AirTech ACR60 Assembly instructions

ACR60
ACR60LV
Installation and Wiring Instructions
All wiring to be in accordance with the current I.E.E. Regulations, or
the appropriate standards of your country and MUST be installed
by a suitably qualified person.
The Fan should be provided with a local isolator switch capable of
disconnecting all poles, having a contact separation of at least
3mm.
Ensure that the mains supply (Voltage, Frequency, and Phase)
complies with the rating label.
The Fan should only be used in conjunction with the appropriate
Airtech products.
The fan should only be used in conjunction with fixed wiring.
When the Fan is used to remove air from a room containing a fuel-
burning appliance, ensure that the air replacement is adequate for
both the fan and the fuel-burning appliance.
The Fan should not be used where it is liable to be subject to direct
water spray for prolonged periods of time.
Where ducted Fans are used to handle moisture-laden air, a
condensation trap should be fitted. Horizontal ducts should be
arranged to slope slightly downwards away from the Fan.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Young children should be supervised to ensure that they do not
play with the appliance.
This product should not be disposed of with household waste. Please recycle where facilities exist. Check with
your local authority for recycling advice.
IPX4
SAFETY AND GUIDANCE NOTES

The fan is a continuously running extract fan for kitchens, utility rooms, bathrooms and toilets.
The incorporated LED display allows the installer to configure the fan to suit its installation.
The display is also used to display the day logger and power run meter. The fan can be wall,
window or panel/ceiling mounted.
SITING THE TRANSFORMER (SELV Model only)
1. The transformer must not be installed in a shower cubicle or enclosure. It must be sited
away from direct sources of water spray and out of reach (1.5m) of a person using a
fixed bath or shower.
2. Site away from direct sources of heat. Ambient temperature range 0 ºC to 40ºC. Do not
site in an area containing excessive levels of grease.
3. Decide where to site the transformer and fan and work out the required cable runs.
PANEL/CEILING/ INTERIOR WALL MOUNTING
1. Cut a 105mm diameter hole.
2. Loosen the screw at the bottom of the grille, and then remove the grille by carefully
pulling away from the housing.
3. Mark the screw centres through the holes in the fan back plate. Drill, plug and screw
into position. Attach ducting as required for the installation.
4. Wire the fan as described in the Wiring section. Adjust any settings as required (see
Setup section).
5. After installation, ensure impeller rotates freely.
6. Replace the grille and tighten the retaining screw.
EXTERIOR WALL MOUNTING
1. For wall mounting cut a 117mm diameter hole through the wall and insert the wall
sleeve. Slope the sleeve slightly downwards away from the fan. Where necessary cut
to length and cement both ends into position flush with the wall faces.
2. Fix exterior grille into position with the louvres positioned downwards.
3. Loosen the screw at the bottom of the grille, and then remove the grille by carefully
pulling away from the housing.
4. Mark the screw centres through the holes in the fan back plate. Drill, plug and screw
into position.
5. Wire the fan as described in Wiring section. Adjust any settings as required (see Setup
section).
6. After installation, ensure impeller rotates freely.
7. Replace the grille and tighten the retaining screw.
WINDOW MOUNTING
For window mounting refer to the instructions provided with the kit.
INSTALLATION
DESCRIPTION

WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED
FROM THE POWER SUPPLY DURING THE INSTALLATION / OR MAINTENANCE.
IMPORTANT
The cross-sectional area of supply cord used should be ranged from 1 -1.5mm
2
.
The extraction fan or transformer (SELV model) is suitable for connection to
220-240V 50Hz supply.
The Transformer (SELV model only) MUST be surface mounted to allow air to freely
circulate around the unit. When installed in a loft void it MUST NOT be enclosed or covered
with insulation.
The fan is a class II double insulated product and MUST NOT be earthed.
1. Follow the wiring diagram shown.
2. Check all connections have been made correctly and ensure all terminal connections
and supply wires are securely fastened.
3. Ensure the impeller rotates and is free from obstructions.
Accessing the commissioning menu
To configure the fan first remove the grille. With the grille removed the control board is visible
(Fig.7). Do NOT isolate the fan from the power supply as configuration requires power to the
fan; removing the grille will automatically stop the impeller from spinning.
IMPORTANT
Do NOT attempt to remove the circuit board cover (Fig.7). This covers
the high voltage power supply, preventing the risk of an electric shock.
With the cover removed the LED display will show the commissioning menu. There are 3
buttons located below the display; these are used to control the setup process:
The + button is used to increase the value of a setting, the – button is used to reduce the
value of a setting and the X(Mode) button moves to the next setting.
Commissioning menu structure
Display text
Installation Option
Selections
Default
r
-
n
Display rotation*
r
-
n = Default
r
-
y
= Rotated 180
o
Default
b
-
n
Kitchen or Bathroom mode
b
-
n
=
Kitchen
mode
b
-
y = Bathroom mode
Kitchen
d
-
n
Ducted or Wall/Windo kit
d
-
n
=
all/ indo
mode
d
-
y = Ducted mode
Wall/Windo
WIRING
SETUP
+
-
X
r-y

* This setting rotates the display only; the buttons retain their original function. For example; the
mode button is on the right when in normal rotation and on the left when the screen is rotated and
looking at the fan so the display is correctly orientated.
The table shows the settings available to commission the fan. They appear in this order
starting with the bathroom or kitchen mode selection. The available options and default
position for each setting is also shown.
Settings
Installation selection
There are four different installation type settings, kitchen or bathroom and ducted or
window/wall. The difference between bathroom and kitchen mode is shown below, the boost
speeds are higher for kitchen applications. If the fan is installed in a ducted setup changing
the fan to ducted mode will compensate for the reduced airflow due to the higher pressure of
the system. During commissioning select the relevant setting for your installation.
Boost time
The boost setting allows the boost timer to be adjusted from 1-30 minutes, the default is 15
minutes.
Humidity level trigger
The humidity setting defines at what relative humidity the fan will trigger, adjustable from 50%
to 70% rH.
Comfort mode
Comfort mode changes how the fan boosts. Normally the fan will go into boost as soon as an
LS input is detected and over run for the set period when LS is disconnected. In comfort
mode the fan will not boost until the LS has been on for 5 minutes, preventing nuisance
noise. After 5 minutes of LS being on the fan will run in boost as long as LS is on and for the
over run time after LS is switched off. If the LS is switched off before 5 minutes the fan will not
boost. This mode does not affect the pullcord operation, pulling the pullcord will still activate
boost.
b15
Boost time
b01 to b30
–
1 to 30 minutes
15 minutes
h60
Humidity level trigger
h50 to h70
-
50% to 70% relative humidity
60% RH
c
-
n
Comfort mode
c
-
n = normal boost
operation
c
-
y = comfort mode
No
Mode
Trickle
Boost 1
Boost 2
Boost time
Humidity
Kitchen
11
l/s
30 l/s
60 l/s
15 minutes
60% RH
Bathroom
11
l/s
15 l/s
30 l/s
15 minutes
60% RH
Ducted
This adjusts the impeller speed to give the required airflo ith a high duct pressure
Wall/Windo
This adjusts the impeller speed to give the required airflo at a lo duct pressure

Setup example
> > > > > >
> >
Mode button being pressed to scroll through menu. This set up is for a kitchen, in a through the all
installation ith 15 minute boost timer, 60% rH set point and not in comfort mode.
> > > > > >
Mode and up buttons pressed to change the setting to Bathroom and ducted modes
> > > > > >
Up button pressed to change boost time from 15 to 18 minutes
Pull Cord Function
Pull Boost 1 Pull Boost 2 Pull Boost Off
Pulling the pullcord will activate boost 1, a second pull will enter boost 2 and a third pull will
cancel the boost, returning the fan to trickle speed. The pullcord can be used to cancel an LS
activated boost, if the fan is in an LS activated boost pulling the pullcord will first enter boost a
further pull will return the fan to trickle.
Data Logger (ACR60 model)
With the fan powered up; upon removing the cover the display will automatically activate. It
will display the commissioning options. Holding down the Mode button for 5 seconds will open
the data logger menu. Use the mode button to move the display to the next data set.
Data Logger Menu
* When the display is rotated the decimal point will no longer display; eg. 055 represents 5.5KWh
Display text
Description
tot run 00y 00d Total run time in years and days
Tri run 00y 00d Trickle speed run time in years and days
Boo run 00d Boosted run time in days
rhu run 00d Humidity boosted run time in days
tot EnErgy 00.0 Total Energy used displayed in KWh*
24h EnErgy 00 Energy used in last 24 hours displayed in Wh
+
+
+
+
+
X
X
X
X
X

Data Examples
Text scrolling from right to left
In this example the display is showing a total run time of 1 year and 237 days.
Text scrolling from right to left
In this example the display is showing 34Wh of energy consumption in the previous 24h.
Returning to commissioning mode
A further 5 second press of the Mode button will return the fan to the commissioning menu.
WARNING: THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE
ISOLATED FROM THE POWER SUPPLY DURING MAINTENANCE.
1. At intervals appropriate to the installation, the fan should be inspected and cleaned to
ensure there is no build-up of dirt or other deposits.
2. Wipe the inlets and front face with a damp cloth until clean.
The fan has sealed for life bearings, which do not require lubrication.
1. The fan continuously runs in boost:
a. Cause:
i. The room is damp or recently redecorated.
ii. The humidity set point is set too low.
b. Solution:
i. If the room is damp or has recently been decorated, it could take up to 2
weeks for the humidity levels to stabilise. Please leave the fan to dry out
the room and after this period the fan should run normally.
ii. The humidity set point could be set too low. Adjust the humidity set point to
a higher setting. (Setup Section)
2. The fan does not boost when the humidity is high:
a. Cause:
i. The humidity set point is set too high.
b. Solution:
i. Adjust the humidity set point to a lower setting. (Setup Section)
SERVICING AND MAINTENANCE
TROUBLESHOOTING

3. Water is dripping out of the fan when installed in a ceiling:
a. Cause:
i. This is caused by condensation forming on the inside of the ducting and
dripping out of the fan inlet.
b. Solution:
i. This is normal and the fan is designed to handle condensation build up.
However a condensation trap connected immediately after the fan will help
to prevent water dripping into the room.
Fig.2 Continuous boost 1 with no trickle facility. (The fan is internally fused)
Fig.1 Continuous trickle with boost via pull cord. (The fan is internally fused)
Siting
the
fan.



Fig.3. Continuous trickle with boost facility. (The fan is internally fused)
~
N
L
1 Phase Supply
(220-240V 50Hz). FUSE
Switched
Fused Spur
(3A)
LS12V
0V
Controller
Fan
12V D.C
SELV Supply
N L
LS
LS
N
L
2
1
3
Fig.5 Continuous boost 1 with no trickle facility ACR60LV model
Fig.4 Continuous trickle with pullcord boost ACR60LV model
~
N
L
1 Phase Supply
(220-240V 50Hz). FUSE
Switched
Fused Spur
(3A)
LS
12V
0V
Controller
Fan
12V D.C
SELV Supply
NL
LS
LS
N
L
LINK
2
1
3
24v D.C
24v D.C
24V
24V
0
0
+
+

Fig.6 Continuous trickle with boost facility via LS or internal pullcord, ACR60LV model
~ N
LS12V
0V
Controller
Fan
12V D.C
SELV Supply
N L
LS
LS
N
L
2
1
3
24v D.C
24V
0
+

Fig.7. Removing the grille for wiring and setup
Display
1. Loosen the screw at the bottom
of the grille
2. Pull the grille
clear of the screw
and lift away
Circuit board cover
DO
NOT REMOVE
Control Board
INCREASE
Value
REDUCE
Value
MODE
Button
Note:
ACR60 models; do
NOT
attempt to pull off the flat front cover.

AIRTECH ENVIRONMENTAL SYSTEMS
STATHE ROAD, BURROWBRIDGE, SOMERSET, TA7 0RY
Tel : [phone]
477775 A 1117
