Aiphone AP-1M User manual

83599800
O AlPHONE
AP-M Series
HIGH-POWER INTERCOM
AP-1M,
1-call master
Models: AP-5M,
5-call master
V
AP-10M,
10-calt master Type a: 2
30V AC version
J
INSTALLATION MANUAL
system in combination with re

■ Components available
• Master stations • Sub stations
Wall/desk Ceiling mount
• Mounting accessories: N-EA: Frame for AS-3N, ceiling surface-mount
NBZ-M: Ceiling flush-mounf
NP-W; Surface-mount box for NP-B
2 NAMES AND FEATURES
• Desk/wall or ceiling subs available
1. Speaker
2. OFF button
3. Station selector button
4. Call-in LED
5. Directory card
6. Power on LED
7. Power switch
8. Mic.
9. RECEIVE volume control
10. TRANSMIT volume control
11. Tone CALL button
12. TALK/LISTEN button
13. Occupied LED
14. AC cord/plug
15. Preset receive & transmit volume controls
8Q horn speaker w/taikback
Separate transmit & receive volume controls
Group call (selectively up to 5 subs)
Speaker
Power on LED
Power switch
Mic.
RECEIVE volume control
TRANSMIT volume control
OFF button
TALK/LISTEN button
Communication LED
AC cord/plug
Preset receive & transmit volume controls
-2-

3 WIRING
• AP-5M terminals
As shown, station numbers 1 - 5 (top row) & 6 - 10 (2nd row)
are assigned, corresponding to the terminal numbers.
■ Cable
Use a single-twisted pair cable for wiring between AP-M and each sub, homerun, or the other AP-M (In USA,
cable # 832202 specified)
■ Wiring
For 8Q horn
-3-

■ WIRING DIAGRAMS
• AP-5M,AP-10M
MOUNTING

5 OPERATIONS on AP-M
■ Placing a call to sub
1. Depress the station selector button of sub.
2. Depress CALL button to ring sub with mono tone.
Or press TALK button and call with voice.
3. Release TALK button to listen.
Press TALK button to repiy.
4. At conclusion, depress OFF button.
■ Receiving a sub call-in
1. Monotone sounds, and a call-in LED is lit for 15 sec.
2. Depress the LED lit station selector button.
3. Press TALK button to talk and release to listen.
4. At conclusion, depress OFF button.
★ A call-in from sub during communication is indicated by a lit LED only.
■ Group Call (up to 5 subs)
1. Depress up to 5 station selector buttons.
2. Depress and hold down TALK button to transmit.
3. Depress OFF button(s) to reset.
■ Communication between AP-M’s
The other AP-M calls in with tone or with voice direct.
Depress the other master’s selector button. Initiating master uses TALK button to talk, and release to
■ Volume adjustments
On front panel, set speech volumes as desired.
Replace to MID levels at end of each communication.
RECEIVE vol. , 3-position
TRANSMIT vol., 3-position
■ Sub stations: AS-3A, AS-3WA, 8Q horn
To call, depress momentarily CALL button on AS-3A sub (either on AS-3WA) or on NP-B. It rings
AP-M master with monotone, and an LED is lit for approx. 15 seconds. Master calls in with tone
and/or voice directly. Just reply toward the unit hands free.
■ Operations on AP-1M
To call a sub with tone, press both
OFF and TALK buttons. Or press
TALK and call by voice.
Continue communications with TALK
When finished, depress OFF button.
-5-

ApXsSto,
AP-M-I/M(E)1096A
