Filter Regulator Made of Stainless Steel Throughout,
up to 80 bar - B3000
0313
General
Compressedairsystemshavetobeprotectedagainstdirtandcondensedwater.Toachievethisafilter
needs to be built into every compressed air system. The choice of filter elements depends on what is
required. Every machine driven by compressed air requires a certain operational pressure. In practice,
thisis notalways thesame astheline pressure.The pressurereducer orpressureregulator isresponsible
for establishing a specific operating pressure (secondary pressure) and keeping it constant regardless
oftheair flow rate and primary pressure. The filterregulatorin a machine serves the purpose of boththe
filterandthe regulator.
Installation
Toensurethe filterregulatorfunctions properly,every pipelineneeds tobepurged, toremoveall deposits
and other foreign materials/objects prior to installing the filter regulator. The filter regulator has to be
installed in the line in such a way that the air flows in the direction of the arrows on the housing (IN to
OUT). Carry out the installation as close as possible to the active appliance. To install a pressurised
stop properly apply a sealing compound paste orTeflon tape to the external screw thread.
Pressure setting:
Prior to starting up the pressure control system, the filter regulator has to be relieved of load by rotating
the adjusting knob/adjusting spindle counter-clockwise. To change the starting pressure the adjusting
knob has to be pulled up as far as possible. This does not apply if the filter regulator has a spindle.
Rotating the adjusting knob/adjusting spindle clockwise increases the outlet pressure. Rotating the
adjusting knob/adjusting spindle anti-clockwise reduces the outlet pressure. Self-relieving regulators
adjusttheoutletpressureaccording tothe settingoftheadjustingknob/adjusting spindle;the filterregulator
ventstheexcesspressure.Withnon-relievingfilter regulators, the outlet pressure has to be reduced by
meansofthe flow rate, or the system has tobeventedat another location. Non-relieving filter regulators
cannot independently reduce overpressure at the outlet. To safeguard the settings press the setting
knob back down. When using a filter regulator with a spindle, the pressure range can be set using the
counter screw.
Maintenance and cleaning
To clean the filter regulator it is necessary to remove it from the construction. If the filter regulator shows erratic behaviour or the outlet
pressureraisespermanently,the usual cause is dirt in the valve seat area.Towork on the filter regulator safely, switch offtheairsupply
and vent the lines. No extra effort or tools are necessary for disassembling the filter regulator.
Regulator unit
To gain access to the membrane and the setting spring, turn the hexagonal bolt or knurled screw on the regulator’s adjustment knob.
Filter regulators in the plastic series have a red plastic ring securing the machine. This must be extracted before rotating.To clean the
valve seat area, the filter container has to be unscrewed by turning it counter-clockwise.Again, if using the plastic series, remove the
security ring first. The filter element and the stay bolts have to be unscrewed or pulled out. Then remove the tappet.
Filter unit:
Removethefilter container by turning it counter-clockwise.Again,when using theplasticseries,remove the security ring first. Unscrew
or pull out the filter element or twist cap. All parts can be cleaned using household detergent. After cleaning, purge all parts with
compressed air: The filter element has to be purged from the inside to remove remaining particles from the surface.
Drain valves:
Overfilled filter containers allow the condensate to flow unhindered through the filter. The filter is not effective then. It is important,
therefore, to make sure the container is emptied on time. Manual drain valves areinexpensive, but require constant monitoring of the
container contents. Pressure sensitive drain valves always empty in a de-pressurised state . They are useful if the machine is
frequentlyswitchedoff.Automatically functioningdrainvalvesdrain thecontainerataspecifiedfluid level.Theyprovidealow-maintenance
operation. Drain automats for external attachment to the container are suited for higher pressures.

AirCom Pneumatic GmbH .Siemensstrasse 18 .D - 40885 Ratingen
Phone: [phone] .Fax: [phone]
Internet: http//www. aircom.net .E-Mail: [email protected]
Description Filter pressure regulator with bowl without sight glass,
completely made of stainless steel.
Diaphragm-operated, from size G¾ on piston-operated.
Media compressed air, gases or liquids
Supply pressure max. 30 bar for B3000-01 and -A2 optionally 50 bar or 80 bar
(with drain plug only)
Adjustment by adjusting screw, from B3000-12 on with T-handle,
max. 50 bar for B3000-02 to -16, optionally 80 bar
Relieving function relieving, optionally non-relieving
Gauge port G¼ on both sides of the body,
G1⁄8 for B3000-01/-A2, one screw plug supplied
Filter element 50 µm and 5 µm, made of stainless steel
Bowl stainless steel version without sight glass
Drain manual drain (max. 30 bar) for B3000-01 and - A2,
screw plug for 50 bar and 80 bar version
automatic drain (max. 16 bar) for G¼ (02) up to G2
Temperature range -20 °C to 80 °C NBR/Buna-N, EPDM or FKM
-20 °C to 130 °C for high temperature version
or low temperature version down to -40 °C / -40 °F
Material Body / Bowl / Inner valve : stainless steel 316L, material-no. 1.4404
O-rings: FKM, optionally EPDM
Diaphragm: NBR/Buna-N with PTFE-coating
