Invacare Eliminator? Manual

Owner's Operator And Maintenance Manual
DEALER: THIS MANUAL MUST BE GIVEN TO THE USER
OF THE WHEELCHAIR.
USER: BEFORE USING THIS WHEELCHAIR, READ THIS
MANUAL AND SAVE FOR FUTURE REFERENCE.
®
Eliminator
EliminatorOSR

2
WARNING
DO NOT OPERATE THIS EQUIPMENT WITHOUT FIRST
READING AND UNDERSTANDING THIS MANUAL. IF YOU ARE
UNABLE TO UNDERSTAND THE WARNINGS AND
INSTRUCTIONS, CONTACT A QUALIFIED TECHNICIAN OR
TOP END CUSTOMER SUPPORT AT [phone]
BEFORE ATTEMPTING TO USE THIS EQUIPMENT - OTHERWISE
INJURY AND/OR EQUIPMENT DAMAGE MAY RESULT.
SAVE THESE INSTRUCTIONS.
W
A
R
N
I
N
G
SPECIAL NOTES
WARNING/CAUTION notices as used in this manual apply to hazards or unsafe practices
which could result in personal injury or property damage.
NOTICE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NO-
TICE.
RACING CHAIR USER
As a manufacturer of racing chairs, Invacare Top End endeavors to supply a wide vari-
ety of racing chairs to meet many needs of the end user. However, final selection of the
type of racing chair to be used by an individual rests solely with the user and his/her
health care professional capable of making such a selection.
RACING CHAIR TIE-DOWN RESTRAINTS AND SEAT POSITIONING STRAPS
Invacare Top End recommends that racing chair users NOT be transported in vehicles of
any kind while in racing chairs. As of this date, the Department of Transportation has not
approved any tie-down systems for transportation of a user while in a racing chair, in a
moving vehicle of any type.
It is Invacare Top End’s position that users of racing chairs should be transferred into
appropriate seating in vehicles for transportation and use be made of the restraints
made available by the auto industry. Invacare Top End cannot and does not recom-
mend any racing chair transportation systems.
AS REGARDS RESTRAINTS - SEAT POSITIONING STRAPS - IT IS THE OBLIGATION OF THE DME
DEALER, THERAPISTS AND OTHER HEALTH CARE PROFESSIONALS TO DETERMINE IF A SEATING
POSITIONING STRAP IS REQUIRED TO ENSURE THE SAFE OPERATION OF THIS EQUIPMENT BY
THE USER. SERIOUS INJURY CAN OCCUR IN THE EVENT OF A FALL FROM A RACING CHAIR.
Invacare Top End recommends Seat Positioning Straps. Not only to serve as protection
against a fall but also to insure minimal movement in the seat cage.
WARNING

3
TABLE OF CONTENTS
SPECIALNOTES ..................................................................................................................................... 2
SPECIFICATIONS .................................................................................................................................... 4
PROCEDURE 1 - GENERAL GUIDELINES ............................................................................................. 5
STABILITY ................................................................................................................................................ 5
OPERATINGINFORMATION ..................................................................................................................... 5
TIREPRESSUREANDINFORMATION ..................................................................................................... 6
WEIGHTTRAINING .................................................................................................................................. 6
WEIGHTLIMITATION ................................................................................................................................6
SAFETY/HANDLINGOFRACINGCHAIRS ................................................................................................. 7
PROCEDURE 2 - SAFETY INSPECTION ................................................................................................ 9
SAFETYINSPECTIONCHECKLIST .......................................................................................................... 9
TROUBLESHOOTING ........................................................................................................................... 10
MAINTENANCE ...................................................................................................................................... 10
PROCEDURE 3 - UPHOLSTERY/FOOTREST.......................................................................................11
ADJUSTING/REPLACINGBACKUPHOLSTERY.......................................................................................11
ADJUSTING/REPLACINGLEGCUSHIONWITHFOOTPOUCH ................................................................11
REPLACINGSEATSLINGUPHOLSTERY ............................................................................................... 12
INSTALLINGTHEPLASTICFOOTPLATE ................................................................................................ 12
INSTALLING/USING/ADJUSTINGTHEFIXEDFOOTREST........................................................................ 13
PROCEDURE 4 - WHEELS ................................................................................................................... 14
INSTALLINGREARWHEELS.................................................................................................................. 14
REPAIRING/REPLACINGREARWHEELTIRE/TUBE .............................................................................. 14
REPLACINGPUSHRIMS ........................................................................................................................ 14
INSTALLING/REMOVINGFRONTWHEEL ............................................................................................... 14
REMOVING/INSTALLINGFORK .............................................................................................................. 15
DETERMININGTOEIN/TOEOUT ........................................................................................................... 16
ADJUSTINGTOEIN/TOEOUT-ELIMINATORONLY ................................................................................ 16
REPLACINGCAMBERINSERTS-ELIMINATORONLY ............................................................................ 16
PROCEDURE 5 - COMPENSATOR ...................................................................................................... 17
ADJUSTINGCOMPENSATORFORSTRAIGHTSANDTURNS ................................................................ 17
REPLACINGCOMPENSATOR ............................................................................................................... 17
PROCEDURE 6 - BRAKES ................................................................................................................... 18
ADJUSTINGHANDCALIPERBRAKESENSITIVITY.................................................................................. 18
ADJUSTING/REPLACINGHANDCALIPERBRAKEPADS ........................................................................ 18
LIMITED WARRANTY ........................................................................................................................... 19
TABLE OF CONTENTS
T
A
B
L
E
O
F
C
O
N
T
E
N
T
S

4
SPECIFICATIONS
SPECIFICATIONS
S
P
E
C
I
F
I
C
A
T
I
O
N
S
SPECIFICATIONS ELIMINATOR ELIMINATOR OSR
Upper Inside
FrameWidth: Custom Custom
Seat Style: StandardorKneelPosition Standard orKneelPosition
Cage Style: I,VorOpenV I,V,orOpenV
Lower Inside
Seat Width (seat cage): Inside seat measurement to allow for Inside seat measurement to allow for
hip space - Snug is preferred hip space - Snug is preferred
AxlePosition
(from rear of
racingchair): 5 to 8-inches 5 to 8-inches
Seat Height/Angle
(height from floor)
Rear: 16,17,18or19-inches 16,17,18,or19-inches
Front: StandardPosition-15,16,17,or18-inches StandardPosition-15,16,17,or18-inches
KneelPosition-SeatAngle:10°,15°,or20° KneelPosition-SeatAngle:10°,15°,or20°
Overall Length
(front wheel to
rear wheel): 56 to 74-inches 68 to 74-inches
Camber 11to15-degrees 11to15degrees
Rear Wheel Size
(diameter): 700C or 26-inch 700C
Rear Axle (diameter): 1/2-inch 1/2-inch
Pushrims
(diameter): 13 to 16-inches 13 to 16-inches
Front Wheel Size
(diameter): 18 or 20-inches (20-inches Standard) 20-inches(carbonfiber optional)
Hand Brake: Caliper Caliper
Weight: 17 lbs. 17
ShippingWeight:
(approx.)* 27 lbs. 27
Options: FixedFootrest,AeroBars,Aluminum AluminumKneePlate, Aluminum
SolidSeat,AluminumKneelPlate Seat, FixedFootrest,Helmet,
CordlessSpeedmeter,AdditionalStraps,
Cushion, Racing Suit, Wheel Bag,
Carbon Fiber Wheels,
Tire Coated Pushrims
*60-inch Length Eliminator with complete package.

5
GENERAL GUIDELINES
G
U
I
D
E
L
I
N
E
S
PROCEDURE 1
G
E
N
E
R
A
L
This Procedure includes the following:
Stability
Operating Information
Tire Pressure
Weight Training
Weight Limitation
Safety/Handling of Racing Chairs
BackUpholstery ●●
●●
●✓✓
✓✓
✓✓✓
✓✓
✓
Knee/Foot Position ✓✓
✓✓
✓●●
●●
●✓✓
✓✓
✓
UserCondition ✓✓
✓✓
✓✓✓
✓✓
✓●●
●●
●
BackUpholstery Knee/FootPosition UserCondition
STABILITY STABILITY WARNING
The tautness of the back upholstery, knee and/or foot position, as well as the user
condition directly relate to the stability of the racing chair. Any change to one (1) or
any combination of the three (3) may cause the racing chair to decrease in stability.
NOTE: When changes to the left hand column occur, follow across the chart and refer to the ✓ procedure to
maintainthe proper stability,safetyand handling of the racingchair.
OPERATING INFORMATION GENERAL WARNINGS
Wear your helmet at ALL times when riding the Eliminator or Eliminator OSR.
The end-user is responsible for normal maintenance and maintaining the Eliminator or
Eliminator OSR in proper operating condition.
The manufacturer is not responsible for failure, damage or injury caused by improper
operation or maintenance by the end-user.
To determine and establish your particular safety limits, practice bending, reaching and
transferring activities in the presence of a qualified healthcare professional BEFORE
attempting active use of the racing chair.
DO NOT sit erect or lean over the top of the back upholstery to reach objects behind
you as this may cause the racing chair to tip over.
If the racing chair is equipped with kneeling upholstery, always ensure the foot pouch
is securely latched to the back upholstery. Otherwise, injury can occur.
DO NOT shift your weight or sitting position toward the direction you are reaching as
the racing chair may tip over.
Before attempting to transfer in or out of the racing chair, every precaution should be
taken to reduce the gap distance.
Operation of the Eliminator or Eliminator OSR is subject to ALL traffic rules and regulations.

6
GENERAL GUIDELINES
PROCEDURE 1
G
U
I
D
E
L
I
N
E
S
G
E
N
E
R
A
L
GENERAL WARNINGS (CONTINUED)
Care must be taken when operating the Eliminator or Eliminator OSR on roads, streets or
highways.
Give pedestrians the right of way.
DO NOT climb, go up or down ramps or traverse slopes greater than 9O.
DO NOT attempt to move up or down an incline with a water, ice or oil film.
NEVER use the hand caliper brake for immediate stops. Using the hand caliper brake
for immediate stops can make the front wheel lock up (skid) causing the front tire to
blow and go flat. If needing to stop immediately, grab the rear wheels with GLOVED
hands.
Before using the racing chair, inspect the hand caliper brake and hand caliper brake
pads for proper operation and wear. Replace if worn.
DO NOT attempt to ride over curbs or obstacles. Doing so may cause your racing chair
to turn over and cause bodily harm or damage to the racing chair.
DO NOT use parts, accessories, or adapters other than those authorized by Invacare
Top End.
DO NOT stand or transfer on the frame of the racing chair.
Invacare strongly recommends that the racing chair be boxed or otherwise protected
before transporting by an airline carrier.
DO NOT use racing chair on an indoor training roller, otherwise the warranty will be
void.
TIRE PRESSURE AND INFORMATION
DO NOT use your racing chair unless it has the proper tire pressure (p.s.i.). DO NOT
overinflate the tires. Refer to manufacturers recommendations on the sidewall of the
tire. Failure to follow these suggestions may cause the tire to explode and cause bodily
harm.
DO NOT continue using your racing chair if tires are bare or flat. The racing chair is not
stable with bare or flat tires, as tire may roll off and cause the racing chair to crash.
Bare tires may result in a flat which may cause the racing chair to crash or veer to one
side.
CORIMA CARBON FIBER WHEELS ONLY - Corima Wheels MUST NOT be used when tires
are bare or flat. If a flat wheel occurs, STOP IMMEDIATELY. Otherwise, the wheel war-
ranty will be void.
WEIGHT TRAINING
Invacare Top End DOES NOT recommend the use of its racing chairs as a weight training
apparatus. Invacare Top End racing chairs have NOT been designed or tested as a
seat for any kind of weight training. If occupant uses said racing chair as a weight
training apparatus, Invacare Top End shall NOT be liable for bodily injury and the war-
ranty will be voided immediately.
WEIGHT LIMITATION
The Invacare Top End Eliminator and Eliminator OSR chairs have a weight limitation of
250 lbs. (113.5 kg.).

7
GENERAL GUIDELINES PROCEDURE 1
G
U
I
D
E
L
I
N
E
S
G
E
N
E
R
A
L
SAFETY/HANDLING OF RACING
CHAIRS
“Safety and Handling” of the racing chair requires the close
attention of the racing chair user as well as the assistant.
This manual points out the most common procedures and
techniquesinvolvedinthesafeoperationandmaintenance
oftheracingchair.Itisimportanttopracticeandmasterthese
safe techniques until you are comfortable in maneuvering
aroundthefrequentlyencounteredarchitecturalbarriers.
Usethisinformationonlyasa“basic”guide.Thetechniques
that are discussed on the following pages have been used
successfully by many.
Individualracingchair usersoftendevelopskills todealwith
daily living activities that may differ from those described in
thismanual.InvacareTopEndrecognizesandencourages
each individual to try what works best for him/her in over-
comingarchitecturalobstaclesthattheymayencounterhow-
ever,ALLWARNINGSandCAUTIONSgiveninthismanual
MUSTbefollowed.Techniquesinthismanualareastarting
pointforthenewracingchairuserandAssistantwith“safety”
asthemostimportant consideration forall.
Stability and Balance
To assure stability and proper operation of your racing chair,
you must at all times wear your seat positioning strap and
maintainproperbalance.Yourracingchairhasbeendesigned
toremainuprightandstableduringnormalracing/trainingac-
tivitiesaslongasyoudonotmovebeyondthecenterofgravity.
WARNING
DO NOT shift your weight or sitting posi-
tion toward the direction you are reach-
ing as the racing chair may tip over.
Virtually all activities which involve movement in the racing
chairhaveaneffectonthecenterofgravity.
A Note to Racing Chair Assistants
When learning assistance techniques for the Eliminator or
Eliminator OSR, have an experienced assistant help you
beforeattemptingitalone.
WhenyouareassistingwiththeEliminatororEliminatorOSR
remember to use good body mechanics. Keep your back
straightandbendyourkneeswheneverliftingorpositioningthe
Eliminator or EliminatorOSR fortheend-user.
WARNING
DO NOT attempt to lift a racing chair by lifting
on any removable (detachable) parts. Lift-
ing by means of any removable (detachable)
parts of a racing chair may result in injury to
the user or damage to the racing chair.
Also,beawareofanyremovable(detachable)parts.These
mustNEVERbeusedforhand-holdorliftingsupports,as
they maybeinadvertentlyreleased, resultinginpossible
injury to the user and/or assistant(s).
When learning a new assistance technique, have an ex-
periencedassistanthelpyoubefore attempting it alone.
Percentage of Weight Distribution
WARNING
The tautness of the back upholstery, knee
and/or foot position, as well as the user con-
dition directly relate to the stability of the
racing chair. Any change to one (1) or any
combination of the three (3) may cause
the racing chair to decrease in stability.
Manyactivitiesrequiretheracingchairownertoreach,bend
and transfer in and out of the racing chair. These move-
mentswillcauseachangetothenormalbalance,thecen-
terofgravity,andtheweightdistribution oftheracingchair.
Todetermineandestablishyourparticularsafetylimits,prac-
ticebending,reachingandtransferring activities in several
combinationsinthepresenceofaqualifiedhealthcarepro-
fessionalBEFOREattemptingactiveuseoftheracingchair.
Proper positioning is essential for your safety and perfor-
mance of the racing chair.
Hand Caliper Brake
WARNING
NEVER use the hand caliper brake for im-
mediate stops. Using the hand caliper brake
for immediate stops can make the front
wheel lock up (skid) causing the front tire to
blow and go flat. If needing to stop immedi-
ately, grab the wheels with GLOVED hands.
Thehandcaliperbrakeisdesignedformanagingsafeopera-
tionoftheracingchairatspeedsgreaterthanten(10)m.p.h.
Transferring To and From Other Seats
WARNING
BEFORE attempting to transfer in or out of
the racing chair, every precaution should
be taken to reduce the gap distance.
The tautness of the back upholstery, knee
and/or foot position, as well as the user con-
dition directly relate to the stability of the
racing chair. Any change to one (1) or any
combination of the three (3) may cause
the racing chair to decrease in stability.
KNEELING SEAT UPHOLSTERY: Ensure that feet
slide evenly into the foot pouch and avoid
the rear wheel spokes. Ensure that the foot
pouch is securely latched to the back up-
holstery. Otherwise, injury can occur.

8
NOT THIS
DO THIS
Position racing chair as close as possible to the de-
sired object. Reach back only as far as your arm
will extend without changing your sitting position.
STEP 6: Strap
feetonto the
footplate.
STEP 7: Strap
the knees up
into a safe and
comfortable
position.
NOTE: Once
seatedinthe
racingchair,
move your feet
back as close as
possible to the
axle as you feel
comfortable and
tightentheknee
strap.
STEP 1: Shift body
weight to the edge of
theracingchairuphol-
stery closest to the
racingchair.
STEP4:
PlaceRIGHT
handonthe
wheelchair
frame.
NOTE: Some racers will rest on the frame cage of the
racing chair half way through the transfer and move
the RIGHT hand to the right side of the frame.
STEP 3:
PlaceLEFT
handon the
framecage.
STEP 5: Lift
andshift
weightinto
racingchair
upholstery.
STEP 2: PlaceLEFT
legthroughthe open-
inginthe framecage.
KNEELING UPHOLSTERY TRANSFER
STEP 1: Shift body
weight to the edge of
thewheelchairuphol-
stery closest to the
racingchair.
STEP 7:
Liftand
shiftweight
intoracing
chair
upholstery.
NOTE: Some racers will rest on the frame cage of the
racing chair half way through the transfer and move
the RIGHT hand to the right side of the frame.
STEP 2: Place
LEFTleg ontop
ofthe LEFT
cageframe.
STEP 5:
PlaceLEFT
handon the
framecage.
STEP 3:
StartRIGHT
leg into the
kneeling
upholstery
andUNDER
the seat
sling.
STEP 4:
StartLEFT
leg into the
kneeling
upholstery
andUNDER
the seat
sling.
STANDARD UPHOLSTERY TRANSFER
Positionthechairascloseaspossiblealongsidetheseat
to which you are transferring. Shift body weight into seat
with transfer.
Reaching, Bending - Backwards
WARNING
DO NOT sit erect or lean over the top of
the back upholstery. This will change your
center of gravity and may cause you to
tip over.
GENERAL GUIDELINES
PROCEDURE 1
G
U
I
D
E
L
I
N
E
S
G
E
N
E
R
A
L
NOTE: Invacare Top End strongly recommends an ex-
perienced assistant help in the transferring to and from
theracingchair.Theassistantshouldholddownthefront
of the racing chair to avoid any instability that may occur.
STEP 6:
PlaceRIGHT
handon the
racingchair
frame.

9
ITEM INITIALLY INSPECT/ INSPECT/ INSPECT/
ADJUST ADJUST ADJUST
WEEKLY MONTHLY PERIODICALLY
GENERAL
Racingchairrollsstraight(noexcessivedragorpulltooneside). X X
SEATAND BACK UPHOLSTERY
Inspectfor ripsor sagging. X X
REARWHEELS
Axles are securely tightened. X X X X
Noexcessive sidemovementorbindingwhen lifted
andspun. X X
CAUTION: As with any vehicle, the wheels and
tires should be checked periodically for cracks and
wear, and should be replaced.
PUSHRIMS
Inspectfor signsof roughedges orpeeling oftire/tape
coatingwhere itmightseparate fromthe pushrim. X X
SPOKES
Inspectfor bentorbroken spokes. X X
All spokes uniformly tight. X X
FRONTWHEEL
Inspectwheel/fork assemblyfor propertension by
frontwheel; frontwheel shouldcome toa gradualstop. X X
Loosen/tightenallen screwsif wheelwobbles
noticeably or binds to a stop. X X
NOTE: There WILL be some play in the front
wheel- This is common in all front hubs.
Wheelbearings areclean andfree ofmoisture. X X X
CAUTION: As with any vehicle, the wheels and
tires should be checked periodically for cracks and
wear, and should be replaced.
HANDCALIPERBRAKE
Doesnot interferewith frontwheelwhen rolling. X X
Hand caliper brake is easy to engage. X X
Noexcessive wearof handcaliper brakepads. X X
TIRES
Inspectfor flatspots andwear. X X
Checkpneumatic tiresfor properinflation. X X
Checkframe cagefor interferencewith tires. X X
CAUTION: As with any vehicle, the wheels and
tires should be checked periodically for cracks and
wear, and should be replaced.
CLEANING
Cleanupholstery withlight detergentand water. X X
SAFETY INSPECTION PROCEDURE 2
I
N
S
P
E
C
T
I
O
N
S
A
F
E
T
Y
NOTE: Every six (6) months or as necessary take
your racing chair to a qualified technician for a thor-
ough inspection and servicing. Regular cleaning will
reveal loose or worn parts and enhance the smooth
operationofyourracingchair.Tooperateproperlyand
safely, your racing chair must be cared for just like
anyothervehicle.Routinemaintenancewillextendthe
life and efficiency of your racing chair.
SAFETY INSPECTION CHECKLIST
Initialadjustmentsshouldbemadetosuityourpersonalbodystructureandpreference.Thereafterfollowthese
maintenance procedures.
This Procedure includes the following:
SafetyInspectionChecklist
Troubleshooting
Maintenance

10
TROUBLESHOOTING GUIDE MECHANICAL
CHAIR CHAIR SLUGGISH SQUEAKS LOOSENESS SOLUTIONS
VEERS VEERS TURNOR AND INCHAIR
RIGHT LEFT PERFORMANCE RATTLES
XX X Check tires for correct and equal pressure.
XX XCheck for loose stem nuts.
XXCheck spokes and nipples.
XX X Adjust compensator (Procedure 5).
XCheck toe in/toe out.
TROUBLESHOOTING
3. Checktiresforproperpressureandifnotinflatedprop-
erly, inflate to recommended tire pressure listed on
thesidewallofthetire.
4. The wheelsandtiresshouldbecheckedperiodically
for cracks and wear, and should be replaced by a
qualifiedtechnician.
5. Regularlycheckforloosespokesintherearandfront
wheels. If loose, have them adjusted by a qualified
technician.
6. Periodically check pushrims to ensure they are se-
cured to the rear wheels. Refer to REPLACING
PUSHRIMS inPROCEDURE2ofthismanual.
7. Periodicallyadjusthandcaliperbrakeincorrelationto
hand caliper brake pad wear. Refer to ADJUSTING
HANDCALIPERBRAKESENSITIVITY/REPLACING
HAND CALIPER BRAKE in PROCEDURE 4 of this
manual.
8. Periodically check rear and front wheel bearings to
make sure they are clean and free from moisture.
Use a Teflon®lubricant if necessary.
9. Check upholstery for sagging, rips or tears.
MAINTENANCE
Maintenance Safety Precautions
WARNING
After making adjustments, always make
sure that parts are properly tightened BE-
FORE using the racing chair.
CAUTION
DO NOT overtighten hardware attaching
to the frame. This could cause damage to
the frame tubing.
Suggested Maintenance Procedures
1. Before using your Invacare Top End Eliminator or Elimi-
nator OSR, check all parts for damage or wear and re-
place,ifnecessary.Checkallpartsforproperadjustment.
2. Keep axles free of dirt and lint to ensure proper fit in
axle receiver. Cross threading will damage the axles
andaxlereceivers.
WARNING
DO NOT use the racing chair unless it has
the proper tire pressure (p.s.i.). DO NOT
overinflate the tires. Failure to follow manu-
facturers recommendations listed on the
side wall of the tire may cause the tire to
explode and cause bodily harm.
SAFETY INSPECTIONPROCEDURE 2
I
N
S
P
E
C
T
I
O
N
S
A
F
E
T
Y

11
PROCEDURE 3UPHOLSTERY/FOOTREST
U
P
H
O
L
S
T
E
R
Y
This Procedure includes the following:
Adjusting/Replacing Back Upholstery
Adjusting/Replacing Leg Cushion with Foot Pouch
Replacing Seat Sling Upholstery
InstallingthePlastic Footplate
Installing/Using/Adjusting the Fixed Footrest
Fastening
Flaps
Slots
Foot Pouch
Attaches
Here
Back Upholstery
FIGURE 1 - ADJUSTING/REPLACING BACK
UPHOLSTERY
Foot Pouch
Bottom of
Back
Upholstery
WARNING
After ANY adjustments, repair or service
and BEFORE use, make sure all attachment
hardware is tightened securely - other-
wise, injury or damage may result.
The tautness of the back upholstery, knee
and/or foot position, as well as the user con-
dition directly relate to the stability of the
racing chair. Any change to one (1) or any
combination of the three (3) may cause
the racing chair to decrease in stability.
Refer to STABILITY in PROCEDURE 1 of this
manual.
ADJUSTING/REPLACING BACK
UPHOLSTERY (FIGURE 1)
1. Unlatch the three (3) fastening flaps that secure the
back upholstery to the racing chair frame.
Adjusting
1. Adjust back upholstery tothedesiredtautness.
TIGHTERupholsterywillincreasethestabilityandmain-
tainnormalmaneuverabilityoftheracingchairbecause
theuseris pushedforwardinthe racingchairslightly.
LOOSERupholsterywillincreasethemaneuverability
and make the racing chair less stable because addi-
tionalweightisbeingdistributedontotherearwheels.
Replacing
1. Unlatch the foot pouch of the leg cushion from the
backupholstery(kneelingupholsteryonly).
2. Unlatch the bottom of the back upholstery from the
seatslingupholstery.
3. Removetheexistingbackupholsteryfromtheracing
chair.
4. Feed the top two (2) fastening flaps of the new back
upholsterythroughtheslotsontheracingchairframe.
5. Feedthebottomfasteningflapofthenewbackupholstery
betweentheracingchairframeandtheclothingguards.
6. Adjustthenewbackupholsteryfordesired tautness.
Refer to ADJUSTING BACK UPHOLSTERY in this
procedureofthemanual.
SeatSling
Upholstery
Seat Cushion
F
O
O
T
R
E
S
T
7. If the racing chair is equipped with kneeling upholstery,
attachthefootpouchtothebackupholsteryandadjust.
Refer to ADJUSTING/REPLACING LEG CUSHION
WITH FOOTPOUCHinthisprocedureofthemanual.
ADJUSTING/REPLACING LEG
CUSHION WITH FOOT POUCH
(FIGURE 2)
WARNING
If the racing chair is equipped with kneel-
ing upholstery, always ensure the foot
pouch is securely latched to the back up-
holstery. Otherwise, injury can occur.
Adjusting
1. Adjust leg cushion w/foot pouch to the desired taut-
ness.

12
4. Remove seatcushionfromthe seatslingupholstery.
5. Unlatch the fastening flap that secures the existing
seatupholstery to itself.
6. Slide the ends of the existing seat upholstery up and
through the frame of the racing chair.
7. Slidethenewupholsterythroughtheframeoftherac-
ing chair as shown in FIGURE 5.
8. Pull the seat upholstery to the desired tautness and
secure with the fastening flap.
9. Reverse STEPS 1-5 to reassemble.
Replacing
1. Unlatch the three (3) fastening flaps that secure the
leg cushion to the racing chair frame.
2. Unlatch the foot pouch from the back upholstery.
3. Remove the existing leg cushion w/foot pouch.
4. Install thenewlegcushionw/footpouch.
5. Feed the top two (2) fastening flaps of the new leg
cushion w/foot pouch through the slots on the racing
chair frame.
6. Feedthebottomfasteningflapbetweenthesideguard
and the racing chair frame and secure together.
7. Attach the foot pouch to the back upholstery and ad-
justtothedesiredtautness.RefertoADJUSTINGLEG
CUSHION WITH FOOT POUCH in this procedure
of the manual.
REPLACING SEAT SLING
UPHOLSTERY (FIGURE 3)
1. Unlatch the foot pouch from the back upholstery.
2. Unlatch the bottom of the back upholstery from the
undersideoftheseat slingupholstery.
3. Unlatchthetoptwo(2)fasteningflapsthatsecurethe
leg cushion to the racing chair frame.
Foam Insert SeatSling
Upholstery
Back
Upholstery
Fastening
Flaps
Slots Foot Pouch
FIGURE 2 - ADJUSTING/REPLACING LEG
CUSHION WITH FOOT POUCH
Seat
Upholstery
Fastening
Flap
Racing
Chair
Frame
FIGURE 3 - REPLACING SEAT SLING
UPHOLSTERY
UPHOLSTERY/FOOTRESTPROCEDURE 3
U
P
H
O
L
S
T
E
R
Y
F
O
O
T
R
E
S
T
INSTALLING THE PLASTIC
FOOTPLATE (FIGURE 4)
WARNING
Feet MUST be secured against the plastic
footplate BEFORE using racing chair. Oth-
erwise, injury or damage may occur.
1. Secure the fastening straps around the frame as
showninFIGURE4.
2. Place feet onto plastic footplate where indicated in
FIGURE4.
NOTE: It may be necessary to loosen or tighten the fas-
teningstrapsforcomfortandtosecurefeettothefootplate.
3. Secure ankles with ankle strap by wrapping strap
aroundankles.

13
PROCEDURE 3UPHOLSTERY/FOOTREST
U
P
H
O
L
S
T
E
R
Y
Seat
Frame
Plastic
Footplate
Fastening
Strap
Place Feet HERE
FIGURE 4 - INSTALLING THE PLASTIC
FOOTPLATE
INSTALLING/USING/ADJUSTING
THE FIXED FOOTREST (FIGURE 5)
WARNING
Feet MUST be secured into the fixed foot-
rest BEFORE using racing chair. Otherwise,
injury or damage may occur.
Installing/Using Fixed Footrest
1. Remove the hex screws from the mounting bracket.
2. Position the upper support tube on the underside of
the racing chair frame.
3. Position the mounting bracket on top of the racing
chair frame.
4. Installthehexscrewstosecurethemountingbracket
totheuppersupporttube.
6. If necessary, adjust footrest. Refer to ADJUSTING
FIXED FOOTREST in this procedure.
7. Pull the buckle out to release foot strap.
8. Place feet onto footrests.
9. Pull endoffootstrapto tighten.
10. Closebuckletosecurefootstrapandfeettofootplate.
11. Secureanklesbywrappinganklestraparoundlower
footrestsupporttubeand ankles.
Adjusting Fixed Footrest
HEIGHT.
1. Loosen the set screw securing the upper and lower
footrest support tubes.
2. Reposition the footrest up or down as desired.
DETAIL "A" - ADJUSTING DEPTH
FIGURE 5 - INSTALLING/USING/
ADJUSTING THE FIXED FOOTREST
Fastening
Strap
Ankle
Strap
Mounting
Bracket
Upper
Support
Tube
LowerSupport Tube
SetScrew
Hex Screw
Footplate Foot Strap
Ankle Strap
FootplateMounting
Bracket
Hex Screw
Locknut
Buckle
Racing Chair Frame
Footplate
Hex Screws
Mounting
Holes
3. Tighten the set screw to secure the upper and lower
footrest support tubes.
ANGLE.
1. Loosen thelocknutssecuringthe footplatemounting
bracket.
2. Adjusttheangleof thefootplateasdesired.
3. Tightenthe locknuts securingthefootplatemounting
bracket.
DEPTH.
1. Remove the locknuts and hex screws securing the
footplatemountingbracket.
2. Reposition the footplate to the desired set of mount-
ingholes(DETAIL"A").
3. Installthehexscrewsthroughthefootplate,footstrap
andfootplatemountingbracket.
4. Secure the hex screws with the locknuts. Tighten
securely.
F
O
O
T
R
E
S
T

14
WHEELSPROCEDURE 4
W
H
E
E
L
S
FIGURE 2 - REPLACING PUSHRIMS
Allen Screw
Spoke
Spokes
FRONT OF
RACING
CHAIR
Pushrim
Axle Tube Rear Wheel
FIGURE 1 - INSTALLING REAR WHEELS
This Procedure includes the following:
Installing Rear Wheels
Repairing, Replacing Rear Wheel Tire/Tube
Replacing Pushrims
Installing/Removing Front Wheel
Removing/Installing Fork
Determining Toe In/ Toe Out
Adjusting Toe In/Toe Out - Eliminator Only
Replacing Camber Inserts - Eliminator Only
Spokes
FRONT OF RACING
CHAIR
Pushrim
INSTALLING/REMOVING FRONT
WHEEL (FIGURE 3)
NOTE: To remove, reverse the order of the steps below.
NOTE: There WILL be some play in the front wheel.
This is common in all front hubs.
1. Remove the two (2) hex axles from the front wheel.
2. Line up the mounting holes in the front wheel with
the holes in the forks.
3. Reinstall the (2) hex axles and securely tighten the
front wheel to the fork.
Allen Wrench Allen
Wrench
WARNING
After ANY adjustments, repair or service and BE-
FOREuse, makesure all attachment hardwareis
tightened securely-otherwise, injuryordamage
may result.
INSTALLING REAR WHEELS
(FIGURE 1)
NOTE: There is a RIGHT and LEFT rear wheel. The
pushrims should be pushing onto the spokes at the top of
the rear wheel.
1. Determine the right and left rear wheel.
2. Apply a small amount of grease onto the axle.
3. Insert axle into the axle tube onthe racing chair frame.
4. Securely tighten the axle to the racing chair frame us-
ing the allen wrench.
REPAIRING, REPLACING REAR
WHEEL TIRE/TUBE
WARNING
Replacement of a clincher tire or tube MUST be
performed by a qualified technician.
NOTE:TUBULARTIRESaretireswithtubessewnintothe
tires, they are high pressure (140+ lbs. psi) and must be
glued to the rim. Once they have a hole in them, they
must be replaced.Also,tubulartireswillloseairovernight,
buttheyarenotfaulty.Thisisacharacteristicoftubulartires.
Tubular tires do not fit on a clincher rim.
NOTE:CLINCHERTIRESarelikeconventionalbicycletires,
thereisaninnertubeseparatefromtheactualtire.Theyare
moredurablefor longerperiodsoftimeandifpuncturedthe
tube canbereplaced(bya qualifiedtechnician)and thetire
will still be in tact. Clincher tires use 100+ lbs. psi. Clincher
tires do not fit on a tubular rim.
REPLACING PUSHRIMS (FIGURE 2)
1. Remove the rear wheel from the racing chair.
2. Loosentheallenscrewsthatsecuretheexistingpushrim
to the rear wheel.
3. Remove the existing pushrim.
4. Install the new pushrim onto the rear wheel and se-
curely tighten the allen screws.
NOTE:Ensuretherimispushingontothespokesatthetop
of the rear wheel.
5. Reinstall rear wheel onto the racing chair.

15
PROCEDURE 4WHEELS
W
H
E
E
L
S
Hex Axle
Front Wheel Fork
FIGURE 3 - INSTALLING/REMOVING FRONT WHEEL
Hex Axle
Steering Cylinder
Locknut
Fork
Stem
Spacer
Metal
Washers Needle
Bearing
Head
Tube
Metal
Washers Needle
Bearing
Spacer
FIGURE 4 - REMOVING/INSTALLING FORK
Socket Screw
Headset
5. Install headset onto new/existing fork stem. Refer to
FIGURE 4.
6. Install socket screw through mounting hole in head-
set and tighten securely.
7. Remove the locknut that secures the steering cylin-
der to the front fork.
8. Install the steering cylinder onto the front fork and se-
curely tighten with the locknut.
9. If equipped, line up the custom steering handle with
the racing chair frame and tighten the socket screw
securely.
Socket Screw
Headset
Custom
Steering
Handle
DETAIL"A"
Fork
Stem
BOTTOM
TOP
REMOVING/INSTALLINGFORK
(FIGURE 4)
Removing
1. Remove the two (2) hex axles that secure front wheel
to existing fork and remove front wheel from the rac-
ing chair.
2. Remove the locknut that secures the steering cylin-
der to the exisiting fork and remove the steering cylin-
der from the fork.
3. Remove the socket screw that secures the headset
to the exisiting fork stem.
4. If equipped, loosen the socket screw that secures the
custom steering handle to the existing fork as shown
in DETAIL "A" of FIGURE 4.
5. Remove the headset, custom steering handle (if
equipped), TOP metal washer, needle bearing, metal
washer and spacer from the exisiting fork stem.
6. Slide existing fork stem out of head tube of the racing
chair.
7. Remove BOTTOM metal washer, needle bearing,
metal washer and spacer from the existing fork stem.
Installing
1. Install the BOTTOM metal washer, needle bearing,
metal washer and spacer onto the new/existing fork
stem. Refer to FIGURE 4.
2. Slide new/existing fork stem into head tube of racing
chair.
3. InstallTOPspacer,metalwasher,needlebearingand
metal washer onto new/existing fork stem. Refer to
FIGURE 4.
4. If equipped, install custom steering handle onto new/
existing fork stem. Refer to DETAIL "A" of FIGURE 4.

16
DETERMINING TOE IN/TOE OUT
(FIGURE 5)
1. Inflate all pneumatic tires to recommended tire pres-
sures.
NOTE: Recommended air pressure is listed on the
sidewall of the tire.
2. Measure the distance between the center lines at
therearandfrontoftherearwheelsatapproximately
12-inches from the ground/floor.
NOTE: For optimum accuracy, perform STEP 2 with the
racing chair occupied.
3. Determine the difference between the two (2) mea-
surements. If the difference between the two (2)
measurements is GREATER than 1/2-inch (0 +
1/4-inch for maximum rollability), one (1) of two
(2) conditions exists:
a. If the rear centerline measurement of the rear
wheels is SMALLER than the front centerline
measurement of the rear wheels, a TOE-OUT
condition exists (FIGURE 5).
b. If the rear centerline measurement of the rear
wheels is LARGER than the front centerline
measurementoftherearwheels,aTOE-INcon-
dition exists (FIGURE 5).
Toe-in
Smaller Than
Front
Larger Than Front
Toe-out
Top View of
Racing
chair
FRONT OF RACING CHAIR
FIGURE 5 - DETERMINING TOE IN/TOE OUT
4. Ifthedifferencebetweenthemeasurementsisgreater
than 1/2-inch, correct the toe-in/toe-out condition. Re-
fertoADJUSTINGTOE-IN/TOE-OUT-ELIMINATOR
ONLYin this procedure of the manual.
ADJUSTING TOE IN/TOE OUT -
ELIMINATOR ONLY (FIGURE 6)
1. Loosen, but do not remove the two (2) socket screws
and clamps that secure the two (2) camber inserts to
the camber bar.
2. Slowly rotate the camber insert CLOCKWISE or
COUNTERCLOCKWISEuntiltherearwheelsareap-
proximately in a straight line.
3. Securely tighten the socket screws and clamps that
secure the camber inserts to the camber bar.
4. Measure the distance between the center lines at the
rear and front of the rear wheels at approximately 12-
inches from the ground/floor. Refer to DETERMIN-
INGTOEIN/TOEOUTinthisprocedureofthemanual.
5. RepeatSTEPS1-4untilthetoein/toeoutmeasurement
islessthan1/2-inch(0+1/4-inchformaximumrollability).
Camber
Insert
Camber Bar
Socket
Screw
Clamp
FIGURE 6 - ADJUSTING TOE IN/TOE OUT -
ELIMINATOR ONLY / REPLACING CAMBER INSERTS-
ELIMINATOR ONLY
PROCEDURE 4 WHEELS
W
H
E
E
L
S
REPLACING CAMBER INSERTS -
ELIMINATOR ONLY (FIGURE 6)
1. Loosen, but do not remove the socket screws and
clamps that secure the camber inserts to camber bar.
2. Remove existing camber insert from the camber bar.
3. Install the new camber insert into the camber bar.
4. Adjust the toe in/toe out of the racing chair. Refer to
DETERMINING TOE IN/TOE OUT in this procedure
of the manual.
Front
Centerline
Rear
Centerline

17
COMPENSATOR PROCEDURE 5
FIGURE 1 - ADJUSTING COMPENSATOR FOR
STRAIGHTS AND TURNS
This Procedure includes the following:
Adjusting Compensator for Straights and Turns
Replacing Compensator
FIGURE 2 - REPLACING COMPENSATOR
TRACK STOPS
Locknuts
Washer
Compensator
Racing Chair
Frame
Locknut
Steering
Cylinder
C
O
M
P
E
N
S
A
T
O
R
Locknuts
Track Stop
Screw
(turns)
Track
Stop
Screw
(straights)
FRONT OF RACING
CHAIR
Compensator TOP VIEW OF
RACING CHAIR
Locknuts
Track Stop
Screw
Track Stop
Screw
Racing Chair
Frame
WARNING
After ANY adjustments, repair or service and BE-
FOREuse, makesure all attachment hardwareis
tightened securely-otherwise, injuryordamage
may result.
ADJUSTING COMPENSATOR FOR
STRAIGHTS AND TURNS (FIGURE 1)
NOTE: Adjustments to the compensator should be made
while sitting in the racing chair.
NOTE: Different speeds will affect the way racing chair
handles. Therefore, it is critical for maximum performance
to set compensator close to expected race speed. Keep in
mind that all tracks are different. Also, different conditions
willaffectthewayracingchairhandles.Extremecrosswinds
should be taken into consideration.
NOTE: The procedures below are for a counter-clock-
wise racing track. Reverse the Right and Left instruc-
tions for a clockwise racing track.
Straights While Racing or Training
1. Turn front wheel until it is approximately in a straight line.
2. Turn the RIGHT track stop screw until the locknut on
the track stop is touching the racing chair frame.
3. RepeatSTEPS1-2untilracingchairfollowsastraightline.
Turns While Racing or Training
1. Turnfrontwheeluntilinrequiredpositionfordesiredturn.
2. Turn the LEFT track stop screw until it is touching the
racing chair frame.
3. Repeat STEPS 1-2 until racing chair follows the de-
sired turn.
REPLACING COMPENSATOR
(FIGURE 2)
CAUTION
The track stops are spring loaded. Use caution
when removing.
1. Remove the locknut that secures the steering cylin-
der to the compensator.
2. Remove the two (2) locknuts and washer that se-
cure the compensator to the racing chair frame.
3. Removethecompensatorfromtheracingchairframe.
4. Remove the two (2) track stops from the compensa-
tor by using the following steps:
A. Remove the locknut on the track stop screws.
B. Remove track stop screw and spring from com-
pensator.
5. Install new compensator by reversing STEPS 1-4.
6. Adjustthecompensator.RefertoADJUSTINGCOM-
PENSATORFORSTRAIGHTSANDTURNSinthis
procedure of the manual.

18
FIGURE 2 - ADJUSTING/REPLACING HAND CALIPER
BRAKEPADS
Allen
Screw
Hand Caliper
Brake Cable
Allen Screw
Washer
REPLACING
Hand Caliper Brake Pad
BRAKESPROCEDURE 6
B
R
A
K
E
S
This Procedure includes the following:
Adjusting Hand Caliper Brake Sensitivity
Adjusting/Replacing Hand Caliper Brake Pads
FIGURE 1 - ADJUSTING HAND CALIPER
BRAKE SENSITIVITY
Tire
Rim
Allen
Screw
Hand Caliper
Brake Pad
ADJUSTING
Arrow
ADJUSTING/REPLACING HAND
CALIPER BRAKE PADS (FIGURE 2)
WARNING
Before using the racing chair, inspect the hand
caliper brake and hand caliper brake pads for
proper operation and wear. Replace if worn.
Adjusting Hand Caliper Brake Pads
1. Loosen the allen screw that secures the hand caliper
brake pad to the hand caliper brake.
2. Position the hand caliper brake pad until it is in-line
with the rim of the front wheel.
3. Securelytightentheallenscrewthatsecuresthehand
caliper brake pad to the hand caliper brake.
4. Repeat the above steps for the opposite side.
5. Adjust hand caliper brake. Refer to ADJUSTING
HAND CALIPER BRAKE SENSITIVITY in this pro-
cedure of the manual.
Replacing Hand Caliper Brake Pads
NOTE: Invacare Top End recommends replacing BOTH
hand caliper brake pads at the same time to achieve the
best hand caliper brake performance possible.
1. Removethefrontwheel.RefertoINSTALLING/REMOV-
INGFRONTWHEELinPROCEDURE4ofthismanual.
2. Remove allen screw and washer that secure the ex-
istinghandcaliperbrakepadtothehandcaliperbrake.
3. Install the NEW hand caliper brake pad with the ar-
row pointing towards the front of the racing chair
with the existing hardware.
NOTE: The arrow pointing towards the front of the racing
chair determines the right and left hand caliper brake pad.
4. Repeat above steps for opposite brake pad.
5. Reinstall the front wheel onto the racing chair. Refer
to INSTALLING/REMOVING FRONT WHEEL in
PROCEDURE 4 of this manual.
6. Adjustthehandcaliperbrakepads.RefertoADJUST-
ING HAND CALIPER BRAKE PADS in this proce-
dure of the manual.
WARNING
AfterANYadjustments,repairorserviceandBEFORE
use,makesureallattachmenthardwareistightened
securely - otherwise, injury or damage may result.
Replacement of the hand caliper brake MUST
be performed by a qualified technician.
ADJUSTING HAND CALIPER BRAKE
SENSITIVITY (FIGURE 1)
WARNING
Beforeusingtheracingchair,inspectthehandcali-
perbrakeandhandcaliperbrakepadsforproper
operation and wear. Replace if worn.
Adjusting Hand Caliper Brake Sensitivity
1. Loosen the allen screw that maintains the tautness of
the hand caliper brake cable.
2. Squeeze both hand caliper brake pads with your hand
to adjust the hand caliper brake cable.
3. Loosely tighten the allen screw toensurethatthehand
caliper brakes are adjusted properly.
NOTE: When the hand caliper brake is engaged, the
hand caliper brake pads should rest solely on the rim of
the wheel. If not, adjust the hand caliper brake pads.
Refer to ADJUSTING HAND CALIPER BRAKE PADS
in this procedure of the manual.
4. Repeat the above steps until the hand caliper brakes
are adjusted properly.
5. Securelytightentheallenscrewthatmaintainsthetaut-
ness of the hand caliper brake cable.

19
LIMITED WARRANTY
PLEASE NOTE: THE WARRANTY BELOW HAS BEEN DRAFTED TO COMPLY WITH FEDERAL LAWAPPLI-
CABLE TO PRODUCTS MANUFACTURED AFTER JULY 4, 1975.
This warranty is extended only to the original purchaser/user of our products.
This warranty gives you specific legal rights and you may also have other legal rights which
vary from state to state.
Invacare warrants the Eliminator/Eliminator OSR frame to be free from defects in materials
and workmanship for a period of two (2) years from date of purchase to the original owner.
All component parts including, but not limited to camber tubes, compensator, and uphol-
stery are warranted against defects in materials and workmanship for a period of one (1) year
from the original invoice date except steering cylinders, cushion, bushings, bearings, cables
and tires/tubes. Carbon fiber wheels are subject to the wheel manufacturer's warranty and
are not warranted by Invacare. If within such warranty period any such product shall be
proven to be defective, such product shall be repaired or replaced, at Invacare's option. This
warranty does not include any labor or shipping charges incurred in replacement part instal-
lation or repair of any such product. Invacare's sole obligation and your exclusive remedy
under this warranty shall be limited to such repair and/or replacement.
For warranty service, please contact the dealer from whom you purchased your Invacare
product. In the event you do not receive satisfactory warranty service, please write directly to
Invacare at the address below. Provide dealer’s name, address, date of purchase, indicate
nature of the defect and, if the product is serialized, indicate the serial number. Do not return
products to our factory without our prior consent.
LIMITATIONS AND EXCLUSIONS: THE FOREGOING WARRANTY SHALL NOT APPLY TO SERIAL NUM-
BERED PRODUCTS IF THE SERIAL NUMBER HAS BEEN REMOVED OR DEFACED, PRODUCTS SUB-
JECTED TO NEGLIGENCE, ACCIDENT, IMPROPER OPERATION, MAINTENANCE OR STORAGE,
COMMERCIAL OR INSTITUTIONAL USE, PRODUCTS MODIFIED WITHOUT INVACARE'S EXPRESS
WRITTEN CONSENT (INCLUDING, BUT NOT LIMITED TO, MODIFICATION THROUGH THE USE OF UN-
AUTHORIZED PARTS OR ATTACHMENTS; PRODUCTS DAMAGED BY REASON OF REPAIRS MADE TO
ANY COMPONENT WITHOUT THE SPECIFIC CONSENT OF INVACARE, OR TO A PRODUCT DAM-
AGED BY CIRCUMSTANCES BEYOND INVACARE'S CONTROL, AND SUCH EVALUATION WILL BE
SOLELY DETERMINED BY INVACARE. THE WARRANTY SHALL NOT APPLY TO PROBLEMS ARISING
FROM NORMAL WEAR, USE ON AN INDOOR TRAINING ROLLER, OR FAILURE TO ADHERE TO THESE
INSTRUCTIONS.
THE FOREGOING WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS WARRANTIES.
IMPLIED WARRANTIES, IF ANY, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, SHALL NOT EXTEND BEYOND THE DURATION OF THE EX-
PRESS WARRANTY PROVIDED HEREIN AND THE REMEDY FOR VIOLATIONS OF ANY IMPLIED WAR-
RANTY SHALL BE LIMITED TO REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT PURSUANT
TO THE TERMS CONTAINED HEREIN. INVACARE SHALL NOT BE LIABLE FOR ANY CONSEQUENTIAL
OR INCIDENTAL DAMAGES WHATSOEVER.
THIS WARRANTY SHALL BE EXTENDED TO COMPLY WITH STATE/PROVINCIAL LAWS AND REQUIRE-
MENTS.
WARRANTY
W
A
R
R
A
N
T
Y

Invacare Corporation www.invacare.com
USA Invacare Top End
One Invacare Way Sports and Recreation Products Invacare and Top End are registered trademarks of Invacare
Elyria, Ohio USA 4501 63rd Circle North Corporation.
44036-2125 Pinellas Park, FL 34665 Eliminator and Yes, you can. are trademarks of Invacare
800-333-6900 800-532-8677 Corporation.
Teflon is a registered trademark of E. I. Du Pont De
Nemours and Company.
© 2001 Invacare Corporation
Form No. 94-171 Part No. 1052767 Rev B (1) 04/01
