AIRFLO PSV-8E Programming manual

Airflo MANUFACTURING CO., INC.
365 UPPER OAKWOOD AVE, ELMIRA NY 14903
PHONE: [phone] / FAX: [phone]
OPERATOR & PARTS MANUAL
PSV-8E (GAS DRIVEN SPREADER)
Visit our website at www.air-flo.com

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
1 | P a g e
Contents
Pre-Use Checklist .................................................. 1
Vehicle Requirements........................................... 2
Spreader and Material Weights....................... 3
Safety .................................................................... 3
Installation Instructions ........................................ 4
Mounting the Spreader onto the Vehicle........ 4
Things to Know after Mounting the Spreader
................................................................. 5
Mounting the Spinner/Chute Assembly.......... 5
Spreader Operation .............................................. 7
Control Panel Description ................................ 7
Wire Harness Installation................................. 8
Starting the Engine........................................... 8
Stopping the Engine ......................................... 8
Spinner Operation............................................ 8
Spinner/Chute Assembly Operation................ 9
Precautions....................................................... 9
Spreader Maintenance ....................................... 10
Part List ............................................................... 12
Spinner/Chute Assembly ............................... 12
Chute Body with 12 Inch Extension ............... 15
Hopper Assembly ........................................... 15
Spreader Controller........................................ 16
MATERIAL SPREADER WARRANTY ...................... 19
OPERATORS MANUAL-PSV-8E (GAS) REVISION
HISTORY .............................................................. 20
Pre-Use Checklist
oRead this entire Owner’s Manual
before attempting to operate or
install the spreader. Consult the
Briggs & Stratton engine Owner’s
Manual as well. NOTE: The Briggs &
Stratton Owner’s Manual can be
found online at the Briggs &
Stratton website. You will need the
model number and type number,
which can be found at the front of
the engine. Refer to Figure 1.
Figure 1.
oTo avoid overloading the sander,
check the recommended maximum
payload for the sander before
loading or operating.
oCheck all CAUTION, WARNING and
DANGER decals on the spreader
before operating. Refer to figures 2-
5.

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
2 | P a g e
Figure 2.
Figure 3.
oCheck the engine crankcase and the
gearbox to make sure that any
lubricants that are being used at
filled to their required levels and
have the right viscosities.
oMake sure the engine cover is
securely fastened to the spreader
before operating.
oVerify that all personnel are clear of
the spreader spray area before
operating.
oMake sure that the spreader is
securely fastened to the vehicle.
Figure 4.
Figure 5.
Vehicle Requirements
¾ or 1 ton pick-up above 8500#
GVWR
CAUTION
Do not overload the vehicle GVWR or
GAWR. Check the vehicles load rating
certification sticker for maximum
vehicle capacity.

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
3 | P a g e
Spreader and Material Weights
Safety
1. Persons who install, mount, operate,
or service this equipment must be
properly instructed and warned.
2. Read operator manuals completely
before operating the equipment.
3. Read all instructional, cautionary,
and warning decals.
4. Check the spreader to ensure that
all shields and gates are in place.
5. Use care when mounting and
dismounting the spreader.
6. Make sure to turn off all power to
the spreader before performing any
repairs, maintenance, or
inspections.
7. Keep all personnel and property
away from the chute/spinner
assembly while the spreader is in
operation.
8. Keep the spreader unit and
components in proper working
condition. Replace any missing or
damaged safety signs.
9. Any unauthorized modifications to
the spreader and related
components may impair its
functions and/or safety.
10. Check to make sure all safety guards
are securely mounted into place
before operating the spreader.
11. Keep all loose clothing, hair, jewelry
and limbs clear of the spreader
before starting or operating the
spreader.
12. Do not adjust, clean, oil or unclog
material jams without first turning
off the spreader, removing the
engine spark plug and control panel
fuse.
13. Do not climb on or in the spreader
during operation.
14. Do not ride the spreader while in
operation.
15. Do not attempt to operate the
spreader when it is in need of
maintenance or repair.
MATERIAL WEIGHT (POUNDS PER CUBIC YARD)
PSV-8E 650 lbs.
#1 Rock Salt 950 lbs.
#2 Rock Salt 1,215 lbs.
Coarse Sand-Dry 2,565 lbs.
Coarse Sand- Wet 3,240 lbs.
WARNING
Observe the following Safety Precautions
before, during and after operating the
spreader. By following these precautions
and common sense, possible injury to
persons and potential damage to this may
be avoided.

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
4 | P a g e
Installation Instructions
Mounting the Spreader onto the
Vehicle
1. Install the inverted “V” in the
spreader using the bolts, nuts, and
washers provided. See Figure 6.
2. Remove the tailgate from the
vehicle.
3. Lift the spreader by attaching the
lifting device to the slot on the
passenger side of the rear inside
brace.
4. Place the spreader on top of two
pieces of lumber so that the lumber
rests under the side gussets as
shown in Figure 7. NOTE: This will
help to remove any excess material
that accumulates under the
spreader.
5. Lift the spreader and place it in the
back of the vehicle so that it is
centered to the vehicle and the rails
of the spreader are 14” from the
rear of the truck.
6. Bolt the spreader to the vehicle
frame through side gussets and the
lumber.
7. Tie the spreader to the vehicle from
the tie-down eyes to the vehicles
anchor points.
Bill of Materials
Figure 6.
Figure 7.
CAUTION
Check the rated maximum payload of
the lifting device before lifting the
spreader.

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
5 | P a g e
Things to Know after Mounting the
Spreader
A. The tie-down straps are provided for
the purpose of securing the
spreader to the vehicle only and are
not to be used for any other
purpose. It is imperative that the
spreader be tied to the vehicle at all
times.
B. Be sure to verify with vehicles
manufacturer that the factory
installed anchor points are designed
for this application.
C. Periodically check to see if the
spreader mounting hardware is
securely tightened.
Mounting the Spinner/Chute
Assembly
1. Attach the Spinner/Chute Assembly
to the spreader using the four 3/8-
16 X 5/8” hex head bolts, lock
washers and nuts provided. Attach
the bolts so that the bolt head is
inside the chute assembly. Refer to
Figures 8-9. NOTE: Attach the bolts
loosely at this time.
2. Install the roller chain between the
sprocket mounted to the
Spinner/Chute Assembly and the
Gearbox Sprocket. Make sure both
sprockets are in-line with one
another. Tighten the gearbox
sprocket set screw. Install the roller
chain master link. See Figure 10.
Figure 8.
Figure 9.
Figure 10.

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
6 | P a g e
3. Adjust the tension of the roller chain
by loosening the Pillow Block
Bearings that are supporting the
Spinner Shaft and moving the shaft
either towards or away from the
Gearbox Sprocket. The correct chain
tension should allow a 5/16”
deflection in the chain midway
between both chain sprockets. See
Figures 11-12. NOTE: Be sure to
maintain the vertical alignment
between the Spinner Shaft and the
bearings before re-tightening the
hardware.
4. Install the chain guard using the
three ¼-20 X ¾” hex head bolts, lock
washers, and nuts.
5. Torque the 3/8-16x1-1/4” Pillow
Block Bolts to 236 Inch-Pounds (20
Foot-Pounds).
Figure 11.
Figure 12.
CAUTION
Do not over-tighten the chain
tension. This can cause damage to
the chain, shaft, bearings and
Gearbox.
Pillow Block Bolts

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
7 | P a g e
Figure 13.
Spreader Operation
NOTE: Before Starting the engine, follow
all safety precautions.
Control Panel Description
1. The “Spinner”switch is a three
position switch with the following
functions:
a. OFF Position: While the switch is
in this position and the engine is
running, the spreader feed chain
and the spinner disk will remain
non-operational.
b. ON Position: While the switch is
in this position and the engine is
running, the spreader feed chain
and the spinner disk will
dispense the ice control material
at the normal regulated rate.
c. BLAST Position: While the switch
is in this position and the engine
is running, the spreader feed
chain and the spinner disk will
dispense the ice control material
at a higher rate. NOTE: In order
to use this option, the switch
must be held in this position. It
cannot be toggled like the “ON”
or “OFF” options.
2. The “Start”switch is a three position
switch with the following functions:
a. OFF Position: While in this
position, 12 VDC power is shut
off to the spreader.
b. ON Position: While in this
position, 12 VDC power is turned
on to the spreader.
c. START Position: While in this
position, the engine speed will
increase.
3. The “Choke” switch is a two position
switch with the following functions:
a. CHOKE/FAST Position: While in
this position, the engine speed
will increase to help start the
engine.
b. IDLE Position: While in this
position, the engine speed will
decrease to release the choke.
CHOKE/FAST
IDLE

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
8 | P a g e
Wire Harness Installation
Figure 14.
1. The Hot Wire (RED) can be
connected to either the fuse box or
directly to the battery.
2. The White Wire must be ground to
the chassis.
Figure 15.
3. Connect the Female Connector to
the Male Connector near the engine.
Starting the Engine
1. Verify that the Spinner switch and
the Start switch on the spreader
control unit are in the OFF position.
2. Now turn the Start switch to the ON
position.
3. Move the Choke switch to the IDLE
position and hold for approximately
two seconds.
4. Turn the Start switch to the START
position and hold.
5. While the engine is cranking, move
the throttle switch to the
CHOKE/FAST position.
6. Release the Choke switch when the
engine starts to fire.
7. Release the Start switch when the
engine turns over.
8. Now move the Choke switch to the
IDLE position for ½ to 1 second to
release the choke.
Stopping the Engine
1. To stop the engine, simply move the
Start switch to the off position.
Spinner Operation
1. Start the engine and adjust the
speed to slightly above IDLE.
2. Move the Spinner switch to the on
position.
3. Increase the engine RPM by moving
the Choke Switch towards the
CHOKE/FAST position.
4. It is recommended that the clutch
only be engaged at the lowest
possible speed without stopping the
engine. This will prevent premature
spinner chain failure and tension
loss.

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
9 | P a g e
Spinner/Chute Assembly
Operation
1. The spread pattern and the amount
of material dispensed depends on
the following:
a. Engine RPM
b. Feed Gate Position
c. Baffle Settings
2. Keep the following information in
mind:
a. Decreasing the RPM’s will
decrease the amount of material
transporting to the spinner.
b. Increasing the engine RPM’s will
increase the amount of material
transporting to the spinner.
c. The size of the feed gate opening
will determine the amount of
material transporting to the
spinner in relation to the
position of the gate.
Precautions
1. If the feed chain does not move
because of dense material or jams,
remove all material from the hopper
and free the chain.
2. If the material in the hopper freezes,
move the spreader into a warm area
to thaw.
3. To prevent the feed chain from
freezing, do not store the material in
the spreader.
4. The gearbox is designed to only
accept torque from the input shaft.
CAUTION
Always follow the spreader
precautions in order to limit any
damage done to the spreader
CAUTION
DO NOT ATTEMPT TO FREE THE FEED
CHAIN BY USING A PIPE WRENCH OR
SIMILAR TOOL TO MOVE OR
DISLODGE THE CHAIN.
IF THE FEED CHAIN IS MOVED, THE
GEARS WITHIN THE GEAR CASE WILL
STRIP. THIS ACTION WILL VOID THE
WARRANTY.

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
10 | P a g e
Spreader Maintenance
1. Use dielectric grease on all electrical
connections before an electrical
connection is made or after a
connector is disconnected.
2. Grease the following:
a. Idler Shaft Bushings (2)
b. Drive Shaft Bushings (2)
c. Spinner Shaft Bushings (2)
d. Flanged Bearing located
between gearbox and clutch
e. Gearbox Input Shaft Bearing.
NOTE: Do not over grease. Can
cause seal damage.
3. Fill the gear case to the oil level plug
with SAE 90 gear-type lubricant.
Routinely check and maintain level.
4. Fill the engine crankcase with the
recommended oil until it reaches
the fill line. Refer to the Briggs &
Stratton owner’s manual for the
recommended viscosity. Routinely
check and maintain level.
5. Maintain the correct tension on the
following chains:
a. Feed Chain Tension-Check to
make sure that the distance
between the end rail and the
point of contact between the
chain and the lower flange of the
rail is 26” to 30”. Refer to Figure
16. Turn the screws shown in
Figures 17 and 18 to adjust the
chain tension as needed.
Figure 16.
Figure 17.
Figure 18.

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
11 | P a g e
b. Engine to Gearbox Drive Chain-
Maintain proper tension on the
Drive Chain by checking to see if
the deflection at the mid-point
between the two sprockets is
5/16”. Loosen the four 3/8” – 16
X 1” carriage bolts and slide the
engine mount stand. Then
torque the bolts back to 236
Inch-Pounds (20 Foot-Pounds).
See Figures 19 and 20.
Figure 19.
Figure 20.
c. Gearbox to Spinner Shaft Drive
Chain-Correct tension for the
Drive Chain is also a 5/16”
deflection at the mid-point
between the two sprockets.
Adjust the chain by loosening
the Pillow Block Bolts as was
shown in Figures 11 and 12 and
slide the pillow blocks in the
desired direction.
6. Empty the spreader of all snow
control material when not in use to
prevent a frozen feed chain.
7. Wash out the spreader when it is
not in use and at the end of the
season to remove all snow control
materials. Thoroughly dry all metal
surfaces. Paint and oil all bare
carbon steel surfaces to help protect
against rust build-up. Properly store
spreader during the off-seasons.
8. Use the following procedures to
help minimize the possibility of
damage and extend the life of the
electric clutch:
a. At the end of the season,
remove and clean the clutch.
b. After cleaning, coat both of the
mating surfaces with oil or light
grease.
c. Remove oil and grease prior to
using clutch again.
9. Maintain the engine according to
the Briggs & Stratton owner’s
manual that has been provided with
the spreader. The engine warranty
is covered by Briggs & Stratton. If
service is required, contact an
authorized Briggs & Stratton Service
Center.

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
12 | P a g e
Part List
Spinner/Chute Assembly

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
13 | P a g e

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
14 | P a g e
19
18
12
23
25
24
21

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
15 | P a g e
Chute Body with 12 Inch Extension
Hopper Assembly

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
16 | P a g e
Spreader Controller
Cab Control
Box w/ Wire
Harness
(40149) Qty. 1

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
17 | P a g e
Brown RVI
Wire (07141)
Qty. 1
Green RVI
Wire (07138)
Qty. 1
Black RVI
Wire (07139)
Qty. 1
Red RVI Wire
(07136) Qty.
1
Yellow RVI
Wire (07140)
Qty. 1
White RVI
Wire (07137)
Qty. 1

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
18 | P a g e
Spreader Side
Wiring Harness
(40044) Qty. 1
Terminal
Connector Male
(07149) Qty. 6
Terminal
Connector Female
(07148) Qty. 6
Terminal
Connector Male
(07151) Qty. 1
Terminal
Connector Female
(07150) Qty. 1

OPERATORS MANUAL –PSV-8E (GAS) AIR FLO MANUFACTURING., CO INC.
19 | P a g e
MATERIAL SPREADER WARRANTY
AIR-FLO MANUFACTURING CO., INC., hereinafter referred to as “Manufacturer”, warrants each
new material spreader sold by the manufacturer to be free from defects in material and
workmanship, under normal use and service, for a period of One (1) year after the date of
delivery to the original retail purchaser, and Manufacturer will, at its option, replace or repair,
at one of the Manufacturer’s Dealers, or at a point designated by the Manufacturer, any part or
parts which shall appear to the satisfaction of the Manufacturer upon inspection at such point,
to have been defective in material or workmanship. This warranty does not obligate the
Manufacturer to bear any transportation charges in connection with the replacement or repair
of defective parts.
This warranty shall not apply to any spreader which shall have been installed or operated in a
manner not recommended by the Manufacturer; not to any spreader which shall have been
repaired, altered, neglected, or used in any way which, in the Manufacturers opinion, adversely
affects its performance; nor to any spreader in which parts not manufactured by the
Manufacturer, or supplied by the Manufacturer or by one of the Manufacturers distributors or
service centers, have been used; nor any accessories installed on the spreader where the
accessory manufacturer has its own warranty; nor to normal maintenance services or
replacement of normal service items.
Manufacturer reserves the right to modify, alter, and improve any spreader or parts without
obligation to replace any spreader or parts previously sold with such modified, altered, or
improved spreader or part.
THIS WARRANTY, AND THE MANUFACTURER’S OBLIGATION HEREUNDER, IS IN LIEU OF ALL
OTHER WARRANTIES, EXPRESS IMPLIED, OR STATUTORY, INCLUDING ANY WARRANTIES OF
MERCHANTABILITY OR OF FITNESS FOR A PARTICULAR PURPOSE, and all other obligations or
liabilities, including special or consequential damages or contingent liabilities arising out of
failure of any spreader or part to operate properly. No person is authorized to give any other
warranty or to assume any additional obligation on the Manufacturer’s behalf unless made in
writing and signed by the Manufacturer.
