Airspan MicroMAX User manual

UGD-D00068 Rev J
MicroMAX
Hardware Installation
User Guide
Software Release 7.7

MicroMAX Hardware Installation User Guide
Page 2 Commercial in Confidence UWB-D00068 Rev J
Acknowledgements
Airspan Networks Inc acknowledges the following trademarks used within this document:
© Intel Corporation http://www.intel.com/
© SEQUANS COMMUNICATIONS http://www.sequans.com
© Microsoft Corporation http://www.microsoft.com
Copyright
© Copyright by Airspan Networks Inc., 2009. All rights reserved worldwide.
The information contained within this document is proprietary and is subject to all relevant copyright,
patent and other laws protecting intellectual property, as well as any specific agreements protecting
Airspan Networks Inc. rights in the aforesaid information. Neither this document nor the information
contained herein may be published, reproduced or disclosed to third parties, in whole or in part,
without the express, prior, written permission of Airspan Networks Inc. In addition, any use of this
document or the information contained herein for the purposes other than those for which it is
disclosed is strictly forbidden.
Airspan Networks Inc. reserves the right, without prior notice or liability, to make changes in
equipment design or specifications.
Information supplied by Airspan Networks Inc. is believed to be accurate and reliable. However, no
responsibility is assumed by Airspan Networks Inc. for the use thereof nor for the rights of third parties
which may be effected in any way by the use of thereof.
Any representation(s) in this document concerning performance of Airspan Networks Inc. product(s)
are for informational purposes only and are not warranties of future performance, either expressed or
implied. Airspan Networks Inc. standard limited warranty, stated in its sales contract or order
confirmation form, is the only warranty offered by Airspan Networks Inc. in relation thereto.
This document may contain flaws, omissions or typesetting errors; no warranty is granted nor liability
assumed in relation thereto unless specifically undertaken in Airspan Networks Inc. sales contract or
order confirmation. Information contained herein is periodically updated and changes will be
incorporated into subsequent editions. If you have encountered an error, please notify Airspan
Networks Inc. All specifications are subject to change without prior notice.
Product performance figures quoted within this document are indicative and for information purposes
only.

MicroMAX Hardware Installation User Guide
Page 3 Commercial in Confidence UWB-D00068 Rev J
Table of Contents
Acknowledgements ..........................................................................................................................2
Copyright ..........................................................................................................................................2
Table of Contents .............................................................................................................................3
Summary of Figures .........................................................................................................................6
Summary of Tables ..........................................................................................................................9
Warnings and Cautions ..................................................................................................................10
Human Exposure to Radio Frequencies.....................................................................................10
Radio Interference ......................................................................................................................10
Avoiding Radio Interference .......................................................................................................10
Modifications...............................................................................................................................10
General .......................................................................................................................................10
DECLARATION OF CONFORMITY...............................................................................................11
FCC Notice .....................................................................................................................................12
Federal Communication Commission Notice .............................................................................12
GPS Compliance ........................................................................................................................12
Maximum Output TX Power .......................................................................................................13
700MHz External Antennas........................................................................................................13
1About this Guide.......................................................................................................................14
1.1Purpose ................................................................................................................................. 14
1.2Intended Audience ................................................................................................................14
1.3Conventions ..........................................................................................................................14
1.4Referenced Documentation ..................................................................................................14
2System Overview .....................................................................................................................15
2.1MicroMAX Frequency Ranges ..............................................................................................16
2.2System Components.............................................................................................................17
2.3Customer Benefits.................................................................................................................18
2.4Architecture ...........................................................................................................................18
2.5Power ....................................................................................................................................19
2.6Models...................................................................................................................................19
3Installation Prerequisites..........................................................................................................20
3.1Package Contents.................................................................................................................20
3.2Required Tools ......................................................................................................................21
3.3Radio Site Planning...............................................................................................................21
3.3.1 Radio Antenna Alignment .............................................................................................21
4Physical Description.................................................................................................................22
4.1MicroMAX BSR .....................................................................................................................22
4.1.1 Physical Dimensions .....................................................................................................22

MicroMAX Hardware Installation User Guide
Page 4 Commercial in Confidence UWB-D00068 Rev J
4.1.2 Ports ..............................................................................................................................23
4.2SDA-4S Type II .....................................................................................................................24
4.2.1 Physical Dimensions .....................................................................................................24
4.2.2 Ports ..............................................................................................................................25
4.2.3 LEDs..............................................................................................................................25
4.3SDA-4SDC Type II ................................................................................................................25
4.3.1 Physical Dimensions .....................................................................................................26
4.3.2 Ports ..............................................................................................................................27
4.3.3 LEDs..............................................................................................................................27
5BSDU Description ....................................................................................................................29
5.1Physical Dimensions .............................................................................................................29
5.2Ports ......................................................................................................................................30
6GPSD Description ....................................................................................................................33
6.1Physical Dimensions .............................................................................................................34
6.2Ports ......................................................................................................................................35
6.3LEDs......................................................................................................................................35
6.4Mounting the GPSD ..............................................................................................................36
6.5GPSD Architecture ................................................................................................................37
7GPS Description.......................................................................................................................39
7.1Physical Dimensions .............................................................................................................39
7.2Ports ......................................................................................................................................40
7.3Crimping GPS Cable.............................................................................................................40
7.4Contact Socket Crimping ......................................................................................................41
8AC/DC Power Converter..........................................................................................................43
8.1.1 Physical Dimensions .....................................................................................................43
8.2Redundant PS Unit ...............................................................................................................43
9Mounting the Base Station Radio (BSR)..................................................................................44
9.1Pole-Mounting the BSR.........................................................................................................45
9.2Wall-Mounting the BSR (Optional) ........................................................................................ 49
9.3Installing the SDA-4S ............................................................................................................52
9.3.1 Wall Mounting................................................................................................................52
10 Mounting the BSDU ..............................................................................................................54
10.1 Desktop mounting .........................................................................................................54
10.2 Rack mounting ..............................................................................................................54
11 Mounting the GPS.................................................................................................................56
12 Mounting the AC/DC Power Converter .................................................................................57
12.1 Rack Mounting ..............................................................................................................57
12.2 Connecting Redundant PS Unit ....................................................................................57

MicroMAX Hardware Installation User Guide
Page 5 Commercial in Confidence UWB-D00068 Rev J
13 Cabling the BSR....................................................................................................................59
13.1 Connecting the BSR to the SDA-4S..............................................................................59
13.2 SDA-4S Type II .............................................................................................................60
13.3 Connecting the BSR to BSDU.......................................................................................61
13.4 Connecting BSDU to Network.......................................................................................63
13.5 Connecting BSDUs .......................................................................................................64
13.6 Connecting BSDU for SNMP Management ..................................................................65
14 Connecting the SDA-4S to the power supply........................................................................67
14.1 Connecting the SDA-4S Type II ....................................................................................67
14.2 Connecting the SDA-4SDC Type II...............................................................................68
14.3 Connecting SDA-4S to Ethernet Network .....................................................................69
15 Connecting Power Cable for SDA-4SDC..............................................................................70
15.1 Housing the Connectors................................................................................................70
15.2 Connecting to the SDA-4SDC.......................................................................................70
16 Connecting BSDU to AC/DC Power converter .....................................................................72
16.1 Connections ..................................................................................................................72
16.2 Power Cable Assembly .................................................................................................73
16.3 Housing the Connectors................................................................................................73
16.4 Cable Connection..........................................................................................................74
17 Lightning and Surge Protection.............................................................................................78
17.1 Lightning Protection ......................................................................................................79
17.1.1 Air Terminals .................................................................................................................79
17.1.2 Grounding......................................................................................................................80
17.1.3 Surge Suppression........................................................................................................81
17.2 Cable Preparation (for grounding).................................................................................84
17.3 FM Interference & ESD Protection Recommendations.................................................85
17.4 Connecting Lightning and Surge Protector ...................................................................85
17.5 Lightning and Surge Protection Connection Scenarios ................................................88
18 Connecting Third-Party External Antennas...........................................................................91
18.1 Connecting GPS Antenna to BSDU..............................................................................92
18.1.1 Connecting the GPS .....................................................................................................92
18.1.2 GPS Alignment..............................................................................................................95
19 Appendix ...............................................................................................................................96
19.1 Environmental ...............................................................................................................96
19.2 Glossary of Terms.........................................................................................................97
19.3 Revision History ..........................................................................................................100
19.4 Contact Information.....................................................................................................100

MicroMAX Hardware Installation User Guide
Page 6 Commercial in Confidence UWB-D00068 Rev J
Summary of Figures
Figure 1 - MicroMAX Maximum Output TX Power .........................................................................13
Figure 2 - Typical Setup .................................................................................................................19
Figure 3 - BSR ports.......................................................................................................................22
Figure 4 - SDA-4S Type II ..............................................................................................................24
Figure 5 - SDA-4SDC Type II .........................................................................................................26
Figure 6 - SDA-4S top panel ..........................................................................................................28
Figure 7 - BSDU front .....................................................................................................................30
Figure 8 - BSDU Front Panel..........................................................................................................30
Figure 9 - BSDU Rear Panel ..........................................................................................................32
Figure 10 – GPSD ..........................................................................................................................33
Figure 11 - External antenna (included) .........................................................................................34
Figure 12 - "Y" cable (4 included)...................................................................................................34
Figure 13 - GPSD top panel ...........................................................................................................36
Figure 14 - Wall mount ...................................................................................................................36
Figure 15 - mounting template........................................................................................................37
Figure 16 - GPS antenna................................................................................................................39
Figure 17 - GPS dimensions ..........................................................................................................39
Figure 18 - GPS pinouts .................................................................................................................40
Figure 19 - Db-15 ...........................................................................................................................40
Figure 20 - Crimping tool (Daniels AFM8)......................................................................................41
Figure 21 - Contact crimp tool ........................................................................................................42
Figure 22 - Inserting socket into crimper ........................................................................................42
Figure 23 - AC/DC Power Converter..............................................................................................43
Figure 24 - RPSU-BSDU-1.............................................................................................................43
Figure 25 - BSR- rear view .............................................................................................................44
Figure 26 - Pole mounting bracket .................................................................................................45
Figure 27 - Mounting bracket attached...........................................................................................46
Figure 28 - Pole mount clamping bracket.......................................................................................47
Figure 29 - Pole mount U-bolts.......................................................................................................47
Figure 30 - elevation holes .............................................................................................................48
Figure 31 – positioning ...................................................................................................................48
Figure 32 - strain relief....................................................................................................................49
Figure 33 - mount separation .........................................................................................................49
Figure 34 - mounting template........................................................................................................50
Figure 35 - wall-mount bracket .......................................................................................................51
Figure 36 - attach mounting bracket...............................................................................................51
Figure 37 - wall mount ....................................................................................................................52

MicroMAX Hardware Installation User Guide
Page 7 Commercial in Confidence UWB-D00068 Rev J
Figure 38 - SDA-4S mounting template .........................................................................................53
Figure 39 - Rack mounted ..............................................................................................................54
Figure 40 - GPS pole mounting ......................................................................................................56
Figure 41 - PSU front......................................................................................................................58
Figure 42 - BSR front panel............................................................................................................59
Figure 43 - Pinouts .........................................................................................................................60
Figure 44 - BSR – SDA ..................................................................................................................61
Figure 45 - BSR-to-BSDU cable connection ..................................................................................63
Figure 46 - BSDU-to-backhaul network..........................................................................................64
Figure 47 - Cable connections for BSDU chaining with GPS.........................................................65
Figure 48 - BSDU-to-PC local network management cabling ........................................................66
Figure 49 - Power chord .................................................................................................................67
Figure 50 - Connecting to AC power ..............................................................................................68
Figure 51 - Connect to Ethernet .....................................................................................................69
Figure 52 - Power connectors (Anderson Powerpole) ...................................................................70
Figure 53 - Contact pin ...................................................................................................................70
Figure 54 – crimped........................................................................................................................70
Figure 55 – Insertion.......................................................................................................................70
Figure 56 - Connect to power source .............................................................................................71
Figure 57 - BSDU - AC/DC cable ...................................................................................................72
Figure 58 - BSDU to DC cable .......................................................................................................73
Figure 59 - Power connectors (Anderson Powerpole) ...................................................................73
Figure 60 - Contact pin ...................................................................................................................73
Figure 61 – Crimped.......................................................................................................................73
Figure 62 - Insertion .......................................................................................................................73
Figure 63 - BSDU to PS MNG port.................................................................................................74
Figure 64 - PSU to J1 port..............................................................................................................74
Figure 65 - Connect to Negative.....................................................................................................75
Figure 66 - Connect to Positive ......................................................................................................75
Figure 67 - Back panels..................................................................................................................75
Figure 68 - Front power connect ....................................................................................................76
Figure 69 - Rear panels..................................................................................................................76
Figure 70 - Front LEDs ...................................................................................................................77
Figure 71 - Air Terminal..................................................................................................................80
Figure 72 - Termination and Tower ................................................................................................80
Figure 73 - Level 1..........................................................................................................................82
Figure 74 - Level 2..........................................................................................................................82
Figure 75 - Level 3..........................................................................................................................83

MicroMAX Hardware Installation User Guide
Page 8 Commercial in Confidence UWB-D00068 Rev J
Figure 76 - Ring terminal ................................................................................................................85
Figure 77 – CAT-5e SFTP cable with ring terminal........................................................................85
Figure 78 - Complete assembly with Ferrite (optional)...................................................................85
Figure 79 - Working with SDA (W/O GPS Sync)............................................................................87
Figure 80 - RJ45 working with SDA................................................................................................87
Figure 81 - Working with BSDU (GPS Sync) .................................................................................87
Figure 82 - RJ45 working with BSDU.............................................................................................87
Figure 83 - Mounting template........................................................................................................88
Figure 84 - SDA-4S + Polyphaser + BSR ......................................................................................88
Figure 85 - SDA-4SDC + Polyphaser + BSR .................................................................................89
Figure 86 - BSDU + Polyphaser + BSR .........................................................................................90
Figure 87 - Antenna connection .....................................................................................................92
Figure 88 - BSDU rear panel GPS port ..........................................................................................93
Figure 89 - GPS connector pinouts ................................................................................................93
Figure 90 - GPS-to-BSDU cable connection ..................................................................................95

MicroMAX Hardware Installation User Guide
Page 9 Commercial in Confidence UWB-D00068 Rev J
Summary of Tables
Table 1 - 700MHz External Antennas Types..................................................................................13
Table 2 - MicroMAX Frequency Ranges ........................................................................................16
Table 3 - BSR Dimensions .............................................................................................................22
Table 4 - BSR ports ........................................................................................................................23
Table 5 - SDA-4S dimensions ........................................................................................................24
Table 6 - SDA-4S ports ..................................................................................................................25
Table 7 - SDA-4SDC dimensions...................................................................................................26
Table 8 - SDA-4SDC ports .............................................................................................................27
Table 9 - SDA-4S LEDs..................................................................................................................27
Table 10 - BSDU dimensions .........................................................................................................29
Table 11 - Front Panel Interfaces...................................................................................................30
Table 12 - BSDU LEDS description................................................................................................31
Table 13 - Rear panel Interfaces ....................................................................................................32
Table 14 - GPSD Voltage & Currency Ratings...............................................................................33
Table 15 - GPSD dimensions .........................................................................................................34
Table 16 - GPSD ports ...................................................................................................................35
Table 17 - GPSD LED description..................................................................................................35
Table 18 - GPS dimensions............................................................................................................39
Table 19 - GPS Pinouts..................................................................................................................40
Table 20 - Contact socket crimping................................................................................................41
Table 21 - AC/DC power converter dimensions ............................................................................. 43
Table 22 - BSR- BSDU connections...............................................................................................62
Table 23 - BSDU-to-WAN cable connector pinouts .......................................................................63
Table 24 - BSDU connecting cable connector pinouts...................................................................64
Table 25 - BSDU to PC for IP network management .....................................................................65
Table 26 - Required Equipment......................................................................................................72
Table 27 - Level of Lightning Protection.........................................................................................78
Table 28 - Application matrix ..........................................................................................................79
Table 29 – Accessories ..................................................................................................................84
Table 30 - Description ....................................................................................................................90
Table 31 - Connector pinouts for BSDU-to-GPS cabling ...............................................................94
Table 32 - BSR & SDA ...................................................................................................................96
Table 33 – BSDU............................................................................................................................96
Table 34 - GPSD ............................................................................................................................96

MicroMAX Hardware Installation User Guide
Page 10 Commercial in Confidence UWB-D00068 Rev J
Warnings and Cautions
Human Exposure to Radio Frequencies
The MicroMAX should be installed and operated from a minimum distance of 2 meters to your
body.
Radio Interference
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment on and off, the technician is encouraged to try
to correct the interference by performing one or more of the following measures:
¾Re-orientate or relocate the receiving antenna
¾Increase separation between the equipment and receiver
¾Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected
Avoiding Radio Interference
¾This transmitter must not be co-located or operating in conjunction with any antenna or
transmitter.
¾Ensure a minimum of 1-meter separation between co-located BSRs.
Modifications
Any changes and modifications to this device that are not expressly approved by Airspan
Networks may void the user's authority to operate the equipment.
General
¾Only qualified personnel should be allowed to install, replace, and service the equipment.
¾The device cannot be sold retail, to the general public or by mail order. It must be sold to
dealers.
¾Installation must be controlled.
¾Installation must be performed by licensed professionals.
¾Installation requires special training.
¾The MicroMAX radio and antenna should be installed ONLY by experienced installation
professionals who are familiar with local building and safety codes and, wherever
applicable, are licensed by the appropriate government regulatory authorities. Failure to
do so may void Airspan's WiMAX product warranty and may expose the end user or the
service provider to legal and financial liabilities. Airspan and its resellers or distributors
are not liable for injury, damage or violation of regulations associated with the installation
of outdoor units or antennas.

MicroMAX Hardware Installation User Guide
Page 11 Commercial in Confidence UWB-D00068 Rev J
DECLARATION OF CONFORMITY
European Community, Switzerland, Norway, Iceland, and Liechtenstein
Declaration of Conformity with Regard to the R&TTE Directive 1999/5/EC
English:
This equipment is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Deutsch:
Dieses Gerät entspricht den grundlegenden Anforderungen und den weiteren entsprecheneden
Vorgaben der Richtlinie 1999/5/EU.
Dansk:
Dette udstyr er i overensstemmelse med de væsentlige krav og andre relevante bestemmelser i
Directiv 1999/5/EF.
Español:
Este equipo cumple con los requisitos esenciales asi como con otras disposiciones de la
Directive 1999/5/EC.
Greek:
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Airspan ΔΗΛΩΝΕΙ ΟΤΙ ΟΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français:
Cet appareil est conforme aux exigencies essentialles et aux autres dispositions pertinantes de la
Directive 1999/5/EC.
Íslenska:
Þessi búnaður samrýmist lögboðnum kröfum og öðrum ákvæðum tilskipunar 1999/5/ESB.
Italiano:
Questo apparato é conforme ai requisiti essenziali ed agli altri principi sanciti dalla Direttiva
1999/5/EC.
Nederlands:
Deze apparatuur voldoet aan de belangrijkste eisen en andere voorzieningen van richtlijn
1999/5/EC.
Norsk:
Dette utstyret er i samsvar med de grunnleggende krav og andre relevante bestemmelser i EU-
directiv 1999/5/EC.
Português:
Este equipamento satisfaz os requisitos essenciais e outras provisões da Directiva 1999/5/EC.
Suomalainen:
Tämä laite täyttää direktiivin 1999/5/EY oleelliset vaatimukset ja on siinä asetettujen muidenkin
ehtojen mukainen.
Svenska:
Denna utrustning är i överensstämmelse med de väsentliga kraven och andra relevanta
bestämmelser i Direktiv 1999/5/EC.
The Declaration of Conformity related to this product can be obtained from
[e-mail]

MicroMAX Hardware Installation User Guide
Page 12 Commercial in Confidence UWB-D00068 Rev J
FCC Notice
Federal Communication Commission Notice
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his/her own
expense.
Fixed and base stations transmitting a signal with an emission bandwidth greater than 1 MHz
must not exceed an ERP of 1000 watts/MHz and an antenna height of 305 m HAAT, except that
antenna heights greater than 305 m HAAT are permitted if power levels are reduced below 1000
watts/MHz ERP.
GPS Compliance
The GPS is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC."
The GPS complies with the following EMC Common Regulatory Testing standards:
¾EN55022: Radiated and Conducted Emissions
¾CISPR 22: Class B
¾EN 50081-1: Generic Emissions Class B
¾EN 50082-1: Generic Immunity Class B
¾EN 61000-4-2: Electrostatic Discharge Immunity
¾EN 61000-4-3: Radiated RF EM Field Immunity Test
¾EN 61000-4-4: Electrical Fast Transient/Burst Test
¾EN 61000-4-6: Conducted Immunity
¾EN 61000-4-8: Magnetic Field Immunity
Note: A GPS is required for synchronizing between TDD/FDD sectors.

MicroMAX Hardware Installation User Guide
Page 13 Commercial in Confidence UWB-D00068 Rev J
Maximum Output TX Power
Figure 1 - MicroMAX Maximum Output TX Power
Caution: Do not set maximum output TX power to higher than local regulations.
700MHz External Antennas
Table 1 - 700MHz External Antenna Types
Type Frequency range Gain Manufacturer Model number
V-Pol MCX 698-746 MHz 7.5 dBi Mars Antennas MA-WA70-AS8
Flat panel 698-746 MHz 10.5 dBi Mti Wireless Edge Ltd. MT-223003/N
Sector 698-746 MHz 12 ± 0.5 dBi Mti Wireless Edge Ltd. MT-223002/NV
Sector 698-746 MHz 13.5 dBi Mti Wireless Edge Ltd. MT-223006/NV
Yagi directional 698 - 746 MHz 15.3 dBi Trival antene AD-40/722-14

MicroMAX Hardware Installation User Guide
Page 14 Commercial in Confidence UWB-D00068 Rev J
1 About this Guide
This section discusses the purpose, intended audience, conventions, referenced documentation
and organization for this guide.
1.1 Purpose
This guide provides step-by-step instructions for setting up and installing the MicroMAX BSR.
The purpose of this User Guide is to provide step-by-step instructions for setting up and installing
the MicroMAX BSR. These procedures include:
¾System Overview
¾Installation Prerequisites
¾Physical descriptions
¾Mounting
¾Cabling
¾Connecting
¾Lightning and Surge Protection
1.2 Intended Audience
This guide is intended for qualified and authorized technicians who are responsible for installing
the MicroMAX BSR.
1.3 Conventions
Icon Description
Checkpoint: Marks a point in the workflow where there may be an exit or
branch to some other procedure. At each Checkpoint the reason for an
exit or branch is given along with specific directions to locate the entry
point in the other procedure.
Reference: Gives a resource in the workflow that may be needed to
complete a procedure along with specific directions to use the resource.
Caution: Describes a possible risk and how to lessen or avoid the risk.
Advice: Provides a recommendation based on best practice.
Note: Provides useful information.
1.4 Referenced Documentation
For a description of the Web-based management tools for configuring and managing MicroMAX
BSR, see the following manual:
¾MicroMAX Web-based Management User's Guide
¾MicroMAX Overview

MicroMAX Hardware Installation User Guide
Page 15 Commercial in Confidence UWB-D00068 Rev J
2 System Overview
MicroMAX is a highly upgradeable Micro-cell base station, based on the Sequans System On a
Chip (SOC), with a pole/roof (wall) mounted radio system and antennae. This high performance
chip can support up to 28 + 28 MHz channels (full duplex) forms part of the AIRSPAN WIMAX
portfolio of WiMAX network infrastructure equipment. It is compatible with the Airspan EasyST
and ProST subscriber terminals and other manufacturer's CPEs that are fully WiMAX compliant.
The MicroMAX BSR is an outdoor radio that is mounted outside on a pole or wall. The BSR
provides a wireless link with subscribers and interfaces with the provider's backbone. The
MicroMAX BSR is available in two models. These models differ by antenna design (providing
integral flat-panel antennas, or an N-type port for attaching third-party external antennas).
MicroMAX BSR is available in numerous frequency bands, operating in FDD and TDD modes in
numerous channels see: MicroMAX Frequency Ranges.
The BSR connects to the indoor Ethernet switch by a CAT-5e cable, which carries the Ethernet
signal, and DC power. For a MicroMAX Base Station consisting of multiple BSRs, there are two
(2) options. The BSRs can be connected to individual Subscriber Data Adapters (SDA-4S) or to
Base Station Distribution Units (BSDU). For a Base Station consisting of a single BSR, the BSR
typically connects to a single Subscriber Data Adapter (SDA-4S or SDA-4SDC).
MicroMAX BSR provides a low cost, high-performance point-to multipoint packet-based
Broadband Wireless Access (BWA) solution. MicroMAX BSR Provides wireless connectivity
designed to deliver high-speed data, voice over IP (VoIP) and multimedia services to residential,
SOHO (Small Office/Home Office), and SME (Small to Medium Enterprises).
The MicroMAX is an encased outdoor radio providing access to the MicroMAX's communication
ports on its bottom panel. The MicroMAX's back panel provides holes for mounting.
MicroMAX BSR interfaces with the service provider's backbone through either:
¾The SDA-4S Type II or the SDA-4SDC (referred henceforth as SDA-4S) integrated LAN
switches.
•SDA-4S Type II: integrated LAN switch, providing power and four 10/100BaseT ports
for interfacing with the subscriber’s network
•SDA-4SDC Type II: integrated LAN switch, providing power and four 10/100BaseT
interfaces and especially designed for implementation where available power supply
is DC (10 to 52 VDC), e.g. from a solar panel. This model provides regulated –48
VDC power to the BSR.
¾Base Station Distribution Unit (BSDU) - provides an interface between multiple BSRs
and the service provider's backbone.
MicroMAX can be managed by an SNMP-based network management system (Netspan) using
standard and proprietary MIBs. In addition, external third-party management systems such as HP
OpenView can also manage the MicroMAX using these MIBs. Basic management can be
performed using any standard Web browser.
Note: For management refer to MicroMAX Web Management documentation.

MicroMAX Hardware Installation User Guide
Page 16 Commercial in Confidence UWB-D00068 Rev J
2.1 MicroMAX Frequency Ranges
The table below lists the frequency range of MicroMAX models currently available. This table will
grow as more models become available.
Table 2 - MicroMAX Frequency Ranges
Frequency Band Channel Bandwidth
698 – 746 MHz in TDD mode ¾2.5 MHz
¾5 MHz
¾10 MHz
1.42 - 1.52 GHz in TDD mode ¾1.5 MHz
¾1.75 MHz
¾2.5 MHz
¾5 MHz
2.5 – 2.69 GHz in TDD mode
NPI
¾2.5 MHz
¾5 MHz
¾10 MHz
2.7 – 2.9 GHz in TDD mode
NPI
¾3 MHz
¾6 MHz
¾10 MHz
3.3 - 3.5 GHz in TDD mode ¾1.75 MHz
¾2.75 MHz
¾3 MHz
¾3.5 MHz
¾5 MHz
3.4 - 3.5 GHz in FDD mode/ 50MHz ¾1.75 MHz
¾3.5 MHz
¾5 MHz *
3.4 - 3.6 GHz in FDD mode
(Lo, Hi)
¾1.75 MHz
¾3.5 MHz
3.4 - 3.6 GHz in TDD mode ¾1.75 MHz
¾3.5 MHz
¾5 MHz
3.6 - 3.8 GHz in FDD mode
(Lo, Hi)
¾1.75 MHz
¾3.5 MHz
3.6 - 3.8 GHz in TDD mode ¾1.75 MHz
¾3.5 MHz
¾5 MHz
¾7 MHz

MicroMAX Hardware Installation User Guide
Page 17 Commercial in Confidence UWB-D00068 Rev J
Frequency Band Channel Bandwidth
4.9 - 5.0 GHz in TDD mode ¾2.5 MHz
¾5 MHz
¾10 MHz
5.15 - 5.35 GHz in TDD mode ¾2.5 MHz
¾5 MHz
¾10 MHz
5.47 - 5.725 GHz in TDD mode ¾2.5 MHz
¾5 MHz
¾10 MHz
5.725 - 5.875 GHz in TDD mode ¾2.5 MHz
¾5 MHz
¾10 MHz
5.85 - 5.95 GHz in TDD mode ¾2.5 MHz
¾5 MHz
¾10 MHz
* As long as the central channel is an even number
2.2 System Components
¾Outdoor - Unit(s):
•MicroMAX Base Station Radio(s) (BSR)
•Global Positioning System (GPS)
¾Indoor:
•SDA-4S Type II: small low cost IDU with built in LAN switch
•SDA-4SDC Type II: small low cost DC IDU with built in LAN Switch
•GPSD: optional Global Positioning System Distribution unit (for up to 4 BSRs)
•BSDU: optional Ethernet switch for implementing Base Stations consisting of multiple
BSRs
¾IDU/ODU connectivity:
•CAT-5e cable 24 gauge or better (22 gauge recommended) for connecting to BSR
(SFTP - Shielded Foiled Twisted Pair - recommended)
•Fast Ethernet: 4 pins
•VDC power: BSR FDD/TDD requires 2 pins
•IDU/ODU length for BSR FDD: up to 100 meters
¾Minimum configuration:
•SDA-4S and a single BSR
¾Larger configurations:
•N*SDA-4Ss and N*BSRs

MicroMAX Hardware Installation User Guide
Page 18 Commercial in Confidence UWB-D00068 Rev J
•N*BSRs and BSDU (up to 8 BSRs per unit)
¾Optional AC/DC power converter - in the event -48 VDC is not available at BS site
2.3 Customer Benefits
The MicroMAX BSR offers the following customer benefits:
¾Based on the latest wireless technology WiMAX IEEE 802.16 2004 standard
¾SOC engine for best cost/performance
•Based on Sequans "System On a Chip" (SOC)
ohigh performance chip
ohigh growth potential
2.4 Architecture
The MicroMAX system consists of the following component designs:
¾Integrated Antenna Design
•Encased MicroMAX BSR outdoor unit with integrated antenna
•SDA-4S Type II or SDA-4SDC Type II indoor unit
•GPSD (optional for up to 4 BSRs)
•BSDU (optional for multiple BSRs)
•GPS antenna utilized with BSDU
•External AC/DC power converter (optional)
¾External Antenna Design
•Encased MicroMAX BSR outdoor unit
•SDA-4S Type II or SDA-4SDC Type II indoor unit
•BSDU (optional for multiple BSRs)
•GPS antenna utilized with BSDU or GPSD unit
•Third-party external antenna (optional deployment)
¾External AC/DC power converter (optional)
The figures below displays a typical setup (using BSDU) of the MicroMAX(s) mounted outdoors
on a pole (with an integrated antenna).

MicroMAX Hardware Installation User Guide
Page 19 Commercial in Confidence UWB-D00068 Rev J
Figure 2 - Typical Setup
2.5 Power
¾The SDA-4S is a switch providing the MicroMAX BSR with -48 VDC power supply, and
10/100BaseT interface with the subscriber's PCs/network.
¾The BSDU is also responsible for providing BSRs with -48 VDC power supply and for
synchronizing BSDUs, BSRs and Base Stations (when a GPS is implemented).
¾An external AC/DC power converter (optional) is available in the event -48 VDC is not
available at BS site. Contact your Airspan supplier.
2.6 Models
The MicroMAX is available in the following basic physical designs:
¾MicroMAX with a built-in (integral), internal antenna.
¾MicroMAX with an N-type type RF connector for connecting an optional third-party
external antenna.
Note: A MicroMAX with an N-type port for attaching a third-party external
antenna does not provide a built-in antenna.

MicroMAX Hardware Installation User Guide
Page 20 Commercial in Confidence UWB-D00068 Rev J
3 Installation Prerequisites
Before installing your MicroMAX, review:
¾Package Contents
¾Required tools
¾Radio Site planning
3.1 Package Contents
Examine the AIRSPAN WIMAX shipping container. If you notice any damage, or missing items as
listed in the Packing List, immediately notify the carrier that delivered the unit and contact a
Airspan representative.
The MicroMAX kit should contain the following items:
¾MicroMAX Base Station radio
¾DB15-to-RJ45 adapter for plugging into the BSR's 15-pin D-type port
¾Pole-mounting kit:
o2 x M10 hex head screws
o2 x M10 flat washers
o2 x M10 spring lock washers
o2 x M10 hex nuts
•Mounting bracket
o2 x M6 hex head screws
o2 x M6 spring lock washers
•Clamping bracket
o2 x M8 'U'- bolts
o4 x M8 hex nuts
o4 x M8 plain washers
o4 x M8 spring lock washers
The GPSD (optional) kit should contain the following items:
¾GPSD (AC or DC)
¾Power cable – for AC
¾GPS antenna
¾4 “Y” cables
The GPS kit should contain the following items:
¾GPS Smart Antenna RS422
¾Conn DB15PM AMP - for discrete wires IDC
¾Connector, Circular (Deutsch IMC26-2212X) - Industrial Micro 12P F
¾Cable 4x2422# (CAT-5e) - 10 meters
¾8x Contact sockets (for Deutsch 6862-20122278) - Circular Micro connectors
¾Boot shrink w/ glue (Raychem) - heat shrink
¾Plastic Hood 15-Pin - D-Type sub-connector
