Airwheel SE3 User manual

SE3
USER MANUAL

- 01 -
Check Packing Contents
Case body 1 unit Charger 1 unit
manual / Warranty card 1 unit Quality approval 1 unit
Battery wiring 1 unit Spare charger(Optional) 1 unit
Dust cover 1 unit
Packing List
Case body
Charger
Battery wiring
User manual /
Warranty card
Quality approval
Dust cover
Spare charger
(Optional)

- 02 -
SE3 Diagram
Front wheel
Rear wheel
Handle
Quick connector
*Lite edition
Lift grip
Pull rod
Rear light
Meter
Accelerator
Pedal
Customs
coded lock
Charge interface
Unfold switch
Power switch
Meter instruction
1. Short press the up button to switch
between single and total distance
2. Long press the down button to
activate electronic brake
3. Fault code icker
4. Long press the up and down button
3 seconds to clear ODO distance.
Up button
Battery
indication
Speed
Kilometer
Down button
(electronic
brake)
km/h
km
SPEED
TRIP

- 03 -
SE3 Diagram
*Wit edition
USB Charger
Bluetooth speaker
Flash light
Bluetooth speaker instruction(wit edition)
Turn on phone's bluetooth, play music once connected.

- 04 -
Motor size 6.5 inches Motor QTY 1
Motor weight 3kg Motor power 250W
Specications
Main specications
Battery specications
Motor specications
Warning
Please don't dispose of used batteries to avoid environmental pollution. The used lithium battery of this
product is responsible for recycling by the company or distributors and government designated sites.
Open size 629X365X826mm Vehicle weight ~14.5kg
Folded size 489X365X580mm Maximum load 90kg
USB Output voltage 5V Maximum climbing angles ~15°
Lock type TSA coded lock Applicable temperature -10℃~40℃
Rear wheel 8 inches inatableX2 Volume 29.3L
Material Shell ABS+PC
Aluminum alloy frame Front wheel 6.5 inches motor wheel
Smart phone support IOS/Andriod Maximum speed ≤10km/h
Pull rod Three range aluminum rod Color Black/Silver
Battery capacity 185Wh/73.26Wh Charging time 3h/2h
Battery type lithium Battery voltage 37V
Removable Yes Charging voltage AC100-240V 50-60Hz

- 05 -
Unfold
Turn on the power switch and place the unfold switch in the "I" position. The handlebars will
automatically unfold. After the expansion is completed, the unfold switch will be reset to the "o"
position.
1.
2.
1.
2.
Loosen the quick connector. After pulling the handlebar to a proper position, fasten the quick
connector. Check that there is no loosening and the unfolding is complete.
Use SE3
Power
switch
Ⅰposition auto unfold
Ⅱposition auto fold
o position stop
Folded status Unfolded status
quick
connector
Unfold
switch
Fold
Turn on the power switch and place the unfold switch in the “II” position. The handlebars will
automatically fold and the unfold switch will be reset to the “o” position after the folding nish.
Turn off the power.
Loosen the quick connector, shrink the handlebar until it cannot shrink, and fasten the quick
connector.

- 06 -
Battery removal instructions
Before removing, check whether the power is off, open the box, pull
open the lining zipper, open the inner lining, unplug the battery cable,
pull out the cloth tape outside the battery box forcefully, and the battery
will be lifted up and remove the battery.
(When the battery is taken out for the first time, the fixed tie on the
battery box needs to be cut and removed.)
Custom coded lock instruction
The original password is 0-0-0, set your own password, follow these steps:
1.Dial the password to the original password: 0-0-0;
2.Press the button A with a pen or other tool until you
hear the 'tick' sound;
3.Dial the password wheel B to set your own password,
for example: 8-8-8;
4.Push button C in the direction of the arrow and hear the “tick” sound
again. Button A pops up and the password is successfully set.
Now you have completed your password setup, please keep it in mind. If you need to reset your password,
repeat the above steps.
A
C
B
Battery Extension Cable Instructions (Optional)
Battery wiring
When the battery is removed for charging, connect the battery and charger as shown below.
Connect battery Connect charger
Battery connector terminal plug Note：
When inserting the battery cable terminal, please make sure
the terminal "+" pole to the "+" pole, "-" pole on the "-" pole (see
right diagram); never insert positive to negative poles.
WARNING
battery box
battery
tie
cloth bag
+
-
+
-

- 07 -
Riding precautions
Riding SE3
Turn on the power switch, check whether the battery is sufcient before riding, whether the
brake is intact, and the charging port is covered
Drive
forward
Get on Brake
Electronic
brake
Towing SE3
Lifting SE3
Fold SE3, pull out rod and tow
Fold SE3, lift grip and go
Before using for the rst time, it is recommended to charge to full battery rst.
During the ride, it is not recommended to make sudden braking and hard turning to prevent side
slipping or overturning.
In the process of use, please comply with the trafc regulations and various site management
regulations.
Avoid using this product in bad weather (such as rain, snow, or ice).
When not riding, turn off the power.
The right hand turns the
accelerator to move forward
Sit on the case, adjust the center
of gravity, place both feet on the
pedal
Long press the electroni brake
to decelerate
Pull rod
Lift grip
1.
2.
3.
4.
5.

- 08 -
Safety
Please note that SE3 must be carefully read and follow the requirements of SE3 riding. Do not use
this product until you have read the instructions carefully to understand SE3 performance; do not lend
it to people who will not operate the product.
Very important
It is strictly forbidden to accelerate, decelerate and turn sharply, or overspeed. When cell phone APP shows one
cell or SE3 display voltage shows one cell, it is not recommended to ride. Please keep slow speed during riding.
If you face risk of fall, please protect your personal safety. Do not consider SE3. The SE3 may lose during
riding and during parking, affecting the performance of the product. So before you ride SE3, you must do the
following checks:
It is necessary to check whether the each components of the SE3 are installed securely, without damage, whether
the brake function and tires are intact, and whether the tire pressure is normal.
The quick connector mechanism is locked.
You need to have a thorough understanding of the surrounding riding environment: Make sure you are not
disturbed by cars, pedestrians, pets, bicycles and other obstacles.
1.
2.
3.
Before safely riding SE3, you need a lot of practice to master safe riding skills. If the riding technique is
unskillful or the use of this product is not required by this guideline, personal injury or property damage to the
cyclist or a third party may result. The company only assumes responsibility for product failure or damage, and
does not assume responsibility for any personal injury or property damage associated with the use of this product.
How to use the battery
Battery charge: If the time to production date is short, the user can directly load the battery. If the time is longer
(more than 2 months), the battery will lose power during storage and transportation. The battery should be
charged before you riding. Charging method: insert its original plug into the battery charging hole and then
connect it to the AC100-240V power supply (commercial power) to charge it for 2 to 4 hours until the charger
indication is fully charged.
Normal charging of the battery: The operation of the SE3 is also the discharging process of the battery. After the
operation is stopped, the battery should be charged in time. Please turn off the power when not riding.
The connectors of the battery should be plugged and fastened as required (the battery cable has been reliably
connected before leaving the factory). Loose or incorrect connections can cause abnormal operation of the
relevant components. In severe cases, the components can be damaged.
Lithium batteries can not be close to open ame or high temperature heat source, and can not throw the power
battery into the water, the battery would not allow to expose to sunlight in high temperature season.
Lithium batteries are well-packaged and must not be disassembled or tear down.
For scrapped batteries, please submit them to the recycler or distributor for disposal. Do not discard them to
avoid contamination.
1.
2.
3.
4.
5.
6.
How to use the charger
Carefully check that the charger's rated input voltage (AC100-240V) is consistent with the grid voltage.
When need to charge, connect the charger's input plug and the battery's charging jack in order, and then connect
the charger's input to the AC power supply. When the charger's charging indicator is red, indicates that the
battery is charging. When the green light is on, it will be fully charged for about 15 minutes. The charging time is
about 2-4 hours (time of charging depends on the remaining battery capacity).
When the charging is completed, rst cut off the power, pull out the power plug, pull out the charging connector,
and close the charging port cover.
1.
2.
3.

- 09 -
When charging, place it in a safe place that children cannot touch.
It should not be used without full charge.
Do not use other brands of charger to charge, other types of batteries should not use the charger.
The charger contains high voltage circuits. Do not disassemble it.
During use and storage, liquid and metal crumbs should be prevented from penetrating the inside of the charger. Be
careful not to drop or impact them to avoid damage.
Never cover anything while the charger is charging.
Charging precautions
1.
2.
3.
4.
5.
6.
Precautions
Do not store cash or valuables in the suitcase.
Protective equipment such as helmets, gloves, elbow pads, and knee pads must be worn before riding to prevent accidents.
Before riding must conrm the safety and reliability of the brakes, cabinets, handlebars, wheels to avoid accidents.
Avoid riding on uneven, muddy, gravel roads, slippery roads, accumulating roads, and stairs, in case of tire explosion
and rims deformation, incuring dangerous.
Handle not allow hang anything during cycling to prevent accidental operation.
This product is suitable for riding by one person and is prohibited from carrying people.
It is not recommended to ride in the cold winter.
It is forbidden to ride on a rainy day.
Do not overload or climb more than 15 degrees.
Pregnant women, minors under the age of 15 and senior citizens over the age of 60 are prohibited from studying and
cycling.
Persons who are still under the inuence of drugs or alcohol and who have restricted mobility and reaction are
prohibited from riding.
If the rider is not suitable for cycling because of the rider's own reasons or other objective factors, riding is
prohibited.
Develop a good habit of charging in time every day. When riding each time, you must fully charge the battery
before the minimum allowable voltage in order to make the battery serve you longer. Therefore, it is very
important to develop the habit of charging in time every day.
Almost all battery types are affected by the environment. In general, when the temperature is higher, the discharge
performance of electricity is better. When the temperature drops below 0°C, the battery power may drop by more
than one third. Therefore, when the winter comes, or in cold regions, the reduction of driving distance after one-
time charging is normal. When the temperature rises above 20°C, the function will naturally recover.
When you lift the battery box, please be careful not to insert metal objects (such as wires, keys, etc.) into the
battery charging holes or the positive and negative contacts on the battery output, to avoid short circuit, re, and
personal safety problem.
It is forbidden to use chargers and other accessories that are not specially provided by the company. If an
accident occurs, the company will not be responsible for it.
Lithium batteries must not be near fire sources and should be kept away from flammable and explosive
corrosive gases.
Do not disassemble the battery box body to avoid damage to internal parts.
Do not short-circuit the positive and negative electrodes of the battery with wires or conductors to avoid danger
and damage the battery.
Lithium batteries need to be handled gently to avoid impact and fall, to prevent damage to the housing and to
avoid accidents.
If it is not used for a long time, it must be fully charged and turned off. The maximum recharge time can not
exceed 3 months from the last charge.
It is forbidden to dismantle or ret the vehicle without authorization. Our company will not bear the loss caused
by this, and it may cause you to lose the warranty.
All rights reserved in this manual shall be the property of the company.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.

- 10 -
Download APP
Scan QR code to download
*Support Android 4.3 or higher, iOS 7.0 or higher.
APP Instructions
1. Turn on SE3 power button, and start App as well as Bluetooth.
2. Click the search button and do as the follows to connect
(verify password is 11111111).
3. Refer to ofcial website or give calls for details.
Click the Intelligent scooter
in the App interface.
Click the search button
or .
Search Airwheel nearby,click
the searched Airwheel model
to connect.
Input the verify password:
11111111 to connect.
Bluetooth password authentication
cance lcomfirm
Input verify password 1111111 1
�`�r�n���p�u�$�Q�r� �v�p�r�€ A
Airwheel
Intelligent helmet
Intelligent scooter
Search Devices

- 11 -
Maintaining
Appearance cleaning
Battery maintaining
Other maintaining
Vehicles need to be cleaned at any time.
When cleaning dust, do not wipe the electrical parts and connectors with a damp cloth.
When using it, it was found that the battery was low, it need to be recharged.
When not in use, turn off the switch.
For long-term (more than three months) not in use, it is recommended to remove the battery.
Regularly or according to vehicle condition, tighten the screws to prevent loosening. If you nd that the screw nut
is loose, stop using it.
Lubricate the front and rear axles once every six months.
Check and tighten contact of electrical connectors.
Check the tires:
(1) Whether the tire pressure is normal, do not over-inate or under-inate to prevent the tire from leaking.
(2) Cracks.
Handlebar: Is the quick connector loose?
Whether the brake is workable.
1.
2.
1.
2.
3.
1.
2.
3.
4.
5.
6.
