ABM-200
Class1 Bluetooth Module
Production Information Data Sheet
ID : ABM-200-1XXX
May.2004
Rev 2.0
1. Module Features
-Bluetooth™ V1.1 Compliant
-Transmit Power +20dBm(Class1)
-2.7V to3.6VOperation
-Full Bluetooth data rate over UART
and USB
-Four low power modes : Park, Sniff,
Hold and Deep Sleep
-Support for up to seven slaves
2. General Description
ABM-200-1XXX is a Class1 surface
mountable Bluetooth™ Module for
Notebook PC, Desktop PC, Access Point,
Serial Adapter applications.
It provides fully compliant Bluetooth system
for data and voice communications. Physical
interface to host (UART, USB) can support
full Bluetooth data rate 723.2k/57.6kbps.
A-Law, u-Law,13bit or 16bit linear PCM,
8k sample/sec synchronous bidirectional
audio interface is also available.
4. Features
-Size(28.2 X 15 X 2.8mm)
-Class1 Support(+20dBm)
-Surface Mountable
-Dual Power Supply
-Support PCM interface for SCO
5. Specification
-Operating Conditions
Supply Voltage……. VDD: 2.7V~3.6V
Temperature Range….…..… -20~+70°C
-Radio Characteristics
Receiver Sensitivity … -88dBm
Transmitter Power ….. +16.0dBm(Typical)
3. Application
-Laptop and Desktop PCs
-Access point
-Serial Adapter
-Personal Digital Assistants (PDAs)
-Domestic and Industrial Applications
BlueCore2-EXT
SPI
UART
USB
PCM
PIO
4M or 8M
Flash
Memory
Regulator
X-Tal
16MHz
I
N
T
E
R
F
A
C
E
TX _ A
TX _ B
BPF
Balun
VDD
VDD1.8V
Loop
Filter
ANTENNA
Power AMP
LNA
Switch
RX _ IN
PVCC

Bluetooth™ Module Application Note
Copyright © 2004 AirLogic Co., Ltd.
All specification are preliminary and AirLogic reserves the right to change these without notice.
http://www.airlogic.co.kr
6. Electrical Characteristics
Absolute Maximum Ratings
Parameter Min Max Unit
Storage Temperature -40 +85
°C
Supply Voltage(VDD) 2.7 3.6 DCV
Supply Voltage(PVCC) 3.0 3.0 DCV
Other Pin Voltage Vss-0.4 VDD+0.4 DCV
Recommended Operating Conditions
Parameter Min Max Unit
Temperature -20 +70
°C
Supply Voltage for UART 3.0 3.6 DCV
Supply Voltage USB 3.1 3.6 DCV
7. RF Specification
Transmitter Performance
Parameter Condition Min Typ Max Unit
Output Power Normal/extreme test - 16 20 dBm
Power Density Normal/extreme test - - 20 dBm
Power Control Normal/extreme test 2dB ≤Step size ≤8dB
Frequency Range Normal/extreme test 2400 - 2483.5 MHz
20dB Bandwidth Normal/extreme test - 850 1000 KHz
±2MHz - - -20 dBm
±3MHz - - -40 dBm
Adjacent channel power
±4MHz - - -40 dBm
∆F1avg 140 - 175 KHz
∆F2max 115 - - KHz
Modulation Characteristics
∆F2avg /∆F1avg - - 80 %
Initial Carrier Frequency Tolerance -75 - 75 KHz
One slot packet(DH1) -25 - 25 KHz
Three slot packet(DH3) -40 - 40 KHz
Carrier Frequency Drift
five slot packet(DH5) -40 - 40 KHz
Transceiver Performance
Parameter Condition Min Typ Max Unit
30MHz-1GHz - - -36 dBm
1GHz-12.75GHz - - -30 dBm
1.8GHz-5.3GHz - - -47 dBm
Out-of-Band Spurious Emissions
5.1GHz-5.3GHz - - -47 dBm
Receiver Performance
Parameter Condition Min Typ Max Unit
Sensitivity level Single slot packets -70 -83 - dBm
Sensitivity level Multi slot packets -70 - - dBm
C/I co-channel - - 11 dB
C/I1MHz (Adjacent channel selectivity) - - 0 dB
C/I2MHz (2nd Adjacent channel selectivity) - - -30 dB
C/I performance
C/I≥3MHz (3rd Adjacent channel selectivity) - - -40 dB
30MHz-2000MHz -10 - - dBm
2000MHz-2400MHz -27 - - dBm
2500MHz-3000MHz -27 - - dBm
Blocking performance
3000MHz-12.75MHz -10 - - dBm
Intermodulation
Performance n=5 -39 - - dBm
Maximun Input Level -20 -10 - dBm

Bluetooth™ Module Application Note
Copyright © 2004 AirLogic Co., Ltd.
All specification are preliminary and AirLogic reserves the right to change these without notice.
http://www.airlogic.co.kr
8. Pin Description
Pin No. Pin Name Description
1 GND Common ground
2 PVCC Power Amp Power Supply
3 AIO(0) Programmable I/O terminal
4 AIO(1) Programmable I/O terminal
5 PIO(0) Programmable I/O terminal, RX Enable
6 PIO(1) Programmable I/O terminal, TX Enable
7 PIO(2) Programmable I/O terminal, USB_PULL_UP
8 PIO(3) Programmable I/O terminal, USB_WAKE_UP
9 PIO(4) Programmable I/O terminal, USB_ON
10 PIO(5) Programmable I/O terminal, USB_DETACH
11 PIO(6) Programmable I/O terminal, CLK_REQ
12 PIO(7) Programmable I/O terminal
13 PIO(8) Programmable I/O terminal
14 PIO(9) Programmable I/O terminal
15 RESET_IN Module Reset INPUT
16 VDD Core & Baseband Power Supply
17 GND Common ground
18 GND Common ground
19 USB+ USB Data plus
20 USB- USB Data minus
21 PCM_SYNC Synchronous data strobe
22 PCM_IN Synchronous 8Kss-1 data input
23 PCM_OUT Synchronous 8Kss-1 data output
24 PCM_CLK Synchronous data clock
25 UART_RX UART Data in
26 UART_TX UART Data out
27 UART_RTS UART ready to send
28 UART_CTS UART clear to send
29 SPI_MOSI Serial Peripheral Interface data input
30 SPI_CSB Chip select for Synchronous Serial Interface active low
31 SPI_CLK Serial Peripheral Interface clock
32 SPI_MISO Serial Peripheral Interface data output
33 PIO(11) Programmable I/O terminal
34 PIO(10) Programmable I/O terminal
35 RF-IN_OUT Connect to Antenna
36 GND Common ground

Bluetooth™ Module Application Note
Copyright © 2004 AirLogic Co., Ltd.
All specification are preliminary and AirLogic reserves the right to change these without notice.
http://www.airlogic.co.kr
9. UART Interface
ABM-200-1xxx Universal Asynchronous Receiver and Transmitter(UART) interface provides a
simple mechanism for communicating with other serial device using the RS232 standard.
When ABM-200-1xxx is connected to another digital device, UART_RX and UART_TX
transfer data between the two devices. The remaining two signal, UART_CTS, UART_RTS,
can be used to implement RS232 hardware flow control where both are active low indicators.
All UART connections are implemented using CMOS technology and have signaling levels of
0V and VDD
<UART connected to Host PC>
<UART connected to MCU>
10. USB Interface
ABM-200-1xxx USB devices contain a full speed(12Mbit/s) USB interface that is capable of
driving of a USB cable directly. No external USB transceiver is required. The device operates as
a USB peripheral, responding to requests from a master host controller such as a PC. Both the
OHCI and the UHCI standards are supported. The set of USB endpoints implemented behave as
specification V1.1
As USB is a Master/Slave oriented system(in common with other USB peripherals), ABM-200-
1xxx only supports USB slave operation.
ABM-200-1xxx features an internal USB pull-up resistor. This pulls the USB+ pin weakly high
when ABM-200-1xxx is ready to enumerate. It signal to the PC that it is a full speed(12Mbit/s)
USB device.

Bluetooth™ Module Application Note
Copyright © 2004 AirLogic Co., Ltd.
All specification are preliminary and AirLogic reserves the right to change these without notice.
http://www.airlogic.co.kr
<USB BUS powered Mode connected to Host PC>
11. PCM Interface
Pulse Code Modulation(PCM) is a standard method used to digitize human voice
patterns for transmission over digital communication channels. Through its PCM
interface, ABM-200-1xxx has hardware support for continual transmission reception of
PCM data, thus reducing processor overhead for wireless application. ABM-200-1xxx
offers a bi-directional digital audio interface that routes directly into the baseband layer
of the Module firmware. It does not pass through the HCI protocol layer.
Hardware on ABM-200-1xxx allows the data to be sent to the received from a SCO
connection.
ABM-200-1xxx can be configured as PCM interface Master generating an output clock
of 128, 256, or 512kHz. When configured as PCM interface slave it can operated with
input clock up to 2048kHz. ABM-200-1xxx is compatible with a variety of clock
formats, including Long Frame Sync, Sort Frame and GCI timing environments.
It supports 13-bit or 16-bit liner, 8-bit u-law or A-law companied sample formats at 8k
samples/s and can receive and transmit on any selection of the first four slots following
PCM_SYNC.
<ABM-200-1xxx as PCM Interface Master>

Bluetooth™ Module Application Note
Copyright © 2004 AirLogic Co., Ltd.
All specification are preliminary and AirLogic reserves the right to change these without notice.
http://www.airlogic.co.kr
<ABM-200-1xxx as PCM Interface Slave>
12. RESET
ABM-200-1xxx may be reset from several source : RESET_IN pin, power on reset, a
UART break character or via a software configured watchdog timer.
The RESET_IN pin is an active high reset and is internally filtered using the internal
low frequency clock oscillator. A reset will be performed between 1.5 and 4.0ms
following RESET_IN being active. It is recommended that RESET_IN is applied for a
period greater than 5ms.
<ABM-200-1xxx as Power ON Reset>
<ABM-200-1xxx as Manual Reset>

Bluetooth™ Module Application Note
Copyright © 2004, AirLogic Co., Ltd.
All specification are preliminary and AirLogic reserves the right to change these without notice.
http://www.airlogic.co.kr
Ordering information
1 Class1
Dimension
Unit : mm
4 4Mbit
8 8Mbit
Interface
UA UART
US USB
BC BCSP
1.25 4.0 2.1
15.0
28.2
0.4 0.8
0.8
2.8
1
GND
18
19
GND
36
A B M 2 0 0 1 X X
Flash Memory Size
X
Baud Rate
A 4800
B 9600
C 14400
D 38400
E 57600
F 115200
G 230400
H 460800
I 912600
J 1382400
Top View Top View
Side View
910
27
28
15.0
1.25 4.0
0.8 x 0.8 1.5 X 1.5
PCB Layout (Top View)
GND GND
5.3 x 2.4 5.3 x 2.4
2.1
2.1
Design to Micro Strip Line
GROUND Copper

Bluetooth™ Module Application Note
Copyright © 2004 AirLogic Co., Ltd.
All specification are preliminary and AirLogic reserves the right to change these without notice.
http://www.airlogic.co.kr
15. Record of Changes
Date Revision Reason of Change
May. 2002 1.0 -First Issue
May. 2004 2.0 -Changed Data in Power Amp VCC 3.0V
-Changed Data in Typical Transmit Power 16dBm
- Import Data in UART, USB, PCM interface description
-Corrected Data in Pin Description
-Corrected Data in Dimension
