AirSpeed 1000 Installation Guide
Part Number: DUG01289
System Release: 16.0
Revision: A
Published: January 2019

© Copyright by Airspan Networks Ltd., 2018-2019. All rights reserved worldwide.
Legal Notices
The information contained within this document is proprietary, privileged and intended only for the recipient. As
such, the information is subject to all relevant copyright, patent and other laws protecting intellectual property, as
well as any specific agreements protecting Airspan Networks Ltd. rights in the aforesaid information. Neither this
document nor the information contained herein may be published, reproduced, transmitted or disclosed to third
parties, in whole or in part, without the express, prior, written permission of Airspan Networks Ltd. In addition, any
use of this document or the information contained herein for the purposes other than those for which it is disclosed
is strictly forbidden.
Airspan Networks Ltd. reserves the right, without prior notice or liability, to make changes in equipment design or
specifications.
Information supplied by Airspan Networks Ltd. is believed in good faith to be accurate and reliable, while every
care has been taken in preparing these documents. However, Airspan Networks Ltd. does not make any
representations and gives no warranties of whatever nature in respect of these documents, including without
limitation, the accuracy or completeness of any information, facts and/or opinions contained therein. No
responsibility is assumed by Airspan Networks Ltd. for the use of the documents nor for the rights of third parties
which may be effected in any way by the use thereof. The provision of these documents (and the documents
themselves) does not constitute professional advice of any kind. Any representation(s) in these documents
concerning performance of Airspan Networks Ltd. product(s) are for informational purposes only and are not
warranties of future performance, either expressed or implied. Airspan Networks Ltd., its affiliates, directors,
employees and agents shall not be held liable for any damages or losses, of any nature whatsoever, arising from
any use of and/or reliance on the documents.
These documents may contain flaws, omissions or typesetting errors; no warranty is granted nor liability assumed
in relation thereto unless specifically undertaken in Airspan Networks Ltd. sales contract or order confirmation.
Information contained herein is periodically updated and changes will be incorporated into subsequent editions. If
you have encountered an error, please notify Airspan Networks Ltd.
Product performance figures quoted within this document are indicative and for information purposes only.
UK WEEE Registration number: WEEE/AB0207WZ. For more information, see WEEE Information for Airspan
Customers and Recyclers.
Acknowledgements
© Intel Corporation http://www.intel.com/
© Microsoft Corporation http://www.microsoft.com

DUG01289 Airspan Commercial and Internal Use i
Table of Contents
Document Information...............................................................................2
Abstract..................................................................................................................2
Revision History.....................................................................................................2
Warnings and Cautions.............................................................................3
Human Exposure to Radio Frequencies ................................................................3
Avertissement et Precautions d’Utilisation................................................3
Exposition des personnes aux fréquences radioélectriques ..................................3
Radio Interference..................................................................................................3
Modifications..........................................................................................................3
General..................................................................................................................3
Général..................................................................................................................3
Important Safety Instructions............................................................................4
Safety.....................................................................................................................4
Securite..................................................................................................................4
Warning of Hazardous Voltages ............................................................................5
Attention aux Voltages Hasardeux.........................................................................5
Adherence to European Directive 1999/5/EC ........................................................5
Warning Symbols...................................................................................................6
Service Information................................................................................................6
UL Information .......................................................................................................6
DECLARATION OF CONFORMITY .........................................................6
Maximum Output TX Power......................................................................8
Product Variants ....................................................................................................8
Power Consumption...............................................................................................8
External Antennas..................................................................................................9
About This Document..............................................................................10
Purpose................................................................................................................10
Intended Audience...............................................................................................10
Document Conventions........................................................................................10

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use ii
Related Reading..................................................................................................11
Customer Care Help Desk ......................................................................12
Airspan Encourages Comments ..........................................................................12
1Introduction..........................................................................................13
1.1 AirSpeed 1000 ..............................................................................................13
2Getting Started.....................................................................................14
2.1 Workflow of Installation .................................................................................14
2.2 AirSpeed 1000 Installation Checklist.............................................................14
3Verifying Prerequisites.........................................................................15
3.1 Verifying Site Requirements..........................................................................15
3.2 Verify Installation Requirements....................................................................15
3.2.1 Verify the Tools............................................................................................15
3.2.2 Verify the Parts and Kits...............................................................................16
3.2.3 Power Supply...............................................................................................16
3.2.4 Connections.................................................................................................17
3.2.5 Physical Dimensions....................................................................................18
3.2.6 Environmental..............................................................................................18
4AirSpeed 1000 Installation...................................................................20
4.1 Connecting the GPS Antenna.......................................................................20
4.2 Pole Mounting Assembly...............................................................................20
4.2.1 Pole Mounting (Larger Poles).......................................................................21
4.3 Wall Mount Assembly....................................................................................23
4.4 LED Display ..................................................................................................24
5Connect and Manage Cables..............................................................25
5.1 Grounding .....................................................................................................25
5.2 Remote Antenna Assembly...........................................................................25
5.3 Weather-proofing Antenna Connections .......................................................25
5.4 Ethernet Cable Installation............................................................................26
5.5 Connecting the DC Power Cable...................................................................26
AJob Sheet.............................................................................................28
BChecklist ..............................................................................................29

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use iii
CAbbreviations.......................................................................................30
Figures
Figure 1: AirSpeed 1000....................................................................................................................9
Figure 2: AirSpeed 1000 Front View ................................................................................................13
Figure 3: Workflow...........................................................................................................................14
Figure 4: AirSpeed 1000 Top Ports..................................................................................................17
Figure 5: AirSpeed 1000 Bottom Ports.............................................................................................18
Figure 6: Attaching GPS Antenna.................................................................................................... 20
Figure 7: Pole Mounting Assembly................................................................................................... 22
Figure 8: Mounted on Pole...............................................................................................................22
Figure 9: AirSpeed onWall..............................................................................................................23
Figure 10: Connecting Antenna RF Cable........................................................................................25
Figure 11: Weather-proof the Connection ........................................................................................25
Figure 12: Gland Connected............................................................................................................26
Figure 13: Ethernet Cable through Connector.................................................................................. 26
Figure 14: Power Cable Attached ....................................................................................................27
Tables
Table 1: AirSpeed 1000 ETSI Maximum Output TX Power.................................................................8
Table 2: AirSpeed 1000 FCC Maximum Output TX Power .................................................................8
Table 3: Supported Frequency Bands................................................................................................8
Table 4: Power Consumption.............................................................................................................8
Table 5: Typographic Conventions...................................................................................................10
Table 6. Minimum Hardware Requirements .....................................................................................15
Table 7. Parts & Kits........................................................................................................................16
Table 8. AirSpeed 1000 Physical Dimensions..................................................................................18
Table 9. AirSpeed 1000 Environment Compliance...........................................................................19
Table 10: ABBREVIATIONS & DEFINITIONS..................................................................................30

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 2
Document Information
Abstract
This document details procedures for installing the Airspan’s AirSpeed 1000 Pico-class LTE eNodeB
variant.
Revision History
Revision Details
Date
Summary of Changes
Rev 0.1 –0.2
August 2017
Initial document –draft(s)
comments
Rev A
August 2017
comments
Published
Rev A1
January 2019
Updates
This document is available at: AirSpeed 1000 Installation Guide

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 3
Warnings and Cautions
Human Exposure to Radio Frequencies
The AirSpeed 1000 should be installed and operated from a minimum safe distance of about 48Cm.
Avertissement et Precautions d’Utilisation
Exposition des personnes aux fréquences radioélectriques
Les AirSpeed 1000 doivent être installée et utilisée de façon à garantir la distanceminimale de sécurité
de 2.5m.
Radio Interference
This AirSpeed 1000 generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio, television reception or WiFi AP, which can be
determined by turning the equipment on and off, the technician is encouraged to try to correct the
interference by performing one or more of the following measures:
Re-orientate or relocate the unit
Increase separation between the units and/or End Devices
Connect the equipment to an outlet on a circuit different from that to which the power source is
connected
Modifications
Any changes and modifications to this device that are not expressly approved by Airspan Networks
may void the user's authority to operate the equipment.
General
Only qualified personnel should be allowed to install, replace, and service the equipment.
The device cannot be sold retail, to the general public or by mail order. It must be sold to
operators.
Installation must be controlled.
Installation must be performed by licensed professionals.
Installation requires special training. The AirSpeed 1000 should be installed ONLY by
experienced installation professionals who are familiar with local building and safety codes
and, wherever applicable, are licensed by the appropriate government regulatory authorities.
Failure to do so may void Airspan's product warranty and may expose the end user or the
service provider to legal and financial liabilities.
Airspan and its resellers or distributors are not liable for injury, damage or violation of
regulations associated with the installation of units or antennas.
Général
Seul le personnel qualifié peut être autorisé pour installer ou remplacer l’équipement ainsi
qu’effectuer les opérations de maintenance pour cet équipement.
L’équipement ne peut pas être vendu en grande distribution ou par commande via email à
destination du public. Il doit être vendu aux opérateurs de télécommunications.
Son installation doit être contrôlée
Son Installation doit être effectuée par des professionnels autorises.
Son installation requiert une formation spécifique du personnel. L’AirSpeed 1000, radio et
antenne doit être installe UNIQUEMENT par des installateurs professionnels expérimentés et
ayant une connaissance des constructions locales et règles de sécurité, ainsi que, dès que

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 4
nécessaire, disposant d’un agreement des autorités gouvernementales de régulation. Toute
enfreinte a ces obligations peut annuler la garantie délivrée par Airspan pour ces produits et
peut exposer l’utilisateur final ou le fournisseur de services a des dommages légaux et
financiers.
Airspan et ses revendeurs ou ses distributeurs ne sont pas responsables des blessures,
dommages ou violations de la régulation en vigueur lies a l’installation du système ou des
antennes.
Important Safety Instructions
Read and Save these instructions
This Installation Guide contains instructions and warnings that should be followed during
installation, and operation.
Failure to follow these instructions could cause bodily injury and/or product failure
Safety
1. Read this guide and follow all operating and safety instructions.
2. No user serviceable parts inside.
3. Position the power cord to avoid possible damage; do not overload circuits.
4. Do not place this product on or near a direct heat source, and avoid placing objects on
the terminal.
5. Use only a damp cloth for cleaning. Do not use liquid or aerosol cleaners. Disconnect the
power before cleaning.
6. The units should not be located near power lines or other electrical power circuits.
7. It is the user’s responsibility to install this device in accordance with the local electrical
codes.
8. Installation of the AirSpeed 1000 must be contracted to a professional installer.
9. The circuit breaker should be easily accessible in case you have to disconnect the
device.
10. When installed in the final configuration, the product must comply with the applicable
Safety Standards and regulatory requirements of the country in which it is installed. If
necessary, consult with the appropriate regulatory agencies and inspection authorities to
ensure compliance.
Securite
1. Lire attentivement ce guide et suivre les instructions d’utilisation et de sécurité.
2. Aucune pièce a l’intérieur est d’utilité pour l’utilisateur.
3. Positionner le cordon d’alimentation de façon à éviter des dommages potentiels. Ne pas
surcharger les circuits.
4. Ne pas placer ce produit sur ou à proximité d’une source directe de chaleur et éviter de
placer des objets sur le terminal.
5. Utiliser uniquement chiffon de coton pour nettoyage. Ne pas utiliser de produits liquides
ou d’aérosols. Déconnecter le produit de la source d’alimentation avant nettoyage.
6. L’unité ne doit pas être située trop près de lignes électriques ou autres circuits de
puissance, avec lesquels il pourrait entrer en contact.
7. L’utilisateur est tenu responsable de l’installation du produit conformément aux règles
électrique en vigueur localement.
8. L’installation de AirSpeed 1000 doit être contractualisée avec un installateur
professionnel.

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 5
9. L’interrupteur de circuit électrique doit être facilement accessible afin de pouvoir
déconnecter l’équipement.
10. Lors de l’installation de la configuration finale, le produit doit être conforme aux Standards
de Sécurité en vigueur ainsi qu’aux exigences réglementaires du pays dans lequel il est
installé. Si nécessaire, consulter les agences règlementaires appropriées, ainsi que les
autorités chargées de l’inspection afin de garantir la conformité.
Warning of Hazardous Voltages
On AC installations, hazardous voltages exist. Use caution when verifying or working with AC power.
Remove metal jewellery that could come into contact with AC power.
On DC sections, short-circuiting the low voltage, low impedance circuits can cause severe arcing that
may result in burns or eye damage. Remove rings, watches etc. to avoid shorting DC circuits.
Note: Airspan products do not contain hazardous substances (as defined in UK Control of
Substances Hazardous to Health Regulations 1989 and the Dangerous Substances Regulations
1990). At the end of any Airspan products life cycle, the customer should consult with Airspan to
ensure that the product is disposed of in conformance with the relevant regulatory requirements.
Attention aux Voltages Hasardeux
Sur les installations de réseau électrique de type courant alternatif (CA), des voltages hasardeux
peuvent survenir. Garder une Attention particulière lors d’une vérification ou de travaux sur réseau
électrique CA. Retirer tous bijoux en métal qui pourraient entrer en contact avec l’alimentation ou le
réseau CA.
Sur les portions de réseau électrique de type courant continu (CC), un circuit basse impédance peut
causer de sérieux arcs électriques qui pourraient bruler ou endommager les yeux. Retirer bagues,
anneaux, montres etc… afin d’éviter les court-circuit sur le réseau CC.
Adherence to European Directive 1999/5/EC
European Council Recommendation 1999/5/EC details basic restrictions and reference levels on
human exposure to electromagnetic fields as advised by the ICNIRP. Adherence to these
recommended restrictions and reference levels should provide a high level of protection as regards
the established health effects that may result from exposure to electromagnetic fields.
Airspan equipment is compliant with CE and R&TTE regulations and can be operated in all EU
(European Union) locations listed below:
Country Code
BE
EL
LT
PT
BG
ES
LU
RO
CZ
FR
HU
SI
DK
HR
MT
SK
DE
IT
NL
FI
EE
CY
AT
SE
IE
LV
PL
UK

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 6
Warning Symbols
The following symbols may be encountered during installation or troubleshooting. These warning
symbols mean danger. Bodily injury may result if you are not aware of the safety hazards involved in
working with electrical equipment and radio transmitters. Familiarize yourself with standard safety
practices before continuing.
Caution, hot surface
Caution
Electro-Magnetic
Radiation
DC
Service Information
Refer all repairs to qualified service personnel. Do not modify any part of this device, as this will void
the warranty.
Disconnect the power to this product and return it for service if the following conditions apply:
a. The terminal does not function after following the operating instructions outlined in this
manual.
b. Liquid has been spilled, a foreign object is inside, or the terminal has been exposed to
rain.
c. The product has been dropped or the housing is damaged.
Locate the serial number of the terminal and record this on your registration card for future reference.
Also record the MAC address, located on the product sticker.
UL Information
- The electrical source must be properly grounded according with NEC and other local safety code
requirements.
- AirSpeed 1000 is designed to operate in environmental conditions complying with IP40 and relevant
standards.
DECLARATION OF CONFORMITY
European Community, Switzerland, Norway, Iceland, and Liechtenstein
Declaration of Conformity with Regard to the R&TTE Directive 1999/5/EC
English:
This equipment is in compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Deutsch:
Dieses Gerät entspricht den grundlegenden Anforderungen und den weiteren entsprecheneden
Vorgaben der Richtlinie 1999/5/EU.
Dansk:
Dette udstyr eri overensstemmelsemed devæsentlige krav og andrerelevantebestemmelser i Directiv
1999/5/EF.
Español:
Este equipo cumple con los requisitos esenciales asi como con otras disposiciones de la Directive
1999/5/EC.

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 7
Greek:
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Airspan ΔΗΛΩΝΕΙ ΟΤΙ Ο ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ
ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français:
Cet appareil est conforme aux exigencies essentialles et aux autres dispositions pertinantes de la
Directive 1999/5/EC.
Íslenska:
Þessi búnaður samrýmist lögboðnum kröfum og öðrum ákvæðum tilskipunar 1999/5/ESB.
Italiano:
Questo apparato éconforme ai requisiti essenziali ed agli altri principi sanciti dalla Direttiva 1999/5/EC.
Nederlands:
Deze apparatuur voldoet aan de belangrijkste eisen en andere voorzieningenvan richtlijn 1999/5/EC.
Norsk:
Dette utstyret er i samsvar med de grunnleggende krav og andre relevante bestemmelser i EU-directiv
1999/5/EC.
Português:
Este equipamento satisfaz os requisitos essenciais e outras provisões da Directiva 1999/5/EC.
Suomalainen:
Tämä laite täyttää direktiivin 1999/5/EY oleelliset vaatimukset ja on siinä asetettujen muidenkin ehtojen
mukainen.
Svenska:
Denna utrustning är i överensstämmelse med de väsentliga kraven och andra relevanta bestämmelser
i Direktiv 1999/5/EC.
Român:
Acest echipament este în conformitate cu cerinţele esenţiale şi alte prevederi relevante ale Directivei
1999/5/CE.
The Declaration of Conformity related to this product can be obtained from [e-mail].

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 8
Maximum Output TX Power
Table 1: AirSpeed 1000 ETSI Maximum Output TX Power
Frequency Band
(MHz)
ETSI
TX (dBm) EIRP (dBm)
Antenna Gain
(dBi)
Variant
3550-3700
25
45.5
20.5
1000
Table 2: AirSpeed 1000 FCC Maximum Output TX Power
Frequency Band
(MHz)
FCC
TX (dBm) EIRP (dBm)
Antenna Gain
(dBi)
Variant
3550-3700
23.98
44.48
20.5
1000
Note: The AirSpeed 1000 requires operation using an Airspan FCC-specific version of Netspan
acting as a CBRS Domain Proxy.
Caution: Do not set maximum output TX total power to higher than local regulations.
Product Variants
AirSpeed supports the following frequency bands with the specific performance values:
Table 3: Supported Frequency Bands
LTE Band
Variant
Downlink
Freq.
(MHz)
Uplink
Freq.
(MHz)
Duplex
Tx / Rx
Conf.
Tx Power
per Port
(dBm)
Power
Source
48, 42H,
43L
AS10-U48-B02D
3550-3700
3550-3700
TDD
2 x 2
25
DC
Power Consumption
Table 4: Power Consumption
Power Source
Nominal Power Consumption
(W)
Max Nominal Power
Consumption (W)
DC
40
65
Note: Nominal Power Consumption (W) - refers to average power consumption over time.

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 9
External Antennas
AirSpeed 1000 connects to the external antennas via four (4) N-Type female connectors located at
the top panel. The antenna should be mounted to its appropriate mounting facility.
The supported antennas should be dual slant, cross polar antennas.
Note: For a list of compatible external antennas, please contact your nearest Airspan Sales
representative.
Figure 1: AirSpeed 1000

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 10
About This Document
Purpose
This guide provides the workflow and step-by-step procedures for installing the Airspan’s AirSpeed
1000, Pico-class LTE eNodeB variant. These procedures include:
Verify prerequisites
Install Mounting bracket
Install the AirSpeed 1000
Connect and manage cables
Intended Audience
This guide is intended for persons who are responsible for installing the AirSpeed 1000 equipment.
Document Conventions
This document uses the following typographic conventions.
Table 5: Typographic Conventions
Convention
Element
Blue underlined text
Cross-reference links.
Bold text
Keyboard buttons and GUI elements.
Command
Command names or phrases.
Computer output
Text displayed by the computer.
Hyperlinks
Website and e-mail addresses.
Danger
Signifies a hazardous situation—if not avoided—will
cause death or serious injury. Describes how to avoid
it.
Warning
Signifies a hazardous situation—if not avoided—can
cause death or serious personal injury. Describes
how to avoid it.
Caution
Signifies a hazardous situation—if not avoided—can
void the product warranty, and cause property
damage. Describes how to avoid it.
Important
Provides necessary information to explain a task.
Note
Provides additional information.
Tip
Provides helpful hints.

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 11
Related Reading
The following documents contain related information:
AirSpeed 1000 Product Datasheet
Airspan LTE Commissioning Manual

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 12
Customer Care Help Desk
Airspan’s Customer Care Help Desk offers prompt and efficient customer support services.
Note: To avail Airspan’s Customer Care Help Desk support, youmust be a registered user and must
have a valid support contract. To register, click here and fill the Registration form.
To create and update issue logs, send e-mails to Customer Care Help Desk. Once you submit your
issue, the system generates a new issue and sends an issue number for your reference. The system
uses this issue number to categorize and store e-mails under the appropriate issue.
To help Customer Care Help Desk identify your issue, include the issue number and your Customer
Care Helpdesk account details in all further communications.
Main Operations
Airspan Communications Ltd.
Capital Point
33 Bath Road
Slough, Berkshire
SL1 3UF, United Kingdom
Tel: [phone]
Worldwide Headquarters
Airspan Networks Inc.
777, Yamato Road, Suite 105
Boca Raton, FL 3341-4408, USA
Tel: [phone]
Airspan Encourages Comments
Airspan welcomes any feedback and suggestionsthat help to improve the quality of the documentation.
Send your feedback to [e-mail].

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 13
1 Introduction
This section provides a descriptive overview of the Airspan’s AirSpeed 1000 Pico-class eNodeB
variant and its place in the Airspan product suite.
1.1AirSpeed 1000
AirSpeed 1000 is part of Airspan’s carrier-class LTE Advanced outdoor small cell eNodeB family.
AirSpeed 1000 is a Pico-class LTE eNodeB product, providing high-speed data, mobility, Voice over
LTE, and broadcast/multicast services.
AirSpeed 1000 is a super compact, easy to install Pico-class eNodeB. Allowing an operator to deploy
LTE broadband services on any Street Furniture, rooftop or building front.
AirSpeed 1000 is a dual sector / carrier 2x2 MIMO product.
Note: For management please refer to the Airspan LTE Commissioning Manual as well as the
Netspan User Manual.
Note: The AirSpeed 1000 requires operation using an Airspan FCC-specific version of Netspan
acting as a CBRS Domain Proxy.
The AirSpeed 1000 unit is displayed below.
Figure 2: AirSpeed 1000 Front View

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 14
2 Getting Started
2.1Workflow of Installation
The Workflow to install the AirSpeed 1000 is displayed in the following diagram:
Figure 3: Workflow
2.2AirSpeed 1000 Installation Checklist
Plan the installation of the AirSpeed 1000 by using the Installation Checklist, which you can find as a
removable job aid in Appendix B for this guide.

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 15
3 Verifying Prerequisites
Prior to installing the AirSpeed 1000, verify the required safety, power, tools, parts and components.
This chapter includes the hardware, software, and client requirements for installation.
Important: Set up requirements for the installation is detailed in the Job Sheet, see Appendix A.
3.1Verifying Site Requirements
To set up the AirSpeed 1000, an IP connection to a Netspan server is required.
3.2Verify Installation Requirements
3.2.1 Verify the Tools
Table 6. Minimum Hardware Requirements
Tool
Use
Large flat bladed screwdriver
securing the pole straps (bands)
13 mm wrench
for securing M8 nuts
10 mm or 13/32 inch wrench
for securing M6 nuts
Large pliers
Tightening cable glands - To fit 15 mm
Note: Airspan does not provide screws and wall anchors for mounting the unit to the wall. The screw
size depends on the structure of the building to which the unit is to be attached. When selecting
screw sizes, consideration must be given to the weight of the unit and load that may be induced in
windy conditions.

AirSpeed 1000 Installation Guide
DUG01289 Airspan Commercial and Internal Use 16
3.2.2 Verify the Parts and Kits
Note: Verify order and requirements to ensure the correct unit type is being installed.
Table 7. Parts & Kits
Installation Kit
/ Part
Product
Code
Airspan
No.
Consisting of:
Images
AirSpeed 1000,
3.550-3.700 GHz
(B48)
AS10-U48-
B02D
998-73-
483
AirSpeed 1000 Copper Backhaul,
DC Unit
AirSpeed 1000
Acc. Mounting Kit
TBD
903-03-
803
AirSpeed 1000 mounting kit
including:
1 - CPE Pole mount
Bracket Base
2 –U-bolt M8 x2
for 1” (33.7mm) to 1.5”
(48.3mm) pole
4 - M8 Hex Nut
4 –Washer Spring
4 –Washer M8
4 –M6 x 20 Hex head
bolt with 2 washers
2- Maxi Clamps, band
9/16” wide + quick
adjustment lock –for
1.8” (45 mm) to 8” (210
mm) pole
GPS antenna
3.2.3 Power Supply
AirSpeed 1000 supports direct connection to DC power source:
Operational Voltage Range: -40.5 to -57 VDC
Transient Voltage: +150V (ETR283)
Note: AC power feed is also available, using an AC/DC power converter offered by Airspan.
For more details on the offered AC/DC converter (sold separately), please contact your nearest Airspan sales representative.
