airnet AIR-AP600GHP User manual

Quick Installaon Guide
300 Mbps AIR-AP600GHP
802.11b/g/n Indoor High Power Access Point
Package Contents:
Airnet Indoor High Power Access Point
Mounng bracket
Power Supply (24VDC)
Detachable antennas
CD-ROM

Warnings
Hardware
Installaon
1
Quick
Installaon
Guide
NETKROM shall not be liable for incidental or consequenal damages resulng from the furnishing, performance, or use of
this manual.
Do not locate the antenna near overhead power lines or other electric light or power circuits, or where it can come into
contact with such circuits. When installing the antenna, take extreme care not to come into contact with such circuits, as they
may cause serious injury or death.
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
To meet regulatory restricons, the radio and the external antenna must be professionally installed. The network
administrator or other IT professional responsible for installing and configuring the unit must be a suitable professional
installer. Following installaon, access to the unit should be password protected by the network administrator to maintain
regulatory compliance.
The AIRNET Indoor High Power Access Point can be damaged by incorrect power applicaon. Read and carefully follow the
installaon instrucons before connecng the system to its power source.
2
High Capacity Wireless Networks www.netkrom.com
300 Mbps AIR-AP600GHP

Package contents
Hardware
Installaon
1
Quick
Installaon
Guide
Take a moment to ensure you have all of the following parts in
your Indoor Unit installaon kit before you begin installing the
product. If any parts are missing, please contact your local
vendor or contact us.
Please see the contact informaon in Secon 6.
3
www.netkrom.com
AIRNET Indoor High Power Access Point
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

Setup Requirements
Before starng, please verify that the following is available:
Hardware
Installaon
1
Quick
Installaon
Guide
CAT5/5e Ethernet cable (from the Indoor AP to switch or PC)
At least one computer is installed with a Web browser and a wired or wireless
network interface adapter
TCP/IP protocol is installed and IP address parameters areproperly
configured on all your network’s nodes
4
www.netkrom.com
Important!
Configure and verify the indoor AP operaons first before you mount the
unit in a remote locaon.
For choosing the best locaon for your Indoor AP choose an elevated locaon
where obstacles will not obstruct the antenna signals and which offers
maximum line-of-sight propagaon with the users.
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

AIRNET Indoor High Power
Access Point Installaon
Step 1:
Hardware
Installaon
1
Quick
Installaon
Guide
Connect the external antennas to the SMA connectors of the access point.
Step 2:
Insert one end of the Ethernet cable to any of the Ethernet ports
on your indoor access point, and the other end of the cable to your
PC’s Ethernet network adapter.
5
www.netkrom.com
Step 3:
Aach the power adapter to the main electrical supply, and connect
the power plug into the socket of the access point.
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

Mounng the Airnet Indoor
High Power Access Point
Step 1:
Hardware
Installaon
1
Quick
Installaon
Guide
Screw the mount onto the unit.
Step 2:
Align the unit and mount to the wall.
Using the mount as a guide, make 2 marks and drill
2 holes into the wall.
6
www.netkrom.com
Step 3:
Screw the mount onto the unit.
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

Using uConfig
uConfig
Ulity2
Quick
Installaon
Guide
7
www.netkrom.com
When you execute the uConfig file you should see a window as it is
shown on the right side. Click yes to connue
The screen is divided into three secons. The top secon shows the
Ethernet adapter that is accessing the network device and the middle
poron shows the roung table associated with the Ethernet adapter.
In the lower window, a list of all uConfig compable devices on the
network is shown.
Highlight the device you desire to configure. Then click on the “Open
web” buon.
uConfig is a feature that provides the ability to directly access the
AIRNET Indoor High Power Access Point without the need to know
absolutely its IP address. It may be run directly from the product CD
or installed on the user’s PC for later access.
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

uConfig
Ulity2
Quick
Installaon
Guide
8
www.netkrom.com
Click the OK buon to connue
At the login prompt, enter the User name and Password. The default
are:
User name: admin
Password: password
Click on OK and start configuring the radio.
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

PC
Configuraon3
Quick
Installaon
Guide
9
www.netkrom.com
If you don’t use the uConfig Ulity you need to establish Ethernet
connecon between your PC and the AIRNET Indoor High Power Access
Point, by default the indoor AP has the IP address 192.168.168.1.
Therefore, your PC must be in the same network segment as the AIRNET
Indoor High Power Access Point is to get Ethernet connecvity. The
steps shown below are for Windows XP.
Step 1:
Go to Start buon, then go to My Network Places and finally click on
Network Connecons.
Right-Click over your network adapter and select Properes.
Step 2:
Select the Internet Protocol Opon and then click in Properes.
Step 3:
Now configure the IP Address of your network adapter with an IP in
the same Network segment as your AIRNET Indoor High Power Access
Point is as it is shown in the picture, you don’t need to assign any
gateway address.
Press OK and then press the Close buon.
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

Common
Configuraons4
Quick
Installaon
Guide
10
www.netkrom.com
Find below typical and basic configuraons using the AIRNET Indoor High
Power Access Point. For advanced features please refer to the user manual.
Geng Started
You can start configuring your AIRNET Indoor High Power Access Point
using either your Web Browser or the uConfig ulity.
At the Address bar, enter hp://192.168.168.1 and press Enter on
your keyboard.
At the login prompt, enter the Username and Password and then click
on OK.
User name: admin
Default Password: password
You will then reach the home page of your radio’s Web interface: the
Status Page.
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

Common
Configuraons4
Quick
Installaon
Guide
11
www.netkrom.com
The AIRNET Indoor High Power is used in many wireless applicaons.
Access Point Mode
& Staon Mode
It enables the bridging of wireless clients to wired network.
In Staon Mode the device acts as a wireless client. When connected to an
access point, it creates a network link between the Ethernet network connected
at this device, and the wireless Ethernet network connected at the access point.
Access Point Mode:
Staon Mode:
Staon Mode does not provide transparent bridging.
Staon WDS Mode does provide transparent bridging.
NOTE
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

Common
Configuraons4
Quick
Installaon
Guide
12
www.netkrom.com
You can implement a Point-to-Point connecon by simply seng one
access point as Access Point Mode and seng the other access point in
Staon mode (client).
Point to Point Applicaon
Click on the Basic Wireless Tab.
In wireless mode choose Access Point.
Enter a name for the Local AP-ESSID.
Choose the wireless profile
NA: 5GHz, mix of a and n
NG: 2.4GHz, mix of b, g and n
Save the changes and reboot the device to let your changes take effect.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
6.
Click on the Basic Wireless Tab.
In wireless mode choose Staon.
Enter the name of the Remote AP-ESSID.
Note: this opon must match with the ESSID configured in the Access point.
Enter the Access Point’s MAC in Remote AP-Lock to MAC.
Choose the wireless profile
NA: 5GHz, mix of a and n
NG: 2.4GHz, mix of a, b and n
Note: this opon must match with the wireless profile configured in the Access point.
Save the changes and reboot the device to let your changes take effect.
Follow these steps to setup Access Point Mode.
Follow these steps to setup Staon Mode.
Repeat the Staon steps to add more Clients to the Point-to-Mulpoint connecon.
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

Advanced
Configuraon5
Quick
Installaon
Guide
13
www.netkrom.com
Wireless with Router Mode:
Please go to page 69 of User Manual.
Advanced Sengs:
Please go to page 74 of User Manual.
Advanced Wireless Configuraon:
Please go to page 44 of User Manual.
Wireless Operaon Modes:
Please go to page 9 and 33 of User Manual.
Wireless Security Setup:
Please go to page 38 of User Manual.
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

With these basics steps you can enjoy your wireless link without problems,
please for more informaon about the capabilies and advanced configuraon
of our product please see the user manual
Quick
Installaon
Guide
14
www.netkrom.com
Congratulaons
300 Mbps AIR-AP600GHP
High Capacity Wireless Networks

Contact Informaon
Address:
2134 NW 99th Avenue, Miami FL 33172
Sales and ordering:
American Customers: [email protected]om
Worldwide Customers: [email protected]
Lan American and Spanish Customers: vent[email protected]
Technical Support:
Worldwide and English Customers: [email protected]om
Lan American Customers: [e-mail]
Phones:
([phone]
Fax:
([phone]
