Sam TANDEM-AXLE Technical reference manual

P1
Computer Control
(400 & 800mm wide floor-belts)
All models from 2020
INSTRUCTION AND
PARTS MANUAL
www.sammachinery.co.nzPh 07 847 8492 or 0508 726 726
Strong. Simple. Smart.
8 TONNE TANDEM-AXLE COMBO (800mm wide belt)
6 TONNE TANDEM-AXLE (400mm wide belt)

P2
THANKS FOR CHOOSING A SAM
This Instruction and Parts Manual covers all Computer Control spreaders manufactured since 2020.
For all other SAM Machinery Instruction Manuals please visit www.sammachinery.co.nz
SERIAL NUMBER
All SAM Machinery products are identified with a unique serial number located on the front of the machine
(e.g. ‘20 S 1234’). Please include this number with all parts and servicing enquiries so we can provide you with fast
and accurate assistance.
INTRODUCTION
Coombridge & Alexander have created SAM Spreaders from over 70 years’ experience making
agricultural machinery in New Zealand. SAM’s set the benchmark for Spreaders in New Zealand.
Strong, simple and smart, each machine is handcraed from the very best materials and componentry
we can find. They are known for their practical design and easy to use operation.
A family-owned and operated company, located in the heart of the Waikato, Coombridge & Alexander control
the complete manufacturing process of the iconic SAM range: Fertiliser Spreaders, Combo Spreaders,
Orchard Spreaders, Feed Wagons, Hydraulic Trailers and Quick Hitches.
We stand by the quality of all of our products - our team have put the hard work in so you can expect a long working
life out of your gear. All the best with your new SAM. We trust you will love it.
For all parts, servicing or support enquiries please contact us on 07 847 8492.
For international parts and servicing please contact 0064 7 847 8492.
www.sammachinery.co.nz
MODEL DETAILS
MODEL
Proudly NZ-made since 1946
Serial Number:
Call + 64 7 847 8492 | 0508 726 726
Visit www.sammachinery.co.nz
Email [email protected]o.nz
HQ Maeroa Road, Hamilton, New Zealand
20 S 1234

P3
QUALITY GUARANTEE
SAM Machinery products are guaranteed against any defects in either material or manufacture for a period of 24
months from delivery date, provided that the equipment is properly maintained and has not been subject to abuse
or misuse, operated incorrectly, over loaded or used for purposes other than for which the equipment is designed or
is not maintained correctly or if fitted with other than genuine parts.
Claims are only valid when approved by the manufacturer. No person or agent is authorised to assume any
liability.
As the use of the equipment is outside our control we can only guarantee quality. No liability for loss, direct
expenses incurred from the use of this equipment or from any other cause of in respect of performance etc.
can be accepted.
Defective parts must be returned freight paid to the manufacturer or available to be inspected as directed.
Should such parts prove to the manufacturers satisfaction to be faulty - repair of - replacement of defective parts
shall constitute fulfillment of guarantee obligations. Parts destroyed, lost or tampered with nullify guarantee.
WARRANTY
SAM Machinery products as designed and supplied by Coombridge & Alexander Ltd are warranted against faulty
workmanship and defective materials for a period of 24 months from date of purchase. Such warranty is subject to
the following conditions:
1. That the basic maintenance (as noted in p5) is followed.
2. This warranty covers the repair or replacement of parts or machinery sold by Coombridge &
Alexander Ltd and damaged as a result of faulty workmanship of materials in such part of machinery.
It does not extend to any other loss or damage including consequential loss or damage to other
property or persons, or damage through poor maintenance.
3. No responsibility will be accepted for repairs made other than by Coombridge & Alexander Ltd or its
accredited agent and without prior authorisation by Coombridge & Alexander Ltd.
Without limiting the generality of paragraph 2. above, this warranty does not cover the following;
a. Losses sustained through delay in delivery
b. Travel expenses
c. Damage caused by accident, misuse or abuse
4. Damage to any goods which have been altered or modified by someone other than Coombridge &
Alexander Ltd or its authorised dealers.
5. Procedure for recovery under warranty;
1. No loss or damage will be covered under warranty unless the following procedure is followed by
the purchaser.
1. If the purchaser is an authorised dealer -
a. Coombridge & Alexander Ltd must first be advised of details of the goods
concerned, the loss or damage sustained and the circumstances in which the loss
or damage arose.
b. Coombridge & Alexander Ltd will then decide if such loss or damage is within the
terms of warranty and shall advise the dealer as to how the loss or damage
is to be repaired.
2. If the purchase is not an authorised dealer -
a. The loss or damage should be reported directly to Coombridge & Alexander Ltd
who will advise whether it is covered by the warranty and direct the purchaser
accordingly as to what action is to be taken.

P4
BASIC SAFETY
Many agricultural machines have potentially dangerous moving parts, which can cause serious or fatal
injuries. Remember;
1. Read ALL warning labels on the machine and ensure you understand operating instructions
2. Turn o the tractor before removing any guards, blockages or servicing the machine
3. Never use your hands or fingers to check for hydraulic oil leaks
4. Keep at least 15 metres distance from the spinner discs when operating
5. Do not use the machine in steep areas where there is a high-risk of roll-over occurring.
OPERATIONAL CHECK
Before you start work with a machine there are a few basic checks that can be carried out. Ask yourself:
1. Is the machine you intend to use suitable for the job e.g. in good working order and safe to use?
2. Are all safety devices such as guards in place and working correctly?
3. Are there any known mechanical defects – pay particular attention to items such as wheels and tyres, and
moving parts?
4. Are you (or the operator) properly trained to do this job/use this machine?
5. Has the instruction manual for the machine been provided, read and understood?
6. Is the right personal protective equipment (PPE) available and worn?
7. Has a risk assessment been carried out?
8. Has the work been properly planned and communicated to those who may be at risk?
9. Is the machine operator competent to do the job safely?
10. Hitching and attachment points for trailed machinery - check that it has been safely attached to the
towing vehicle such as a tractor. Pay attention to the condition of drawbar/pick-up hitch, and hitch rings,
pins, clips etc.
11. Carry out any pre-use checks as specified.
HEALTH & SAFETY RISK ASSESSMENT
A hazard identification, assessment and control procedure has been conducted on a representative
SAM Spreader and where necessary appropriate risk control measures have been outlined below;
HAZARD HARM CONTROLS
Contact, impact or entanglement
from moving parts/ loose objects
inc. gears, chains, sprockets, spinner
shas and discs, and wheels.
1. Deep cuts or amputation
2. Bruising
3. Fractures
Avoid wearing loose clothing,
jewellery or gloves - they increase
the risk of entanglement.
Stand a safe distance from the
machine when under operation.
Leaking hydraulic hoses and/or
couplings.
1. Leaking oil may get into skin
2. Skin and eye irritation
3. Breathing diiculties
Apply a programme of preventive
maintenance (hydraulic hoses and
hydraulic hose couplings).
Leaking oil, or bulging or abraded
hose walls, must have faulty parts
replaced.
Never use hands or fingers to
detect leaks.
Wear appropriate PPE
(personal protective equipment).
Tractor and/or Fertiliser Spreader
roll-over due to instability under
varying conditions and terrain.
1. Serious injury
2. Fatality
Do not use the machine in steep
areas, or on unstable ground.

P5
BASIC MAINTENANCE
To keep your SAM Spreader in excellent working condition, please follow these basic maintenance
procedures as you go.
1. Keep your machine fairly clean and very well greased.
2. Before each use; check the hydraulic system for signs of oil leaks or wear. Check there is no play in the spinner
bearings by liing up on the spinner discs. Tension the spinner bearings by tightening the large nyloc nut at
the top of the spinner sha (this can be adjusted by undoing the grub screws).
3. Aer every five hours of operation grease all nipples on the front and back floor shas, and the four spinner
sha bearings should be well greased.
4. Aer every ten hours of operation check all bolts are tight, including the wheel nuts, joiners and
spinner discs and vanes. Check all nipples and grease points on the front floor adjusters slides,
drawbar jack, clutch pivot bearings, back door jack, hubs and tandem axle pivot points.
5. The floor-belt should be tensioned with a 40mm sag below the middle of the chassis, with an even curve/sag
from front to back. Adjust when necessary.
6. All roller chains should be kept well oiled, particularly during long periods of storage.
7. Check the couplings above the spinner tubes stay approximately 2mm between the top and bottom halves.
8. Keep conveyor greased and belt tracking in the centre of the rollers (by adjusting at the non-drive end).
9. Check your linkage/tow pins.
10. Always ensure tractor oils are kept in excellent condition. Beware when changing a Spreader between
dierent tractors. Pump oil out of the hoses unless they use the same hydraulic oil.
11. If you have load cells, please make sure the bolts are regularly tightened.
12. Avoid high pressure hosing/waterblasting around your load cells, sensors and monitor.
13. Do not weld on this machine. Welding will destroy load cells and computer.
Please keep these checks up for the lifetime of your SAM.

P6
SET-UP AND OPERATION
BEFORE STARTING WORK please read the following application and set-up instructions
to ensure safe and productive operation.
HYDRAULICS (TRACTOR OIL FLOW REQUIREMENTS)
For the Spreader to operate at its maximum rates, a tractor hydraulic flow of approximately 90 Litres per minute
is required. Standard SAM Computer Controlled Spreaders are fitted with two OMP50 hydraulic motors running
in series, requiring an external oil flow of a max of 50 litres/minute. The floor drive requires approximately 40
Litres to rotate at its maximum speed.
It is very important that you adjust the hydraulic oil flow from the tractor as above. Note, the higher the
bypass oil flow, the higher the pressure in the e-Spreader’s hydraulic system.
COUPLING THE HYDRAULICS
The live hose (red) must be coupled to a high pressure outlet point on the tractor’s external hydraulic system.
This take o point can be fitted to an existing double acting valve already fitted for farm machinery, or a new
fitting can be installed.
The return hose (yellow) can be coupled into the same double acting bank or a free flow dump return using the
quick release coupling supplied.
HYDRAULIC OPERATION
The hydraulic spinners and valve control must be coupled to the tractors hydraulic system to ensure safe
operation. If you are unsure of set up please contact your local dealership or Coombridge & Alexander directly.
Always ensure tractor oils are kept in excellent condition. Beware when changing an Spreader
between dierent tractors. Pump oil out of the hoses unless they use the same hydraulic oil.
SPREADING CENTRES
We recommend spreading at 15 metre centres for granulated fertiliser products and 10 metre centres for powered or
fine granulated products such as Lime. You can choose any spread width in the set-up mode.
MESH SCREEN
We recommend removing the mesh screen from inside the polyethelene bin when spreading lime.

P7
CONFIGURE TO YOUR TRACTOR
1. The Spreader’s spinners are adjustable from the valve block at the back of the machine (see the drawing
below).
Wind the knob on the valve block anti-clockwise until the spinner speed in the grey box is at
850rpm. Then tighten the lock ring.
TOPCON
For all TOPCON set up instructions - see the TOPCON manual provided.
SPINNERS

P8
BULK DENSITY
TO MEASURE BULK DENSITY OF PRODUCT BEING SPREAD
This quick process is very important for spread accuracy.
1. Turn on the scales. Put the empty scoop on the scales. Then zero the scale (by pressing the TARE button).
2. Take scoop o the scales and fill to the top. Product must be level with the top.
3. Put the scoop and product back on the scales and weigh it.
782 grams = a density of 782 kilograms per cubic metre.
Note: You can take multiple samples and average them to double-check your accuracy.

P9
12345678
10
9
11
12
SPARE-PARTS FOR COMPUTER CONTROLLED SPREADER
MACHINE SIDE-VIEW - For 4, 5, 6 Tonne Computer Controlled Spreaders - Both 400 & 800 wide belts
REFERENCE PART NUMBER DESCRIPTION QTY.
1*
3103 Wheel & Tyre - 11.5/80 x 15.3 (12ply)
2-43107 Wheel & Tyre - 400/60 X 15.5 (TR Tread)
3948 Wheel & Tyre - 550/60 x 22.5 (16ply)
2 5967 Gear Box 1
3 P4769 Mudguard 2
4 P4697A Floor Tension Adjusters 2
5 P3022 Front Sha (Complete) 1.5” - (inc. Sprockets + Spacer Ring)
For all 400 wide belt
1
P4826 Front Sha (Complete) 1.5”
For 800 wide belt - 5 & 6 Tonne
1
6 P221 Deadeye Bearing 1.5” 2
7 6535 Front Bin Skirt Rubber
For 800 wide belt
1
3526 Front Bin Skirt Rubber
For 400 wide belt
1
8 1609 Serial Number Plate 1
9 7500 Hose Kit - D200
For 400 wide belt
1
7501 Hose Kit -
For 800 wide belt - 5 & 6 tonne
1
10 P1402 Jack Stand (70sq) - DG701 1
11*
P3145D Fixed Tow Hitch (16mm Mounting Plate) - 50mm Donut Eye
1
P3145 Fixed Tow Hitch (16mm Mounting Plate) - 37mm Ball Eye
P3557B Swivel Tow Hitch (16mm Mounting Plate) - 37mm Ball Eye
P3557 Swivel Tow Hitch (16mm Mounting Plate) - 50mm Ball Eye
12* - Hub & Stub - 70sq 2-4
13 5924 Load cells 8
* Wheel & Tyre, Tow Hitch and Hub & Stub set-up varies depending on machine model, size and year of manufacture.
NB: the image above is showing a 6 Tonne SAM Spreader with Computer Control and a 400mm wide-belt.
13

P10
12345678
10
9
11
12
PARTS MANUAL - SAM 8T & 9T COMBO SPREADER
MACHINE SIDE-VIEW - For 8 & 9 Tonne Computer Controlled Spreaders - Both 400 & 800 wide belts
REFERENCE PART NUMBER DESCRIPTION QTY.
1 3869 Wheel & Tyre - 500/60 x 22.5 (16ply) 4
2 7815 Gearbox 1
3 5924 Load cells 8
4 P4697 Belt & Floor Chain Tension Adjusters 2
5 P4984 Front Sha (Complete) 1.5” - (inc. Sprockets + Spacer Ring) 1
6 4024 Bearing & Housing - Pillow-Block 50mm (P210) 2
7 6535 Front Bin Skirt Rubber 1
8 1609 Serial Number Plate 1
9 4086 Hose Kit - D208 1
10 P1402 Jack Stand (70sq) - DG701 1
11 P2102 Swivel Tow Hitch (20mm Mounting Plate) - Ball/No Ball
12* - Hub & Stub - 80sq 2-4
P4859 Mudguards 2
* Wheel & Tyre, Tow Hitch and Hub & Stub set-up varies depending on machine model, size and year of manfacture.
Please include the machine serial number with all parts and servicing enquiries.
NB: the image below is a 9 Tonne SAM Combo Spreader with Computer Control and an 800 wide floor belt.

P11
1
2
5
4
3
6
7
9
8
10
11
12
13
SPARE-PARTS FOR COMPUTER CONTROLLED SPREADER
MACHINE REAR-VIEW - For 4, 5, 6 Tonne Computer Controlled Spreaders - Both 400 & 800 wide belts
REFERENCE PART NUMBER DESCRIPTION QTY.
1 P5077 Danfoss OMP50/9 Hydraulic Motor 2
2* P3040 Skirt Pressing (S/S) - (inc. Rubber + Rivets)
specify le/right
2
P4686 Skirt Rubber & Rivet Set - x2 (2.77 x 80mm) + 34 Rivets 1
3* P3067 Floor-belt and Chain (Complete)
for 4, 5, 6 Tonne 800 wide belt
1
P0391 Floor-belt and Chain (Complete)
for 4, 5, 6 Tonne 400 wide belt
1
4 P4882 Spinner Tube Mounting Frame
for 800 wide belt
1
P202 Spinner Tube Mounting Frame
for 400 wide belt
1
5 P4857 Deflector + Divider S/S Panel (Complete) 1
6 P2809 Back Door Jack
for 400 wide belt
1
P2101 Back Door Jack
for 800 wide belt
1
7 7311 Hydraulic Sensor Valve HCV 3749-1 1
8 0440 Flexi Coupling CA90 - 25mm/1” (with rubber insert) 2
9 3424 UNF Nyloc Nut 1 1/4” & Grubscrew 3/8” 2
10 P4695 Mollybush Bearing and Housing
Check the length - long or short
2
11 P4683 Back Sha - 50mm (Complete inc. 5T Sprockets)
for 800 wide belt
1
P4664 Back Sha - 50mm (Complete inc. 5T Sprockets)
for 400 wide belt
1
12 P20H Spinner Tube - Complete
for 800 wide belt
2
P20C Spinner Tube - Complete
for 400 wide belt
2
13 P2103 Spinner Vanes - Set 5CR12 Vanes 1
* Parts vary depending on machine model, size and year of manufacture. include your serial number with parts enquiries.

P12
MACHINE REAR-VIEW - For 8 & 9 Tonne Computer Controlled Spreaders - Both 400 & 800 wide belts
REFERENCE PART NUMBER DESCRIPTION QTY.
1 P4751 Danfoss OMP50/9 Hydraulic Motor 2
2P4666 Skirt Pressing (S/S) - (inc. Rubber + Rivets)
Specify le/right
2
P4709 Skirt Rubber & Rivet Set - x2 (4.0 x 80mm) + 34 Rivets 2
3 P3068 Floor-belt and Chain (Complete)
for 8 or 9 Tone Combo
1
4 P4882 Spinner Tube Mounting Frame 1
5 P4857 Deflector + Divider S/S Panel (Complete) 1
6 P2101 Back Door Jack
for 800 wide belt
1
7 7311 Hydraulic Flow Control Valve - HCV 3749-1 1
8 P440 Flexi Coupling CA90 - 25mm/1” 2
9 3424 UNF Nyloc Nut 1 1/4” & Grubscrew 3/8” 2
10 4024 Bearing & Housing - Pillow-Block 50mm (P210) 2
11 P4835 Back Sha - 50mm (Complete inc. 5T Sprockets) 1
12 P20G Spinner Tube - Complete 1
13 P4684 Spinner Vanes - Set 5CR12 Vanes + Welded Bis Inserts 1
* Floor-Belt and Chain, Skirt Pressings, Couplings and Back/Front Shas vary depending on machine model, size and year
of manufacture. Please include the machine serial number with all parts and servicing enquiries.
1
2
5
4
3
6
7
9
8
10
11
12
13
NB: the image above is an 8 Tonne SAM Combo Spreader with an 800 wide floor belt.

P13
HUB MAKE / MODEL HUB SIZE BEARINGS SEAL HUB CAP
ADR Mk7 70sq 30213/32210 100 x 120 x 8 Screw on
ADR Mk7 80SQ 32215/32212 130 X 77 Screw on
BEARINGS / SEALS

P14
The spreading table below is fixed beside the back door of each SAM Fertiliser Spreader.
The required fertiliser application rate can be set by adjusting the back door jack and viewing the spreading table
sticker to achieve the desired rate per hectare - setting the pointers on the back door level with the selected box.
The ‘DOOR HEIGHT’ side scale (1-20cm) represents the opening space (in centimetres) between the floor-belt and
the back door.
SPREADING TABLES

P15

P16
QUESTION / PROBLEM SOLUTION
What is the spreader bin capacity?
4t Fertiliser Spreader = 3.2m3 of fertiliser
4t of Superphosphate (1.3t/m3 density)
5.5t of Lime (1.7t/m3 density)
2.6t of Urea (0.8t/m3 density)
5t Fertiliser Spreader = 3.9m3 of fertiliser
5t of Superphosphate (1.3t/m3 density)
6.6t of Lime (1.7t/m3 density)
3.1t of Urea (0.8t/m3 density)
6t Fertiliser Spreader = 4.6m3 of fertiliser
6t of Superphosphate (1.3t/m3 density)
7.7t of Lime (1.7t/m3 density)
3.7t of Urea (0.8t/m3 density)
What paint treatment does the chassis
receive?
The chassis is firstly sand-blasted, then thermal-arc spray
galvanised, primed, followed by a final two-pot epoxy
top-coat.
Can I get dierent wheel/tyre options? A variety of tyre options are available for each model. Please
contact Coombridge & Alexander directly for more information.
How do I prevent Urea blocking the back
door exit?
A sheet for chicken wire with 1/2”/1.5cm gaps (or similar) can be
fixed to the existing mesh grill inside the spreader bin to prevent
larger clumps of product blocking the back door exit.
If you are experiencing something that is not listed here, please contact Coombridge & Alexander directly or see
your local dealership.
TROUBLESHOOTING

P17
TROUBLESHOOTING
QUESTION / PROBLEM SOLUTION
What hydraulic oil flow is required?
Standard SAM Fertiliser Spreaders are fitted with two OMP50
hydraulic motors running in series, requiring an external oil flow
of 50 litres/minute plus 40 litres for the floor. For a total require-
ment of 90 litres.
What RPM should the spinner sha turn at? The spinner sha should turn at approx 850RPM.
What direction do the spinner discs turn in?
When standing at the back of the machine, the right-hand spinner
disc should turn clockwise and the le-hand spinner disc
anti-clockwise.
How do I prevent fertiliser product falling
out the sides and/or front of the spreader bin
(e.g. striping)?
The side-skirts (running the length of the machine, inside the
plastic bin) and front/rear bin scrapers will require regular
adjustment, particularly when the machine is new. Both the
side-skirts and front/rear bin scrapers are bolted (slotted holes)
onto the machine - these bolts can be simply loosened and the
skirt or scraper maneuvered to be flush with the floor-belt.
What tension should be on the floor-belt and
chain assembly?
The floor-belt should be tensioned with a 40mm sag below the
middle of the chassis, with an even curve/sag from front to back.
What are the minimum and maximum
application rates for various fertiliser
products?
From 45kg/hectare at 15m spreading centres for Urea (and similar
products), and up to 3,000kg/hectare at 10m spreading centres
for Lime.
How accurate is the spread pattern?
Representative machines have been tested using the
nationally recognised Spreadmark test for accuracy. Spread
patterns are rated using Coeicient of Variation (CV), a
measure of the percentage of fertiliser outside a perfect spread -
0% being a perfect spread pattern.
New Zealand standards recognise a CV under 15% as acceptable
for nitrogenous fertilisers (DAP, Urea, Nitroposka Blue etc.). SAM
Fertiliser Spreaders have achieved a 7.1% CV for Urea and 8.1% CV
for Superphosphate - well within industry standards.

P18
Need help fast?
Our SAM range is backed by a fast and comprehensive spare-parts support service from our Hamilton
location. Our team is also available for diagnostic support, as well as technical and sales information.
Call 07 847 8492
Freephone 0508 726 726
info@sammachinery.co.nz
www.sammachinery.co.nz
Follow or like us to keep up with our latest
facebook/@newsfromSAM
instagram/@sammachinery
Or call in to see us at our manufacturing facility
SAM HQ
256 Maeroa Road, Hamilton 3204
New Zealand
This manual suits for next models
1
Table of contents
Other Sam Spreader manuals
Popular Spreader manuals by other brands

New Leader
New Leader L4000G4 manual

Enerpac
Enerpac FSM8 instruction sheet

Vogal
Vogal SPREADMAX TPL750 Operation Maintenance & Parts Manual

Boss Snowplow
Boss Snowplow SNR24030 owner's manual

Broadwood
Broadwood Wessex Country FS170T Operations manual and parts book

agromaster
agromaster BAF Series OPERATOR'S MANUAL AND SPARE PARTS
