Setup SMS command you send Response SMS Controller function you activate
90 SETUP Setup reset (Owner deleted)
and controller restart
93 VERSION First time Owner number entry
Setup SMS command you send Controller function you activate
91xx* User1 number entry (to delete: 910)
92xx* User2 number entry (to delete: 920)
93xx* Owner number entry (to delete: 930)
*xx marks the place of mobile phone number
Setup reset
For setup reset send the SMS “90” to the controller. AirPatrol responds with SETUP report:
“Owner: All; Users: All; Pump: All; Param: 5, 24, 180, 30”.
This means Owner is not specied; all users can send commands;
the pump model is not specied, call commands are set to default;
“LOW TEMPERATURE” message will be sent when room temperature drops below 5 °C , “NO POWER”
message blackout is in 24 hours and the “SERVICE” alarm message interval is 180 days, “HIGH
TEMPERATURE” message will be sent when room temperature rises abowe 30 °C
User setup
To set User numbers start your command SMS with “91”, followed by the mobile phone number of the
User. For example: “91+495012345” or “915012345” to enter User1 number where “5012345” is the
cell phone number of User1 and +49 is the country code. User numbers (Owner, User1, User2) can be
international (with the “+” symbol and country code) or local. The length of the number must be between
3-16 symbols (“+” counts as one symbol). Multiple commands can be combined into one SMS. When a
User has been set, AirPatrol responds with a SETUP report message.
Multiple commands
If you want to set up several parameters with one SMS, separate commands with one of the following:
space
comma “,”
semicolon “;”
For example, the SMS „91+49550111111 92+49550222222 9513 9720”
sets the User1 and User2 numbers, species the heat pump model as “Fujitsu”, and determines that NO
POWER message is sent immediately in case of a power failure.
When a command in the multi-setup is incorrect, the Owner will receive an error message. All the correct
commands that precede the error command in the multi-setup command will be activated.
Multi-setup sender will always receive SETUP report SMS from AirPatrol to conrm that all commands
arrived to the controller. There can be spaces before and after a command but not inside a command as
this will interfere with the code.
