physical contact with grounded surfaces such a pipes,
heaters, etc.
There is an increased risk of electrical shock if your body is grounded.
b) Keep the device away from rain or moisture.
Water penetrating into the tool increases the risk of electrical shock.
c) Keep tool away from heat, oil, sharp edges, or moving device parts.
3.4.3. PERSONAL SAFETY
a) Be careful, pay attention to what you are doing and use power
tools responsibly.
Do not use power tools when you are tired or under the inuence
of drugs, alcohol or medication. One moment of carelessness
when using the tool can lead to severe injuries.
b) Always wear personal safety equipment and protective eyewear.
Wearing protective safety equipment such as a dust mask, safety
shoes, a protective helmet and hearing protection, depending
on the type and use of of the tool, decreases the risk of injuries.

Im Martelacker 12 – D-79588 Efringen-Kirchen – Telefon 0 76 28 - 91 11- 0 – Telefax 0 76 28 - 91 11-90
E-Mail: [email protected] – Internet: www.hs-technik.com
- 15 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
c) Avoid unintended start-up.
Ensure that the power tool is shut off before you connect it to the
battery, pick it up, or carry it. If you have your nger on the trigger
while carrying the power tool, or the device is connected to the
power supply, this can lead to accidents.
d) Avoid non-ergonomic posture.
Make sure you are standing stably and always maintain your balance.
You can then control the power tool in unexpected situations.
e) Wear suitable clothing.
Do not wear loose clothing or jewelry. Keep your hair, clothing and
gloves away from moving parts. Loose clothing, jewelry or long hair
can get caught in moving parts.
3.4.4. USING AND HANDLING THE POWER TOOL
a) Do not overload the tool.
Use the proper tool for your work . You work better and more safely
in the dened output range when using the proper tool .
b) Do not use power tools with defective switches.
A tool that cannot be shut off is dangerous and must be repaired.
c) Remove the battery before you change tool settings, replace
accessories or lay the tool down.
This prevents the power tool from starting unintentionally.
d) Store unused tools out of reach of children.
Do not allow persons to use the device who are not familiar with
it or have not read these instructions. Power tools are dangerous if
they are used by inexperienced persons.
e) Take good care of the power tool.
Check that moving parts work properly and do not jam, that there
are no broken or damaged parts and that the functionality is not
hindered. Have damaged parts repaired prior to using the device.
Many accidents are caused by poorly maintained power tools.

- 16 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
f) Keep the tools clean.
Carefully maintained tools jam less often and are easier to use.
g) Use the tool, accessories, etc. in accordance with these instructions.
Take the working conditions and task to be executed into
account. The use of power tools for other purposes than the
intended use can lead to hazardous situations.
h) Use the right tool
Do not use low-output tools for heavy loads. Do not use the tool
for purposes and work for which it is not intended.
i) Check your tool for damage
Prior to further use of the tool, the safety equipment or damaged
parts must be inspected to ensure proper functionality.
Check to ensure the functionality of moving parts, that they don’t
jam, that no parts are broken and that all parts are properly and
correctly installed and all conditions required for the operation of
the device have been fullled.
Damaged safety equipment and parts should be properly repaired
or replaced by a customer service workshop unless otherwise
indicated in the operating instructions . Damaged switches must
be replaced by a customer service workshop. Do not use tools on
which the trigger cannot be easily switched on and off .
3.4.5. SERVICE
NOTICE
Only allow your power tool to be repaired by a
qualied technician using only original spare parts,
available from AIMCO. This ensures that the safety of
your device is maintained.

Im Martelacker 12 – D-79588 Efringen-Kirchen – Telefon 0 76 28 - 91 11- 0 – Telefax 0 76 28 - 91 11-90
E-Mail: [email protected] – Internet: www.hs-technik.com
- 17 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
3.5.0. LITHIUMION BATTERY
NOTICE
Please make sure to follow the following instructions
for using lithium-ion batteries!
a) Only charge the batteries in chargers recommended by the
manufacturer.
If the battery is not charged on a suitable charger, it can be
permanently damaged .
b) Only use the provided battery for power tools.
The use of other batteries can lead to injuries and re hazards.
c) If the battery is not used for a longer period of time, it must not
remain on the charger or on the tool.
If a work break of more than 3 hours is expected, the battery
must be removed from the tool. Otherwise, the battery may be
permanently damaged.
d) The lithium-ion battery should not remain on the charger for
longer than 36 hours for safety reasons.
Remove the battery from the charger immediately after the
charging process is completed.
e) An empty battery should not be in contact with the tool or a
charger that is disconnected from the mains for a longer period
of time.
In both cases, currents are owing that deep discharge the
battery and can permanently damage it.
f) Recharge the lithium-ion batteries immediately and never store
them when empty.
If the battery is stored while disconnected from the tool and the
charger, it will maintain a constant capacity over a long period of
time. (Loss approx. 5% per year)
g) Always transport the battery separately from the tool.
You thus prevent accidentally switching on the tool and deep
discharging the battery.

- 18 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
NOTICE
Lithium-ionbatterieshavenearlynoself-dischargeand
donothavea memoryeffect.Ifproperlyused,they will
reliably supply your tool with power for several years
(approx. 700 - 1000 charge cycles).
In general the following applies:
Avoid deep discharging or overcharging the lithium-
ion battery under any circumstances. It will be
permanently damaged from this.
h) Do not subject the lithium-ion battery to high temperatures
(+ 50°C) or direct sunlight.
If the battery gets warmer than 50°C during operation (charging
or discharging), it must be removed from the charger or tool
immediately.
i) Keep the unused battery away from paper clips, coins, keys, nails,
screws or other small metal objects which might bridge the contacts.
Do not open the battery and do not short-circuit it.
A short-circuit between the battery contacts can lead to burns, re
or explosions.
j) Under extreme use or temperature conditions, batteries can leak.
Avoid contact with the skin or eyes if the battery leaks. The
battery uid is acidic and can cause chemical burns on tissue.
If the uid comes into contact with skin, immediately wash it with
soap and water and then rinse it with lemon juice or vinegar. If the
uid gets into the eyes, ush with water for at least 10 minutes and
immediately go to the doctor.
k) Make sure that the Li-Ion battery does not fall down or is subject
to vibrations and impacts.
l) Clean the contacts regularly with a cotton swab soaked in a high-
percent alcohol.

Im Martelacker 12 – D-79588 Efringen-Kirchen – Telefon 0 76 28 - 91 11- 0 – Telefax 0 76 28 - 91 11-90
E-Mail: [email protected] – Internet: www.hs-technik.com
- 19 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
1. Make sure that none of the tool parts are
damaged. All damaged parts must be
repaired prior to using the device. If you work
with damaged tool parts, you risk injury.
2. If you work on raised platforms, wear a safety
belt and avoid letting the tool fall down. Non-
compliance may lead to injury and signicant
damage.
3. First remove the battery before you clean the
device or perform general maintenance.
4. Never hold your face near the exhaust holes.
5. Avoid skin contact with substances such as
lubricating grease and oil. These substances are
ammable on skin. If you do come into contact
with them, thoroughly wash the area.
6. Avoid unstable working positions. You might fall
down and injure yourself.
7. Maintain your tool carefully. Follow the operating
instructions for maintenance and cleaning.
- Keep the handle free of lubrication greases
and dirt.
8. Use the tool carefully and pay attention
to proper use. Use the tool carefully. When
working, the framework conditions should be
fullled. Always concentrate while working.
3.6.0. CLEANING AND DISPOSING OF THE TOOL
Use and dispose of used materials and substances properly, in particu-
lar cleaning agents and solvents.
Donotthrowtheusedbatteryinthehouseholdtrash,areorinwater;
have it properly disposed of by a specialist shop or the manufacturer.
3.7.0. RISK OF INJURY AND DAMAGE TO THE TOOL

- 20 -
10000 SE Pine St. Portland, Oregon 97216 Phone: [phone]
www.aimco-global.com
4. STARTUP
Do not let the tool fall or allow other objects to fall on the device.
Protect it from impact damage. Make sure that the device does not
come into contact with sprayed water or oil.
• To remove the battery, set the
rotational direction switch to
the center position, slide the
clip on the front side of the
battery back and pull it for-
ward away from the machine.
• To install the battery, align the
tongue of the battery with the
groove in the casing so it can
easily slide into place.
• Always slide it on completely
until it locks with a click. Check
that the battery is correctly
locked in place before starting
to work.
If the battery is not installed proper-
ly, it can fall out of the tool and
lead to injuries.
• Never use force when install-
ing the battery. If the battery
cannot be easily slide in, it has
not been correctly installed.
1 – Clip
2 – Remove battery
2
1
4.1.0. INSTALLING OR REMOVING
THE BATTERY
