Zero Gravity Laser™
Wall Racer
Controller/Charger
NOTE: USE ON SMOOTH, CLEAN
SURFACES ONLY!
FOR INDOOR USE ONLY.
ADULT SUPERVISION RECOMMENDED!
TO GET THE MOST OUT OF YOUR
ZERO GRAVITY LASER™
WALL RACER PLEASE READ THESE
INSTRUCTIONS FIRST!
Check to make sure contents are
complete:
• 1 Zero Gravity Laser™ Wall Racer
• 1 Controller/Charger
• 1 Instruction Guide
BATTERY INSTALLATION
CHARGING YOUR ZERO GRAVITY LASER™
1. Switch
car to “OFF”.
2. Switch
controller/
charger to
“OFF”.
3. Take out
charger
plug and
plug into
c a r.
4. Slide the
switch to
the “Charge”
position on
the controller.
5. Red light ashing:
Vehicle is charging.
Green & Red light
ashing together:
Vehicle is charged.
Green & Red light ashing
alternatively: error.
Green light
ashing/Red light off:
Replace AA Batteries.
6. When
charged, turn
controller/
charger
switch to
“OFF”.
• Charging should take between 30 and 50 minutes depending on how much charge is left in the car.
• NOTE: Do not charge battery immediately after use. Let the car battery cool for at least 10 minutes.
If charging is not complete in 50 minutes, replace the charger batteries.
Your Wall Climber has a pre-installed rechargeable battery inside the vehicle body. (Rechargeable battery is not replaceable.)
CONTROLLER/CHARGER
Six 1.5-V AA
Alkaline Batteries
Battery
Compartment
Battery
Compartment
Door
OFF
CHARGE OFF ON
CHARGE OFF ON
CHARGE OFF ON
Red
LED Green
LED
TM
1. Requires 6 1.5-V AA alkaline batteries.
2. Open the battery door with a screwdriver.
3. If used batteries are present, remove these batteries from the
unit by pulling up on one end of each battery.
4. Install new batteries as shown in the polarity diagram (+/-) inside
the battery compartment.
5. Replace battery door securely.
6. Check your local laws and regulations for correct recycling and/or
battery disposal.
INSTRUCTION
GUIDE
®
1

To drive on walls and upside down, you must have switch positioned
to the left.
NOTE: Avoid driving overhead when other people are around. Do not
stand underneath when driving overhead.
To drive on the ground you must have the switch positioned in the middle.
The fan will not turn ON, but the green light on top of vehicle will turn
on and will drive properly on the ground. (The ground mode saves the
battery charge.)
The fabric air skirts can be adjusted outward at a 45º angle to ensure
proper wall suction.
IMPORTANT: The Zero Gravity Laser™ should only be driven
on smooth, clean, at surfaces. Dirt or debris can get inside the fan
and cause damage.
When nished with your Zero Gravity Laser™ Wall Climber, remove vehicle from wall.
Turn vehicle OFF. Turn the controller OFF.
Turn the controller “ON”. Pull the trigger on controller to emit a beam, point
the beam at the wall or ground in front of car.
The car will chase the beam from controller, as
you move the beam across the wall or ground.
DRIVING ON WALLS OR UPSIDE DOWN DRIVING ON WALLS OR UPSIDE DOWN
DRIVING SEQUENCE
DRIVING ON THE GROUND
WG
OFF
WG
OFF
CHARGE OFF ON
PROBLEMS? Before you return to retailer, please call our HOTLINE for assistance,
1-800-622-8339
2

up to 2 metres/
6 feet
WHILE DRIVING YOUR ZERO GRAVITY LASER™ WALL CLIMBER,
MAKE SURE TO FOLLOW THESE RULES
Stand within 2 metres/6 feet
of the wall.
Do not drive off the corner
or off the edge of the wall.
Only drive on smooth, clean, dry
surfaces. Make sure walls are clear of
obstacles, including hanging pictures,
light switches, etc...
Do not drive on uneven,
porous, or broken surfaces, as vehicle
will not adhere and can fall off.
.33 metres/
1 foot
.33 metres/
1 foot
Make sure to point the
laser beam within .33 metres/1 foot
radius of the vehicle.
Do Not point the laser beam outside
a .33 metres/1 foot radius of the vehicle,
or the vehicle will not respond.
IMPORTANT: The Zero Gravity Laser™ Wall Climber may not work on windows, glass or reective surfaces as the remote function could be impaired.
3

Your Zero Gravity Laser™ is equipped with a
Lithium Polymer battery.
WARNING:
• Never charge battery unattended.
• Charge battery in isolated area. Keep away from
flammable materials.
• Do not expose to direct sunlight.
• There is a risk of the batteries exploding,
overheating, or igniting. Do not disassemble,
modify heat, or short circuit the batteries. Do not
place them in fires or leave them in hot places.
• Do not drop or subject to strong impacts.
• Do not allow the batteries to get wet.
• Only charge the batteries with the specified
Spin Master™ battery charger.
• Only use the batteries in the device specified by
Spin Master™.
• Carefully read the instruction guide, and use the
batteries correctly.
• In the unlikely event of leakage or explosion use sand
or a chemical fire extinguisher for the battery.
• Batteries must be recycled or disposed of properly.
TROUBLESHOOTING
PROBLEM SOLUTION
TM
Vehicle will not run.
Vehicle does not drive well.
Vehicle does not climb walls.
Vehicle slips climbing walls.
Vehicle falls off the wall.
1. Power switch is off. Turn on.
2. Controller battery is installed with incorrect polarity. Check (+) and (-) markings to make sure the battery is properly aligned.
3. Batteries are drained. Install new batteries.
1. Make sure surface is clean of dirt/dust. 2. Make sure surface is neither too rough or too smooth.
3. Make sure surface is at.
1. Turn vehicle off for 30 seconds then restart.
2. Suction is jammed. Remove debris by blowing gently on the fan area located on the bottom of the vehicle.
1. Clean the tires with a damp rag. 2. Fold up the fabric skirts for a better seal prior to use.
1. Make sure to discharge and then charge again for 30 to 50 minutes.
2. Clean tires and make sure your wall and oor are also clean.
3. Check the fabric skirts for damage. If they have been pulled loose, tape them back on with exible tape.
4. Make sure surface is at.
IMPORTANT: When the LED begins to blink, the battery is
running low on power. Car should be removed from the wall
immediately. Otherwise the vehicle may fall off the wall.
The Zero Gravity
Laser™ Wall Climber has
a working LED light on the
top of the car.
This product complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that may cause undesirable operation. This equipment has been tested and found to comply with the limits for Class B
digital devices pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference to radio communications. Because this toy
generates, uses, and can radiate radio frequency energy, there can be no guarantee that interference will not occur. If this toy does cause interference to radio or television reception
(you can check this by turning the toy off and on while listening for the interference), one or more of the following measures may be useful: • Reorient or relocate the receiving antenna
• Increase the separation between the toy and the radio or the TV • Consult the dealer or an experienced TV-radio technician for help.
NOTE: Changes, adjustments or modifications to this unit, including but not limited to, replacement of any transmitter component (crystal, semiconductor, etc.) could result in a violation of
FCC rules under part 15 and/or 95 and must be expressly approved by Spin Master Ltd. or they could void the user’s authority to operate the equipment.
This class B digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment Regulations.
BATTERY SAFETY INFORMATION:
• Requires 6 x 1.5V AA batteries (not included)
• Batteries are small objects.
• Replacement of batteries must be done by adults.
• Follow the polarity (+/-) diagram in the battery compartment.
• Promptly remove dead batteries from the toy.
• Dispose of used batteries properly.
• Remove batteries for prolonged storage
• DO NOT incinerate used batteries.
• DO NOT dispose of batteries in fire, as batteries may explode or leak.
• DO NOT mix old and new batteries or types of batteries
(i.e. alkaline/standard).
• DO NOT use rechargeable batteries.
• DO NOT recharge non-rechargeable batteries.
• DO NOT short-circuit the supply terminals.
Spin Master Ltd., 450 Front Street West, Toronto, ON M5V 1B6 Canada
Spin Master Inc., PMB #10053, 300 International Drive, Suite 100,
Williamsville, NY 14221, USA
Spin Master Toys Far East Limited. Rm #1113, 11/F,
Chinachem Golden Plaza, 77 Mody Rd., Tsimshatsui E., Kowloon, HK
North American Consumer Information
Phone: [phone]
www.spinmaster.com
®, TM and © 2009 Spin Master Ltd. Air Hogs ® is a registered trademark of Spin Master Ltd. All rights
reserved. Conforms to product safety standards ASTM F963, regulatory requirements. • Please retain
this information for future reference. • Please remove all packaging materials before giving to children.
• An adult should periodically check this toy to ensure no damage or hazards are found, if so, remove
from use. • Children should be supervised during play. • Keep addresses and phone numbers for
future reference. • The item inside this package may vary from the photographs and/or illustrations.
Patent Pending. MADE IN CHINA.
20029107, 20029109 NBL English REV 0
T44366_0007_20029107_NBL_IS_R1
4
!
WARNING:
Do not point the LED light at eyes. It is rare but
possible for seizures to be triggered by light
ashes. To reduce exposure to such potential,
do not ash lights directly into eyes.
!
NOTE: If normal function of the product is disturbed or interrupted, strong electro-magnetic interference may be causing the issue. To reset product, turn it
completely off, then turn it back on. If normal operation does not resume, move the product to another location and try again.
To ensure normal performance, change the batteries, as low batteries may not allow full function.
IMPORTANT SAFETY INFORMATION: Keep clear from face, eyes, and hair at all times. Do not aim at people or animals. Use caution; make sure people around you know that you are
playing with AIR HOGS®. Stay away from obstacles and electrical hazards. Play with this product in a wide-open room, far away from breakable items. Avoid playing near vents and/or fans,
as these may over power this product and make it difficult to control. NOTE: Always get permission to play with this product indoors. Please retain this information for future reference. Use
alkaline batteries for best performance. ADULT SUPERVISION RECOMMENDED.
