Airwheel H3T User manual

- 1 -
USER MANUAL
EN
H3T
- 1 -

- 2 -
Backrest
Backpack (optional)
Battery
Clutch
Motor
Rear wheel
Controller
Armrest
Handrail button
Frame
Footrest
Front wheel
Packing list
Diagram
H3T 1 unit Charger 1 piece
Instruction 1 unit Accessory 1 set
Rear foot (optional)

- 3 -
After completing the above steps, turn on the power. The main power
switch and charging port are located behind the battery compartment
(Picture3-1).
3.Turn on the main power
1-1 1-2
3-1
User Instructions:
Hand mode
Electric
mode
Tie rod of
clutch
Open the wheelchair carton, take out the wheelchair and place it
gently on the  oor, then take out the accessory box at the rear of
the wheelchair (see Picture1-1) and remove the cardboard near
the motor lock. Turn the motor lock to drive mode (see Picture1-2).
Contents in the paper box: a Charger, controller, user manual,
plastic tie and assembling tools etc.
1.Take out the accessory box at the
rear of the wheelchair
Charging port
Main power
switch
The joystick could be installed on the left or right armrest freely, accoridng to user's habit
①Fix the joystick groove with screw and tighten the screw (Figure 2-1)
②Insert the joystick into the groove and tighten the screw. (Figure 2-2)
③Connect the wires and  x the wires with cable tires.(Figure 2-3)
2.Install the joystick
2-1 2-2 2-3
The joystick groove
The joystick
assembly
The joystick wiring
Screw

- 4 -
Installation and usage
When removing the battery case,  rst make sure that the main power
switch is off. Unplug the battery bus connector (as shown in Figure 1-1),
press the spring clip and pull out the battery case (Figure 1-2); when the
battery is installed, insert the battery box directly until the spring clips the
battery box, then put Insert the battery bus plug into the battery bus jack.
Note: 1. Pay attention to the front and back of the battery case, and the
side with the sticker facing up.
2. When the battery bus is plugged in and out, please align the
card slot with the protrusion (as shown in Figure 1-3).
3. Do not touch the main wires and charging port with metal
objects when the main battery switch is turned on, to prevent
damage to accessories and danger.
If the wheelchair cannot be folded automatically due to a
malfunction of the electrical parts, please use the given tools to
remove the screws located at the rear of the wheelchair (see
Picture 4-2) to fold/unfold it manually.
1. Battery disassembly instructions
Notes:
4-2
Screw
1-1
1-3
1-2
Main power
switch
bus bump
bus plug
shrapnel
top sticker
Press and hold the up/extension button 1 on the controller for 3
seconds in the off state (as shown in Figure 4-1). When the controller
panel lights up. Release the button when the “Drip” sound appears,
wait for the wheelchair to automatically expand. After the expansion
is completed, press ③ to exit the expansion and contraction.
Turn on the power switch ④and start to use (Figure 4-1).
4.Unfold the wheelchair
4-1
Power Switch
Speed up /
Unfold
Speed down / Fold
Stop folding /
unfolding
④
①
②
③

- 5 -
2.Main power switch
3.Battery charging instructions
Tip: Please turn off power to prevent the battery from over-discharging if riders don’t use it.
When the indicator is on, H3T is powered on, and when it's off,H3T is powered off.
Please connect the charger to the wheelchair before connecting it to
the AC power while charging. Please align the notch on the charger
(See Picture 3-1) with the protruding part of the charging port (See
Picture 3-2), insert and tighten the xing cap for connection. Please
loosen the xing cap before removing the charger from the wheelchair. 3-1 3-2
notch protruding part
Warning
Please do not throw away the waste battery, so as not to pollute the environment. The waste lithium battery of the product is to be
recycled by the enterprise or dealer, and the government designated outlets.
4. Left and Right Joystick Exchange
4-3 4-4 4-5 4-64-1 4-2
Disconnect the joystick cable (Figure 4-1) and loosen the screw to remove the joystick (Figure 4-2). Remove notch of one side
of the joystick (Figure 4-3), turn it 180 degrees to the other armrest position, tighten the screw to secure the joystick (Figure
4-4), then insert the joystick into the notch. Attach the screw (Figure 4-5), reconnect the joystick wiring, and nally attach the
joystick cable with the cable ties (Figure 4-6).
The joystick
groove
The joystick
assembly
Screw

- 6 -
Main Technical Parameters
Size 1076X620X987mm Item weight ~29.6kg（without battery）
Folding size 842X620X420mm
（controller size not included）Max. load 130kg
Rotation radius 1.2m Frame Aluminum alloy 6061
Standard max. speed 6Km/h Climbing capacity about 9°
Braking performance ≤1.5m Slope capacity about 9°
Charging time about 5H Battery lithium 25.2V 524Wh
Reduction gearbox worm and gear
reduction ratio 1: 32 Applicable temperature -15℃~50℃
Over-obstacle capacity ≥40mm Trench crossing capacity 100mm
Front wheel 8 inch Rear wheel 12.5 inch, inatable tire
Battery weight 3kg
Motor Dual-drive brush motor with clutch pull rod. Power: 200W; voltage: 24V;
revolving speed: 4000rpm
Automatic folding
function a key to automatically contract and extend
Specications

- 7 -
Horn Button
Joystick
Press the button the buzzer will buzz; Release the button,
the buzzer stop buzzing.
Horn Button
Controller instruction
Headlight Switch
Power Switch
Speed indicator
Speed up / Unfold
5-level LED power indicator
Speed down / Fold
Stop folding / unfolding
Make sure the power button on the battery box is turned on
and the wheelchair is unfolded, then press the power switch
on the controller to be ready to drive or remote control.
Press it again to shut down the ready mode.
Note: The power switch on the controller cannot be turned
on when the wheelchair is completely folded. Please turn
on the power on the battery box rst, unfold the wheelchair,
and turn on the power switch on the controller to be ready
to drive.
Power Switch
Make sure both the power on the battery box and on the
controller are turned on, then press the headlight switch
to turn on the headlight, and press it again to turn off.
In the power-off state, press the button over 2 seconds,
the H3T enters the extending/contracting mode. Release it
to contract.
In the extending/contracting mode, click the button to stop
contracting if it is contracting. When extending stops, click
it to contract.
In the ready mode, remote control mode and riding mode,
click the gear button to decrease one gear.
Headlight switch
Speed down / Fold

- 8 -
Press the speed up button, the LED lights of speed
indicator will be on one by one.
Press the speed down button, the LED lights of speed
indicator will be off one by one.
It shows the percentage of the remaining battery capacity.
Each LED light represents 20% of the battery capacity. The
LED lights will be off one by one after consumed every 20%
of the battery. For example, it means 40% battery consumed
already when two LED lights are off. Better charge the battery
when 2 or 3 LED lights are off to prolong the battery life. It is
prohibited to drive the wheelchair when there is only one LED
light on, otherwise, it will cause damage to the battery due
to over-discharge. The accuracy of the power indicator will
decrease after daily use.
Speed indicator
5-level LED power indicator
In the power-off state, press the button over 2 seconds,
the H3T enters the extending/contracting mode.
Release it to extend.
In the extending/contracting mode, click the button
to stop extending if it is extending. When contracting
stops, click it to extend.
In the ready mode, remote control mode and riding
mode, click the gear button to increase one gear.
In the extending/contracting mode, click the button to stop
extending or contracting. It enters the shutdown state.
Speed up / Unfold Stop folding / unfolding
Shutdown state: the circuit connection is complete, the power switch in the battery pack is turned on. But the on-off
button in the control box isn't pressed and the indicator light isn't on.
Standby state: press the on-off button in the control box, the indicator light will be on, but without any man-made
operation.
Riding state: press the on-off button in the control box, the indicator light will be on, and use the operating lever to
make it move.

- 9 -
Forward:
Push the operational rocker forward and
the H3T will move forward.
Backward:
Pull the operational rocker backward and
the H3T will move backward.
Leftward:
Push the operational rocker leftward and
the H3T will move to the left.
Rightward:
Push the operational rocker rightward and
the H3T will move to the right.
The controller controls H3T to go forward, backward, and turn left and right, and to accelerate, decelerate and brake.
After turn on the switch button, push the rod forward vertically and H3T moves forward. More forward, the faster the speed.
Release the rod to slow down and when fully released, the rod is reset and H3T stops and is in the braking state. Pull the rod
backward, H3T moves backwards, more backward, the faster the speed to backward.Release the rod to slow down and when
fully released, the rod is reset and H3T stops and is in the braking state.
Similarly, turn the rod to left or right, H3T will turn left or right. Pushing more left or right, the faster the speed towards left or
right. Release the rod to slow down and when fully released, the rod is reset and H3T stops and is in the braking state.
How to use the controller

- 10 -
Pull the tie rod to the open position, then the brake of H3T will not work, the weelchair can be pushed by people(no matter
the H3T is power on or power off, people can do it), when people pulf the tie rod to the close position, nobody can push the
H3T.
Tie rod of clutch
Hand mode Hand mode
Electric mode Electric mode
Tie rod of clutch
Hand mode, pull it
counterclockwise to
brake.
Electric mode, pull it
clockwise to brake.
Hand mode, pull it
clockwise to brake.
Electric mode, pull it
counterclockwise to
brake.
Operate tie rod of clutch
The clutch lever must be in electric mode, it means the H3T is braking, people can drive the H3T.
To ensure the security of people and H3T.it is prohibited to use this function when the H3T uphill or downhill.
Tie rod of clutch
Hand mode, pull it
clockwise to brake.
Electric mode, pull it
counterclockwise to
brake.

- 11 -
Rear support leg (optional)
8-1
8-3
8-2
8-4
Rear
support leg
button
vertical tube
Rear
support leg
8-5
rear support
leg
Install the legs:
Press down on the rear leg button and hold it (Figure 8-1), insert the leg into the riser (Figure 8-2), and release the rear leg
button When the rear leg hole is aligned with the vertical tube hole. Then the installation is completed. Disassembling the rear
support leg: press down and hold the button and pull out the foot.
Note: When the rear support leg wheel is mounted downwards, it can be used as an anti-tip wheel (Picture 8-3); when the rear
support leg wheel is mounted upwards (Picture 8-4), it can be used as a rear leg and a rear support. See the  nal use of the it
(Picture 8-5).

- 12 -
Get familiar with local trafc rules.
H3T belongs to non-motor vehicle, being designed especially for the old and the people with mobility problem. No driving
license is needed in accordance with trafc law, but driver of H3T should observe the same trafc rules that are applied to
pedestrians. Please drive H3T in pedestrian lane or bike lane.
①Get familiar with all the trafc signals marks used for pedestrians.
②Do not turn direction or cross road suddenly when driving on road.
1.
2.
3.
4.
Safety
Please read User Manual carefully and follow riding requirements during the H3T ride. Please do not use it until riders
have read User Manual carefully and learned the performance well. Do not lend it to those who cannot manipulate H3T.
Important Note:
Attentions before operation:
You need lots of practice to grasp the skill before you ride H3T safely. If you are not skilled, or fail to follow the user guide
of this product, it may cause rider or others injury or property loss. Our company only takes the responsibility for product
defects or damage, and we are NOT responsible for physical injury or property loss related with using products.
Operation Practice.
Before your rst time to operate this H3T, please get familiar with all the functions of this vehicle. Practice the operations like
moving forward, increasing speed, reducing speed, stopping, moving backward, moving uphill, moving downhill and turning
direction in a safe pace with less people and good road condition. Then you can ofcially drive on road after getting familiar
with all these operations.
If possible, please nd a person familiar with this H3T to accompany you to ensure your safety during rst on-road
operation.

- 13 -
Never expose the electrical system of this vehicle to humid environment (such as rain, snow or fog), do not wash
this vehicle with water, which will damage the electrical system. If the H3T is wet, it could only be used after being
dried and conrmed for good condition.
Do not drive the H3T under hostile weather conditions, such as rain, snow, fog, strong wind, temperature lower
than -20℃or higher than 40℃.The electrical system may be damaged under those conditions to cause failures
in control.
Do no drive the H3T on desert, beach, muddy road, road with pooled water, iced road, too smooth road or saline
and alkaline land to prevent the driving property of this vehicle.
Do not drive the H3T after you drink, are exhausted or are not consciously clear to guarantee your safety.
Please conrm that the operator of this H3T is not suffered from any mental disease or other diseases that may attack during
driving and result in the driver's incompetence of driving the vehicle safely.
If you are taking medicine, please conrm from your doctor that if such medicine will have adverse inuence on your ability to
operate the H3T.
Check the vehicle condition to conrm if the brake and various properties are normal, if the seat is locked and ift the charge
volume is enough.
Do not ret this H3T without the authorization of our company
5.
6.
7.
8.
9.

- 14 -
H3T is designed with only one seat not allowing for taking passengers.
H3T is not intended to be used for moving or loading cargos.
The operator should sit on the seat and grip the handle for operation.
Do not drive in a zigzag manner, take a sudden turn at high speed or incline your body to prevent H3T inclination to one
side.
Please high concentrate and drive slowly on uneven or soft road (such as grassland), when making a turn, on streets with
a lot of trafc, in shopping centers or parks.
Do not use wireless communication devices such as mobile phone during driving. These devices could only be used when
you stop the H3T in a safe place and cut off the power supply.
When moving backward, pay attention to road conditions and pedestrians at a slow speed.
Drive at a slow speed when getting out of door or elevator. It is not permitted to sit on the H3T on escalator.
Keep highly concentrated, fasten the safety belt and drive straightly at a slow speed when driving uphill or downhill. It is
not permit to drive the H3T across slopes exceeding the limit of this vehicle.
Do not cross the slope exceeding 5°at a high speed.
Do not cross over obstacles or steps higher than 4cm, which may impede the H3T from moving forward. At this condition,
release operational handle immediately.
Do not cross any gap wider than 10cm. Drive the H3T straightly when crossing gap less than 10 cm in width.
Follow trafc rules when driving through cross street and do not run a red light. When passing railway, please stop to
observe the surrounding conditions, and then drive across the railway slowly in a direction perpendicular to tracks to avoid
dropping into the gap between different sleepers.
Do not frequently lock or unlock the electrical door. Do not frequently start or stop the H3T.
Do not lend your H3T to anyone who is not familiar with or has never used this vehicle. Do not fet children paly with
electrical door lock or operational handle.
Do not use this vehicle with too much load (higher than 130KG).
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
Attentions during Operation:

- 15 -
If you are not going to use the H3T for over 48 hours, Please turn off the power switch.
When bring H3T to other vehicles, make sure the battery is xed.
1.
2.
When you release the operation handle during driving and the handle has returned to the central position, but the H3T
does not stop, please lock the electrical door as soon as possible and contact the nearest dealer.
Attentions after Operation:
Battery usage:
Auxiliary charge: such as short delivery time, users can directly use the battery.If the delivery time is longer (2 months or longer),
the battery will lose power during storage and transport. It is better to charge the battery before use. To charge it requires plugging
the exclusive charge to the battery charging hole and connecting AC100-240V power source for 5 hours until the charger is full.
The normal charge of the battery: the operation of AIR is also the discharge process of the battery. The battery should be charged
immediately after the use of the power-assisted vehicle.
Please turn off the power if not riding.
The connectors of the battery box should be xed tightly according to the requirements (the battery box connecting line has been
reliably connected before ex-factory). Loosened or wrong connection will cause the related parts abnormal and lead to serious
damage.
1.
2.
3.
Lithium batteries can not be close to open re or high temperature heat source, can not be thrown into water and can not be
exposed in the sun in high temperature season.
Do not disassemble and decompose, as the internal part of them lithium battery has been packaged intactly.
The waste lithium battery of the product is to be recycled by the enterprise or dealer, and the government designated outlets. Please
do not throw away the waste battery, so as not to pollute the environment.
4.
5.
6.

- 16 -
Airwheel reserves the right of nal interpretation of all the terms and conditions of this User Manual.
The driver should fasten safety belt after sitting on the seat.
Press the starting button and then the 5-scale charge volume display will be on or twinkles slowly,
Push the rocker slowly forward until you hear the sound of electromagnetic brake. At this time, the H3T should move forward.
Similarly, push or pull the rocker backward/leftward/rightward, the H3T will move
backward/leftward/rightward.
Adjust the speed scale button to regulate driving speed according to road condition, surrounding conditions and personal
preference.
When you want to stop, release the operational rocker and it will turn to central position. Then you could hear electromagnetic
sound soon, it means that the H3T is braking steadily.
Pay attention to surrounding conditions when moving backward. Slowly pull the rocker backward and the H3T
will move backward.
1.
2.
3.
4.
5.
6.
Charger usage:
Carefully check whether the charger's rated input voltage (AC100-240V) and the grid voltage is consistent.
When the vehicle needs charging,rst connect the battery to the charger, and then connect the charger to AC power source .
The charging indicator is red meaning it is charging. When it turns green, it will take 15 minutes to be fully charged. The charging time is
about 5 hours (depending on the quantity of remaining battery).
1.
2.
When charging, please put it in the safe place where children can not touch.
It is not advised to use it when it is not fully charged.
Do not use other brands of chargers, and other brands of batteries are not suitable for the use of the charger.
Do not disassemble, as the charger contains high voltage circuit.
Prevent liquid and metal particles from penetrating into the inside and be aware of falling and impact, so as not to
cause damage during use and storage.
When charging, do not afx any items.
It requires to charge it fully and turn off power before storage. Charge it every three months (at most).
Matters needing attention in charging:
How to Drive this H3T:
1.
2.
3.
4.
5.
6.
7.

- 17 -
The four corners' Velcro are tied to the frame
respectively (see right Figure), to complete the
installation, and it can also be removed.
Backpack (optional)
Handrail precautions
Press and hold the armrest
button (see Figure 9-1) while
pulling the armrest up 90° (see
Figure 9-2)
Reset the armrest down and
complete the  xing (see Figure
9-3), which is normal use
state.
9-1 9-2 9-3 9-4
Handrail
button
Normal use state

- 18 -
Remote control blutooth pairing
1.Put AAA battery into the handle, power on, The green light 󽗊ashes once in an instant;
2.Let the remote control close to the wheelchair in 1 meter, Short press "Power button", The green light is always on,
then press the “@” button quickly, the green light starts to breathe slowly and enters the pairing (do not move the
joystick during the pairing process);
Bluetooth remote control(if have this optional)
Joystick
@ (pairing)
C (gear-high)
B (folding-shrinking)
D (gear-low)
Power button
Indicator light
A (fold-extension) ① Upper side
big button (horn)
② Lower side big
button (headlights)

- 19 -
3.After the pairing is successful, the green light 󽗊ashes quickly. After a few seconds, turn on the wheelchair and enters
the remote control mode. Now the remote control stops 󽗊ashing, and it lights 0.5s and then goes o󽗈.
Push the joystick, it could control the wheelchair to run, stop and turn normally, and the remote control indicator
light goes o󽗈, short press the “upper side big button”, the horn sounds, short press the “downside big button”,
the headlights turn on; The green light 󽗊ashes once every 5 seconds when it is in remote control mode.
Short press button“C”, the wheelchair switches to highest speed (5), and press button“D”, the wheelchair
switches to lower speed (2).
Short press or long press "Power button" and release, the wheelchair joystick light will be o󽗈 and power o󽗈, then
short press or long press "Power button" and release, the wheelchair will automatically turn on within 3~5 seconds;
After the above steps, short press or long press the “power button” and release, the wheelchair will be turned o󽗈.
At the moment, press and hold the “B” button, the wheelchair automatically enters the folding mode and starts
to fold, then release the button and short press “B”, the folding pauses . and then short press "A", the wheelchair
will be unfolded. After the expansion is completed, short press the "@" button, the wheelchair exits the folding
mode, the joystick turned o󽗈 and the light is o󽗈.
1.
2.
3.
4.
1.
2.
3.
Short press or long press "Power button" and release, the wheelchair is power on, long press "@" button, after a few
seconds, the red light 󽗊ashes once, it exits the remote control mode and goes to sleep mode;Short press the “Power
button”, the remote control will wake up, the green light will 󽗊ash quickly, the remote control will automatically
connect the wheelchair after a few seconds, and the wheelchair will automatically turn on.
After power on, push the Bluetooth remote joystick and release, from now on, about 2 minutes later, the remote
control automatically enters the sleep state, and the red light 󽗊ashes once.
When the dry battery voltage is lower than 2.1V, the Bluetooth remote control will be in a low battery state, and the
red light will continue to 󽗊ash.
How to use the blutooth remote control
Bluetooth remote indicator

- 20 -
App download(optional)
Scan QR code to download
*Applicable to Android 4.3 or higher, iOS 7.0 or higher.
APP Instructions
1. Turn on H3T power button, and start App as well as Bluetooth.
2. Click the search button and do as the follows to connect (verify password is 11111111).
3. Refer to ofcial website or give calls for details.
Click the Intelligent
scooter in the App
interface.
Click the search button
or .
Search Airwheel nearby,click
the searched Airwheel
model to connect.
Input the verify
password: 11111111 to
connect.
Intelligent helmet
Intelligent scooter
Search Devices A
Airwheel Bluetooth password authenticatio
cancecomfirm
Input verify password 1111111
